uu

Seats

u

Third Row Seats

222

Co
ntrols

■

When returning the seat to the upright position:

1.

Grab the handle from outside.
Pull up the folded seat, begin to pivot it
forward, then allow it to drop into position.

2.

The front leg latches when it contacts the
floor striker.

Pull the strap to put the seat-back(s)
upright. Rock the seat-back and forth to
confirm the seat is securely locked in
position. There should be no movement.

1

When returning the seat to the upright position:

Make sure the seat is securely latched before driving
by rocking the seat-back and forth.

Handles

Straps

223

uu

Seats

u

Rear Seat Reminder

Co
ntrols

Rear Seat Reminder

This feature alerts you to the possible presence of passengers or items in the second
row or third row seats before you exit the vehicle. It activates when the vehicle is set
to VEHICLE OFF if the rear doors were opened shortly before or after the vehicle was
set to ON.

A reminder appears on the driver information
interface and an alert will sound when the
power mode is set to VEHICLE OFF.

A reminder appears on the audio/information
screen when the power mode is set to
VEHICLE OFF.
To dismiss the notification, select

Dismiss

.

1

Rear Seat Reminder

When the power mode is set to VEHICLE OFF, the
reminder comes on briefly, then the function is
deactivated.

The reminder will not work if the power mode has
not been set to ON within 10 minutes of operating
the rear doors.

The system does not detect passengers in the rear
seats. Instead, it can detect when a rear door is
opened and closed, indicating that there may be
something in the rear seats.

You can turn off the notification setting.

2

Customized Features

 P. 413

Models with CabinWatch

®

224

uu

Seats

u

Maintain a Proper Sitting Position

Co
ntrols

Maintain a Proper Sitting Position

After all occupants have adjusted their seats and head restraints, and put on their
seat belts, it is very important that they continue to sit upright, well back in their
seats, with their feet on the floor, until the vehicle is safely parked and the engine is
off.

Sitting improperly can increase the chance of injury during a crash. For example, if
an occupant slouches, lies down, turns sideways, sits forward, leans forward or
sideways, or puts one or both feet up, the chance of injury during a crash is greatly
increased.

In addition, an occupant who is out of position in the front seat can be seriously or
fatally injured in a crash by striking interior parts of the vehicle or being struck by an
inflating front airbag.

1

Maintain a Proper Sitting Position

3

WARNING

Sitting improperly or out of position can
result in serious injury or death in a crash.

Always sit upright, well back in the seat,
with your feet on the floor.

225

uu

Seats

u

Head Restraints

Continued

Co
ntrols

Head Restraints

Your vehicle is equipped with head restraints in all seating positions.

Head restraints are most effective for
protection against whiplash and other rear-
impact crash injuries when the center of the
back of the occupant’s head rests against the
center of the restraint. The tops of the
occupant’s ears should be level with the
center height of the restraint.

■

Adjusting the Front and Second Row Outer and Third Row

Outer Head Restraints Positions

1

Head Restraints

In order for the head restraint system to work
properly:

•

Do not hang any items on the head restraints, or
from the restraint legs.

•

Do not place any objects between an occupant and
the seat-back.

•

Install each restraint in its proper location.

3

WARNING

Improperly positioning head restraints
reduces their effectiveness and increases
the likelihood of serious injury in a crash.

Make sure head restraints are in place and
positioned properly before driving.

Position head in the center
of the head restraint.

226

uu

Seats

u

Head Restraints

Co
ntrols

To raise the head restraint:

Pull it upward.

To lower the head restraint:

Push it down

while pressing the release button.

Front and second row outer

Third row outer

227

uu

Seats

u

Head Restraints

Co
ntrols

A passenger sitting in the second row/third
row center seating position should adjust the
height of their head restraint to an
appropriate position before the vehicle begins
moving.

To raise the head restraint:

Pull it upward.

To lower the head restraint:

Push it down while pressing the release
button.

Head restraints can be removed for cleaning or repair.

To remove a head restraint:

Pull the restraint up as far as it will go. Then, push the release button and pull the
restraint up and out.

To reinstall a head restraint:

Insert the legs back in place, then adjust the head restraint to an appropriate height
while pressing the release button. Pull up on the restraint to make sure it is locked
in position.

■

Changing the Second Row/Third Row Center Seat Head

Restraint Positions

■

Removing and Reinstalling the Head Restraints

1

Removing and Reinstalling the Head Restraints

To remove the third row seat outer head restraints,
fold down the seat-back first.

2

Third Row Seats

 P. 220

3

WARNING

Failure to reinstall, or correctly reinstall, the
head restraints can result in severe injury
during a crash.

Always replace the head restraints before
driving.

228

uu

Seats

u

Armrest

Co
ntrols

Armrest

Pull down the armrest.

Pull the armrest all the way down, then pull it
up to the desired angle.

Pull up the strap and fold down the center
backrest to use as an armrest.

■

Using the Front and Second Row Outer Seat Armrest

Front seat with adjustable armrest

■

Using the Second Row Seat Armrest

229

Continued

Co
ntrols

Interior Convenience Items

Interior Lights

■

ON

The interior lights come on regardless of
whether the doors or the tailgate are open or
closed.

■

Door activated

The interior lights come on in the following
situations:

Front:

•

When any of the doors or the tailgate are
opened.

•

You unlock the driver’s door.

•

When the power mode is set to VEHICLE
OFF.

Cargo area:

When the tailgate is open.

■

OFF

The interior lights remain off regardless of
whether the doors or the tailgate are open or
closed.

■

Interior Light Switches

1

Interior Light Switches

In the door activated position, the interior lights fade
out and go off about 30 seconds after the doors are
closed.
The lights go off after 30 seconds in the following
situations:

•

When you unlock the driver’s door but do not open
it.

•

When you set the power mode to VEHICLE OFF but
do not open a door.

You can change the interior light dimming time.

2

Customized Features

 P. 413

The interior lights go off immediately in the following
situations:

•

When you lock the driver’s door.

•

When you set the power mode to ON.

•

When you close the driver’s door in ACCESSORY
mode.

If you leave any of the doors open in VEHICLE OFF
mode, the interior lights go off after about 15
minutes.

If you leave the tailgate open in VEHICLE OFF mode,
the cargo area light goes off after about 30 minutes.

To avoid draining the battery, do not leave the
interior light on for an extended length of time when
the engine is off.

Door
Activated
Position

Off

On

Front

Door Activated Position

Off

On

Cargo Area

uu

Interior Convenience Items

u

Interior Lights

230

Co
ntrols

■

Front

The map lights can be turned on and off by
pressing the lenses.

■

Second and third row

The map lights can be turned on and off by
pressing the lenses when the front interior
light switch is in the door activated position.

■

Map Light Switches

1

Interior Light Switches

To avoid draining the battery, do not leave the
interior light on for an extended length of time when
the engine is off.

1

Map Light Switches

When the front interior light switch is in the door
activated position and any door is open, the map
light will not go off when you press the lens.

231

uu

Interior Convenience Items

u

Storage Items

Continued

Co
ntrols

Storage Items

Pull the handle to open the glove box. You
can lock the glove box with the built-in key.

■

Glove Box

1

Glove Box

3

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

232

uu

Interior Convenience Items

u

Storage Items

Co
ntrols

To open the console box, pull the handle and
slide the box forward.

You can create more storage space by
removing the divider.

■

Console Box

*

Handle

Divider

* Not available on all models

233

uu

Interior Convenience Items

u

Storage Items

Continued

Co
ntrols

To open the console compartment, press the
knob to unlock the lid, and then slide it
rearward.

Pull the handle to open the center pocket.

■

Console Compartment with Lid

Knob

■

Center Pocket

*

Handle

* Not available on all models

uu

Interior Convenience Items

u

Storage Items

234

Co
ntrols

■

Center console beverage holders

■

Front door beverage holders

■

Second row seat beverage holders

To use the beverage holder, fold the backrest.

2

Using the Second Row Seat Armrest



P. 228

■

Beverage Holders

1

Beverage Holders

NOTICE

Spilled liquids can damage the upholstery, carpeting,
and electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

235

uu

Interior Convenience Items

u

Storage Items

Continued

Co
ntrols

■

Rear door beverage holders

■

Third row seat beverage holders

uu

Interior Convenience Items

u

Storage Items

236

Co
ntrols

There are coat hooks under the grab handles
in the second row, and under the window
frames in the third row. Pull it down to use it.

■

Coat Hooks

1

Coat Hooks

The coat hooks are not designed for large or heavy
items.

Second row

Third row

237

uu

Interior Convenience Items

u

Storage Items

Continued

Co
ntrols

Use the cargo hooks to secure luggage in the
cargo area.

■

Cargo Hooks
