Honda Accord (2022 year). Manual in english

624

Fuses

Fuse Locations

Han

lin
g the U

expected

Located under the dashboard.
Fuse locations are shown on the label on
the side panel.
Locate the fuse in question by the fuse
number and label number.

■

Interior Sub Fuse Box

Models with Auto Idle Stop

Fuse Label

Sub Fuse Box

■

Circuit protected and fuse rating

Circuit Protected

Amps

VST ACC 1

7.5 A

BACKUP2 MAIN

15 A

EOP

7.5 A

BACKUP3

7.5 A

EBB

7.5 A

METER VST

7.5 A

VSA/ABS

7.5 A

625

Fuses

Inspecting and Changing Fuses

Han

lin
g the U

expected

Inspecting and Changing Fuses

Set the power mode to VEHICLE OFF. Turn
headlights and all accessories off.

Open the fuse box cover in the engine
compartment.

Check the large fuse in the engine
compartment.

If the fuse is blown, use a Phillips-head
screwdriver to remove the screw and
replace it with a new one.

Inspect the small fuses in the engine
compartment and the vehicle interior.

If there is a blown fuse, remove it with
the fuse puller and replace it with a new
one.

Inspecting and Changing Fuses

NOTICE

Replacing a fuse with one that has a higher rating
greatly increases the chances of damaging the
electrical system.

Use the charts to locate the fuse in question and
confirm the specified amperage on the fuse label.

Fuse Locations

P. 620

Replace fuse with a spare fuse of the same specified
amperage.

There is a fuse puller on the back of the engine
compartment fuse box cover.

Combined
Fuse

Blown Fuse

Fuse Puller

626

Han

lin
g the U

expected

Emergency Towing

Call a professional towing service if you need to tow your vehicle.

■

Flatbed equipment

The operator loads your vehicle on the back of a truck.

This is the best way to transport your vehicle.

■

Wheel lift equipment

The tow truck uses two pivoting arms that go under the front tires and lift them off
the ground. The rear tires remain on the ground.

This is an acceptable way to

tow your vehicle.

Emergency Towing

NOTICE

Trying to lift or tow your vehicle by the bumpers will
cause serious damage. The bumpers are not designed
to support the vehicle’s weight.

Make sure the parking brake is released. If you
cannot release the parking brake, your vehicle must
be transported by the flatbed equipment.

Parking Brake

P. 508

NOTICE

Improper towing such as towing behind a
motorhome or other motor vehicle can damage the
transmission.

Never tow your vehicle with just a rope or chain.
It is very dangerous, since ropes or chains may shift
from side to side or break.

627

Han

lin
g the U

expected

If You Cannot Unlock the Fuel Fill Door

If you cannot unlock the fuel fill door, use the following procedure.

Open the trunk.

Pull the release handle toward you.

The release handle unlocks the fuel fill
door when it is pulled.

Open the fuel fill door.

How to Refuel

P. 532

■

What to Do If Unable to Unlock the Fuel Fill Door

If You Cannot Unlock the Fuel Fill Door

After taking these steps, contact a dealer to have the
vehicle checked.

Release Handle

628

Han

lin
g the U

expected

If You Cannot Open the Trunk

If you cannot open the trunk, use the following procedure.

Remove the driver side rear outer head
restraint.

Removing and Reinstalling the Head
Restraints

P. 221

Remove the built-in key from the keyless
remote.

Wrap a cloth around the tip of the built-in
key. Put it into the cover (as shown in the
image) and remove the cover.

Insert the key into the cylinder and turn it
clockwise.

The trunk unlocks and opens.

■

What to Do If Unable to Open the Trunk

If You Cannot Open the Trunk

Following up:
After taking these steps, contact a dealer to have the
vehicle checked.

Cover

Models with adjustable headrest

All models

Key

Models with the cylinder in the cover

630

Han

lin
g the U

expected

Refueling

Refueling From a Portable Fuel Container

If you have run out of fuel and need to refuel your vehicle from a portable fuel
container, use the funnel provided with your vehicle.

Turn off the engine.

Press on the edge of the fuel fill door until
you hear a click when the driver’s door is
unlocked.

The fuel fill door opens.

Take the funnel out of the tool case in the
trunk.

Types of Tools

P. 596

Place the end of the funnel on the lower
part of filler opening, then insert it slowly
and fully.

Make sure that the end of the funnel
goes down along with the filler pipe.

Fill the tank with fuel from the portable fuel
container.

Pour fuel carefully so you do not spill any.

Remove the funnel from the filler neck.

Wipe up any fuel from the funnel before
storing it.

Shut the fuel fill door by hand.

Refueling From a Portable Fuel Container

NOTICE

Do not insert the nozzle of a portable fuel container
or any funnel other than the one provided with your
vehicle. Doing so can damage the fuel system.
Do not try to pry open or push open the sealed fuel
tank with foreign objects. This can damage the fuel
system and its seal.

Make sure the fuel in the portable fuel container is
gasoline before you refuel.

WARNING

Gasoline is highly flammable and explosive.
You can be burned or seriously injured
when handling fuel.

•

Stop the engine, and keep heat, sparks,
and flames away.

•

Handle fuel only outdoors.

•

Wipe up spills immediately.

Funnel

632

Info

ation

Specifications

■

Vehicle Specifications

■

Air Conditioning

Model

ACCORD

No. of Passengers:
Front

Rear

Total

Weights:
Gross Vehicle
Weight Rating

See the certification label on the driver’s
doorjamb

Gross Axle Weight
Rating (Front)

See the certification label on the driver’s
doorjamb

Gross Axle Weight
Rating (Rear)

See the certification label on the driver’s
doorjamb

Refrigerant Type

HFO-1234yf (R-1234yf)

Charge Quantity

13.9 – 15.7 oz (395 – 445 g)

Lubricant Type

ND-OIL 14

Quantity

5.6 – 6.5 cu-in (92 – 107 cm

)

1.5 L engine models

■

Engine Specifications

■

Fuel

■

Washer Fluid

Displacement

91 cu-in (1,498 cm

)

Spark Plugs

NGK

DILKAR8P8SY

Type

Unleaded gasoline, Pump octane number
of 87 or higher

Fuel Tank Capacity

14.8 US gal (56 L)

Tank Capacity

U.S.: 2.6 US qt (2.5 L)
Canada: 4.8 US qt (4.5 L)

■

Light Bulbs

*1: Models with halogen high beam headlights
*2: Models with LED high beam headlights

Headlights (Low Beam)

LED

Headlights (High Beam)

60W (HB3)

LED

Fog Lights

LED

Parking/Daytime Running Lights

LED

Front Turn Signal Lights

LED

Front Side Marker Lights

LED

Side Turn Signal Lights
(on Door Mirrors)

LED

Brake Lights

LED

Rear Turn Signal Lights

21W (Amber)

Rear Side Marker Lights

LED

Taillights

LED

Back-Up Lights

16W

High-Mount Brake Light

LED

Rear License Plate Light

LED

Interior Lights

Map Lights

Ceiling Light

Ambient Lights

LED

Vanity Mirror Lights

1.4W

Center Pocket Light

LED

Door Courtesy Lights

2CP (3.8W)

Door Inner Handle Lights

LED

Trunk Light

* Not available on all models

633

Specifications

Continued

Info

ation

■

Brake Fluid

■

Continuously Variable Transmission

Fluid

Specified

Honda Heavy Duty Brake Fluid DOT 3

Specified

Honda HCF-2

Capacity

Change

3.9 US qt (3.7 L)

■

Engine Oil

■

Engine Coolant

Recommended

·Honda Genuine Motor Oil 0W-20
·API Premium-grade 0W-20 detergent oil

Capacity

Change

3.4 US qt (3.2 L)

Change
including
filter

3.7 US qt (3.5 L)

Specified

Honda Long-Life Antifreeze/Coolant Type2

Ratio

50/50 with distilled water

Capacity

1.59 US gal (6.03 L)
(change including the remaining
0.17 US gal (0.66 L) in the reserve tank)

■

Tire

*1: Models with 17 inch wheel
*2: Models with 19 inch wheel

Regular

Size

225/50R17 94V

235/40R19 96V

Pressure
psi (kPa [kgf/cm

])

Front

32 (220 [2.2])

33 (225 [2.25])

Rear

32 (220 [2.2])

33 (225 [2.25])

Compact
Spare

Size

T135/90D16 102M

T135/80D17 103M

Pressure
psi (kPa [kgf/cm

])

60 (420 [4.2])

Wheel Size

Regular

17 x 7 1/2J

19 x 8 1/2J

Compact Spare

16 x 4T

17 x 4T

634

Specifications

Info

ation

■

Vehicle Specifications

■

Air Conditioning

Model

ACCORD

No. of Passengers:
Front

Rear

Total

Weights:
Gross Vehicle
Weight Rating

See the certification label on the driver’s
doorjamb

Gross Axle Weight
Rating (Front)

See the certification label on the driver’s
doorjamb

Gross Axle Weight
Rating (Rear)

See the certification label on the driver’s
doorjamb

Refrigerant Type

HFO-1234yf (R-1234yf)

Charge Quantity

13.9 – 15.7 oz (395 – 445 g)

Lubricant Type

ND-OIL 14

Quantity

5.6 – 6.5 cu-in (92 – 107 cm

)

2.0 L engine models

■

Engine Specifications

■

Fuel

■

Washer Fluid

Displacement

122 cu-in (1,996 cm

)

Spark Plugs

NGK

DILKAR8P8SY

Type

Unleaded gasoline, Pump octane number
of 87 or higher

Fuel Tank Capacity

14.8 US gal (56 L)

Tank Capacity

U.S.: 2.6 US qt (2.5 L)
Canada: 4.8 US qt (4.5 L)

■

Light Bulbs

Headlights (Low Beam)

LED

Headlights (High Beam)

LED

Fog Lights

LED

Parking/Daytime Running Lights

LED

Front Turn Signal Lights

LED

Front Side Marker Lights

LED

Side Turn Signal Lights
(on Door Mirrors)

LED

Brake Lights

LED

Rear Turn Signal Lights

21W (Amber)

Rear Side Marker Lights

LED

Taillights

LED

Back-Up Lights

16W

High-Mount Brake Light

LED

Rear License Plate Light

LED

Interior Lights

Map Lights

Ceiling Light

Ambient Lights

LED

Vanity Mirror Lights

1.4W

Center Pocket Light

LED

Door Courtesy Lights

2CP (3.8W)

Door Inner Handle Lights

LED

Trunk Light

* Not available on all models

635

Specifications

Info

ation

■

Brake Fluid

■

Automatic Transmission Fluid

Specified

Honda Heavy Duty Brake Fluid DOT 3

Specified

Honda Automatic Transmission Fluid
ATF-type 2.0

Capacity

Change

4.5 US qt (4.3 L)

■

Engine Oil

■

Engine Coolant

Recommended

·Honda Genuine Motor Oil 0W-20
·API Premium-grade 0W-20 detergent oil

Capacity

Change

4.6 US qt (4.4 L)

Change
including
filter

5.0 US qt (4.8 L)

Specified

Honda Long-Life Antifreeze/Coolant Type2

Ratio

50/50 with distilled water

Capacity

1.34 US gal (5.06 L)
(change including the remaining
0.17 US gal (0.66 L) in the reserve tank)

■

Tire

Regular

Size

235/40R19 96V

Pressure
psi (kPa [kgf/cm

])

Front

33 (225 [2.25])

Rear

33 (225 [2.25])

Compact
Spare

Size

T135/80D17 103M

Pressure
psi (kPa [kgf/cm

])

60 (420 [4.2])

Wheel Size

Regular

19 x 8 1/2J

Compact Spare

17 x 4T

636

Info

ation

Identification Numbers

Vehicle Identification Number (VIN), Engine Number,
and Transmission Number

Your vehicle has a 17-digit vehicle identification number (VIN) used to register your
vehicle for warranty purposes, and for licensing and insuring your vehicle.
The locations of your vehicle’s VIN, engine number, and transmission number are
shown as follows.

Vehicle Identification Number (VIN), Engine Number, and
Transmission Number

The interior vehicle identification number (VIN) is
located under the cover.

Cover

Vehicle Identification Number

Engine Number

Certification Label/
Vehicle Identification
Number

Continuously Variable
Transmission (CVT)
Number

2.0 L engine models

1.5 L engine models

Engine Number

Automatic Transmission
Number

Vehicle Identification Number

638

Info

ation

Reporting Safety Defects

In the U.S.
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you
should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to
notifying American Honda Motor Co., Inc.

If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists
in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved
in individual problems between you, your dealer, or American Honda Motor Co., Inc.

To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-327-4236 (TTY: 1-800-424-
9153); go to

http://www.safercar.gov

; or write to: Administrator, NHTSA, 1200 New Jersey Avenue, SE.,

Washington, DC 20590. You can also obtain other information about motor vehicle safety from

http://

www.safercar.gov

In Canada
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you
should immediately inform Honda Canada Inc. and you may also inform Transport Canada.

If Transport Canada receives similar complaints, it may open an investigation, and if it finds that a safety
defect exists in a group of vehicles, it may lead to a recall and remedy campaign. However, Transport Canada
cannot become involved in individual problems between you, your dealer, or Honda Canada Inc.

To contact Transport Canada’s Defect Investigations and Recalls Division, you may call 1-800-333-0510. For
more information on reporting safety defects or about motor vehicle safety, go to

http://www.tc.gc.ca/

roadsafety

639

Continued

Info

ation

Emissions Testing

Testing of Readiness Codes

Your vehicle has readiness code as part of the onboard self diagnostic system. Some
states use these codes for testing to verify whether your vehicle’s emissions
components are working properly.
The codes may not be read properly if testing is performed just after the battery has
gone dead or been disconnected.

To check if they are set, set the power mode to ON, without starting the engine. The
malfunction indicator lamp will come on for several seconds. If it then goes off, the
readiness codes are set. If it blinks five times, the readiness codes are not set.

If you are required to have your vehicle tested before the readiness codes are ready,
prepare the vehicle for retesting by doing the following:

Fill the gas tank to approximately 3/4 full.

Park the vehicle and leave the engine off for 6 hours or more.

Make sure the ambient temperature is between 40°F and 95°F (4°C and 35°C).

Start the engine without touching the accelerator pedal, and let it idle for 20
seconds.

Keep the vehicle in

(

. Increase the engine speed to 2,000 rpm, and hold it there

for about 3 minutes.

Let the engine idle with your foot off the accelerator for 20 seconds.

Testing of Readiness Codes

The readiness codes are erased when the battery is
disconnected, and set again only after several days of
driving under a variety of conditions.

If a testing facility determines that the readiness
codes are not set, you may be requested to return at
a later date to complete the test.

If the testing facility determines the readiness codes
are still not set, see a dealer.

Honda Accord (2022 year). Manual in english - page 39
