C333 Terminal Identification Driver Seat Harness

Connector

Part

Information

z

12064762

z

6-Way F Metri-Pack 150 Series
(GY)

Connector

Part

Information

z

12064763

z

6-Way M Metri-Pack 150 Series
(GY)

Pin

Wire

Color

Circuit

No.

Function

Pin

Wire

Color

Circuit

No.

Function

A

BN

2077

Heated Seat Cushion Element
Supply Voltage - w/KA7

A

RD/WH

2077

Heated Seat Cushion Element
Supply Voltage - w/KA7

B

BK/RD

2425

Driver Heated Seat Back
Temperature Sensor Signal -
w/KA7

B

D-BU

2425

Driver Heated Seat Back
Temperature Sensor Signal -
w/KA7

C

YE

2432

Driver Heated Seat Back
Element Supply Voltage -
w/KA7

C

BN

2432

Driver Heated Seat Back
Element Supply Voltage -
w/KA7

D

BK

2424

Driver Heated Seat Back
Element Control - w/KA7

D

PU

2424

Driver Heated Seat Back
Element Control - w/KA7

E

BK/RD

2426

Driver Heated Seat Back
Temperature Sensor Low
Reference - w/KA7

E

PK

2426

Driver Heated Seat Back
Temperature Sensor Low
Reference - w/KA7

F

BK

2078

Heated Seat Cushion Element
Control - w/KA7

F

L-GN

2078

Heated Seat Cushion Element
Control - w/KA7



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems (Connector End Views) - Hummer H2



C350 Terminal Identification I/P Harness to Console Harness

Connector

Part

Information

z

12064998

z

8-Way F Metri-Pack 280 Series
(BK)

Connector

Part

Information

z

15358651

z

8-Way M Metri-Pack 280 Serie
(BK)

Pin

Wire

Color

Circuit

No.

Function

Pin

Wire

Color

Circuit

No.

Function

A

PU/WH

611

Driver Seat Lumbar Motor
Forward Control

A

D-BU

611

Driver Seat Lumbar Motor
Forward Control

B

L-BU

1063

Driver Seat Lumbar
Horizontal Position Sensor
Signal

B

YE/BK

1063

Driver Seat Lumbar
Horizontal Position Sensor
Signal

C

BN

5287

Voltage Reference

C

WH

5287

Voltage Reference

BN

5287

Voltage Reference

D

TN/WH

1258

Driver Seat Torso Bolster Out
Control

D

PU

1258

Driver Seat Torso Bolster Ou
Control

E

PK/BK

1257

Driver Seat Torso Bolster In
Control

E

YE

1257

Driver Seat Torso Bolster In
Control

F

D-

BU/WH

5288

Low Reference

F

BN/WH

5288

Low Reference

D-

BU/WH

5288

Low Reference

G

PU/WH

5700

Driver Seat Torso Bolster
Position Sensor Signal

G

PU

5700

Driver Seat Torso Bolster
Position Sensor Signal

H

D-

BU/WH

610

Driver Seat Lumbar Motor
Rearward Control

H

PK

610

Driver Seat Lumbar Motor
Rearward Control



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems (Connector End Views) - Hummer H2



Connector Part

Information

z

15317325

z

22-Way F GT 150 280 (L-
GY)

Connector

Part

Information

z

15317322

z

22-Way M GT 150 280 (L-GY

Pin

Wire

Color

Circuit

No.

Function

Pin

Wire

Color

Circuit

No.

Function

A1

BN/WH

230

Instrument Panel Lamps
Dimming Control

A1

BN/WH

230

Instrument Panel Lamps
Dimming Control

A2

L-

GN/BK

584

Park Lock Control
Solenoid Supply Voltage

A2

L-

GN/BK

584

Park Lock Control Solenoid
Supply Voltage

A3

OG

340

Battery Positive Voltage

A3

OG

340

Battery Positive Voltage

A4

OG

1040

Battery Positive Voltage

A4

OG

1040

Battery Positive Voltage -
Accessory Power Outlet -
Console - Left

OG

1040

Battery Positive Voltage -
Accessory Power Outlet -
Console - Right

A5

-

-

Not Used

A5

-

-

Not Used

A6

BK

1050

Ground

A6

BK

1050

Ground

A7

-

-

Not Used

A7

-

-

Not Used

A8

D-

GN/WH

1547

Left Rear Low Level
Audio Signal (-)

A8

D-

GN/WH

1547

Left Rear Low Level Audio
Signal (-)

A9

D-BU

546

Right Rear Low Level
Audio Signal (+)

A9

D-BU

546

Right Rear Low Level Audio
Signal (+)

A10

L-BU

2288

LGM Class 2 Serial Data

A10

L-BU

2288

LGM Class 2 Serial Data

A11

BN

599

Left Rear Low Level
Audio Signal (+)

A11

BN

599

Left Rear Low Level Audio
Signal (+)

B1

PK

1020

Ignition 0 Voltage

B1

PK

1020

Ignition 0 Voltage

B2

D-

GN/WH

1135

A/T Shift Lock Control
Solenoid Supply Voltage

B2

D-

GN/WH

1135

A/T Shift Lock Control
Solenoid Supply Voltage

Remote Shift Selector



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems (Connector End Views) - Hummer H2



C355 Terminal Identification Body Harness to Console Harness - Heated Seats w/Class 2 Amplifier

B3

YE

1996

Signal

B3

YE

1996

Remote Shift Selector Signa

B4-

B5

-

-

Not Used

B4-

B5

-

-

Not Used

B6

BK/WH

1851

Ground

B6

BK/WH

1851

Ground

B7

-

-

Not Used

B7

-

-

Not Used

B8

BK

1946

Right Rear Low Level
Audio Signal (-)

B8

BK

1946

Right Rear Low Level Audio
Signal (-)

B9-

B10

-

-

Not Used

B9-

B10

-

-

Not Used

B11

-

2099

Drain Wire w/o Class 2
Amplifier

B11

-

2099

Drain Wire w/o Class 2
Amplifier

Connector

Part

Information

z

15332145

z

8-Way F GT 150 (BK)

Connector

Part

Information

z

15332150

z

8-Way M GT 150 (BK)

Pin

Wire

Color

Circuit

No.

Function

Pin

Wire

Color

Circuit

No.

Function

A

BN

1634

Right Rear Heated Seat
Switch Signal - w/KA7

A

BN

1634

Right Rear Heated Seat
Switch Signal - w/KA7

B

BK/WH

1635

Right Rear Heated Seat High
Temperature Indicator Control
- w/KA7

B

BK/WH

1635

Right Rear Heated Seat High
Temperature Indicator Control
- w/KA7

C

PK

1636

Right Rear Heated Seat Low
Temperature Indicator Control
- w/KA7

C

PK

1636

Right Rear Heated Seat Low
Temperature Indicator Control
- w/KA7

D-

E

-

-

Not Used

D-

E

-

-

Not Used
