Honda Odyssey (2023 year). Manual in english

254

Climate Control System

Rear Climate Control System

Co
ntrols

Rear Climate Control System

Use the system when the engine is running.

Press the

REAR CLIMATE

button.

Press the

REAR CLIMATE

button to display AUTO, MODE, temperature control,

and fan control information on the audio/information screen for several seconds.

Select the

AUTO

icon.

The rear system changes to AUTO mode.

The system automatically adjusts the fan speed and airflow levels to maintain
the set rear temperature. Change the temperature if necessary.

To turn off the rear climate control system, select the

ON/OFF

icon.

■

Using the Rear Climate Control System From the Front Panel

Rear Climate Control System

LOCK

appears on the rear control panel while the

rear lock is on.

If the rear lock is on while in SYNC mode, the rear
control panel is disabled.

LOCK SYNC

appears on the

rear control panel.

Using the Rear Climate Control System From the Front Panel

Select the

LOCK

icon to turn the rear lock mode on

and off.

While the rear lock mode is on, the rear control panel
is disabled.

The color of

LOCK

icon on the audio/information

screen changes from gray to blue.

LOCK

Icon

REAR CLIMATE

Button

Rear

AUTO

Icon

Rear Fan Control
Icon

Mode Control Icon
(Rear floor vents)

Mode Control Icon
(Rear ceiling vents and
floor vents)

Mode Control Icon
(Rear ceiling vents)

ON/OFF

Icon

Rear
Temperature
Control Icon

255

Climate Control System

Rear Climate Control System

Co
ntrols

Use the system when the engine is running.

Press the

AUTO

button.

Adjust the interior temperature using the rear temperature control bar.

To turn off the rear climate control system, press

button.

■

Using the Rear Climate Control System From the Rear Panel

Using the Rear Climate Control System From the Front Panel

When the rear fan is set to maximum speed, Auto
Idle Stop does not activate.

Auto Idle Stop may not activate under other

conditions when the rear climate control system is
in use.

Using the Rear Climate Control System From the Rear Panel

When the rear lock mode is off, the temperature of
the rear passenger compartment can be controlled
independently.

Rear ceiling
vents

Rear floor
vents

Rear ceiling vents
and floor vents

(Rear Fan

Control) Bar

Rear Temperature
Control Bar

(On/Off) Button

Rear

MODE

Button

Rear

AUTO

Button

258

Features

Audio System

About Your Audio System

The audio system features AM/FM radio and SiriusXM

Radio

service. It can also

play audio CDs

, USB flash drives, iPod, iPhone, iPad and

Bluetooth

devices.

You can operate the audio system from the knob on the panel, the remote controls
on the steering wheel, or the icons on the touchscreen interface.

About Your Audio System

State or local laws may prohibit the operation of
handheld electronic devices while operating a
vehicle.

Video CDs and 3-inch (8-cm) mini CDs are not
supported.

SiriusXM

Radio

is available on a subscription basis

only. For more information on SiriusXM

Radio

contact a dealer.

General Information on the Audio System

P. 341

SiriusXM

Radio

is available in the United States and

Canada, except Hawaii, Alaska, and Puerto Rico.

SiriusXM

is a registered trademark of SiriusXM

Radio

, Inc.

After you set the power mode to VEHICLE OFF, you
can use the audio system for up to 30 minutes per
driving cycle, or until opening the driver’s door.
However, whether you can continue using the audio
system depends on the battery condition. Repeatedly
using this feature may drain the battery.

Models with Blu-ray

player

Remote Controls

iPod

USB Flash Drive

* Not available on all models

259

Audio System

USB Ports

Continued

Features

USB Ports

Install the USB connector or the USB flash drive to the USB port.

■

In the console compartment

The USB port (2.5A) is for charging devices,
playing audio files and connecting compatible
phones with Apple CarPlay or Android Auto.

To prevent any potential issues, be sure
to use an Apple MFi Certified Lightning
Connector for Apple CarPlay, and for
Android Auto, the USB cables should be
certified by USB-IF to be compliant with
USB 2.0 Standard.

USB Ports

•

Do not leave the iPod or USB flash drive in the
vehicle. Direct sunlight and high temperatures may
damage it.

•

We recommend that you use a USB cable if you are
attaching a USB flash drive to the USB port.

•

Do not connect the iPod or USB flash drive using a
hub.

•

Do not use a device such as a card reader or hard
disk drive, as the device or your files may be
damaged.

•

We recommend backing up your data before using
the device in your vehicle.

•

Displayed messages may vary depending on the
device model and software version.

If the audio system does not recognize the iPod, try
reconnecting it a few times or reboot the device. To
reboot, follow the manufacturer’s instructions
provided with the iPod or visit

www.apple.com/ipod

The USB port can supply up to 2.5A of power. It does
not output 2.5A unless the device requests.
For amperage details, read the operating manual of
the device that needs to be charged.

Under certain conditions, a device connected to the
port may generate noise to the radio station you are
listening to.

USB charge

260

Audio System

USB Ports

Features

■

On the console panel

The USB port (2.5A) is only for charging
devices.

You cannot play music even if you have
connected music players to them.

■

On the back of the console
compartment

The USB ports (2.5A) are only for charging
devices.

You cannot play music even if you have
connected music players to them.

■

On the left side of the third row seats

The USB port (2.5A) is only for charging
devices.

You cannot play music even if you have
connected music players to them.

* Not available on all models

261

Audio System

Auxiliary Input Jack

Features

Auxiliary Input Jack

Use the jack to connect standard audio
devices.

Open the

AUX

cover.

Connect a standard audio device to the
input jack using a 1/8 inch (3.5 mm) stereo
miniplug.

The audio system automatically switches
to the AUX mode.

Audio System Theft Protection

The audio system is disabled when it is disconnected from the power source, such as
when the battery is disconnected or goes dead. In certain conditions, the system
may display a code entry screen. If this occurs, reactivate the audio system.

■

Reactivating the audio system

Set the power mode to ON.

Turn on the audio system.

Press and hold the audio system power knob for more than two seconds.

The audio system is reactivated when the audio control unit establishes a
connection with the vehicle control unit. If the control unit fails to recognize
the audio unit, you must go to a dealer and have the audio unit checked.

Auxiliary Input Jack

You can return to AUX mode by selecting the audio
source icon on the audio/information screen.

You cannot use the auxiliary input jack if you replace
the audio system.

262

Audio System

Audio Remote Controls

Features

Audio Remote Controls

Allow you to operate the audio system while driving. The information is shown on
the driver information interface.

(

(Volume) Bar

Press

(

To increase the volume.

Press

(

To decrease the volume.

Audio Remote Controls

Some modes appear only when an appropriate
device or medium is used.

Depending on the

Bluetooth

device you connect,

some functions may not be operated.

Press the

(back) button to go back to the

previous screen or cancel a command.

Press the

(home) button to go back to the home

screen of the driver information interface.

You can show or hide the audio mode icons, or
change the order of the icons.

Show/Hide Apps

P. 140

Arrange Apps

P. 141

ENTER

Button

(

Bar

Buttons

3 4

263

Audio System

Audio Remote Controls

Features

/ENTER Buttons

•

When selecting the audio mode
Press

select

Now Playing

on the home screen of the driver

information interface, and then press the

ENTER

button.

Press

or :

To cycles through the audio modes as follows:

Android Auto/Apple CarPlay



SiriusXM



Rear Entertainment



AUX

Input



Bluetooth

Audio



Social Playlist



My Honda Music



USB/

iPod

•

When listening to the radio

Press :

To select the next preset radio station.

Press :

To select the previous preset radio station.

Press and hold

To select the next strong station.

Press and hold

To select the previous strong station.

•

When listening to an iPod, USB flash drive, My Honda Music, or

Bluetooth

Audio

Press :

To skip to the next song.

Press :

To go back to the beginning of the current or previous song.

•

When listening to an iPod, USB flash drive, My Honda Music,

Bluetooth

Audio,

or Apple CarPlay

Press and hold

To move rapidly within a song.

3 4

* Not available on all models

264

Features

Audio System Basic Operation

To use the audio system function, the power mode must be in ACCESSORY or ON.

: Select to go to the home screen.

Switching the Display

P. 265

: Select to go back to the previous display

when it is displayed.

: Select to change the audio/information

screen brightness.
Select

once and select

to make

an adjustment.

Each time you select

, the mode

switches among the daytime mode,
nighttime mode and off mode.

(Day/Night) Icon

(Home) Icon

(Back) Icon

265

Audio System Basic Operation

Audio/Information Screen

Continued

Features

Audio/Information Screen

Displays the audio status and wallpaper. From this display, you can go to various
setup options.

■

Using the audio/information screen

Select

to go to the home screen.

Select the following icons on the home screen or after selecting

All Apps

■

Switching the Display

Audio/Information Screen

Touchscreen Operation

•

Use simple gestures - including touching, swiping,
and scrolling - to operate certain audio functions.

•

Some items may be grayed out during driving to
reduce the potential for distraction.

•

You can select them when the vehicle is stopped or
use voice commands.

•

Wearing gloves may limit or prevent touchscreen
response.

You can change the touchscreen sensitivity setting.

Customized Features

P. 413

Home Screen

(Home) Icon

All Apps

266

Audio System Basic Operation

Audio/Information Screen

Features

■

Phone

Displays the HFL information.

Bluetooth

HandsFreeLink

P. 435

■

Trip Computer

Displays the trip computer information.

•

Current Drive

tab: Displays the current trip information.

•

Trip A

Trip B

tab: Displays information for the current and three previous drives.

The information is stored every time you reset Trip A/B.
To reset Trip A/B, select

Reset

To change the setting of how to reset Trip A/B, select

Settings

, then select

Trip

A Reset Method

Trip B Reset Method

■

Clock

Displays the clock.

■

System Updates

Updates the software version of the audio system.

System Updates

P. 279

■

FM/AM/Sirius XM

/USB/Bluetooth Audio/AUX Input/My Honda Music/

Social Playlist

Displays the each audio information.

■

Settings

Enters the customizing menu screen.

Customized Features

P. 413

* Not available on all models

267

Audio System Basic Operation

Audio/Information Screen

Continued

Features

■

Navigation

Displays the navigation screen.

Refer to the Navigation System Manual

■

HondaLink

Displays the HondaLink

screen.

HondaLink

P. 324

■

Apple CarPlay/Android Auto

Displays the

Apple CarPlay

Android Auto

Apple CarPlay

P. 332

Android Auto

P. 335

■

Messages

Displays the text message screen.

Bluetooth

HandsFreeLink

P. 435

■

CabinTalk

Displays the

CabinTalk

screen.

CabinTalk

P. 461

■

CabinWatch

Displays the

CabinWatch

screen.

CabinWatch

P. 460

■

Rear Entertainment

Displays the rear audio screen.

Blu-ray/DVD Rear Entertainment System

P. 365

* Not available on all models

268

Audio System Basic Operation

Audio/Information Screen

Features

■

AT&T Hotspot

Displays the AT&T Hotspot screen.

AT&T Hotspot

P. 330

■

File Manager

Displays the file manager screen.

File Manager

P. 285

* Not available on all models

Continued

269

Audio System Basic Operation

Audio/Information Screen

Features

You can change, store, and delete the wallpaper on the audio/information screen.

■

Import wallpaper

Connect the USB flash drive to the USB port
in the console compartment.

USB Ports

P. 259

Select

Clock

Select

Settings

Select

Clock Faces

Select

Add More

The

File Manager

screen is displayed.

Import a desired picture.

How to Transfer a File

P. 285

The display will return to the

Clock Faces

screen.

■

Wallpaper Setup

Wallpaper Setup

The wallpaper you set up on

Clock Faces

cannot be

displayed on the driver information interface.

•

The file name must be fewer than 255 characters.

•

The file format of the image that can be imported
is BMP, GIF, JPEG, PNG, or WebP.

•

If the USB flash drive does not have any pictures,
the

No Data

message appears.

Honda Odyssey (2023 year). Manual in english - page 16
