a. Make the assembly mark on the inner trumpet connector and three-pin section assembly. Caution: remove the grease in the connector before make the mark and don’t make the mark by the hard object such as punch. b. Remove the inner trumpet connector. 4. Disassembly of three-pin section assembly a. Use the circlip pliers to remove the circlip. b. Use the adz and hand hammer to make the assembly mark on the shaft and three-pin section assembly. c. Use the cooper bar and hand hammer to remove the three-pin section. Caution: Remove the cooper chip on the shaft or three-pin section assembly if has. 5. Remove the inner jacket a. Use the pliers to disassemble the small clip of inner jacket. b. Pull out the inner jacket. Caution: Remove the grease in the jacket and maintain the clean field. 6. Use the straight screwdriver to disassemble the large and small clip of outer jacket. assembly mark assembly mark |
