Instrument Panel

This chapter describes the buttons, indicators, and gauges that are used while driving.

Indicators ............................................ 82

Driver Information Interface Warning and

Information Messages.................... 108

Gauges and Displays

Gauges............................................ 133
Driver Information Interface ............. 135
Head-Up Display

*

............................ 157

* Not available on all models

82

In

strum

e

nt Pa

nel

Indicators

Deceleration Paddle
Selector Indicator



P. 90

Parking Brake and
Brake System Indicator
(Red)

Parking Brake and
Brake System Indicator
(Amber)

U.S.

Canada

U.S.

Canada

Automatic Brake Hold
System Indicator

Automatic Brake Hold
Indicator

U.S.

Canada

*1 : When you set the power mode to ON, these indicators come on to indicate that system checks are being performed. They go off a few seconds later or after the power

system has started. If an indicator does not come on or turn off, there may be a malfunction in the corresponding system. To resolve the issue, follow the instructions in
the owner’s manual.



P. 83

*1

Malfunction Indicator
Lamp

12-Volt Battery
Charging System
Indicator

Anti-lock Brake System
(ABS) Indicator

Seat Belt Reminder
Indicator

Low Fuel Indicator

Vehicle Stability Assist

®



(VSA

®

) System Indicator

Vehicle Stability Assist

®



(VSA

®

) OFF Indicator

Supplemental Restraint
System Indicator

Auto High-Beam
Indicator

Low Tire Pressure/TPMS
Indicator

Electric Power Steering
(EPS) System Indicator

Turn Signal and Hazard
Warning Indicators

Lights On Indicator

High Beam Indicator

Fog Light Indicator

*

ECON Mode Indicator

System Message
Indicator

SPORT Mode Indicator

Adaptive Cruise Control
(ACC) with Low Speed
Follow (LSF) Indicator
(Amber)

Lane Keeping Assist
System (LKAS)
Indicator (Amber)

Safety Support
Indicator (Amber)

Safety Support
Indicator (Green/Gray)



P. 84



P. 88



P. 88



P. 89



P. 90

*1

*1

*1

*1



P. 96

*1

*1

Shift Position Indicator



P. 90

Transmission System
Indicator



P. 91

READY Indicator



P. 87

POWER SYSTEM
Indicator



P. 86



P. 92



P. 92



P. 93



P. 93



P. 93



P. 94

*1

*1

*1

*1



P. 95

*1



P. 95



P. 97



P. 102

*1



P. 97



P. 97



P. 100



P. 97

Immobilizer System
Indicator



P. 98

Security System Alarm
Indicator



P. 98



P. 99



P. 101



P. 103



P. 104



P. 107

*1

Adaptive Cruise Control
(ACC) with Low Speed
Follow (LSF) Indicator
(Green)



P. 102

Lane Keeping Assist
System (LKAS)
Indicator (Green)



P. 103

*1

*1

EV Indicator



P. 87

*1

EV Mode Indicator



P. 87

*1

*1

* Not available on all models

83

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Parking Brake
and Brake
System
Indicator (Red)

• Comes on when the parking brake

is applied, and goes off when it is
released.

• Comes on when the brake fluid

level is low.

• Comes on if there is a problem with

the brake system.

• The beeper sounds and the

indicator comes on if you drive with
the parking brake not fully released.

• Comes on for about 30 seconds

when you pull or push the electric
parking brake switch when the
power mode is in ACCESSORY or
VEHICLE OFF.

• Stays on for about 30 seconds

when you set the power mode to
VEHICLE OFF while the electric
parking brake is set.

• Comes on while driving - Make sure

the parking brake is released. Check the
brake fluid level.

2 What to do when the indicator

comes on while driving P. 648

• Comes on along with the brake

system indicator (amber) - Immediately
stop in a safe place. Contact a dealer for
repair. The brake pedal becomes harder to
operate. Depress the pedal further than
you normally do.

• Comes on along with the ABS

indicator - Have your vehicle checked by
a dealer.

2 If the Brake System Indicator (Red)

Comes On or Blinks P. 648

• Blinks and the brake system indicator

(amber) comes on at the same time -
There is a problem with the electric
parking brake system. The parking brake
may not be set.
Avoid using the parking brake and have
your vehicle checked by a dealer
immediately.

2 If the Brake System Indicator (Red)

Comes On or Blinks at the Same Time
When the Brake System Indicator
(Amber) Comes On P. 649

U.S.

Canada

(Red)

84

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Parking Brake
and Brake
System
Indicator
(Amber)

• Comes on if there is a problem with

a system related to braking other
than the conventional brake
system.

• Comes on if there is a problem with

the cooperative control with
regenerative braking, the electric
servo brake system, or the hill start
assist system.

• Comes on if there is a problem with

the electric parking brake system.

• Stays on constantly - Have your vehicle

checked by a dealer.

• Comes on while driving - Avoid using

the parking brake and have your vehicle
checked by a dealer immediately.

• With this indicator on, your vehicle still

has normal braking ability.

• Comes on if there is a problem with

the radar sensor.

• Indicator may come on temporarily

when the Maximum Load Limit is
exceeded.

• Make sure the total load is within the

Maximum Load Limit.

2 Maximum Load Limit P. 455

U.S.

Canada

(Amber)

U.S.

Canada

85

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Parking Brake
and Brake
System
Indicator
(Amber)

• Comes on if there is a problem with

the automatic brake hold system.

2 Automatic Brake Hold P. 545

U.S.

Canada

(Amber)

U.S.

Canada

86

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

POWER
SYSTEM
Indicator

• Comes on if there is a problem with

the electric vehicle system.

• Comes on when the High Voltage

battery temperature becomes high
while the battery is being charged.

• Have your vehicle checked by a dealer.

87

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

READY
Indicator

• Comes on when the vehicle is ready

to drive.

2 Turning on the Power P. 458

EV Indicator

• Comes on when the vehicle is

moved by the motor, and the
engine is not operating.

—

—

EV Mode
Indicator

• Comes on when the vehicle is in EV

mode.

2 SPORT HYBRID i-MMD (intelligent

Multi Mode Drive) P. 10

88

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Automatic
Brake Hold
System
Indicator

• Comes on when the automatic

brake hold system is on.

2 Automatic Brake Hold P. 545

Automatic
Brake Hold
Indicator

• Comes on when the automatic

brake hold is activated.

2 Automatic Brake Hold P. 545

—

U.S.

Canada

89

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Malfunction
Indicator Lamp

• After you have set the power mode

to ON, the vehicle performs system
checks. However, if the readiness
codes have not been set by that
time, this indicator will blink five
times and then go off.

• Comes on if there is a problem with

the emissions control system.

• Blinks when a misfire in the

engine’s cylinders is detected.

• Readiness codes are part of the on board

diagnostics for the emissions control
systems.

2 Testing of Readiness Codes P. 667

• Comes on while driving - Have your

vehicle checked by a dealer.

• Blinks while driving - Stop in a safe

place where there are no flammable
objects. Stop the power system for 10
minutes or more, and wait for it to cool
down. Then, take your vehicle to a dealer.

2 If the Malfunction Indicator Lamp

Comes On or Blinks P. 647

90

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

12-Volt Battery
Charging
System
Indicator

• Comes on when the 12-volt battery

is not charging.

• Stop in a safe place and have your vehicle

checked by a dealer immediately.

2 If the 12-Volt Battery Charging

System Indicator Comes On P. 646

Shift Position
Indicator

• Indicates the current shift position.

2 Shifting P. 465

—

Deceleration
Paddle Selector
Indicator

• Comes on when the selector is

pulled.

• Blinks when the effective of

deceleration does not change while
pulling the selector.

• Comes on with M when SPORT

mode is selected and pulling the
selector.

2 Deceleration Paddle Selector P. 472

—

91

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Transmission
System
Indicator

• The current shift position blinks if

the transmission system has a
problem.

• Blinks while driving - Avoid sudden

starts and acceleration, and have your
vehicle checked by a dealer immediately.

• The current shift position or all the

shift positions blink if there is a
problem with the transmission and
the vehicle is no longer able to run.

• Immediately park your car in a safe place.

2 Emergency Towing P. 657

• Have your vehicle checked by a dealer.

• The current shift position or all the

shift positions blink if there is a
problem with the transmission and
it is not possible to select

(

P.

• While the vehicle is stopped, apply the

parking brake.

• Have your vehicle checked by a dealer

immediately.

92

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Seat Belt
Reminder
Indicator

• Blinks and the beeper sounds for a

few seconds if you are not wearing
a seat belt when you set the power
mode to ON, then the indicator
comes on.

• If the front passenger is not

wearing a seat belt, the indicator
comes on a few seconds later.

• Blinks while driving if either you

and/or the front passenger has not
fastened a seat belt. The beeper
sounds and the indicator blinks at
regular intervals.

• The beeper stops and the indicator goes

off when you and the front passenger
fasten their seat belts.

• Stays on after you and/or the front

passenger has fastened the seat
belt(s) - A detection error may have
occurred in the sensor. Have your vehicle
checked by a dealer.

2 Seat Belt Reminder P. 43

Low Fuel
Indicator

• Comes on when the fuel reserve is

running low (approximately 1.6
U.S. gal./6.2 Liter left).

• Blinks if there is a problem with the

fuel gauge.

• Comes on - Refuel your vehicle as soon

as possible.

• Blinks - Have your vehicle checked by a

dealer.

93

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Anti-lock Brake
System (ABS)
Indicator

• Comes on if there is a problem with

the ABS.

• Stays on constantly - Have your vehicle

checked by a dealer. With this indicator
on, your vehicle still has normal braking
ability but no anti-lock function.

2 Anti-lock Brake System (ABS) P. 547

Supplemental
Restraint
System
Indicator

• Comes on if a problem with any of

the following is detected:

- Supplemental restraint system
- Knee airbag system
- Side airbag system
- Side curtain airbag system
- Seat belt tensioner

• Stays on constantly - Have your vehicle

checked by a dealer.

Auto High-
Beam Indicator

• Comes on when all the operating

conditions of the auto high-beam
are met.

2 Auto High-Beam P. 195

—

94

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Vehicle Stability
Assist® (VSA®)
System
Indicator

●

Blinks when VSA® is active.

●

Comes on if there is a problem with
the VSA® system.

●

Stays on constantly - Have your vehicle
checked by a dealer.

2 Vehicle Stability Assist® (VSA®), aka

Electronic Stability Control (ESC),
System P. 477

●

Comes on if the VSA® system is
deactivated temporarily after the
12-volt battery has been
disconnected, then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

95

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Vehicle Stability
Assist® (VSA®)
OFF Indicator

• Comes on when you partially

disable VSA®.

2 VSA® On and Off P. 478

• Comes on if the VSA® system is

deactivated temporarily after the
12-volt battery has been
disconnected, then re-connected.

• Drive a short distance at more than 12

mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

Electric Power
Steering (EPS)
System
Indicator

• Comes on if there is a problem with

the EPS system.

• Stays on constantly - Have your vehicle

checked by a dealer.

2 If the Electric Power Steering (EPS)

System Indicator Comes On P. 650
