143

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Locking the doors and tailgate

Press the door lock button on a front door or
the tailgate.

u

Some exterior lights flash; the beeper
sounds; all the doors and tailgate lock;
and the security system sets.

1

Using the Smart Entry with Push Button Start System

•

Do not leave the smart entry remote in the vehicle
when you get out. Carry it with you.

•

Even if you are not carrying the smart entry remote,
you can lock/unlock the doors and tailgate while
someone else with the remote is within range.

•

The door may be unlocked if the door handle is
covered with water in heavy rain or in a car wash if
the smart entry remote is within range.

•

If you grip a door handle wearing gloves, the door
sensor may be slow to respond or may not respond
by unlocking the doors.

•

After locking the door, you have up to 2 seconds
during which you can pull the door handle to
confirm whether the door is locked. If you need to
unlock the door immediately after locking it, wait
at least 2 seconds before gripping the handle,
otherwise the door will not unlock.

•

The door might not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

•

Even within the 32 inches (80 cm) radius, you may
not be able to lock/unlock the doors with the smart
entry remote if it is above or below the outside
handle.

•

The smart entry remote may not operate if it is too
close to the door and door glass.

Door Lock Button

Door Lock
Button

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

144

Co
ntrols

■

Locking the doors and tailgate (Walk away auto lock®)

When you walk away from the vehicle while
carrying the smart entry remote, the doors will
automatically lock.
The auto lock function activates when all
doors and tailgate are closed, and the smart
entry remote is within about 5 feet (1.5 m)
radius of the outside door handle.
Exit vehicle while carrying smart entry remote
and close door(s).

1. While within about 5 feet (1.5 m) radius of

the vehicle.

u

The beeper sounds; the auto lock
function will be activated.

2. Carry the smart entry remote beyond about

5 feet (1.5 m) from the vehicle and remain
outside this range for 2 or more seconds.

u

Some exterior lights flash; the beeper
sounds; all doors and tailgate will then
lock.

1

Locking the doors and tailgate (Walk away auto lock®)

The auto lock function is set to OFF as the factory
default setting. The auto lock function can be set to
ON using the audio/information screen.
Turning ON auto lock function using the audio/
information screen, shall only activate the function in
remote transmitter that was used to unlock the
driver's door.

2 Customized Features P. 432

After the auto lock function has been activated, when
you stay within the locking/unlocking operation range,
the indicator on the smart entry remote will continue to
flash until the doors are locked.

When you stay beside the vehicle within the
operation range, the doors will automatically lock
approximately 30 seconds after the auto lock
function activating beeper sounds.

When you open a door after the auto lock function
activating beeper sounds, the auto lock function will
be delayed until all doors and tailgate are closed.

Under the following circumstances, the auto-lock
function will not activate:

•

The remote is inside the vehicle.

u

The buzzer will not sound.

•

The remote is taken out of its operational range
before all the doors are closed.

u

The buzzer will sound.

The activation range of
the auto lock function is
about 5 feet (1.5 m)

Continued

145

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Co
ntrols

To temporarily deactivate the function:
1. Set the power mode to OFF.
2. Open the driver's door.
3. Using the master door lock switch, operate

the lock as follows:
Lock  Unlock  Lock  Unlock.

u

The beeper sounds and the function is
deactivated.

To restore the function:
• Set the power mode to ON.
• Lock the vehicle without using the auto lock

function.

• With the smart entry remote on you, move

out of the auto lock function operation
range.

• Open any door.

1

Locking the doors and tailgate (Walk away auto lock®)

If equipped, the user must wait until the power
tailgate fully closes before the auto lock function will
be activated.

The auto lock function does not operate when any of
the following conditions are met.

•

The smart entry remote is inside the vehicle.

•

A door or the hood is not closed.

•

The power mode is set to any mode other than
OFF.

•

The smart entry remote is not located within a
radius of about 5 feet (1.5 m) from the vehicle
when you get out of the vehicle and close the
doors.

Auto lock function operation stop beeper
After the auto lock function has been activated, the
auto lock operation stop beeper sounds for
approximately two seconds in the following cases.

•

The smart entry remote is put inside the vehicle
through a window.

•

You are located too close to the vehicle.

•

The smart entry remote is put inside the tailgate.

If the warning beeper sounds, check that you are
carrying the smart entry remote. Then, open/close a
door and confirm the auto lock activation beeper
sounds once.

Models with power tailgate

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

146

Co
ntrols

■

Unlocking the doors and tailgate

Grab the driver’s door handle:

u

The driver’s door unlocks.

u

Some exterior lights flash twice and the
beeper sounds twice.

Grab the front passenger’s door handle:

u

All doors and the tailgate unlock.

u

Some exterior lights flash twice and the
beeper sounds twice.

Press the tailgate outer handle:

u

The tailgate unlocks and opens

*

.

u

Some exterior lights flash twice and the
beeper sounds twice.

2 Using the Tailgate Outer Handle P. 158

1

Using the Smart Entry with Push Button Start System

The light flash, beeper, and unlock settings can be
customized using the audio/information screen.

2 Customized Features P. 432

You can also unlock and open with the power
tailgate

*

.

2 Using the Tailgate Outer Handle P. 158

Outer
Handle

* Not available on all models

Continued

147

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Locking the doors and tailgate

Press the lock button.
Once:

u

Some exterior lights flash, all the doors
and tailgate lock, and the security system
sets.

Twice (within five seconds after the first
push):

u

The beeper sounds and verifies the
security system is set.

■

Unlocking the doors and tailgate

Press the unlock button.
Once:

u

Some exterior lights flash twice, and the
driver’s door unlocks.

Twice:

u

The remaining doors and tailgate unlock.

■

Using the Remote Transmitter

1

Using the Remote Transmitter

If you do not open a door within 30 seconds of
unlocking the vehicle with the remote transmitter,
the doors will automatically relock.
You can change the relock timer setting.

2 Vehicle Customization P. 125

2 Customized Features P. 432

You can lock or unlock doors using the remote
transmitter only when the power mode is in VEHICLE
OFF.

The remote transmitter uses low-power signals, so
the operating range may vary depending on the
surroundings.

The remote will not lock the vehicle when a door is
open.

If the distance at which the remote transmitter works
varies, the battery is probably low.
If the LED does not come on when you press a
button, the battery is dead.

2 Replacing the Button Battery P. 674

You can customize the door unlock mode setting.

2 Vehicle Customization P. 125

2 Customized Features P. 432

Models with color audio system

Models with Display Audio

Models with color audio system

Models with Display Audio

LED

Unlock
Button

Lock
Button

LED

Unlock
Button

Lock
Button

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

148

Co
ntrols

If the lock or unlock button of the smart entry remote does not work, use the key
instead.

Fully insert the key and turn it.

If you do not have the key on you, or if for some reason you cannot lock a door using
the key, you can lock the door without it.

■

Locking the front doors

Push the lock tab forward

a

 or push the

master door lock switch in the lock direction

b

, and close the door.

■

Locking the rear doors

Push the lock tab forward and close the door.

■

Lockout prevention system

The doors and tailgate cannot be locked when
the smart entry remote is inside the vehicle.

■

Locking/Unlocking the Doors Using a Key

1

Locking/Unlocking the Doors Using a Key

When you lock the driver’s door with a key, all the
other doors and tailgate lock at the same time. When
unlocking, the driver’s door unlocks first. Turn the
key a second time within a few seconds to unlock the
remaining doors and the tailgate.

You can customize the door unlock mode setting.

2 Vehicle Customization P. 125

2 Customized Features P. 432

Models with color audio system

Models with Display Audio

Lock

Unlock

■

Locking a Door Without Using a Key

1

Locking a Door Without Using a Key

When you lock the driver’s door, all the other doors
and tailgate lock at the same time.

Before locking a door, make sure that the key is not
inside the vehicle.

149

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Inside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Inside

■

Locking a door

Push the lock tab forward.

■

Unlocking a door

Pull the lock tab rearward.

■

Using the Lock Tab

1

Using the Lock Tab

When you lock the door using the lock tab on the
driver’s door, all of the other doors and the tailgate
lock at the same time.
When you unlock the door using the lock tab on the
driver’s door, only the driver’s door will unlock.

To Unlock

Lock Tab

To Lock

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Inside

150

Co
ntrols

Pull the front door inner handle.

u

The door unlocks and opens in one
motion.

Unlocking and opening the driver’s door from the inner handle unlocks all the other
doors.

To avoid all the doors to be unlocked, use the lock tab on the driver’s door to unlock,
then lock again before opening the door.

u

This setting works for one time only. If you do not want all the doors to be
unlocked all the time, customize the Auto Door Unlock setting to OFF using
the driver information interface

*

 or audio/information screen

*

.

2 Vehicle Customization P. 125

2 Customized Features P. 432

■

Unlocking Using the Front Door Inner Handle

1

Unlocking Using the Front Door Inner Handle

The front door inner handles are designed to allow
front seat occupants to open the door in one motion.
However this feature requires that front seat
occupants never pull a front door inner handle while
the vehicle is in motion.

Children should always ride in a rear seat where
childproof door locks are provided.

2 Childproof Door Locks P. 151

Inner Handle

Models with color audio system

Models with Display Audio

* Not available on all models

151

uu

Locking and Unlocking the Doors

u

Childproof Door Locks

Co
ntrols

Press the master door lock switch in as shown
to lock or unlock all doors and the tailgate.

Childproof Door Locks

The childproof door locks prevent the rear doors from being opened from the inside
regardless of the position of the lock tab.

Slide the lever in the rear door to the lock
position, and close the door.

■

When opening the door

Open the door using the outside door handle.

■

Using the Master Door Lock Switch

1

Using the Master Door Lock Switch

When you lock/unlock either of the front doors using
the master door lock switch, all the other doors and
the tailgate lock/unlock at the same time.

To Unlock

Master Door Lock Switch

To Lock

■

Setting the Childproof Door Locks

1

Childproof Door Locks

To open the door from the inside when the
childproof door lock is on, put the lock tab in the
unlock position, lower the rear window, put your
hand out of the window, and pull the outside door
handle.

Lock

Unlock

152

uu

Locking and Unlocking the Doors

u

Auto Door Locking/Unlocking

Co
ntrols

Auto Door Locking/Unlocking

Your vehicle locks all doors and unlocks all doors automatically when a certain
condition is met.

■

Drive lock mode

All doors and tailgate lock when the vehicle’s speed reaches about 10 mph (15
km/h).

■

Driver’s door open mode

All doors and tailgate unlock when the driver’s door is opened.

■

Auto Door Locking

■

Auto Door Unlocking

1

Auto Door Locking/Unlocking

You can turn off or change to another auto door
locking/unlocking setting using the driver
information interface.

2 Vehicle Customization P. 125

You can turn off or change to another auto door
locking/unlocking setting using the audio/
information screen.

2 Customized Features P. 432

Models with color audio system

Models with Display Audio

153

Continued

Co
ntrols

Opening and Closing the Tailgate

Precautions for Opening/Closing the Tailgate

Always make sure individuals and objects are clear of the tailgate before opening or
closing it.

• Open the tailgate all the way.

u

If it is not fully opened, the tailgate may begin to close under its own weight.

• Be careful when it is windy. The wind may cause the tailgate to close.

Keep the tailgate closed while driving to:

u

Avoid possible damage.

u

Prevent exhaust gas from leaking into the vehicle.

2 Carbon Monoxide Gas P. 76

1

Precautions for Opening/Closing the Tailgate

Be careful not to hit your head on the tailgate or to
put your hands between the tailgate and the cargo
area when closing the tailgate.

When you are storing or picking up cargo from the
cargo area, or by using a forward and back kicking
motion under the center of the rear bumper for
hands free access

*

, while the engine is idling, do not

stand in front of the exhaust pipe. You may get
burned.

Do not allow any passenger in the cargo space. They
may get hurt during hard braking, a sudden
acceleration, or a crash.

3

WARNING

Anyone caught in the path of a tailgate
that is being opened or closed can be
seriously injured.

Make sure that all people are clear of the
tailgate before opening or closing it.

Models without power tailgate

All models

* Not available on all models

uu

Opening and Closing the Tailgate

u

Precautions for Opening/Closing the Tailgate

154

Co
ntrols

The power tailgate can be operated by pressing the power tailgate button on the
remote transmitter, pressing the power tailgate button in the driver side control
panel, pressing the button on the tailgate, or by raising and lowering your foot
under the center of the rear bumper for hands free access

*

.

The power tailgate can be opened/closed when the transmission is in

(

P.

1

Precautions for Opening/Closing the Tailgate

NOTICE

Do not push or pull on the power tailgate when it is
being automatically opened or closed.
Forcibly opening or closing the power tailgate while
in operation can deform the tailgate frame.

When operating the power tailgate, make sure there
is enough space around your vehicle. People near the
tailgate may be seriously hurt if the tailgate hits or
closes on their heads. Be especially cautious if
children are around.

The power tailgate may not open or close under the
following conditions:

•

You start the engine while the tailgate is
automatically opening or closing.

•

The vehicle is parked on a steep hill.

•

The vehicle is swayed in a strong wind.

•

The tailgate or the roof is covered with snow or ice.

3

WARNING

Closing a power tailgate while anyone is in
the path of the tailgate can cause serious
injury.

Make sure everyone is clear before closing
the power tailgate.

Models with power tailgate

Models with power tailgate

* Not available on all models

Continued

155

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

*

Co
ntrols

Opening/Closing the Power Tailgate

*

Use a forward and back kicking motion under
the center of the rear bumper to open or close
the power tailgate while carrying the smart
entry remote.

u

Some exterior lights flash twice and a
beeper sounds once, then the tailgate
begins to move.

■

Using the Hands Free Access

*

1

Precautions for Opening/Closing the Tailgate

If you close the power tailgate with all the doors
locked, the power tailgate locks automatically.

1

Using the Hands Free Access

*

During rain or in other instances when the vehicle
becomes wet, the sensor may not properly detect
your foot motion.

When performing work on or around the rear section
of the vehicle, you may inadvertently open or close
the tailgate.
To prevent this from happening, select Customized
Features on the audio/information screen and then
select OFF for the feature.

2 Customized Features P. 432

If you hold your foot under the bumper for too long,
the power tailgate does not open or close.

This function will not operate if you don't have the
smart entry remote on you. Please make sure you
have the smart entry remote on you.

The duration of the kicking motion should be
approximately one second.

1 sec.

* Not available on all models

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

*

156

Co
ntrols

Press the power tailgate button for more than
one second to operate when the power mode
is in VEHICLE OFF (LOCK).

u

Some exterior lights flash and the beeper
sounds.

If you press the button again while the power
tailgate is moving, it will reverse direction.

■

Customizing when to open the tailgate

Anytime: The power tailgate unlocks and opens at the same time. This is the
default setting.
When Unlocked: The tailgate opens when all doors are unlocked.

2 Customized Features P. 432

■

Using the Remote Transmitter

1

Opening/Closing the Power Tailgate

*

If you close the power tailgate when all the doors are
locked, the power tailgate locks automatically.

If you replace the battery or the power tailgate fuse
while the tailgate is open, the power tailgate may be
disabled. The power tailgate resumes once you
manually close the tailgate.

Installing aftermarket components other than
genuine Honda accessories on the power tailgate
may prevent it from fully opening or closing.

Make sure the power tailgate is fully open before you
get your cargo in and out.

Make sure the power tailgate is fully closed before
you start the vehicle.

The beeper sounds when you start driving while the
power tailgate is still open, or closing.

Power
Tailgate
Button

* Not available on all models

Continued

157

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

*

Co
ntrols

To open or close the power tailgate, press the
power tailgate button for about one second.

u

Some exterior lights flash and the beeper
sounds.

If you press the button again while the power
tailgate is moving, it will stop.
Press the button for about one second, and
the power tailgate will reverse direction.

■

Using the Power Tailgate Button

1

Opening/Closing the Power Tailgate

*

If the power tailgate meets resistance while opening
or closing, the auto reverse feature reverses the
direction. The beeper sounds three times.

The auto reverse function stops sensing when the
tailgate is almost closed to make sure that it fully
closes.

Do not touch the sensors located on both sides of the
tailgate. The power tailgate does not close if you
touch either sensor when you are trying to close the
tailgate.

Be careful not to scratch the sensors with a sharp
object. If scratched, they can be damaged, and the
power tailgate closing feature malfunctions.

Power Tailgate Button

* Not available on all models

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

*

158

Co
ntrols

If you press the outer handle of the tailgate for
no longer than one second, the tailgate opens
automatically.

u

The beeper sounds.

u

If you want to open the tailgate
manually, press the button for more than
one second.

2 Opening and Closing the Tailgate

P. 153

If you are carrying the smart entry remote, you
do not have to unlock the tailgate before
opening it.

To close the tailgate, press the outer handle
again while the tailgate opening.

If you press the outer handle again while the
power tailgate is moving, it will stop.
Press the outer handle, and the power tailgate
will reverse direction.

■

Using the Tailgate Outer Handle

1

Opening/Closing the Power Tailgate

*

Do not leave the key, remote transmitter, or smart
entry remote in the cargo area before closing the
tailgate.

Even if you are not carrying the smart entry remote,
you can lock/unlock the tailgate while someone else
with the remote is within range.

You can change the power tailgate operation setting
on and off.

2 Customized Features P. 432

Outer
Handle

* Not available on all models
