Honda Pilot (2019 year). Instruction

127

Gauges and Displays

Driver Information Interface

Continued

strum

nt Pa

nel

Default All

ENTER

Auto Door Lock

Security Relock Timer

Auto Door Unlock

Key And Remote Unlock Mode

Keyless Lock Answer Back

Door Setup

Exit

3
4

Walk Away Auto Lock

128

Gauges and Displays

Driver Information Interface

strum

nt Pa

nel

■

List of customizable options

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable settings

Meter Setup

Language Selection

Changes the displayed language.

English

/Français/Español

“Trip A” Reset Timing

Changes the setting of how the distance and
average fuel economy of trip computer A is reset.

When Fully Refueled/IGN OFF/
Manually Reset

“Trip B” Reset Timing

Changes the setting of how the distance and
average fuel economy of trip computer B is reset.

When Fully Refueled/IGN OFF/
Manually Reset

Adjust Alarm Volume

Changes the volume setting for buzzers, warnings,
turn signals, and other alerting systems.

High/Mid

/Low

Fuel Efficiency
Backlight

Turns the ambient meter feature on and off.

/OFF

Driver Assist
System
Setup

Forward Collision
Warning Distance

Changes the distance at which CMBS

alerts.

Long/Normal

/Short

ACC Forward Vehicle
Detect Beep

Causes the system to beep when the system detects a
vehicle, or when the vehicle goes out of ACC range.

ON/OFF

Road Departure
Mitigation Setting

Changes the setting for the road departure
mitigation system.

Normal

/Wide/Warning Only

Lane Keeping Assist
Suspend Beep

Causes the system to beep when the LKAS is
suspended.

ON/OFF

129

Gauges and Displays

Driver Information Interface

Continued

strum

nt Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable settings

Lighting
Setup

Interior Light
Dimming Time

Changes the length of time the interior lights stay on
after you close the doors.

60sec/30sec

/15sec

Headlight Auto OFF
Timer

Changes the length of time the exterior lights stay
on after you close the driver’s door.

60sec/30sec/15sec

/0sec

Auto Light Sensitivity

Changes the timing for the headlights to come on.

Max/High/Mid

/Low/Min

Auto Interior
Illumination
Sensitivity

Changes the sensitivity of the brightness of the
instrument panel when the headlight switch is in the
AUTO position.

Max/High/Mid

/Low/Min

Auto Headlight ON
With Wiper ON

Changes the settings for the wiper operation when
the headlights automatically come on while the
headlight switch is in the AUTO position.

/OFF

130

Gauges and Displays

Driver Information Interface

strum

nt Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable settings

Door Setup

Auto Door Lock

Changes the setting for when the doors
automatically lock.

With Vehicle Speed

/Shift

From P/OFF

Auto Door Unlock

Changes the setting for when the doors
automatically unlock.

All Doors When Driver’s Door
Opens

/All Doors When

Shifted To Park/All Doors When
Ignition Switched OFF/OFF

Key And Remote
Unlock Mode

Sets up either the driver’s door or all doors to unlock
on the first operation of the remote or built-in key.

Driver Door

/All Doors

Walk Away Auto Lock

Changes the settings for the auto lock function
when you walk away from the vehicle.

ON/OFF

Keyless Lock Answer
Back

LOCK/UNLOCK - The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

/OFF

Security Relock Timer

Changes the time it takes for the doors to relock and
the security system to set after you unlock the
vehicle without opening a door.

90sec/60sec/30sec

Default All

—

Cancels customized changes you have made or
restores them to their default setting.

Cancel/Set

131

Gauges and Displays

Driver Information Interface

Continued

strum

nt Pa

nel

■

Example of how to customize a setting

Below are steps that explain how to change the reset timing for trip A from the
default setting (manual) so that it resets automatically when the vehicle is fully
refueled.

1. Press the

(home) button and then the

button to select Settings, then

press the ENTER button.

2. Press the

button to select Vehicle

Customization, then press the ENTER
button.

3 4

132

Gauges and Displays

Driver Information Interface

strum

nt Pa

nel

3. Press the

button to select Meter

Setup, then press the ENTER button.

Language Selection appears first in the
display.

4. Press the

button to select “Trip A”

Reset Timing, then press the ENTER
button.

The display switches to the
customization setup screen, where you
can select When Fully Refueled, IGN
OFF, Manually Reset, or Exit.

5. Press the

button to select When

Fully Refueled, then press the ENTER
button.

The SETUP “When Fully Refueled”
screen appears, then the display returns
to the customization menu screen.

3 4

133

Gauges and Displays

Driver Information Interface

strum

nt Pa

nel

6. Press the

button until Exit appears

on the display, then press the ENTER
button.

7. Repeat Step 6 until you return to the

Vehicle Customization screen, then press
the

(home) or

(back) button to

return to the home screen.

3 4

136

Co
ntrols

Clock

Adjusting the Clock

You can adjust the time manually in the audio/information screen, with the power
mode in ON.

■

Using the MENU/CLOCK button

1. Press and hold the MENU/CLOCK button

for two seconds.

2. Select Adjust Clock, then press

3. Rotate

to adjust the hours.

4. Press

to switch to minute adjustment.

5. Rotate

to adjust the minutes.

6. Press

to switch to Set.

7. Press

to complete clock adjustment.

■

Adjusting the Time

Clock

The clock is automatically updated through the
navigation system, so the time does not need to be
adjusted.

Models with navigation system

Models without navigation system

Using the MENU/CLOCK button

These indications are used to show how to operate
the selector knob.
Rotate

to select.

Press

to enter.

To change the setting between 12h and 24h:
1. Press the MENU/CLOCK button.
2. Rotate

select

Settings, then press

3. Rotate

to select Clock Format, then press

4. Rotate

select

12h or 24h, then press

You can also access to the clock adjustment mode by
pressing and holding the MENU/CLOCK button.

You can customize the clock display to show the 12
hour clock or 24 hour clock.

2 Customized Features P. 425

Models with color audio system

Continued

137

Clock

Adjusting the Clock

Co
ntrols

■

Using the Settings menu on the audio/
information screen

1. Select

, then select Settings.

2. Select System.
3. Select Date & Time.
4. Select Set Date & Time.
5. Select Automatic Date & Time, then

select OFF.

To adjust time:
6. Select Set Time.
7. Selecting /

AM/PM icon can be switched to each
other either by selecting

, or by

directly touching the icon.

When you customize the clock display to
24 hour clock, AM/PM icon is not
displayed.

2 Customized Features P. 432

8. Select Save to set the time.

Using the Settings menu on the audio/information screen

You can also adjust the clock by touching the clock
displayed on the upper right corner of the display or
the Clock icon on the home screen.
1. Touch the clock on the display.

The clock screen of the select face-type appears.

2. Select Settings.
3. Select Date & Time Settings.
4. Select Set Date & Time.
5. Select Automatic Date & Time, then select OFF.
6. Select Set Date or Set Time.
7. Adjusting the dates, hours and minutes by

selecting /

8. Select Save to set the time.

You can customize the clock display to show the 12
hour clock or 24 hour clock.

2 Customized Features P. 432

Models with Display Audio

3 4

Models with Display Audio

3 4

139

Continued

Co
ntrols

Locking and Unlocking the Doors

Key Types and Functions

This vehicle comes with the following keys:

Use the keys to start and stop the engine, and to lock and unlock all the doors and
tailgate. You can also use the remote transmitter to lock and unlock all the doors
and tailgate.

The built-in key can be used to lock/unlock the
doors when the smart entry remote battery
becomes weak and the power door lock/
unlock operation is disabled.

To remove the built-in key, slide the release
knob and then pull out the key. To reinstall
the built-in key, push the built-in key into the
smart entry remote until it clicks.

Key Types and Functions

All the keys have an immobilizer system. The
immobilizer system helps to protect against vehicle
theft.

2 Immobilizer System P. 163

Follow the advice below to prevent damage to the
keys:

•

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

•

Do not drop the keys or set heavy objects on them.

•

Keep the keys away from liquids, dust and sand.

•

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the engine
may not start, and the remote transmitter may not
work.
If the keys do not work properly, have them
inspected by a dealer.

You can remotely start the engine using the smart
entry remote.

2 Remote Engine Start

P. 529

Models with remote engine start

■

Built-in Key

Models without
smart entry system

Models with smart
entry system

Models with smart entry
system and power tailgate

Release Knob

Built-in Key

* Not available on all models

Locking and Unlocking the Doors

Key Types and Functions

140

Co
ntrols

Contains a number that you will need if you
purchase a replacement key.

■

Key Number Tag

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact a
dealer.

If you lose your key and you cannot start the engine,
contact a dealer.

141

Locking and Unlocking the Doors

Low Smart Entry Remote Signal Strength

Co
ntrols

Low Smart Entry Remote Signal Strength

The vehicle transmits radio waves to locate the smart entry remote when locking/
unlocking the doors and tailgate, or to start the engine.

In the following cases, locking/unlocking the doors and tailgate, or starting the
engine may be inhibited or operation may be unstable:
• Strong radio waves are being transmitted by nearby equipment.
• You are carrying the smart entry remote together with telecommunications

equipment, laptop computers, cell phones, or wireless devices.

• A metallic object is touching or covering the smart entry remote.

Models with smart entry system

Low Smart Entry Remote Signal Strength

Communication between the smart entry remote and
the vehicle consumes the smart entry remote’s
battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the smart entry
remote is receiving strong radio waves. Avoid placing
it near electrical appliances such as televisions and
personal computers.

* Not available on all models

142

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the smart entry remote, you
can lock/unlock the doors and the tailgate.

You can lock/unlock the doors and the
tailgate within a radius of about 32 inches (80
cm) of the outside door handle or tailgate
outer handle.

■

Using the Smart Entry with Push Button Start System

Except U.S. LX models

Locking/Unlocking the Doors from the Outside

If the interior light switch is in the door activated
position, the interior lights come on when you unlock
the doors and tailgate.
No doors opened: The lights fade out after 30
seconds.
Doors and tailgate relocked: The lights go off
immediately.

2 Interior Lights P. 209

Using the Smart Entry with Push Button Start System

If you do not open a door or the tailgate within 30
seconds of unlocking the vehicle with the smart entry
system, the doors and tailgate will automatically
relock.

You can lock or unlock doors using the smart entry
system only when the power mode is in VEHICLE OFF.

Honda Pilot (2019 year). Instruction - part 9
