Gauges and Displays

u

Driver Information Interface

*

128

In

strum

e

nt Pa

nel

Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada).

■

Adjusting the outside temperature display

Adjust the temperature reading up to ±5°F or ±3°C if the temperature reading
seems incorrect.
Use the driver information interface’s customized features to correct the
temperature.

2 Customized Features P. 133

Shows the instant fuel economy as a bar graph in mpg or l/100 km.

When the turbo charger is producing boost,
this meter shows the boost pressure.

■

Outside Temperature

■

Instant Fuel Economy

■

Turbo Meter

1

Outside Temperature

The temperature sensor is in the front bumper.
Road heat and exhaust from another vehicle can
affect the temperature reading when your vehicle
speed is less than 19 mph (30 km/h).

It may take several minutes for the display to be
updated after the temperature reading has stabilized.

1.5 L engine models

2.0 L engine models

Continued

129

uu

Gauges and Displays

u

Driver Information Interface

*

In

strum

e

nt Pa

nel

Shows you turn-by-turn driving directions to your destination linked with the
navigation system.

2 Refer to the Navigation System Manual

Shows the current audio information.

2 Audio System Basic Operation P. 237, 255

Shows the current mail information.

2 Bluetooth® HandsFreeLink®

*

 P. 407

Shows the current phone information.

2 Bluetooth® HandsFreeLink®

*

 P. 381, 407

■

Turn-by-Turn Directions

*

■

Audio

*

■

Mail

*

■

Phone

*

1

Turn-by-Turn Directions

*

You can select whether the turn-by-turn display
comes on or not during the route guidance.

2 Customized Features P. 133, 348

* Not available on all models

130

uu

Gauges and Displays

u

Driver Information Interface

*

In

strum

e

nt Pa

nel

Displays the strength (G) and direction of the load that is applied to the vehicle
during driving.

Displays the brake pressure in PSI when the brake is applied.

Displays the accelerator position in degrees of %.

Light up from left to right according to engine
speed.

■

G-Meter

*

■

Braking Pressure Meter

*

■

Accelerator Position Meter

*

■

Rev Indicators

*

Rev Indicators

* Not available on all models

Continued

131

uu

Gauges and Displays

u

Driver Information Interface

*

In

strum

e

nt Pa

nel

Measures the lap time, and displays the previously measured times, split time and
the fastest lap time.

■

Measuring LAP Time

1. Press the ENTER button to display the lap

time measurement screen.

2. Press the ENTER button to start

measurement.

3. Press the ENTER button again to stop

measurement.

u

To measure the time per lap, press the

/

 button at the completion of each

lap.

u

To return to the Stopwatch screen,
press the

 (Hang-up/back)

button.

■

Stopwatch

*

1

Stopwatch

*

Be sure to use this measurement function only where
and when it is safe to do so.

Lap time is displayed from 00:00.00 to 9:59:59.99.

 Button

3

ENTER Button

 Button

 Button

 (Hang-up/Back)

Button

 Button

4

3 4

* Not available on all models

132

uu

Gauges and Displays

u

Driver Information Interface

*

In

strum

e

nt Pa

nel

■

Checking/Clearing history

• To check history, press the

 button (when

lap time is not running) to change the
display, then press the

/

 button to

scroll through lap times.

u

A maximum of 20 lap times can be
stored at a time.

• To clear the history, press and hold the

/

 button when lap time is not running.

• To return to the lap time measurement

screen, press the

 button.

• To return to the Stopwatch screen, press

the

 (Hang-up/back) button.

Press
Button

Press
Button

3 4

3

4

Continued

133

uu

Gauges and Displays

u

Driver Information Interface

*

In

strum

e

nt Pa

nel

Use the driver information interface to customize certain features.

■

How to customize

Select the Vehicle Settings screen by pressing the

 button while the ignition

switch is in ON

(

w

*1

, and the vehicle is at a complete stop, and the shift lever is in

(

P (continuously variable transmission), and the parking brake is set (manual

transmission). Select Vehicle Settings, then press the ENTER button.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Customized Features

Models with color audio system

1

Customized Features

To customize other features, press the

 /



button.

2 List of customizable options P. 137
2 Example of customization settings P. 142

When you customize settings:

Shift to

(

P.

Set the parking brake.

3

4

Models with continuously variable transmission

Models with manual transmission

ENTER Button
Press to set your selection.

 Button

Press to go to Vehicle Menu.

 Button

Press to scroll upwards.

3

 Button

Press to scroll downwards.

4

Driver information interface:
Goes to Vehicle Settings.

134

uu

Gauges and Displays

u

Driver Information Interface

*

In

strum

e

nt Pa

nel

■

Customization flow

Press the

 button.

ENTER

Vehicle Settings

“Trip A” Reset Timing

Language Selection

Adjust Outside Temp. Display

3

4

TPMS Calibration

*

ENTER

“Trip B” Reset Timing

Fuel Efficiency Backlight

*

3

4

ACC Forward Vehicle Detect Beep

*

3

4

Tachometer

ENTER

Forward Collision Warning Distance

*

3

4

3

4

Lane Keeping Assist Suspend Beep

*

Road Departure Mitigation Setting

*

Adjust Alarm Volume

Speed/Distance Units

3

4

ENTER

Driver Assist System Setup

Meter Setup

Rev Match System

*

Shift Up Backlight

*

Gear Position Display

*

* Not available on all models

135

uu

Gauges and Displays

u

Driver Information Interface

*

Continued

In

strum

e

nt Pa

nel

ENTER

Keyless Access Light Flash

Keyless Access Beep

3

4

Door Unlock Mode

Keyless Access Setup

*

3

4

Remote Start System ON/OFF

*

* Not available on all models

136

uu

Gauges and Displays

u

Driver Information Interface

*

In

strum

e

nt Pa

nel

Exit

3

4

3

4

3

4

Maintenance Reset

Default All

3

4

ENTER

3

4

3

4

Key And Remote Unlock Mode

Auto Door Lock

Auto Door Unlock

Keyless Lock Answer Back

Security Relock Timer

Interior Light Dimming Time

Headlight Auto OFF Timer

Auto Light Sensitivity

3

4

3

4

Auto Headlight ON With Wiper ON

ENTER

ENTER

Auto Interior Illumination Sensitivity

Lighting Setup

Door Setup

Walk Away Auto Lock

*

* Not available on all models

137

uu

Gauges and Displays

u

Driver Information Interface

*

Continued

In

strum

e

nt Pa

nel

■

List of customizable options

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

TPMS
Calibration

*

—

Calibrates the TPMS.

Cancel/Calibrate

Driver Assist
System
Setup

Forward Collision
Warning Distance

Changes the distance at which CMBS

TM

 alerts.

Long/Normal

*1

/Short

ACC Forward Vehicle
Detect Beep

Causes the system to beep when the system detects a
vehicle, or when the vehicle goes out of ACC range.

ON/OFF

*1

Road Departure
Mitigation Setting

Changes the setting for the road departure
mitigation system.

Normal

*1

/Wide/Warning

Only

Lane Keeping Assist
Suspend Beep

Causes the system to beep when the LKAS is
suspended.

ON/OFF

*1

Rev Match System

*

Turns the Rev Match System feature on and off.

ON

*1

/OFF

* Not available on all models

138

uu

Gauges and Displays

u

Driver Information Interface

*

In

strum

e

nt Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Meter Setup

Language Selection

Changes the displayed language.

English

*1

/Français/Español

Adjust Outside Temp.
Display

Adjusts the temperature reading by a few degrees.

-5°F ~ ±0°F

*1

 ~ +5°F

Gear Position Display

*

Turns the gear position display feature on and off.

ON

*1

/OFF

“Trip A” Reset Timing

Changes the setting of how to reset trip meter A,
average fuel economy A, average speed A, and
elapsed time A.

When Refueled/IGN OFF/
Manually Reset

*1

“Trip B” Reset Timing

Changes the setting of how to reset trip meter B,
average fuel economy B, average speed B, and
elapsed time B.

When Refueled/IGN OFF/
Manually Reset

*1

Adjust Alarm Volume

Changes the alarm volume, such as buzzers,
warnings, turn signal sound, and so on.

High/Mid

*1

/Low

Shift Up Backlight

*

Turns the shift up backlight blink feature on and off.

ON

*1

/OFF

Fuel Efficiency Backlight

*

Turns the ambient meter feature on and off.

ON

*1

/OFF

Speed/Distance Units

Selects the trip computer units.

mph∙miles

*1

/km/h∙km

Tachometer

Selects whether the tachometer is displayed on the
driver information interface.

ON

*1

/OFF

* Not available on all models

139

uu

Gauges and Displays

u

Driver Information Interface

*

Continued

In

strum

e

nt Pa

nel

*1: Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Keyless
Access
Setup

*

Keyless Access Beep

Causes the beeper to sound when you unlock/lock
the doors.

ON

*1

/OFF

Keyless Access Light
Flash

Causes some exterior lights to flash when you
unlock/lock the doors.

ON

*1

/OFF

Door Unlock Mode

Changes which doors unlock when you grab the
driver’s door handle.

Driver Door Only

*1

/All Door

Remote Start System
ON/OFF

*

Turns the remote engine start feature on and off.

ON

*1

/OFF

Lighting
Setup

Interior Light Dimming
Time

Changes the length of time the interior lights stay on
after you close the doors.

60sec/30sec

*1

/15sec

Headlight Auto OFF
Timer

Changes the length of time the exterior lights stay
on after you close the driver’s door.

60sec/30sec/15sec

*1

/0sec

Auto Light Sensitivity

Changes the timing for the headlights to come on.

Max/High/Mid

*1

/Low/Min

Auto Interior
Illumination Sensitivity

Changes the sensitivity of the brightness of the
instrument panel when the headlight switch is in the
AUTO position.

Max/High/Mid

*1

/Low/Min

Auto Headlight ON With
Wiper ON

Changes the settings for the wiper operation when
the headlights automatically come on while the
headlight switch is in the AUTO position.

ON

*1

/OFF

* Not available on all models

140

uu

Gauges and Displays

u

Driver Information Interface

*

In

strum

e

nt Pa

nel

*1: Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Door Setup

Auto Door Lock

Changes the setting for when the doors
automatically lock.

With Vehicle Speed

*1

/Shift

from P/OFF

With Vehicle Speed

*1

/OFF

Auto Door Unlock

Changes the setting for when the doors
automatically unlock.

When Driver’s Door Opens

*1

/

When Shifting Into Park/
When Ignition Switched
OFF/OFF

When Driver’s Door Opens

*1

/

When Ignition Switched
OFF/OFF

Key And Remote Unlock
Mode

Sets up either the driver’s door or all doors to unlock
on the first operation of the remote or ignition key.

Driver Door

*1

/ All Doors

Continuously variable
transmission models

Manual transmission models

Continuously variable
transmission models

Manual transmission models

141

uu

Gauges and Displays

u

Driver Information Interface

*

Continued

In

strum

e

nt Pa

nel

*1: Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Door Setup

Keyless Lock Answer
Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

ON

*1

/OFF

Security Relock Timer

Changes the time it takes for the doors to relock and
the security system to set after you unlock the
vehicle without opening any door.

90sec/60sec/30sec

*1

Walk Away Auto Lock

*

Changes the settings for the automatic locking the
doors when you walk away from the vehicle while
carrying the smart entry remote.

ON/OFF

*1

Maintenance
Reset

—

Cancels/Resets the engine oil life display when you
have performed the maintenance service.

Cancel/All Due Items

Default All

—

Cancels/Resets all the customized settings as
default.

Cancel/Set

* Not available on all models

142

uu

Gauges and Displays

u

Driver Information Interface

*

In

strum

e

nt Pa

nel

■

Example of customization settings

The steps for changing the “Trip A” Reset Timing setting to When Refueled are
shown below. The default setting for “Trip A” Reset Timing is Manually Reset.

1. Press the

 button to select Vehicle

Settings, then press the ENTER button.

2. Press the

 /

 button until Meter Setup

appears on the display.

3. Press the ENTER button.

u

Language Selection appears first in the
display.

3

4

143

uu

Gauges and Displays

u

Driver Information Interface

*

In

strum

e

nt Pa

nel

4. Press

the

/

button

until

“Trip A”

Reset Timing appears on the display, then
press the ENTER button.

u

The display switches to the
customization setup screen, where you
can select When Refueled, IGN OFF,
Manually Reset, or Exit.

5. Press the

 /

 button and select When

Refueled, then press the ENTER button.

u

The When Refueled Setup screen
appears, then the display returns to the
customization menu screen.

6. Press the

 /

 button until Exit appears

on the display, then press the ENTER
button.

7. Repeat Step 6 until you return to the

normal screen.

3

4

3

4

3

4
