Fig. 23: G308 Component View
Courtesy of GENERAL MOTORS CORP.

Callouts For Fig. 23

Callout

Component Name

1

G308

2

Body Mount - RH

3

Chassis Harness



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems (Component List) - Hummer H2



Fig. 24: G310 Component View
Courtesy of GENERAL MOTORS CORP.

Callouts For Fig. 24

Callout

Component Name

1

Body Mount - LH

2

G310

3

Chassis Harness



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems (Component List) - Hummer H2



Fig. 25: G401 Component View
Courtesy of GENERAL MOTORS CORP.

Callouts For Fig. 25

Callout

Component Name

1

G401

2

Body Mount - LH

3

Fuel Tank Filler Ground

4

Chassis Harness



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems (Component List) - Hummer H2



Fig. 26: G405 Component View
Courtesy of GENERAL MOTORS CORP.

Callouts For Fig. 26

Callout

Component Name

1

Chassis Harness

2

G405

3

Body Mount - RH

4

Air Suspension Inflator Switch Connector
