Continued

557

uu

If a Tire Goes Flat

u

Changing a Flat Tire

Han

d

lin
g the U

n

expected

1.

Put the flat tire in the storage bag provided
with your vehicle.

u

The storage bag is in the tool case.

2.

Knot the top of the storage bag.

3.

Securely put the jack, jack handle bar and
wheel nut wrench back in the tool case.

4.

Bore through the bag, and pass the holding
belt through the hole of the bag and the
wheel of the flat tire as shown.

5.

Place the flat tire in the cargo area, and
thread the belt through the rear anchor as
shown.

6.

Pass the belt through the ring, and tighten
the belt to secure the flat tire in place.

■

Storing the Flat Tire

1

Storing the Flat Tire

3

WARNING

Loose items can fly around the interior in a
crash and can seriously injure the
occupants.

Store the wheel, jack, and tools securely
before driving.

Belt

Rear Anchor

uu

If a Tire Goes Flat

u

Changing a Flat Tire

558

Han

d

lin
g the U

n

expected

If you replace a flat tire with the spare tire, the low tire pressure/TPMS indicator
comes on while you are driving. After driving for a few miles (kilometers), the
indicator will start blinking for a short time and then stay on.

Tire Pressure

Monitor Problem

 appears on the driver information interface, but this is normal.

If you replace the tire with a specified regular tire, the warning message on the
driver information interface and the low tire pressure/TPMS indicator will go off after
a few miles (kilometers).

■

TPMS with Tire Fill Assist and the Compact Spare Tire

1

TPMS with Tire Fill Assist and the Compact Spare Tire

The system cannot monitor the pressure of the spare
tire. Manually check the spare tire pressure to be sure
that it is correct.

Use the TPMS specific wheels. Each is equipped with
a tire pressure sensor mounted inside the tire behind
the valve stem.

559

Han

d

lin
g the U

n

expected

Engine Does Not Start

Checking the Engine

If the engine does not start, check the starter.

Starter condition

Checklist

Starter doesn’t turn or turns
over slowly.

The battery may be dead. Check
each of the items on the right and
respond accordingly.

Check for a message on the driver information interface.

●

If the

To Start, Hold Remote Near Start Button

 message appears

2

If the Keyless Remote Battery is Weak

 P. 560

u

Make sure the keyless remote is in its operating range.

2

ENGINE START/STOP Button Operating Range

 P. 158

The starter turns over normally
but the engine doesn’t start.

There may be a problem with a
fuse. Check each of the items on
the right and respond accordingly.

Review the engine start procedure.

Follow its instructions, and try to start the engine again.

2

 Starting the Engine

 P. 394

Check the immobilizer system indicator.

When the immobilizer system indicator is blinking, the engine cannot be started.

2

Immobilizer System

 P. 151

Check the fuel level.

There should be enough fuel in the tank.

2

 Fuel Gauge

 P. 107

Check the fuses.

Check all fuses, or have the vehicle checked by a dealer.

2

Inspecting and Changing Fuses

 P. 576

If the problem continues:

2

Emergency Towing

 P. 577

1

Checking the Engine

If you must start the vehicle immediately, use an
assisting vehicle or booster battery to jump start it.

2

If the Battery Is Dead

 P. 562

560

uu

Engine Does Not Start

u

If the Keyless Remote Battery is Weak

Han

d

lin
g the U

n

expected

If the Keyless Remote Battery is Weak

If the beeper sounds, the

To Start, Hold Remote Near Start Button

 message

appears on the driver information interface, the

ENGINE START/STOP

 button

flashes, and the engine won’t start, start the engine as follows:

1.

Touch the center of the

ENGINE START/

STOP

 button with the

H

 logo on the keyless

remote while the

ENGINE START/STOP



button is flashing. The buttons on the
keyless remote should be facing you.

u

The

ENGINE START/STOP

 button

flashes for about 30 seconds.

2.

Depress the brake pedal and press the

ENGINE START/STOP

 button within 10

seconds after the beeper sounds and the

ENGINE START/STOP

 button changes

from flashing to on.

u

If you don’t depress the pedal, the mode
will change to ACCESSORY.

561

uu

Engine Does Not Start

u

Emergency Engine Stop

Han

d

lin
g the U

n

expected

Emergency Engine Stop

The

ENGINE START/STOP

 button may be used to stop the engine due to an

emergency situation even while driving. If you must stop the engine, do either of the
following operations:

•

Press and hold the

ENGINE START/STOP

 button for about two seconds.

•

Firmly press the

ENGINE START/STOP

 button three times.

The steering wheel will not lock. However, because turning off the engine disables
the power assist the engine provides to the steering and braking systems, it will
require significantly more physical effort and time to steer and slow the vehicle. Use
both feet on the brake pedal to slow down the vehicle and stop immediately in a
safe place.

The gear position automatically changes to

(

P

 after the vehicle comes to a complete

stop. Then, the power mode changes to VEHICLE OFF.

The gear position automatically changes to

(

P

 after the vehicle comes to a complete

stop. Then, press the

ENGINE START/STOP

 button twice without depressing the

brake pedal to change the mode VEHICLE OFF.

1

Emergency Engine Stop

Do not press the

ENGINE START/STOP

 button while

driving unless it is absolutely necessary for the engine
to be turned off.
If you press the

ENGINE START/STOP

 button while

driving, the beeper sounds.

U.S. models

Canadian models

562

Han

d

lin
g the U

n

expected

If the Battery Is Dead

Turn off the power to electric devices, such as audio and lights. Turn off the engine,
then open the hood.

1.

Pull up on the engine compartment cover,
remove it from the pin holders.

2.

Remove the holding clips and the air intake
duct.

■

Jump Starting Procedure

1

If the Battery Is Dead

Securely attach the jumper cables clips so that they
do not come off when the engine vibrates. Also be
careful not to tangle the jumper cables or allow the
cable ends to touch each other while attaching or
detaching the jumper cables.

Battery performance degrades in cold conditions and
may prevent the engine from starting.

3

WARNING

A battery can explode if you do not follow
the correct procedure, seriously injuring
anyone nearby.

Keep all sparks, open flames, and smoking
materials away from the battery.

Pin

Engine Compartment Cover

Air Intake Duct

Clip

563

uu

If the Battery Is Dead

u

Continued

Han

d

lin
g the U

n

expected

3.

Pull up on the engine cover, remove it from
the pins.

u

Start on the passenger side and lift the
outermost edge of the cover.

u

Move towards the driver side while
applying uniform upward pressure.

4.

Connect the first jumper cable to your
vehicle’s battery

+

 terminal.

5.

Connect the other end of the first jumper
cable to the booster battery

+

 terminal.

u

Use a 12-volt booster battery only.

u

When using an automotive battery
charger to boost your 12-volt battery,
select a lower charging voltage than 15-
volts. Check the charger manual for the
proper setting.

6.

Connect the second jumper cable to the
booster battery

-

 terminal.

7.

Connect the other end of the second
jumper cable to the engine hanger as
shown. Do not connect this jumper cable to
any other part.

8.

If your vehicle is connected to another
vehicle, start the assisting vehicle’s engine
and increase its rpm slightly.

9.

Attempt to start your vehicle’s engine. If it
turns over slowly, check that the jumper
cables have good metal-to-metal contact.

Pin

Engine Cover

Booster Battery

564

uu

If the Battery Is Dead

u

Han

d

lin
g the U

n

expected

Once your vehicle’s engine has started, remove the jumper cables in the following
order:

1.

Disconnect the jumper cable from your vehicle’s ground.

2.

Disconnect the other end of the jumper cable from the booster battery

-



terminal.

3.

Disconnect the jumper cable from your vehicle’s battery

+

 terminal.

4.

Disconnect the other end of the jumper cable from the booster battery

+



terminal.

Have your vehicle inspected by a nearby service station or a dealer.

■

What to Do After the Engine Starts

565

Continued

Han

d

lin
g the U

n

expected

Overheating

How to Handle Overheating

Overheating symptoms are as follows:

•

The temperature gauge needle is at the

 mark or the engine suddenly loses

power.

•

Stop Driving When Safe. Engine Temperature Too Hot

 message appears on

the driver information interface.

•

Steam or spray comes out of the engine compartment.

■

First thing to do

1.

Immediately park the vehicle in a safe place.

2.

Turn off all accessories and turn on the hazard warning lights.

u

No steam or spray present:

Keep the engine running and open the hood.

u

Steam or spray is present:

Turn off the engine and wait until it subsides.

Then, open the hood.

1

How to Handle Overheating

NOTICE

Continuing to drive with the temperature gauge
needle at the

 mark may damage the engine.

Continuing to drive with the

Stop Driving When

Safe. Engine Temperature Too Hot

 message on

the driver information interface may damage the
engine.

3

WARNING

Steam and spray from an overheated
engine can seriously scald you.

Do not open the hood if steam is coming
out.

H

H

uu

Overheating

u

How to Handle Overheating

566

Han

d

lin
g the U

n

expected

■

Next thing to do

1.

Check that the cooling fan is operating and
stop the engine once the temperature
gauge needle comes down.

u

If the cooling fan is not operating,
immediately stop the engine.

2.

Once the engine has cooled down, inspect
the coolant level and check the cooling
system components for leaks.

u

If the coolant level in the reserve tank is
low, remove the engine compartment
cover then add coolant until it reaches
the

MAX

 mark.

2

Engine Compartment Cover

 P. 509

u

If there is no coolant in the reserve tank,
check that the radiator is cool. Cover the
radiator cap with a heavy cloth and open
the cap. If necessary, add coolant up to
the base of the filler neck, and put the
cap back on.

■

Last thing to do

Once the engine has cooled sufficiently, restart it and check the temperature gauge.
If the temperature gauge needle has gone down, resume driving. If it has not gone
down, contact a dealer for repairs.

1

How to Handle Overheating

If the coolant is leaking, contact a dealer for repairs.

Use water as an emergency/temporary measure only.
Have a dealer flush the system with proper antifreeze
as soon as possible.

3

WARNING

Removing the radiator cap while the
engine is hot can cause the coolant to spray
out, seriously scalding you.

Always let the engine and radiator cool
down before removing the radiator cap.

Reserve Tank

MAX

MIN

567

Han

d

lin
g the U

n

expected

Indicator, Coming On/Blinking

If the Engine Oil Low Warning Appears

■

Reasons for the warning to appear

Appears when the engine oil pressure is low.

■

What to do as soon as the warning
appears

1.

Immediately park the vehicle on level
ground in a safe place.

2.

If necessary, turn the hazard warning lights
on.

■

What to do after parking the vehicle

1.

Stop the engine and let it sit for
approximately three minutes.

2.

Open the hood and check the oil level.

u

Add oil as necessary.

2

Oil Check

 P. 511

3.

Start the engine and check the

Engine Oil

Low

 warning.

u

The warning disappears: Start driving
again.

u

The warning does not disappear within
10 seconds: Immediately stop the engine
and contact a dealer for repairs.

1

If the

Engine Oil Low

 Warning Appears

NOTICE

Running the engine with low oil pressure can cause
serious mechanical damage almost immediately.

568

uu

Indicator, Coming On/Blinking

u

If the Charging System Indicator Comes On

Han

d

lin
g the U

n

expected

If the Charging System Indicator Comes On

■

Reasons for the indicator to come on

Comes on when the battery is not being charged.

■

What to do when the indicator comes on

Turn off the climate control system, rear defogger, and other electrical
systems, and immediately contact a dealer for repairs.

If the Malfunction Indicator Lamp Comes On or Blinks

■

Reasons for the indicator lamp to come on or blink

•

Comes on when there is a problem with the engine emissions control
system.

•

Blinks when engine misfiring is detected.

■

What to do when the indicator lamp comes on

Avoid high speeds and immediately get your vehicle inspected at a
dealer.

■

What to do when the indicator lamp blinks

Park the vehicle in a safe place with no flammable items and wait at least
10 minutes or more with the engine stopped until it cools.

1

If the Charging System Indicator Comes On

If you need to stop temporarily, do not turn off the
engine. Restarting the engine may rapidly discharge
the battery.

1

If the Malfunction Indicator Lamp Comes On or Blinks

NOTICE

If you drive with the malfunction indicator lamp on,
the emissions control system and the engine could be
damaged.

If the malfunction indicator lamp blinks again when
restarting the engine, drive to the nearest dealer at
31 mph (50 km/h) or less. Have your vehicle
inspected.

569

uu

Indicator, Coming On/Blinking

u

If the Brake System Indicator (Red) Comes On

Han

d

lin
g the U

n

expected

If the Brake System Indicator (Red) Comes On

■

Reasons for the indicator to come on

•

The brake fluid is low.

•

There is a malfunction in the brake system.

■

What to do when the indicator comes on while driving

Depress the brake pedal lightly to check pedal pressure.

•

If normal, check the brake fluid level the next time you stop.

•

If abnormal, take immediate action. If necessary, downshift the
transmission to slow the vehicle using engine braking.

If the Electric Power Steering (EPS) System Indicator Comes On

■

Reasons for the indicator to come on

•

Comes on when there is a problem with the EPS system.

•

If you depress the accelerator pedal repeatedly to increase the engine
speed while the engine is idling, the indicator comes on, and
sometimes the steering wheel becomes harder to operate.

■

What to do when the indicator comes on

Stop the vehicle in a safe place and restart the engine.
If the indicator comes on and stays on, immediately have your vehicle
inspected by a dealer.

1

If the Brake System Indicator (Red) Comes On

Have your vehicle repaired immediately.
It is dangerous to drive with low brake fluid. If there
is no resistance from the brake pedal, stop
immediately in a safe place. If necessary downshift
the gears.

If the brake system indicator and

ABS

 indicator come

on simultaneously, the electronic brake distribution
system is not working. This can result in vehicle
instability under sudden braking.
Have your vehicle inspected by a dealer immediately.

U.S.

Canada

570

uu

Indicator, Coming On/Blinking

u

If the Low Tire Pressure/Tire Pressure Monitoring System (TPMS) Indicator Comes On or Blinks

Han

d

lin
g the U

n

expected

If the Low Tire Pressure/Tire Pressure Monitoring
System (TPMS) Indicator Comes On or Blinks

■

Reasons for the indicator to come on or blink

A tire pressure is significantly low. If there is a problem with the TPMS
with Tire Fill Assist or the compact spare tire is installed, the indicator
blinks for about one minute, and then stays on.

■

What to do when the indicator comes on

Stop your vehicle in a safe place. Check the tire pressure and adjust the
pressure to the specified level. The specified tire pressure is on a label on
the driver side doorjamb.

■

What to do when the indicator blinks, then remains on

Have the tire inspected by a dealer as soon as possible. If the compact
spare tire causes the indicator to blink, change the tire to a full-size tire.
The indicator goes off after driving for a few miles (kilometers).

1

If the Low Tire Pressure/Tire Pressure Monitoring System (TPMS)
Indicator Comes On or Blinks

NOTICE

Driving on an extremely underinflated tire can cause
it to overheat. An overheated tire can fail. Always
inflate your tires to the prescribed level.

TPMS with Tire Fill Assist provides visual and audible
assistance during tire pressure adjustment. With the
power mode in ON, while you adjust tire pressure up
or down, the system alerts you as follows:

Below recommended pressure:

The beeper

sounds and exterior lights flash once every five
seconds.

At recommended pressure:

The beeper sounds

and exterior lights flash rapidly for ~ five seconds.

Above recommended pressure:

The beeper

sounds and lights flash twice every two seconds.

571

uu

Indicator, Coming On/Blinking

u

If the Transmission Indicator Blinks along with the Warning Message

Han

d

lin
g the U

n

expected

If the Transmission Indicator Blinks along with the Warning Message

■

Reasons for the indicator to blink

The transmission is malfunctioning.

■

What to do when the indicator blinks

•

Immediately have your vehicle inspected by
a dealer.

•

Change the gear position to

(

N

 after

starting the engine.

u

Check if the

(

N

 position in the

instrument panel and the indicator on
the

(

N

 button light/blink.

u

The engine cannot be turned on unless
the parking brake is set.

2

Starting the Engine

 P. 394

1

If the Transmission Indicator Blinks along with the Warning Message

You may not be able to start the engine.

Make sure to set the parking brake when parking
your vehicle.

Call a professional towing service if you need to tow
your vehicle.

2

Emergency Towing

 P. 577

572

Han

d

lin
g the U

n

expected

Fuses

Fuse Locations

If any electrical devices are not working, set
the power mode to VEHICLE OFF (LOCK)
and check to see if any applicable fuse is
blown.

Fuse locations are shown on the fuse box
cover. Locate the fuse in question by the
fuse number and box cover number.
Located near the passenger's side damper
house. Push the tabs to open the box.

■

Engine Compartment Fuse Box Type A

Tab

■

Circuit protected and fuse rating

Circuit Protected

Amps

1

−

(70 A)

REAR BLOWER

30 A

ABS/VSA MTR

40 A

ABS/VSA FSR

20 A

MAIN FAN

30 A

MAIN FUSE

150 A

2

SUB FAN

30 A

WIP MTR

30 A

WASHER

20 A

PREMIUM AMP

*

(20 A)

ENGINE MOUNT

30 A

FRONT BLOWER

40 A

A/C INVERTER

*

(30 A)

STANDARD AMP

*

(30 A)

REAR DEF

40 A

−

(30 A)

PREMIUM AMP

*

(20 A)

3

−

−

−

−

−

−

−

−

4

PARKING LIGHT

10 A

5

CRUISE CANCEL SW

7.5 A

6

STOP LIGHT

10 A

7

FI SUB VSS

10 A

8

L H/L LO

10 A

9

−

−

10

R H/L LO

10 A

11

IGPS

7.5 A

12

INJECTOR

20 A

13

H/L LO MAIN

20 A

14

VBUM

10 A

15

FRONT FOG

*

(10 A)

16

HAZARD

15 A

17

PASSENGER P/

SEAT(RECLINE)

*

(20 A)

18 PASSENGER P/SEAT(SLIDE)

*

(20 A)

19

−

−

20

MG CLUTCH

7.5 A

21

MAIN RLY

15 A

22

FI SUB

15 A

23

IG COIL

15 A

24

DBW

15 A

25

SMALL/STOP MAIN

20 A

26

BACK UP

10 A

27

HTD STRG WHEEL

*

(15 A)

28

HORN

10 A

29

RADIO/USB

15 A

Circuit Protected

Amps

* Not available on all models
