Honda HR-V (2024 year). Manual in english

289

Audio System Basic Operation

Playing a USB Flash Drive

Features

You can select repeat, and random modes when playing a file.

■

Random/Repeat

Repeatedly select the random or repeat icon
until you find a play mode option of your
preference.

■

To turn off a play mode

Select the mode you want to turn off.

■

How to Select a Play Mode

How to Select a Play Mode

Play Mode Menu Items

Random

Random off:

Random mode to off.

Random All Tracks:

Plays all files in random

order.

Random in Folder:

Plays all files in the current

folder in random order.

Repeat

Repeat off:

Repeat mode to off.

Repeat track:

Repeats the current file.

Repeat folder:

Repeats all files in the current

folder.

Repeat Icon
Random Icon

290

Audio System Basic Operation

Playing

Bluetooth

Audio

Features

Playing

Bluetooth

Audio

Your audio system allows you to listen to music from your

Bluetooth

-compatible

phone.
This function is available when the phone is paired and connected to the vehicle’s

Bluetooth

HandsFreeLink

(HFL) system.

P. 384

Not all

Bluetooth

-enabled phones with streaming

audio capabilities are compatible with the system.
For a list of compatible phones:

•

U.S.: Visit

automobiles.honda.com/handsfreelink/

or call 1-888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-855-490-7351.

It may be illegal to perform some data device
functions while driving.

Only one phone can be used with HFL at a time.
When there is more than one paired phone in the
vehicle, the system automatically connects to the
prioritized phone. You can assign priority to a phone
in the

Bluetooth

device list.

Phone Setup

P. 384

The connected phone for

Bluetooth

Audio can be

different.

If more than one phone is paired to the HFL system,
there may be a delay before the system begins to play.

In some cases, the name of the artist, album, or track
may not appear correctly.

Some functions may not be available on some devices.

If a phone is currently connected via Apple CarPlay or
Android Auto,

Bluetooth

Audio from that phone is

unavailable. However, a second previously paired
phone can stream

Bluetooth

Audio by selecting

from the

Bluetooth

device list.

Phone Setup

P. 384

Audio/Information Screen

Browse Icon

Select to display the menu items.

Play/Pause Icon

Bluetooth

Indicator

Appears when your phone

is connected to HFL.

Track Icons

Select

to change tracks.

Select and hold to move rapidly

within a track.

Repeat Icon

Select to repeat the

current track.

(Back) Button

Press to go back

to the previous

display.

VOL/

AUDIO

(Volume/Power) Knob

Press to turn the audio

system on and off.
Turn to adjust the

volume.

Shuffle Icon

Select to play all files

in the current

category in random

order.

Continued

291

Audio System Basic Operation

Playing

Bluetooth

Audio

Features

Make sure that your phone is paired and
connected to the system.

Phone Setup

P. 384

Select the

Bluetooth

Audio mode.

If the phone is not recognized, another HFL-
compatible phone, which is not compatible
for

Bluetooth

Audio, may already be

connected.

■

To play or pause a file

Select the play/pause icon.

Select

Browse

Select a search category (e.g., Albums).

Select an item.

The selection begins playing.

■

To Play

Bluetooth

Audio Files

To Play

Bluetooth

Audio Files

To play the audio files, you may need to operate your
phone. If so, follow the phone maker’s operating
instructions.

Switching to another mode pauses the music playing
from your phone.

You can change the connected phone by selecting

Change Device

Phone Setup

P. 384

■

Searching for Music

Searching for Music

Depending on the

Bluetooth

device you connect,

some or all of the lists may not be displayed.

Audio System Basic Operation

Playing

Bluetooth

Audio

292

Features

You can select shuffle and repeat modes when playing a file.

■

Shuffle/Repeat

Repeatedly select the shuffle or repeat icon
until you find a play mode option of your
preference.

■

To turn off a play mode

Select the mode you want to turn off.

■

How to Select a Play Mode

How to Select a Play Mode

Play Mode Menu Items

Shuffle

Shuffle off:

Shuffle mode to off.

Shuffle All Songs:

Plays all available songs in a

selected list in random order.

Repeat

Repeat off:

Repeat mode to off.

Repeat Song:

Repeats the current song.

Repeat Group:

Repeats the current group.

Repeat all:

Repeats the all songs.

Depending on the

Bluetooth

device you connect,

some or all of the functions may not be displayed.

Repeat Icon
Shuffle Icon

293

Audio System Basic Operation

HondaLink

Continued

Features

HondaLink

HondaLink

connects you to the latest information from Honda. You can connect

your phone wirelessly through Wi-Fi or

Bluetooth

Wi-Fi Connection

P. 300

Phone Setup

P. 384

■

Connect

Displays the connection status of the vehicle.

■

Help & Support

Displays tips for vehicle usage, and get support via roadside or customer service
center.

■

Message

Displays helpful and important information from Honda.

■

HondaLink

Menu

HondaLink

The HondaLink

connect app is compatible with most

iPhone and Android phones.

Some cell phone carriers charge for tethering and
smartphone data use. Check your phone’s data
subscription package.

If there is an active connection to Apple CarPlay or
Android Auto, HondaLink

can only be connected

through Wi-Fi.

294

Audio System Basic Operation

HondaLink

Features

Use the following procedure to connect to HondaLink

service.

■

To enable the HondaLink

service

Press the

button.

Select

General Settings

Select

System

Select

Data Sharing Setting

Select

■

To link with HondaLink

You can see the connection guide screen after
launching HondaLink

when there is no

connection to a network. If you do not need
this guide, select check-box and select

■

To Set Up to Connect HondaLink

Service

297

Audio System Basic Operation

Smart Shortcuts

Continued

Features

Smart Shortcuts

By observing and learning driver behaviors, patterns, and preferences, the system
anticipates driver actions and presents on-screen suggestions to help perform
desired actions quicker and with fewer steps.

•

The app will suggest actions based on what it learns you do often, and
occasionally make recommendations based on your learned preferences.

•

The system will take some time to learn. The more you interact with the system,
the more suggestion you will see, and the more accurate they will become.

•

Suggestions will automatically refresh periodically to provide updated content for
each profile.

•

You can also provide feedback on whether a suggestion is helpful by pressing and
holding on it. This can help the app grow smarter over time.

•

To change the notifications behavior for Smart Shortcuts:

Select

Options

on the

Smart Shortcuts

screen.

Select

Suggestion Settings

Select an option.

•

All data used for Smart Shortcuts can be erased by a

Factory Data Reset

Defaulting All the Settings

P. 358

Smart Shortcuts

The app also supports different profiles for each user,
with customized learning for each profile. The app
will also learn to associate a profile to a user over time
based on key fob and connected phone data.

Smart Shortcuts

Screen

Shortcut Suggestion

Audio System Basic Operation

Smart Shortcuts

298

Features

Press the

button.

Select

Smart Shortcuts

Select a shortcut to take the action
suggested.

•

Call Suggestions:

When selected, a call to the contact or number suggested will

be placed and shown. Based on your calling patterns, contacts will be suggested
for you to call.

Connect your smartphone through

Bluetooth

to get contact suggestions.

Call suggestions will not be displayed when you are connected to Apple
Carplay.

•

Navigation Suggestions

When selected, a route will be started to the

suggested destination and the embedded navigation app will open.

When a long route is set in your navigation system, you can receive
recommendations for gas stations and places to stop at along the way.

The places you frequently navigate to while using the embedded navigation
system will be suggested as shortcuts.

Save your home location in the embedded navigation app to have a shortcut
suggestion for it when you’re away from home.

■

How to Use

How to Use

You can change the profile by selecting

on the

top of the

Smart Shortcuts

screen.

You can customize the following items by selecting

Options

on the top of the

Smart Shortcuts

screen.

•

Profiles

: Create, change, and manage profiles.

•

View App Walkthrough

: View the Smart

Shortcuts walkthrough.

•

Suggestion Settings

: Change where suggestions

can appear.

To create a profile:

1. Select

Options

on the

Smart Shortcuts

screen.

2. Select

Profiles

3. Select

Manage Profiles

4. Select

+ Add New Profile

5. Enter name for your profile.
6. Select

Done

A new profile has been created and the Smart App

will automatically switch to that profile.

To change a profile:

1. Select

Options

on the

Smart Shortcuts

screen.

2. Select

Profiles

3. Select

Change Current Profile

4. Select a profile from the list.

The change to the selected profile has been made.

* Not available on all models

299

Audio System Basic Operation

Smart Shortcuts

Features

•

Radio Suggestions:

When selected, the corresponding radio app (FM, AM, or

SiriusXM

) will open and it will start playing the station.

From radio apps you can receive:
- FM, AM, SiriusXM

: Most frequently listened stations you may like to play

next.
- FM, SiriusXM

: Genre-based suggestions.

Considerations:
- FM suggestions will appear only when they are within range, according to
your vehicle’s tuner signal.
- SiriusXM

suggestions will be available as long as there is an active account in

the vehicle.

300

Audio System Basic Operation

Wi-Fi Connection

Features

Wi-Fi Connection

This vehicle is equipped with Wi-Fi connectivity. You can connect to an external Wi-
Fi hotspot or communication device.

Press the

button.

Select

General Settings

Select

Connections

Select

Wi-Fi

Select

Select an access point from the network list.

To connect to a hotspot that is not
automatically detected, select

Options

then

Add Network

Enter the password.

If you check the

Use this network to

automatically download system
updates

box, you can set the network to

be used for system updates.

System Updates

P. 257

Select

Connect

■

Turning off the Wi-Fi connection

Select

Change Mode

Select

OFF

■

Connect the Vehicle to a Wi-Fi Hotspot

Wi-Fi Connection

Wi-Fi and Wi-Fi Direct are registered trademarks of
Wi-Fi Alliance

Connect the Vehicle to a Wi-Fi Hotspot

You cannot go through the setting procedure while
the vehicle is moving. Park in a safe place to set the
audio system in Wi-Fi mode.

Some cell phone carriers charge for tethering and
smartphone data use. Check your phone’s data
subscription package.

Check your phone manual to find out if the phone
has Wi-Fi connectivity.

You can confirm whether Wi-Fi connection is on or
off with the

icon on the system status area.

Transmission speed and others will not be displayed
on this screen.

301

Audio System Basic Operation

Apple CarPlay

Continued

Features

Apple CarPlay

If you connect an Apple CarPlay-compatible iPhone to the system via the USB port
or wirelessly, you can use the audio/information screen, instead of the iPhone
display, to make a phone call, listen to music, view maps (navigation), and access
messages.

USB Ports

P. 213

■

Apple CarPlay Menu

Apple CarPlay

Only iPhone 5 or newer versions with iOS 8.4 or later
are compatible with Apple CarPlay.

We recommend using the latest OS.

Park in a safe place before connecting your iPhone to
Apple CarPlay and when launching any compatible
apps.

To directly access the Apple CarPlay phone function,
select

Phone

on the home screen. While connected

to Apple CarPlay, calls are only made through Apple
CarPlay. If you want to make a call with
HandsFreeLink, turn Apple CarPlay OFF.

Setting Up Apple CarPlay

P. 303

When your iPhone is connected to Apple CarPlay, it is
not possible to use the

Bluetooth

Audio or

Bluetooth

HandsFreeLink

. However, other

previously paired phones can stream audio via

Bluetooth

while Apple CarPlay is connected.

Phone Setup

P. 384

Apple CarPlay and Android Auto cannot run at the
same time.

For details on countries and regions where Apple
CarPlay is available, as well as information pertaining
to function, refer to the Apple homepage.

Go back to the

home screen

Home screen

Apple CarPlay icon

Apple CarPlay menu screen

: Go back to the

Apple CarPlay

Dashboard screen

: Go back to the

Apple CarPlay menu

screen

Audio System Basic Operation

Apple CarPlay

302

Features

•

Phone

Access the contact list, make phone calls, or listen to voicemail.

•

Messages

Check and reply to text messages, or have messages read to you.

•

Music

Play music stored on your iPhone.

•

Maps

Display Apple Maps and use the navigation function just as you would on your
iPhone.

Only one navigation system (pre-installed navigation or Apple CarPlay) can give
directions at a time. When you are using one system, directions to any prior
destination set on the other system will be canceled, and the system you are
currently using will direct you to your destination.

Apple CarPlay

Apple CarPlay Operating Requirements &
Limitations

Apple CarPlay requires a compatible iPhone with an
active cellular connection and data plan. Your
carrier’s rate plans will apply.

Changes in operating systems, hardware, software,
and other technology integral to providing Apple
CarPlay functionality, as well as new or revised
governmental regulations, may result in a decrease or
cessation of Apple CarPlay functionality and services.
Honda cannot and does not provide any warranty or
guarantee of future Apple CarPlay performance or
functionality.

It is possible to use 3rd party apps if they are
compatible with Apple CarPlay. Refer to the Apple
homepage for information on compatible apps.

Models with navigation system

Continued

303

Audio System Basic Operation

Apple CarPlay

Features

After you have connected your iPhone to the system via the USB port or wirelessly,
use the following procedure to set up Apple CarPlay. Use of Apple CarPlay will result
in the transmission of certain user and vehicle information (such as vehicle location,
speed, and status) to your iPhone to enhance the Apple CarPlay experience. You will
need to consent to the sharing of this information on the audio/information screen.

Connect the iPhone to the USB port using the USB cable.

USB Ports

P. 213

The confirmation screen will be displayed.

Select

Yes

If you do not want to connect Apple CarPlay, select

You may change the consent settings under the

Smartphone Connection

settings

menu.

■

Setting Up Apple CarPlay

■

Connecting Apple CarPlay Using the USB Cable to the USB Port

Setting Up Apple CarPlay

Only initialize Apple CarPlay when you are safely
parked.
When Apple CarPlay first detects your iPhone, you
will need to set up your iPhone. Refer to the
instruction manual that came with your iPhone.

You can use the following procedure to disconnect or
delete the devices connecting Apple CarPlay:
Press the

button



Select General Settings



Smartphone Connection



Apple CarPlay



Select device

Use of user and vehicle information

The use and handling of user and vehicle information
transmitted to/from your iPhone by Apple CarPlay is
governed by the Apple iOS terms and conditions and
Apple’s Privacy Policy.

304

Audio System Basic Operation

Apple CarPlay

Features

■

Connect Apple CarPlay wirelessly on the home screen

Press the

button.

Select

Smartphone Connection

Select

+ Connect New Device

Pair the iPhone to the vehicle’s

Bluetooth

HandsFreeLink

(HFL) system.

Phone Setup

P. 384

Select

Yes

If your iPhone asks for permission to accept an Apple CarPlay connection,
accept to connect. A confirmation message for HondaLink Assist appears.

Select

Yes

■

Connect Apple CarPlay wirelessly on the Apple CarPlay device list

Press the

button.

Select

General Settings

Select

Smartphone Connection

Select

Apple CarPlay

Select

+ Connect New Device

Pair the iPhone to the vehicle’s

Bluetooth

HandsFreeLink

(HFL) system.

Phone Setup

P. 384

Select

Yes

If your iPhone asks for permission to accept an Apple CarPlay connection,
accept to connect. A confirmation message for HondaLink Assist appears.

Select

Yes

■

Connect Apple CarPlay Wirelessly

305

Audio System Basic Operation

Apple CarPlay

Continued

Features

■

Connect Apple CarPlay wirelessly on the

Bluetooth

device list

Press the

button.

Select

General Settings

Select

Connections

Select

Bluetooth

Select

+ Connect New Device

Pair the iPhone to the vehicle’s

Bluetooth

HandsFreeLink

(HFL) system.

Phone Setup

P. 384

Check the box on

Apple CarPlay

If you select

Apple CarPlay

, you cannot select

Audio

and

Phone

Select

Connect

Select

Yes

If your iPhone asks for permission to accept an Apple CarPlay connection,
accept to connect. A confirmation message for HondaLink Assist appears.

10.

Select

Yes

■

Connect Apple CarPlay wirelessly with the steering wheel

Press and hold the

(talk) button on the steering wheel.

Pair the iPhone to the vehicle’s

Bluetooth

HandsFreeLink

(HFL) system.

Phone Setup

P. 384

Check the box on

Apple CarPlay

If you select

Apple CarPlay

, you cannot select

Audio

and

Phone

Select

Connect

Select

Yes

If your iPhone asks for permission to accept an Apple CarPlay connection,
accept to connect. A confirmation message for HondaLink Assist appears.

Select

Yes

306

Audio System Basic Operation

Apple CarPlay

Features

■

Connect Apple CarPlay wirelessly at start-up (when there is no phone
paired to the system)

Set the power mode to ACCESSORY or ON.

Select

If there is no registered device, the

Bluetooth

pairing screen will be displayed.

If you check the box with

Do not show this again

, this screen will not be

displayed.

Pair the iPhone to the vehicle’s

Bluetooth

HandsFreeLink

(HFL) system.

Phone Setup

P. 384

Check the box on

Apple CarPlay

If you select

Apple CarPlay

, you cannot select

Audio

and

Phone

Select

Connect

Select

Yes

If your iPhone asks for permission to accept an Apple CarPlay connection,
accept to connect. A confirmation message for HondaLink Assist appears.

Select

Yes

307

Audio System Basic Operation

Apple CarPlay

Features

Press and hold the

(talk) button to activate Siri.

■

Operating Apple CarPlay with Siri

Operating Apple CarPlay with Siri

Below are examples of questions and commands for
Siri.

•

What movies are playing today?

•

Call dad at work.

•

What song is this?

•

How’s the weather tomorrow?

•

Read my latest email.

•

Find a table for four tonight in Chicago.

For more information, please visit

www.apple.com/ios/siri

(Talk) button:

Press and hold to activate Siri.
Press again to deactivate Siri.
Press and release to activate

standard voice recognition system.

308

Audio System Basic Operation

Android Auto

Features

Android Auto

When you connect an Android phone to the audio system via the USB port or
wirelessly, Android Auto is automatically initiated. When connected via Android
Auto, you can use the audio/information screen to access the Phone, Google Maps
(Navigation), and Google Now functions. When you first use Android Auto, a
tutorial will appear on the screen.
We recommend that you complete this tutorial while safely parked before using
Android Auto.

USB Ports

P. 213

Auto Pairing Connection

P. 309

•

Maps

Display Google Maps and use the navigation function just as you would with your
Android phone. When the vehicle is in motion, it is not possible to make keyboard
entries. Stop the vehicle in a safe location to undertake a search or provide other
inputs.

■

Android Auto Menu

Android Auto

We recommend that you update Android OS to the
latest version when using Android Auto.

Bluetooth

A2DP cannot be used while your phone is

connected to Android Auto.

To use Android Auto on a smartphone with Android
9.0 (Pie) or earlier, you need to download the
Android Auto app from Google Play to your
smartphone.

Park in a safe place before connecting your Android
phone to Android Auto and when launching any
compatible apps.

When your Android phone is connected to Android
Auto, it is not possible to use the

Bluetooth

Audio.

However, other previously paired phones can stream
audio via

Bluetooth

while Android Auto is

connected.

Phone Setup

P. 384

Apple CarPlay and Android Auto cannot run at the
same time.

Android Auto is a trademark of Google LLC.

Android Auto menu screen

Home screen

Android Auto icon

Go back to the

home screen

Go back to the Android

Auto menu screen

Continued

309

Audio System Basic Operation

Android Auto

Features

•

Phone

Make and receive phone calls as well as listen to voicemail.

•

Exit

•

Operate Android Auto with your voice.

•

You can check Android notifications.

•

(Android Auto Home)

Display useful information organized by Android Auto into simple cards that
appear just when they’re needed.

When you connect an Android phone to the unit via the USB port or wirelessly,
Android Auto is automatically initiated.

■

Auto Pairing Connection

Android Auto

For details on countries and regions where Android
Auto is available, as well as information pertaining to
function, refer to the Android Auto homepage.

Screens may differ depending on the version of the
Android Auto app you are using.

Android Auto Operating Requirements &
Limitations

Android Auto requires a compatible Android phone
with an active mobile connection and data plan. Your
carrier’s rate plans will apply.

Changes in operating systems, hardware, software,
and other technology integral to providing Android
Auto functionality, as well as new or revised
governmental regulations, may result in a decrease or
cessation of Android Auto functionality and services.
Honda cannot and does not provide any warranty or
guarantee of future Android Auto performance or
functionality.

It is possible to use 3rd party apps if they are
compatible with Android Auto. Refer to the Android
Auto homepage for information on compatible apps.

Audio System Basic Operation

Android Auto

310

Features

Connect the Android phone to the USB port using the USB cable.

USB Ports

P. 213

The confirmation screen will be displayed.

Select

Yes

If you do not want to connect Android Auto, select

You may change the consent settings under the

Smartphone Connection

settings

menu.

■

Connect Android Auto wirelessly on the home screen

Press the

button.

Select

Smartphone Connection

Select

+ Connect New Device

Pair the Android phone to the vehicle’s

Bluetooth

HandsFreeLink

(HFL) system.

Phone Setup

P. 384

Select

Yes

If your Android phone asks for permission to accept an Android Auto
connection, accept to connect. A confirmation message for HondaLink Assist
appears.

Select

Yes

■

Connecting Android Auto Using the USB Cable to the USB Port

■

Connect Android Auto Wirelessly

Connecting Android Auto Using the USB Cable to the USB Port

Only initialize Android Auto when you are safely
parked. When Android Auto first detects your phone,
you will need to set up your phone so that auto
pairing is possible. Refer to the instruction manual
that came with your phone.

You can use the following procedure to disconnect or
delete the devices connecting Android Auto after you
have completed the initial setup:
Press the

button



Select General Settings



Smartphone Connection



Android Auto



Select device

Use of user and vehicle information

The use and handling of user and vehicle information
transmitted to/from your phone by Android Auto is
governed by the Google’s Privacy Policy.

311

Audio System Basic Operation

Android Auto

Continued

Features

■

Connect Android Auto wirelessly on the Android Auto device list

Press the

button.

Select

General Settings

Select

Smartphone Connection

Select

Android Auto

Select

+ Connect New Device

Pair the Android phone to the vehicle’s

Bluetooth

HandsFreeLink

(HFL) system.

Phone Setup

P. 384

Select

Yes

If your Android phone asks for permission to accept an Android Auto
connection, accept to connect. A confirmation message for HondaLink Assist
appears.

Select

Yes

■

Connect Android Auto wirelessly on the

Bluetooth

device list

Press the

button.

Select

General Settings

Select

Connections

Select

Bluetooth

Select

+ Connect New Device

Pair the Android phone to the vehicle’s

Bluetooth

HandsFreeLink

(HFL) system.

Phone Setup

P. 384

Check the box on

Android Auto

If you select

Android Auto

, you cannot select

Audio

and

Phone

Select

Connect

Select

Yes

If your Android phone asks for permission to accept an Android Auto
connection, accept to connect. A confirmation message for HondaLink Assist
appears.

10.

Select

Yes

312

Audio System Basic Operation

Android Auto

Features

■

Connect Android Auto wirelessly with the steering wheel

Press and hold the

(talk) button on the steering wheel.

Pair the Android phone to the vehicle’s

Bluetooth

HandsFreeLink

(HFL) system.

Phone Setup

P. 384

Check the box on

Android Auto

If you select

Android Auto

, you cannot select

Audio

and

Phone

Select

Connect

Select

Yes

If your Android phone asks for permission to accept an Android Auto
connection, accept to connect. A confirmation message for HondaLink Assist
appears.

Select

Yes

■

Connect Android Auto wirelessly at start-up (when there is no phone
paired to the system)

Set the power mode to ACCESSORY or ON.

Select

If there is no registered device, the

Bluetooth

pairing screen will be displayed.

If you check the box with

Do not show this again

, this screen will not be

displayed.

Pair the Android phone to the vehicle’s

Bluetooth

HandsFreeLink

(HFL) system.

Phone Setup

P. 384

Check the box on

Android Auto

If you select

Android Auto

, you cannot select

Audio

and

Phone

Select

Connect

Select

Yes

If your Android phone asks for permission to accept an Android Auto
connection, accept to connect. A confirmation message for HondaLink Assist
appears.

Select

Yes

313

Audio System Basic Operation

Android Auto

Features

Press and hold the

(talk) button to operate Android Auto with your voice.

■

Operating Android Auto with Voice Recognition

Operating Android Auto with Voice Recognition

Below are examples of commands you can give with
voice recognition:

•

Reply to text.

•

Call my wife.

•

Navigate to Honda.

•

Play my music.

•

Send a text message to my wife.

•

Call flower shop.

For more information, please refer to the Android
Auto homepage.

You can also activate the voice recognition function

by selecting the

icon in the lower-right corner of

the screen.

(Talk) button:

Press and hold to operate Android

Auto with your voice.
Press and release to activate

standard voice recognition system.

314

Features

Audio Error Messages

iPod/USB Flash Drive

If an error occurs while playing an iPod or USB flash drive, you may see the following
error messages. If you cannot clear the error message, contact a dealer.

*1:Models with 7-in. Color Touchscreen
*2:Models with 9-in. Color Touchscreen

Error Message

Solution

Bad USB Device
Please check owners manual

Appears when an incompatible device is connected. Disconnect the device. Then, turn
the audio system off and turn it on again. Do not reconnect the device that caused the
error.

Connect Retry

*1, *2

Appears when the system does not acknowledge the iPod. Reconnect the iPod.

Unplayable File

*1, *2

Appears when the files in the USB flash drive are copyright protected or an unsupported
format. This error message appears for about a few seconds, then plays the next file.

No Data

*1, *2

Appears when the iPod is empty.

Appears when the USB flash drive is empty or there are no MP3, WMA, AAC, FLAC, or
WAV files in the USB flash drive.

Check that compatible files are stored on the device.

Unsupported

*1, *2

Appears when an unsupported device is connected. If it appears when a supported
device is connected, reconnect the device.

iPod

USB flash drive

iPod and USB flash drive

315

Audio Error Messages

iPod/USB Flash Drive

Features

*1:Models with 7-in. Color Touchscreen
*2:Models with 9-in. Color Touchscreen

Error Message

Solution

Device No Response

*1, *2

Appears when the system does not communicate with a connected device. If it appears
when a device is connected, contact your place of device purchase.

USB hub not supported

*1, *2

Appears when only a HUB is connected. If it appears, connect a USB flash drive to the
HUB.

A charging error has occurred with the
connected USB device. When safe please
check the compatibility of the device and
USB cable and try again.

*1, *2

Appears when an incompatible device is connected. Disconnect the device. Then, turn
the audio system off and turn it on again. Do not reconnect the device that caused the
error.

316

Features

General Information on the Audio System

SiriusXM

Radio Service

You need your radio ID ready before registering for subscription. To see the ID on
the screen, select

Channel

Have your radio ID ready, and either call or visit the SiriusXM

website to

subscribe.

Switch to the SiriusXM

mode by using the audio remote controls on the steering

wheel, or through the audio/information screen, and stay in this mode for about 30
minutes until the service is activated. Make sure your vehicle is in an open area with
good reception.

Channel **** is not subscribed. Call SiriusXM to subscribe.

You are not subscribed to the channel selected.

Subscription Updated:

SiriusXM

radio is receiving information update from the network.

Channel Not Available:

No such channel exists, or the artist or title information is unavailable.

No Signal:

The signal is too weak in the current location.

Check Tuner:

There is a problem with the SiriusXM

tuner. Contact a dealer.

Antenna Disconnected, Antenna Shorted:

There is a problem with the SiriusXM

antenna. Contact a dealer.

*1 : ****part is variable characters, and will change depending upon the channel selected.

■

Subscribing to SiriusXM

Radio

■

Receiving SiriusXM

Radio

■

SiriusXM

Radio Display Messages

Subscribing to SiriusXM

Radio

Contact Information for SiriusXM

Radio:

•

U.S.: SiriusXM

Radio at

www.siriusxm.com/

subscribenow

, or 1-866-635-2349

•

Canada: SiriusXM

Canada at

www.siriusxm.ca/

subscribe-now

, or 1-877-209-0079

Receiving SiriusXM

Radio

The SiriusXM

satellites are in orbit over the equator;

therefore, objects south of the vehicle may cause
satellite reception interruptions. Satellite signals are
more likely to be blocked by tall buildings and
mountains the farther north you travel from the
equator.

You may experience reception problems under the
following circumstances:

•

In a location with an obstruction to the south of
your vehicle.

•

In tunnels

•

On the lower level of a multi-tiered road

•

Large items carried on the roof rack

* Not available on all models

317

General Information on the Audio System

Compatible iPod, iPhone, and USB Flash Drives

Features

Compatible iPod, iPhone, and USB Flash Drives

•

A USB flash drive of 256 MB or higher is recommended.

•

Some digital audio players may not be compatible.

•

Some USB flash drives (e.g., a device with security lockout) may not work.

•

Some software files may not allow for audio play or text data display.

•

Some versions of MP3, WMA, AAC, FLAC, or WAV formats may be unsupported.

*1 : Models with 9-in. Color Touchscreen
*2 : Models with 7-in. Color Touchscreen

■

iPod and iPhone Model Compatibility

Model

Made for iPod touch (6th to 7th generation) released between 2015 and 2019
Made for iPhone 5/iPhone 5s/iPhone 5c/iPhone 6/iPhone 6 Plus/iPhone 6S/iPhone 6S
Plus/iPhone SE/iPhone 7/iPhone 7 Plus/iPhone 8/iPhone 8 Plus/iPhone X/iPhone XS/
iPhone XS Max/iPhone XR/iPhone 11/iPhone 11 Pro/iPhone 11 Pro Max/iPhone SE
(2nd generation)/iPhone 12/iPhone 12 Pro/iPhone 12 Pro Max/iPhone 12 mini

Model

Made for iPod touch (5th to 6th generation) released between 2012 and 2015
Made for iPhone 4s/iPhone 5/iPhone 5s/iPhone 5c/iPhone 6/iPhone 6 Plus/iPhone 6S/
iPhone 6S Plus/iPhone SE/iPhone 7/iPhone 7 Plus/iPhone 8/iPhone 8 Plus/iPhone X/
iPhone XS/iPhone XS Max/iPhone XR/iPhone 11/iPhone 11 Pro/iPhone 11 Pro Max/
iPhone SE (2nd generation)/iPhone 12/iPhone 12 Pro/iPhone 12 Pro Max/
iPhone 12 mini

iPod and iPhone Model Compatibility

This system may not work with all software versions
of these devices.

The Lightning connector works with iPhone 5, iPhone
5s, iPhone 5c, iPhone 6, iPhone 6 Plus, iPhone 6S,
iPhone 6S Plus, iPhone SE, iPhone 7, iPhone 7 Plus,
iPhone 8, iPhone 8 Plus, iPhone X, iPhone XS, iPhone
XS Max, iPhone XR, iPhone 11, iPhone 11 Pro, iPhone
11 Pro Max, iPhone SE (2nd generation), iPhone 12,
iPhone 12 Pro, iPhone 12 Pro Max, iPhone 12 mini,
iPod touch (5th

, 6th, 7th

generation).

The 30-pin connector works with iPhone 4s

USB works with iPhone 4s

, iPhone 5, iPhone 5s,

iPhone 5c, iPhone 6, iPhone 6 Plus, iPhone 6S, iPhone
6S Plus, iPhone SE, iPhone 7, iPhone 7 Plus, iPhone 8,
iPhone 8 Plus, iPhone X, iPhone XS, iPhone XS Max,
iPhone XR, iPhone 11, iPhone 11 Pro, iPhone 11 Pro
Max, iPhone SE (2nd generation), iPhone 12, iPhone
12 Pro, iPhone 12 Pro Max, iPhone 12 mini, iPod
touch (5th

, 6th, 7th

generation).

Models with 7-in. Color Touchscreen

Models with 9-in. Color Touchscreen

■

USB Flash Drives

USB Flash Drives

Files on the USB flash drive are played in their stored
order. This order may be different from the order
displayed on your PC or device.

318

General Information on the Audio System

Honda App License Agreement

Features

Honda App License Agreement

PLEASE CAREFULLY READ THIS END USER LICENSE AGREEMENT (THIS “AGREEMENT”) WHICH GOVERNS YOUR USE OF THE SOFTWARE
INSTALLED ON YOUR HONDA OR ACURA VEHICLE (YOUR “VEHICLE”) AS WELL AS THE APPLICATIONS, SERVICES, FUNCTIONS, AND
CONTENT PROVIDED THROUGH THE SOFTWARE (COLLECTIVELY, THE “SERVICES”). YOUR USE OF THE SOFTWARE OR SERVICES WILL
SERVE AS YOUR CONSENT TO THE TERMS OF THIS AGREEMENT. THE SOFTWARE IS OWNED (OR LICENSED), PROVIDED, AND/OR
OPERATED BY AMERICAN HONDA MOTOR CO. INC., (“HONDA,” “US,” “WE,” OR “OUR”), WITH ITS BUSINESS ADDRESS AT 1919
TORRANCE BLVD., TORRANCE, CA 90501. REFERENCE TO “HONDA” IN THIS AGREEMENT INCLUDES HONDA’S PARENT COMPANY AND
ITS AFFILIATES AND DESIGNATED AGENTS. THE SERVICES ARE OWNED (OR LICENSED), PROVIDED, AND/OR OPERATED BY HONDA OR A
THIRD-PARTY SERVICE PROVIDER (A “PROVIDER”). REFERENCE TO A “PROVIDER” IN THIS AGREEMENT INCLUDES SUCH PROVIDER’S
PARENT COMPANY, AFFILIATES, AND DESIGNATED AGENTS.

Description of the Software.

The SOFTWARE includes the software, firmware and the like, installed and executing on your VEHICLE

during manufacture, and thereafter updated from time to time by HONDA, you or an authorized HONDA dealer (a “DEALER”). The
SOFTWARE allows you to access and use a variety of SERVICES, including but not limited to: (a) HONDA applications, services, and content
provided through the SOFTWARE (together, “HONDA SERVICES”); and (b) PROVIDER applications, services, and content provided through
the SOFTWARE (together, “PROVIDER SERVICES”), each of which may provide access to various information, media, content, and services.

B. SOFTWARE Licensing and Intellectual Property.
1.

SOFTWARE.

This AGREEMENT grants you a non-exclusive, limited, and revocable license to use the SOFTWARE and SERVICES solely (a)

as installed on your VEHICLE by HONDA, (b) as updated on your Vehicle by HONDA, you (but only as and when directed by HONDA), or a
DEALER and (c) as permitted under the terms of this AGREEMENT.

HONDA Services.

The SOFTWARE may provide you with access to various HONDA SERVICES. Installation, activation, or use of HONDA

SERVICES may require your consent to additional terms, conditions, and privacy policies applicable to those HONDA SERVICES (the
“HONDA TERMS”). You acknowledge and agree that any collection, use, sharing of data generated by your VEHICLE or your use of your
VEHICLE, and your use of the HONDA SERVICES shall be subject to this AGREEMENT and any additional HONDA TERMS that may be
specifically applicable to such HONDA SERVICES or data generation. The HONDA SERVICES may collect, use, and share such data while
you are using the SOFTWARE.

■

END USER LICENSE AGREEMENT

319

General Information on the Audio System

Honda App License Agreement

Continued

Features

Open-Source Software.

The SOFTWARE and SERVICES may incorporate software licensed to HONDA under free or open-source

licenses which govern HONDA’s distribution and your use of such software. HONDA and the third-party authors, licensors, and distributors
of such software disclaim all warranties and all liability arising from any and all use or distribution of the software. To the extent such
software is provided under terms that differ from the applicable free or open-source licenses, those terms are offered by HONDA alone.
Additional information regarding free and open-source software incorporated in the SOFTWARE and SERVICES is available in this manual
or within the SOFTWARE.

Provider Services.

The SOFTWARE may provide you with access to various PROVIDER SERVICES. Installation or use of such PROVIDER

SERVICES may require your consent to additional terms, conditions, and privacy policies of the applicable PROVIDER (the “PROVIDER
TERMS”). This AGREEMENT restricts the manner in which you can install and use PROVIDER SERVICES but does not grant you a license or
permission to use such PROVIDER SERVICES. Your permission to use PROVIDER SERVICES is limited and subject to any license grants,
conditions, and limitations included in the PROVIDER TERMS. You acknowledge that any collection, use, sharing of your information,
targeted advertising practices by PROVIDERS, and your use of the PROVIDER SERVICES shall be subject to both this AGREEMENT and any
applicable PROVIDER TERMS. The PROVIDER SERVICES may collect, use, and share such information while you are using the SOFTWARE.

5. License Limitations and Restrictions on Use.

(a) Limited License. You understand and agree that the SOFTWARE and SERVICES are licensed, not sold, to you solely for use in accordance
with this AGREEMENT and any applicable PROVIDER TERMS, and any documentation for the VEHICLE made available to you by HONDA
(any “DOCUMENTATION”). HONDA and its licensors reserve all rights in the SOFTWARE and HONDA SERVICES not expressly granted to
you under this AGREEMENT. PROVIDERS and their licensors reserve all rights in the PROVIDER SERVICES not expressly granted to you under
the applicable PROVIDER TERMS.

320

General Information on the Audio System

Honda App License Agreement

Features

(b) Restrictions on Use. The licenses granted under this AGREEMENT do not permit you to use the SOFTWARE or SERVICES on a device
other than your VEHICLE. As a condition of using the SOFTWARE and SERVICES, you agree that you may not and will not:

Intellectual Property Rights.

All title and intellectual property rights in and to the SOFTWARE and SERVICES, the accompanying

DOCUMENTATION, and all copies of the SOFTWARE or SERVICES are owned by HONDA, PROVIDERS, or their suppliers or licensors. This
AGREEMENT does not grant you any rights in connection with any trademarks or service marks of HONDA, PROVIDERS, or their licensors,
affiliates, or suppliers.

(1) copy, download, distribute, modify, publish, sell, rent, lease, lend, license, sublicense, reuse, or create derivative works of the
SOFTWARE or SERVICES or any of the content or other material within the SOFTWARE or SERVICES, including without limitation,
HONDA or PROVIDER names, logos, or any other trademarks of HONDA or PROVIDERS or used in association with the SOFTWARE or
any SERVICES, except as required to use the SOFTWARE or SERVICES in accordance with this AGREEMENT, any applicable PROVIDER
TERMS, and the DOCUMENTATION;
(2) access or use the SOFTWARE or SERVICES in any manner intended to damage or impair the operation of the SOFTWARE or SERVICES
or interfere with anyone else’s use and enjoyment of the SOFTWARE or SERVICES;
(3) access or attempt to access any system or server on which the SOFTWARE or SERVICES is hosted or modify or alter the SOFTWARE
or SERVICES in any way;
(4) use the SOFTWARE or SERVICES for any unlawful purpose, or in violation of any third party rights;
(5) use the SOFTWARE or SERVICES in violation of any applicable traffic regulations, rules or laws, including but not limited to any driver
distraction laws, rules or regulations;
(6) violate the terms of this AGREEMENT, any HONDA TERMS, any PROVIDER TERMS or other applicable third-party terms, conditions,
and privacy policies; or
(7) reverse engineer, decompile, disassemble, attempt to derive the source code of, nor permit others to reverse engineer, decompile,
or disassemble, or attempt to derive the source code of the SOFTWARE or SERVICES, except and only to the extent that such activity is
expressly permitted (a) by applicable law notwithstanding this limitation or (b) the terms of applicable free or opensource software
licenses.

Honda HR-V (2024 year). Manual in english - page 9
