When Driving

Shifting

432

Driving

Use the paddle shifters to change between 1st and 7th speeds without removing
your hands from the steering wheel. The transmission switches to the 7-speed
manual shift mode when you pull a paddle shifter while driving. This mode is useful
when engine braking is needed.

■

When the shift lever is in

(

The shift mode goes into the 7-speed manual shift mode temporarily, and the
number is displayed in the shift indicator.
The 7-speed manual shift mode is canceled automatically if you drive at constant
speed or accelerate, and the number in the shift indicator goes off.
You can cancel this mode by pulling the

(

+ paddle shifter for a few seconds.

The 7-speed manual shift mode is especially useful when reducing the vehicle speed
temporarily before making a turn.

■

When the shift lever is in

(

The shift mode goes into the 7-speed manual shift mode. The M indicator and the
speed number are displayed in the shift indicator. As the vehicle speed slows down,
the transmission automatically shifts down accordingly. When the vehicle comes to
a stop, it automatically shifts down into 1st.

If the vehicle speed increases and the engine speed reaches near the tachometer’s
red zone, the transmission automatically shifts up.

You can only pull away in 1st speed.

When canceling the 7-speed manual shift mode, move the shift lever from

(

S to

(

D. When the 7-speed manual shift mode is canceled, the M indicator and shift

indicator go off.

■

7-Speed Manual Shift Mode

7-Speed Manual Shift Mode

To improve fuel economy, the transmission may shift
up to a higher speed than the seventh under certain
circumstances. In this case, the number in the shift
indicator remains as 7.

In the 7-speed manual shift mode, the transmission
shifts up or down by operating either paddle shifter
under the following conditions:
Shift Up: The engine speed reaches the lowest
threshold of the higher speed position.
Shift Down: The engine speed reaches the highest
threshold of the lower speed position.

When the engine speed reaches near the
tachometer’s red zone, the transmission shifts up
automatically.
When the engine speed reaches the lowest threshold
of the selected speed position, the transmission shifts
down automatically.

Operating the paddle shifters on slippery surfaces
may cause the tires to lock up. In this case, the 7-
speed manual shift mode is canceled and goes back
to the normal D driving mode.

433

When Driving

Shifting

Driving

■

7-Speed Manual Shift Mode Operation

7-Speed Manual Shift Mode Operation

Each paddle shift operation makes a single speed
change.
To change continuously, release the paddle shifter
before pulling it again for the next speed.

Recommended Shift Points
Use this table as a guideline to help increase fuel
efficiency and reduce emissions.

The shift indicator blinks when you cannot shift up or
down. It indicates that your vehicle speed is not in its
allowable shifting range.
Slightly accelerate to shift up and decelerate to shift
down while the indicator is blinking.

Shift Up

Normal Acceleration

1 to 2

15 mph (24 km/h)

2 to 3

25 mph (40 km/h)

3 to 4

40 mph (64 km/h)

4 to 5

45 mph (72 km/h)

5 to 6

50 mph (80 km/h)

6 to 7

55 mph (89 km/h)

(

- Paddle Shifter

(Shift down)

(

+ Paddle Shifter

(Shift up)

Downshifting when pulling
the

(

- paddle shifter

(Changes to lower speed
number)

Upshifting when pulling
the

(

+ paddle shifter

(Changes to higher speed
number)

434

When Driving

Shifting

Driving

Shifting

Change the shift position in accordance with your driving needs.

■

Shift lever positions

Automatic transmission models

Shifting

You cannot change the power mode from ON to
VEHICLE OFF (LOCK) unless the shift lever is in

(

The vehicle may move forward very slightly even in

(

N while the engine is cold.

Depress the brake pedal firmly and, when necessary,
apply the parking brake.

When shifting gears in extremely low temperatures
(-22°F/-30°C), there may be a short delay before the
shift is indicated in the display. Always confirm you
are in the correct gear before driving.

Reverse
Used when reversing

Drive
Used for:

●

Normal driving (gears change between
1st and 6th automatically)

●

Temporally driving in the sequential
mode

Park
Used when parking or starting the engine

Neutral
Used when idling

Release Button

Drive (S)

●

Automatically changing gears between
1st and 5th (5th gear is used only at
high speed)

●

Used when towing a trailer in hilly
terrain

●

Used for driving in the sequential mode

Continued

435

When Driving

Shifting

Driving

■

Shift Lever Operation

Shift Lever Operation

NOTICE

When you change the shift lever from

(

D to

(

R and

vice versa, come to a complete stop and keep the
brake pedal depressed.
Operating the shift lever before the vehicle has come
to a complete standstill can damage the transmission.

Use the shift lever position indicator to check the
lever position before pulling away.

If the transmission indicator blinks when driving, in
any shift position, there is a problem with the
transmission.
Avoid sudden acceleration and have the transmission
checked by a dealer as soon as possible.

The fuel supply may be cut off if you drive at engine
speeds in or over the tachometer’s red zone (engine
speed limit). If this happens, you may experience a
slight jolt.

It may not be possible to operate the shift lever if the
brake pedal is applied while the shift lever release
button is held down.
Depress the brake pedal first.

Shift Lever Position Indicator

Tachometer’s red zone

Models with multi-information display

Models with information display

Shift Lever Position Indicator

Depress the brake pedal and press the shift lever release
button to shift.

Shift without pressing the shift lever release button.

Tachometer’s red zone

M (Sequential Shift Mode)
Indicator/Gear Position Indicator

Press the shift lever release button and shift.

436

When Driving

Shifting

Driving

Use the paddle shifters to change between 1st and 6th gears without removing your
hands from the steering wheel. The transmission will switch to the sequential shift
mode.

■

When the shift lever is in

(

The vehicle will go into the sequential shift mode momentarily, and the gear position
indicator will come on.

Once you start traveling at a constant speed, the sequential shift mode will
automatically switch off, and the gear position indicator will go off.

Hold the

(

+ paddle shifter for two seconds to return to normal drive.

■

When the shift lever is in

(

The vehicle will go into the sequential shift mode, and the M (sequential shift mode)
indicator and gear position indicator will come on. At speeds of 6 mph (10 km/h) or
less, the vehicle automatically shift down into 1st gear.

If you do not operate the paddle shifters while in 1st gear, the transmission
automatically shift up to 2nd gear. It does not shift automatically from 2nd through
6th gears.

You can only pull away in 1st and 2nd gear.

When canceling the sequential shift mode, move the shift lever from

(

S to

(

When the sequential shift mode is canceled, the M indicator and gear position
indicator go off.

■

Sequential Shift Mode

437

When Driving

Shifting

Driving

■

Second gear lock mode

If you pull the

(

+ paddle shifter while stopped or driving at 6 mph (10 km/h) or less,

the gear position will be locked in 2nd gear. This makes it easier to pull away on
slippery surfaces such as snow covered roads.

To cancel the 2nd gear lock mode, pull the

(

- paddle shifter, or move the shift lever

from

(

S to

(

■

Sequential Shift Mode Operation

Sequential Shift Mode Operation

Each paddle shift operation makes a single gear
change.
To change gear continuously, release the paddle
shifter before pulling it again for the next gear.

Recommended Shift Points
Use this table as a guideline to help increase fuel
efficiency and reduce emissions.

The gear position indicator blinks when you cannot
shift up or down. It indicates that your vehicle speed
is not in its allowable gear shifting range.
Slightly accelerate to shift up and decelerate to shift
down while the indicator is blinking.

Shift Up

Normal Acceleration

1st to 2nd

15 mph (24 km/h)

2nd to 3rd

25 mph (40 km/h)

3rd to 4th

40 mph (64 km/h)

4th to 5th

47 mph (76 km/h)

5th to 6th

52 mph (84 km/h)

(

- Paddle Shifter

(Shift down)

(

+ Paddle Shifter

(Shift up)

Downshifting when pulling
the

(

- paddle shifter

(Changes to a lower gear)

Upshifting when pulling
the

(

+ paddle shifter

(Changes to a higher gear)

438

When Driving

Shifting

Driving

Shifting

Fully depress the clutch pedal to operate the shift lever and change gears, then
slowly release the pedal.

Depress the clutch pedal, and pause for a few seconds before shifting into

(

R, or

shift into one of the forward gears for a moment. This stops the gears so they do not
“grind.”

■

Shift Lever Operation

Manual transmission models

Shifting

NOTICE

Do not shift to

(

R before the vehicle comes to a

complete stop.
Shifting to

(

R before stopping can damage the

transmission.

NOTICE

Before downshifting, make sure the engine will not
go into the tachometer's red zone. Should this occur,
it can severely damage your engine.

There is a metallic part on the shift lever. If you leave
the vehicle parked outside for a long time on a hot
day, be careful before moving the shift lever. Because
of heat, the shift lever may be extremely hot. If the
outside temperature is low, the shift lever may feel
cold.

Continued

439

When Driving

Shifting

Driving

When you are not shifting, do not rest your
foot on the clutch pedal. This can cause your
clutch to wear out faster.

Shifting

Recommended Shift Points
Driving in the highest gear that allows the engine to
run and accelerate smoothly helps to optimize fuel
economy and effective emissions control. The
following shift points are recommended:

Shift Up

Normal Acceleration

1st to 2nd

17 mph (27 km/h)

2nd to 3rd

29 mph (46 km/h)

3rd to 4th

37 mph (60 km/h)

4th to 5th

43 mph (69 km/h)

5th to 6th

49 mph (79 km/h)

Shift Up

Normal Acceleration

1st to 2nd

15 mph (24 km/h)

2nd to 3rd

25 mph (40 km/h)

3rd to 4th

40 mph (64 km/h)

4th to 5th

47 mph (76 km/h)

5th to 6th

52 mph (84 km/h)

4-cylinder models
U.S. LX-S and Canadian LX models

4-cylinder models
Except U.S. LX-S and Canadian LX models

When Driving

Shifting

440

Driving

The manual transmission has a lockout mechanism that stops you from accidentally
shifting into

(

R from a forward gear while the vehicle is moving above a certain

speed.

If you cannot shift to

(

R when the vehicle is stopped, do the following:

1. Depress the clutch pedal, move the shift

lever all the way to the left, and shift to

(

2. If you still cannot shift into

(

R, apply the

parking brake, and turn the ignition switch
to ACCESSORY

(

q or LOCK

(

3. Depress the clutch pedal and shift into

(

4. Keep depressing the clutch pedal and start

the engine.

Have the vehicle checked by a dealer if you
have to go through this procedure repeatedly.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Reverse Lockout

Shifting

If you exceed the maximum speed for the gear you
are in, the engine speed will enter into the
tachometer’s red zone. When this happens, you may
experience a slight jolt.

Shift Up

Normal Acceleration

1st to 2nd

17 mph (28 km/h)

2nd to 3rd

27 mph (44 km/h)

3rd to 4th

36 mph (57 km/h)

4th to 5th

41 mph (66 km/h)

5th to 6th

44 mph (71 km/h)

6-cylinder models

441

When Driving

ECON Button

Driving

ECON Button

The ECON button turns the ECON mode on and off.
The ECON mode helps you improve your fuel economy by adjusting the
performance of the engine, transmission, climate control system, and cruise control.

* Not available on all models

442

When Driving

Cruise Control

Driving

Cruise Control

Maintains a constant vehicle speed without having to keep your foot on the
accelerator. Use cruise control on freeways or open roads where you can travel at a
constant speed with little acceleration or deceleration.

Cruise Control

It may not be possible to maintain a constant speed
when driving uphill or downhill.

When not using cruise control:
Turn off cruise control by pressing the CRUISE

MAIN

button.

While in the ECON mode, it may take relatively more
time to accelerate to maintain the set speed.

When the engine speed slows down, try to
downshift.
You can maintain the set speed if you change gear
within five seconds.

WARNING

Improper use of the cruise control can lead
to a crash.

Use the cruise control only when traveling
on open highways in good weather.

Manual transmission models

When to use

■

Shift positions for cruise control:
In

(

D or

(

Always keep sufficient distance
between you and the vehicle in
front of you.

Automatic transmission/CVT models

■

Vehicle speed for cruise control:
Desired speed in a range above
roughly 25 mph (40 km/h) ~

How to use

CRUISE MAIN

/CRUISE MODE

is on in the instrument panel.
Cruise control is ready to use.

■

Press the CRUISE

MAIN

button on

the steering wheel.

Models without
ACC

Models with ACC

* Not available on all models

443

When Driving

Cruise Control

Continued

Driving

Take your foot off the pedal and press the –/SET button when you reach the desired
speed.

The moment you release the –/SET button, the set speed is fixed, and cruise control
begins. The CRUISE CONTROL indicator comes on.

During cruise control, Straight Driving Assist Function is activated. This control
function is an EPS function and it helps reduce the steering effort to keep the
steering angle on a straight road with cants.

■

To Set the Vehicle Speed

–/SET Button

On when cruise
control begins

Press and release

Models without
ACC

Models with ACC

Models without adaptive cruise control

When Driving

Cruise Control

444

Driving

Increase or decrease the vehicle speed using the RES/+ or –/SET buttons on the
steering wheel.

• Each time you press the button, the vehicle speed is increased or decreased by

about 1 mph (1.6 km/h).

• If you keep the button pressed, the vehicle speed increases or decreases until you

release it. This speed is then set.

To cancel cruise control, do any of the
following:
• Press the CANCEL button.
• Press the CRUISE

/MAIN

button.

• Depress the brake pedal.
• Depress the clutch pedal for five seconds or

more.

The CRUISE CONTROL indicator goes off.

■

To Adjust the Vehicle Speed

To Adjust the Vehicle Speed

You can set the vehicle speed using the –/SET button
on the steering wheel when adjusting the speed with
the accelerator and brake pedals.

■

To Cancel

To decrease speed

To increase speed

To Cancel

Resuming the prior set speed:
After cruise control has been canceled, you can still
resume the prior set speed by pressing the RES/+
button while driving at a speed of at least 25 mph
(40 km/h) or more.

You cannot set or resume in the following situations:

•

When vehicle speed is less than 25 mph (40 km/h)

•

When the CRUISE

/MAIN

button is turned off

At vehicle speeds of 22 mph (35 km/h) or less, cruise
control is canceled automatically.

CRUISE

MAIN

Button

CANCEL
Button

* Not available on all models

445

When Driving

Front Sensor Camera

Continued

Driving

Front Sensor Camera

The camera, used in systems such as LKAS, RDM, ACC, and CMBS

, is designed to

detect an object that triggers any of the systems to operate its functions.

This camera is located behind the rearview
mirror.

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing
system to shut off, when parking, find a shady
area or face the front of the vehicle away from
the sun. If you use a reflective sun shade, do
not allow it to cover the camera housing.
Covering the camera can concentrate heat on
it.

■

Camera Location and Handling Tips

Front Sensor Camera

Never apply a film or attach any objects to the
windshield, the hood, or the front grill that could
obstruct the camera’s field of vision and cause the
system to operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Honda replacement windshield. Making
even minor repairs within the camera’s field of vision
or installing an aftermarket replacement windshield
may also cause the system to operate abnormally.
After replacing the windshield, have a dealer
recalibrate the camera. Proper calibration of the
camera is necessary for the system to operate
properly.

Do not place an object on the top of the instrument
panel. It may reflect onto the windshield and prevent
the system from detecting lane lines properly.

Front Sensor
Camera

* Not available on all models

When Driving

Front Sensor Camera

446

Driving

Front Sensor Camera

If the Some Driver Assist Systems Cannot
Operate: Camera Temperature Too High message
appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed towards the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the Some Driver Assist Systems Cannot
Operate: Clean Front Windshield message
appears:

•

Park your vehicle in a safe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.

* Not available on all models

447

When Driving

Adaptive Cruise Control (ACC)

Continued

Driving

Adaptive Cruise Control (ACC)

Helps maintain a constant vehicle speed and a set following-interval behind a vehicle
detected ahead of yours, without you having to keep your foot on the brake or the
accelerator.

Adaptive Cruise Control (ACC)

Important Reminder
As with any system, there are limits to ACC. Use the
brake pedal whenever necessary, and always keep a
safe distance between your vehicle and other
vehicles.

Be careful not to have the radar sensor cover strongly
impacted.

WARNING

Improper use of ACC can lead to a crash.

Use ACC only when traveling on open
highways in good weather.

WARNING

ACC has limited braking capability.

When your vehicle speed drops below
22 mph (35 km/h), ACC will
automatically cancel and no longer will
apply your vehicle’s brakes.

Always be prepared to apply the brake
pedal when conditions require.

When to use

■

Vehicle speed for adaptive cruise control: Desired speed in a range above
roughly 25 mph (40 km/h) ~

■

Shift position for ACC: In

(

D or

(

The radar sensor is
at the lower part of
the front bumper.

The camera is
located behind
the rearview
mirror.

* Not available on all models

Content .. 26 27 28 29 ..
