Honda e (2021 year). Manual in english - page 7

uu

Child Safety

u

Safety of Infants and Small Children

98

Safe Driving

A tether anchorage point is provided behind
each rear seating position. If you have a child
restraint system that comes with a tether but
can be installed with a seat belt, the tether
may be used for additional security.

1.

Locate the appropriate tether anchorage
point.

u

Retract the luggage area cover.

2

Luggage Area Cover

P. 242

■

Adding Security with a Tether

1

Adding Security with a Tether

WARNING:

Child restraint anchorages are designed

to withstand only those loads imposed by correctly
fitted child restraints. Under no circumstances are
they to be used for adult seat belts, harnesses or for
attaching other items or equipment to the vehicle.

Always use a tether for front-facing child restraint
system when using the seat belt or lower anchorages.

a

Tether Anchorage Points

99

uu

Child Safety

u

Safety of Infants and Small Children

Safe Driving

2.

Raise the head restraint to its highest
position, then route the tether strap
between the head restraint legs, and secure
the tether strap hook to the anchorage.

u

Make sure the strap is not twisted.

2.

Raise the head restraint to its highest
position, route the tether strap through the
outsides of the head restraint legs, and
secure the tether strap hook to the
anchorage.

u

Make sure the strap is not twisted.

3.

Secure the tether strap hook to the
anchorage.

4.

Tighten the tether strap as instructed by the
child restraint system manufacturer.

Straight Top Tether Type

a

Tether Strap Hook

b

Anchorage

Straight Top Tether Type

Other Top Tether Type

a

Tether Strap Hook

b

Anchorage

Other Top Tether Type

All Models

100

uu

Child Safety

u

Safety of Larger Children

Safe Driving

Safety of Larger Children

The following pages give instructions on how to check proper seat belt fit, what kind
of booster seat to use if one is needed, and important precautions for a child who
must sit in front.

When a child is too big for a child restraint system, secure the child in a rear seat
using the lap/shoulder seat belt. Have the child sit upright and all the way back, then
answer the following questions.

■

Checklist

•

Do the child's knees bend comfortably over
the edge of the seat?

•

Does the shoulder belt cross between the
child's neck and arm?

•

Is the lap part of the seat belt as low as
possible, touching the child's thighs?

•

Will the child be able to stay seated like this
for the whole trip?

If you answer yes to all these questions, the child is ready to wear the lap/shoulder
seat belt correctly. If you answer no to any question, the child needs to ride on a
booster seat until the seat belt fits properly without a booster seat.

■

Protecting Larger Children

■

Checking Seat Belt Fit

1

Safety of Larger Children

3

WARNING

Allowing a child aged 12 or under to sit in
front can result in injury or death if the
passenger's front airbag inflates.

If a larger child must ride in front, move the
vehicle seat as far to the rear as possible,
have the child sit up properly and wear the
seat belt properly, using a booster seat if
needed.

Continued

101

uu

Child Safety

u

Safety of Larger Children

Safe Driving

If a lap/shoulder seat belt cannot be used
properly, position the child in a booster seat in
the rear seat. For the child's safety, check that
the child meets the booster seat
manufacturer's recommendations.

A backrest is available for a specific booster
seat. Install the backrest to the booster seat
and adjust it to the vehicle seat according to
the booster seat manufacturer's instructions.
Make sure the seat belt is properly routed
through the guide at the shoulder of the
backrest and the belt does not touch and
cross the child’s neck.

■

Booster Seats

1

When installing a booster seat, make sure to read the
instructions that came with it, and install the seat
accordingly.
There are high- and low-type booster seats. Choose a
booster seat that allows the child to wear the seat
belt correctly.

We recommend a booster seat with a backrest as it is
easier to adjust the shoulder belt.

a

Guide

102

uu

Child Safety

u

Safety of Larger Children

Safe Driving

Your vehicle has a rear seat where children can be properly restrained. If you ever
have to carry a group of children, and a child must ride in front:

•

Make sure you read and fully understand the instructions and safety information
in this manual.

•

Move the front passenger seat as far back as possible.

•

Have the child sit upright and well back in the seat.

•

Check that the seat belt is properly positioned so that the child is secure in the
seat.

■

Monitoring child passengers

We strongly recommend that you keep an eye on child passengers. Even older, more
mature children sometimes need to be reminded to fasten their seat belts and sit up
properly.

■

Protecting Larger Children - Final Checks

103

Safe Driving

Safety Labels

Label Locations

These labels are in the locations shown. They warn you of potential hazards that can
cause serious injury or death. Read these labels carefully.

If a label comes off or becomes hard to read, contact a dealer for a replacement.

a

Protecting Child Passenger (Left-hand drive type)

2

P. 75

b

Protecting Child Passenger (Right-hand drive type)

2

P. 75

c

Rear Head Restraint

2

P. 233

d

Passenger Front Airbag Off System (Right-hand drive type)

2

P. 64

e

12-Volt Battery

2

P. 619

f

PCU Coolant Reserve Tank

2

P. 595

g

Air Conditioner

2

P. 621

h

Pop-up Hood

2

P. 73

i

IPU Coolant Reserve Tank

2

P. 595

j

Passenger Front Airbag Off System (Left-hand drive type)

2

P. 64

k

Charging Information Label

*

2

* Not available on all models

104

105

Instrument Panel

This chapter describes the buttons, indicators, and gauges that are used while driving.

.......................................... 106

Driver Information Interface Warning and

Information Messages.................... 130

Gauges and Displays

Gauges............................................ 154
Driver Information Interface ............. 156

106

In

strum

e

nt Pa

nel

Indicators

Low Charge Indicator

(Amber)



P.

Turn Signal and Hazard
Warning Indicators



P.

Passenger Front Airbag
On/Off Indicators

*1



P.

Parking Brake and Brake
System Indicator (Red)

Parking Brake and Brake
System Indicator (Amber)

Automatic Brake Hold
System Indicator

Automatic Brake Hold
Indicator

*1 : When you set the power mode to ON, these indicators come on to indicate that system checks are being performed. They go off a few seconds later or after the power

system has been turned on. If an indicator does not come on or turn off, there may be a malfunction in the corresponding system. To resolve the issue, follow the
instructions in the owner’s manual.



P.

*1

Transmission System
Indicator

12-Volt Battery Charging
System Indicator

Anti-lock Brake System
(

ABS

) Indicator

Seat Belt Reminder
Indicator

Supplemental Restraint
System Indicator

Low Tyre Pressure/
Deflation Warning System
Indicator



P.



P.



P.



P.



P.

*1

*1

*1

*1



P.

*1

Power System Indicator



P.

Ready Indicator



P.



P.



P.



P.

*1

*1

Shift Position Indicator



P.

*1

*1

System Message Indicator



P.

SPORT

Mode Indicator



P.

NORMAL

Mode Indicator



P.

Deceleration Paddle
Selector Indicator



P.

Electric Power Steering
(EPS) System Indicator

*1



P.

107

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Lights On Indicator



P.

*1 : When you set the power mode to ON, these indicators come on to indicate that system checks are being performed. They go off a few seconds later or after the power

system has been turned on. If an indicator does not come on or turn off, there may be a malfunction in the corresponding system. To resolve the issue, follow the
instructions in the owner’s manual.

Vehicle Stability Assist
(VSA) System Indicator

Adaptive Cruise Control
(

ACC

) with Low Speed

Follow Indicator (Amber)

Lane Keeping Assist
System (

LKAS

) Indicator

(Amber)



P.

Immobilizer System
Indicator



P.



P.



P.

Adaptive Cruise Control
(

ACC

) with Low Speed

Follow Indicator (White/
Green)



P.

Lane Keeping Assist
System (

LKAS

) Indicator

(Green)



P.

Vehicle Stability Assist
(VSA)

OFF

Indicator



P.

*1

*1

Rear Fog Light Indicator



P.

High Beam Indicator

Front Fog Light Indicator



P.



P.

Security System Alarm
Indicator



P.

*1

Auto High-Beam Indicator



P.

Road Departure
Mitigation Ready to Assist
Indicator



P.

Intelligent Speed Limiter
Indicator (White/Green)



P.

Adaptive Cruise Control
(

ACC

) with Low Speed

Follow Distance Indicator



P.

Safety Support Indicator
(Amber)



P.

Safety Support Indicator
(Green/Gray)



P.

*1

Parking Sensor Indicator
(Amber)



P.

*1

Single Pedal Indicator



P.

Adjustable Speed Limiter
Indicator (White/Green)



P.

Parking Sensor Indicator
(Green)



P.



P.

Side Camera Mirror
System Indicator

*1

108

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Parking Brake
and Brake
System Indicator
(Red)

•

Comes on when the parking brake
is applied and goes off when it is
released.

•

Comes on when the brake fluid
level is low.

•

Comes on if there is a problem
with the brake system.

•

The beeper sounds and the
indicator comes on if you drive
with the parking brake not fully
released.

•

Comes on while driving

- Make sure

the parking brake is released. Check
the brake fluid level.

2

What to do when the indicator
comes on while driving

P. 656

•

Comes on along with the parking
brake and brake system indicator
(amber)

- Immediately stop in a safe

place. Contact a dealer for repair. The
brake pedal becomes harder to
operate. Depress the pedal further
than you normally do.

2

If the Brake System Indicator
(Red) Comes On or Blinks at the
Same Time When the Brake
System Indicator (Amber) Comes
On

•

Comes on along with the ABS
indicator

- Have your vehicle checked

by a dealer.

2

If the Brake System Indicator
(Red) Comes On or Blinks

P. 656

(Red)

109

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Parking Brake
and Brake
System Indicator
(Red)

•

Comes on for about 30 seconds
when you apply the electric
parking brake while the power
mode is in ACCESSORY or VEHICLE
OFF, then goes off.

•

Stays on for about 30 seconds
when you set the power mode to
VEHICLE OFF while the electric
parking brake is applied, then goes
off.

•

Blinks and the parking brake and
brake system indicator (amber)
comes on at the same time

- There

is a problem with the electric parking
brake system. The parking brake may
not be set.
Avoid using the parking brake and
have your vehicle checked by a dealer
immediately.

2

If the Brake System Indicator
(Red) Comes On or Blinks at the
Same Time When the Brake
System Indicator (Amber) Comes
On

P. 658

—

Automatic Brake
Hold System
Indicator

•

Comes on when the automatic
brake hold system is on.

2

Automatic Brake Hold

P. 504

Automatic Brake
Hold Indicator

●

Comes on when the automatic
brake hold is activated.

2

Automatic Brake Hold

P. 504

—

(Red)

110

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Parking Brake
and Brake
System Indicator
(Amber)

•

Comes on if there is a problem
with a system related to braking
other than the conventional brake
system.

•

Comes on if there is a problem
with the cooperative control with
regenerative braking, the electric
servo brake system, the single
pedal control and the Honda
Parking Pilot

*

.

•

Comes on while driving

- Avoid high

speeds and sudden braking. Take the
vehicle to a dealer immediately.

(Amber)

* Not available on all models

111

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Parking Brake
and Brake
System Indicator
(Amber)

●

Comes on if there is a problem with
the electric parking brake system
and/or the automatic brake hold
system.

●

Stays on constantly

- Avoid using the

parking brake and have your vehicle
checked by a dealer immediately.

Power System
Indicator

•

Comes on if there is a problem
with the electric vehicle system or
plug-in charging system.

•

Have your vehicle checked by a dealer
immediately.

2

If the Power System Indicator
Comes On

P. 661

•

Comes on when you set the power
mode to ON after having charged your
vehicle - Have your vehicle checked by
a dealer immediately.

(Amber)

112

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Ready Indicator

•

Comes on when the vehicle is
ready to drive.

2

Turning on the Power

P. 381

12-Volt Battery
Charging
System Indicator

•

Comes on when the 12-volt
battery is not charging.

•

Stop in a safe place and have your
vehicle checked by a dealer
immediately.

2

If the 12-Volt Battery Charging
System Indicator Comes On

113

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Shift Position
Indicator

•

Indicates the current shift position.

2

P. 386

—

Transmission
System Indicator

•

The current shift position or all the
shift positions blink if there is a
problem with the transmission
system.

•

Avoid sudden start and acceleration,
and stop in a safe place immediately.

2

Emergency Towing

•

Have your vehicle checked by a dealer.

•

The indicated current shift position
or all the shift positions blink if you
cannot select

(

P

due to a

transmission system failure.

•

The power system can be activated as a
temporary measure.

2

If the Transmission System
Indicator Blinks along with the
Warning Message

•

Set the parking brake when parking.

•

Have your vehicle checked by a dealer
immediately.

Content .. 5 6 7 8 ..
