97

uu

Indicators

u

Continued

In

strum

ent Pa

nel

*1:Canadian models only: Apply and hold the brake pedal before selecting the ON mode.

Indicator

Name

On/Blinking

Explanation

Immobilizer
System Indicator

●

Blinks if the immobilizer system cannot
recognize the key information.

•

Blinks

- You cannot start the engine. Set the

power mode to VEHICLE OFF

*1

, then select the ON

mode again.

•

Repeatedly blinks

- The system may be

malfunctioning. Have your vehicle checked by a
dealer.

•

Do not attempt to alter this system or add other
devices to it. Electrical problems can occur.

Security System
Alarm Indicator

●

Blinks when the security system alarm has
been set.

2

Security System Alarm

 P. 156

U.S.

Canada

Indicator

Indicator

U.S.

Canada

Indicator

Indicator

98

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

ECON

 Mode

Indicator

•

Comes on when you set the drive mode to

ECON

.

2

Drive Mode System

 P. 419

NORMAL

 Mode

Indicator

•

Comes on when you set the drive mode to

NORMAL

.

2

Drive Mode System

 P. 419

SNOW

 Mode

Indicator

•

Comes on when you set the drive mode to

SNOW

.

2

Drive Mode System

 P. 419

Hill Descent
Control System
Indicator (White/
Green)

•

Lights up in white when the Hill Descent
Control System is on and ready to use.

•

Lights up in green when the Hill Descent
Control System is in operation.

2

Hill Descent Control System

 P. 422

System Message
Indicator

•

Comes on along with a beep when a
problem is detected. A system message on
the driver information interface appears at
the same time.

•

While the indicator is on, press the

 (home)

button, and select

Warnings

 to see the message

again.

2

Switching the Display

 P. 107

•

Refer to the Indicators information in this chapter
when a system message appears on the driver
information interface. Respond to the message
accordingly.

•

The driver information interface will not return to
the normal screen unless the warning is canceled,
or the

 (home) button is pressed.

99

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Adaptive Cruise
Control (ACC)
with Low Speed
Follow Indicator
(Amber)

●

Comes on if there is a problem with ACC
with Low Speed Follow.

●

Comes on while driving

- Have your vehicle

checked by a dealer.

●

Indicator may come on temporarily when the
Maximum Load Limit is exceeded.

●

ACC with Low Speed Follow has been
automatically canceled.

●

Make sure the total load is within the Maximum
Load Limit.

2

Maximum Load Limit

 P. 403

●

Stays on constantly

- Have your vehicle checked

by a dealer.

●

Comes on if the ACC with Low Speed Follow
is deactivated temporarily after the battery
has been disconnected, then reconnected.

●

Drive a short distance at more than 12 mph (20
km/h). The indicator should go off. If it does not,
have your vehicle checked by a dealer.

Adaptive Cruise
Control (ACC)
with Low Speed
Follow Indicator
(White/Green)

●

Lights up in white when you press the



button.

●

Lights up in green when you press the

RES/+/SET/−

 switch up or down.

2

Adaptive Cruise Control (ACC) with Low
Speed Follow

 P. 461

Cruise Mode
Indicator (White/
Green)

●

Lights up in white when you change to
cruise mode.

●

Lights up in green when you have set a
speed for cruise control.

2

To Switch ACC with Low Speed Follow to
Cruise Control

 P. 478

100

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Lane Keeping
Assist System
(LKAS) Indicator
(Amber)

●

Comes on if there is a problem with the
LKAS.

●

Stays on constantly

- Have your vehicle checked

by a dealer.

●

Indicator may come on temporarily when the
Maximum Load Limit is exceeded.

●

Make sure the total load is within the Maximum
Load Limit.

2

Maximum Load Limit

 P. 403

●

Stays on constantly

- Have your vehicle checked

by a dealer.

Lane Keeping
Assist System
(LKAS) Indicator
(White/Green)

●

Lights up in white when you press the LKAS
button.

●

Lights up in green when the LKAS is in
operation.

2

Lane Keeping Assist System (LKAS)

 P. 481

101

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Safety Support
Indicator (Amber)

●

Comes on if there is a problem with Road
Departure Mitigation system, CMBS

TM

, Low

Speed Braking Control

*

, or blind spot

information system

*

.

●

Stays on constantly

 - Have your vehicle checked

by a dealer.

●

Comes on if there is a problem with the
parking sensor.

●

Check if the area around the sensor(s) is covered
with mud, ice, snow, etc. If the indicator stays on
even after you clean the area, have the system
checked by a dealer.

●

Indicator may come on temporarily when the
Maximum Load Limit is exceeded.

●

Make sure the total load is within the Maximum
Load Limit.

2

Maximum Load Limit

 P. 403

●

Stays on constantly

 - Have your vehicle checked

by a dealer.

●

Comes on if the Road Departure Mitigation
system, Low Speed Braking Control

*

 and

CMBS

TM

 are deactivated temporarily after

the battery has been disconnected and then
reconnected.

●

Drive a short distance at more than 12 mph (20
km/h). The indicator should go off. If it does not,
have your vehicle checked by a dealer.

Models with Parking Sensor System

* Not available on all models

102

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Safety Support
Indicator (Amber)

●

Comes on when Road Departure Mitigation
system and/or CMBS

TM

 shuts itself off.

●

Stays on

 - The temperature inside the camera is

too high.
Use the climate control system to cool down the
camera.
The system activates when the temperature inside
the camera cools down.

2

Front Wide View Camera

 P. 515

●

Stays on

 - The area around the camera is blocked

by dirt, mud, etc. Stop your vehicle in a safe place
and wipe the debris off with a soft cloth.

●

Have your vehicle checked by a dealer if the
indicator and message are still displayed even after
you have cleaned the area around the camera.

2

Front Wide View Camera

 P. 515

●

It may come on when the ambient conditions are
dark, such as when driving in a tunnel, or at night,
dawn, or dusk.

103

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Safety Support
Indicator (Amber)

●

Comes on when mud, snow, or ice
accumulates in the vicinity of sonar sensor.

●

Remove the obstacle in the vicinity of sonar sensor.

2

Low Speed Braking Control

*

 P. 455

●

Comes on when mud, snow, or ice
accumulates in the vicinity of the blind spot
information system sensor.

●

Comes on when the temperature of the
blind spot information system sensor is high.

●

Comes on while driving

 - Something may be

interfering with the blind spot information system
sensor. Check the vicinity of the blind spot
information system sensor and remove any
obstacles.

●

The system will return to normal when the
temperature cools down.

2

Blind Spot Information System

*

 P. 435

Safety Support
Indicator (Green/
Gray)

●

Lights up in green when Road Departure
Mitigation system, CMBS

TM

, Low Speed

Braking Control

*

, Parking Sensor System

*

,

and blind spot information system

*

 are on.

●

Lights up in green and gray when Road
Departure Mitigation system, CMBS

TM

, Low

Speed Braking Control

*

, Parking Sensor

System

*

, or blind spot information system

*

,

or any two, three or four of these systems
are off.

●

Lights up in gray when Road Departure
Mitigation system, CMBS

TM

, Low Speed

Braking Control

*

, Parking Sensor System

*

,

and blind spot information system

*

 are off.

2

Road Departure Mitigation System

 P. 501

2

Collision Mitigation Braking System

TM



(CMBS

TM

)

 P. 443

2

Blind Spot Information System

*

 P. 435

2

Low Speed Braking Control

*

 P. 455

2

Parking Sensor System

*

 P. 528

Models with Low Speed Braking Control

Models with blind spot information system

* Not available on all models

104

In

strum

ent Pa

nel

Gauges and Driver Information Interface

Gauges

Gauges include the speedometer, fuel gauge, and other related indicators.
They are displayed when the power mode is in ON.

Displays your driving speed in mph or km/h.

Shows the number of engine revolutions per minute.

Displays the amount of fuel left in the fuel tank.

■

Speedometer

■

Tachometer

■

Fuel Gauge

1

Speedometer

You can change the Speed/Distance units.

2

Speed/Distance Units

 P. 122

2

Settings

*

 P. 123

2

Customized Features

 P. 342

1

Tachometer

You can turn the tachometer display on or off.

2

Settings

*

 P. 123

2

Customized Features

 P. 342

1

Fuel Gauge

NOTICE

You should refuel when the reading approaches

.

Running out of fuel can cause the engine to misfire,
damaging the catalytic converter.

The actual amount of remaining fuel may differ from
the fuel gauge reading.

E

* Not available on all models

Continued

105

uu

Gauges and Driver Information Interface

u

Gauges

In

strum

ent Pa

nel

Shows the total number of miles or kilometers that your vehicle has accumulated.

Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada).

■

Adjusting the outside temperature display

Adjust the temperature reading by up to ±5°F or ±3°C if the temperature reading
seems incorrect.

Shows certain detected traffic signs while driving.
If speed limit warning is activated, the sign icon blinks when the maximum speed of
the traffic sign detected is exceeded by a threshold, when compared with the vehicle
speed.

2

Traffic Sign Recognition System

 P. 509

■

Odometer

■

Outside Temperature

■

Traffic Sign Recognition System

1

Outside Temperature

The temperature sensor is in the front bumper.
Road heat and exhaust from another vehicle can
affect the temperature reading when your vehicle
speed is less than 19 mph (30 km/h).

It may take several minutes for the display to be
updated after the temperature reading has stabilized.

You can adjust the temperature reading.

2

Settings

*

 P. 123

2

Customized Features

 P. 342

1

Traffic Sign Recognition System

The default speed limit warning threshold is the
maximum speed of the traffic sign detected.

You can adjust the threshold for speed limit warning.

2

Settings

*

 P. 123

2

Customized Features

 P. 342

* Not available on all models

106

uu

Gauges and Driver Information Interface

u

Gauges

In

strum

ent Pa

nel

Shows the current mode for ACC with Low Speed Follow, LKAS, and Traffic Jam
Assist

*

.

2

Adaptive Cruise Control (ACC) with Low Speed Follow

 P. 461

2

Lane Keeping Assist System (LKAS)

 P. 481

2

Traffic Jam Assist

*

 P. 492

Shows the clock.
You can adjust the time manually and change the clock display to show the 12 hour
clock or 24 hour clock.

2

Clock

 P. 134

■

Current Mode for ACC with Low Speed Follow, the LKAS, and
Traffic Jam Assist

*

■

Clock

* Not available on all models

107

uu

Gauges and Driver Information Interface

u

Driver Information Interface

Continued

In

strum

ent Pa

nel

Driver Information Interface

The driver information interface shows information such as the estimated travelable
distance and fuel economy of the vehicle. It also displays messages such as warnings
and other helpful information.
When a warning message displays, please check the message and contact a dealer
to have the vehicle inspected if necessary. Please refer to the pages below if the

Engine oil pressure low

 or

Engine temperature too hot

 message is displayed.

2

If the Engine oil pressure low Warning Appears

 P. 613

2

Overheating

 P. 611

Press the

 (home) button, then roll the left selector wheel to scroll to the content

you want to see. Press the left selector wheel to see detailed information.

■

Switching the Display

1

Switching the Display

You can add or delete the meter contents.

2

Customize Display

 P. 121

108

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

Customize
display

 P. 121

Left Selector

Wheel

 (home) Button

Roll the left

selector wheel.

No content

 P. 122

Speed & time

 P. 111

Warnings

 P. 122

Range & fuel

 P. 109

Settings

*

 P. 123

Driver
attention

 P. 114

Seat belts

 P. 118

Safety
Support

 P. 118

Maintenance

 P. 118

Phone

*

 P. 112

Audio

*

 P. 112

Navigation

*

 P. 113

AWD torque
distribution

*

 P. 117

Brightness

 P. 120

* Not available on all models

109

uu

Gauges and Driver Information Interface

u

Driver Information Interface

Continued

In

strum

ent Pa

nel

Roll the left selector wheel to switch between trip meter A and trip meter B.

■

Range/Fuel/Trip Meter

Average Fuel Economy

Range

Trip Meter B

Instant Fuel Economy

Trip Meter A

uu

Gauges and Driver Information Interface

u

Driver Information Interface

110

In

strum

ent Pa

nel

■

Trip meter

Shows the total number of miles or kilometers driven since the last reset. Meters A
and B can be used to measure two separate trips.

Resetting a trip meter

To reset the trip meter, display it, press the left selector wheel, and then select

Reset

.

u

The trip meter is reset to 0.0.

■

Average Fuel Economy

Shows the estimated average fuel economy of each trip meter in mpg or l/100 km.
The display is updated at set intervals. When a trip meter is reset, the average fuel
economy is also reset.

■

Instant Fuel Economy

Shows the instant fuel economy as a bar graph in mpg or l/100 km.

■

Range

Shows the estimated distance you can travel on the remaining fuel. This estimated
distance is based on the vehicle’s current fuel economy.

1

Average Fuel Economy

You can change when to reset the average fuel
economy.

2

Settings

*

 P. 123

2

Customized Features

 P. 342

1

Range

The driving range displayed is only an estimate and
may differ from the actual distance the vehicle can
travel.

* Not available on all models

111

uu

Gauges and Driver Information Interface

u

Driver Information Interface

Continued

In

strum

ent Pa

nel

Roll the left selector wheel to switch between trip meter A and trip meter B.

■

Speed/Time/Trip Meter

Trip Meter B

Average Speed

Trip Meter A

Elapsed Time

uu

Gauges and Driver Information Interface

u

Driver Information Interface

112

In

strum

ent Pa

nel

■

Trip meter

2

Trip meter

 P. 110

■

Elapsed time

Shows the time elapsed since Trip A or Trip B was reset.

■

Average speed

Shows the average speed in mph or km/h since Trip A or Trip B was reset.

Shows the current audio information.

2

Audio System Basic Operation

 P. 244

Shows the current phone information.

2

Bluetooth

®

 HandsFreeLink

®

 P. 379

■

Audio

*

■

Phone

*

1

Elapsed time

You can change when to reset the elapsed time.

2

Settings

*

 P. 123

2

Customized Features

 P. 342

1

Average speed

You can change when to reset the average speed.

2

Settings

*

 P. 123

2

Customized Features

 P. 342

* Not available on all models

Continued

113

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

■

Compass

Shows the compass screen.

■

Turn-by-Turn Directions

When driving guidance is provided by the navigation system

*

, Android Auto or

Apple CarPlay, turn-by-turn directions to your destination appear.

2

Refer to the Navigation System Manual

2

Android Auto

TM

 P. 308

2

Apple CarPlay

 P. 301

■

Navigation

*

1

Navigation

*

You can select whether to have the turn-by-turn
display come on or not during the route guidance.

2

Customized Features

 P. 342

Turn-by-turn directions may not be available for all
apps.

When the compass or turn-by-turn directions are
displayed, you can control some navigation system
functions on the driver information interface by
scrolling the left selector wheel.

2

Refer to the Navigation System Manual

Models with navigation system

* Not available on all models

uu

Gauges and Driver Information Interface

u

Driver Information Interface

114

In

strum

ent Pa

nel

The Driver Attention Monitor analyzes steering inputs to determine if the vehicle is
being driven in a manner consistent with drowsy or inattentive driving. If it
determines that the vehicle is being driven in such a manner, it will display the
degree of the driver’s attention on the driver information interface.

When you select

Driver attention

 on the

driver information interface, bars on it light up
in white to indicate the degree of the driver’s
attention.

2

Switching the Display

 P. 107

■

Driver Attention Monitor

1

Driver Attention Monitor

The Driver Attention Monitor cannot always detect if
the driver is tired or inattentive.
Regardless of the system’s feedback, if you are
feeling tired, stop in a safe location and rest for as
long as needed.

Driver Information

Interface

Left Selector

Wheel

 (home) Button

Level

115

uu

Gauges and Driver Information Interface

u

Driver Information Interface

Continued

In

strum

ent Pa

nel

If two bars light up, the

Driver attention

level low

 message will appear.

If one bar lights up, the

Driver attention

level low. Time for a break.

 message will

appear, a beep will sound, and the steering
wheel will vibrate.
If this message appears, stop in a safe location
and rest for as long as needed.
The message will disappear when the left
selector wheel is pressed or when the system
has determined that the driver is driving
normally.
If the driver does not take a break and the
monitor continues to detect that the driver is
very tired, the message will appear again after
approximately 15 minutes, accompanied by a
beep and steering wheel vibrations.
The message does not appear when the
traveling time is 30 minutes or less.

uu

Gauges and Driver Information Interface

u

Driver Information Interface

116

In

strum

ent Pa

nel

■

The Driver Attention Monitor resets when:

•

The engine is turned off.

•

The driver unfastens the seat belt and opens the door while the vehicle is stopped.

■

For the Driver Attention Monitor to function:

•

The vehicle must be traveling above 25 mph (40 km/h).

•

The electric power steering (EPS) system indicator must be off.

■

Depending on driving conditions or other factors, the Driver Attention
Monitor may not function in the following circumstances:

•

The steering assist function of the Lane Keeping Assist System (LKAS) is active.

2

Lane Keeping Assist System (LKAS)

 P. 481

•

The condition of the road is poor; e.g., the surface is unpaved or bumpy.

•

It is windy.

•

The driver is frequently operating the vehicle in an assertive manner, such as
changing lanes or accelerating.

■

Customizing

You can change the Driver Attention Monitor settings. Select

Tactile and audible

alert

*1

/

Tactile And Audible Alert

*2

,

Tactile alert

*1

/

Tactile Alert

*2

, or

OFF

.

2

Settings

*

 P. 123

2

Customized Features

 P. 342

*1 : Models with 7-in. Color Touchscreen
*2 : Models with 9-in. Color Touchscreen

1

For the Driver Attention Monitor to function:

The bars on the driver information interface remain
grayed-out unless the Driver Attention Monitor is
functioning.

* Not available on all models

117

uu

Gauges and Driver Information Interface

u

Driver Information Interface

Continued

In

strum

ent Pa

nel

The indicators on the display show the
amount of torque being transferred to the
right front, left front, right rear, and left rear
wheels.

2

Real Time AWD with Intelligent Control
System

TM

*

 P. 427

■

AWD Torque Distribution Monitor

*

* Not available on all models

uu

Gauges and Driver Information Interface

u

Driver Information Interface

118

In

strum

ent Pa

nel

Occurs, under specified conditions, when seat belts are latched or unlatched.

2

Seat Belt Reminder

 P. 41

Shows the remaining oil life and Maintenance Minder

TM

.

2

Maintenance Minder

TM

 P. 545

Indicates the status of the Road Departure Mitigation system, CMBS

TM

, Low Speed

Braking Control

*

, Parking Sensor System

*

, and blind spot information system

*

, such

as On, Off, or Failure, by color and letters.

The following colors indicate the status of any of the above-mentioned systems:

•

Green: The system is on.

•

Gray: The system is off.

•

Amber: There is a problem with the system.

■

Seat Belts

■

Maintenance

■

Safety Support

1

Safety Support

If a system is indicated by the color amber, have your
vehicle checked by a dealer immediately.

To turn each system on or off, first rotate the left
selector wheel to switch displays. From the next
display, you can select which system to turn on or off.

2

Road Departure Mitigation System

 P. 501

2

Blind Spot Information System

*

 P. 435

2

Collision Mitigation Braking System

TM



(CMBS

TM

)

 P. 443

2

Low Speed Braking Control

*

 P. 455

2

Parking Sensor System

*

 P. 528

You can also confirm the status of each function by
the color of the safety support indicator.

2

Safety Support Indicator (Amber)

 P. 101

2

Safety Support Indicator (Green/Gray)



P. 103

* Not available on all models

119

uu

Gauges and Driver Information Interface

u

Driver Information Interface

Continued

In

strum

ent Pa

nel

Area Info

for CMBS

TM

Area Info

for Road

Departure

Mitigation

System

Area Info

for Blind

Spot

Information

System

Area Info

for Parking

Sensor

System

Road

Departure

Mitigation

System Icon

and Status

Info

Area Info for Low

Speed Braking

Control

Blind Spot

Information

System Icon

and Status

Info

Parking

Sensor

System

Icon and

Status Info

CMBS

TM



Icon and

Status

Info

Low

Speed

Braking

Control

Icon and

Status

Info

Models with Blind Spot

Information System

Models with Low Speed

Braking Control

Models with Parking

Sensor System

uu

Gauges and Driver Information Interface

u

Driver Information Interface

120

In

strum

ent Pa

nel

Press the left selector wheel when the

Brightness

 screen is displayed.

When the power mode is in ON, you can use the left selector wheel to adjust
instrument panel brightness.

Brighten:

Roll the left selector wheel up.

Dim:

Roll the left selector wheel down.

Press the left selector wheel to exit.

■

Brightness

1

Brightness

The brightness of the gauge is automatically adjusted
depending on the ambient brightness.

•

The brightness dims when the ambient light is
dark.

•

The brightness brightens when the ambient light is
bright.

You can change the setting even when the ambient
lighting is bright, but the brightness of the gauge
won’t change.

Continued

121

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

■

Arrange content

You can choose which icons to display on the home screen.

1.

Roll the left selector wheel to scroll to select

Customize display

, then press the left

selector wheel.

2.

Roll the left selector wheel.

3.

Roll the left selector wheel to scroll
between icons, then press the left selector
wheel to check or uncheck them.

■

Customize Display

1

Customize Display

Icons that are gray cannot be removed from the
home screen.

When you customize settings, shift to

(

P

.

uu

Gauges and Driver Information Interface

u

Driver Information Interface

122

In

strum

ent Pa

nel

2

Tachometer

 P. 104

■

Speed/Distance Units

Enables you to show another unit on the driver information interface and audio/
information screen and set the displayed measurements to read in either miles and
mph or km and km/h.

Press and hold the left selector wheel when you select

No content

 on the driver

information interface. Each time you do this, the unit will change from miles and
mph to km and km/h or vice versa. After this, a confirmation screen will appear for
a few seconds.

You can check if there are any active warning messages.

■

No Content

■

Warnings

1

No Content

The tachometer can be turned on and off using the
driver information interface or audio/information
screen.

2

Settings

*

 P. 123

2

Customized Features

 P. 342

Even if you have turned off the tachometer on the
driver information interface or audio/information
screen, if

No content

 is selected on the driver

information interface, it will change to a tachometer-
only display.

2

Switching the Display

 P. 107

1

Warnings

If there are multiple warnings, you can roll the left
selector wheel to see other warnings.

* Not available on all models

Continued

123

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

Use the driver information interface to customize certain features.

■

How to customize

Press the

 (home) button, then select the

Settings

 screen by rolling the left

selector wheel while the power mode is in ON, the vehicle is at a complete stop, and
the shift position is in

(

P

. Then, press the left selector wheel.

■

Settings

*

1

Settings

*

To customize other features, roll the left selector
wheel.

2

List of customizable options

 P. 124

2

Example of customization settings

 P. 130

When you customize settings, shift to

(

P

.

Driver

Information

Interface

Left Selector Wheel

 (home) Button

* Not available on all models

124

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

■

List of customizable options

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

TPMS
calibration

*

—

Calibrates the TPMS.

Cancel

/

Calibrate

Driver assist
system setup

Forward collision
warning distance

Changes the distance at which CMBS

TM

 alerts.

Long

/

Normal

*1

/

Short

ACC forward vehicle
detect beep

Causes the system to beep when a vehicle is detected or
when the vehicle is out of ACC with Low Speed Follow
range.

ON

/

OFF

*1

Road departure
mitigation setting

Changes the setting for the Road Departure Mitigation
system.

Narrow

/

Normal

*1

/

Wide

/

Warning only

Lane keeping assist
suspend beep

Causes the system to beep when the LKAS is suspended.

ON

/

OFF

*1

Blind spot
information

*

Changes the setting for the blind spot information.

Audible and visual
alert

*1

/

Visual alert

* Not available on all models

125

uu

Gauges and Driver Information Interface

u

Driver Information Interface

Continued

In

strum

ent Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Driver assist
system setup

Traffic sign
recognition system
display setting

Turns the traffic sign recognition system on and off.

ON

*1

/

OFF

Traffic sign
recognition system
exceeding speed
warning

Turns the traffic sign recognition system over speed
warning on and off.

ON

*1

/

OFF

Speed limit warning
threshold setting

Changes the setting speed the traffic sign recognition
system over speed warning is activated.

Speed limit

*1

/

Speed limit+3mph

/

Speed limit+5mph

/

Speed limit+10mph

(When mph is selected)

Speed limit

*1

/

Speed limit+5km/h

/

Speed limit+10km/h

/

Speed limit+15km/h

(When km/h is selected)

Driver attention
monitor

Changes the setting for the driver attention monitor.

Tactile and audible
alert

*1

/

Tactile alert

/

OFF

126

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Meter setup

Language selection

Changes the displayed language.

English

*1

/

Français

/

Español

Adjust outside temp.
display

Adjusts the temperature reading by a few degrees.

-5°F

 ~

±0°F

*1

 ~

+5°F



(U.S.)

-3°C

 ~

±0°C

*1

 ~

+3°C



(Canada)

“Trip A” reset timing

Changes the setting of how to reset trip meter A,
average fuel economy A, average speed A, and elapsed
time A.

When fully refueled

/

IGN OFF

/

Manually reset

*1

“Trip B” reset timing

Changes the setting of how to reset trip meter B,
average fuel economy B, average speed B, and elapsed
time B.

When fully refueled

/

IGN OFF

/

Manually reset

*1

Adjust alarm volume

Changes the alarm volume, such as buzzers, warnings,
turn signal sound, and so on.

High

/

Mid

*1

/

Low

Fuel efficiency backlight

Turns the ambient meter feature on and off.

ON

*1

/

OFF

Rear seat reminder

Turns the Rear Seat Reminder feature on and off.

ON

*1

/

OFF

Speed/distance units

Selects the trip meter units.

km/h∙km

/

mph∙miles

*1



(U.S.)

km/h∙km

*1

/

mph∙miles



(Canada)

Tachometer

Selects whether the tachometer is displayed on the
instrument panel.

ON

*1

/

OFF

127

uu

Gauges and Driver Information Interface

u

Driver Information Interface

Continued

In

strum

ent Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Keyless access
setup

*

Door unlock mode

Changes which doors unlock when you grab the driver’s
door handle.

Driver door only

*1

/

All

doors

Keyless access light
flash

Causes some exterior lights to flash when you unlock/
lock the doors.

ON

*1

/

OFF

Keyless access beep

Causes the beeper to sound when you unlock/lock the
doors.

ON

*1

/

OFF

Remote start system
ON/OFF

Turns the remote engine start feature on and off.

ON

*1

/

OFF

Lighting setup

Auto high-beam

Turns the auto high-beam on and off.

ON

*1

/

OFF

Interior light dimming
time

Changes the length of time the interior lights stay on
after you close the doors.

60sec

/

30sec

*1

/

15sec

Headlight auto off
timer

Changes the length of time the exterior lights stay on
after you close the driver’s door.

60sec

/

30sec

/

15sec

*1

/

0sec

Auto light sensitivity

*

Changes the timing for the headlights to come on.

Max

/

High

/

Mid

*1

/

Low

/

Min

Auto headlight ON
with wiper ON

Changes the settings for the wiper operation when the
headlights automatically come on while the headlight
switch is in the

AUTO

 position.

ON

*1

/

OFF

* Not available on all models

128

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Door setup

Auto door lock

Changes the setting for when the doors and the tailgate
automatically lock.

With vehicle speed

*1

/

Shift from P

/

OFF

Auto door unlock

Changes the setting for when the doors and the tailgate
automatically unlock.

All doors when driver’s
door opens

*1

/

All doors

when shifted to Park

/

All doors when ignition
switched OFF

/

OFF

Walk away auto lock

*

Changes the settings for the auto lock function when
you walk away from the vehicle.

ON

/

OFF

*1

Keyless lock answer
back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

ON

*1

/

OFF

Keyless remote power
window control

Turns remote window control using the keyless remote
on and off.

ON

*1

/

OFF

Lockout prevention

*

Changes the settings for the lockout protection
function.

ON

*1

/

OFF

Lock presetting

Changes the settings for the Lock Presetting function.

ON

*1

/

OFF

* Not available on all models
