Torque Converter Clutch Pulse Width Modulated (TCC PWM) Solenoid Valve Connector Terminal
Identification, Wiring Harness Side

3-2 Shift Solenoid (SS) Valve Assembly Connector Terminal Identification, Wiring Harness Side

A

RD

839A

Ignition 1 Voltage

B

YE

1223

2-3 Shift Solenoid Valve Control

Connector Part

Information

z

12162202

z

Conn 2-Way F M/P 150.2 P2S (BU)

Pin

Wire Color

Circuit

No.

Function

A

RD

839E

Ignition 1 Voltage

B

TN

418

Torque Converter Clutch Pulse Width Modulated Solenoid
Valve Control



2004 Hummer H2

2004 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E (Introduction) - Hummer H2



Pressure Control (PC) Solenoid Valve Connector Terminal Identification, Wiring Harness Side

Connector Part Information

z

12146094

z

Conn 2-Way F M/P 150.2 P2S (M-GY)

Pin

Wire Color

Circuit No.

Function

A

RD

839C

Ignition 1 Voltage

B

WH

687

3-2 Shift Solenoid Valve Control

Connector Part Information

z

12146800

z

Conn 2-Way F M/P 150.2 (L-GY) Delphi

Pin

Wire Color

Circuit No.

Function

A

PU

1228

Pressure Control (PC) Solenoid Valve High Control

B

L-BU

1229

PC Solenoid Valve Low Control



2004 Hummer H2

2004 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E (Introduction) - Hummer H2



Torque Converter Clutch (TCC) Solenoid Valve Connector Terminal Identification, Wiring Harness
Side

AUTOMATIC TRANSMISSION RELATED CONNECTOR END VIEWS

Vehicle Speed Sensor Assembly Connector Terminal Identification, Wiring Harness Side

Connector Part Information

z

10478128

z

CBL Solenoid Valve

Pin

Wire Color

Circuit No.

Function

A

RD

839D

Ignition 1 Voltage

B

BK

422

Torque Converter Clutch Solenoid Valve Control

Connector Part Information

z

12162194

z

Asm Conn 2F M/P 150.2 P2S (BLK)

Pin

Wire Color

Circuit No.

Function



2004 Hummer H2

2004 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E (Introduction) - Hummer H2



Transmission Range Terminal Identification Switch Connector, Wiring Harness Side

Tow/Haul Terminal Identification Switch Connector, Wiring Harness Side

1

PU/WH

821

VSS High Signal

2

L GN

/BK

822

VSS Low Signal

Connector Part Information

z

15416722 BK

z

ASM Conn 12 F GT

Pin

Wire Color

Circuit No.

Function

1

D-GN

1433

Clutch Start Switch Signal

2

-

-

Not Used

3

Plug GN

15305171

Not Used

4

YE

772

Transmission Range Switch Signal B

5

BK

771

Transmission Range Switch Signal A

6

GY

773

Transmission Range Switch Signal C

7

BK

451

Ground

8

WH

776

Transmission Range Switch Signal P

9

L-GN

275

P/N Position Switch Signal

10

GY

1524

Back-up Lamp Supply Voltage

11

PK

839

IGN 1 Voltage

12

PK

639

IGN 1 Voltage



2004 Hummer H2

2004 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E (Introduction) - Hummer H2
