Honda CR-V Hybrid (2022 year). Manual in english - page 14

220

uu

Interior Convenience Items

u

Storage Items

Co
ntrols

Storage Items

Pull the handle to open the glove box. You
can lock the glove box with the built-in key.

■

Glove Box

1

Glove Box

3

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

Handle

To lock

Glove Box

221

uu

Interior Convenience Items

u

Storage Items

Continued

Co
ntrols

You can change the position of the tray by
sliding it forward or back.

If you want to make greater use of the console
box:

1.

Pull the knob to open the armrest.

2.

Slide the tray back.

3.

Hold the front of the tray and pull it up.

■

Center Console Box

Tray

Knob

uu

Interior Convenience Items

u

Storage Items

222

Co
ntrols

■

Front seat beverage holders

Are located in the console between the front
seats.

■

Rear seat beverage holders

Fold the armrest down to use the rear seat
beverage holders.

■

Beverage Holders

1

Beverage Holders

NOTICE

Spilled liquids can damage the upholstery, carpeting,
and electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

223

uu

Interior Convenience Items

u

Storage Items

Continued

Co
ntrols

■

Door side beverage holders

Located in the side pockets of all doors.

Front

Rear

uu

Interior Convenience Items

u

Storage Items

224

Co
ntrols

There is a coat hook on the rear left grab
handle. Pull it down to use it.

The tie-down anchors on the cargo area floor
can be used to install a net for securing items.

■

Coat Hook

1

Coat Hook

The coat hook is not designed for large or heavy
items.

■

Tie-down Anchors

1

Tie-down Anchors

Do not let anyone access items in the cargo area
while driving. Loose items can cause injury if you have
to brake hard.

Anchors

Anchors

Continued

225

uu

Interior Convenience Items

u

Storage Items

Co
ntrols

The cargo hook on the driver’s side of the
cargo area can be used to hang light items.

■

Cargo Hook

1

Cargo Hook

NOTICE

Do not hang a large object or an object that weighs
more than 6 lbs (3 kg) on the cargo hook. Hanging
heavy or large objects may damage the hook.

Hook

uu

Interior Convenience Items

u

Storage Items

226

Co
ntrols

To open the sunglasses holder, press and
release the indent. To close, press it again until
it latches.

You can store eyeglasses and other small
items in this holder.

■

Conversation mirror

The sunglasses holder comes with a mirror.
Open the sunglasses holder fully, then push it
back to the first detent.

You can use the mirror to view the rear seats.

■

Sunglasses Holder

1

Sunglasses Holder

Keep the holder closed while driving except when
accessing stored items.

Press

Continued

227

uu

Interior Convenience Items

u

Storage Items

Co
ntrols

The rear cargo cover can be used to conceal
items in the cargo area and protect them from
direct sunlight.

■

To extend:

Lift up on the handle at the center edge of the
cover to unhook each end, then pull the cover
rearward and clip the mounting rods in the
hooks at both sides of the tailgate opening.

■

Rear Cargo Cover

1

Rear Cargo Cover

Do not let anyone access items in the cargo area
while driving. Loose items can cause injury if you have
to brake hard.

Do not stack objects higher than the top of the seat
in the cargo area. They could block your view and be
thrown about the vehicle during a sudden stop.

To prevent rear cargo cover damage:

•

Do not place items on the rear cargo cover.

•

Do not put weight on the rear cargo cover.

Be sure that each mounting rod sets in its respective
retention groove when you retract the rear cargo
cover. If they are not set in the grooves, the rods may
rattle as they contact the surrounding surfaces.

Handle

Mounting Rod

Hook

228

uu

Interior Convenience Items

u

Storage Items

Co
ntrols

■

To retract:

Slip the rods out of the hooks, then slowly roll
it back until it is completely retracted.

■

To remove:

Push either end of the housing inward, then
lift it out of its position.

Mounting Rod

Hook

229

uu

Interior Convenience Items

u

Other Interior Convenience Items

Continued

Co
ntrols

Other Interior Convenience Items

The accessory power socket can be used when the power mode is in ACCESSORY or
ON.

■

Accessory power socket in the center
console box

Slide the tray back and open the cover to use
it.

■

Accessory Power Socket

1

Accessory Power Socket

NOTICE

Do not insert an automotive type cigarette lighter
element.
This can overheat the accessory power socket.

The accessory power socket is designed to supply
power for 12-volt DC accessories that are rated 180
watts (15 amps) or less.

To prevent 12-volt battery drain, only use the
accessory power socket with the power system on.

When the accessory power socket is not in use, close
the cover to prevent any small foreign objects from
getting into the accessory power socket.

uu

Interior Convenience Items

u

Other Interior Convenience Items

230

Co
ntrols

To use the wireless charger, the power mode must be in ACCESSORY or ON.
Charge a compatible device on the area indicated by the

 mark as follows:

1.

To turn the system on and off, press and
hold the

 (power) button.

u

When the system is activated, the green
indicator light comes on.

2.

Place the device you want to charge on the
charging area.

u

The system will automatically start
charging the device, and the amber
indicator light will come on.

u

Make sure that the device is compatible
with the system, and placed with the
chargeable side in the center of the
charging area.

3.

When charging is completed, the green
indicator light will come on.

u

Depending on the device, the amber
indicator light will stay on.

■

Wireless Charger

*

1

Wireless Charger

*

This system consumes a lot of power. Do not use the
system for a long time when the power system is off.
This may weaken the 12-volt battery, making it
difficult to turn the power system on.

When using the wireless charger, check the user’s manual that
came with the compatible device you want to charge.

3

CAUTION

Metal objects between the charge pad
and the device to be charged will get
hot and can burn you.

•

Always remove foreign objects from
the charge pad before charging the
device.

•

Be sure the surface is clear of dust and
other debris before charging.

•

Do not spill liquids (i. e. water, drinks,
etc.) on the charger and the device.

•

Do not use oil, grease, alcohol,
benzine or thinner for cleaning the
charge pad.

•

Do not cover the system with towels,
clothing, or other objects while
charging etc.

•

Avoid spraying aerosols which may
come in contact with the charge pad
surface.

Green Indicator
Amber Indicator

Charging Area

 (Power) Button

* Not available on all models

Continued

231

uu

Interior Convenience Items

u

Other Interior Convenience Items

Co
ntrols

■

When charging does not start

Perform one of the solutions in the following table.

Indicator

Cause

Solution

Green

&

Amber

Blinking
simulta-

neously

There is an obstacle(s) between
the charging area and the
device.

Remove the
obstacle(s).

The device is not within the
charging area.

Pick up and reset the
device to the center of
the charging area
where

is

located.

Amber

Blinking

The wireless charger is faulty.

Contact a dealer for
repairs.

1

Wireless Charger

*

NOTICE

Do not place any magnetic recording media or
precision machines within the charging area while
charging.
The data on your cards such as credit cards can be
lost because of the magnetic effect. Also, precision
machines such as watches may malfunction.

“Qi” and

 marks are the registered trademarks

owned by Wireless Power Consortium (WPC).

In the following cases, charging may stop or not start:

•

The device is already fully charged.

•

The temperature of the device is extremely high
while charging.

•

You are at a place that emits strong
electromagnetic waves or noises such as TV station,
electric power plant, or gas station.

A device may not charge if the size or shape of its
chargeable side is not appropriate for use with the
charging area.

Not all devices are compatible with the system.

During the charging phase, it is normal for the
charging area and device to heat up.

Charging may be briefly interrupted when:

•

All the doors or the tailgate are closed

- to avoid interference with the proper functioning
of the keyless access system.

•

The position of the device is altered.

Do not charge more than one device at a time on a
charging area.

* Not available on all models

uu

Interior Convenience Items

u

Other Interior Convenience Items

232

Co
ntrols

■

FCC statement

RF Exposure Notice:
This wireless charger complies with FCC RF exposure guidelines at the distance of
3.94 inches (10 cm).
Keep a distance of at least 3.94 inches (10 cm) between all occupants and the
wireless charger when charging.
Don’t remove the wireless charger yourself; contact a dealer for assistance.

1

Wireless Charger

*

 appears on the audio/information screen when

the device is being charged by the wireless charger.

FCC statement

This product complies with the appropriate
requirements or the required standards of FCC
(Federal Communication Commission), described
below:
This device complies with Part 18 of the FCC rules.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used
per the instructions, may cause harmful interference
to radio communications.

In order to use safely:

•

Remove any metal objects from the charge pad
before charging a device.

•

Do not open the charger case.

•

Do not use the charger if it malfunctions. Contact a
dealer.

If the charger interferes with radio communications,
attempt to correct the interference:

•

Press and hold the switch on the charger for a few
seconds to turn off the charger.

Wireless

Charger

3.94 inches

(10 cm)

All Around

3.94 inches

(10 cm)

All Around

 3.94 inches (10 cm)

All Around

3.94 inches

(10 cm)

Wireless

Charger

Wireless Charger

* Not available on all models

Continued

233

uu

Interior Convenience Items

u

Other Interior Convenience Items

Co
ntrols

The heated steering wheel can be used when
the power mode is in ON.

Press the button on the right side of the
steering wheel.

When a comfortable temperature is reached,
press the button again to turn it off.

The heated steering wheel is turned off every
time you start the power system, even if you
turned it on the last time you drove the
vehicle.

■

Heated Steering Wheel

*

1

Heated Steering Wheel

*

Do not use the heated steering wheel continuously
when the power system is off. Under such conditions,
the 12-volt battery may be weakened, making the
power system difficult to start.

* Not available on all models

uu

Interior Convenience Items

u

Other Interior Convenience Items

234

Co
ntrols

The seat heaters can be used when the power
mode is in ON.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

When the power mode is turned on after it is
turned off, the previous setting is maintained.

■

Seat Heaters

*

1

Seat Heaters

*

Do not use the seat heaters even in LO when the
power system is off. Under such conditions, the 12-
volt battery may be weakened, making the power
system difficult to start.

After a certain period of time, the strength setting for
the seat heater will automatically be reduced by one
level at a time until the seat heater shuts off. The
elapsed time varies according to the interior
environment.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lowerlimb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

235

Continued

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Temperature Control Dial

Fan Control Dial

 (Windshield Defroster) Button

 (Fresh Air) Button

 (ON/OFF) Button

 (Recirculation) Button

AUTO

 Button

Air flows from

dashboard

vents, and

back of the

center

console.

Air flows from

floor and

dashboard

vents, and

back of the

center

console.

Air flows from

floor vents.

Air flows from

floor and

windshield

defroster

vents.

Models without SYNC button

A/C

 (Air Conditioning) Button
