Honda Accord (2024 year). Manual in english

Airbags

Airbag Care

Safe

Driving

Airbag Care

You do not need to, and should not, perform any maintenance on or replace any
airbag system components yourself. However, you should have your vehicle
inspected by a dealer in the following situations:

■

When the airbags have deployed

If an airbag has inflated, the control unit and other related parts must be replaced.
Similarly, once an automatic seat belt tensioner has been activated, it must be
replaced.

■

When the vehicle has been in a moderate-to-severe collision

Even if the airbags did not inflate, have your dealer inspect the following: the driver’s
seat position sensor, weight sensors in the passenger’s seat, seat belt tensioners for
the front seats and outer rear seats, and each seat belt that was worn during the
crash.

■

Do not remove or modify a front seat without consulting a dealer

This would likely disable or affect the proper operation of the driver’s seat position
sensor or the weight sensors in the passenger’s seat. If it is necessary to remove or
modify a front seat to accommodate a person with disabilities, contact a Honda
dealer. For U.S. vehicles, contact American Honda Automobile Customer Service at
1-800-999-1009. For Canadian vehicles, contact Honda Canada Customer Relations
at 1-888-9-HONDA-9.

Airbag Care

We recommend against the use of salvaged airbag
system components, including the airbag, tensioners,
sensors, and control unit.

Safe

Driving

Child Safety

Protecting Child Passengers

Each year, many children are injured or killed in vehicle crashes because they are
either unrestrained or not properly restrained. In fact, vehicle crashes are the
number one cause of death of children ages 12 and under.

To reduce the number of child deaths and injuries, every state and Canadian
province and territory requires that infants and children be properly restrained when
they ride in a vehicle.

Children should sit properly restrained in a rear seat.

This is because:

•

An inflating front airbag can injure or kill a
child sitting in the front seat.

•

A child in the front seat is more likely to
interfere with the driver’s ability to safely
control the vehicle.

•

Statistics show that children of all sizes and
ages are safer when they are properly
restrained in a rear seat.

Protecting Child Passengers

The National Highway Traffic Safety Administration
and Transport Canada recommend that all children
ages 12 and under be properly restrained in a rear
seat. Some states or provinces/territories have laws
restricting where children may ride.

WARNING

Children who are unrestrained or

improperly restrained can be seriously

injured or killed in a crash.

Any child too small for a seat belt should be

properly restrained in a child seat. A larger

child should be properly restrained with a

seat belt, using a booster seat if necessary.

Child Safety

Protecting Child Passengers

Safe

Driving

•

Never hold a child on your lap because it is impossible to protect them in the
event of a collision.

•

Never put a seat belt over yourself and a child. During a crash, the belt would
likely press deep into the child and cause serious or fatal injuries.

•

Never let two children use the same seat belt. Both children could be very
seriously injured in a crash.

•

Any child who is too small to wear a seat belt correctly must be restrained in an
approved child seat that is properly secured to the vehicle using either the seat
belt or the lower anchors of the LATCH system.

•

Do not allow children to operate the doors, windows, or seat adjustments.

•

Do not leave children in the vehicle unattended, especially in hot weather when
the inside of the vehicle can get hot enough to kill them. They could also activate
vehicle controls causing it to move unexpectedly.

Protecting Child Passengers

To deactivate a lockable retractor, release the buckle
and allow the seat belt to wind up all the way.

To remind you of the passenger’s front airbag
hazards and child safety, your vehicle has warning
labels on the dashboard (U.S. models) and on the
front visors. Please read and follow the instructions
on these labels.

Safety Labels

P. 82

WARNING

Allowing a child to play with a seat belt or

wrap one around their neck can result in

serious injury or death.

Instruct children not to play with any seat

belt and make sure any unused seat belt a

child can reach is buckled, fully retracted,

and locked.

Child Safety

Safety of Infants and Small Children

Safe

Driving

Safety of Infants and Small Children

An infant must be properly restrained in a rear-facing child seat until the infant
reaches the seat manufacturer’s weight or height limit for the seat.

■

Positioning a rear-facing child seat

Child seats must be placed and secured in a
rear seating position.

When properly installed, a rear-facing child seat may prevent the driver or a front
passenger from moving their seat all the way back, or from locking their seat-back
in the desired position. Make sure that there is no contact between the child seat
and the seat in front of it.

It can also interfere with proper operation of the passenger’s advanced front airbag
system.

Airbags

P. 49

If this occurs, we recommend that you install the child seat directly behind the front
passenger’s seat, move the seat as far forward as needed, and leave it unoccupied.
Or, you may wish to get a smaller rear-facing child seat.

■

Protecting Infants

Protecting Infants

Experts recommend use of a rear-facing seat for a
child so long as the child’s height and weight are
appropriate for a rear-facing seat.

Infants should never be seated in a forward-facing
position.

Always refer to the child seat manufacturer’s
instructions before installation.

Do not allow a front seat to rest against a child seat
installed in a rear seating position:
The weight sensor in the front seat may not correctly
detect the actual weight of the occupant.

WARNING

Placing a rear-facing child seat in the front

seat can result in serious injury or death

during a crash.

Always place a rear-facing child seat in the

rear seat, not the front.

Continued

Child Safety

Safety of Infants and Small Children

Safe

Driving

If a child has exceeded the weight and height limitations of a rear-facing child seat,
the child should be properly restrained in a firmly secured forward-facing child seat
until they exceed the weight and height limitations for the forward-facing child seat.

■

Forward-facing child seat placement

We strongly recommend placing a forward-
facing child seat in a rear seating position.

Placing a forward-facing child seat in the front seat can be hazardous, even with
advanced front airbags that automatically turn the passenger’s front airbag off. A
rear seat is the safest place for a child.

■

Protecting Smaller Children

Protecting Smaller Children

Educate yourself about the laws and regulations
regarding child seat use where you are driving, and
follow the child seat manufacturer’s instructions.

WARNING

Placing a forward-facing child seat in the

front seat can result in serious injury or

death if the front airbag inflates.

If you must place a forward-facing child

seat in front, move the vehicle seat as far

back as possible, and properly restrain the

child.

Child Safety

Safety of Infants and Small Children

Safe

Driving

Most child seats are LATCH-compatible (Lower Anchors and Tethers for Children).
Some have a rigid-type connector, while others have a flexible-type connector. Both
are equally easy to use. Some existing and previously owned child seats can only be
installed using the seat belt. Whichever type you choose, follow the child seat
manufacturer’s use and care instructions including recommended expiration dates
as well as the instructions in this manual. Proper installation is key to maximizing
your child’s safety.

In seating positions and vehicles not equipped with LATCH, a LATCH-compatible
child seat can be installed using the seat belt and a top tether for added security.
This is because all child seats are required to be designed so that they can be secured
with a lap belt or the lap part of a lap/shoulder belt. In addition, the child seat
manufacturer may advise that a seat belt be used to attach a LATCH-compatible seat
once a child reaches a specified weight. Please read the child seat owner’s manual
for proper installation instructions.

■

Important consideration when selecting a child seat

Make sure the child seat meets the following three requirements:

•

The child seat is the correct type and size for the child.

•

The child seat is the correct type for the seating position.

•

The child seat is compliant with Federal Motor Vehicle Safety Standard 213 or
Canadian Motor Vehicle Safety Standard 213.

■

Selecting a Child Seat

Selecting a Child Seat

Installation of a LATCH-compatible child seat is
simple.

LATCH-compatible child seats have been developed
to simplify the installation process and reduce the
likelihood of injuries caused by incorrect installation.

Continued

Child Safety

Safety of Infants and Small Children

Safe

Driving

A LATCH-compatible child seat can be installed in either of the two outer rear seats.
A child seat is attached to the lower anchors with either the rigid or flexible type of
connectors.

Locate the anchor marks affixed to the
base of the seat cushion.

Pull out the anchor covers with the marks
to expose the lower anchors.

Place the child seat so that the probes are
on the cover.

■

Installing a LATCH-Compatible Child Seat

Installing a LATCH-Compatible Child Seat

WARNING

Never attach two child seats to the same

anchor. In a collision, one anchor may not

be strong enough to hold two child seat

attachments and may break, causing

serious injury or death.

Marks
Cover

Probes

Child Safety

Safety of Infants and Small Children

Safe

Driving

Attach the child seat to the lower anchors
according to the instructions that came
with the child seat.

When installing the child seat, make
sure that the lower anchors are not
obstructed by the seat belt or any other
object.

Installing a LATCH-Compatible Child Seat

For your child’s safety, when using a child seat
installed using the LATCH system, make sure that the
child seat is properly secured to the vehicle.
A child seat that is not properly secured will not
adequately protect a child in a crash and may cause
injury to the child or other vehicle occupants.

Rigid Type

Lower Anchors

Flexible Type

Lower Anchors

Continued

Child Safety

Safety of Infants and Small Children

Safe

Driving

Open the tether anchor cover behind the
head restraint.

Route the tether strap over the top of the
head restraint.
Make sure the strap is not twisted.

Route the tether strap over the side of the
head restraint.
Make sure the strap is not twisted.

Secure the tether strap hook to the
anchor.

Tighten the tether strap as instructed by
the child seat manufacturer.

Make sure the child seat is firmly secured
by rocking it forward and back and side to
side; little movement should be felt.

10.

Make sure any unused seat belt that a
child can reach is buckled, the lockable
retractor is activated, and the belt is fully
retracted and locked.

Installing a LATCH-Compatible Child Seat

Installing a LATCH-compatible child seat in the
rear center seat

Each outer rear seat is equipped with a pair of lower
anchors which are used to secure a LATCH-
compatible child seat. The rear center seat, however,
is not equipped with anchors of any kind.
The inner and outer anchors are spaced apart at a
standard distance of 11 inches (280 mm). The
distance between the two inner anchors is 15.4
inches (390 mm).
LATCH-compatible restraint systems that are fitted
with rigid-type attachments cannot be installed in the
rear center seat. However, a system fitted with
flexible-type attachments can be installed in the
center seat, provided that the manufacturer’s
instructions for that system permit the use of the
inner anchors with the stated spacing.
Before seating a child, make sure that the system is
properly attached to both the lower anchors and
tether anchors.

WARNING

Using the outer rear seats' inner anchors to

secure a LATCH-compatible child seat in the

center seating position may result in failure

of the child seat, causing injury or death.

Only use the outer rear seats' inner anchors

to install a child seat in the center seating

position if the manufacturer's instructions

expressly permit.

Anchor

Tether Strap

Hook

Straight top tether type

Other top tether type

Tether Strap

Hook

Anchor

Straight top tether type

Other top tether type

All types

Child Safety

Safety of Infants and Small Children

Safe

Driving

A child seat can be installed with a lap/shoulder belt in any rear seat or, if absolutely
necessary, the front passenger seat.

Place the child seat on the vehicle seat.

Route the seat belt through the child seat
according to the seat manufacturer’s
instructions, and insert the latch plate into
the buckle.

Insert the latch plate fully until it clicks.

Slowly pull the shoulder part of the belt all
the way out until it stops. This activates the
lockable retractor.

Let the seat belt retract a few inches and
check that the retractor has switched
modes by pulling on the webbing. It should
not pull out again until it is reset by
removing the latch plate from the buckle.

If you are able to pull the shoulder belt
out, the lockable retractor is not
activated. Slowly pull the seat belt all the
way out, and repeat steps 3 – 4.

■

Installing a Child Seat with a Lap/Shoulder Seat Belt

Installing a Child Seat with a Lap/Shoulder Seat Belt

A child seat that is not properly secured will not
adequately protect a child in a crash and may cause
injury to the child or other vehicle occupants.

Continued

Child Safety

Safety of Infants and Small Children

Safe

Driving

Grab the shoulder part of the seat belt near
the buckle, and pull up to remove any slack
from the lap part of the belt.

When doing this, place your weight on
the child seat and push it into the vehicle
seat.

Make sure the child seat is firmly secured by
rocking it forward and back and side to
side; less than one inch of movement
should occur near the seat belt.

Make sure any unused seat belt that a child
can reach is buckled, the lockable retractor
is activated, and the belt is fully retracted
and locked.

Installing a Child Seat with a Lap/Shoulder Seat Belt

To deactivate a lockable retractor, release the buckle
and allow the seat belt to wind up all the way.

Child Safety

Safety of Infants and Small Children

Safe

Driving

A tether anchor point is provided behind each
rear seating position.
If you have a child seat that comes with a
tether but can be installed with a seat belt, the
tether may be used for additional security.

Locate the appropriate tether anchor point
and lift the cover.

Route the tether strap over the top of the
head restraint. Make sure the strap is not
twisted.

Route the tether strap over the side of the
head restraint. Make sure the strap is not
twisted.

Secure the tether strap hook to the anchor.

Tighten the tether strap as instructed by the
child seat manufacturer.

■

Adding Security with a Tether

Adding Security with a Tether

Always use a tether for forward-facing child seats
whether using the seat belt or lower anchors.

Tether Anchor Points

Cover

Anchor

Tether Strap

Hook

Straight top tether type

Anchor

Tether Strap

Hook

Other top tether type

Straight top tether type

Other top tether type

All types

Child Safety

Safety of Larger Children

Continued

Safe

Driving

Safety of Larger Children

The following pages give instructions on how to check proper seat belt fit, what kind
of booster seat to use if one is needed, and important precautions for a child who
must sit in front.

When a child is too big for a child seat, secure the child in a rear seat using the lap/
shoulder seat belt. Have the child sit upright and all the way back, then answer the
following questions.

■

Checklist

•

Do the child’s knees bend comfortably over
the edge of the seat?

•

Does the shoulder belt cross between the
child’s neck and arm?

•

Is the lap part of the seat belt as low as
possible, touching the child’s thighs?

•

Will the child be able to stay seated like this
for the whole trip?

If you answer yes to all these questions, the child is ready to wear the lap/shoulder
seat belt correctly. If you answer no to any question, the child needs to ride on a
booster seat until the seat belt fits properly without a booster seat.

■

Protecting Larger Children

■

Checking Seat Belt Fit

Safety of Larger Children

WARNING

Allowing a child age 12 or under to sit in

front can result in injury or death if the

passenger’s front airbag inflates.

If a larger child must ride in front, move the

vehicle seat as far to the rear as possible,

have the child sit up properly and wear the

seat belt properly, using a booster seat if

needed.

Child Safety

Safety of Larger Children

Safe

Driving

If a lap/shoulder seat belt cannot be used
properly, position the child in a booster seat in
the rear seat. For the child’s safety, check that
the child meets the booster seat
manufacturer’s recommendations.

Your vehicle has a rear seat where children can be properly restrained. If you ever
have to carry a group of children, and a child must ride in front:

•

Make sure you read and fully understand the instructions and safety information
in this manual.

•

Move the front passenger seat as far back as possible.

•

Have the child sit upright and well back in the seat.

•

Check that the seat belt is properly positioned so that the child is secure in the
seat.

■

Monitoring child passengers

We strongly recommend that you keep an eye on child passengers. Even older, more
mature children sometimes need to be reminded to fasten their seat belts and sit up
properly.

■

Booster Seats

Booster Seats

When installing a booster seat, make sure to read the
instructions that came with it, and install the seat
accordingly.
There are high- and low-type booster seats. Choose a
booster seat that allows the child to wear the seat
belt correctly.

Some U.S. states and Canadian provinces and
territories require children to use a booster seat until
they reach a given age or weight (e.g., 6 years or 60
lbs). Be sure to check current laws in the state,
province, or territory where you intend to drive.

■

Protecting Larger Children - Final Checks

Safe

Driving

Exhaust Gas Hazard

Carbon Monoxide Gas

The engine exhaust from this vehicle contains carbon monoxide, a colorless,
odorless, and highly toxic gas. As long as you properly maintain your vehicle, carbon
monoxide gas will not get into the interior.

■

Have the exhaust system inspected for leaks whenever

•

The exhaust system is making an unusual noise.

•

The exhaust system may have been damaged.

•

The vehicle is raised for an oil change.

When you operate a vehicle with the trunk open, airflow can pull exhaust gas into
the interior and create a hazardous condition. If you must drive with the trunk open,
open all the windows and set the climate control system as shown below.

Select the fresh air mode.

Select the

mode.

Set the fan speed to high.

Set the temperature control to a comfortable setting.

Adjust the climate control system in the same manner if you sit in your parked
vehicle with the engine running.

Carbon Monoxide Gas

An enclosed area such as a garage can quickly fill up
with carbon monoxide gas.
Do not run the engine with the garage door closed.
Even when the garage door is open, drive out of the
garage immediately after starting the engine.

WARNING

Carbon monoxide gas is toxic.

Breathing it can cause unconsciousness and

even kill you.

Avoid any enclosed areas or activities that

expose you to carbon monoxide.

strum

ent Pa

nel

Indicators

Indicators come on/blink depending on the condition of the vehicle. Messages may
display on the driver information interface at the same time. Please take the
appropriate action outlined in the message, such as contacting a dealer.

Parking Brake and

Brake System

Indicator (Red)

Parking Brake and

Brake System

Indicator (Amber)

U.S.

Canada

U.S.

Canada

Automatic Brake

Hold System

Indicator

Automatic Brake

Hold Indicator

U.S.

Canada

*1 : When you set the power mode to ON, these indicators come on to indicate that system checks are being performed. They go off a few seconds later or after the engine

has started. If an indicator does not come on or turn off, there may be a malfunction in the corresponding system. To resolve the issue, follow the instructions in the
owner's manual.



P. 86

Malfunction

Indicator Lamp

Charging System

Indicator

Seat Belt Reminder

Indicator

Low Fuel Indicator



P. 88



P. 88



P. 88



P. 89



P. 89

Shift Position

Indicator



P. 89

Transmission System

Indicator



P. 90



P. 90



P. 91

Anti-lock Brake System

(

ABS

) Indicator

Vehicle Stability

Assist

(VSA

)

System Indicator

Vehicle Stability Assist

(VSA

)

OFF

Indicator

Supplemental

Restraint System

Indicator

Electric Power

Steering (EPS) System

Indicator



P. 91



P. 91



P. 92



P. 92



P. 91

Indicators

Continued

strum

ent Pa

nel

*1 : When you set the power mode to ON, these indicators come on to indicate that system checks are being performed. They go off a few seconds later or after the engine

has started. If an indicator does not come on or turn off, there may be a malfunction in the corresponding system. To resolve the issue, follow the instructions in the
owner's manual.

Auto High-Beam

Indicator

Low Tire Pressure/

TPMS Indicator

Turn Signal and

Hazard Warning

Indicators

Lights On

Indicator

High Beam

Indicator

System Message

Indicator

Adaptive Cruise Control

(ACC) with Low Speed

Follow Indicator

(Amber)

Lane Keeping Assist

System (LKAS) Indicator

(Amber)

Safety Support

Indicator (Green/Gray)



P. 93

Auto Idle Stop System

Indicator (Amber)



P. 96



P. 94



P. 98



P. 94



P. 94



P. 94

Immobilizer System

Indicator



P. 95

Security System Alarm

Indicator



P. 95



P. 94



P. 99



P. 103

Adaptive Cruise Control

(ACC) with Low Speed

Follow Indicator

(White/Green)



P. 98

Lane Keeping Assist

System (LKAS) Indicator

(White/Green)



P. 99

Safety Support

Indicator (Amber)



P. 100

ECON Mode

Indicator



P. 95

Auto Idle Stop

OFF

Indicator



P. 96

Auto Idle Stop

Suspend Indicator



P. 97

Cruise Mode Indicator

(White/Green)



P. 99

Adaptive Cruise Control

(ACC) with Low Speed

Follow Interval

Indicator



P. 99

Auto Idle Stop

Indicator (Green)



P. 96

* Not available on all models

Indicators

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Parking Brake and
Brake System
Indicator (Red)

●

Comes on when the parking brake is
applied, and goes off when it is released.

●

The beeper sounds and the indicator comes on if
you drive with the parking brake applied.

●

Comes on for about 30 seconds when you apply
the electric parking brake while the power mode is
in ACCESSORY or VEHICLE OFF, then goes off.

●

Stays on for about 30 seconds when you set the
power mode to VEHICLE OFF while the electric
parking brake is applied, then goes off.

•

Comes on when the brake fluid level is
low.

•

Comes on while driving

- Make sure the parking

brake is released. Stop in a safe place and check
the brake fluid level.

What to do when the indicator comes on
while driving

P. 493

U.S.

Canada

(Red)

Indicators

Continued

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Parking Brake and
Brake System
Indicator (Red)

●

Comes on if there is a problem with the
brake system.

●

Comes on along with the Parking Brake and
Brake System Indicator (amber)

- Immediately

stop in a safe place. Contact a dealer for repair. The
brake pedal becomes harder to operate. Depress
the pedal further than you normally do.

If the Brake System Indicator (Red) Comes On
or Blinks at the Same Time When the Brake
System Indicator (Amber) Comes On

P. 494

●

Comes on along with the ABS indicator

- Have

your vehicle checked by a dealer.

If the Brake System Indicator (Red) Comes On
or Blinks

P. 493

●

Blinks and the Parking Brake and Brake System
Indicator (amber) comes on at the same time

There is a problem with the electric parking brake
system. The parking brake may not be set.
Avoid using the parking brake and have your
vehicle checked by a dealer immediately.

If the Brake System Indicator (Red) Comes On
or Blinks at the Same Time When the Brake
System Indicator (Amber) Comes On

P. 494

U.S.

Canada

(Red)

Indicators

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Parking Brake and
Brake System
Indicator (Amber)

●

Comes on if there is a problem with a
system related to braking other than the
conventional brake system.

●

Comes on while driving

- Avoid high speeds and

sudden braking. Take the vehicle to a dealer
immediately.

●

Comes on if there is a problem with the
electric parking brake system and/or the
automatic brake hold system.

●

Stays on constantly

- Avoid using the parking

brake and have your vehicle checked by a dealer
immediately.

●

Comes on if the brake system is
deactivated temporarily after the battery
has been disconnected, then reconnected.

●

Drive a short distance at more than 12 mph (20
km/h). The indicator should go off. If it does not,
have your vehicle checked by a dealer.

●

Comes on if there is a problem with the
radar sensor.

●

Indicator may come on temporarily when
the Maximum Load Limit is exceeded.

●

Make sure the total load is within the Maximum
Load Limit.

Maximum Load Limit

P. 293

●

Stays on constantly

- Have your vehicle checked

by a dealer.

Automatic Brake
Hold System
Indicator

●

Comes on when the automatic brake hold
system is on.

Automatic Brake Hold

P. 404

Automatic Brake
Hold Indicator

●

Comes on when the automatic brake hold
is activated.

Automatic Brake Hold

P. 404

U.S.

Canada

(Amber)

U.S.

Canada

Indicators

Continued

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Malfunction
Indicator Lamp

●

After you have set the power mode to ON,
the vehicle performs system checks.
However, if the readiness codes have not
been set by that time, this indicator will
blink five times and then go off.

●

Readiness codes are part of the on-board
diagnostics for the emissions control systems.

Testing of Readiness Codes

P. 515

●

Comes on if there is a problem with the
emissions control systems.

●

Blinks when a misfire in the engine’s
cylinders is detected.

If the Malfunction Indicator Lamp Comes On
or Blinks

P. 492

Charging System
Indicator

●

Comes on when there is a problem with
the charging system.

●

Stop in a safe place and contact a dealer
immediately.

Checking the Battery

P. 461

If the Charging System Indicator Comes On

P. 491

Shift Position
Indicator

●

Indicates the current shift position.

Shifting

P. 304

Indicators

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Transmission
System Indicator

●

Blinks if the transmission system has a
problem.

●

Have your vehicle checked by a dealer immediately.

Seat Belt Reminder
Indicator

●

Blinks and the beeper sounds for a few
seconds if you are not wearing a seat belt
when you set the power mode to ON, then
the indicator comes on.

●

If the front passenger is not wearing a seat
belt, the indicator comes on a few seconds
later.

●

Comes on for a while when the rear seat
belt is unfastened while the power mode in
ON.

●

Blinks while driving if you and/or any
passenger has not fastened a seat belt. The
beeper sounds and the indicator blinks at
regular intervals.

●

The beeper stops and the indicator goes off when
you and the passengers fasten their seat belts.

●

Stays on after you and/or the passengers have
fastened the seat belt(s)

- A detection error may

have occurred in the sensor. Have your vehicle
checked by a dealer.

Seat Belt Reminder

P. 42

Indicators

Continued

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Low Fuel Indicator

●

Comes on when the fuel reserve is running
low (approximately 2.2 U.S. gal/8.4 Liter
left).

●

Refuel your vehicle as soon as possible.

●

Blinks if there is a problem with the fuel
gauge.

●

Have your vehicle checked by a dealer.

Anti-lock Brake
System (

ABS

)

Indicator

●

Comes on if there is a problem with the
ABS.

●

Stays on constantly

- Have your vehicle checked

by a dealer. With this indicator on, your vehicle still
has normal braking ability but no anti-lock
function.

Anti-lock Brake System (ABS)

P. 407

Supplemental
Restraint System
Indicator

●

Comes on if a problem with any of the
following is detected:

Supplemental Restraint System

Side airbag system

Side curtain airbag system

Seat belt tensioner

●

Stays on constantly

- Have your vehicle checked

by a dealer.

Electric Power
Steering (EPS)
System Indicator

•

Comes on if there is a problem with the
EPS system.

•

Stays on constantly

- Have your vehicle checked

by a dealer.

•

Do not drive displays on the driver
information interface

- Immediately stop in a

safe place and contact a dealer.

If the Electric Power Steering (EPS) System
Indicator Comes On

P. 495

Indicators

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Vehicle Stability
Assist

(VSA

)

System Indicator

●

Blinks when VSA

is active.

—

●

Comes on if there is a problem with the
VSA

system, brake assist system, hill start

assist system, starting assist brake function,
or agile handling assist.

●

Stays on constantly

- Have your vehicle checked

by a dealer.

Vehicle Stability Assist

(VSA

), aka

Electronic Stability Control (ESC), System

P. 313

Brake Assist System

P. 408

Hill start assist system

P. 301

Starting Assist Brake Function

P. 312

Agile Handling Assist

P. 315

●

Comes on if the VSA

system is deactivated

temporarily after the battery has been
disconnected, then reconnected.

●

Drive a short distance at more than 12 mph (20
km/h). The indicator should go off. If it does not,
have your vehicle checked by a dealer.

Vehicle Stability
Assist

(VSA

)

OFF

Indicator

●

Comes on when you partially disable VSA

Switching the Display

P. 112

Vehicle Stability Assist Mode

P. 122

Indicators

Continued

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Low Tire Pressure/
TPMS Indicator

●

May come on briefly if the power mode is
set to ON and the vehicle is not moved
within 45 seconds, to indicate the
calibration process is not yet complete.

●

Comes on and stays on when:

One or more tires’ pressures are
determined to be significantly low.

The system has not been calibrated.

●

Comes on while driving

- Stop in a safe place,

check tire pressures, and inflate the tire(s) if
necessary.

●

Stays on after the tires are inflated to the
recommended pressures

- The system needs to

be calibrated.

TPMS Calibration

P. 318

●

Blinks for about one minute, and then stays
on if there is a problem with the TPMS, or
when a compact spare tire is temporarily
installed.

●

Blinks and remains on

- Have your vehicle

checked by a dealer. If the vehicle is fitted with a
compact spare tire, get your regular tire repaired or
replaced and put back on your vehicle as soon as
you can.

●

Comes on if the TPMS is deactivated
temporarily after the battery has been
disconnected, then reconnected.

●

Drive a short distance at more than 12 mph (20
km/h). The indicator should go off. If it does not,
have your vehicle checked by a dealer.

* Not available on all models

Indicators

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Turn Signal and
Hazard Warning
Indicators

•

Blinks when you operate the turn signal
lever.

•

Blinks along with all turn signals when you
press the hazard warning button.

●

Does not blink or blinks rapidly

- Have your

vehicle checked by a dealer.

Lights On Indicator

•

Comes on when the parking, tail, and
other external lights are on.

Light Switches

P. 167

High Beam
Indicator

•

Comes on when the high beam headlights
are on.

—

Auto High-Beam
Indicator

•

Comes on when all the operating
conditions of the auto high-beam are met.

Auto High-Beam

P. 171

System Message
Indicator

•

Comes on along with a beep when a
problem is detected. A system message on
the driver information interface appears at
the same time.

●

While the indicator is on, roll the right selector
wheel to see the message again.

Switching the Display

P. 112

●

Refer to the Indicators information in this chapter
when a system message appears on the driver
information interface. Respond to the message
accordingly.

●

The driver information interface will not return to
the normal screen unless the warning is canceled,
or the right selector wheel is rolled.

Indicators

Continued

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

ECON Mode
Indicator

●

Comes on when the ECON mode is on.

ECON Mode

P. 306

Immobilizer System
Indicator

•

Blinks if the immobilizer system cannot
recognize the key information.

•

Blinks

- You cannot start the engine. Set the

power mode to VEHICLE OFF, then select the ON
mode again.

Depress and hold the brake pedal before setting
the power mode to ON.

•

Repeatedly blinks

- The system may be

malfunctioning. Have your vehicle checked by a
dealer.

•

Do not attempt to alter this system or add other
devices to it. Electrical problems can occur.

Security System
Alarm Indicator

•

Blinks when the security system alarm has
been set.

Security System Alarm

P. 155

Indicator

Canadian models

Indicator

Indicators

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Auto Idle Stop

OFF

Indicator

●

Comes on when the Auto Idle Stop system
has been turned off by the Auto Idle Stop

OFF

button.

Auto Idle Stop System ON/OFF

P. 309

Auto Idle Stop
System Indicator
(Amber)

●

Blinks if there is a problem with the Auto
Idle Stop system.

●

Have your vehicle checked by a dealer.

Auto Idle Stop
Indicator (Green)

●

Comes on when Auto Idle Stop is in
operation. The engine automatically shuts
off.

Auto Idle Stop

P. 307

Indicators

Continued

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Auto Idle Stop
Suspend Indicator

●

Comes on while Auto Idle Stop is
temporarily suspended in the following
situations.

—

Brake pedal is not fully pressed

●

Depress the brake pedal firmly.

The transmission is in a position other than

(

Auto Idle Stop

P. 307

System charging is prioritized

Climate control system is prioritized

is ON (indicator on).

Engine coolant temperature is not in
operating range

The battery temperature is too low.

Auto Idle Stop does not activate for some
reason.

Indicators

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Adaptive Cruise
Control (ACC) with
Low Speed Follow
Indicator (Amber)

●

Comes on if there is a problem with ACC
with Low Speed Follow.

●

Comes on while driving

- Have your vehicle

checked by a dealer.

●

Comes on if the ACC with Low Speed
Follow is deactivated temporarily after the
battery has been disconnected, then
reconnected.

●

Drive a short distance at more than 12 mph (20
km/h). The indicator should go off. If it does not,
have your vehicle checked by a dealer.

●

Indicator may come on temporarily when
the Maximum Load Limit is exceeded.

●

ACC with Low Speed Follow has been
automatically canceled.

●

Make sure the total load is within the Maximum
Load Limit.

Maximum Load Limit

P. 293

●

Stays on constantly

- Have your vehicle checked

by a dealer.

Adaptive Cruise
Control (ACC) with
Low Speed Follow
Indicator
(White/Green)

●

Lights up in white when you press the

button.

●

Lights up in white and green if no vehicle is
detected ahead of you while ACC with Low
Speed Follow is in operation.

●

Lights up in green if a vehicle is detected
ahead of you while ACC with Low Speed
Follow is in operation.

Adaptive Cruise Control (ACC) with Low
Speed Follow

P. 350

Honda Accord (2024 year). Manual in english - page 2
