Honda HR-V (2023 year). Manual in english

260

Audio System Basic Operation

System Updates

Features

■

View the update history

Use the following procedure to confirm the update history.

Press the

button.

Select

System Updates

is not displayed on the home screen, select

All Apps

Select

Settings

Select

Update History

261

Audio System Basic Operation

System Updates

Continued

Features

■

Wireless connection mode setup

Press the

button.

Select

System Updates

is not displayed on the home screen, select

All Apps

Select

Settings

Select

Connection Setup

Select

Select an access point from the network list.

To connect to a hotspot that is not automatically detected, select

Options

then

Add Network

Enter the password.

If you check the

Use this network to automatically download system

updates

box, you can set the network to be used for system updates.

Select

Connect

■

How to update

Press the

button.

Select

System Updates

is not displayed on the home screen, select

All Apps

Select

via Wireless

Select

Download

A notification appears on the screen for the user to accept the download.

Select

Install Now

Install While Vehicle Off

A notification appears on the screen if the update is successful.

■

How to Update Wirelessly

Audio System Basic Operation

System Updates

262

Features

■

Download the update files from the server

Press the

button.

Select

System Updates

is not displayed on the home screen, select

All Apps

Select

Other Methods

Select

Via USB

A notification appears on the screen.

Connect a USB device into the USB port.

The inventory data is copied into the USB device.

USB Ports

P. 213

Remove the USB device from the USB port.

Connect the USB device into your computer, and then download the update files.

Follow the link to download the required software update files. Refer to

https://usb.honda.com

for instructions.

■

Update the audio system

Press the

button.

Select

System Updates

Select

Other Methods

Select

Via USB

A notification appears on the screen.

Connect the USB device with the update files into the USB port.

A notification appears on the screen.

USB Ports

P. 213

Select

Install Now

A notification appears on the screen if the update is successful.

■

How to Update with a USB Device

How to Update with a USB Device

A USB device with a minimum of 8 GB of free space
or more is recommended.

Be sure to delete any previous inventory or update
files from the USB before starting the USB update
process.

263

Audio System Basic Operation

Adjusting the Sound

Features

Adjusting the Sound

Press the

button.

Select an audio source icon.

Select

Sound

Select an item from the following choices:

•

Bass / Treble:

Treble, Midrange, Bass

•

Balance / Fader:

Balance, Fader

•

Speed Volume Compensation:

Set the

amount of volume increase.

Adjusting the Sound

The

Speed Volume Compensation

adjusts the

volume level based on the vehicle speed. As you go
faster, audio volume increases. As you slow down,
audio volume decreases.

You can also adjust the sound by the following
procedure.
1. Press the

button.

2. Select

General Settings

3. Select

Sound

To reset each setting for

Bass / Treble

Balance /

Fader

, and

Speed Volume Compensation

, select

Default

on each setting screen.

264

Audio System Basic Operation

Display Setup

Features

Display Setup

You can set the screen brightness.

Select

Display Mode

The brightness bar is displayed for a few
seconds.

Select

to adjust the brightness.

Select

Display OFF

to turn off the

screen. To turn on the screen, press the

button.

■

Switching Display Mode Manually

Display Setup

You can adjust the screen brightness by sliding or
tapping on the brightness bar.

You can also change the screen brightness on the
following procedures.
1. Press the

button.

2. Select

General Settings

3. Select

Display

4. Select the setting you want.

To reset the settings, select

Default

265

Audio System Basic Operation

Display Setup

Features

Select

Audio Source

in the header area, then select an icon on the source list to

switch the audio source.

Certain manual functions are disabled or inoperable while the vehicle is in motion.
You cannot select a grayed-out option until the vehicle is stopped.

■

Selecting an Audio Source

■

Limitations for Manual Operation

Select

Audio Source

Source Select Screen

Source List Icons

266

Audio System Basic Operation

Voice Control Operation

Features

Voice Control Operation

Your vehicle has a voice control system that allows hands-free operation.
The voice control system uses the

(Talk) button on the steering wheel and a

microphone near the map lights on the ceiling.

To achieve optimum voice recognition when using the voice control system:

•

Make sure the correct screen is displayed for the voice command that you are
using.
The system recognizes only certain commands.
Available voice commands:

Voice Portal Screen

P. 267

•

Close the windows and moonroof.

•

Adjust the dashboard and side vents so air does not blow onto the microphone
on the ceiling.

•

Speak clearly in a natural speaking voice without pausing between words.

•

Reduce any background noise if possible. The system may misinterpret your
command if more than one person is speaking at the same time.

■

Voice Recognition

Voice Control Operation

When you press the

button, a helpful prompt asks

what you would like to do. Press and release the

button again to bypass this prompt and give a
command.

Voice Recognition

The voice control system can only be used from the
driver’s seat because the microphone unit removes
noises from the front passenger’s side.

267

Audio System Basic Operation

Voice Control Operation

Continued

Features

When the

(talk) button is pressed,

available voice commands appear on the
screen.
For a complete list of commands, say

“Help”

after the beep.

Depending on the selected mode, the
displayed commands are different on the
voice portal screen. The commands
recognized are the same regardless of
which screen is selected.
Normal Mode: A list of example commands
is displayed to quickly complete your
desired function.
Assist Mode: A list of basic commands is
displayed to guide you step by step through
the voice menu.

■

Voice Portal Screen

You can change the mode on the

General

Settings

screen.

Voice Control

P. 356

The system only recognizes the commands
on the following pages, at certain screens.
Free-form voice commands are not
recognized.

When the voice portal screen is displayed, it
will change to the top screen of each
function by using the global commands.

•

Music Search

•

Sirius XM

•

Navigation

•

Phone

When the system recognizes a phone
command, the screen will change to the
dedicated phone voice recognition screen.
These commands can only be used when a
phone is connected.

■

General Commands

■

Phone Commands

■

Phone Commands

•

Call <name>

•

Call <number>

The system only recognizes contact names
stored in the phonebook of your phone. If a
full name is registered in the first name
field, the system will recognize the first
name and last name as one contact name.

Phone commands are not available if using
Apple CarPlay.

When the system recognizes an audio
command, the screen will change to the
dedicated audio voice recognition screen.

■

FM Commands

•

Tune to <FM frequency>

■

AM Commands

•

Tune to <AM frequency>

■

Sirius XM Commands

•

Tune to SXM <channel number>

•

Tune to SXM <station name>

■

Audio Commands

* Not available on all models

268

Audio System Basic Operation

Voice Control Operation

Features

■

iPod Commands

•

List Album <name>

•

List Artist <name>

•

List Genre <name>

•

List Playlist <name>

•

Play <artist> <album>

•

Play

•

Play Album <name>

•

Play Artist <name>

•

Play Genre <name>

•

Play Music <text:media_combo>

•

Play Playlist <name>

•

Play Song <name>

■

USB Commands

•

List Album <name>

•

List Artist <name>

•

List Playlist <name>

•

Play <artist> <album>

•

Play

•

Play Album <name>

•

Play Artist <name>

•

Play Music <text:media_combo>

•

Play Playlist <name>

•

Play Song <name>

The screen will change to the navigation
screen when a navigation voice command is
received.

Refer to the Navigation System Manual

•

Voice Help

•

Cancel

•

Back

Voice Help provides guidance for the
current screen.

•

Previous

•

Next

•

Yes

•

■

Navigation Commands

■

Standard Commands

■

List Commands

* Not available on all models

269

Audio System Basic Operation

Playing AM/FM Radio

Continued

Features

Playing AM/FM Radio

(Back) Button

Press to go back to the previous
display.

Seek Buttons

Press

to search the selected band up

or down for a station with a strong signal.

VOL/

AUDIO (Volume/Power) Knob

Press to turn the audio system on and
off.
Turn to adjust the volume.

Settings Icon

Select whether to tune to HD
Radio

automatically.

Tune Icon

Select to use the on-screen keyboard for entering
the radio frequency directly.

Audio/Information Screen

Scan Icon

Select to scan each station with a strong signal.

Preset Icons

Tune the radio frequency for preset
memory.
Select and hold the preset icon to
store that station. Select

display beyond preset 5.

Audio System Basic Operation

Playing AM/FM Radio

270

Features

To store a station:

Tune to the selected station.

Select and hold the preset icon to store that station.

Selecting

Press & Hold

can be set a new preset station.

Lists the strongest stations on the selected band.

Select

Station List

to display a list.

Select the station.

■

Manual update

Updates your available station list at any time.

Select

Station List

to display a list.

Select

Refresh

■

Preset Memory

■

Station List

Preset Memory

The

indicator appears on the display indicating

stereo FM broadcasts.
Stereo reproduction in AM is not available.

Switching the Audio Mode
Roll the left selector wheel or select

Audio Source

on the screen.

Audio Remote Controls

P. 215

You can store 12 AM/FM stations into preset
memory.

HD Radio Technology manufactured under license
from iBiquity Digital Corporation. U.S. and Foreign
Patents. For patents see

http://dts.com/patents

. HD

Radio, Artist Experience, and the HD, HD Radio, and
“ARC” logos are registered trademarks or
trademarks of iBiquity Digital Corporation in the
United States and/or other countries.

Continued

271

Audio System Basic Operation

Playing AM/FM Radio

Features

Samples each of the strongest stations on the selected band for 10 seconds. To turn
off scan, select

Stop

or press the

button.

Displays the subchannel list when an HD Radio

station is selected while listening to

an FM station.

Select

HD Radio Channels

Select the channel number.

Provides text data information related to your selected RDS-capable FM station.

■

To find an RDS station from Station List

Select

Station List

to display a list while listening to an FM station.

Select the station.

■

Manual update

Updates your available station list at any time.

Select

Station List

to display a list while listening to an FM station.

Select

Refresh

■

Scan

■

HD Subchannel

■

Radio Data System (RDS)

Radio Data System (RDS)

When you select an RDS-capable FM station, the RDS
automatically turns on, and the frequency display
changes to the station name. However, when the
signals of that station become weak, the display
changes from the station name to the frequency.

272

Audio System Basic Operation

Playing AM/FM Radio

Features

Change the AM/FM settings.

Select

Settings

Select an option.

•

HD Radio:

Automatically choose a digital or an analog channel, or listen to

analog only.

•

Artwork:

Turns the artwork display on and off.

■

AM/FM Settings

273

Audio System Basic Operation

Playing SiriusXM

Radio

Continued

Features

Playing SiriusXM

Radio

Channel Icons

Select

to the previous or next channel.

Select and hold to rapidly skip 10 channels at a time.

Settings Icon

Select settings to display and
customize SiriusXM

settings.

Category Icons

Select

to display and select a SiriusXM

Radio category.

Audio/Information Screen

Preset Icons

Tune the radio frequency for preset
memory.
Select and hold the preset icon to store
that station. Select

to display beyond

preset 5.

Seek Buttons

Press

to search the selected band

up or down for a station with a strong signal.

Album Art

(Back) Button

Press to go back to the previous
display.

VOL/

AUDIO (Volume/Power) Knob

Press to turn the audio system on and
off.
Turn to adjust the volume.

Audio System Basic Operation

Playing SiriusXM

Radio

274

Features

Select

Settings

Select

Tune Mode

Select

Channel

Category

■

To Change the Tune Mode

Playing SiriusXM

Radio

In the channel mode, all available channels are
selectable. In the category mode, you can select a
channel within a category (Jazz, Rock, Classical, etc.).

There may be instances when SiriusXM

Radio does

not broadcast all the data fields (artist name, title).
This does not indicate a problem with your audio
system.

SiriusXM

Radio stations load in ascending order,

which can take about a minute. Once they have
loaded you will be able to scroll up or down to make
your selections.

Switching the Audio Mode
Roll the left selector wheel or select

Audio Source

on the screen.

Audio Remote Controls

P. 215

Tune Start:

When you change to a preset channel, a song being
played on that channel restarts from the beginning
with this function. This can be turned on or off by the
following procedure.
1. Select

Settings

2. Select

Tune Start

3. Select

OFF

To change a category, select

Category

icons, or

select

More

and then select

Category List

Continued

275

Audio System Basic Operation

Playing SiriusXM

Radio

Features

To store a channel:

Tune to the selected channel.

Select and hold the preset icon to store that channel.

Selecting

Press & Hold

can be set a new preset channel.

■

Multi-channel preset (for music channels only)

You can store up to 10 of your preferred music channels per preset.

Tune a station.

Select and hold the preset number you
want to add a music channel.

Select

Add to TuneMix

Create

TuneMix

A message appears if there are no
available presets.

■

Preset Memory

Playing SiriusXM

Radio

You can store 12 SiriusXM

channels into the preset

memory.

Multi-channel preset (for music channels only)

TuneMix

is a registered trademark of SiriusXM

Radio, Inc.

TuneMix:

The multi-channel preset function can be turned on
or off by the following procedure.
1. Select

Settings

2. Select

TuneMix

3. Select

OFF

When you want to replace the channel, select

Replace Preset

If you want to delete a channel, select

Edit TuneMix

and then select the channel you want to delete.

Honda HR-V (2023 year). Manual in english - page 15
