Honda HR-V (2019 year). Instruction

128

Gauges and Displays

Multi-Information Display

strum

nt Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Door Setup

Auto Door Lock

Changes the setting for when the doors
automatically lock.

With Vehicle Speed

Shift From P/OFF

Auto Door Unlock

Changes the setting for when the doors
automatically unlock.

All Doors When Driver's
Door Opens

All Doors When Shifted To
Park/
All Doors When Ignition
Switched OFF/
OFF

Key And Remote Unlock
Mode

Sets up either the driver’s door or all doors to unlock
on the first operation of the remote or built-in key.

Driver Door

/All Doors

Walk Away Auto Lock

Changes the settings for the auto lock function
when you walk away from the vehicle.

ON/OFF

Keyless Lock Answer
Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

/OFF

Security Relock Timer

Changes the time it takes for the doors to relock and
the security system to set after you unlock the
vehicle without opening any door.

90sec/60sec/30sec

Maintenance
Info.

—

Resets or cancels the engine oil life display when you
have performed the maintenance service.

Cancel/Reset

Default All

—

Cancels/Resets all the customized settings as
default.

Cancel/Set

* Not available on all models

129

Gauges and Displays

Multi-Information Display

Continued

strum

nt Pa

nel

■

Example of customization settings

The steps for changing the “Trip A” Reset Timing setting to When Refueled are
shown below. The default setting for “Trip A” Reset Timing is Manually Reset.

1. Press the

button until Vehicle

Settings appears on the display, then press
the SEL/RESET button.

2. Press the

button until Meter

Setup appears on the display.

3. Press the SEL/RESET button.

130

Gauges and Displays

Multi-Information Display

strum

nt Pa

nel

4. Press the

button until “Trip A”

Reset Timing appears on the display, then
press the SEL/RESET button.

The display switches to the
customization setup screen, where you
can select When Refueled, IGN OFF,
Manually Reset, or Exit.

5. Press the

button and select When

Refueled, then press the SEL/RESET
button.

The When Refueled Setup screen
appears, then the display returns to the
customization menu screen.

6. Press the

button until Exit appears

on the display, then press the SEL/RESET
button.

7. Repeat Step 6 until you return to the

normal screen.

132

Co
ntrols

Clock

Adjusting the Clock

You can adjust the time in the clock display with the ignition switch is in ON

(

■

Display audio system

1. Select the

(HOME) icon, then select

Settings.

2. Select Clock/Info, then Clock

Adjustment.

3. Adjust the hours and minutes by selecting

4. Select OK to set the time.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Adjusting the Time

Models without navigation system

Adjusting the Time

The clock in the multi-information display

information display

is automatically adjusted along

with the audio system’s clock display.

The clock is automatically updated through the
navigation system, so the time does not need to be
adjusted.

You can customize the clock display to show the 12
hour clock or 24 hour clock.

2 Customized Features P. 122

Models with navigation system

Models without navigation system

Display audio system

You can turn the clock display on and off.

2 Customized Features P. 122

3 4

* Not available on all models

133

Clock

Adjusting the Clock

Co
ntrols

■

Color audio system

1. Press and hold the MENU/CLOCK button.

Adjust Clock is selected.

2. Rotate

to change hour, then press

3. Rotate

to change minute, then press

4. To enter the selection, rotate

and select

Set, then press

Color audio system

These indications are used to show how to operate
the LIST/SELECT (List/Selector) knob.
Rotate

to select.

Press

to enter.

You can also select Adjust Clock by pressing the
MENU/CLOCK button.
Rotate

to select Adjust Clock, then press

* Not available on all models

134

Co
ntrols

Locking and Unlocking the Doors

Key Types and Functions

This vehicle comes with the following keys:

Use the smart entry remote to start and stop
the engine, and to lock and unlock all the
doors and tailgate. You can also use the smart
entry system to lock and unlock the doors and
tailgate.

Use the key to start and stop the engine, and
to lock and unlock all the doors and tailgate.
You can also use the remote transmitter to
lock and unlock the doors and tailgate.

The built-in key can be used to lock/unlock the
doors when the smart entry remote battery
becomes weak and the power door lock/
unlock operation is disabled.

To remove the built-in key, slide the release
knob and then pull out the key. To reinstall
the built-in key, push the built-in key into the
smart entry remote until it clicks.

Key Types and Functions

All the keys have an immobilizer system. The
immobilizer system helps to protect against vehicle
theft.

2 Immobilizer System P. 157

Follow the advice below to prevent damage to the
keys:

•

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

•

Do not drop the keys or set heavy objects on them.

•

Keep the keys away from liquids, dust and sand.

•

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the engine
may not start, and the remote transmitter/smart entry
system

may not work.

If the keys do not work properly, have them
inspected by a dealer.

Ignition Key
with Remote
Transmitter

Smart
Entry
Remote

Models with smart entry system

Models without smart entry system

■

Built-in Key

Release Knob

Built-in Key

* Not available on all models

135

Locking and Unlocking the Doors

Key Types and Functions

Co
ntrols

Contains a number that you will need if you
purchase a replacement key.

■

Key Number Tag

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact a
dealer.

If you lose your key and you cannot start the engine,
contact a dealer.

136

Locking and Unlocking the Doors

Low Smart Entry Remote Signal Strength

Co
ntrols

Low Smart Entry Remote Signal Strength

The vehicle transmits radio waves to locate the smart entry remote when locking/
unlocking the doors and tailgate, or to start the engine.

In the following cases, locking/unlocking the doors and tailgate, or starting the
engine may be inhibited or operation may be unstable:
• Strong radio waves are being transmitted by nearby equipment.
• You are carrying the smart entry remote together with telecommunications

equipment, laptop computers, cell phones, or wireless devices.

• A metallic object is touching or covering the smart entry remote.

Low Smart Entry Remote Signal Strength

Communication between the smart entry remote and
the vehicle consumes the smart entry remote’s
battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the smart entry
remote is receiving strong radio waves. Avoid placing
it near electrical appliances such as televisions and
personal computers.

* Not available on all models

137

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the smart entry remote, you
can lock/unlock the doors and the tailgate.
You can lock/unlock the doors and the
tailgate within a radius of about 32 inches (80
cm) of the outside door or tailgate outer
handle.

■

Using the Smart Entry with Push Button Start System

Locking/Unlocking the Doors from the Outside

If the interior light switch is in the door activated
position, the interior light comes on when you unlock
the doors and tailgate.
No doors opened: The light fades out after 30
seconds.
Doors and tailgate relocked: The light goes off
immediately.

2 Interior Lights P. 198

Using the Smart Entry with Push Button Start System

If you do not open a door or the tailgate within 30
seconds of unlocking the vehicle with the smart entry
system, the doors and tailgate will automatically
relock.

You can lock or unlock doors using the smart entry
system only when the power mode is in VEHICLE OFF.

•

Do not leave the smart entry remote in the vehicle
when you get out. Carry it with you.

•

Even if you are not carrying the smart entry remote,
you can lock/unlock the doors and the tailgate
while someone else with the remote is within
range.

•

The door may be unlocked if the door handle is
covered with water in heavy rain or in a car wash if
the smart entry remote is within range.

* Not available on all models

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

138

Co
ntrols

■

Locking the doors and tailgate

Press the door lock button on the front door
or the tailgate.

Some exterior lights flash; the beeper
sounds; all the doors and tailgate lock;
and the security system sets.

Using the Smart Entry with Push Button Start System

•

If you grip a front door handle wearing gloves, the
door sensor may be slow to respond or may not
respond by unlocking the doors.

•

After locking the door, wait at least two seconds
before unlocking it by gripping the handle.

•

The door might not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

•

Even within the 32 inches (80 cm) radius, you may
not be able to lock/unlock the doors and the
tailgate with the smart entry remote if it is above or
below the outside handle.

•

The smart entry remote may not operate if it is too
close to the door and door glass.

The light flash, beep, and door unlock mode settings
can be customized using the multi-information
display.

2 Customized Features P. 122

Door Lock
Button

Lock Button

* Not available on all models

139

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

■

Unlocking the doors and tailgate

Grab the driver’s door handle:

The driver’s door unlocks.

Some exterior lights flash twice and the
beeper sounds twice.

Grab the front passenger’s door handle:

All the doors and the tailgate unlock.

Some exterior lights flash twice and the
beeper sounds twice.

Press the tailgate release button:

The tailgate unlocks.

Some exterior lights flash twice and the
beeper sounds twice.

2 Using the Tailgate Release Button

P. 155

Tailgate Release
Button

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

140

Co
ntrols

■

Locking the doors and tailgate (Walk
away auto lock®)

When you walk away from the vehicle while
carrying the smart entry remote, the doors
and tailgate will automatically lock.
The auto lock function activates when all
doors and tailgate are closed, and the smart
entry remote is within about 5 feet (1.5 m)
radius of the outside door handle.
Exit vehicle while carrying smart entry remote
and close door(s) and tailgate.
1. While within about 5 feet (1.5 m) radius of

the vehicle.

The beeper sounds; the auto lock
function will be activated.

2. Carry the smart entry remote beyond about

5 feet (1.5 m) from the vehicle and remain
outside this range for 2 or more seconds.

Some exterior lights flash; the beeper
sounds; all doors and tailgate will then
lock.

Locking the doors and tailgate (Walk away auto lock®)

The auto lock function is set to OFF as the factory
default setting. The auto lock function can be set to
ON using the multi-information display.
If you set the auto lock function to ON using the
multi-information display, only the remote
transmitter that was used to unlock the driver’s door
prior to the setting change can activate auto lock.

2 Customized Features P. 122

After the auto lock function has been activated,
when you stay within the locking/unlocking
operation range, the indicator on the smart entry
remote will continue to flash until the doors and
tailgate are locked.

When you stay beside the vehicle within the
operation range, the doors and tailgate will
automatically lock approximately 30 seconds after
the auto lock function activating beeper sounds.

When you open a door or tailgate after the auto lock
function activating beeper sounds, the auto lock
function will be delayed until all doors and tailgate
are closed.

Under the following circumstances, the auto-lock
function will not activate:

•

The smart entry remote is inside the vehicle.

The beeper will not sound.

•

The remote is taken out of its operational range
before all the doors are closed.

The beeper will sound.

The activation range of
the auto lock function is
about 5 feet (1.5 m)

Continued

141

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

To temporarily deactivate the function:
1. Set the power mode to OFF.
2. Open the driver’s door.
3. Using the master door lock switch, operate

the lock as follows:
LockUnlockLockUnlock.

The beeper sounds and the function is
deactivated.

To restore the function:
• Set the power mode to ON.
• Lock the vehicle without using the auto lock

function

• With the smart entry remote on you, move

out of the auto lock function operation
range.

• Open any door.

Locking the doors and tailgate (Walk away auto lock®)

The auto lock function does not operate when any of
the following conditions are met.

•

The smart entry remote is inside the vehicle.

•

A door, tailgate or the bonnet is not closed.

•

The power mode is set to any mode other than OFF.

•

The smart entry remote is not located within a
radius of about 5 feet (1.5 m) from the vehicle
when you get out of the vehicle and close the
doors and tailgate.

Auto lock function operation stop beeper
After the auto lock function has been activated, the
auto lock operation stop beeper sounds for
approximately two seconds in the following cases.

•

The smart entry remote is put inside the vehicle
through a window.

•

You are located too close to the vehicle.

•

The smart entry remote is put inside the tailgate.

If the warning beeper sounds, check that you are
carrying the smart entry remote. Then, open/close a
door and confirm the auto lock activation beeper
sounds once.

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

142

Co
ntrols

■

Locking the doors

Press the lock button.
Once:

Some exterior lights flash, all the doors
and tailgate lock, and the security system
sets.

Twice (within five seconds after the first
push):

A beeper sounds and verifies the security
system is set.

■

Using the Remote Transmitter

Using the Remote Transmitter

If you do not open a door within 30 seconds of
unlocking the vehicle with the remote transmitter,
the doors will automatically relock.

You can change the relock timer setting.

2 Customized Features P. 122

The remote transmitter uses low-power signals, so
the operating range may vary depending on the
surroundings.

The remote transmitter will not lock the vehicle when
a door is open.

The remote transmitter will not work when the key is
in the ignition switch.

You can lock or unlock doors using the remote
transmitter or smart entry system only when the
power mode is in VEHICLE OFF.

Models with multi-information display

Models without smart entry system

Models with smart entry system

LED

Unlock Button

Lock Button

Unlock Button

LED

Lock Button

Continued

143

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Unlocking the doors

Press the unlock button.
Once:

Some exterior lights flash twice, and the driver’s door unlocks.

Twice:

The remaining doors and the tailgate unlock.

Using the Remote Transmitter

If the distance at which the remote transmitter works
varies, the battery is probably low.
If the LED does not come on when you press a
button, the battery is dead.

2 Replacing the Button Battery P. 562

You can customize the door unlock mode setting.

2 Customized Features P. 122

Models with multi-information display

Honda HR-V (2019 year). Instruction - part 9
