 Electrical System  12-205

®

05745159

4 WAY HVAC BLOWER RESISTOR HARNESS  LOCATION: RIGHT A-PILLAR

3 WAY  LOCATION: LEFT A-BEAM NEAR FUEL MANAGER

9-S12-104

9-S12-103

C 37 MALE

C 37 FEMALE

A

A

B

B

C

C

D

D

PIN

CKT

COLOR

DESCRIPTION

A

754

YL

Blower activation

B

751

OR

Medium 1 blower

C

755

DB

Low blower

D

752

GY

Medium 2 blower

9-S12-151

9-S12-152

C 38 FEMALE

C 38 MALE

PIN

CKT

COLOR

DESCRIPTION

A

206

WH

Trailer connector ground

B

58

BK

 Ambient temp sensor ground

C

59

BK

Main and auxiliary fuel sending units, rear lamps ground

4-1-00

12-206

Electrical System

______________________________________________________

®

7 WAY TURN SIGNAL SWITCH HARNESS LOCATION: STEERING COLUMN

6 WAY TURN SIGNAL SWITCH HARNESS LOCATION: STEERING COLUMN

PIN

CKT

COLOR

DESCRIPTION

A

3

LB

Left front turn signal, status center signal.

B

9

YL

Left rear turn signal

C

1

DB

Horn circuit ground

D

13

TN

Low beam circuit

E

12

OR

High beam signal

F

15

WH

Head lamp feed

G

Empty

PIN

CKT

COLOR

DESCRIPTION

A

385

TN

Hazard signal ground

B

22

RD

Brake lamp switch signal (receives 12v with brakes applied.)

C

460

BK

Ground

D

44

LB

Indicator signal ground

E

2

LG

Right turn signal, status center signal

F

5

DG

Right rear turn signal

00-S12-014

     C 39 FEMALE

B

C

D

E

F

A

G

00-S12-013

   C 40 FEMALE

A

B

C

D

E

F

4-1-00

_____________________________________________________

 Electrical System  12-207

®

05745159

8 WAY LIFT GATE JUMPER HARNESS LOCATION:

4 WAY SLANT DOOR WIPER PLUG TOP OF SLANT DOOR BEHIND TRIM.

PIN

CKT

COLOR

DESCRIPTION

A

59

BK

Ground G4

B

66

RD

Rear wiper 12 v common supply

C

64

LG

Rear wiper 12 v start supply

D

62

LB

Rear wiper 12 v run supply

E

118

BR

Unlock/lock signal to power door lock motor

F

117

PK

Lock/unlock signal to power door lock motor

G

Empty

H

Empty

PIN

CKT

COLOR

DESCRIPTION

A

59

BK

Ground G4

B

66

RD

Rear wiper 12 v Common Supply

C

64

LG

Rear wiper 12 v Start Supply

D

62

LB

Rear wiper 12 v Run Supply

9-S12-035

C 41 MALE

C41 FEMALE

9-S12-036

D

A

E

H

H

A

E

D

C 42 MALE

C 42 FEMALE

00-S12-019

00-S12-020

A

C

D

B

A

B

C

D

4-1-00

12-208

Electrical System

______________________________________________________

®

3 WAY FRONT WIPER HARNESS NEAR MOTOR BEHIND A-PILLAR TRIM

2 WAY WIPER MOTOR CONNECTOR NEAR MOTOR BEHIND THE A-PILLAR TRIM

PIN

CKT

COLOR

DESCRIPTION

A

28

DB

Intermittent Power Supply

B

63

DG

Low Speed Power Supply

C

61

RD

High Speed Power Supply

PIN

CKT

COLOR

DESCRIPTION

A

59

BR

Ground G4

B

65

BK

Intermittent Start Supply

C 43 MALE

C 43 FEMALE

9-S12-155

A

B

C

A

B

C

C 44 MALE

C 44 FEMALE

9-S12-156

A

B

B

A

4-1-00
