 Electrical System  12-197

®

05745159

D6

570

BK

Ground G2

D7

570

BK

Ground G2

D8

D9

D10

D11

714

RD

Check throttle lamp control

D12

D13

537

OR

Battery

D14

154

TN

Waste gate solenoid control

D15

D16

PIN

CKT

COLOR

DESCRIPTION

4-1-00

12-198

Electrical System

______________________________________________________

®

24 WAY PCM-BROWN  LOCATION: CENTER CONSOLE, PCM

PIN

CKT

CKT

DESCRIPTION

A1

491

BK

Closure ground

A2

703

OR

High resolution sensor signal

A3

565

BR

Transmission output speed sensor/VSS

A4

442

BR

Cam sensor signal

A5

349

YL

Crankshaft position sensor signal

A6

223

DB

Vehicle speed sensor

A7

709

DB

Injection timing stepper motor (HI)

A8

708

TN

Injection timing stepper motor (LO)

A9

710

OR

Injection timing stepper motor (LO)

A10

711

YL

Injection timing stepper motor (HI)

A11

151

GY

Cruise control on/off signal

A12

722

PP

APP (2) ground

B1

719

BR

APP (1) ground

B2

718

DB

APP (1) signal

B3

351

PK

Front axle switch signal + from jumper

B4

764

PP

B5

763

DB

B6

762

OR

B7

PTO (1360 rpm) user installed

B8

PTO (1070 rpm) user installed

B9

810

PP

Cruise control brake switch

B10

22

RD

TCC brake switch

B11

152

DB

Cruise control set/coast signal

B12

359

BK

Boost, engine temp, intake air temp, trans temp sensor ground

9-S12-028

A1

A12

B1

A12

C29 MALE

4-1-00

_____________________________________________________

 Electrical System  12-199

®

05745159

8 WAY REMOTE ENTRY, GRAY  LOCATION: CENTER CONSOLE

PIN

CKT

COLOR

DESCRIPTION

A

58

BK

Module ground G4

B

C

D

53

LB

Dome lamp activation

E

1

DB

Horn Activation

F

840

DG

Fused ignition input to the remote entry module

G

554

GY

Fused battery input to the remote entry module

H

14

LB

Parking lamps activation

9-S12-026

A

H

D

E

C30 FEMALE

4-1-00

12-200

Electrical System

______________________________________________________

®

8 WAY REMOTE ENTRY, BLACK  LOCATION: CENTER CONSOLE

9-S12-036

A

D

H

E

C31 FEMALE

PIN

CKT

COLOR

DESCRIPTION

A

118

BR

Lock signal to the door lock actuators

B

122

PP

Lock signal from the switch to the module

C

D

517

OR

Fused battery input

E

117

PK

Unlock signal to the door lock actuators

F

121

YL

Unlock signal from the switch to the module

G

117

PK

Unlock signal to the drivers door lock actuator

H

121

YL

Unlock signal from the switch to the module

4-1-00
