Honda e (2021 year). Manual in english - page 41

642

uu

If a Tyre Goes Flat

u

Temporarily Repairing a Flat Tyre

Han

d

lin
g the U

n

expected

14.

Apply the wheel label to the flat surface of
the wheel.

u

The wheel surface must be clean to
ensure the label adheres properly.

15.

Store the tyre repair kit in the luggage
area.

u

Do not remove the sealant bottle from
the air compressor.

a

Wheel Label

Continued

643

uu

If a Tyre Goes Flat

u

Temporarily Repairing a Flat Tyre

Han

d

lin
g the U

n

expected

1.

Apply the speed restriction label to the
location as shown.

2.

Drive the vehicle for about 10 minutes or
three to ten kilometres (two to six miles).

u

Do not exceed 80 km/h (50 mph).

3.

Stop the vehicle in a safe place.

■

Distributing the Sealant in the Tyre

1

Distributing the Sealant in the Tyre

Refer to the driver’s doorjamb label for the specified
pressure.

a

Speed Restriction Label

644

uu

If a Tyre Goes Flat

u

Temporarily Repairing a Flat Tyre

Han

d

lin
g the U

n

expected

4.

Recheck the air pressure using the gauge
on the air compressor.

u

Do not turn the air compressor on to
check the pressure.

5.

If the air pressure is

•

Less than 130 kPa (1.3 bar, 19 psi): Do
not add air and continue driving. The
leak is too severe. Call for help and have
your vehicle towed.

2

Emergency Towing

 P. 671

•

Specified air pressure (See the label on
driver’s doorjamb.) or more: Continue
driving until you reach the nearest
service station. Do not exceed 80 km/h
(50 mph).

•

Greater than 130 kPa (1.3 bar, 19 psi):,
but less than specified air pressure (See
the label on driver’s doorjamb.): Inflate
the tyre to the specified air pressure.

2

Inflating an Under-inflated Tyre



P. 645

And repeat steps 2 to 4 until you reach the
nearest service station. Do not exceed 80
km/h (50 mph).

u

The distance to the nearest service
station has to be within about 200
kilometres (120 miles).

6.

Repackage and properly stow the kit.

a

Air Compressor

b

OFF

c

ON

645

uu

If a Tyre Goes Flat

u

Temporarily Repairing a Flat Tyre

Continued

Han

d

lin
g the U

n

expected

You can use the kit to inflate a non-punctured under-inflated tyre.

1.

Take the air compressor out of the
luggage area.

2.

Place the kit, face up, on flat ground near
the flat tyre, away from traffic. Do not
place the kit on its side.

3.

Remove the valve cap.

4.

Attach the hose onto the tyre valve. Screw
it until it is tight.

u

Make sure the air valve is closed.

5.

Plug in the compressor to the accessory
power socket.

u

Be careful not to pinch the cord in a
door or window.

2

Accessory Power Socket

 P. 243

6.

Turn on the vehicle's power system.

■

Inflating an Under-inflated Tyre

a

Air Valve

b

Hose

a

Plug

b

Accessory Power Socket

uu

If a Tyre Goes Flat

u

Temporarily Repairing a Flat Tyre

646

Han

d

lin
g the U

n

expected

7.

Turn the air compressor switch on to
inflate the tyre.

u

The compressor starts to inject air into
the tyre.

u

If you have started the power system,
leave it running while injecting air.

8.

Inflate the tyre to the specified air
pressure.

9.

Turn off the kit.

u

Check the pressure gauge on the air
compressor.

u

If overinflated, turn the air valve to
deflate.

10.

Turn on the vehicle's power system off,
then unplug the air compressor from the
accessory power socket.

11.

Unscrew the air compressor hose from the
tyre valve. Reinstall the valve cap.

12.

Store the air compressor in the luggage
area.

1

Inflating an Under-inflated Tyre

NOTICE

Do not operate the temporary tyre repair kit
compressor for more than 15 minutes. The
compressor can overheat and become permanently
damaged.

a

Air Valve

b

Switch

c

OFF

d

ON

647

Han

d

lin
g the U

n

expected

Handling of the Jack

Your vehicle has jacking points as shown.
When replacing your tyres, consult a dealer.

a

Jacking Points

648

Han

d

lin
g the U

n

expected

Power System Won’t Start

Checking the Procedure

When the

 (Ready) indicator does not come on and

 does not appear on

the driver information interface, check the following items and take appropriate
action.

Checklist

Condition

What to Do

Check if the related
indicator or driver
information interface
messages come on.

 appears

Removing a charge connector. Set the power
mode to ACCESSORY, then to ON.

 appears

Charge the High Voltage battery.

2

Charging

 P. 562

 appears.

2

Driver Information Interface Warning and
Information Messages

 P. 130

 appears.

u

Make sure the keyless remote is in its operating range.

2

If the Keyless Remote Battery is Weak



P. 649

The

 (Power System) indicator comes on.

Have your vehicle checked by a dealer.

The transmission system indicator blinks and

 appears.

The power system can be activated as a
temporary measure.

2

If the Transmission System Indicator Blinks
along with the Warning Message

 P. 660

Check the brightness
of the interior lights.

The interior lights are dim or do not come on at all.

Have the 12-volt battery checked by a dealer.

The interior lights come on normally.

Check all fuses, or have your vehicle checked by
a dealer.

2

Inspecting and Changing Fuses

 P. 669

Check the Security
System Alarm
indicator.

When the Security System Alarm indicator is blinking, the power
system cannot be turned on.

2

Security System Alarm

 P. 189

1

Checking the Procedure

If you must start the vehicle immediately, use an
assisting vehicle or booster battery to jump start it.

2

If the 12-Volt Battery Is Dead

 P. 651

Do not hold the

POWER

 button for more than 15

seconds.

649

uu

Power System Won’t Start

u

If the Keyless Remote Battery is Weak

Han

d

lin
g the U

n

expected

If the Keyless Remote Battery is Weak

If the beeper sounds,

 appears on the driver information interface, and the

POWER

 button flashes, the

 (Ready) indicator does not come on.

Turn on the power system as follows:

1.

Touch the centre of the

POWER

 button

with the

H

 logo on the keyless remote while

the

POWER

 button is flashing. The buttons

on the keyless remote should be facing you.

u

The

POWER

 button flashes for about 30

seconds.

2.

Depress the brake pedal and press the

POWER

 button within 10 seconds after the

beeper sounds and the

POWER

 button

changes from flashing to on.

u

The

 (Ready) indicator comes on.

u

If you do not depress the pedal, the
mode will change to ACCESSORY.

650

uu

Power System Won’t Start

u

Emergency Power System Off

Han

d

lin
g the U

n

expected

Emergency Power System Off

The

POWER

 button may be used to turn the power system off due to an emergency

situation even while driving. If you must turn the power system off, do either of the
following operations:

•

Press and hold the

POWER

 button for about two seconds.

•

Firmly press the

POWER

 button three times.

The gear position automatically changes to

(

P

 after the vehicle comes to a complete

stop. Then, the power mode changes to VEHICLE OFF.

1

Emergency Power System Off

Do not press the

POWER

 button while driving unless

it is absolutely necessary for the power system to be
turned off.
If you press the

POWER

 button while driving, the

beeper sounds.

651

Continued

Han

d

lin
g the U

n

expected

If the 12-Volt Battery Is Dead

Turn off the power to electric devices, such as audio and lights. Turn off the power
system, then open the bonnet.

1.

Open the terminal cover on your vehicle's
12-volt battery positive

+

 terminal.

2.

Connect the first jumper cable to your
vehicle's 12-volt battery

+

 terminal.

3.

Connect the other end of the first jumper
cable to the booster battery

+

 terminal.

u

Use a 12-volt booster battery only.

u

When using an automotive battery
charger to boost your 12-volt battery,
select a lower charging voltage than 15-
volt. Check the charger manual for the
proper setting.

4.

Connect the second jumper cable to the
booster battery

-

 terminal.

■

Jump Starting Procedure

1

If the 12-Volt Battery Is Dead

NOTICE

If a 12-volt battery sits in extreme cold, the electrolyte
inside can freeze. Attempting to jump start with a
frozen 12-volt battery can cause it to rupture.

Securely attach the jumper cables clips so that they
do not come off when the power system vibrates.
Also be careful not to tangle the jumper cables or
allow the cable ends to touch each other while
attaching or detaching the jumper cables.

3

WARNING

A 12-volt battery can explode if you do not
follow the correct procedure, seriously
injuring anyone nearby.

Keep all sparks, open flames, and smoking
materials away from the 12-volt battery.

a

Booster Battery

uu

If the 12-Volt Battery Is Dead

u

652

Han

d

lin
g the U

n

expected

5.

Connect the other end of the second
jumper cable to the nut of the 12-volt
battery sensor

-

 terminal as shown. Do not

connect this jumper cable to any other part.

6.

If your vehicle is connected to another
vehicle, start the assisting vehicle's engine
and increase its rpm slightly.

7.

Attempt to start your vehicle's power
system. If it isn’t turn on, check that the
jumper cables have good metal-to-metal
contact.

1

If the 12-Volt Battery Is Dead

12-volt battery performance degrades in cold
conditions and may prevent the power system from
starting.

Do not force the door to open or close.

There is a mechanism that lowers the window when
the door is opened. If the 12-volt battery has died
and the window cannot be lowered, it may scrape
against the vehicle body when the door is opened or
closed. If this happens, slowly open or close the door
while pressing down on the upper part of the
window.

653

uu

If the 12-Volt Battery Is Dead

u

Han

d

lin
g the U

n

expected

Once your vehicle's power system has started, remove the jumper cables in the
following order.

1.

Disconnect the jumper cable from your vehicle's nut of the 12-volt battery sensor

-

 terminal.

2.

Disconnect the other end of the jumper cable from the booster battery

-



terminal.

3.

Disconnect the jumper cable from your vehicle's 12-volt battery

+

 terminal.

4.

Disconnect the other end of the jumper cable from the booster battery

+



terminal.

Have your vehicle inspected by a nearby service station or a dealer.

■

What to Do After the Power System Starts

654

Han

d

lin
g the U

n

expected

Overheating

How to Handle Overheating

 appears on the driver information interface when the power system

temperature is high.

2

Driver Information Interface Warning and Information Messages

 P. 130

1.

Keep the power mode on, and wait until

 goes off.

u

If

 does not go off, have the vehicle inspected at a dealer.

655

Han

d

lin
g the U

n

expected

Indicator, Coming On/Blinking

If the 12-Volt Battery Charging System Indicator Comes On

■

Reasons for the indicator to come on

Comes on when the 12-volt battery is not being charged.

■

What to do when the indicator comes on

Stop in a safe place and have your vehicle checked by a dealer
immediately.

1

If the 12-Volt Battery Charging System Indicator Comes On

If you need to stop temporarily, do not turn off the
power system. Restarting the power system may
rapidly discharge the battery.

The power system uses the 12-volt battery to
activate.
You may not be able to turn the power system on
again if you have turned it off with this indicator on.

656

uu

Indicator, Coming On/Blinking

u

If the Brake System Indicator (Red) Comes On or Blinks

Han

d

lin
g the U

n

expected

If the Brake System Indicator (Red) Comes On or Blinks

■

Reasons for the indicator to come on

•

The brake fluid is low.

•

There is a malfunction in the brake system.

■

What to do when the indicator comes on while driving

Depress the brake pedal lightly to check pedal pressure.

•

If normal, check the brake fluid level the next time you stop.

•

If abnormal, have your vehicle repaired immediately.

■

Reasons for the indicator to blink

•

There is a problem with the electric parking brake system.

■

What to do when the indicator lamp blinks

•

Avoid using the parking brake and have your vehicle checked by a
dealer immediately.

1

If the Brake System Indicator (Red) Comes On or Blinks

Have your vehicle repaired immediately.
It is dangerous to drive with low brake fluid. If there
is no resistance from the brake pedal, stop
immediately in a safe place.

If the Brake System Indicator (Red) and

ABS

 indicator

come on simultaneously, the electronic brake
distribution system is not working. This can result in
vehicle instability under sudden braking.
Have your vehicle inspected by a dealer immediately.

If the Brake System Indicator (Red) blinks at the same
time when the brake system indicator (amber) comes
on, the parking brake may not work.
Avoid using the parking brake and have your vehicle
checked by a dealer immediately.

2

If the Brake System Indicator (Red) Comes
On or Blinks at the Same Time When the
Brake System Indicator (Amber) Comes On



P. 658

If you repeatedly operate the electric parking brake in
a short period of time, the brake stops operating to
prevent heating of the system and the indicator
blinks.
It returns to its original state in approximately 1
minute.

(Red)

657

uu

Indicator, Coming On/Blinking

u

If the Electric Power Steering (EPS) System Indicator Comes On

Han

d

lin
g the U

n

expected

If the Electric Power Steering (EPS) System Indicator Comes On

■

Reasons for the indicator to come on

•

Comes on when there is a problem with the EPS system.

•

If you depress the accelerator pedal repeatedly to increase the motor
speed while the motor is idling, the indicator comes on, and
sometimes the steering wheel becomes harder to operate.

■

What to do when the indicator comes on

Stop the vehicle in a safe place, turn off the power system, and turn on
the power system again.
If the indicator re-appears and stays on, immediately have your vehicle
inspected by a dealer.
