Honda HR-V (2024 year). Manual in english

129

Gauges and Driver Information Interface

Driver Information Interface

Continued

strum

ent Pa

nel

Setup Group

Customizable Features

Description

Selectable Settings

Maintenance
reset

—

Resets the Maintenance Minder display when you have
performed the maintenance service.

(Selects Reset Items)

Default all

—

Cancels customized changes you have made or restores
them to their default setting.

Cancel

Set

130

Gauges and Driver Information Interface

Driver Information Interface

strum

ent Pa

nel

■

Example of customization settings

The steps for changing the

“Trip A” reset timing

setting to

When fully refueled

are shown below. The default setting for

“Trip A” reset timing

Manually reset

Press the

(home) button and roll the left

selector wheel to select

Settings

, then

press the left selector wheel.

131

Gauges and Driver Information Interface

Driver Information Interface

Continued

strum

ent Pa

nel

Roll the left selector wheel until

Meter

setup

appears on the display.

Press the left selector wheel.

Language selection

appears first in the

display.

Roll the left selector wheel until

“Trip A”

reset timing

appears on the display, then

press the left selector wheel.

The display switches to the
customization setup screen, where you
can select

When fully refueled

IGN

OFF

Manually reset

, or

Back

Roll the left selector wheel and select

When fully refueled

, then press the left

selector wheel.

The

Selected

appears, then the display

returns to the customization menu
screen.

134

Co
ntrols

Clock

Adjusting the Clock

You can adjust the time in the clock display with the power mode in ON.

Press the

MENU

button.

Select

Clock Settings

Select

Automatic Time

, then select

OFF

Select

Set Time

Select

12H

24H

to change 12 or 24 hour

clock.

Select

or .

Select

Set

to set the time.

■

Adjusting the Time

Adjusting the Clock

The clock is automatically updated through the audio
system.

You can also select and enter with the selector knob
instead of the touch panel.

Models with 7-in. Color Touchscreen

MENU

Button

Models with 7-in. Color Touchscreen

135

Clock

Adjusting the Clock

Co
ntrols

Press the

button.

Select

General Settings

Select

System

Select

Date & Time

Select

Set Date & Time

Select

Automatic Date & Time

, then

select

OFF

To adjust date:
7.

Select

Set Date

Select

or .

Select

Save

to set the date.

To adjust time:
7.

Select

Set Time

Select

or .

Select

Save

to set the time.

Adjusting the Clock

You can also adjust the clock by touching the clock
displayed on the header area of the audio/
information screen,

Clock

displayed on the home

screen, or

All Apps

1. Touch the clock on the screen.

The clock screen of the face-type appears.

2. Select

Settings

3. Select

Date & Time

4. Select

Set Date & Time

5. Select

Automatic Date & Time

, then select

OFF

6. Select

Set Date

Set Time

7. Adjusting the dates, hours, and minutes by

selecting

or .

8. Select

Save

to set the time.

You can customize the clock display to show the 12
hour clock or 24 hour clock.

How to Customize the General Settings

P. 342

You can customize the date display to

MM/DD/

YYYY

DD/MM/YYYY

, or

YYYY/MM/DD

How to Customize the General Settings

P. 342

Models with 9-in. Color Touchscreen

136

Co
ntrols

Locking and Unlocking the Doors

Key

This vehicle comes with the following keys:

Use the keys to start and stop the engine, and
lock and unlock all the doors, tailgate, and
fuel fill door.

Key

All the keys have an immobilizer system. The
immobilizer system helps protect against vehicle
theft.

Immobilizer System

P. 156

Follow the advice below to prevent damage to the
keys:

•

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

•

Do not drop the keys or set heavy objects on them.

•

Keep the keys away from liquids, dust, and sand.

•

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the engine
may not start, and the remote transmitter may not
work.
If the keys do not work properly, have them
inspected by a dealer.

You can remotely start the engine using the remote
engine start.

Remote Engine Start

P. 410

Models with

button

Models without

button

Models with

button

* Not available on all models

137

Locking and Unlocking the Doors

Key

Co
ntrols

The built-in key can be used to unlock the
doors when the keyless remote battery
becomes weak and the power door unlock
operation is disabled.

To remove the built-in key, push the release
button and then pull out the key. To reinstall
the built-in key, push the built-in key into the
keyless remote until it clicks.

Contains a number that you will need if you
purchase a replacement key.

■

Built-in Key

Release Button

Built-in Key

■

Key Number Tag

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact a
dealer.

If you lose your key and you cannot start the engine,
contact a dealer.

138

Locking and Unlocking the Doors

Low Keyless Remote Signal Strength

Co
ntrols

Low Keyless Remote Signal Strength

The vehicle transmits radio waves to locate the keyless remote to start the engine;
lock and unlock

all the doors and the fuel fill door; and open the tailgate.

In the following cases, starting the engine, locking/unlocking

the doors/fuel fill

door, or opening the tailgate may be inhibited, or operation may be unstable:

•

Strong radio waves are being transmitted by nearby equipment.

•

You are carrying the keyless remote together with telecommunications
equipment, laptop computers, cell phones, or wireless devices.

•

A metallic object is touching or covering the keyless remote.

Low Keyless Remote Signal Strength

Communication between the keyless remote and the
vehicle consumes the keyless remote’s battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the keyless
remote is receiving strong radio waves. Avoid placing
it near electrical appliances such as televisions and
personal computers.

* Not available on all models

139

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the keyless remote, you can
lock/unlock the doors and fuel fill door, and
open the tailgate.
You can lock/unlock the doors, fuel fill door,
and tailgate within a radius of about 32 inches
(80 cm) of the outside door handle or tailgate
outer handle.

■

Using the Keyless Access System

Locking/Unlocking the Doors from the Outside

If the interior light switch is in the door activated
position, the interior light comes on when you unlock
the doors and tailgate.
No doors opened: The light fades out after 30
seconds.
Doors and tailgate relocked: The light goes off
immediately.

Interior Lights

P. 189

Using the Keyless Access System

If you do not open a door or the tailgate within 30
seconds of unlocking the vehicle with the keyless
access system, the doors and tailgate will
automatically relock.

You can lock or unlock doors using the keyless access
system only when the power mode is in VEHICLE OFF.

•

Do not leave the keyless remote in the vehicle
when you get out. Carry it with you.

•

Even if you are not carrying the keyless remote, you
can lock/unlock the doors and tailgate while
someone else with the remote is within range.

•

The door may be unlocked if the door handle is
covered with water in heavy rain or in a car wash if
the keyless remote is within range.

* Not available on all models

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

140

Co
ntrols

■

Locking the doors and tailgate

Touch the door lock sensor on the front door
or press the lock button on the tailgate.

All the doors, fuel fill door, and tailgate
lock, and the security system sets.

Some exterior lights flash once and the
beeper sounds once.

Using the Keyless Access System

•

If you grip a front door handle or touch the front
door lock sensor wearing gloves, the door sensor
may be slow to respond or may not respond by
locking/unlocking the doors.

•

After locking the door, you have up to 2 seconds
during which you can pull the door handle to
confirm whether the door is locked. If you need to
unlock the door immediately after locking it, wait
at least 2 seconds before gripping the handle,
otherwise the door will not unlock.

•

The door might not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

•

Even within the 32 inches (80 cm) radius, you may
not be able to lock/unlock the doors and tailgate
with the keyless remote if it is above or below the
outside handle.

•

The keyless remote may not operate if it is too close
to the door, door glass and tailgate.

The light flash, beep, and door unlock mode settings
can be customized using the driver information
interface or audio/information screen.

Settings

P. 123

How to Customize the Vehicle Settings

P. 350

Models with 7-in. Color Touchscreen

Models with 9-in. Color Touchscreen

Door Lock

Sensor

Lock Button

* Not available on all models

141

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

■

Unlocking the doors and tailgate

Grab the driver’s door handle:

The driver’s door and fuel fill door
unlock.

Some exterior lights flash twice and the
beeper sounds twice.

Grab the front passenger’s door handle:

All the doors and the tailgate unlock.

Some exterior lights flash twice and the
beeper sounds twice.

Press the tailgate outer handle:

The tailgate unlocks.

Some exterior lights flash twice and the
beeper sounds twice.

Opening/Closing the Tailgate

P. 154

Outer Handle

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

142

Co
ntrols

■

Locking the doors and tailgate (Walk
away auto lock

)

When you walk away from the vehicle with all
doors and tailgate closed while carrying the
keyless remote, the doors, tailgate and fuel fill
door will automatically lock.
The auto lock function activates when all
doors and tailgate are closed, and the keyless
remote is within about 5 feet (1.5 m) radius of
the outside door handle or tailgate outer
handle.
Exit vehicle while carrying keyless remote and
close door(s) and tailgate.

While within about 5 feet (1.5 m) radius of
the vehicle.

The beeper sounds; the auto lock
function will be activated.

Carry the keyless remote beyond about 5
feet (1.5 m) from the vehicle and remain
outside this range for 2 or more seconds.

Some exterior lights flash; the beeper
sounds; all doors and tailgate will then
lock.

Locking the doors and tailgate (Walk away auto lock

)

The auto lock function is set to OFF as the factory
default setting. The auto lock function can be set to
ON using the driver information interface or audio/
information screen.
If you set the auto lock function to ON using the
driver information interface or audio/information
screen, only the remote transmitter that was used to
unlock the driver’s door prior to the setting change
can activate auto lock.

Settings

P. 123

How to Customize the Vehicle Settings

P. 350

After the auto lock function has been activated,
when you stay within the locking/unlocking
operation range, the indicator on the keyless remote
will continue to flash until the doors and tailgate are
locked.

When you stay beside the vehicle within the
operation range, the doors and tailgate will
automatically lock approximately 30 seconds after
the auto lock function activating beeper sounds.

When you open a door or tailgate after the auto lock
function activating beeper sounds, the auto lock
function will be canceled.

Models with 7-in. Color Touchscreen

Models with 9-in. Color Touchscreen

The activation range of

the auto lock function is

about 5 feet (1.5 m)

* Not available on all models

Continued

143

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

To temporarily deactivate the function:

Set the power mode to OFF.

Open the driver’s door.

Using the master door lock switch, operate
the lock as follows:
Lock



Unlock



Lock



Unlock.

The beeper sounds and the function is
deactivated.

To restore the function:

•

Set the power mode to ON.

•

Lock the vehicle without using the auto lock
function

•

With the keyless remote on you, move out
of the auto lock function operation range.

•

Open any door.

Locking the doors and tailgate (Walk away auto lock

)

Under the following circumstances, the auto-lock
function will not activate:

•

The keyless remote is inside the vehicle.

The beeper will not sound.

•

The keyless remote is taken out of its operational
range before all the doors are closed.

The beeper will sound.

The auto lock function does not operate when any of
the following conditions are met.

•

The keyless remote is inside the vehicle.

•

A door, tailgate, or the hood is not closed.

•

The power mode is set to any mode other than
OFF.

•

The keyless remote is not located within a radius of
about 5 feet (1.5 m) from the vehicle when you get
out of the vehicle and close the doors and tailgate.

Auto lock function operation stop beeper

After the auto lock function has been activated, the
auto lock operation stop beeper sounds for
approximately two seconds in the following cases.

•

The keyless remote is put inside the vehicle through
a window.

•

You are located too close to the vehicle.

•

The keyless remote is put inside the tailgate.

If the warning beeper sounds, check that you are
carrying the keyless remote. Then, open/close a door
and confirm the auto lock activation beeper sounds
once.

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

144

Co
ntrols

The vehicle will automatically lock after you
lock the doors in advance then close the doors
and tailgate.

Activate lock presetting after closing the
driver’s door.

Touch the door lock sensor on the driver’s
door

or press the lock button on the

remote transmitter.

Alert sounds and lock presetting is
activated.

Close all doors and the tailgate.

Some exterior lights flash and a beeper
sounds when vehicle locks.

Make sure the doors and tailgate are locked
before moving away from the vehicle.

■

Locking the doors and tailgate (lock presetting)

Locking the doors and tailgate (lock presetting)

Lock presetting will be reset if a door or the tailgate is
opened before the vehicle has locked completely.

Before locking a door, make sure that the key is not
inside the vehicle.

You can turn this function on and off.

Settings

P. 123

How to Customize the Vehicle Settings

P. 350

Models with 7-in. Color Touchscreen

Models with 9-in. Color Touchscreen

Door Lock

Sensor

* Not available on all models

Continued

145

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Locking the doors and tailgate

Press the lock button.

Once:

Some exterior lights flash, all the doors,
fuel fill door, and tailgate lock, and the
security system sets.

Twice (within five seconds after the first
push):

A beeper sounds and verifies the security
system is set.

■

Unlocking the doors and tailgate

Press the unlock button.

Once:

Some exterior lights flash twice, and the
driver’s door and fuel fill door unlock.

Twice:

The remaining doors and the tailgate
unlock.

■

Using the Remote Transmitter

Using the Remote Transmitter

If you do not open a door or the tailgate within 30
seconds of unlocking the vehicle with the remote
transmitter, the doors and tailgate will automatically
relock.

The remote transmitter uses low-power signals, so
the operating range may vary depending on the
surroundings.

You can lock or unlock doors using the remote
transmitter only when the power mode is in VEHICLE
OFF.

If the distance at which the remote transmitter works
varies, the battery is probably low.
If the LED does not come on when you press a
button, the battery is dead.

Replacing the Remote Battery

P. 584

LED

Unlock

Button

Lock

Button

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

146

Co
ntrols

If the unlock button of the keyless remote does not work, use the built-in key
instead. The keyhole is behind the door handle.

Pull and hold the outer handle.
Insert the built-in key into the key cylinder
from below the handle and then turn it.

■

Unlocking the Doors Using a Key

Unlocking the Doors Using a Key

When unlocking, the driver’s door unlocks first. Turn
the key a second time within a few seconds to unlock
the remaining doors and the tailgate.

If the lock button of the keyless remote does not
work, refer to the following.

Locking a Door Without Using a Key

P. 147

Continued

147

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

If you do not have the key on you, or if for some reason you cannot lock a door using
the key, you can lock the door without it.

■

Locking the front doors

Push the lock tab forward

or push the

master door lock switch in the lock direction

, and close the door.

■

Locking the rear doors

Push the lock tab forward and close the door.

■

Locking a Door Without Using a Key

Locking a Door Without Using a Key

When you lock the driver’s door, all the other doors
and tailgate lock at the same time.
Before locking a door, make sure that the key is not
inside the vehicle.

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

148

Co
ntrols

■

Lockout protection function

If the vehicle cannot detect the keyless
remote, lockout protection activates.

A beeper sounds, some exterior lights
flash, the doors unlock, and a message
appears on the driver information
interface.

This allows you to open a door in case
the keyless remote is still inside the
vehicle.

If you do not open a door, all doors relock
after 15 seconds.

To avoid non-detection, make sure to keep
the keyless remote away from cell phones and
other devices that may cause signal
interference.

■

Lockout prevention system

The doors and the tailgate cannot be locked
when the keyless remote is inside the vehicle.

Locking a Door Without Using a Key

You can change the lockout protection operation
setting.

Settings

P. 123

How to Customize the Vehicle Settings

P. 350

Models with keyless access system

Models with 7-in. Color Touchscreen

Models with 9-in. Color Touchscreen

Models with keyless access system

Models without keyless access system

* Not available on all models

149

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Inside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Inside

■

Locking a door

Push the lock tab forward.

■

Unlocking a door

Pull the lock tab rearward.

■

Using the Lock Tab

Using the Lock Tab

When you lock the door using the lock tab on the
driver’s door, all of the other doors and the tailgate
lock at the same time.
When you unlock the door using the lock tab on the
driver’s door, only the driver’s door will unlock.

To unlock

Lock Tab

To lock

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Inside

150

Co
ntrols

Pull the front door inner handle.

The door unlocks and opens in one
motion.

Unlocking and opening the driver’s door from the inner handle unlocks all the other
doors.

To avoid all the doors unlocking use the lock tab on the driver’s door to unlock, then
lock again before opening the door.

This setting works for one time only.

If you do not want all the doors to unlock all the time, customize the

Auto door

unlock

Auto Door Unlock

setting to

OFF

using the driver information interface

or audio/information screen.

Settings

P. 123

How to Customize the Vehicle Settings

P. 350

*1 : Models with 7-in. Color Touchscreen
*2 : Models with 9-in. Color Touchscreen

■

Unlocking Using the Front Door Inner Handle

Unlocking Using the Front Door Inner Handle

The front door inner handles are designed to allow
front seat occupants to open the door in one motion.
However, this feature requires that front seat
occupants never pull a front door inner handle while
the vehicle is in motion.

Children should always ride in a rear seat where
childproof door locks are provided.

Childproof Door Locks

P. 151

Inner Handle

Models with 7-in. Color Touchscreen

Models with 9-in. Color Touchscreen

* Not available on all models

151

Locking and Unlocking the Doors

Childproof Door Locks

Co
ntrols

Press the master door lock switch in as shown
to lock or unlock all the doors, fuel fill door,
and tailgate.

Childproof Door Locks

The childproof door locks prevent the rear doors from being opened from the inside
regardless of the position of the lock tab.

Slide the lever in the rear door to the lock
position, and close the door.

■

When opening the door

Open the door using the outside door handle.

■

Using the Master Door Lock Switch

Using the Master Door Lock Switch

When you lock/unlock either of the front doors using
the master door lock switch, all the other doors, fuel
fill door, and tailgate lock/unlock at the same time.

To lock

To unlock

Master Door Lock Switch

■

Setting the Childproof Door Locks

Childproof Door Locks

To open the door from the inside when the
childproof door lock is on, put the lock tab in the
unlock position, lower the rear window, put your
hand out of the window, and pull the outside door
handle.

Lock

Unlock

152

Locking and Unlocking the Doors

Auto Door Locking/Unlocking

Co
ntrols

Auto Door Locking/Unlocking

Your vehicle locks or unlocks all doors automatically when a certain condition is met.

■

Drive lock mode

All doors lock when the vehicle’s speed reaches about 10 mph (15 km/h).

■

Driver’s door open mode

All doors and the tailgate unlock when the driver’s door is opened.

■

Auto Door Locking

■

Auto Door Unlocking

Auto Door Locking/Unlocking

You can turn off or change to another auto door
locking/unlocking setting using the driver
information interface or audio/information screen.

Settings

P. 123

How to Customize the Vehicle Settings

P. 350

Models with 7-in. Color Touchscreen

Models with 9-in. Color Touchscreen

* Not available on all models

153

Co
ntrols

Tailgate

Precautions for Opening/Closing the Tailgate

Always make sure individuals and objects are clear of the tailgate before opening or
closing it.

•

Open the tailgate all the way.

If it is not fully opened, the tailgate may begin to close under its own weight.

•

Be careful when it is windy. The wind may cause the tailgate to close.

Keep the tailgate closed while driving to:

Avoid possible damage.

Prevent exhaust gas from leaking into the vehicle.

Carbon Monoxide Gas

P. 83

Precautions for Opening/Closing the Tailgate

Be careful not to hit your head on the tailgate or to
put your hands between the tailgate and the cargo
area when closing the tailgate.

When you are storing or picking up luggage from the
cargo area while the engine is idling, do not stand in
front of the exhaust pipe. You may get burned.

Do not allow any passenger in the cargo space. They
may get hurt during hard braking, a sudden
acceleration, or a crash.

WARNING

Anyone caught in the path of a tailgate
that is being opened or closed can be
seriously injured.
Make sure that all people are clear of the
tailgate before opening or closing it.

154

Tailgate

Opening/Closing the Tailgate

Co
ntrols

Opening/Closing the Tailgate

When all the doors are unlocked or press the
tailgate unlock button on the remote
transmitter, the tailgate is unlocked. Press the
tailgate outer handle and lift open the
tailgate.

If you are carrying the keyless remote, you do
not have to unlock the tailgate before
opening it.

To close the tailgate, grab the inner handle,
pull the tailgate down, and push it closed
from outside.

If you close the tailgate when the driver’s door
is locked, the tailgate locks automatically.

Some exterior lights flash.

Precautions for Opening/Closing the Tailgate

Make sure cargo or other items do not touch the
tailgate support struts.

Tailgate Support Struts

Outer Handle

Inner Handle

Models with keyless access system

All models

Opening/Closing the Tailgate

•

Do not leave the keyless remote in the vehicle
when you get out. Carry it with you.

•

Even if you are not carrying the keyless remote, you
can unlock the tailgate while someone else with
the remote is within range.

•

Do not leave the keyless remote inside the cargo
area and close the tailgate. The beeper sounds and
the tailgate cannot be closed.

Models with keyless access system

156

Co
ntrols

Security System

Immobilizer System

This system prevents a key that has not been pre-registered from starting the
engine.

Pay attention to the following when pressing the

ENGINE START/STOP

button:

•

Do not allow objects that emit strong radio waves near the

ENGINE START/

STOP

button.

•

Make sure the key is not covered by or touching a metal object.

•

Do not bring a key from another vehicle’s immobilizer system near the

ENGINE

START/STOP

button.

•

Do not put the key near magnetic items. Electronic device, such as televisions and
audio systems, emit strong magnetic fields. Note that even a key chain can
become magnetic.

Security System Alarm

The security system alarm activates when the tailgate, hood, or doors are forcibly
opened. The alarm does not activate if the tailgate or doors are opened with the key,
remote transmitter or keyless access system

However, the alarm activates if a door is opened with the key and then the
transmission is taken out of

(

or the hood is opened before the power mode is in

ON.

■

When the security system alarm activates

The horn sounds intermittently, and some exterior lights flash.

Immobilizer System

NOTICE

Leaving the key in the vehicle can result in theft or
accidental movement of the vehicle.
Always take the key with you whenever you leave the
vehicle unattended.

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

Apply and hold the brake pedal before turning the
vehicle on the first time after the battery has been
disconnected.

Canadian models

Security System Alarm

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

The security system alarm continues for a maximum
of two minutes until the security system alarm
deactivates.

* Not available on all models

Continued

157

Security System

Security System Alarm

Co
ntrols

■

To deactivate the security system alarm

Unlock the vehicle using the key, the remote transmitter, or keyless access system

or set the power mode to ON. The system, along with the horn and flashing lights,
is deactivated.

■

Setting the security system alarm

The security system alarm automatically sets when the following conditions have
been met:

•

The power mode is set to VEHICLE OFF.

•

The hood is closed.

•

All doors and the tailgate are locked from outside with the remote transmitter or
keyless access system

■

When the security system alarm sets

The security system alarm indicator in the instrument panel blinks and the blinking
interval changes after about 15 seconds.

■

To cancel the security system alarm

The security system alarm is canceled when the vehicle is unlocked using the remote
transmitter or keyless access system

, or when the power mode is set to ON. The

security system alarm indicator goes off at the same time.

Security System Alarm

Do not set the security system alarm when someone
is in the vehicle or a window is open. The system can
accidentally activate when:

•

Unlocking the door with the lock tab.

•

Opening the hood with the hood release handle.

•

Taking the transmission out of

(

If the battery goes dead after you have set the
security system alarm, the security alarm may activate
once the battery is recharged or replaced.
If this occurs, deactivate the security system alarm by
unlocking a door using the key, remote transmitter,
or keyless access system

* Not available on all models

158

Security System

Security System Alarm

Co
ntrols

■

The panic button on the remote
transmitter

If you press the panic button for
approximately one second, the following will
occur for about 30 seconds:

•

The horn sounds.

•

Some exterior lights flash.

■

Canceling panic mode

•

Press any button on the remote transmitter.

•

Set the power mode to ON.

■

Panic Mode

Panic Button

159

Continued

Co
ntrols

Windows

Opening/Closing the Power Windows

The power windows can be opened and closed when the power mode is in ON,
using the switches on the doors. The driver’s side switches can be used to open and
close all of the windows.

The power window lock button on the driver’s side must be switched off (not
pushed in, indicator off) to open and close the windows from anywhere other than
the driver’s seat.

When the power window lock button is pushed in, the indicator comes on and you
can only operate the driver’s window. Turn the power window lock button on if a
child is in the vehicle.

■

Manual operation

To open:

Push the switch down lightly, and

hold it until the desired position is reached.

To close:

Pull the switch up lightly, and hold it

until the desired position is reached.

■

Automatic operation

To open:

Push the switch down firmly.

To close:

Pull the switch up firmly.

The window opens or closes completely. To
stop the window at any time, push or pull the
switch briefly.

■

Opening/Closing the Windows with Auto-Open/Close

Function

Opening/Closing the Power Windows

The power windows can be operated for up to 10
minutes after you set the power mode to VEHICLE
OFF. Opening either front door cancels this function.

Auto Reverse

If a power window senses resistance when closing
automatically, it will stop closing and reverse
direction.

The driver’s window auto reverse function is disabled
when you continuously pull up the switch.

The auto reverse function stops sensing when the
window is almost closed to ensure that it fully closes.

WARNING

Closing a power window on someone’s
hands or fingers can cause serious injury.

Make sure your passengers are away from
the windows before closing them.

Power Window Lock Button

Driver’s

Window

Switch

Indicator

Passenger’s

Window

Switch

* Not available on all models

Windows

Opening/Closing the Power Windows

160

Co
ntrols

To open:

Push the switch down.

To close:

Pull the switch up.

Release the switch when the window reaches
the desired position.

■

Opening/Closing Windows without Auto-Open/Close

Function

Opening/Closing the Power Windows

While driving with any of the windows open, you
may hear a booming, throbbing, or helicopter-type
noise or pressure. This is called wind buffeting. This is
a normal occurrence that can be minimized.

If you hear a wind buffeting noise with any of the
windows slightly or open the moonroof

to the

comfort position.

Open

* Not available on all models

Honda HR-V (2024 year). Manual in english - page 4
