C355 Terminal Identification Body Harness to Console Harness - Heated Seats w/o Class 2 Amplifier

F

PK

1631

Left Rear Heated Seat Low
Temperature Indicator Control

F

PK

1631

Left Rear Heated Seat Low
Temperature Indicator Control

G

BK/WH

1638

Left Rear Heated Seat High
Temperature Indicator Control

G

BK/WH

1638

Left Rear Heated Seat High
Temperature Indicator Control

H

BN

1637

Left Rear Heated Seat Switch
Signal

H

BN

1637

Left Rear Heated Seat Switch
Signal

Connector

Part

Information

z

15326110

z

12-Way F GT 280 (BK)

Connector

Part

Information

z

15332150

z

12-Way M GT 280 (BK)

Pin

Wire

Color

Circuit

No.

Function

Pin

Wire

Color

Circuit

No.

Function

A

BN

1634

Right Rear Heated Seat
Switch Signal - w/KA7

A

BN

1634

Right Rear Heated Seat
Switch Signal - w/KA7

B

BK/WH

1635

Right Rear Heated Seat High
Temperature Indicator Control
- w/KA7

B

BK/WH

1635

Right Rear Heated Seat High
Temperature Indicator Control
- w/KA7

C

PK

1636

Right Rear Heated Seat Low
Temperature Indicator Control
- w/KA7

C

PK

1636

Right Rear Heated Seat Low
Temperature Indicator Control
- w/KA7

D

BN

599

Left Rear Low Level Audio
Signal (+)

D

BN

599

Left Rear Low Level Audio
Signal (+)

E

D-

GN/WH

1547

Left Rear Low Level Audio
Signal (-)

E

D-

GN/WH

1547

Left Rear Low Level Audio
Signal (-)

F

D-BU

546

Right Rear Low Level Audio
Signal (+)

F

D-BU

546

Right Rear Low Level Audio
Signal (+)

Right Rear Low Level Audio

Right Rear Low Level Audio



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems (Connector End Views) - Hummer H2



C375 Terminal Identification Body Harness to Passenger Seat Harness

G

BK

1946

Signal (-)

G

BK

1946

Signal (-)

H

BARE

2099

Drain Wire

H

BARE

2099

Drain Wire

J

PK

1631

Left Rear Heated Seat Low
Temperature Indicator Control
- w/KA7

J

PK

1631

Left Rear Heated Seat Low
Temperature Indicator Control
- w/KA7

K

BK/WH

1638

Left Rear Heated Seat High
Temperature Indicator Control
- w/KA7

K

BK/WH

1638

Left Rear Heated Seat High
Temperature Indicator Control
- w/KA7

L

BN

1637

Left Rear Heated Seat Switch
Signal - w/KA7

L

BN

1637

Left Rear Heated Seat Switch
Signal - w/KA7

M

-

-

Not Used

M

-

-

Not Used

Connector

Part

Information

z

15305133

z

16-Way F GT 150 280 (BK)

Connector

Part

Information

z

15305132

z

16-Way M GT 150 280 (BK)

Pin

Wire

Color

Circuit

No.

Function

Pin

Wire

Color

Circuit

No.

Function

A

OG

1440

Battery Positive Voltage

A

OG

1440

Battery Positive Voltage

B

PK

2480

Heated Seat Cushion Element
Control - w/KA7

B

PK

2480

Heated Seat Cushion Element
Control - w/KA7

C

L-BU

2433

Passenger Heated Seat Back
Element Control - w/KA7

C

L-BU

2433

Passenger Heated Seat Back
Element Control - w/KA7

D-

F

-

-

Not Used

D-

F

-

-

Not Used

G

GY

2434

Passenger Heated Seat Back
Temperature Signal - w/KA7

G

D-BU

2434

Passenger Heated Seat Back
Temperature Signal - w/KA7

H

D-BU

2479

Passenger Heated Seat Element

H

D-BU

2479

Passenger Heated Seat Elemen
Supply Voltage - w/KA7



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems (Connector End Views) - Hummer H2



C376 Terminal Identification Body Harness to Passenger Seat Harness

C377 Terminal Identification Body Harness to Passenger Seat Harness (Heated Seats)

Supply Voltage - w/KA7

D-BU

2479

Passenger Heated Seat Elemen
Supply Voltage - w/KA7

J-P

-

-

Not Used

J-P

-

-

Not Used

R

PK

2435

Low Reference - w/KA7

R

L-BU

2435

Low Reference - w/KA7

S

BK

1250

Ground

S

BK

1250

Ground

Connector

Part

Information

z

12064752

z

6-Way F Metri-Pack 150 Series
(BK)

Connector

Part

Information

z

12064754

z

6-Way M Metri-Pack 150 Series
(BK)

Pin

Wire

Color

Circuit

No.

Function

Pin

Wire

Color

Circuit

No.

Function

A

BK

289

Passenger Seat Rear Vertical
Motor Down Control

A

L-BU

289

Passenger Seat Rear Vertical
Motor Down Control

B

RD

288

Passenger Seat Rear Vertical
Motor Up Control

B

YE

288

Passenger Seat Rear Vertical
Motor Up Control

C

BK

290

Passenger Seat Horizontal
Motor Rearward Control

C

L-GN

290

Passenger Seat Horizontal
Motor Rearward Control

D

RD

296

Passenger Seat Horizontal
Motor Forward Control

D

TN

296

Passenger Seat Horizontal
Motor Forward Control

E

BK

298

Passenger Seat Front Vertical
Motor Down Control

E

D-BU

298

Passenger Seat Front Vertical
Motor Down Control

F

RD

297

Passenger Seat Front Vertical
Motor Up Control

F

D-GN

297

Passenger Seat Front Vertical
Motor Up Control



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems (Connector End Views) - Hummer H2



C378 Terminal Identification Body Harness to Passenger Seat Harness

Connector

Part

Information

z

12064762

z

6-Way F Metri-Pack 150 Series
(GY)

Connector

Part

Information

z

12064763

z

6-Way M Metri-Pack 150 Series
(GY)

Pin

Wire

Color

Circuit

No.

Function

Pin

Wire

Color

Circuit

No.

Function

A

BN

2479

Passenger Heated Seat
Element Supply Voltage -
w/KA7

A

D-BU

2479

Passenger Heated Seat Elemen
Supply Voltage - w/KA7

B

BK

2434

Passenger Heated Seat Back
Temperature Signal - w/KA7

B

D-BU

2434

Passenger Heated Seat Back
Temperature Signal - w/KA7

C

YE

2479

Passenger Heated Seat
Element Supply Voltage -
w/KA7

C

D-BU

2479

Passenger Heated Seat Elemen
Supply Voltage - w/KA7

D

BK

2424

Passenger Heated Seat Back
Element Control - w/KA7

D

L-BU

2424

Passenger Heated Seat Back
Element Control - w/KA7

E

BK/RD

2435

Low Reference - w/KA7

E

L-BU

2435

Low Reference - w/KA7

F

BK

2480

Heated Seat Cushion Element
Control - w/KA7

F

PK

2480

Heated Seat Cushion Element
Control - w/KA7



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems (Connector End Views) - Hummer H2
