Honda HR-V eHEV (2022 year). Manual in english - page 33

529

uu

Maintenance Under the Bonnet

u

Refilling Window Washer Fluid

Main

tenan

ce

Refilling Window Washer Fluid

Check the amount of window washer fluid
using the washer fluid level gauge on the cap.

If the level is low, fill the washer reservoir.

Pour the washer fluid carefully. Do not overflow the reservoir.

Fuel Filter

Replace fuel filter according to the time and distance recommendations in the
maintenance schedule.

Have a qualified technician change the fuel filter. Fuel in the system can spray out
and create a hazard if all fuel line connections are not handled correctly.

1

Refilling Window Washer Fluid

NOTICE

Do not use engine antifreeze or a vinegar/water
solution in the windscreen washer reservoir.
Antifreeze can damage your vehicle’s paint. A
vinegar/water solution can damage the windscreen
washer pump.
Use only commercially available windscreen washer
fluid.
Avoid prolonged use of hard water to prevent lime
scale buildup.

a

Cap

b

Level Gauge

1

Fuel Filter

The fuel filter should be replaced according to the
service reminder indication.

Models with service reminder system

530

Main

tenan

ce

Replacing Light Bulbs

Headlights

Headlights are LED type. Have an authorised Honda dealer inspect and replace the
light assembly.

Front Fog Lights

*

Front fog lights are LED type. Have an authorised Honda dealer inspect and replace
the light assembly.

Position/Daytime Running Lights

Position/daytime running lights are LED type. Have an authorised Honda dealer
inspect and replace the light assembly.

Front Turn Signal Lights

Front turn signal lights are LED type. Have an authorised Honda dealer inspect and
replace the light assembly.

Active Cornering Lights

*

Active cornering lights are LED type. Have an authorised Honda dealer inspect and
replace the light assembly.

Side Turn Signal/Emergency Indicator Lights

Door mirror side turn lights are LED type. Have an authorised Honda dealer inspect
and replace the light assembly.

1

Headlights

The headlight aim is set by the factory, and does not
need to be adjusted. However, if you regularly carry
heavy items in the luggage area, have the aiming
readjusted at a dealer or by a qualified technician.

* Not available on all models

531

uu

Replacing Light Bulbs

u

Brake/Taillights and Rear Turn Signal Light Bulbs

Continued

Main

tenan

ce

Brake/Taillights and Rear Turn Signal Light Bulbs

When replacing, use the following bulbs.

1.

Insert the flat-tip screwdriver between the
upper end of the cover and the vehicle
body, then remove the pin.

u

Wrap the flat-tip screwdriver with a cloth
to prevent scratching the vehicle body.

2.

Insert the flat-tip screwdriver between the
lower end of the cover and the light
assembly, then remove the pin.

u

Wrap the flat-tip screwdriver with a cloth
to prevent scratching the light assembly.

3.

Remove the cover by pulling it in the
direction of the arrow in the image.

Brake Light: LED
Taillight: LED
Rear Turn Signal Light: 21 W (Amber)

1

Brake/Taillights and Rear Turn Signal Light Bulbs

Brake/taillights are LED type. Have an authorised
Honda dealer inspect and replace the light assembly.

a

Pins

532

uu

Replacing Light Bulbs

u

Brake/Taillights and Rear Turn Signal Light Bulbs

Main

tenan

ce

4.

Remove the bolts.

5.

Remove the light assembly by pulling it in
the direction of the arrow in the image.

6.

Turn the socket anticlockwise and remove
it. Remove the old bulb.

7.

Insert a new bulb.

a

Bolts

a

Socket

b

Bulb

533

uu

Replacing Light Bulbs

u

Taillights, Rear Fog Light, and Back-Up Light Bulbs

Main

tenan

ce

Taillights, Rear Fog Light, and Back-Up Light Bulbs

When replacing, use the following bulbs.

1.

Remove the cover by prying on the edge
using a flat-tip screwdriver.

u

Wrap the flat-tip screwdriver with a cloth
to prevent scratches.

2.

Turn the socket anticlockwise and remove
it. Remove the old bulb.

3.

Insert a new bulb.

Taillight: LED
Rear Fog Light: LED
Back-Up Light: 16 W

1

Taillights, Rear Fog Light, and Back-Up Light Bulbs

Taillights and rear fog light are LED type. Have an
authorised Honda dealer inspect and replace the light
assembly.

a

Cover

a

Socket

b

Bulb

534

uu

Replacing Light Bulbs

u

Rear Licence Plate Light

Main

tenan

ce

Rear Licence Plate Light

Rear licence plate light is LED type. Have an authorised Honda dealer inspect and
replace the light assembly.

High-Mount Brake Light

High-mount brake light is LED type. Have an authorised Honda dealer inspect and
replace the light assembly.

535

uu

Replacing Light Bulbs

u

Other Light Bulbs

Main

tenan

ce

Other Light Bulbs

Have an authorised Honda dealer inspect and replace the light bulbs.

■

Vanity Mirror Light Bulbs

536

Main

tenan

ce

Checking and Maintaining Wiper Blades

Checking Wiper Blades

If the wiper blade rubber has deteriorated, it will leave streaks, become noisy, and
the hard surfaces of the blade may scratch the window glass.

Changing the Front Wiper Blade Rubber

1.

Lift the driver side wiper arm first, then the
passenger side.

2.

Press up on and hold the tab, then slide
the holder off the wiper arm.

1

Changing the Front Wiper Blade Rubber

NOTICE

Avoid dropping the wiper arm onto the windscreen,
it may damage the wiper arm and/or the windscreen.

a

Tab

b

Holder

537

uu

Checking and Maintaining Wiper Blades

u

Changing the Front Wiper Blade Rubber

Continued

Main

tenan

ce

3.

Pull the end of the wiper blade in the
direction of the arrow in the image until it
is out of the holder’s end cap.

4.

Pull the wiper blade in the opposite
direction to slide it out of the holder.

a

Wiper Blade

b

End Cap at the bottom

a

Wiper Blade

b

Holder

538

uu

Checking and Maintaining Wiper Blades

u

Changing the Front Wiper Blade Rubber

Main

tenan

ce

5.

Insert the flat side of the new wiper blade
onto the bottom part of the holder. Insert
the blade all the way.

6.

Install the end of the wiper blade into the
cap.

7.

Slide the holder onto the wiper arm until it
locks.

8.

Lower the passenger side wiper arm first,
then the driver side.

a

Wiper Blade

b

Cap

c

Holder

539

uu

Checking and Maintaining Wiper Blades

u

Changing the Rear Wiper Blade Rubber

Continued

Main

tenan

ce

Changing the Rear Wiper Blade Rubber

1.

Raise the wiper arm off.

2.

Pivot the bottom end of the wiper blade up
until it comes off from the wiper arm.

3.

Slide the blade out of the wiper.

1

Changing the Rear Wiper Blade Rubber

NOTICE

Avoid dropping the wiper arm; it may damage the
rear window.

a

Wiper Arm

a

Wiper Blade

540

uu

Checking and Maintaining Wiper Blades

u

Changing the Rear Wiper Blade Rubber

Main

tenan

ce

4.

Remove the retainers from wiper blade and
mount to a new rubber blade.

5.

Slide the new wiper blade onto the holder.

u

Make sure it is engaged correctly, then
install the wiper blade assembly onto the
wiper arm.

a

Retainer

a

Holder

541

Main

tenan

ce

Checking and Maintaining Tyres

Checking Tyres

To safely operate your vehicle, your tyres must be of the proper type and size, in
good condition with adequate tread, and properly inflated.

■

Inflation guidelines

Properly inflated tyres provide the best combination of handling, tread life, and
comfort. Refer to the driver’s doorjamb label for the specified pressure.

Underinflated tyres wear unevenly, adversely affect handling and fuel economy, and
are more likely to fail from overheating.

Overinflated tyres make your vehicle ride harshly, are more prone to road hazards,
and wear unevenly.

Every day before you drive, look at each of the tyres. If one looks lower than the
others, check the pressure with a tyre gauge.

At least once a month or before long trips, use a gauge to measure the pressure in
all tyres. Even tyres in good condition can lose 10–20 kPa (0.1–0.2 bar, 1–2 psi) per
month.

■

Inspection guidelines

Every time you check inflation, also examine the tyres and valve stems.
Look for:

•

Bumps or bulges on the side or in the tread. Replace the tyre if you find any cuts,
splits, or cracks in the side of the tyre. Replace it if you see fabric or cord.

•

Remove any foreign objects and inspect for air leaks.

•

Uneven tread wear. Have a dealer check the wheel alignment.

•

Excessive tread wear.

2

Wear Indicators

 P. 542

•

Cracks or other damage around valve stem.

1

Checking Tyres

Measure the air pressure when tyres are cold. This
means the vehicle has been parked for at least three
hours, or driven less than 1.6 km (1 mile). If
necessary, add or release air until the specified
pressure is reached.

If checked when hot, tyre pressure can be as much as
30–40 kPa (0.3–0.4 bar, 4–6 psi) higher than if
checked when cold.

Whenever tyre pressure is adjusted, you must
calibrate the deflation warning system.

2

Deflation Warning System

 P. 392

3

WARNING

Using tyres that are excessively worn or
improperly inflated can cause a crash in
which you can be seriously hurt or killed.

Follow all instructions in this owner’s
manual regarding tyre inflation and
maintenance.

542

uu

Checking and Maintaining Tyres

u

Wear Indicators

Main

tenan

ce

Wear Indicators

The groove where the wear indicator is
located is about 1.6 mm (about 1/16 inch)
shallower than elsewhere on the tyre. If the
tread has worn so that the indicator is
exposed, replace the tyre.

Worn out tyres have poor traction on wet
roads.

Tyre Service Life

The life of your tyres is dependent on many factors, including driving habits, road
conditions, vehicle loading, inflation pressure, maintenance history, speed, and
environmental conditions (even when the tyres are not in use).

In addition to regular inspections and inflation pressure maintenance, it is
recommended that you have annual inspections performed once the tyres reach five
years old. All tyres should be removed from service after 10 years from the date of
manufacture, regardless of their condition or state of wear.

1

Checking Tyres

Have a dealer check the tyres if you feel a consistent
vibration while driving. New tyres and any that have
been removed and reinstalled should be properly
balanced.

a

Example of a Wear Indicator
mark

543

uu

Checking and Maintaining Tyres

u

Tyre and Wheel Replacement

Main

tenan

ce

Tyre and Wheel Replacement

Replace your tyres with radials of the same size, load range, speed rating, and
maximum cold tyre pressure rating (as shown on the tyre’s sidewall). Using tyres of
a different size or construction can cause certain vehicle systems such as the ABS
and Vehicle Stability Assist (VSA) system to work incorrectly.

It is best to replace all four tyres at the same time. If that isn’t possible, replace the
front or rear tyres in pairs.

Make sure that the wheel’s specifications match those of the original wheels.

1

Tyre and Wheel Replacement

3

WARNING

Installing improper tyres on your vehicle
can affect handling and stability. This can
cause a crash in which you can be seriously
hurt or killed.

Always use the size and type of tyres
recommended in the tyre information label
on your vehicle.

544

uu

Checking and Maintaining Tyres

u

Tyre Rotation

Main

tenan

ce

Tyre Rotation

Rotating tyres according to the maintenance schedule helps to distribute wear more
evenly and increase tyre life.

■

Tyres without rotation marks

Rotate the tyres as shown here.

■

Tyres with rotation marks

Rotate the tyres as shown here.

1

Tyre Rotation

Tyres with directional tread patterns should only be
rotated front to back (not from one side to the other).
Directional tyres should be mounted with the
rotation indication mark facing forward, as shown
below.

When the tyres are rotated, make sure the air
pressures are checked.

Whenever tyres are rotated, you must calibrate the
deflation warning system.

2

Deflation Warning System

 P. 392

a

Front

b

Rotation Mark

a

Front

a

Front
