Honda Accord Coupe (2017 year). Instruction

112

Gauges and Displays

Multi-Information Display

strum

nt Pa

nel

*1: Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Door Setup

Auto Door Lock

Changes the setting for when the doors
automatically lock.

With Vehicle Speed

/Shift

from P/Off

Auto Door Unlock

Changes the setting for when the doors
automatically unlock.

All Doors When Driver’s
Door Opens

/All Doors

When Shifted To Park/All
Doors When Ignition
Switched Off/Off

Key And Remote Unlock
Mode

Sets up either the driver’s door or both doors to
unlock on the first operation of the remote or built-
in key.

Driver Door

/ All Doors

Keyless Lock Answer
Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

/Off

Security Relock Timer

Changes the time it takes for the doors to relock and
the security system to set after you unlock the
vehicle without opening either door.

90sec/60sec/30sec

Maintenance
Reset

—

Resets/Cancels the engine oil life display when you
have performed the maintenance service.

Cancel/Reset

Default All

—

Cancels/Resets all the customized settings as
default.

Cancel/Set

113

Gauges and Displays

Multi-Information Display

Continued

strum

nt Pa

nel

■

Example of customization settings

The steps for changing the “Trip A” Reset Timing setting to With Refuel are
shown below. The default setting for “Trip A” Reset Timing is Manually Reset.

1. Press the

button to select Vehicle

Settings, then press the SEL/RESET
button.

2. Press the

button until Meter

Setup appears on the display.

3. Press the SEL/RESET button.

Language Selection appears first in the
display.

114

Gauges and Displays

Multi-Information Display

strum

nt Pa

nel

4. Press the

button until “Trip A”

Reset Timing appears on the display, then
press the SEL/RESET button.

The display switches to the
customization setup screen, where you
can select With Refuel, IGN Off,
Manually Reset, or Exit.

5. Press the

button and select With

Refuel, then press the SEL/RESET button.

The With Refuel Setup screen appears,
then the display returns to the
customization menu screen.

6. Press the

button until Exit appears

on the display, then press the SEL/RESET
button.

7. Repeat Step 6 until you return to the

normal screen.

116

Co
ntrols

Clock

Adjusting the Clock

You can adjust the time in the clock display with the ignition switch is in ON

(

■

Using the Settings menu on the audio/information screen

1. Press the SETTINGS button.
2. Rotate

select

System Settings, then

press .

Repeat the procedure to select Clock,
then Clock Adjustment.

3. Rotate

to change hour, then press

4. Rotate

to change minute, then press

■

Using the SETTINGS button

1. Press and hold the CLOCK (SETTINGS)

button until the clock display blinks.

2. Press Preset

(

4 (Hour) or

(

5 (Minute) to

adjust the time.

3. Press the CLOCK button again to set the

time.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Adjusting the Time

Adjusting the Clock

These indications are used to show how to operate
the selector knob.
Rotate

to select.

Press

to enter.

You can customize the clock display to show the 12
hour clock or 24 hour clock.

2 Customized Features P. 298, 316

You can turn the clock display on and off.

2 Customized Features P. 298, 316

Models with one display

Using the SETTINGS button

To set the time to the nearest hour: Press and hold
the CLOCK button until the clock display blinks, then
press the

(

6 (Reset) button.

Depending on the displayed time, the clock sets
forward or backward.
Example:
1:06 will reset to 1:00
1:53 will reset to 2:00

CLOCK (SETTINGS)
Button

(

6 (Reset) Button

(

4 (Hour) Button

(

5 (Minute) Button

117

Clock

Adjusting the Clock

Co
ntrols

■

Using the Settings menu on the audio/information touch screen

1. Select

, then select Settings.

2. Select Clock/Info, then Clock

Adjustment.

3. Adjust the hours and minutes by selecting

4. Select OK to set the time.

Models with two displays

Using the Settings menu on the audio/information touch screen

The clock is automatically updated through the audio
system, so the time does not need to be adjusted.

Models with two displays

3 4

118

Co
ntrols

Locking and Unlocking the Doors

Key Types and Functions

This vehicle comes with the following keys:

Use the key to start and stop the engine, to
lock and unlock the doors and to open the
trunk. You can also use the remote
transmitter or smart entry system

to lock and

unlock the doors and to open the trunk.

■

Smart entry remote

The built-in key can be used to lock/unlock the
doors when the smart entry remote battery
becomes weak and the power door lock/
unlock operation is disabled.

To remove the built-in key, pull it out while
sliding the release knob. To reinstall the built-
in key, push the built-in key into the smart
entry remote until it clicks.

■

Master Keys

Key Types and Functions

All the keys have an immobilizer system. The
immobilizer system helps to protect against vehicle
theft.

2 Immobilizer System P. 133

The keys contain precision electronics.
Adhere to the following advice to prevent damage to
the electronics:

•

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

•

Do not drop the keys or set heavy objects on them.

•

Keep the keys away from liquids.

•

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the engine
may not start, and the remote transmitter may not
work.
If the keys do not work properly, have them
inspected by a dealer.

You can remotely start the engine using the smart
entry remote.

2 Remote Engine Start

P. 425

Models with remote engine starter

Master Key

Smart Entry
Remote

Smart Entry
Remote with
Remote Engine
Starter

Built-in Key

Release Knob

* Not available on all models

119

Locking and Unlocking the Doors

Key Types and Functions

Co
ntrols

Can be used to start and stop the engine, and
lock and unlock driver's door.

Contains a number that you will need if you
purchase a replacement key.

■

Valet Key

Valet Key

When you need to leave a key with a third party,
leave the valet key.

Gray

■

Key Number Tag

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact a
dealer.

If you lose your key and you cannot start the engine,
contact a dealer.

* Not available on all models

120

Locking and Unlocking the Doors

Low Smart Entry Remote Signal Strength

Co
ntrols

Low Smart Entry Remote Signal Strength

The vehicle transmits radio waves to locate the smart entry remote when locking/
unlocking the doors, opening the trunk, or to start the engine.

In the following cases, locking/unlocking the doors, opening the trunk, or starting
the engine may be inhibited or operation may be unstable:
• Strong radio waves are being transmitted by nearby equipment.
• You are carrying the smart entry remote together with telecommunications

equipment, laptop computers, cell phones, or wireless devices.

• A metallic object is touching or covering the smart entry remote.

Low Smart Entry Remote Signal Strength

Communication between the smart entry remote and
the vehicle consumes the smart entry remote’s
battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the smart entry
remote is receiving strong radio waves. Avoid placing
it near electrical appliances such as televisions and
personal computers.

* Not available on all models

121

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the smart entry remote, you
can lock/unlock the doors and open the trunk.
You can lock/unlock the doors within a radius
of about 32 inches (80 cm) of the outside door
handle. You can open the trunk within about
32 inches (80 cm) radius from the trunk
release button.

■

Locking the doors and the trunk

Press the door lock button on either door.

Some exterior lights flash; the beeper
sounds; both doors and the trunk lock;
and the security system sets.

■

Using the Smart Entry with Push Button Start System

Door Lock Button

Using the Smart Entry with Push Button Start System

•

Do not leave the smart entry remote in the vehicle
when you get out. Carry it with you.

•

Even if you are not carrying the smart entry remote,
you can lock/unlock the doors while someone else
with the remote is within range.

•

The door may be unlocked if the door handle is
covered with water in heavy rain or in a car wash if
the smart entry remote is within range.

•

If you grip either door handle wearing gloves, the
door sensor may be slow to respond or may not
respond by unlocking the doors.

•

You cannot unlock the door by gripping the handle
after two seconds of locking it.

•

The door might not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

•

Even within the 32 inches (80 cm) radius, you may not
be able to lock/unlock the doors with the smart entry
remote if it is above or below the outside handle.

•

The smart entry remote may not operate if it is too
close to the door and door glass.

If the distance at which the remote transmitter works
varies, the battery is probably low.
If the LED does not come on when you press a
button, the battery is dead.

2 Replacing the Button Battery P. 547

You can customize the door lock mode and keyless
lock acknowledgement setting.

2 Customized Features P. 106, 298, 31 6

* Not available on all models

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

122

Co
ntrols

■

Unlocking the vehicle

Grab the driver’s door handle:

The driver’s door unlocks.

Some exterior lights flash twice and the
beeper sounds twice.

Grab the passenger’s door handle:

Both doors and the trunk unlock.

Some exterior lights flash twice and the
beeper sounds twice.

Press the trunk release button:

The trunk unlocks and opens.

2 Using the Trunk Release Button

P. 130

Trunk Release Button

Using the Smart Entry with Push Button Start System

If you do not open a door within 30 seconds of
unlocking the vehicle, the doors will automatically
relock.

The light flash, beep and unlock settings can be
customized using the multi-information display

audio/information screen

or audio/information

touch screen

2 Customized Features P. 106, 298 , 316

* Not available on all models

Continued

123

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Locking the doors

Press the lock button.
Once:

Some exterior lights flash, both doors
lock, and the security system sets.

Twice (within five seconds after the first
push):

The beeper sounds and verifies the
security system is set.

■

Using the Remote Transmitter

Using the Remote Transmitter

If you do not open a door within 30 seconds of
unlocking the vehicle with the remote transmitter,
the doors will automatically relock.
You can change the relock timer setting.

2 Customized Features P. 106, 298, 31 6

If the interior light switch is in the door activated
position, the interior lights come on when you press
the unlock button.
No doors opened: The lights fade out after 30
seconds.
Doors relocked with the remote: The lights go off
immediately.

2 Interior Lights P. 169

The remote transmitter uses low-power signals, so
the operating range may vary depending on the
surroundings.

The remote transmitter will not work when the key is
in the ignition switch.

You can lock or unlock doors using the remote
transmitter or smart entry system only when the
power mode in VEHICLE OFF.

The remote will not lock the vehicle when a door is
open.

Models without smart entry system

Models with smart entry system

All models

LED

Unlock Button

Lock Button

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

124

Co
ntrols

■

Unlocking the doors

Press the unlock button.
Once:

Some exterior lights flash twice, and the driver’s door unlocks.

Twice:

The passenger’s door unlocks.

Using the Remote Transmitter

If the distance at which the remote transmitter works
varies, the battery is probably low.
If the LED does not come on when you press a
button, the battery is dead.

2 Replacing the Button Battery P. 547

You can customize the door unlock mode setting.

2 Customized Features P. 106, 298 , 316

125

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

Fully insert the key and turn it.

■

Locking the driver’s door

Push the lock tab forward

or push the

master door lock switch in the lock direction

, and close the door.

The doors cannot be locked when the key
is in the ignition switch

, or the smart

entry remote is inside the vehicle.

■

Locking the passenger’s door

Push the lock tab forward and close the door.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Locking/Unlocking the Doors Using a Key

Locking/Unlocking the Doors Using a Key

When you lock the driver’s door with a key, the
passenger’s door locks at the same time. When
unlocking, the driver’s door unlocks first. Turn the
key a second time within a few seconds to unlock the
passenger’s door.

You can customize the door unlock mode setting.

2 Customized Features P. 106, 298, 31 6

Lock

Unlock

■

Locking a Door Without Using a Key

Locking a Door Without Using a Key

When you lock the driver’s door, the passenger’s
door locks at the same time.
Make sure you have the key in your hand before
locking the door to prevent it from being locked in
the vehicle.

126

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Inside

Co
ntrols

Locking/Unlocking the Doors from the Inside

■

Locking a door

Push the lock tab forward.

■

Unlocking a door

Pull the lock tab rearward.

■

Using the Lock Tab

Using the Lock Tab

When you lock the door using the lock tab on the
driver's door, the passenger’s door locks at the same
time.
When you unlock the door using the lock tab on the
driver's door, only the driver's door will unlock.

To Unlock

Lock Tab

To Lock

Continued

127

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Inside

Co
ntrols

Pull the inner handle.

The door unlocks and opens in one
motion.

Unlocking and opening the driver’s door from the inner handle unlocks both doors.

To avoid both doors to be unlocked, use the lock tab on the driver’s door to unlock,
then lock again before opening the door.

This setting works for one time only. If you do not want both doors to be
unlocked all the time, customize the Auto Door Unlock setting to Off using
the multi-information display

, audio/information screen

or audio/information

touch screen

■

Unlocking Using the Inner Handle

Unlocking Using the Inner Handle

The inner handles are designed to allow front seat
occupants to open the door in one motion. However
this feature requires that front seat occupants never
pull an inner handle while the vehicle is in motion.

Inner Handle

* Not available on all models

Honda Accord Coupe (2017 year). Instruction - part 8
