REV MATCH - MANUAL
TRANSMISSION

This feature provides a smoother driving
experience, particularly during a downshift
event. Rev Match commands a quick
engine RPM match to the selected gear
during a clutch pressed gear shift. You can
switch this feature on and off through the
touchscreen.

LAUNCH CONTROL - MANUAL
TRANSMISSION

Temporarily holds the engine RPM at a set
point and maximizes traction to the wheels
for a more aggressive start.

Enabling or Disabling Launch
Control

From the Track Apps menu, press

Launch Control

To set the RPM hold point:

From the Track Apps menu, press

Launch Settings

Note:

You can also enable or disable the

feature from this screen.

E38549 3

2. Use the slider bar or arrows to set the

RPM value.

Using Launch Control

Make sure launch control is enabled.

2. Bring your vehicle to a complete stop.

3. The indicator illuminates white in the

instrument cluster when launch control
is ready.

4. Fully press and hold the clutch pedal.

5. Shift the transmission into first gear.

6. Fully press the accelerator pedal and

keep it pressed. Allow the tachometer
to settle at the RPM that you selected
and wait for the indicator to turn green.

Release the clutch pedal.

Improving Your Launch

If launch control is not available when you
come to a stop:
•

Wait for the engine to come to
operating temperature. If the engine is
too hot or cold, launch control is not
available.

•

Make sure the drive mode is not set to
Slippery.

If the vehicle did not launch effectively:
•

Adjust the RPM and practice releasing
the clutch. It may take practice to get
a feel for how quickly to release the
clutch.

•

Switch traction control on, this can
reduce excessive wheel spin.

Keep in mind that weather, road surface,
and tire conditions can also affect your
launch.

Launch Control Indicators

With Traction Control Off

E379195

Not ready.

E379193

Ready to use.

E379194

Active and ready to launch.

With Traction Control On

E379192

Not ready.

406

My Mustang

E375124

Ready to use.

E375125

Active and ready to launch.

DRIFT BRAKE

(If Equipped)

E380329

Allows you to lock up the rear
tires to enable drift maneuvers.

Before drifting, make sure you are on a
track, and have the necessary safety
equipment including a certified helmet and
approved neck restraint device. Work up
to your limit while drifting, do not expect
to be an expert right away.

Note:

Drift brake is for track use only. Do

not use it under any other driving conditions.

Note:

Using this feature may result in

significantly increased rear tire wear.

Switching Drift Brake On or Off

From the Track Apps menu, press

Drift

Brake

2. Confirm the selection. This enables

track mode.

Note:

If track mode is already enabled,

there is no confirmation message.

Note:

Switching drift brake on

automatically enables track mode. If you
change to a different drive mode, drift brake
disables.

3. Press

Drift Brake

again to switch it off.

Note:

When you switch drift brake off, track

mode remains on.

Note:

When the feature is on, the brake

handle applies braking to the rear wheels
only and locks up the rear wheels. When the
feature is off, the brake handle works like
the foot brake and applies braking to all four
wheels.

Note:

The system may exit track mode if it

reaches certain threshold limits. If this
happens, Drive Mode Not Available or
Service AdvanceTrac messages display in
the instrument cluster display screen. You
can reset the system by switching your
vehicle off and back on, driving normally up
to 15 minutes and reaching 45 mph
(73 km/h). After the system is re-calibrated,
drive modes will be available through the
button on the steering wheel.

Drift Brake Driving Hints - Vehicles
with: Automatic Transmission

Two important things to note when driving
a vehicle with an automatic transmission:
•

Keep the RPM high when drifting to
prevent unintentional engine stall. The
engine RPM drops rapidly when locking
the rear wheels, so it is best to be on
the throttle prior to and after pulling
the handle to prevent stalling.

•

Using the paddle shifters or manual
shift mode enhances your ability to
keep the vehicle in the power band.
This way when you release the drift
brake you can quickly get back on the
throttle and maintain your drift.

As your drifting skills develop, it may be
beneficial to turn off other vehicle control
systems such as traction control and
electronic stability control. See

(page 198). Before returning to

public roads, re-enable both systems.

Drift Brake Driving Hints - Vehicles
with: Manual Transmission

Drifting in a manual transmission gives you
more control over the chosen gear, which
allows you to make sure you have correct
application of power to maintain the drift.

407

My Mustang

Two things to note while drifting in a
manual transmission vehicle:
•

Make sure to disengage the clutch
immediately prior to pulling the drift
brake. This prevents fighting engine
torque and prevents unintended stalls.

•

After releasing the drift brake, rapidly
engage the clutch and get back on the
throttle to maintain your drift.

As your drifting skills develop, it may be
beneficial to turn off other vehicle control
systems such as traction control and
electronic stability control. See

(page 198). Before returning to

public roads, re-enable both systems.

AUXILIARY GAUGES

E380326

Auxiliary gauges are available in
the touchscreen.

From the My Mustang menu, press

Auxiliary Gauges

E380325

E380324

Press the button to switch
between three or five-gauge
view.

To edit the gauges:

E280315

Press the button.

2. Use the arrows on the screen to select

the gauges you prefer.

Auxiliary gauges:
•

Cylinder head temperature.

•

Engine oil temperature.

•

Transmission oil temperature.

•

Axle temperature.

•

Engine oil pressure.

•

Inlet air temperature.

•

Manifold charge temperature.

•

Intercooler coolant temperature.

•

Vacuum or vacuum/boost.

•

Voltage.

Note:

Depending on your vehicle

configuration, not all gauges are available.

CUSTOM DRIVE MODE

Allows you to create your own drive mode
experience. Choose a drive mode to use as
a starting point and then mix and match
settings to tailor the experience to your
preferences. You can create up to six
custom modes.

E375917

You can set one of the six
custom modes as the active
mode. The active mode appears

as an available mode when selecting a
drive mode. See

Selecting a Drive Mode

(page 226).

408

My Mustang

Creating a Drive Mode

E385494

Profile selection.

Base drive mode.

Adjustable settings.

From the My Mustang menu, press

Custom Drive Mode

2. Press the profile button to select a

profile to edit.

Note:

Selecting a profile also sets it as the

active mode.

3. Select the base drive mode you prefer.

4. Press each option and select the

setting you prefer.

CLUSTER THEME

E380328

You can change the style of the
display behind the steering
wheel.

From the My Mustang menu, press

Cluster Theme

2. Select a theme.

Note:

If you choose

Match Drive Mode

, the

instrument cluster style changes according
to the drive mode you select.

MY COLOR

E380323

Allows you to customize the
colors of the instrument cluster
and touchscreen.

You can also adjust the ambient lighting.
See

Ambient Lighting

(page 101).

From the My Mustang menu, press

MyColor

2. Adjust the primary and secondary

colors to the setting you prefer.

EXHAUST MODE

(IF EQUIPPED)

Allows you to change how loud your
exhaust is. You can choose from one of
four settings.

Quiet Mode

E384530

Lowers the noise of the exhaust.

409

My Mustang

Quiet Start

Minimizes exhaust noise when you start
the vehicle. You can set a schedule for
when you want quiet start to be on.

To access the quiet start menu:

Press

Settings

on the touchscreen.

2. Press

Vehicle

3. Press

Quiet Start

From the menu, you can do the following:
•

Switch quiet start on or off.

•

Set the schedule.

Normal Mode

E287122

Default factory setting.

Sport Mode

E384531

Raises the noise of the exhaust.

Track Mode

E384532

Loudest level of exhaust noise.

Note:

The track exhaust mode setting is

only for use at tracks and not for use on
public roadways. Use of this setting results
in increased exterior noise, which may not
meet state and local laws and regulations.
It is the obligation of the driver to operate
the vehicle in a manner that complies with
state and local requirements. Only use the
track exhaust mode setting at a competition
track or an off-road course where increased
exterior vehicle noise is acceptable.

410

My Mustang

FORD ASSISTANT

USING FORD ASSISTANT

The digital assistant allows you to control
vehicle features using conversational
requests.

To begin a voice interaction using the wake
word, say the selected wake word, then
say your command.

E142599

Press the voice interaction
button on the steering wheel. A
tone sounds before you can say

your command.

Note:

You may need to enable your

vehicle's modem to use certain voice
commands. See

Enabling and Disabling

the Modem

(page 383).

Note:

When you are not driving, additional

commands are available by using popular
chat applications. Use FordPass to setup a
conversation with your Ford assistant.

Voice Command Examples

To see examples of what voice commands
you can use with different features:

E280315

Press the button on the
touchscreen.

Press

Ford Assistant

2. Press

Voice Command Help

3. Select a feature.

FORD ASSISTANT SETTINGS

To access the settings menu:

E280315

Press the button on the
touchscreen.

Press

Ford Assistant

From the settings menu you can do the
following:
•

Switch listen for wake word on or off.

•

Set the preferred wake word.

•

Switch advance mode on or off.

•

Switch phone confirmation on or off.

•

Switch the commands list on or off.

•

View the commands help menu.

E366956

Press the button next to a menu
option for more information.

FORD ASSISTANT – FREQUENTLY
ASKED QUESTIONS

Why does the system not
understand what I am saying?

•

You are speaking too soon. When using
the button of the steering wheel, wait
for the tone before you speak.

Why does the system not
understand the name of a track or
artist?

•

Bluetooth®

does not support voice

commands.Connect your device to a
USB port.

•

You are not saying the name exactly
as it appears on your device. Say the
name of the track or artist exactly as it
appears on your device. Spell out any
abbreviations in the name.

•

The system does not recognize some
special characters contained in the
name of a song or artist, for example
*, - or +. Rename the files on your
device or use the touchscreen to select
and play the track.

411

Voice Interaction

Why does the system not
understand the name of a contact
in the phonebook on my device and
calls the wrong contact?

•

You are not saying the name exactly
as it appears on your device. Say the
first and last name of the contact
exactly as it appears on your device.
Spell out any abbreviations in the
name.

•

The name contains special characters,
for example *, - or +. Rename the
contact on your device or use the
touchscreen to select and call the
contact.

Why does the system not
understand foreign names of
contacts in the phonebook on my
device?

•

The system applies phonetic
pronunciation rules of the selected
language to the names of contacts in
the phonebook on your device. Select
the name of the contact on the
touchscreen and use the Hear it option
to get an idea of how the system
expects you to pronounce it.

Why do the system voice prompts
and the pronunciation of some
words not seem accurate?

•

The system uses text-to-speech
technology and a synthetically
generated voice rather than a
pre-recorded human voice.

412

Voice Interaction

WHAT IS ALEXA BUILT-IN

Allows you to use Alexa in your vehicle for
auto-specific use cases on the road and
gives you access to an ever-evolving
number of skills that help to make your life
more productive, entertaining, and
connected while using your vehicle.

ALEXA BUILT-IN
REQUIREMENTS

To use Alexa, all of the following must
occur:
•

Your vehicle modem is enabled.

•

You are signed in to an existing Amazon
account.

•

Vehicle location services are enabled.

•

Vehicle connectivity and vehicle data
sharing is enabled.

SIGNING IN TO YOUR
ACCOUNT

E368039

Press the button in the status
bar and follow the on-screen
prompts.

To sign in using the settings menu:

Press

Settings

on the touchscreen.

2. Press

Amazon Alexa

3. Press

Get Started

4. Sign in to your account by either

scanning the QR code or entering the
on-screen code into the Amazon
website.

5. Once signed in, follow the on-screen

prompts.

6. When complete, the vehicle informs

you that Alexa is ready to be used in
the vehicle.

Signing Out of Your Account

Press

Settings

on the touchscreen.

2. Press

Amazon Alexa

3. Press

Sign Out

USING ALEXA BUILT-IN

To use Alexa, say “Alexa” or press the voice
interaction button on the steering wheel
and then say “Alexa” to invoke Alexa to
start listening.

Note:

If the wake word is not enabled, you

can only use the voice interaction button.

You can use Alexa for the following and
more:
•

Entertainment.

•

Hands-free calling.

•

Traffic and navigation.

•

Vehicle controls.

•

Smart home device control.

•

Weather and news information.

ALEXA BUILT-IN SETTINGS

Enabling the Wake Word

Press

Settings

on the touchscreen.

2. Press

Amazon Alexa

3. Switch

Listen for Wake Word

on or off.

Note:

If the wake word is not enabled, you

can only use the voice interaction button.

Contact List

Displays a list of connected phones and
contact sharing status for each phone.

To change the contact sharing status:

Press

Settings

on the touchscreen.

2. Press

Amazon Alexa

3. Press

Contact List

413

Alexa Built-In

PHONE PRECAUTIONS

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

CONNECTING YOUR PHONE

Go to the settings menu on your device and
switch

Bluetooth®

on.

Press the phone option on the
home screen.

Press

Add Phone

Note:

A prompt alerts you to search for your

vehicle on your cell phone.

2. Select your vehicle on your cell phone.

Note:

A number appears on your cell phone

and on the touchscreen.

3. Confirm the number on your cell phone

matches the number on the
touchscreen.

Note:

The touchscreen indicates that you

have successfully paired your cell phone.

4. Download the phonebook from your

cell phone when you are prompted.

Note:

If you pair more than one cell phone,

use the phone settings on the center display
to specify the primary phone. You can
change this setting at any time.

PHONE MENU

This menu becomes available after pairing
a phone.

Recent Call List

Display and select an entry from a list of
previous calls.

Contacts

Display a smart search form to look up your
contacts. Use the List button to
alphabetically sort your contacts.

Favorites

Display the list of favorite contacts that
are set up on your phone.

Messaging

Displays the list of text messages to read,
listen to, or respond to.

Displays the list of emails to read, listen to,
or respond to.

Phone List

Display the list of paired or connected
devices that you can select.

Note:

Up to 12 devices can be stored.

Do Not Disturb

Reject incoming calls and switch ring tones
and alerts off.

Phone Keypad

Directly dial a number.

415

Phone

MAKING AND RECEIVING A
PHONE CALL

Making Calls

To call a number in your contacts,
select:

Action and Description

Menu Item

You can then select the
name of the contact you
want to call. Any numbers
stored for that contact
display along with any
stored contact photos. You
can then select the
number that you want to
call. The system begins the
call.

Contacts

To call a number from your recent calls,
select:

Action and Description

Menu Item

You can then select an
entry that you want to call.
The system begins the call.

Recent Call
List

To call a number from your favorites,
select:

Action and Description

Menu Item

You can then select an
entry that you want to call.
The system begins the call.

Favorites

To call a number that is not stored in
your phone, select:

Action and Description

Menu Item

Select the digits of the
number you wish to call.

Phone
Keypad

The system begins the call.

Call

Pressing the backspace button deletes the
last digit you typed.

Receiving Calls

During an incoming call, an audible tone
sounds. Caller information appears in the
display if it is available.

To accept the call, select:

Menu Item

Note:

You can also accept the call by

pressing the phone button on the steering
wheel.

To reject the call, select:

Menu Item

Reject

Ignore the call by doing nothing. The
system logs it as a missed call.

During a Phone Call

During a phone call, the contacts name
and number display on the screen along
with the call duration.

The phone status items are also visible:

•

Signal Strength.

•

Battery.

You can select any of the following during
an active phone call:

417

Phone

Item

Immediately end a
phone call. You can
also press the
button on the
steering wheel.

End Call

Press this to access
the phone keypad.

Keypad

Item

Mute

You can switch the
microphone off so
the caller does not
hear you.

Transfer the phone
call audio to the
cell phone or back
to the touchscreen.

Privacy

SENDING AND RECEIVING A TEXT MESSAGE

Description

Menu Item

Hear the text message.

Hear It

View the text message.

View

Call the sender.

Call

Reply to the text message with a standard text message.

418

Phone

CONNECTING A BLUETOOTH®
DEVICE

Make sure

Bluetooth®

is enabled on

your device.

2. Press

Settings

on the touchscreen.

3. Press

Connectivity

4. Press

Bluetooth

5. Press

Add a Bluetooth Device

Note:

A prompt alerts you to search for your

vehicle on your device.

6. Select your vehicle on your device.

Note:

A number appears on your device and

on the touchscreen.

Confirm that the number on your
device matches the number on the
touchscreen.

Note:

The touchscreen indicates that you

have successfully paired your device.

The

Bluetooth®

word mark and logos are

registered trademarks owned by

Bluetooth

SIG, Inc.

and any use of such marks by

Ford Motor Company is under license.
Other trademarks and trade names are
those of their respective owners.

PLAYING MEDIA USING
BLUETOOTH®

WARNING:

Driving while distracted

hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

Connect your device.

E100027

Press the audio button on the
home screen.

E250655

Press

Sources

Press the

Bluetooth®

option.

Press to play a track. Press again
to pause the track.

Press to skip to the next track.

Press and hold to fast forward
through the track.

Press once to return to the
beginning of a track. Repeatedly
press to return to previous

tracks.

Press and hold to fast rewind through the
track.

420

Bluetooth®

APP PRECAUTIONS

WARNING:

Driving while distracted

APP REQUIREMENTS

When you start an app through the system
for the first time, you could be asked to
grant certain permissions. You can review
and change the permissions that you have
granted at any time when your vehicle is
not moving. We recommend that you
check your data plan before using your
apps through the system. Using them
could result in additional charges. We also
recommend that you check the app
provider's terms and conditions and
privacy policy before using their app. Make
sure that you have an active account for
apps that you want to use through the
system. Some apps will work with no
setup. Others require you to configure
some personal settings before you can use
them.

ACCESSING APPS

Select the apps option on the
home screen.

ENABLING APPS ON AN IOS
DEVICE

Select the apps option on the
home screen.

Select Mobile Apps Help.

2. Follow the instructions to pair and

connect your device via

Bluetooth®

with a USB cable.

3. Start the apps on your device that you

want to use.

4. Select the app that you want to use on

the touchscreen.

Note:

Some apps may run through Apple

CarPlay if it is enabled.

Note:

Closing an app on your device closes

it on the touchscreen.

Note:

For troubleshooting assistance select

Mobile Apps List under Mobile Apps Help.

ENABLING APPS ON AN
ANDROID DEVICE

Select the apps option on the
home screen.

Select Mobile Apps Help.

2. Follow the instructions to pair and

connect your device via

Bluetooth®

with a USB cable.

3. Start the apps on your device that you

want to use.

4. Select

Find Mobile Apps

5. Select the app that you want to use on

the touchscreen.

Note:

Some devices may lose the ability to

play music over USB when Mobile Apps are
enabled.

Note:

Some apps may run through Android

Auto if it is enabled.

421

Apps

Note:

Closing an app on your device closes

it on the touchscreen.

Note:

For troubleshooting assistance select

Mobile Apps List under Mobile Apps Help.

SWITCHING APPLE CARPLAY
ON AND OFF

Enabling Apple CarPlay with USB

Connect your device to a USB port.

2. Follow the instructions on your device

and the touchscreen.

Note:

Selecting Enable Wireless CarPlay

on your device prepares the device for
wireless Apple CarPlay when you re-enter
the vehicle.

Enabling Apple CarPlay with
Wireless

Pair your device to

Bluetooth®

2. Follow the instructions on your device

and the touchscreen.

Disabling Apple CarPlay

E280315

Select the settings option on the
home screen.

Press Phone List.

2. Select your device from the list.

3. Press Disable.

Re-Enabling Apple CarPlay

E280315

Select the settings option on the
home screen.

Press Phone List.

2. Select your device from the list.

3. Press Connect to Apple CarPlay.

SWITCHING ANDROID AUTO
ON AND OFF

Enabling Android Auto with USB

(If Equipped)

Connect your device to a USB port.

2. Follow the instructions on the

touchscreen.

Note:

Certain features of the system are

not available when you are using Android
Auto.

Enabling Android Auto with
Wireless

Pair your device to

Bluetooth®

2. Follow the instructions on your device

and the touchscreen.

Note:

Certain Android devices do not

support Android Auto Wireless. Check your
Android OS version for compatibility.

Disabling Android Auto

E280315

Select the settings option on the
home screen.

Press Phone List.

2. Select your device from the list.

3. Press Disable.

Re-Enabling Android Auto

E280315

Select the settings option on the
home screen.

Press Phone List.

2. Select your device from the list.

3. Press Connect to Android Auto.

422

Apps

HOW DO PERSONAL PROFILES
WORK

This feature allows you to create multiple
personal profiles enabling users to
personalize vehicle’s settings such as seats
and mirrors, as well as non-positional
settings like radio, navigation and driver
assist. Positional settings are saved by
holding a memory seat button.
Non-positional settings are saved when
you change a setting while a profile is
active. You can create one profile for each
preset memory seat button along with a
guest profile.

Recalling and Changing a Profile

You can recall a profile using the
touchscreen or the preset button you
selected when you created your profile.
You can also link a remote control and a
mobile device to your profile, to recall the
profile.

ENABLING OR DISABLING
PERSONAL PROFILES

When you switch on the Personal Profiles
feature:
•

Unlocking a door with a remote control
or mobile device that is not linked to a
driver profile does not change the
active profile, but remains in the last
known profile. It does not change the
positional settings.

•

Pressing a memory seat button that is
not linked to a driver profile or saved to
a preset setting does not change the
active profile, but remains in the last
known profile. It does not change the
positional settings.

•

Pressing a memory seat button that is
not linked to a driver profile but is saved
to a preset setting does not change the
active profile, but remains in the last
known profile. It recalls the positional
settings that you saved to that memory
seat button.

When you switch off a Personal Profiles
feature:
•

Unlocking a door with a remote control
or mobile device does not recall any
non-positional settings but still recalls
positional settings from the driver
profile which the remote control or
mobile device is linked to.

•

Pressing a memory seat button that is
not linked to a driver profile or saved to
a preset setting does not change the
positional or non-positional settings.

•

Pressing a memory seat button that is
linked to a driver profile or has saved
to a preset setting recalls the positional
settings that you saved to that memory
seat button.

423

Personal Profiles

CREATING A PERSONAL
PROFILE

Use the touchscreen to create a personal
profile.

Switch the vehicle on and leave the
vehicle in park (P).

2. Select the Personal Profiles button

under Settings.

3. Follow the instructions on the display.

LINKING OR UNLINKING A
PERSONAL PROFILE TO A
REMOTE CONTROL

You can save Personal Profiles, including
preset memory positions, for up to three
remote controls by assigning a remote
control to a personal profile using the
touchscreen.

Use the touchscreen to link a remote
control to a personal profile.

Switch the vehicle on and leave the
vehicle in park (P).

2. Select Personal Profiles under Settings.

3. Touch the arrow for the profile you

want to link to a remote control.

4. Select remote control.

5. Follow the instructions on the display.

Note:

If more than one linked remote

control is in range, the memory function
moves to the settings of the first key to
initiate a memory recall.

Note:

The guest profile consists of existing

settings when there is no driver profile
created. After you create a driver profile, the
guest profile serves as an additional driver
profile.

Note:

You cannot link a remote control to

a guest profile.

LINKING OR UNLINKING A
PERSONAL PROFILE TO A
DEVICE

Use the touchscreen to link a mobile device
to a personal profile.

Switch the vehicle on and leave the
vehicle in park (P).

2. Select the Personal Profiles button

under Settings.

3. Touch the arrow for the profile you

wish to link to a mobile device.

4. Select mobile device.

5. Follow the instructions on the display.

Note:

To successfully link a mobile device,

the mobile device must be in your vehicle,
and must have previously been setup as a
remote control for your vehicle.

Note:

The guest profile consists of existing

settings when there is no driver profile
created. After you create a driver profile, the
guest profile serves as an additional driver
profile.

Note:

You cannot link a personalized name

to a guest profile.

424

Personal Profiles

CONNECTED NAVIGATION

(IF

EQUIPPED)

Your vehicle may be equipped with
connected navigation. Depending on your
version, you are given a 90 day or 3 year
trial. After the trial period, you need to sign
up to continue the experience. For
additional information, visit

ford.com/

connectedservices

Note:

If you do not sign up or renew your

subscription, you can still use navigation
through a connected device.

ACCESSING NAVIGATION

Press the button to access
Navigation.

Note:

As the driver, be aware of all local

traffic regulations and road attributes, and
operate your vehicle in a safe and legal
manner.

NAVIGATION MAP UPDATES

To update your map data over Wi-Fi, your
vehicle must be connected to a Wi-Fi
access point. For USB updates and other
details, contact dealers at
1-866-462-8837 in the United States and
Canada, or 800-557-5539 in Mexico.

Note:

If you find map data errors, you may

report them by going to
www.here.com/mapcreator.

ADJUSTING THE MAP

ZOOMING THE MAP IN AND OUT

You can use pinch gestures to zoom in and
out. Place two fingers on the screen and
move them apart to zoom in. Place two
fingers on the screen and bring them
together to zoom out.

CHANGING THE FORMAT OF THE
MAP

E328845

Press the Menu button.

Press the Map Orientation tile.

2. Select a map orientation.

LIVE TRAFFIC

WHAT IS LIVE TRAFFIC

You can observe real-time road congestion
when live traffic is on.

SWITCHING LIVE TRAFFIC ON
AND OFF

E328845

Press the Menu button.

Press the Traffic on Map tile.

2. Press Traffic on or Traffic Off.

SETTING A DESTINATION

SETTING A DESTINATION USING
THE TEXT ENTRY SCREEN

Press the search bar at the top of the
screen.

425

Navigation

(If Equipped)

2. Enter your destination using the

keyboard.

3. Press Search.

4. Select a destination from the list.

5. Press Start to begin navigation.

SETTING A DESTINATION USING
THE MAP SCREEN

Press and hold on the map to place a pin
at that location. Information about the
location of the pin appears on the screen.

E328844

Press the button to begin
navigation to the pin.

SETTING A DESTINATION USING
A PREDICTIVE DESTINATION

Press the predicted destination card on
the screen to navigate to it. These appear
when the navigation system has learned
your driving habits.

SETTING A DESTINATION USING
A RECENT DESTINATION

Press the Recents tile.

2. Select a destination from the list.

SETTING A DESTINATION USING
A SAVED DESTINATION

Press Saved Places.

2. Select a saved destination.

Note:

Press the star icon next when viewing

location details to save the location.

SETTING A DESTINATION USING
A POINT OF INTEREST

Press a point of interest icon on the map.
Information about the location of the point
of interest appears on the screen.

E328844

Press the button to begin
navigation to the point of
interest.

WAYPOINTS

ADDING A WAYPOINT

E328843

Press the Add Waypoint button
when in an active navigation
session.

Select a category or enter your
waypoint on the keyboard and press
Search.

2. Select a waypoint from the list.

3. Press Add to Trip.

EDITING WAYPOINTS

Press the waypoint you would like to
edit.

2. Select an option to reorder or delete

the waypoint.

ROUTE GUIDANCE

ADJUSTING THE GUIDANCE
PROMPT VOLUME

Turn the volume control when a guidance
prompt plays to adjust the volume.

CANCELING ROUTE GUIDANCE

E280804

Press the button to cancel route
guidance to the selected
location.

426

Navigation

(If Equipped)

These software updates introduce new
features or provide updates to vehicle
software systems. To receive updates, we
recommend you switch Automatic
Updates on, set a recurring update
schedule and connect your vehicle to Wi-Fi.
Updates could take longer when not
connected to Wi-Fi or could not download
at all. See

Connecting the Vehicle to a

Wi-Fi Network

(page 383).

Your vehicle may be able to receive
drivable software updates, non-drivable
software updates or both. Drivable
software updates happen during normal
vehicle usage. If Automatic Updates is
switched on, updates happen without any
input from you. If Automatic Updates is
switched off, a software update icon
displays on the touchscreen and customer
acceptance is required.

Non-drivable software updates require you
to input a scheduled start time. You are
notified on your touchscreen and
connected device prior to a non-drivable
update.

Most updates complete in less than 30
minutes, although some updates could
take up to a few hours.

You are notified of the status of the
software updates on the top left part of
the touchscreen and on your connected
device. See

Software Update Indicators

(page 428).

Vehicle Software Update
Requirements

Non-drivable software updates do not
install if any of the following occur:
•

Your vehicle is running.

•

Your vehicle is switched on.

•

Your vehicle is not parked.

•

The 12 V battery charge is too low.

•

The hazard indicators are switched on.

•

The alarm is sounding.

•

The doors are open.

•

The parking lamps are switched on.

•

You are pressing the brake pedal.

•

An emergency call is in process.

•

Your vehicle is in limp home mode.

Vehicle Software Update
Limitations

Once you begin a non-drivable software
update, you cannot:
•

Cancel the update.

•

Enter your vehicle unless you have a
key blade.
•

You can open the doors using the
mechanical latch if child locks are
not on.

•

Use the remote control to lock, unlock
or start your vehicle.

•

Drive your vehicle.

•

Charge your vehicle.
•

Charging resumes once the update
completes.

SOFTWARE UPDATE
SETTINGS

To access the Software Updates menu:

Press

Settings

on the touchscreen.

2. Press

Software Updates

You can do the following in the Software
Updates menu:
•

Switch Automatic Updates on and off.

•

Schedule and install software updates.

•

View software update details.

E366956

Press the button next to a menu
option for more information.

427

Vehicle Software Updates

Switching Automatic Updates On
and Off

Your vehicle may come with Automatic
Updates switched on. Where Automatic
Updates is set to ‘On’ in your vehicle, you
agree that software updates may be
automatically delivered without any further
notice or additional consent from you.

Note:

Software updates require approval

to download or install with Automatic
Updates switched off.

Scheduling and Installing
Software Updates

Scheduling Software Updates

From the Software Updates menu:

Press

Schedule Updates

2. Select the days and time for updates.

3. Press

Save

The more days that updates are
scheduled, the more frequently your
vehicle installs new updates. We
recommend selecting a time you normally
do not need your vehicle.

Note:

The schedule you set is recurring. If

Automatic Updates is on, every time a
non-drivable update is available, it installs
on this schedule unless you change it. You
are notified on your touchscreen and
connected device prior to a non-drivable
update, with an option to reschedule it.

Installing Software Updates

Using the Status Bar

Press a Software Update indicator on
your touchscreen when it appears.

2. Follow the instructions on the

touchscreen.

Using the Touchscreen

From the Software Updates menu:

Press

Update Details

2. Press

Update Now

Viewing Software Update Details

From the Software Updates menu:

Press

Update Details

SOFTWARE UPDATE
INDICATORS

You can press the indicators in the status
bar when they appear for more
information.

E327787

Vehicle software update
reminder, schedule required,
confirmation of default schedule

required, or consent required.

E327788

Vehicle software update
canceled, update not successful,
or precondition not met.

E353218

Vehicle software update
successful.

428

Vehicle Software Updates

For a complete listing of the accessories
that are available for your vehicle, please
contact your authorized dealer or visit the
online store web site:

Web Address (United States)

www.Accessories.Ford.com

Web Address (Canada)

www.Accessories.Ford.ca

We will repair or replace any properly
authorized dealer-installed Ford Original
Accessory found to be defective in
factory-supplied materials or workmanship
during the warranty period, as well as any
component damaged by the defective
accessories.

We will warrant your Ford Original
Accessory through the warranty that
provides the greatest benefit:
•

24 months, unlimited mileage.

•

The remainder of your new vehicle
limited warranty.

Contact an authorized dealer for details
and a copy of the warranty.

Ford Licensed Accessories are the
accessory manufacturer's designs. The
manufacturer develops and therefore
warrants Ford Licensed Accessories, and
does not design or test these accessories
to Ford Motor Company engineering
requirements. Contact an authorized Ford
dealer for the manufacturer’s limited
warranty details, and request a copy of the
Ford Licensed Accessories product limited
warranty from the accessory manufacturer.

For maximum vehicle performance, keep
the following information in mind when
adding accessories or equipment to your
vehicle:
•

When adding accessories, equipment,
passengers and luggage to your
vehicle, do not exceed the total weight
capacity of the vehicle or of the front
or rear axle (GVWR or GAWR as
indicated on the Safety Compliance
Certification label). Ask an authorized
dealer for specific weight information.

•

The Federal Communications
Commission (FCC) and Canadian
Radio Telecommunications
Commission (CRTC) regulate the use
of mobile communications systems
that are equipped with radio
transmitters, for example two-way
radios, telephones and theft alarms.
Any such equipment installed in your
vehicle should comply with Federal
Communications Commission (FCC)
and Canadian Radio
Telecommunications Commission
(CRTC) regulations and should be
installed only by an authorized dealer.

•

An authorized dealer needs to install
mobile communications systems.
Improper installation may harm the
operation of your vehicle, particularly
if the manufacturer did not design the
mobile communication system
specifically for automotive use.

•

If you or an authorized Ford dealer add
any non-Ford electrical or electronic
accessories or components to your
vehicle, you may adversely affect
battery performance and durability. In
addition, you may also adversely affect
the performance of other electrical
systems in the vehicle.

430

Accessories

WHAT IS FORD PROTECT

Protect yourself from the rising cost of
vehicle repairs with a Ford Protect
extended service plan.

Ford Protect Extended Service
Plans - United States Only

Ford Protect extended service plans mean
peace of mind. Extended service plans are
backed by Ford Motor Company, and
provide more protection beyond the New
Vehicle Limited Warranty coverage. When
you visit your Ford Dealer, insist on the Ford
Protect extended service plan.

Ford Protect Can Quickly Pay for Itself

One trip to the service center could easily
exceed the price of your Ford Protect
extended service plan. With the Ford
Protect extended service plan, you
minimize your risk for unexpected repair
bills and rising repair costs.

Up to 1,000+ Covered Vehicle
Components

There are four mechanical Ford Protect
extended service plans with different levels
of coverage. Ask your authorized dealer for
details.

PremiumCARE - Our most
comprehensive coverage. With over
1,000 covered components, this plan
is so complete it is probably easier to
list what is not covered.

2. ExtraCARE - Covers 113 components,

and includes many high-tech items.

3. BaseCARE - Covers 84 components.

4. PowertrainCARE - Covers 29 critical

components.

Ford Protect extended service plans are
honored by all authorized Ford dealers in
the United States, Canada and Mexico.

That means you get:
•

Reliable, quality service at any Ford or
Lincoln dealership.

•

Repairs performed by factory trained
technicians, using genuine parts.

Rental Car Reimbursement

First Day Rental Benefit

If you bring your car into your dealer for
service, we will give you a rental vehicle to
use for the day.

Extended Rental Benefits

If your vehicle is kept overnight for covered
repairs, you are eligible for rental car
coverage, warranty repairs, and field
service actions.

Roadside Assistance

Exclusive 24/7 roadside assistance,
including:

•

Towing, flat-tire change and battery
jump starts.

•

Lock-out assistance.

•

Travel expense reimbursement for
lodging, meals and rental car.

•

Assistance for taxi, shuttle, rental car
coverage or other transportation.

Transferable Coverage

If you sell your vehicle before your Ford
Protect extended service plan coverage
expires, you can transfer any remaining
coverage to the new owner. This should
give you and your potential buyer peace of
mind.

431

Ford Protect

Less Cost to Properly Maintain Your
Vehicle

The Ford Protect extended service plan
also offers a Premium Maintenance Plan
that covers all scheduled maintenance,
and selected wear items. The coverage is
prepaid, so you never have to worry about
the cost of your vehicle’s maintenance.

Covered maintenance includes:
•

Windshield wiper blades.

•

The clutch disc (if equipped).

•

Brake pads and linings.

•

Shock absorbers.

•

Struts.

•

Cabin air filter replacement every
20,000 mi (32,000 km).

Interest Free Finance Options

Just a 5% down payment provides you
with an affordable, no interest, no fee
payment program allowing you all the
security and benefits Ford Protect
extended service plan has to offer while
paying over time. You are pre-approved
with no credit check or hassles. To learn
more, call our Ford Protect extended
service plan specialists at 800-367-3377.

Ford Protect Extended Service Plan
P.O. Box 321067
Detroit, MI 48232

Ford Protect Extended Service
Plan (Canada Only)

You can get more protection for your
vehicle by purchasing a Ford Protect
extended service plan. Ford Protect
extended service plan is the only service
contract backed by Ford Motor Company
of Canada, Limited. Depending on the plan
you purchase, Ford Protect extended
service plan provides benefits such as:

•

Rental reimbursement.

•

Coverage for certain maintenance and
wear items.

•

Protection against repair costs after
your New Vehicle Limited Warranty
Coverage expires.

•

Roadside Assistance benefits.

There are several Ford Protect extended
service plans available in various time,
distance and deductible combinations.
Each plan is tailored to fit your own driving
needs, including reimbursement for towing
and rental. When you purchase Ford
Protect extended service plan, you receive
added peace-of-mind protection
throughout Canada, the United States and
Mexico, provided by a network of
participating authorized Ford Motor
Company dealers.

Note:

Repairs performed outside of Canada

and the United States are not eligible for
Ford Protect extended service plan
coverage.

This information is subject to change. Visit
your local Ford of Canada dealer or
www.ford.ca to find the Ford Protect
extended service plan that is right for you.

432

Ford Protect

GENERAL MAINTENANCE
INFORMATION

Why Maintain Your Vehicle?

Carefully following the maintenance
schedule helps protect against major repair
expenses resulting from neglect or
inadequate maintenance and may help to
increase the value of your vehicle when
you sell or trade it. Keep all receipts for
completed maintenance with your vehicle.

We have established regular maintenance
intervals for your vehicle based upon
rigorous testing. It is important that you
have your vehicle serviced at the proper
times. These intervals serve two purposes;
one is to maintain the reliability of your
vehicle and the second is to keep your cost
of owning your vehicle down.

It is your responsibility to have all
scheduled maintenance performed and to
make sure that the materials used meet
the specifications identified in this owner's
manual. See

Capacities and

Specifications

(page 363).

Failure to perform scheduled maintenance
invalidates warranty coverage on parts
affected by the lack of maintenance.

Why Maintain Your Vehicle at Your
Dealership?

Factory-Trained Technicians

Service technicians participate in extensive
factory-sponsored certification training to
help them become experts on the
operation of your vehicle. Ask your
dealership about the training and
certification their technicians have
received.

Genuine Ford and Motorcraft®
Replacement Parts

Dealerships stock Ford, Motorcraft and
Ford-authorized branded re-manufactured
replacement parts. These parts meet or
exceed our specifications. Parts installed
at your dealership carry a nationwide
24-month or unlimited mile (kilometer)
parts and labor limited warranty.

If you do not use Ford authorized parts they
may not meet our specifications and
depending on the part, it could affect
emissions compliance.

Convenience

Many dealerships have extended evening
and Saturday hours to make your service
visit more convenient and they offer one
stop shopping. They can perform any
services that are required on your vehicle,
from general maintenance to collision
repairs.

Note:

Not all dealers have extended hours

or body shops. Please contact your dealer
for details.

Protecting Your Investment

Maintenance is an investment that pays
dividends in the form of improved
reliability, durability and resale value. To
maintain the proper performance of your
vehicle and its emission control systems,
make sure you have scheduled
maintenance performed at the designated
intervals.

Your vehicle is equipped with an intelligent
oil-life monitor that determines oil life
based on engine operating conditions.

433

Scheduled Maintenance

•

Under normal operating conditions, a
message appears in the instrument
cluster display to indicate the regular
oil change interval.

•

Under severe operating conditions, the
oil change interval may reduce, and the
message interval may adjust.

High performance vehicles can be driven
in such a way that may lead to higher oil
consumption (this includes extended time
at high engine speeds, high loads, engine
braking, hard cornering maneuvers, and
track use). Under these conditions, oil
consumption of approximately 1 quart per
500 miles (1 liter per 800 km) is possible.
As a result, the engine oil level needs to be
checked at every refueling and adjusted to
maintain proper level to avoid engine
damage.

Note:

Oil level should not exceed the

maximum mark on the indicator. See

Checking the Engine Oil Level

(page 299).

Your vehicle can be driven in such a way
that dilutes and increases the level of oil
by short trips that do not allow the engine
to get to operating temperature, extended
idling, and low speed driving for long
periods of time.

When the oil change message appears in
the instrument cluster display, it is time for
an oil change. Make sure you perform the
oil change within two weeks or 500 mi
(800 km) of the message appearing. Make
sure you reset the Intelligent Oil-Life
Monitor after each oil change.

If your instrument cluster display resets
prematurely or becomes inoperative, you
should perform the oil change interval at
six months or 5,000 mi (8,000 km) from
your last oil change. Never exceed one year
or 10,000 mi (16,000 km) between oil
change intervals.

Your vehicle is very sophisticated and built
with multiple, complex, performance
systems. Every manufacturer develops
these systems using different
specifications and performance features.
That is why it is important to rely upon your
dealership to properly diagnose and repair
your vehicle.

Ford Motor Company has recommended
maintenance intervals for various parts
and component systems based upon
engineering testing. Ford Motor Company
relies upon this testing to determine the
most appropriate mileage for replacement
of oils and fluids to protect your vehicle at
the lowest overall cost to you and
recommends against maintenance
schedules that deviate from the scheduled
maintenance information.

We strongly recommend the use of only
genuine Ford, Motorcraft or
Ford-authorized re-manufactured
replacement parts engineered for your
vehicle.

Additives and Chemicals

This owner's manual and the Ford
Workshop Manual list the recommended
additives and chemicals for your vehicle.
We do not recommend using chemicals or
additives not approved by us as part of
your vehicle’s normal maintenance. Please
consult your warranty information.

Oils, Fluids and Flushing

In many cases, fluid discoloration is a
normal operating characteristic and, by
itself, does not necessarily indicate a
concern or that the fluid needs to be
changed. However, a qualified expert, such
as the factory-trained technicians at your
dealership, should inspect discolored fluids
that also show signs of overheating or
foreign material contamination
immediately.

434

Scheduled Maintenance

Make sure to change your vehicle’s oils and
fluids at the specified intervals or in
conjunction with a repair. Flushing is a
viable way to change fluid for many vehicle
sub-systems during scheduled
maintenance. It is critical that systems are
flushed only with new fluid that is the same
as that required to fill and operate the

system or using a Ford-approved flushing
chemical.

Owner Checks and Services

Make sure you perform the following basic
maintenance checks and inspections every
month or at six-month intervals.

Check every month

Engine oil level.

For severe use, high engine speed and engine loads, engine braking and track use, check

engine oil level every fuel fill-up.

Function of all interior and exterior lights.

Tires, including spare, for wear and proper pressure.

Windshield washer fluid level.

Check every six months

Battery connections. Clean if necessary.

Body and door drain holes for obstructions. Clean if necessary.

Cooling system fluid level and coolant strength.

Door weatherstrips for wear. Lubricate if necessary.

Hinges, latches and outside locks for proper operation. Lubricate if necessary.

Parking brake for proper operation.

Seatbelts and seat latches for wear and function.

Safety warning lamps operation for brake, ABS, airbag and seatbelt.

Washer spray and wiper operation. Clean or replace blades as necessary.

435

Scheduled Maintenance

Multi-Point Inspection

In order to keep your vehicle running right,
it is important to have the systems on your
vehicle checked regularly. This can help
identify potential issues and prevent major

problems. We recommend having the
following multi-point inspection performed
at every scheduled maintenance interval
to help make sure your vehicle keeps
running great.

Multi-Point inspection

Hazard warning system operation.

Accessory drive belts.

Horn operation.

Battery performance.

Radiator, cooler, heater and air conditioning

hoses.

Engine air filter.

Suspension components for leaks or

damage.

Exhaust system.

Steering and linkage.

Exterior lamps operation.

Tires, including spare, for wear and proper

pressure.

Fluid levels; fill if necessary.

Windshield for cracks, chips or pits.

For oil and fluid leaks.

Washer spray and wiper operation.

Half-shaft dust boots.

Brake, coolant recovery reservoir, automatic transmission and window washer.

If your vehicle is equipped with a temporary mobility kit, check the tire sealant expiration

Use By date on the canister. Replace as needed.

Be sure to ask your dealership service
advisor or technician about the multi-point
vehicle inspection. It is a comprehensive
way to perform a thorough inspection of
your vehicle. Your checklist gives you
immediate feedback on the overall
condition of your vehicle.

NORMAL SCHEDULED
MAINTENANCE

Intelligent Oil-Life Monitor™

Your vehicle has an Intelligent Oil-Life
Monitor that determines when you should
change the engine oil based on how you
use your vehicle. By using several
important factors in its calculations, the
monitor helps reduce the cost of owning
your vehicle and reduces environmental
waste at the same time.

436

Scheduled Maintenance

This means you do not have to remember
to change the oil on a mileage-based
schedule. Your vehicle lets you know when
an oil change is due by displaying a
message in the information display.

The following table provides examples of
vehicle use and its impact on oil change
intervals. It is a guideline only. Actual oil
change intervals depend on several factors
and generally decrease with severity of
use.

When to expect the message prompting you to change your oil

Vehicle Use and Example

Interval

Normal

7,000–10,000 mi

(11,000–16,000 km)

Normal commuting with highway driving.
No, or moderate, load or towing.
Flat to moderately hilly roads.
No extended idling.

Severe

5,000–7,500 mi

(8,000–12,000 km)

Moderate to heavy load or towing.
Mountainous or off-road conditions.
Extended idling.
Extended hot or cold operation.
High engine speeds and loads, engine braking and hard
cornering.

Extreme

3,000–5,000 mi

(4,800–8,000 km)

Maximum load or towing.
Extreme hot or cold operation.

Normal Maintenance Intervals

At every oil change interval as indicated by the information display

Change the engine oil and filter.

Rotate tires, inspect tire wear and measure the tread depth.

Perform a multi-point inspection, recommended.

Inspect the automatic transmission fluid level if your vehicle has a dipstick. Consult your
dealer for requirements.

Inspect the brake pads, rotors, hoses and the parking brake.

Inspect the engine cooling system strength and hoses.

437

Scheduled Maintenance

Ford Mustang (2024 year). Manual in english - page 13
