Engine Does Not Start

If the Remote Battery is Weak

Han

lin
g the U

expected

If the Remote Battery is Weak

If the beeper sounds, the

To Start, Hold Remote Near Start Button

message

appears on the driver information interface, the

ENGINE START/STOP

button

flashes, and the engine won’t start, start the engine as follows:

Touch the center of the

ENGINE START/

STOP

button with the

logo on the

remote while the

ENGINE START/STOP

button is flashing. The buttons on the
remote should be facing you.

The

ENGINE START/STOP

button

flashes for about 30 seconds.

Depress the brake pedal and press the

ENGINE START/STOP

button within 10

seconds after the beeper sounds and the

ENGINE START/STOP

button changes

from flashing to on.

If you don’t depress the pedal, the mode
will change to ACCESSORY.

658

Engine Does Not Start

Emergency Engine Stop

Han

lin
g the U

expected

Emergency Engine Stop

The

ENGINE START/STOP

button may be used to stop the engine due to an

emergency situation even while driving. If you must stop the engine, do either of the
following operations:

•

Press and hold the

ENGINE START/STOP

button for about two seconds.

•

Firmly press the

ENGINE START/STOP

button three times.

The steering wheel will not lock. However, because turning off the engine disables
the power assist the engine provides to the steering and braking systems, it will
require significantly more physical effort and time to steer and slow the vehicle. Use
both feet on the brake pedal to slow down the vehicle and stop immediately in a
safe place.

The gear position automatically changes to

(

after the vehicle comes to a complete

stop.

Then, the power mode changes to VEHICLE OFF.

Then, press the

ENGINE START/STOP

button twice without depressing the brake

pedal to change the mode to VEHICLE OFF.

Emergency Engine Stop

Do not press the

ENGINE START/STOP

button while

driving unless it is absolutely necessary for the engine
to be turned off.
If you press the

ENGINE START/STOP

button while

driving, the beeper sounds.

U.S. models

Canadian models

659

Continued

Han

lin
g the U

expected

If the Battery Is Dead

Jump Starting Procedure

Turn off the power to electric devices, such as audio and lights. Turn off the engine,
then open the hood.

Connect the first jumper cable to your
vehicle’s battery

terminal.

Connect the other end of the first jumper
cable to the booster battery

terminal.

Use a 12-volt booster battery only.

When using an automotive battery
charger to boost your 12-volt battery,
select a lower charging voltage than 15-
volt. Check the charger manual for the
proper setting.

Connect the second jumper cable to the
booster battery

terminal.

Connect the other end of the second
jumper cable to the engine mounting bolt
as shown. Do not connect this jumper cable
to any other part.

If your vehicle is connected to another
vehicle, start the assisting vehicle’s engine
and increase its rpm slightly.

Attempt to start your vehicle’s engine. If it
turns over slowly, check that the jumper
cables have good metal-to-metal contact.

If the Battery Is Dead

Securely attach the jumper cables clips so that they
do not come off when the engine vibrates. Be careful
not to tangle the jumper cables or allow the cable
ends to touch each other while attaching or
detaching the jumper cables.

Battery performance degrades in cold conditions and
may prevent the engine from starting.

WARNING

A battery can explode if you do not follow
the correct procedure, seriously injuring
anyone nearby.

Keep all sparks, open flames, and smoking
materials away from the battery.

Booster Battery

660

If the Battery Is Dead

Jump Starting Procedure

Han

lin
g the U

expected

Once your vehicle’s engine has started, remove the jumper cables in the following
order.

Disconnect the jumper cable from your vehicle’s engine mounting bolt.

Disconnect the other end of the jumper cable from the booster battery

terminal.

Disconnect the jumper cable from your vehicle’s battery

terminal.

Disconnect the other end of the jumper cable from the booster battery

terminal.

Have your vehicle inspected by a nearby service station or a dealer.

■

What to Do After the Engine Starts

661

Continued

Han

lin
g the U

expected

Overheating

How to Handle Overheating

Overheating symptoms are as follows:

•

The temperature gauge pointer is at the

mark or the engine suddenly loses

power.

•

The

Stop Driving When Safe. Engine Temperature Too Hot

message appears

on the driver information interface.

•

Steam or spray comes out of the engine compartment.

■

First thing to do

Immediately park the vehicle in a safe place.

Turn off all accessories and turn on the hazard warning lights.

No steam or spray present:

Keep the engine running and open the hood.

Steam or spray is present:

Turn off the engine and wait until it subsides.

Then, open the hood.

How to Handle Overheating

NOTICE

Continuing to drive with the temperature gauge
pointer at the

mark may damage the engine.

Continuing to drive with the

Stop Driving When

Safe. Engine Temperature Too Hot

message on

the driver information interface may damage the
engine.

WARNING

Steam and spray from an overheated
engine can seriously scald you.

Do not open the hood if steam is coming
out.

Overheating

How to Handle Overheating

662

Han

lin
g the U

expected

■

Next thing to do

Check that the cooling fan is operating and
stop the engine once the temperature
gauge pointer goes down.

If the cooling fan is not operating,
immediately stop the engine.

Once the engine has cooled down, inspect
the coolant level and check the cooling
system components for leaks.

If the coolant level in the reserve tank is
low, add coolant until it reaches the

MAX

mark.

If there is no coolant in the reserve tank,
check that the radiator is cool. Cover the
radiator cap with a heavy cloth and open
the cap. If necessary, add coolant up to
the base of the filler neck and put the
cap back on.

Radiator

P. 606

■

Last thing to do

Once the engine has cooled sufficiently, restart it and check the temperature gauge.
If the temperature gauge pointer has gone down, resume driving. If it has not gone
down, contact a dealer for repairs.

How to Handle Overheating

If the coolant is leaking, contact a dealer for repairs.

Use water as an emergency/temporary measure only.
Have a dealer flush the system with proper antifreeze
as soon as possible.

WARNING

Removing the radiator cap while the
engine is hot can cause the coolant to spray
out, seriously scalding you.

Always let the engine and radiator cool
down before removing the radiator cap.

MAX

Reserve
Tank

MIN

663

Han

lin
g the U

expected

Indicator, Coming On/Blinking

If the Engine Oil Low Warning Appears

■

Reasons for the warning to appear

Appears when the engine oil pressure is low.

■

What to do as soon as the warning
appears

Immediately park the vehicle on level
ground in a safe place.

If necessary, turn the hazard warning lights
on.

■

What to do after parking the vehicle

Stop the engine and let it sit for
approximately three minutes.

Open the hood and check the oil level.

Add oil as necessary.

Oil Check

P. 601

Start the engine and check the

Engine Oil

Low

warning.

The warning disappears: Start driving
again.

The warning does not disappear within
10 seconds: Immediately stop the engine
and contact a dealer for repairs.

If the

Engine Oil Low

Warning Appears

NOTICE

Running the engine with low oil pressure can cause
serious mechanical damage almost immediately.

664

Indicator, Coming On/Blinking

If the Charging System Indicator Comes On

Han

lin
g the U

expected

If the Charging System Indicator Comes On

■

Reasons for the indicator to come on

Comes on when there is a problem with the charging system.

■

What to do when the indicator comes on

Turn off the climate control system, rear defogger, and other electrical
systems, and immediately contact a dealer for repairs.

If the Malfunction Indicator Lamp Comes On or
Blinks

■

Reasons for the indicator lamp to come on or blink

•

Comes on when there is a problem with the engine emissions control
system.

•

Blinks when engine misfiring is detected.

■

What to do when the indicator lamp comes on

Avoid high speeds and immediately get your vehicle inspected at a
dealer.

■

What to do when the indicator lamp blinks

Park the vehicle in a safe place with no flammable items and wait at least
10 minutes or more with the engine stopped until it cools.

If the Charging System Indicator Comes On

If you need to stop temporarily, do not turn off the
engine. Restarting the engine may rapidly discharge
the battery.

If the Malfunction Indicator Lamp Comes On or Blinks

NOTICE

If you drive with the malfunction indicator lamp on,
the emissions control system and the engine could be
damaged.

If the malfunction indicator lamp blinks again when
restarting the engine, drive to the nearest dealer at
31 mph (50 km/h) or less. Have your vehicle
inspected.

665

Indicator, Coming On/Blinking

If the Brake System Indicator (Red) Comes On or Blinks

Han

lin
g the U

expected

If the Brake System Indicator (Red) Comes On or
Blinks

■

Reasons for the indicator to come on

•

The brake fluid is low.

•

There is a malfunction in the brake system.

■

What to do when the indicator comes on while driving

Depress the brake pedal lightly to check pedal pressure.

•

If normal, check the brake fluid level the next time you stop.

•

If abnormal, take immediate action. If necessary, downshift the
transmission to slow the vehicle using engine braking.

■

Reasons for the indicator to blink

•

There is a problem with the electric parking brake system.

■

What to do when the indicator blinks

•

Avoid using the parking brake and have your vehicle checked by a
dealer immediately.

If the Brake System Indicator (Red) Comes On or Blinks

Have your vehicle repaired immediately.
It is dangerous to drive with low brake fluid. If there
is no resistance from the brake pedal, stop
immediately in a safe place. If necessary downshift
the gears.

If the brake system indicator (red) and

ABS

indicator

come on simultaneously, the electronic brake
distribution system is not working. This can result in
vehicle instability under sudden braking.
Have your vehicle inspected by a dealer immediately.

If the brake system indicator (red) blinks at the same
time when the brake system indicator (amber) comes
on, the parking brake may not work.
Avoid using the parking brake and have your vehicle
checked by a dealer immediately.

If the Brake System Indicator (Red) Comes
On or Blinks at the Same Time When the
Brake System Indicator (Amber) Comes On

P. 666

U.S.

Canada

(Red)

666

Indicator, Coming On/Blinking

If the Brake System Indicator (Red) Comes On or Blinks at the Same Time When the Brake System Indicator (Amber) Comes On

Han

lin
g the U

expected

If the Brake System Indicator (Red) Comes On or
Blinks at the Same Time When the Brake System
Indicator (Amber) Comes On

■

If the brake system indicator (red) comes on or blinks at the

same time when the brake system indicator (amber) comes on,
release the parking brake manually or automatically

Parking Brake

P. 561

•

If the brake system indicator (red) continuously comes on or blinks at

the same time when the brake system indicator (amber) comes on,
stop the vehicle in a safe place and have it inspected by a dealer
immediately.

Preventing the vehicle from moving, put the transmission into

(

•

If only the brake system indicator (red) is turned off, avoid using the

parking brake and have your vehicle checked by a dealer immediately.

If the Brake System Indicator (Red) Comes On or Blinks at the Same
Time When the Brake System Indicator (Amber) Comes On

If you apply the parking brake, you may not be able
to release it.

If the brake system indicator (red) and the brake
system indicator (amber) come on at the same time,
the parking brake is working.

If the brake system indicator (red) blinks at the same
time when the brake system indicator (amber) comes
on, the parking brake may not work because it is
checking the system.

If you repeatedly operate the electric parking brake in
a short period of time, the brake stops operating to
prevent heating of the system and the indicator
blinks.
It returns to its original state in approximately one
minute.

U.S.

Canada

(Red)

U.S.

Canada

(Amber)

667

Indicator, Coming On/Blinking

If the Electric Power Steering (EPS) System Indicator Comes On

Han

lin
g the U

expected

If the Electric Power Steering (EPS) System Indicator
Comes On

■

Reasons for the indicator to come on

Comes on when there is a problem with the EPS system.

■

What to do when the indicator comes on

Stop the vehicle in a safe place and restart the engine.
If the indicator comes on and stays on, immediately have your vehicle
inspected by a dealer.

If the Low Tire Pressure/TPMS Indicator Comes On or
Blinks

■

Reasons for the indicator to come on or blink

A tire pressure is significantly low. If there is a problem with the TPMS
with Tire Fill Assist or the compact spare tire is installed, the indicator
blinks for about one minute, and then stays on.

■

What to do when the indicator comes on

Drive carefully and avoid abrupt cornering and hard braking.
Stop your vehicle in a safe place. Check the tire pressure and adjust the
pressure to the specified level. The specified tire pressure is on a label on
the driver side doorjamb.

■

What to do when the indicator blinks, then remains on

Have the tire inspected by a dealer as soon as possible. If the compact
spare tire causes the indicator to blink, change the tire to a full-size tire.
The indicator goes off after driving for a few miles (kilometers).

If the Low Tire Pressure/TPMS Indicator Comes On or Blinks

NOTICE

Driving on an extremely underinflated tire can cause
it to overheat. An overheated tire can fail. Always
inflate your tires to the prescribed level.

TPMS with Tire Fill Assist provides visual and audible
assistance during tire pressure adjustment. With the
power mode in ON, while you adjust tire pressure up
or down, the system alerts you as follows:

Below recommended pressure:

The beeper

sounds and exterior lights flash once every five
seconds.

At recommended pressure:

The beeper sounds

and exterior lights flash rapidly for three seconds with
five seconds intervals.

Above recommended pressure:

The beeper

sounds and lights flash twice every two seconds.

668

Indicator, Coming On/Blinking

If the Transmission System Indicator Blinks along with the Warning Message

Han

lin
g the U

expected

If the Transmission System Indicator Blinks along
with the Warning Message

■

Reasons for the indicator to blink

The transmission is malfunctioning.

■

What to do when the indicator blinks

•

Immediately have your vehicle inspected by
a dealer.

•

Change the gear position to

(

after

starting the engine.

Check if the

(

position in the

instrument panel and the indicator on
the

(

button light/blink.

Starting the Engine

P. 476

If the Transmission System Indicator Blinks along with the
Warning Message

You may not be able to turn on the engine.

Make sure to set the parking brake when parking
your vehicle.

Call a professional towing service if you need to tow
your vehicle.

Emergency Towing

P. 676

669

Continued

Han

lin
g the U

expected

Fuses

Fuse Locations

If any electrical devices are not working, set
the power mode to VEHICLE OFF and check
to see if any applicable fuse is blown.

■

Fuse box A

Located at the rear end of the engine
compartment on the right side. Push the
tabs to open the box.

Fuse locations are shown on the fuse box
cover. Locate the fuse in question by the
fuse number and box cover number.

■

Engine Compartment Fuse

Box

Tab

■

Circuit protected and fuse rating

Circuit Protected

Amps

−

IG1 VB SOL

10 A

VSA/ABS

5 A

Wiper

30 A

IG1 DBW

15 A

TCU

15 A

IGP1

15 A

Sub Fan Motor

30 A

Rear Driver’s Side Power

Window

30 A

Ignition Coil/Injector

30 A

TCU 2

10 A

TCU 3

10 A

PDM LT2

30 A

ST CUT

30 A

Shutter Grill

(10 A)

Back Up

10 A

Stop

(10 A)

PDM LT1

30 A

Rear Passenger’s Side

Power Window

30 A

ACM

30 A

Hazard

15 A

Washer

15 A

Main Fan Motor

30 A

STRLD

5 A

IGPS

5 A

Stop

(10 A)

29 Right Headlight Low Beam

10 A

Left Headlight Low Beam

10 A

Injector

20 A

Ignition Coil

15 A

FET Module

5 A

Circuit Protected

Amps

670

Fuses

Fuse Locations

Han

lin
g the U

expected

■

Fuse box B

b c

d e f

Remove the engine compartment cover
and the air intake duct.

Engine Compartment Cover

P. 599

Checking the Battery

P. 630

Remove the cover on the

terminal (as

shown).
Replacement of engine compartment
fuses should be done by a dealer.

■

Circuit protected and fuse rating

Circuit Protected

Amps

Battery Main

150 A

FET

70 A

R/B Main 1

70 A

R/B Main 2

70 A

EPS

70 A

VAC

60 A

* Not available on all models

671

Fuses

Fuse Locations

Continued

Han

lin
g the U

expected

Located under the dashboard.

■

Fuse box A

Fuse locations are shown on the label on
the side panel.
Locate the fuse in question by the fuse
number and label number.

■

Driver’s Side Interior Fuse Box

Fuse Label

■

Circuit protected and fuse rating

Circuit Protected

Amps

Meter

10 A

Starter Motor

(10 A)

Option

10 A

−

Moonroof

(20 A)

−

Rear Fuse Box

10 A

IG1 Front

15 A

10 Rear Passenger’s Door Lock

10 A

Driver’s Door Lock

10 A

Front Passenger’s Door

Lock

10 A

Front Passenger’s Door

Unlock

10 A

Driver’s Door Unlock

(10 A)

Rear Wiper

10 A

SMART

10 A

Driver’s Power Seat

Reclining

20 A

Heated Steering Wheel

(10 A)

Front Passenger’s Power

Seat Reclining

20 A

SRS

10 A

Fuel Pump

20 A

Front Accessory Power

Socket

20 A

Left Headlight High Beam

10 A

24 Right Headlight High Beam

10 A

Driver’s Power Window

20 A

Rear Passenger’s Door

Unlock

10 A

ACC

10 A

SRS2

10 A

Driver’s Power Seat Lumbar

Support

(10 A)

Front Passenger’s Power

Seat Sliding

20 A

31 Driver’s Power Seat Sliding

20 A

Tailgate Lock

(10 A)

−

ACG

15 A

DRL

10 A

A/C

10 A

Radio

15 A

Door Lock Main

20 A

Front Passenger’s Power

Window

20 A

Circuit Protected

Amps

* Not available on all models

672

Fuses

Fuse Locations

Han

lin
g the U

expected

■

Fuse box B

Fuse Label

■

Circuit protected and fuse rating

Circuit Protected

Amps

DC/DC2

(30 A)

DC/DC1

(30 A)

EBB

40 A

Fuse Box Main1

50 A

Fuse Box Main2

50 A

Rear Fuse Box Main1

50 A

Rear Fuse Box Main2

50 A

Vacuum

(60 A)

IG Main1

30 A

AC Outlet

(30 A)

IG Main2

30 A

−

Rear Blower

30 A

Audio Amp2

(20 A)

Audio Amp1

(20 A)

Rear Defogger

40 A

−

Heated Windshield

(15 A)

BMS

5 A

Audio Amp3

(30 A)

Front Passenger’s Power

Seat Lumbar Support

(10 A)

−

VSA Motor

40 A

Front Blower

40 A

−

Horn

10 A

−

3rd Row Accessory Power

Socket

(20 A)

Shift By Wire

10 A

VBUM

10 A

VSA

40 A

Circuit Protected

Amps

* Not available on all models

Honda Odyssey (2023 year). Manual in english - page 41
