92

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Parking Brake
and Brake
System Indicator
(Amber)

●

Comes on if there is a problem
with a system related to braking
other than the conventional brake
system.

●

Comes on if there is a problem
with the cooperative control with
regenerative braking, the electric
servo brake system, or the hill start
assist system.

●

Comes on while driving

- Avoid high

speeds and sudden braking. Take the
vehicle to a dealer immediately.

●

Comes on if there is a problem
with the electric parking brake
system or the automatic brake
hold system.

●

Stays on constantly

- Avoid using the

parking brake and have your vehicle
checked by a dealer immediately.

●

Comes on if the brake system is
deactivated temporarily after the
12-volt battery has been
disconnected, then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

●

Comes on if there is a problem
with the radar sensor.

●

Indicator may come on
temporarily when the Maximum
Load Limit is exceeded.

●

Make sure the total load is within the
Maximum Load Limit.

2

Maximum Load Limit

 P. 463

●

Stays on constantly

 - Have your vehicle

checked by a dealer.

—

(Amber)

93

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Automatic Brake
Hold System
Indicator

●

Comes on when the automatic
brake hold system is on.

2

Automatic Brake Hold

 P. 555

Automatic Brake
Hold Indicator

●

Comes on when the automatic
brake hold is activated.

2

Automatic Brake Hold

 P. 555

—

Low Oil Pressure
Indicator

●

Comes on when the engine oil
pressure is low.

●

Comes on while driving

 - Immediately

stop in a safe place.

2

If the Low Oil Pressure Indicator
Comes On

 P. 652

Power System
Indicator

●

Comes on if there is a problem
with the electric vehicle system.

●

Comes on when the High Voltage
battery temperature becomes
high.

●

Stays on constantly

 - Have your vehicle

checked by a dealer immediately.

READY



Indicator

●

Comes on when the vehicle is
ready to drive.

2

Turning on the Power

 P. 469

94

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

EV

 Indicator

●

Comes on when the vehicle is
moved by the motor, and the
engine is not operating.

—

—

EV

 Mode

Indicator

●

Comes on when the vehicle is in
EV mode.

2

SPORT HYBRID i-MMD (intelligent
Multi-Mode Drive)

 P. 11

Malfunction
Indicator Lamp

●

After you have set the power
mode to ON, the vehicle performs
system checks.
However, if the readiness codes
have not been set by that time,
this indicator will blink five times
and then go off.

●

Comes on if there is a problem
with the emissions control systems
or electric vehicle system.

●

Blinks when a misfire in the
engine's cylinders is detected.

●

Readiness codes are part of the on board
diagnostics for the emissions control
systems.

2

Testing of Readiness Codes

 P. 673

●

Comes on while driving

 - Have your

vehicle checked by a dealer.

●

Comes on when there is no gasoline in the
fuel tank, and goes off after vehicle is
refueled, power mode is turned on,
vehicle is driven, and the power system is
turned off multiple times. If it does not go
off, have your vehicle checked by a dealer.

●

Blinks while driving

 - Stop in a safe

place where there are no flammable
objects. Stop the power system for 10
minutes or more, and wait for it to cool
down. Then, take your vehicle to a dealer.

2

If the Malfunction Indicator Lamp
Comes On or Blinks

 P. 653

95

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

12-volt Battery
Charging
System Indicator

●

Comes on when there is a
problem with the charging
system.

●

Stop in a safe place and have your vehicle
checked by a dealer immediately.

2

If the 12-volt Battery Charging
System Indicator Comes On

 P. 652

Shift Position
Indicator

●

Indicates the current shift
position.

2

Shifting

 P. 477

—

Transmission
System Indicator

●

The indicated current shift
position blinks if there is a
problem with the transmission
system.

●

Avoid sudden start and acceleration, and
stop in a safe place immediately.
Have your vehicle checked by a dealer.

●

The indicated current shift
position or all the shift positions
blink if you cannot select

(

P

 due

to the transmission system failure.

●

Set the parking brake when parking.

●

Have your vehicle checked by a dealer
immediately.

Deceleration
Paddle Selector
Indicator

●

Comes on when the paddle
selector is pulled.

●

Blinks when the deceleration does
not occur while pulling the paddle
selector.

●

Comes on with

M

 when

SPORT



mode is selected and pulling the
paddle selector.

2

Deceleration Paddle Selector

 P. 484

—

96

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

SPORT

 Mode

Indicator

●

Comes on when you press the

SPORT

 button.

●

The ambient meter remains lit up in red as
long as sport mode is on.

2

SPORT Mode

 P. 483

Seat Belt
Reminder
Indicator

●

Blinks and the beeper sounds for a
few seconds if you are not
wearing a seat belt when you set
the power mode to ON, then the
indicator comes on.

●

If the front passenger is not
wearing a seat belt, the indicator
comes on a few seconds later.

●

Blinks while driving if you and/or
the front passenger has not
fastened a seat belt. The beeper
sounds and the indicator blinks at
regular intervals.

●

The beeper stops and the indicator goes
off when you and the front passenger
fasten their seat belts.

●

Stays on after you and/or the front
passenger has fastened the seat belt(s)



- A detection error may have occurred in
the sensor. Have your vehicle checked by a
dealer.

2

Seat Belt Reminder

 P. 49

Low Fuel
Indicator

●

Comes on when the fuel reserve is
running low (approximately 2.1
U.S. gal/8.0 Liter left).

●

Blinks if there is a problem with
the fuel gauge.

●

Comes on

 - Refuel your vehicle as soon as

possible.

●

Blinks

 - Have your vehicle checked by a

dealer.

97

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Anti-lock Brake
System (

ABS

)

Indicator

●

Comes on if there is a problem
with the ABS.

●

Stays on constantly

 - Have your vehicle

checked by a dealer. With this indicator
on, your vehicle still has normal braking
ability but no anti-lock function.

2

Anti-lock Brake System (ABS)

 P. 557

Supplemental
Restraint System
Indicator

●

Comes on if a problem with any of
the following is detected:

-

Supplemental restraint system

-

Side airbag system

-

Side curtain airbag system

-

Seat belt tensioner

●

Stays on constantly

 - Have your vehicle

checked by a dealer.

Vehicle Stability
Assist

TM

 (VSA

®

)

System Indicator

●

Blinks when VSA

®

 is active.

●

Comes on if there is a problem with
the VSA

®

 system.

●

Stays on constantly

 - Have your vehicle

checked by a dealer.

2

Vehicle Stability Assist

TM

 (VSA

®

), aka

Electronic Stability Control (ESC),
System

 P. 489

●

Comes on if the VSA

®

 system is

deactivated temporarily after the
12-volt battery has been
disconnected, then re-connected.

●

Drive a short distance at more than 12 mph
(20 km/h). The indicator should go off. If it
does not, have your vehicle checked by a
dealer.

98

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Vehicle Stability
Assist

TM

 (VSA

®

)

OFF Indicator

●

Comes on when you partially
disable VSA

®

.

2

VSA

®

 On and Off

 P. 490

●

Comes on if the VSA

®

 system is

deactivated temporarily after the
12-volt battery has been
disconnected, then re-connected.

●

Drive a short distance at more than 12 mph
(20 km/h). The indicator should go off. If it
does not, have your vehicle checked by a
dealer.

Electric Power
Steering (EPS)
System Indicator

●

Comes on if there is a problem
with the EPS System.

●

Stays on constantly

 - Have your vehicle

checked by a dealer.

2

If the Electric Power Steering (EPS)
System Indicator Comes On

 P. 656

99

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Low Tire
Pressure/TPMS
Indicator

●

May come on briefly if the power
mode is set to ON and the vehicle
is not moved within 45 seconds,
to indicate the calibration process
is not yet complete.

●

Comes on and stays on when:

-

One or more tires’ pressures are
determined to be significantly
low.

-

The system has not been
calibrated.

●

Comes on while driving

 - Stop in a safe

place, check tire pressures, and inflate the
tire(s) if necessary.

●

Stays on after the tires are inflated to
the recommended pressures

 - The

system needs to be calibrated.

2

TPMS Calibration

 P. 494

●

Blinks for about one minute, and
then stays on if there is a problem
with the TPMS.

●

Blinks and remains on

 - Have your

vehicle checked by a dealer.

●

Comes on if the TPMS is
deactivated temporarily after the
12-volt battery has been
disconnected, then reconnected.

●

Drive a short distance at more than 12 mph
(20 km/h). The indicator should go off. If it
does not, have your vehicle checked by a
dealer.

100

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

System Message
Indicator

●

Comes on along with a beep
when a problem is detected. A
system message on the driver
information interface appears at
the same time.

●

While the indicator is on, press the



(display/information) button to see the
message again.

●

Refer to the Indicators information in this
chapter when a system message appears
on the driver information interface.
Respond to the message accordingly.

●

The driver information interface does not
return to the normal screen unless the
warning is canceled, or the

 button is

pressed.

—

Turn Signal and
Hazard Warning
Indicators

●

Blinks when you operate the turn
signal lever.

●

Blink along with all turn signals
when you press the hazard
warning button.

●

Does not blink or blinks rapidly

 - Have your vehicle checked by a dealer.

—

High Beam
Indicator

●

Comes on when the high beam
headlights are on.

—

—

101

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Lights On
Indicator

●

Comes on when the parking, tail,
and other external lights are on.

2

Light Switches

 P. 190

—

Fog Light
Indicator

*

●

Comes on when the fog lights are
on.

2

Fog Lights

*

 P. 194

—

Auto High-Beam
Indicator

●

Comes on when all the operating
conditions of the auto high-beam
are met.

2

Auto High-Beam

 P. 195

—

Immobilizer
System Indicator

●

Blinks if the immobilizer system
cannot recognize the key
information.

●

Blinks

 - You cannot start the power

system. Set the power mode to VEHICLE
OFF, then select the ON mode again.

●

Repeatedly blinks

 - The system may be

malfunctioning. Have your vehicle checked
by a dealer.

●

Do not attempt to alter this system or add
other devices to it. Electrical problems can
occur.

—

Indicator

* Not available on all models

102

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Security System
Alarm Indicator

●

Blinks when the security system
alarm has been set.

2

Security System Alarm

*

 P. 178

—

ECON Mode
Indicator

●

Comes on when the ECON mode
is on.

2

ECON Mode

 P. 487

Blind spot
information
System
Indicator

*

●

Stays on while the blind spot
information system is turned off.

2

Blind spot information System

*



P. 499

●

Comes on when mud, snow, or
ice accumulates in the vicinity of
sensor.

●

Comes on while driving

 - Remove the

obstacle in the vicinity of the sensor.

2

Blind spot information System

*



P. 499

●

Comes on if there is a problem
with the system.

●

Comes on while driving

 - Have your

vehicle checked by a dealer.

Indicator

* Not available on all models

103

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Road Departure
Mitigation
(RDM) Indicator

●

Comes on if there is a problem
with the RDM system.

●

Stays on constantly

 - Have your vehicle

checked by a dealer.

●

Comes on if the RDM is
deactivated temporarily after the
12-volt battery has been
disconnected, then re-connected.

●

Drive a short distance at more than 12 mph
(20 km/h). The indicator should go off. If it
does not, have your vehicle checked by a
dealer.

●

Comes on when the RDM system
shuts itself off.

●

Stays on

- The temperature inside the

camera is too high.
Use the climate control system to cool
down the camera.
The system activates when the
temperature inside the camera cools
down.

2

Front Sensor Camera

 P. 548

104

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Road Departure
Mitigation
(RDM) Indicator

●

Comes on when the RDM system
shuts itself off.

●

Stays on

- The area around the camera is

blocked by dirt, mud, etc. Stop your
vehicle in a safe place and wipe the debris
off with a soft cloth.

●

Have your vehicle checked by a dealer if
the indicator and message come back on
after you cleaned the area around the
camera.

2

Front Sensor Camera

 P. 548

●

Indicator may come on temporarily when
passing through an enclosed space, such
as a tunnel.

●

The area around the radar sensor is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place and wipe the debris
off with a soft cloth. Indicator may take
some time to go off after the radar sensor
is cleaned.

●

Have your vehicle checked by a dealer if
the indicator does not go off even after
you cleaned the radar sensor.

2

Radar Sensor

 P. 550

●

Indicator may come on
temporarily when the Maximum
Load Limit is exceeded.

●

Make sure the total load is within the
Maximum Load Limit.

2

Maximum Load Limit

 P. 463

●

Stays on constantly

 - Have your vehicle

checked by a dealer.

—

105

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Adaptive Cruise
Control (

ACC

)

with Low Speed
Follow Indicator
(Amber)

●

Comes on if there is a problem
with ACC with Low Speed Follow.

●

Comes on while driving

- Have your

vehicle checked by a dealer.

●

Comes on if the ACC with Low
Speed Follow is deactivated
temporarily after the 12-volt
battery has been disconnected,
then re-connected.

●

Drive a short distance at more than 12 mph
(20 km/h). The indicator should go off. If it
does not, have your vehicle checked by a
dealer.

●

Comes on if there is a problem
with ACC with Low Speed Follow.

●

Indicator may come on
temporarily when Maximum Load
Limit is exceeded.

●

ACC with Low Speed Follow has
been automatically canceled.

●

Make sure the total load is within the
Maximum Load Limit.

2

Maximum Load Limit

 P. 463

●

Stays on constantly

 - Have your vehicle

checked by a dealer.

—

106

uu

Indicators

u

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Adaptive Cruise
Control (

ACC

)

with Low Speed
Follow Indicator
(Green)

●

Comes on when you press the

MAIN

 button.

2

Adaptive Cruise Control (ACC) with
Low Speed Follow

 P. 517

—

Lane Keeping
Assist System
(

LKAS

) Indicator

(Amber)

●

Comes on if there is a problem
with the LKAS.

●

Stays on constantly

- Have your vehicle

checked by a dealer.

Lane Keeping
Assist System
(

LKAS

) Indicator

(Green)

●

Comes on when you press the

MAIN

 button.

2

Lane Keeping Assist System (LKAS)



P. 534

—

107

uu

Indicators

u

Continued

In

strum

ent Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Collision
Mitigation
Braking
System

TM



(CMBS

TM

)

Indicator

●

Comes on when you deactivate
the CMBS

TM

. A driver information

interface message appears for five
seconds.

●

Comes on if there is a problem
with the CMBS

TM

.

●

Stays on constantly without the
CMBS

TM

 off

- Have your vehicle checked

by a dealer.

2

Collision Mitigation Braking
System

TM

 (CMBS

TM

)

 P. 506

●

Comes on if the CMBS

TM

 is

deactivated temporarily after the
12-volt battery has been
disconnected, then re-connected.

●

Drive a short distance at more than 12 mph
(20 km/h). The indicator should go off. If it
does not, have your vehicle checked by a
dealer.

●

Comes on when the CMBS

TM



shuts itself off.

●

Stays on

- The area around the camera is

blocked by dirt, mud, etc. Stop your
vehicle in a safe place, and wipe it off with
a soft cloth.

2

Front Sensor Camera

 P. 548

●

Have your vehicle checked by a dealer if
the indicator does not go off even after
you cleaned the camera.
