Honda Civic Hatchback (2018 year). Instruction - part 8

112

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when ACC has been automatically
canceled.

●

You can resume the set speed after the condition that
caused ACC to cancel improves. Press the RES/+ button.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 479

2 Adaptive Cruise Control (ACC)

*

 P. 495

●

Flashes when the system senses a likely collision with
a vehicle in front of you.

●

Take the appropriate means to prevent a collision (apply
the brakes, change lanes, etc.)

2 Collision Mitigation Braking System

TM

 (CMBS

TM

)

*



P. 541

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 479

2 Adaptive Cruise Control (ACC)

*

 P. 495

Models with ACC

* Not available on all models

113

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the distance between your vehicle
and the vehicle ahead of you is too close while ACC
is in operation.

●

ACC has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 479

2 Adaptive Cruise Control (ACC)

*

 P. 495

●

Appears when pressing the –/SET button while the
distance between your vehicle and the vehicle
ahead of you is too close.

●

ACC cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 479

2 Adaptive Cruise Control (ACC)

*

 P. 495

●

Appears when the vehicle speed slows down to 22
mph (35 km/h) and the vehicle ahead of you goes
out of the ACC range while ACC is in operation.

●

ACC has been automatically canceled.

2 Adaptive Cruise Control (ACC)

*

 P. 495

●

Appears when pressing the RES/+ or –/SET button
down while the vehicle speed is less than 25 mph
(40 km/h) and the vehicle ahead of you goes out of
the ACC range.

●

ACC cannot be set.

2 Adaptive Cruise Control (ACC)

*

 P. 495

●

Appears when the driver’s seat belt is unfastened
while your vehicle is automatically stopped by ACC.

●

ACC has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 479

* Not available on all models

114

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when pressing the –/SET button while the
driver’s seat belt is unfastened.

●

ACC cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 479

●

Appears when the shift lever is moved into any
position other than

(

D or

(

S while ACC is in

operation.

●

ACC has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 479

●

Appears when pressing the –/SET button while the
shift lever is in any position other than

(

D or

(

S.

●

ACC cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 479

●

Appears when the vehicle is stopped on a very steep
slope while ACC is in operation.

●

ACC has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 479

●

Appears when pressing the –/SET button while the
vehicle is stopped on a very steep slope.

●

ACC cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 479

* Not available on all models

115

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the parking brake is applied
automatically while ACC is in operation.

●

ACC has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 479

2 Parking Brake P. 532

●

Appears when pressing the –/SET button while the
parking brake is applied.

●

ACC cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 479

2 Parking Brake P. 532

●

Appears when pressing the –/SET button while the
vehicle is moving and the brake pedal is depressed.

●

ACC cannot be set.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 479

●

Appears if ACC is canceled while your vehicle is
automatically stopped by ACC.

●

Immediately depress the brake pedal.

●

Appears if the VSA® or traction control function
operates while ACC is in operation.

●

ACC has been automatically canceled.

2 Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 479

2 Adaptive Cruise Control (ACC)

*

 P. 495

* Not available on all models

116

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the vehicle is driving out of a detected
lane. The steering wheel vibrates rapidly.

●

Keep the vehicle within the lane you are driving.

2 Lane Keeping Assist System (LKAS)

*

 P. 513

●

Appears when the vehicle is driving out of a detected
lane.

- The steering wheel vibrates rapidly when the

vehicle is drifting out of a detected lane.

- The steering wheel vibrates rapidly when the

vehicle is drifting out of a detected lane. The system
also steers the vehicle to help you remain within
your driving lane.

●

Keep the vehicle within the lane you are driving.

2 Road Departure Mitigation (RDM) System

*

 P. 509

●

You can change the setting for the road departure
mitigation system. Normal, Wide, and Warning Only
can be selected.

2 Customized Features P. 133, 348

●

Blinks when you fail to steer the vehicle. The beeper
sounds simultaneously if selected by customization.

●

Operate the steering wheel to resume the LKAS.

●

Appears when the LKAS is in operation, or the LKAS
button is pressed, but there is a problem with a
system related to the LKAS. The LKAS cancels
automatically. The beeper sounds simultaneously if
selected by customization.

●

If any other system indicators come on, such as the VSA®,
ABS and brake system, take appropriate action.

2 Indicators P. 78

Models with LKAS

Lane Keeping Assist System (LKAS)

Road Departure Mitigation (RDM) System

When you selected Warning Only

When you selected Normal or Wide

* Not available on all models

117

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when you unlock and open the driver’s
door while the engine is running by one-way smart
entry remote.

2 Remote Engine Start with Vehicle Feedback

*

 P. 454

Models with remote engine starter

* Not available on all models

118

In

strum

e

nt Pa

nel

Gauges and Displays

Gauges

Gauges include the speedometer, tachometer, fuel gauge, and related indicators.
They are displayed when the ignition switch is in ON

(

w

*1

.

Displays your driving speed in mph or km/h.

Shows the number of engine revolutions per minute.

Displays the amount of fuel left in the fuel tank.

Displays the temperature of the engine coolant.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Speedometer

■

Tachometer

■

Fuel Gauge

■

Temperature Gauge

1

Gauges

Press and hold the km/mile change knob until you
hear a beep. The speedometer reading and the
displayed measurements switch between mph and
km/h.

Press the

 (display/information) button

repeatedly until the

 icon is shown on the driver

information interface. Press ENTER, then press and
hold it again. The speedometer reading and the
displayed measurements will switch between mph
and km/h.

Models with information display

Models with driver information interface

1

Fuel Gauge

NOTICE

You should refuel when the reading approaches

.

Running out of fuel can cause the engine to misfire,
damaging the catalytic converter.

The actual amount of remaining fuel may differ from
the fuel gauge reading.

E

1

Temperature Gauge

NOTICE

Driving with the temperature gauge pointer in the
upper zone can cause serious engine damage. Pull
safely to the side of the road and allow engine
temperature to return to normal.

2 Overheating P. 659

119

uu

Gauges and Displays

u

Gauges

In

strum

e

nt Pa

nel

Blinks when the tachometer reading
approaches the red zone.

■

Shift Up Backlight

*

1

Shift Up Backlight

*

You can use the customized features to turn the shift
up backlight blink feature on and off.

2 Customized Features P. 133, 348

Shift Up Backlight

* Not available on all models

120

uu

Gauges and Displays

u

Information Display

*

In

strum

e

nt Pa

nel

Information Display

*

The information display shows the odometer, trip meter, engine oil life and
maintenance service item codes, and other gauges.

Press the

 (TRIP) knob to change the display.

Shows the total number of miles or kilometers that your vehicle has accumulated.

Shows the total number of miles or kilometers driven since the last reset. Meters A
and B can be used to measure two separate trips.

■

Resetting a trip meter

To reset a trip meter, display it, then press and hold the

 knob. The trip meter is

reset to 0.0.

■

Switching the Display

1

Switching the Display

Each time you press the

 knob, the information

display changes as follows:

Instant Fuel Economy,
Odometer, Trip Meter A,
Outside Temperature

Instant Fuel Economy,
Range, Trip Meter A,
Outside Temperature

Engine Oil Life

Instant Fuel Economy, Average
Fuel Economy A, Trip Meter A,
Outside Temperature

Instant Fuel Economy, Average
Fuel Economy B, Trip Meter B,
Outside Temperature

■

Odometer

■

Trip Meter

 (TRIP)

Knob

1

Trip Meter

Switch between trip meter A and trip meter B by
pressing the

 knob.

* Not available on all models

121

uu

Gauges and Displays

u

Information Display

*

Continued

In

strum

e

nt Pa

nel

Shows the estimated average fuel economy of each trip meter in mpg or l/100 km.
The display is updated at set intervals. When a trip meter is reset, the average fuel
economy is also reset.

Shows the instant fuel economy as a bar graph in mpg or l/100km.

Shows the remaining oil life and Maintenance Minder

TM

.

2 Maintenance Minder

TM

 P. 563

Shows the estimated distance you can travel on the remaining fuel. This distance is
estimated from the fuel economy of your previous trips.

■

Average Fuel Economy

■

Instant Fuel Economy Gauge

■

Engine Oil Life

■

Range

uu

Gauges and Displays

u

Information Display

*

122

In

strum

e

nt Pa

nel

Shows the outside temperature in Fahrenheit.

■

Adjusting the outside temperature indicator

Adjust the temperature reading up to ± 5°F if the temperature reading seems
incorrect.
1. Turn the ignition switch to ON

(

w

*1

.

2. Press and hold the

 (TRIP) knob for 10 seconds or more while the outside

temperature is shown on the information display.

u

The information display goes into temperature adjustment mode. The display
starts showing from -5°F to +5°F.

3. Release the

 knob when the right adjustment amount is shown.

u

The adjustment is complete.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Outside Temperature

1

Outside Temperature

The temperature sensor is in the front bumper.
Road heat and exhaust from another vehicle can
affect the temperature reading when your vehicle
speed is less than 19 mph (30 km/h).

It may take several minutes for the display to be
updated after the temperature reading has stabilized.

123

uu

Gauges and Displays

u

Driver Information Interface

*

Continued

In

strum

e

nt Pa

nel

Driver Information Interface

*

The driver information interface shows the odometer, trip meter, outside
temperature indicator, and other gauges.
It also displays important messages such as warnings and other helpful information.

* Not available on all models

124

uu

Gauges and Displays

u

Driver Information Interface

*

In

strum

e

nt Pa

nel

■

Main displays

Press the

 (display/information) button and press

 or

 to change the

display. Press ENTER to see detailed information.

*1:You can add the contents using the audio/information screen.

■

Switching the Display

1

Switching the Display

You can edit, add, or delete the meter contents using
the audio/information screen.

2 Customizing the Meter P. 260

 (Display/

Information) Button

Press ,

,

or .
Press ENTER.

Range & Fuel

Turbo Meter

Navigation

*

 &

Compass

*

Maintenance
Minder

TM

Customize

*

Audio

Phone

Speed Unit &
Disp OFF

Warning
Messages

Average Speed &
Elapsed Time

Mail

*

Optional contents

*1

:

1.5 L engine models

* Not available on all models

125

uu

Gauges and Displays

u

Driver Information Interface

*

Continued

In

strum

e

nt Pa

nel

*1:You can add the contents using the audio/information screen.

Accelerator
Position/Braking
Pressure Meter

Turbo Meter

Rev Indicators

G-Meter

Stopwatch

Range &
Fuel

Phone

Speed Unit &
Disp OFF

Warning
Messages

Average Speed
& Elapsed Time

Mail

*

Optional contents

*1

:

2.0 L engine models

Navigation

*



& Compass

*

Audio

Customize

*

Maintenance
Minder

TM

Press ,

,

or .
Press ENTER.

 (Display/

Information) Button

* Not available on all models

uu

Gauges and Displays

u

Driver Information Interface

*

126

In

strum

e

nt Pa

nel

■

Trip computer

Press the

 (TRIP) knob to change the display.

Shows the total number of miles or kilometers that your vehicle has accumulated.

Shows the total number of miles or kilometers driven since the last reset. Meters A
and B can be used to measure two separate trips.

■

Resetting a trip meter

To reset a trip meter, display it, then press and hold the

 knob. The trip meter is

reset to 0.0.

■

Odometer

■

Trip Meter

Menu

Menu

Menu

Odometer
Outside temperature

Trip A

Trip B

 (TRIP)

Knob

1

Trip Meter

Switch between trip meter A and trip meter B by
pressing the

 knob.

Continued

127

uu

Gauges and Displays

u

Driver Information Interface

*

In

strum

e

nt Pa

nel

Shows the estimated average fuel economy of each trip meter in mpg or l/100 km.
The display is updated at set intervals. When a trip meter is reset, the average fuel
economy is also reset.

Shows the estimated distance you can travel on the remaining fuel. This distance is
estimated from the fuel economy of your previous trips.

Shows the time elapsed since Trip A or Trip B was reset.

Shows the average speed in mph or km/h since Trip A or Trip B was reset.

Shows the remaining oil life and Maintenance Minder

TM

.

2 Maintenance Minder

TM

 P. 563

■

Average Fuel Economy

■

Range

■

Elapsed Time

*

■

Average Speed

*

■

Engine Oil Life

1

Average Fuel Economy

You can change when to reset the average fuel
economy.

2 Customized Features P. 133, 348

1

Elapsed Time

*

You can change when to reset the elapsed time.

2 Customized Features P. 133, 348

1

Average Speed

*

You can change when to reset the average speed.

2 Customized Features P. 133, 348

* Not available on all models
