ELECTRICAL

1. Specifications................................................ 7-1

2. Electrical Bracket ............................................ 7-2

3. Ignition System.............................................. 7-4

4. Bank Angle Sensor...........................................7-47

5. MAP (Manifold Absolute Pressure) -1200S........................7-48

6. Vacuum Operated Electric Switch (V.O.E.S)....................... 7-49

7. Ignition/Light Switch ......................................... 7-51

8. Ignition Module -1200S....................................... 7-53

9. Cam Position Sensor and Rotor - 1200S.......................... 7-54

10. Ignition Module - All except 1200S...............................7-55

11. Spark Plugs ............................................... 7-57

12. Spark Plug Cables .......................................... 7-58

13. Ignition Coil................................................ 7-59

14. Charging System ........................................... 7-61

15. Alternator ................................................. 7-67

16. Voltage Regulator........................................... 7-69

17. Battery ................................................... 7-70

18. Lamps.................................................... 7-75

19. Rear Brake Switch............................................7-80

20. Handlebar Switches...........................................7-81

21. Horn ..................................................... 7-92

22. Neutral Indicator Switch ...................................... 7-94

23. Directional (Turn Signal) Canceller.............................. 7-95

24. Fuses and Main Circuit Breaker............................... 7-102

25. Electronic Speedometer and Tachometer.........................7-104

26. Deutsch Electrical Connectors................................. 7-111

27. AMP Multilock Electrical Connectors.............................7-116

28. Packard Electrical Connectors..................................7-120

29. Sealed Butt Connectors...................................... 7-122

30. Crimp Tables...............................................7-123

31. Wiring Diagrams........................................... 7-127
