464

Before Performing Maintenance

Parts and Fluids Used in Maintenance Service

Main

tenan

Parts and Fluids Used in Maintenance Service

The use of Honda genuine parts and fluids is recommended when maintaining and
servicing your vehicle. Honda genuine parts are manufactured according to the
same high quality standards used in Honda vehicles.

465

Continued

Main

tenan

Maintenance Minder

If the engine oil life is less than 15%, you will see the Maintenance Minder messages
appear on the information display every time you turn the ignition switch to ON

(

. The messages notify you when to change the engine oil, or when to bring your

vehicle to a dealer for indicated maintenance services.

To Use Maintenance Minder

1. Turn the ignition switch to ON

(

2. Press the

(Select/Reset) knob repeatedly

until the engine oil life appears on the
information display.

The Maintenance Minder indicator (

) stays

on in the instrument panel after the engine oil
life becomes 0%. Have the indicated
maintenance done by a dealer immediately.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Displaying the Engine Oil Life

Displaying the Engine Oil Life

Based on the engine operating conditions, the
remaining engine oil life is calculated and displayed
as a percentage.

Displayed Engine Oil

Life (%)

Calculated Engine Oil

Life (%)

100

100 to 91

90 to 81

80 to 71

70 to 61

60 to 51

50 to 41

40 to 31

30 to 21

20 to 16

15 to 11

10 to 6

5 to 1

466

Maintenance Minder

To Use Maintenance Minder

Main

tenan

To switch the display, press the

(Select/Reset) knob.

■

Maintenance Minder Messages on the Information Display

Oil Life Display

Explanation

Information

Maintenance Minder Indicator

The engine oil life indicator starts
to appear along with other due
soon maintenance item codes
when the remaining oil life
becomes 15 percent.

The engine oil is approaching the
end of its service life.

Starts to come on when the
remaining engine oil life becomes
15 percent.
It goes off when the display is
switched.

The SERVICE message also starts
to appear along with the engine oil
life indicator and the maintenance
item codes.

The engine oil has almost reached
the end of its service life, and the
maintenance items should be
inspected and serviced as soon as
possible.

The remaining engine oil life has
passed its service life, and a
negative distance appears after
driving over 10 miles (U.S. models)
or 10 km (Canadian models). The
negative distance on the display
blinks.

The engine oil life has passed.
The maintenance items must be
inspected and serviced
immediately.

Stays on as a reminder even when
the display is switched.

467

Maintenance Minder

To Use Maintenance Minder

Continued

Main

tenan

■

Maintenance Service Items

Maintenance Service Items

•

Independent of the Maintenance Minder
information, replace the brake fluid every 3 years.

•

Inspect idle speed every 160,000 miles (256,000
km).

•

Adjust the valves during services A, B, 1, 2, or 3 if
they are noisy.

Maintenance Minder
Message

System Message
Indicator

Sub Items

Main
Item

*1: If a message SERVICE does not appear more than 12 months after the display is reset, change the

engine oil every year.

# : See information on maintenance and emissions warranty.

CODE

Maintenance Main Items

●

Replace engine oil

●

Replace engine oil

and oil filter

●

Inspect front and rear brakes

●

Check parking brake adjustment

●

Inspect tie rod ends, steering gearbox, and boots

●

Inspect suspension components

●

Inspect driveshaft boots

●

Inspect brake hoses and lines (Including ABS/VSA)

●

Inspect all fluid levels and condition of fluids

●

Inspect exhaust system

●

Inspect fuel lines and connections

*2: If you drive in dusty conditions, replace the air cleaner element every 15,000 miles (24,000 km).
*3: If you drive primarily in urban areas that have high concentrations of soot in the air from industry and

from diesel-powered vehicles, replace the dust and pollen filter every 15,000 miles (24,000 km).

*4: 4WD only
*5: 6-cylinder models
*6: If you drive regularly in very high temperatures (over 110°F, 43°C), in very low temperatures (under

-20°F, -29°C), or tow a trailer, replace every 60,000 miles (U.S.)/100,000 km (Canada).

CODE

Maintenance Sub Items

●

Rotate tires

●

Replace air cleaner element

●

Replace dust and pollen filter

●

Inspect drive belt

●

Replace transmission and transfer

fluid

●

Replace spark plugs

●

Replace timing belt and inspect water pump

*5, *6

●

Inspect valve clearance

●

Replace engine coolant

●

Replace rear differential fluid

Maintenance Minder

To Use Maintenance Minder

468

Main

tenan

Reset the engine oil life display if you have performed the maintenance service.

1. Turn the ignition switch to ON

(

2. Display the engine oil life by repeatedly

pressing the

(Select/Reset) knob.

3. Press and hold the

knob for ten seconds

or more.

The engine oil life indicator and the
maintenance item codes blink.

4. Press the

knob for five seconds or more.

The displayed maintenance items
disappear, and the engine oil life display
returns to 100%.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Resetting the Display

Resetting the Display

NOTICE

Failure to reset the engine oil life after a maintenance
service results in the system showing incorrect
maintenance intervals, which can lead to serious
mechanical problems.

The dealer will reset the engine oil life display after
completing the required maintenance service. If
someone other than a dealer performs maintenance
service, reset the engine oil life display yourself.

You can reset the engine oil life display using the
audio/information screen.

2 Customized Features

P. 280

Models with audio/information screen

* Not available on all models

469

Continued

Main

tenan

Maintenance Under the Hood

Maintenance Items Under the Hood

4-cylinder models

Brake Fluid
(Black Cap)

Engine Coolant
Reserve Tank

Radiator Cap

Washer Fluid
(Blue Cap)

Engine Oil Dipstick
(Orange)

Engine Oil Fill Cap

Battery

Power Steering Fluid
(Red Cap)

470

Maintenance Under the Hood

Maintenance Items Under the Hood

Main

tenan

6-cylinder models

Engine Oil Dipstick
(Orange)

Washer Fluid
(Blue Cap)

Engine Coolant
Reserve Tank

Radiator Cap

Brake Fluid
(Black Cap)

Engine Oil Fill Cap

Battery

471

Maintenance Under the Hood

Opening the Hood

Main

tenan

Opening the Hood

1. Park the vehicle on a level surface, and set

the parking brake.

2. Pull the hood release handle under the

lower left corner of the dashboard.

The hood will pop up slightly.

3. Push up the hood latch lever in the center

of the hood to release the lock mechanism,
and open the hood.

4. Lift the hood up most of the way.

The hydraulic supports will lift it up the
rest of the way and hold it up.

When closing, lower it to approximately 12
inches (30 cm), then press down firmly with
your hands.

Opening the Hood

NOTICE

Do not open the hood when the wiper arms are
raised.
The hood will strike the wipers, and may damage
either the hood or the wipers.

When closing the hood, check that the hood is
securely latched.

If the hood latch lever moves stiffly, or if you can
open the hood without lifting the lever, the latch
mechanism should be cleaned and lubricated.

Hood Release Handle

Pull

Lever

472

Maintenance Under the Hood

Recommended Engine Oil

Main

tenan

Recommended Engine Oil

Oil is a major contributor to your engine’s
performance and longevity. If you drive the
vehicle with insufficient or deteriorated oil,
the engine may fail or be damaged.

This seal indicates the oil is energy conserving
and that it meets the American Petroleum
Institute’s latest requirements.

Use a Genuine Honda Motor Oil or another
commercial engine oil of suitable viscosity for
the ambient temperature as shown.

■

Synthetic oil

You may also use synthetic motor oil if it is labeled with the API Certification Seal
and is the specified viscosity grade.

• Genuine Honda Motor Oil
• Premium-grade 0W-20 detergent oil with an API Certification Seal on the

container.

Recommended Engine Oil

Engine Oil Additives
Your vehicle does not require oil additives. In fact,
they may adversely affect the engine performance
and durability.

Ambient Temperature

473

Maintenance Under the Hood

Oil Check

Continued

Main

tenan

Oil Check

We recommend that you check the engine oil level every time you refuel.
Park the vehicle on level ground.
Wait approximately three minutes after turning the engine off before you check the
oil.

1. Remove the dipstick (orange).
2. Wipe the dipstick with a clean cloth or

paper towel.

3. Insert the dipstick back all the way into its

hole.

Oil Check

If the oil level is near or below the lower mark, slowly
add oil being careful not to overfill.

4-cylinder models

6-cylinder models

474

Maintenance Under the Hood

Oil Check

Main

tenan

4. Remove the dipstick again, and check the

level. It should be between the upper and
lower marks. Add oil if necessary.

4-cylinder models

6-cylinder models

Upper Mark
Lower Mark

475

Maintenance Under the Hood

Adding Engine Oil

Main

tenan

Adding Engine Oil

1. Unscrew and remove the engine oil fill cap.
2. Add oil slowly.
3. Reinstall the engine oil fill cap, and tighten

it securely.

4. Wait for three minutes and recheck the

engine oil dipstick.

Adding Engine Oil

If any oil spills, wipe it up immediately. Spilled oil may
damage the engine compartment components.

NOTICE

Do not fill the engine oil above the upper mark.
Overfilling the engine oil can result in leaks and
engine damage.

Engine Oil Fill Cap

4-cylinder models

6-cylinder models

Engine Oil Fill Cap

476

Maintenance Under the Hood

Changing the Engine Oil and Oil Filter

Main

tenan

Changing the Engine Oil and Oil Filter

You must change the engine oil and oil filter regularly in order to maintain the
engine’s lubrication. The engine may be damaged if they are not changed regularly.

Change the oil and filter in accordance with the maintenance message on the
information display

/multi-information display

1. Run the engine until it reaches normal

operating temperature, and then turn the
engine off.

2. Open the hood and remove the engine oil

fill cap.

3. Remove the drain bolt and washer from

the bottom of the engine, and drain the
oil into a suitable container.

Changing the Engine Oil and Oil Filter

NOTICE

You may damage the environment if you do not
dispose of the oil in a suitable way. If you are
changing the oil by yourself, appropriately dispose of
the used oil. Put the oil in a sealed container and take
it to a recycling center. Do not throw the oil away
into a garbage can or onto the ground.

4-cylinder models

6-cylinder models

Drain Bolt

Washer

Drain Bolt

Washer

* Not available on all models

477

Maintenance Under the Hood

Changing the Engine Oil and Oil Filter

Main

tenan

4. Remove the oil filter and dispose of the

remaining oil.

5. Check that the filter gasket is not stuck to

the engine contact surface.

If it is stuck, you must detach it.

6. Wipe away dirt and dust adhering to the

contact surface of the engine block, and
install a new oil filter.

Apply a light coat of new engine oil to
the oil gasket.

7. Put a new washer on the drain bolt, then

reinstall the drain bolt.

Tightening torque:
29 lbf∙ft (39 N∙m, 4.0 kgf∙m)

8. Pour the recommended engine oil into the

engine.

Engine oil change capacity (including
filter):

4.2 US qt (4.0 L)

4.5 US qt (4.3 L)

9. Reinstall the engine oil fill cap securely and

start the engine.

10. Run the engine for a few minutes, and

then check that there is no leak from the
drain bolt or oil filter.

11. Stop the engine, wait for three minutes,

and then check the oil level on the
dipstick.

If necessary, add more engine oil.

Changing the Engine Oil and Oil Filter

You will need a special wrench to replace the oil
filter. You can buy this wrench from a dealer.

When installing the new oil filter, follow the
instructions supplied with the oil filter.

Reinstall the engine oil fill cap. Start the engine. The
low oil pressure indicator should go off within five
seconds. If it does not, turn off the engine, and check
your work.

4-cylinder models

6-cylinder models

Oil Filter

4-cylinder models

6-cylinder models

478

Maintenance Under the Hood

Engine Coolant

Main

tenan

Engine Coolant

This coolant is premixed with 50% antifreeze and 50% water. Do not add any
straight antifreeze or water.

We recommend you check the engine coolant level every time you refuel. Check the
reserve tank first. If it is completely empty, also check the coolant level in the
radiator. Add the engine coolant accordingly.

1. Check the amount of coolant in the reserve

tank.

Specified coolant: Honda Long Life Antifreeze/Coolant Type 2

■

Reserve Tank

Engine Coolant

NOTICE

If temperatures consistently below −22°F (−30°C) are
expected, the coolant mixture should be changed to
a higher concentration. Consult a dealer for more
information.

If Honda antifreeze/coolant is not available, you may
use another major brand non-silicate coolant as a
temporary replacement. Check that it is a high quality
coolant recommended for aluminum engines.
Continued use of any non-Honda coolant can result
in corrosion, causing the cooling system to
malfunction or fail. Have the cooling system flushed
and refilled with Honda antifreeze/coolant as soon as
possible.

Do not add rust inhibitors or other additives to your
vehicle’s coolant system. They may not be compatible
with the coolant or with the engine components.

Reserve
Tank

MAX

MIN

4-cylinder models

6-cylinder models

MIN

MAX

Reserve
Tank

479

Maintenance Under the Hood

Engine Coolant

Main

tenan

2. If the coolant level is below the MIN mark,

add the specified coolant until it reaches
the MAX mark.

3. Inspect the cooling system for leaks.

1. Make sure the engine and radiator are

cool.

2. Turn the radiator cap counterclockwise and

relieve any pressure in the coolant system.
Do not push the cap down when turning.

3. Push down and turn the radiator cap

counterclockwise to remove it.

4. The coolant level should be up to the base

of the filler neck. Add coolant if it is low.

5. Put the radiator cap back on, and tighten it

fully.

6. Pour coolant into the reserve tank until it

reaches the MAX mark. Put the cap back
on the reserve tank.

■

Radiator

Radiator

NOTICE

Pour the fluid slowly and carefully so you do not spill
any. Clean up any spills immediately; they can
damage components in the engine compartment.

WARNING

Removing the radiator cap while the
engine is hot can cause the coolant to spray
out, seriously scalding you.

Always let the engine and radiator cool
down before removing the radiator cap.

4-cylinder models

6-cylinder models

Radiator Cap

Content .. 28 29 30 31 ..
