Towing a Trailer

Towing Preparation

422

Driving

Towing equipment varies by the size of your trailer, how much load you are towing,
and where you are towing.

■

Hitches

The hitch must be of an approved type and properly bolted to the underbody.

■

Safety chains

Always use safety chains when you tow a trailer. Leave enough slack to allow the
trailer to turn corners easily, but do not allow the chains to drag on the ground.

■

Trailer brakes

If you are thinking of getting a trailer that has brakes, be sure they are electronically
actuated. Do not attempt to tap into your vehicle's hydraulic system. No matter how
successful it may seem, any attempt to attach trailer brakes to your vehicle's
hydraulic system will lower braking effectiveness and create a potential hazard.

■

Additional towing equipment

Many states and provinces/territories require special outside mirrors when towing a
trailer. Even if mirrors are not required in your locale, you should install special
mirrors if visibility is restricted in any way.

■

Towing Equipment and Accessories

Towing Equipment and Accessories

Make sure that all equipment is properly installed and
maintained, and that it meets federal, state, province/
territory, and local regulations.

Consult your trailer maker for proper installation and
setup of the equipment.
Improper installation and setup can affect the
handling, stability, and braking performance of your
vehicle.

Consult your trailer sales or rental agency if any other
items are recommended or required for your towing
situation.

The lighting and wiring of trailers can vary by type
and brand. If a connector is required, it should only
be installed by a qualified technician.

Trailer packages and products:

•

Ball mount, hitch plug, hitch pin etc.

•

Wiring harness kit

•

Trailer hitch kit

Are available at a dealer.

423

Towing a Trailer

Towing Preparation

Driving

■

Trailer light

Trailer lights and equipment must comply with federal, state, province/territory, and
local regulations. Check with your local trailer sales or rental agency for the
requirements in the area where you plan to tow.

We recommend that you have a dealer install a Honda wiring harness and converter.
They are designed for your vehicle.

The lighting and wiring of trailers can vary by type and brand. If a connector is
required, it should only be installed by a qualified technician.

Trailer light

The trailer lighting connector is located behind the
left side panel in the cargo area.
Even if you are planning to use the non-Honda trailer
lighting harness and converter, ask a dealer for the
correct connector and pins.

Right Turn Signal (Green)

Left Turn Signal (Light Blue)

Small (Gray)

Brake Light (Green)

+B Trailer (Light Violet/Red)

Grand (Black)

424

Towing a Trailer

Driving Safely with a Trailer

Driving

Driving Safely with a Trailer

•

Have the trailer properly serviced and keep it in good condition.

•

Make sure that all the weights and load in the vehicle and trailer are within limits.

Towing Load Limits

P. 421

•

Securely attach the hitch, safety chains, and other necessary parts to the trailer.

•

Securely store all the items in and on the trailer so that they do not shift while
driving.

•

Check if the lights and brakes on the trailer are working properly.

•

Check the pressure of the trailer tires, including the spare.

•

Turn off the Auto Idle Stop system using the Auto Idle Stop

OFF

button. The

trailer weight can affect your vehicle's brake effectiveness if Auto Idle Stop is
activated on a hill while towing a trailer.

•

Turn off the rear parking sensor system.

Parking sensor system on and off

P. 559

•

Turn off the Low Speed Braking Control system. It may activate if it detects the
towed object as an obstacle.

System On and Off

P. 484

•

Drive slower than normal.

•

Obey posted speed limits for vehicles with trailers.

•

Use the

(

position when towing a trailer on level roads.

■

Things You Need To Know Before Towing a Trailer

■

Towing Speeds and Shift Position

Driving Safely with a Trailer

Operating speed when towing a trailer must not
exceed 62 mph (100 km/h).

Parking
In addition to the normal precautions, place wheel
chocks at each of the trailer's tires.

When towing a trailer, we recommend that you carry
a full-size spare wheel and tire for both your vehicle
and trailer. If you use the compact spare tire that
came with your vehicle, it could adversely affect
vehicle driving stability.

Remember to unhitch the trailer before changing a
flat tire. Ask the trailer sales or rental agency where
and how to store the trailer’s spare tire.

Models with parking sensor system

Towing Speeds and Shift Position

When towing a fixed-sided trailer (e.g., camper), do
not exceed 55 mph (88 km/h). At higher speeds, the
trailer may sway or affect vehicle handling.

425

Towing a Trailer

Driving Safely with a Trailer

Driving

•

Turn more slowly and with a wider turning arc than normal.

•

Allow more time and distance for braking.

•

Do not brake or turn suddenly.

•

If the

Engine temperature near limit. Avoid heavy acceleration and high

speed.

message appear on the driver information interface, turn off the climate

control system and reduce speed.
If the

Engine temperature too hot. Do not drive. Allow engine to cool.

message appear on the driver information interface, pull to the side of the road
safely to cool down the engine.

■

Turning and Braking

■

Driving in Hilly Terrain

427

Driving

Off-Highway Driving Guidelines

General Information

Your vehicle has been designed primarily for use on pavement, however, its higher
ground clearance allows you to occasionally travel on unpaved roads. It is not
designed for trail-blazing, or other challenging off-highway activities.

If you decide to drive on unpaved roads, you will find that it requires somewhat
different driving skills and that your vehicle will handle somewhat differently than it
does on pavement. Pay attention to the precautions and tips in this section, and get
acquainted with your vehicle before leaving the pavement.

Important Safety Precautions

To avoid loss of control or rollover, be sure to follow all precautions and
recommendations:

•

Be sure to store cargo properly and do not exceed your cargo load limits.

Maximum Load Limit

P. 419

•

Whenever you drive, make sure you and your passengers always wear seat belts.

•

Keep your speed low, and never go faster than the conditions allow.

•

It’s up to you to continually assess the situation and drive within the limits.

Off-Highway Driving Guidelines

Failure to operate your vehicle correctly might result
in a crash or a rollover.

Important Handling Information

P. 40

Precautions While Driving

P. 436

WARNING

Improperly operating this vehicle on or off-
pavement can cause a crash or rollover in
which you and your passengers could be
seriously injured or killed.

•

Follow all instructions and guidelines in
this owner’s manual.

•

Keep your speed low, and don’t drive
faster than conditions permit.

428

Off-Highway Driving Guidelines

Avoiding Trouble

Driving

Avoiding Trouble

•

Check Out Your Vehicle

before you leave the pavement and make sure that all

scheduled maintenance has been completed. Pay special attention to the
condition of the tires, and check the tire pressures.

•

Remember

the route you choose presents limits (too steep or bumpy), you have

limits (driving skill and comfort), and your vehicle has limits (traction, stability, and
power). Failing to recognize these limits will likely put you and your passengers in
a hazardous situation.

•

Accelerating and Braking

should be done slowly and gradually. Trying to start

or stop too fast can cause a loss of traction and you could lose control.

•

Avoiding Obstacles and Debris

in the road reduces the likelihood of a rollover

or damage to your suspension or other components.

•

Driving on Slopes

increases your risk of a rollover, particularly if you attempt to

drive across a slope that is too steep. Going straight up or down a slope is usually
the safest. If you can’t clearly see all conditions or obstacles on a slope, walk it
before you drive it. If there is any doubt whether you can safely pass, don’t try it.
Find another route. If you get stuck when climbing, do not try to turn around.
Back down slowly following the same route you took up the hill.

•

Crossing a Stream

- Avoid driving through deep water. If you encounter water

in your route (a small stream or large puddle, for example), evaluate it carefully
before going ahead. Make sure it is shallow, flowing slowly, and has firm ground
underneath. If you are not sure of the depth or the ground, turn around and find
another route. Driving through deep water can also damage your vehicle. The
water can get into the transmission and differential, diluting the lubricant and
causing an eventual failure. It can also wash the grease out of the wheel bearings.

•

If You Get Stuck

, carefully go in the direction that you think will get you

unstuck. Do not spin the tires as this will only make things worse and could
damage the transmission. If you are unable to free yourself, your vehicle will need
to be towed. Front and rear tow hooks are provided for this purpose.

429

Continued

Driving

When Driving

Starting the Engine

Make sure the parking brake is applied.

The parking brake and brake system
indicator (red) comes on for 30 seconds
when you pull up the electric parking
brake switch.

Check that the transmission is in

(

, then

depress the brake pedal.

Although it is possible to start the vehicle
in

(

, it is safer to start it in

(

Press the

ENGINE START/STOP

button

without depressing the accelerator pedal.

Starting the Engine

Keep your foot firmly on the brake pedal when
starting the engine.

The engine is harder to start in cold weather and in
thinner air found at altitudes above 8,000 feet (2,400
meters).

When starting the engine in cold weather, turn off all
electrical accessories such as the lights, climate
control system, and rear defogger in order to reduce
battery drain.

If you live in a region where winter is extremely cold,
an engine block heater will improve starting and
warming of the engine. Consult a dealer for details.

If the exhaust system sounds abnormal or you can
smell exhaust gas inside the vehicle, have your vehicle
checked by a dealer. There may be a problem with
the engine or exhaust system.

Bring the keyless remote close to the

ENGINE

START/STOP

button if the battery in the keyless

remote is weak.

If the Keyless Remote Battery is Weak

P. 639

Electric Parking Brake Switch

Brake Pedal

Continued

431

When Driving

Starting the Engine

Driving

You can remotely start the engine using the keyless remote.

■

To start the engine

Press the

button, then press and hold

the

button.

Some exterior lights flash once.

If the engine starts successfully, some exterior
lights flash six times.

■

Remote Engine Start

Remote Engine Start

The remote engine start may violate local laws.
Before using the remote engine start, check your
local laws.

If there are buildings and obstacles between your
vehicle and the remote, the range will be reduced.
This distance may vary by external electrical
interference.

WARNING

Carbon monoxide gas is toxic and can
rapidly accumulate in closed or even partly
enclosed areas.

Breathing it can cause unconsciousness and
even kill you.

Never use the remote engine starter with
the vehicle parked in a garage or other
areas with limited ventilation.

LED: Blinks when any
button is pressed.

* Not available on all models

When Driving

Starting the Engine

432

Driving

If the engine does not start, exterior lights will
not flash.

Go within the range, and try again.

When started remotely, the engine automatically shuts off after 10 minutes of idling
and/or the brake pedal and

ENGINE START/STOP

button have not been pressed

simultaneously.
To extend the run time for another 10 minutes during the first run, press the

button, then press and hold the

button.

Some exterior lights flash six times if a 10-minute extension request was
transmitted successfully.

Remote Engine Start

The engine may not start by the remote engine start
if:

•

You have disabled a remote engine start setting.

Settings

P. 129

Customized Features

P. 359

•

The power mode is not in VEHICLE OFF.

•

The transmission is in a position other than

(

•

The hood is open, or any door or the tailgate is
unlocked.

•

You have already used the remote twice to start
the engine.

•

Another registered keyless remote is in the vehicle.

•

There is any antenna failure.

•

The door is unlocked with the built-in key.

•

The engine oil pressure is low.

•

The engine coolant temperature is extremely high.

•

The security system alarm is not set.

•

The 12-volt battery charge is too low.

* Not available on all models

Continued

433

When Driving

Starting the Engine

Driving

■

To stop the engine

Press and hold the

button for one

second.

If the engine stops successfully, the exterior
lights flash once.

When the remote is out of the keyless access
system range, the exterior lights will not flash.
The engine will not stop.

Go within the range, and try again.

Remote Engine Start

The engine may stop while it is running if:

•

You do not start the vehicle within 10 minutes of
starting the engine with the keyless remote.

•

The engine is stopped by using the keyless remote.

•

The security system alarm is not set.

•

The door is unlocked with the built-in key.

•

The hood is open, or any door, or the tailgate is
unlocked.

•

You press the shift lever release button.

•

The engine coolant temperature is extremely high.

•

The battery is low.

•

The engine oil pressure is low.

•

The malfunction indicator lamp comes on if there is
a problem with the emissions control systems.

While the engine is running, the vehicle will
automatically precondition inside the vehicle.
When it is warm outside:

•

The climate control system is activated in
recirculation mode.

When it is cold outside:

•

The defroster is activated at a moderately warm
temperature.

•

The rear defogger, heated door mirrors

, seat

heaters

and heated steering wheel

are activated.

Rear Defogger/Heated Door Mirror

Button

P. 189

Heated Steering Wheel

P. 220

Front Seat Heaters

P. 221

* Not available on all models

When Driving

Starting the Engine

434

Driving

Depress and hold the brake pedal, then press the

ENGINE START/STOP

button.

Keeping your right foot on the brake pedal, put the transmission into

(

. Select

(

when reversing.

With the parking brake applied, release the brake pedal and gently depress the
accelerator pedal.

Make sure the parking brake and brake system indicator (red) goes off.

Parking Brake

P. 546

■

Hill start assist system

Hill start assist keeps the brake engaged briefly to help prevent the vehicle from
rolling on inclines as you move your foot from the brake pedal to the accelerator.

Put the transmission into

(

, or

(

when facing uphill, or

(

when facing

downhill, then release the brake pedal.

■

Starting to Drive

Starting to Drive

The engine stops when the transmission is taken out
of

(

before the

ENGINE START/STOP

button is

pressed. Follow step 1 when starting to drive.

You can also release the parking brake by pressing
the electric parking brake switch while depressing the
brake pedal.
When facing downhill, you can start your vehicle
more smoothly by manually releasing it with the
electric parking brake switch than by releasing it with
the accelerator pedal.

When the engine was started using the

button on

the keyless remote

When the engine was started using the

button on the keyless remote

When the engine was started in any case

Hill start assist system

Hill start assist may not prevent the vehicle from
rolling downhill on a very steep or slippery slope, and
will not operate on small inclines.

Hill start assist is not a replacement for the parking
brake.

Hill start assist will operate even when VSA

switched off.

435

When Driving

Starting the Engine

Driving

You can turn the engine off when the vehicle is completely stopped.

Put the transmission into

(

Press the

ENGINE START/STOP

button.

■

Stopping the Engine

Stopping the Engine

The power mode will automatically turn to VEHICLE
OFF about 20 minutes after the following conditions
have been met:

•

A door has been opened, such as when leaving the
vehicle.

•

The transmission is in

(

•

The driver’s seat belt is not fastened.

436

When Driving

Precautions While Driving

Driving

Precautions While Driving

Utility vehicles have a significantly higher rollover rate than other types of vehicles.
To prevent rollovers or loss of control:

•

Take corners at slower speeds than you would with a passenger vehicle.

•

Avoid sharp turns and abrupt maneuvers whenever possible.

•

Do not modify your vehicle in any way that you would raise the center of gravity.

•

Do not carry heavy cargo on the roof.

Never carry more than 165 lbs (75 kg) of cargo on the roof rack (Honda accessory).

Avoid driving in deep water and on flooded roads. This can damage the engine or
driveline, or cause electrical component failure.

If there is a strong impact with something under the vehicle, stop in a safe location.
Check the underside of the vehicle for damage or any fluid leaks.

■

Driving Guidelines for Your Utility Vehicle

■

In Rain

■

Other Precautions

Precautions While Driving

NOTICE

Do not operate the shift lever while pressing the
accelerator pedal. You could damage the
transmission.

NOTICE

If you repeatedly turn the steering wheel at an
extremely low speed, or hold the steering wheel in
the full left or right position for a while, the electric
power steering (EPS) system heats up. The system
goes into a protective mode, and limits its
performance. The steering wheel becomes harder
and harder to operate. Once the system cools down,
the EPS system is restored.
Repeated operation under these conditions can
eventually damage the system.

If the power mode is set to ACCESSORY while
driving, the engine will shut down and all steering
and brake power assist functions will stop, making it
difficult to control the vehicle.

Do not select

(

while driving as you will lose engine

braking (and acceleration) performance.

During the first 600 miles (1,000 km) of operation,
avoid sudden acceleration or full throttle operation so
as not to damage the engine or powertrain.

Avoid hard braking for the first 200 miles (300 km)
after purchasing your new vehicle or replacing the
brake pads or rotors, to allow for proper break-in.

437

When Driving

Continuously Variable Transmission

Driving

Continuously Variable Transmission

When the engine runs at higher idle speeds, the creeping force increases.
Keep the brake pedal firmly depressed when stopped.

Quickly depressing the accelerator pedal while driving uphill may cause the
transmission to drop to a lower ratio, unexpectedly increasing vehicle speed.
Depress the accelerator pedal carefully, especially on slippery roads and curves.

Driving Guidelines for Your Utility Vehicle

Failure to operate your vehicle correctly might result
in a crash or a rollover.

Important Handling Information

P. 40

■

Creeping

■

Kickdown

438

When Driving

Shifting

Driving

Shifting

Change the shift position in accordance with your driving needs.

■

Shift positions

Shifting

You cannot change the power mode from ON to
VEHICLE OFF unless the shift position is in

(

The vehicle may move very slightly even in

(

while

the engine is cold.
Depress the brake pedal firmly and, when necessary,
apply the parking brake.

Reverse

Used when reversing.

Drive

Used for normal driving.

Park

Used when parking or starting the
engine.

Neutral

Transmission is not locked.

Release Button

Drive (S)

Used:

●

For better acceleration.

●

To increase engine braking.

●

When going up or down hills.

Low

●

Used to further increase engine braking.

●

Used when going up or down hills.

439

When Driving

Shifting

Driving

■

Shift Operation

Shift Operation

NOTICE

When you change the shift position from

(

and vice versa, come to a complete stop and keep the
brake pedal depressed.
Operating the shift lever before the vehicle has come
to a complete standstill can damage the transmission.

Use the shift position indicator to check the lever
position before pulling away.

If the transmission system indicator blinks when
driving, in any shift position, there is a problem with
the transmission.
Avoid sudden acceleration and have the transmission
checked by a dealer as soon as possible.

The fuel supply may be cut off if you drive at engine
speeds in or over the tachometer red zone (engine
speed limit). If this happens, you may experience a
slight jolt.

It may not be possible to operate the shift lever if the
brake pedal is applied while the shift lever release
button is held down.
Depress the brake pedal first.

When shifting positions in extremely low
temperatures (-22°F/-30°C), there may be a short
delay before the shift position is displayed. Always
confirm you are in the correct shift position before
driving.

Shift Position Indicator
(Transmission System
Indicator)

Depress the brake pedal and press the shift lever release
button to shift.

Shift without pressing the shift lever release button.

Press the shift lever release button and shift.

Tachometer red zone

440

When Driving

Auto Idle Stop

Driving

Auto Idle Stop

To help maximize fuel economy, the engine automatically stops when the vehicle
comes to a stop, depending on environmental and vehicle operating conditions. The
indicator (green) comes on at this time.

The environmental and vehicle conditions that
impact Auto Idle Stop system operation are
varied.

Auto Idle Stop Activates When:

P. 442, 443

The engine then restarts once the vehicle is
about to move again, and the indicator
(green) goes off.

The Engine Automatically Restarts When:

P. 444

If the driver’s door is opened while the
indicator (green) comes on, a buzzer sounds
to notify you that the Auto Idle Stop function
is in operation.

A message associated with Auto Idle Stop
appears on the driver information interface.

Auto Idle Stop

The 12-volt battery installed in this vehicle is
specifically designed for a model with Auto Idle Stop.
Using a 12-volt battery other than this specified type
may shorten the 12-volt battery life, and prevent
Auto Idle Stop from activating. If you need to replace
the 12-volt battery, make sure to select the specified
type. Ask a dealer for more details.

The duration of the Auto Idle Stop operation:

•

Increase in

ECON

mode, compared to when

ECON

mode is off, with climate control in use.

Drive Mode Switch

P. 446

Auto Idle Stop
Indicator (Green)

Continued

441

When Driving

Auto Idle Stop

Driving

The Auto Idle Stop suspend indicator comes
on and a message appears on the gauge
when the Auto Idle Stop system cannot be
activated.

Indicators

P. 90

Auto Idle Stop System ON/OFF

P. 441

To turn the Auto Idle Stop system off, press
this button. The Auto Idle Stop system stops.

Auto Idle Stop system will stop, the
indicator will come on and a message
appears on the gauge.

The Auto Idle Stop system is turned on every
time you start the engine, even if you turned it
off the last time you drove the vehicle.

Auto Idle Stop
Suspend Indicator

■

Auto Idle Stop System ON/OFF

Auto Idle Stop System ON/OFF

If you turn off the Auto Idle Stop system while it is
activated, the engine will restart.

If you hold the Auto Idle Stop

OFF

button, you can

disable idle stop messages.

Indicators

P. 90

Auto Idle Stop

OFF

Indicator

Auto Idle Stop

OFF

button

When Driving

Auto Idle Stop

442

Driving

The vehicle stops with the transmission in

(

and the brake pedal depressed.

When you put the transmission into

(

quickly with depressing the brake pedal, the

Auto Idle Stop continues to operate, even if the brake pedal is released.

If you depress the brake pedal, the engine may automatically restart.

■

Auto Idle Stop does not activate when:

•

The Auto Idle Stop

OFF

button is pressed.

•

The driver’s seat belt is not fastened.

•

The engine is not adequately warmed up or coolant temperature is high.

•

The transmission fluid temperature is low or high.

•

The vehicle comes to a stop again before the vehicle speed reaches 3 mph (5
km/h) after the engine starts.

•

The vehicle is stopped on a steep incline.

•

The transmission is in a position other than

(

•

The engine is started with the hood open.

Turn off the engine. Close the hood before you restart the engine to activate
Auto Idle Stop.

•

The battery charge is low.

•

The internal temperature of the battery is 41°F (5°C) or less.

•

The climate control system is in use, and the outside temperature is below −4°F
(−20°C) or over 104°F (40°C).

•

The climate control system is in use, and the temperature is set to

•

is ON (indicator on).

•

The drive mode is in the

SNOW

mode.

■

Auto Idle Stop Activates When:

Auto Idle Stop Activates When:

Do not open the hood while the Auto Idle Stop
function is activated. If the hood is opened, the
engine will not restart automatically.
In this case, restart the engine with the

ENGINE

START/STOP

button.

Starting the Engine

P. 429

When Adaptive Cruise Control (ACC) with Low
Speed Follow is in operation, the vehicle stops
without depressing the brake pedal and Auto Idle
Stop may activate. In such cases, the engine may
restart if you change the shift position other than

(

Pressing the

ENGINE START/STOP

button causes

the engine to no longer restarts automatically. Follow
the standard procedure to start the engine.

Starting the Engine

P. 429

443

When Driving

Auto Idle Stop

Continued

Driving

■

Auto Idle Stop may not activate when:

•

The vehicle is stopped by braking suddenly.

•

The steering wheel is operated.

•

The vehicle is repeatedly accelerated and decelerated at a low speed.

•

The fan speed is high.

•

The climate control system is in use, and there is a significant difference between
the set temperature and the actual interior temperature.

•

The climate control system is in use, and humidity in the interior is high.

•

Altitude is high.

When Driving

Auto Idle Stop

444

Driving

•

The brake pedal is released (without the automatic brake hold system activated).

•

The accelerator pedal is depressed (with the automatic brake hold system
activated).

Automatic Brake Hold

P. 551

•

When the transmission is put into

(

from

(

on a slope.

■

The engine restarts even if the brake pedal is depressed

when:

•

The Auto Idle Stop

OFF

button is pressed.

•

The steering wheel is operated.

•

The transmission is put into

(

, or

(

, or when it is set from

(

If you put the transmission into

(

after the Auto Idle Stop activates, the Auto

Idle Stop continues to operate. In this case, the engine restarts when you
depress the brake pedal.

•

The pressure on the brake pedal is reduced and the vehicle starts moving while
stopped on an incline.

•

The brake pedal is released slightly during a stop.

•

The battery charge becomes low.

•

The accelerator pedal is depressed.

•

The driver’s seat belt is unlatched.

•

is ON (indicator on).

•

The climate control system is in use, and the difference between the set
temperature and actual interior temperature becomes significant.

•

The climate control system is being used to dehumidify the interior.

•

The vehicle ahead of you starts again when your vehicle stops automatically with
Adaptive Cruise Control (ACC) with Low Speed Follow.

•

The

SNOW

mode is selected by using the

DRIVE MODE

switch.

■

The Engine Automatically Restarts When:

The Engine Automatically Restarts When:

If you are using an electronic device during Auto Idle
Stop, the device may temporarily be turned off when
the engine restarts.

The engine restarts even if the brake pedal is depressed

when:

*1: With the automatic brake hold system activated,
you can release the brake pedal while Auto Idle Stop
is in operation.

If the automatic brake hold system has been turned
off, or if there is a problem with the system, the
engine will restart automatically when you release
the brake pedal.

Automatic Brake Hold

P. 551

446

When Driving

Drive Mode Switch

Driving

Drive Mode Switch

You can choose between three modes,

NORMAL

mode,

ECON

mode and

SNOW

mode by using the

DRIVE MODE

switch.

The current mode is displayed on the driver information interface, and each mode
will appear differently.

Drive Mode Switch

The mode may not be able to be changed when:

•

The vehicle is turning.

•

The VSA

system is activating.

•

There is a problem with the engine, the
transmission, the VSA

, and the EPS.

DRIVE MODE

Switch

NORMAL

Mode

ECON

Mode

SNOW

Mode

When Driving

Drive Mode Switch

448

Driving

Maximizes controllability on snowy road
through powertrain settings.

The mode for the next start-up is saved according to the following chart.

■

SNOW Mode

SNOW

Mode

NOTICE

SNOW

mode does not allow you to drive on snowy

or frozen roads in all situations. There are limits to

SNOW

mode.

When driving on snowy or frozen roads; mount
winter tires or tire chains, reduce speed, and maintain
sufficient distance between vehicles.

Winter Tires

P. 615

While in

SNOW

mode, the Auto Idle Stop System will

stay disabled regardless of the Auto Idle Stop

OFF

button.

Auto Idle Stop

P. 440

■

Next Start-up Mode

Last Mode

Next Mode

NORMAL

SNOW

NORMAL

ECON

449

When Driving

Hill Descent Control System

Continued

Driving

Hill Descent Control System

When driving down hills where engine braking is not enough to decelerate the
vehicle, this system helps maintain a constant vehicle speed without needing to
depress the brake pedal.

The system operates under the following conditions.

•

Driving at a speed between about 2-12 mph (3-20 km/h).

•

Driving downhill.

•

Accelerator pedal and brake pedal are not depressed.

The system’s operating status

•

Green: Activated

•

White: Standby

Vehicle speed display

•

White: Set speed

•

Grey: Current speed

Blinks when the vehicle speed is above
the operating speed.

■

Hill Descent Control Operating Conditions

■

Driver Information Interface Display

Hill Descent Control System

The brake lights automatically come on while the
system is in operation.

The system may not operate when driving down a
gentle slope. Check the Hill Descent Control System
indicator to see if the system is in operation.

The system may activate even when not driving
downhill, such as when the vehicle leans while
driving over uneven surfaces.

WARNING

Hill descent control cannot maintain a
constant vehicle speed in every situation.

When driving down a very steep hill or on
slippery road surfaces, the vehicle may not
be able to maintain the vehicle speed and
could cause a crash, resulting in serious
injury or death.

Since Hill Descent Control is not designed
to increase the limits of vehicle
performance, the driver must always be
aware of road surface conditions and drive
safely.

System’s Operating Status

Vehicle Speed
Display

Current Speed

Operating Range of Set Speed

When Driving

Hill Descent Control System

450

Driving

■

To turn the system on

When the vehicle speed is less than about 12
mph (20 km/h), press the

button to turn

the system on.

The system goes into standby mode, and
the Hill Descent Control System indicator
(white) comes on.

When all the working conditions are met, the
system activates, and the vehicle begins to
maintain the vehicle speed when driving
downhill.

The Hill Descent Control System indicator
(green) comes on when operating.

■

To adjust the set speed

Depress the accelerator pedal or brake pedal
to adjust the vehicle speed within the
operating range. The vehicle speed at which
you release the accelerator pedal or brake
pedal will be the set speed.

■

To turn the system off

Press the

button to turn the system off.

■

How to Operate Hill Descent Control

How to Operate Hill Descent Control

Using the system repeatedly for a long time may
cause the brakes to heat up and make the system go
into standby mode temporarily.

Hill Descent Control is turned off every time you turn
the engine off, even if it was turned on the last time
you drove the vehicle.

The pedals may vibrate or you may hear the system
working when in operation.

Hill Descent Control System
Indicator

(Hill Descent Control) Button

To turn the system off

When the vehicle speed is about 37 mph (60 km/h) or
more, the system turns off automatically.

451

When Driving

Vehicle Stability Assist

(VSA

), aka Electronic Stability Control (ESC), System

Continued

Driving

Vehicle Stability Assist

(VSA

), aka Electronic

Stability Control (ESC), System

VSA

helps stabilize the vehicle during cornering if the vehicle turns more or less

than what was intended. It also assists in maintaining traction on slippery surfaces.
It does so by regulating engine output and selectively applying the brakes.

When VSA

activates, you may notice that the

engine does not respond to the accelerator.
You may also notice some noise from the
hydraulic brake system. You will also see the
indicator blink.

■

VSA

Operation

Vehicle Stability Assist

(VSA

), aka Electronic Stability Control

(ESC), System

The VSA

may not function properly if tire type and

size are mixed. Make sure to use the same size and
type of tire, and the air pressures as specified.

When the VSA

system indicator comes on and stays

on while driving, there may be a problem with the
system. While this may not interfere with normal
driving, have your vehicle checked by a dealer
immediately.

VSA

cannot enhance stability in all driving situations

and does not control the entire braking system. You
still need to drive and corner at speeds appropriate
for the conditions and always leave a sufficient
margin of safety.

The main function of the VSA

system is generally

known as Electronic Stability Control (ESC). The
system also includes a traction control function.

The Vehicle Stability Assist

(VSA

) system, brake

system (Amber), Adaptive Cruise Control (ACC) with
Low Speed Follow, low tire pressure/TPMS

and safety

support indicators may come on in amber along with a
message in the gauge when you set the power mode
to ON after reconnecting the battery.
Drive a short distance at more than 12 mph (20 km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

VSA

System

Indicator

* Not available on all models

When Driving

Vehicle Stability Assist

(VSA

), aka Electronic Stability Control (ESC), System

452

Driving

This button is on the driver side control panel.
To partially disable VSA

functionality/

features, press and hold it until you hear a
beep.

Your vehicle will have normal braking and
cornering ability, but traction control function
will be less effective.

To restore VSA

functionality/features, press

the

(VSA

OFF

) button until you hear a

beep.

VSA

is turned on every time you start the

engine, even if you turned it off the last time
you drove the vehicle.

■

VSA

On and Off

Vehicle Stability Assist

(VSA

), aka Electronic Stability Control

(ESC), System

In certain unusual conditions when your vehicle gets
stuck in shallow mud or fresh snow, it may be easier
to free it with the VSA

temporarily switched off.

When the

button is pressed, the traction control

function becomes less effective. This allows for the
wheels to spin more freely at low speed. You should
only attempt to free your vehicle with the VSA

off if

you are not able to free it when the VSA

is on.

Immediately after freeing your vehicle, be sure to
switch VSA

on again. We do not recommend driving

your vehicle with the VSA

system switched off.

You may hear a motor sound coming from the
engine compartment while system checks are being
performed immediately after starting the engine or
while driving. This is normal.

VSA

OFF

Indicator

453

When Driving

Agile Handling Assist

Driving

Agile Handling Assist

Lightly brakes each of the front and rear wheels, as needed, when you turn the
steering wheel, and helps support the vehicle’s stability and performance during
cornering.

Agile Handling Assist

The agile handling assist cannot enhance stability in
all driving situations. You still need to drive and
corner at speeds appropriate for the conditions and
always leave a sufficient margin of safety.

When the VSA

system indicator comes on and stays

on while driving, the agile handling assist does not
activate.

You may hear a sound coming from the engine
compartment while the agile handling assist is
activated. This is normal.

Honda CR-V (2024 year). Manual in english - page 13
