Ford Mustang (2024 year). Manual in english

AIR CONDITIONING SYSTEM
CAPACITY AND
SPECIFICATION - 2.3L
ECOBOOST™

WARNING:

The air conditioning

refrigerant system contains refrigerant
under high pressure. Only qualified
personnel should service the air
conditioning refrigerant system. Opening

the air conditioning refrigerant system
can cause personal injury.

Use refrigerant and oil that meets the
defined specifications.

If you do not use refrigerant and oil that
meets the defined specifications, it could
result in:
•

Component damage that your vehicle
warranty does not cover.

•

Reduced vehicle performance.

Capacities

Refrigerant Oil

Refrigerant

Variant

3.38 fl oz (100 ml)

19 oz (0.538 kg)

All.

Materials

Specification

Name

WSS-M17B21-A

R-1234yf Refrigerant(U.S.)
R-1234yf Refrigerant / Frigorigène R-1234yf(Canada)
YN-33-A(U.S.)
HS7Z-19B519-BA(Canada)

WSS-M2C300-A2

Motorcraft® R-1234yf Refrigerant PAG Oil(U.S.)
Motorcraft® R-1234yf Refrigerant PAG Oil / Huile
PAG pour frigorigène R-1234yf Motorcraft®(Canada)
YN-35(U.S. & Canada)

376

Capacities and Specifications

AIR CONDITIONING SYSTEM
CAPACITY AND
SPECIFICATION - 5.0L

WARNING:

The air conditioning

refrigerant system contains refrigerant
under high pressure. Only qualified
personnel should service the air
conditioning refrigerant system. Opening

the air conditioning refrigerant system
can cause personal injury.

Use refrigerant and oil that meets the
defined specifications.

If you do not use refrigerant and oil that
meets the defined specifications, it could
result in:
•

Component damage that your vehicle
warranty does not cover.

•

Reduced vehicle performance.

Capacities

Refrigerant Oil

Refrigerant

Variant

3.38 fl oz (100 ml)

19 oz (0.538 kg)

All.

Materials

Specification

Name

WSS-M17B21-A

R-1234yf Refrigerant(U.S.)
R-1234yf Refrigerant / Frigorigène R-1234yf(Canada)
YN-33-A(U.S.)
HS7Z-19B519-BA(Canada)

WSS-M2C300-A2

Motorcraft® R-1234yf Refrigerant PAG Oil(U.S.)
Motorcraft® R-1234yf Refrigerant PAG Oil / Huile
PAG pour frigorigène R-1234yf Motorcraft®(Canada)
YN-35(U.S. & Canada)

WASHER FLUID SPECIFICATION

Capacities

Quantity

Variant

Fill as required.

All.

377

Capacities and Specifications

Materials

Specification

Name

WSS-M14P19-A

Motorcraft® Premium Windshield Wash Concen-
trate with Bitterant(U.S.)
Motorcraft® Premium Quality Windshield Washer
Fluid / Liquide lave-glace de haute qualité Motor-
craft®(Canada)
ZC-32-B2(U.S.)
CXC-37-F/M(Canada)

MANUAL TRANSMISSION
FLUID CAPACITY AND
SPECIFICATION

Use fluid that meets the defined
specification and viscosity grade.

If you do not use fluid that meets the
defined specification and viscosity grade,
it could result in:
•

Component damage that your vehicle
warranty does not cover.

•

Reduced vehicle performance.

•

Reduced fuel economy.

Capacities

Quantity

Variant

2.5 qt (2.4 L)

6-Speed

Approximate total oil volume/capacity. Actual amount could vary between fluid changes.

Note:

Transmission Oil is “filled-for-life” –

No requirement to Service the transmission
oil.

Materials

Specification

Name

WSS-M2C200-D2

Motorcraft® Dual Clutch Transmission Fluid(U.S.)
Motorcraft® Dual Clutch Transmission Fluid / Huile
pour boîtes embrayage double Motor-
craft®(Canada)
XT-11-QDC(U.S. & Canada)

378

Capacities and Specifications

CLUTCH FLUID CAPACITY AND
SPECIFICATION

Only use fluid that meets Ford
specifications.

Materials

Specification

Name

WSS-M6C65-A2

Motorcraft® DOT 4 LV High Performance Motor
Vehicle Brake Fluid(U.S.)
Motorcraft® DOT 4 LV High Performance Motor
Vehicle Brake Fluid / Liquide de frein automobile
haute performance DOT 4 LV Motorcraft®(Canada)
PM-20(U.S. & Canada)

AUTOMATIC TRANSMISSION
FLUID CAPACITY AND
SPECIFICATION

Note:

Only use transmission fluid that

conforms to the defined specification. Use
of other fluids could result in vehicle
damage not covered by the vehicle
warranty.

Quantity

Variant

13.10 qt (12.4 L)

All

Materials

Specification

Name

WSS-M2C949-A,

Motorcraft® MERCON® ULV Automatic Transmis-
sion Fluid(U.S.)
Motorcraft® MERCON® ULV Automatic Transmis-
sion Fluid / MERCON® ULV huile pour boîtes auto-
matique Motorcraft®(Canada)
XT-12-QULV(U.S. & Canada)

379

Capacities and Specifications

BRAKE FLUID SPECIFICATION

Use fluid that meets the defined
specification and viscosity grade.

If you do not use fluid that meets the
defined specification and viscosity grade,
it could result in:
•

Component damage that your vehicle
warranty does not cover.

•

Reduced brake performance.

Note:

We recommend you use Dot 4 Low

Viscosity (LV) High Performance Brake Fluid
meeting WSS-M6C65-A2 specifications or
ISO 4925 Class 6 standards. If you use any
fluid other than the recommended fluid, it
could cause reduced brake performance
and not meet our performance standards.
Keep brake fluid clean and dry.
Contamination with dirt, water, petroleum
products or other materials could result in
brake system damage and possible failure.

Capacities

Quantity

Variant

Fill as required.

All.

Materials

Specification

Name

WSS-M6C65-A2

REAR AXLE FLUID CAPACITY
AND SPECIFICATION

Use fluid that meets the defined
specification and viscosity grade.

If you do not use fluid that meets the
defined specification and viscosity grade,
it could result in:
•

Component damage that your vehicle
warranty does not cover.

•

Reduced vehicle performance.

Capacities

Quantity

Variant

1.6 qt (1.5 L)

All.

For complete refill of our limited slip axles, add 3.28 fl oz (97 ml) of Additive Friction

Modifier XL-3 or equivalent meeting specification EST-M2C118-A. Include this friction
modifier in the total fluid capacity. Our rear axles contain a synthetic lubricant that does
not require changing unless you submerge the axle in water.

380

Capacities and Specifications

VEHICLE IDENTIFICATION
NUMBER

LOCATING THE VEHICLE
IDENTIFICATION NUMBER

The vehicle identification number is on the
left-hand side of the instrument panel.

E311767

Note:

In the illustration, XXXX is

representative of your vehicle identification
number.

VEHICLE IDENTIFICATION
NUMBER OVERVIEW

The vehicle identification number contains
the following information:

E142477

World manufacturer identifier.

Brake system, gross vehicle
weight rating, restraint devices
and their locations.

Make, vehicle line, series, body
type.

Engine or motor type.

Check digit.

Model year.

Assembly plant.

Production sequence number.

382

Vehicle Identification

WHAT IS A CONNECTED
VEHICLE

A connected vehicle has technology that
allows your vehicle to connect to a mobile
network and for you to access a range of
features. When used in conjunction with
the FordPass app, it could allow you to
monitor and control your vehicle further,
for example checking the tire pressures,
the fuel level and the vehicle location. For
additional information, refer to the local
Ford website.

CONNECTED VEHICLE
REQUIREMENTS

Connected service and related feature
functionality requires a compatible vehicle
network.

Some remote features require additional
service activation. Log in to your Ford
account for details. Some restrictions, third
party terms and message or data rates
may apply.

CONNECTED VEHICLE
LIMITATIONS

Evolving technology, cellular networks, or
regulations could affect functionality and
availability, or continued provision of some
features. These changes could even stop
some features from functioning.

CONNECTING THE VEHICLE TO
A MOBILE NETWORK

WHAT IS THE MODEM

The modem allows access to a
range of features built into your
vehicle.

ENABLING AND DISABLING THE
MODEM

Press

Settings

on the touchscreen.

2. Press

Connectivity

3. Press

Connected Vehicle Features

4. Switch vehicle connectivity on or off.

CONNECTING FORDPASS TO THE
MODEM

Make sure that the modem is enabled
using the vehicle settings menu.

2. Open the FordPass app on your device

and log in.

3. Add your vehicle or select your vehicle

if already added.

4. Select the option to activate your

vehicle.

5. Make sure that the name on the screen

matches the name shown in your
FordPass account.

6. Confirm that FordPass account is

connected to the modem.

CONNECTING THE VEHICLE TO
A WI-FI NETWORK

E280315

Press the button on the

touchscreen.

2. Press

Connectivity

3. Press

Wi-Fi

4. Switch

Wi-Fi

on.

5. Press

View Available Networks

6. Select an available Wi-Fi network.

Note:

Enter the network password to

connect to a secure network.

383

Connected Vehicle

CONNECTED VEHICLE –
TROUBLESHOOTING

CONNECTED VEHICLE –
FREQUENTLY ASKED QUESTIONS
- VEHICLES WITH: MODEM

Why can I not confirm the
connection of my FordPass
account to the modem?

•

The modem is not enabled. Switch
vehicle connectivity on.

•

The network signal is weak. Move your
vehicle closer to a place where the
network signal is not obstructed.

CONNECTED VEHICLE –
FREQUENTLY ASKED QUESTIONS
- VEHICLES WITH: SYNC 4

Why can I not confirm the

connection of my FordPass
account to the modem?

•

The modem is not enabled. Switch
vehicle connectivity on.

•

The network signal is weak. Move your
vehicle closer to a place where the
network signal is not obstructed.

Why can I not connect to a Wi-Fi
network?

•

You entered the wrong network
password. Enter the correct password.

•

The network signal is weak. Move your
vehicle closer to the Wi-Fi router or to
a place where the network signal is not
obstructed.

•

There are multiple access points in
range with the same network name.
Choose a unique name for your
network. Do not use the default name
unless it contains a unique identifier,
for example as part of the MAC
address.

Why does the Wi-Fi connection
disconnect after successful
connection?

•

The network signal is weak. Move your
vehicle closer to the Wi-Fi router or to
a place where the network signal is not
obstructed.

What can I do if I am close to a Wi-
Fi router but the network signal
strength is weak?

•

If your vehicle has a heated windshield,
position your vehicle so that the
windshield is not facing the Wi-Fi
router.

•

If your vehicle has metallic tinting on
the windows but not on the windshield,
position your vehicle so that the
windshield is facing the Wi-Fi router or
open the windows that are facing the
router.

•

If your vehicle has metallic tinting on
the windows and the windshield, open
the windows that are facing the router.

•

If your vehicle is in a garage and you
have the garage door closed, open the
garage door as it could block the signal.

384

Connected Vehicle

Why can I not see a network I
expect to see in the list of available
networks?

•

The network is hidden. Make the
network visible and try again, or
manually add a network in the Wi-Fi
settings menu.

•

Some network security types are not
supported, for example WEP.

Why do software downloads take
too long?

•

The network signal is weak. Move your
vehicle closer to the Wi-Fi router or to
a place where the network signal is not
obstructed.

•

Wi-Fi network is in high demand or has
a slow Internet connection. Use a more
reliable Wi-Fi network.

Why does the software not update
when the system seems to connect

to a Wi-Fi network and the signal
strength is excellent?

•

No software update is available at this
time.

•

Select automatic updates option in the
settings menu to enable automatic
software update or contact an
authorized dealer.

•

There could be a connection problem.
Test the network using another device.

385

Connected Vehicle

CREATING A VEHICLE WI-FI
HOTSPOT

You can create a Wi-Fi hotspot in your
vehicle and allow devices to connect to it
for access to the Internet.

E280315

Select the settings option on the
feature bar.

Press

Vehicle Hotspot

Note:

The vehicle hotspot default setting

is on.

2. Press

Settings

3. Press

Edit

4. Press

Hotspot visibility

Note:

The hotspot visibility default setting

is on.

Finding the Wi-Fi Hotspot Name
and Password

E280315

Select the settings option on the
feature bar.

Press

Vehicle Hotspot

2. Press

Settings

Note:

The network name is the hotspot

name.

3. Press

View Password

Connecting a Device to the Wi-Fi
Hotspot

On your device, switch Wi-Fi on and
select the hotspot from the list of
available Wi-Fi networks.

2. When prompted, enter the password.

Purchasing a Data Plan

Connect a device to the hotspot.

Note:

The vehicle network carrier’s portal

opens on your device.

2. If the portal does not open on your

device, open a website and it redirects
to the vehicle network carrier’s portal.

Note:

Secure websites do not redirect.

3. Follow the instructions on the carrier

portal to purchase a plan.

Note:

If you have an active plan, the system

does not redirect to the vehicle network
carrier’s portal when you connect a device.
Visit the vehicle network carrier’s website
to purchase more data.

Note:

If data usage information is available

in the vehicle hotspot menu, it is
approximate.

Note:

If you carry out a factory reset, the

system does not remove your vehicle from
your vehicle network carrier’s account. To
remove your vehicle from the account,
contact your vehicle network carrier.

Note:

The vehicle network carrier provides

Vehicle Hotspot services, subject to your
vehicle network carrier agreement, coverage
and availability.

CHANGING THE VEHICLE WI-
FI HOTSPOT NAME OR
PASSWORD

E280315

Select the settings option on the
feature bar.

Press

Vehicle Hotspot

2. Press

Settings

3. Press

Edit

4. Press

Change Network Name

5. Enter your required network name.

6. Press

Done

Press

Change Password

8. Enter your required password.

9. Press

Done

386

Vehicle Wi-Fi Hotspot

Changing the Wi-Fi Hotspot
Frequency

Note:

The vehicle hotspot frequency band

is selectable depending upon your device
capabilities. You will not be able to connect
your device to the vehicle hotspot if it does
not support the selected frequency band.

E280315

Select the settings option on the
feature bar.

Press

Vehicle Hotspot

2. Press

Settings

3. Press

Edit

4. Select a frequency.

VEHICLE WI-FI HOTSPOT –
TROUBLESHOOTING

VEHICLE WI-FI HOTSPOT –
FREQUENTLY ASKED QUESTIONS

Why can I not see the Wi-Fi hotspot
name when I search for Wi-Fi
networks on my cell phone or other
device?

•

Make sure Wi-Fi hotspot visibility is on.

•

The system does not provide a Wi-Fi
hotspot at this time.

•

Check what frequency the hotspot is
transmitting in the vehicle hotspot
settings menu. If the frequency is 5 GHz
and your device cannot see the
network, change the frequency to 2.4
GHz.

387

Vehicle Wi-Fi Hotspot

AUDIO SYSTEM
PRECAUTIONS

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

Listening to loud audio for long periods of
time could damage your hearing.

SWITCHING THE AUDIO UNIT
ON AND OFF

Press the button on the volume
control.

SELECTING THE AUDIO
SOURCE

Audio Unit

E308143

Press to open the media source
menu.

You can press this multiple times to
change the audio source or scroll through
the media sources.

Touchscreen

Press

Sources

on the touchscreen to open

the media source menu.

PLAYING OR PAUSING THE
AUDIO SOURCE

Audio Unit

Press the button to pause
playback. Press again to resume
playback.

Touchscreen

Press the button to pause
playback. Press again to resume
playback.

Note:

Not all sources can be paused.

ADJUSTING THE VOLUME

E248939

Turn to adjust the volume.

Some vehicles may be able to adjust the
volume using buttons on the steering
wheel.

388

Audio System

SWITCHING SHUFFLE MODE
ON AND OFF

Press the button on the
touchscreen to switch shuffle
mode on or off.

Note:

Not all sources have shuffle mode.

SWITCHING REPEAT MODE ON
AND OFF

Press the button on the
touchscreen to switch repeat
mode on or off.

Note:

Not all sources have repeat mode.

SETTING A MEMORY PRESET

Select a station or channel.

2. Press and hold a memory preset button

on the touchscreen.

Note:

The audio mutes briefly while the

system saves the preset and returns once it
is stored.

Note:

You can save presets from multiple

sources to the memory preset bar.

MUTING THE AUDIO

Press to mute the signal. Press
again to restore the signal.

ADJUSTING THE SOUND
SETTINGS

Balance and Fade

(If Equipped)

Press

Settings

on the touchscreen.

2. Press

Sound Settings

3. Press

Balance / Fade

4. Press the arrows to adjust the settings.

Tone Settings

Press

Settings

on the touchscreen.

2. Press

Sound Settings

3. Press

Tone Settings

4. Press the arrows or slider bar to adjust

the settings.

Speed Compensated Volume

Press

Settings

on the touchscreen.

2. Press

Sound Settings

3. Press

Speed Compensated Volume

4. Press a setting.

Occupancy Mode

(If Equipped)

Press

Settings

on the touchscreen.

2. Press

Sound Settings

3. Press

Occupancy Mode

4. Press a setting.

Sound Mode

(If Equipped)

Press

Settings

on the touchscreen.

2. Press

Sound Settings

3. Press

Sound Mode

4. Press a setting.

SETTING THE CLOCK AND
DATE

Press

Settings

on the touchscreen.

2. Press

Clock Settings

3. Set the time.

Note:

The

and

options are not

available if

24-hour mode

is on.

389

Audio System

Switching Automatic Time
Updates On and Off

Press

Settings

on the touchscreen.

2. Press

Clock Settings

3. Switch

Auto Time Update

on or off.

FM RADIO

FM RADIO LIMITATIONS

The further you travel from a FM station,
the weaker the signal and the weaker the
reception.

Hills, mountains, tall buildings, bridges,
tunnels, freeway overpasses, parking
garages, dense tree foliage and
thunderstorms can interfere with the
reception.

When you pass a ground-based broadcast
repeating tower, a stronger signal may
overtake a weaker one and result in the
audio system muting.

SELECTING AN FM RADIO
STATION

Manually Selecting a Radio
Station

E356421

Press the button on the radio
tuner to go up the frequency
band.

E356422

Press the button on the radio
tuner to go down the frequency
band.

Using Seek

E357091

Press to seek the next station up
the frequency band.

E357092

Press to seek the next station
down the frequency band.

Using the Station List

Press the search button on the radio
screen.

2. Press a radio station from the list.

SWITCHING THE DISPLAY ON
AND OFF

Audio Unit

E272035

Press the button.

Touchscreen

To switch the display off:

Press

Settings

on the touchscreen.

2. Press

Display Settings

3. Press

Display Off

Note:

The display defaults to on each time

you switch your vehicle on.

To switch the display on, press anywhere
on the touchscreen.

DIGITAL RADIO

WHAT IS DIGITAL RADIO

HD Radio™ technology is the digital
evolution of analog FM radio.

For additional information, visit

www.HDRadio.com

HD Radio Technology is manufactured
under license from iBiquity Digital
Corporation and foreign patents. HD Radio
and the HD and HD Radio logos are
proprietary trademarks of XPERI. The
vehicle manufacturer and XPERI are not
responsible for the content sent using HD
Radio technology. Content may be
changed, added or deleted at any time at
the station owner's discretion.

390

Audio System

HOW DOES DIGITAL RADIO WORK

Your system has a special receiver that
allows it to receive digital broadcasts in
addition to analog broadcasts.

HD1 signifies the main programming status
and is available in both analog and digital
broadcasts. Other multicast stations are
only available digitally and could contain
new or different content.

Note:

When the system first receives an

HD1 station, it plays the station in the analog
version until it verifies the station is an HD
Radio station. Then it shifts to the digital
version.

Note:

There is an audio mute delay when

switching to an HD2 or HD3 station because
the system has to reacquire and decode the
digital signal.

DIGITAL RADIO LIMITATIONS

If you are outside the reception area, the
system could not work.

If you are on the fringe of the reception
area, the station could mute due to weak
signal strength.

Note:

If you are listening to HD1, the system

changes back to the analog broadcast until
the digital broadcast is available again. If
you are listening to any other multicast
channels, the station mutes and stays
muted unless it is able to connect to the
digital signal again.

Depending on the station quality, you could
hear a slight sound change when the
station changes between analog and
digital audio.

You cannot access a saved HD station if
your vehicle is outside the station’s
reception area.

SWITCHING DIGITAL RADIO
RECEPTION ON AND OFF

Press

Settings

on the touchscreen.

2. Press

Radio Settings

3. Switch

HD Radio

on or off.

DIGITAL RADIO INDICATORS

HD Radio Indicator

The indicator appears when HD Radio is
on and you tune to a station broadcasting
HD Radio technology.

E142616

The color of the indicator changes to
indicate the system status.

Gray indicates the system is acquiring a
digital station.

Orange indicates digital audio is playing.

Multicast Indicator

The multicast indicator appears if the
current station is broadcasting multiple
digital broadcasts. The highlighted
numbers indicate additional digital
channels available.

Note:

For stations that have more than one

HD multicast, the HD indicator and radio
text appears as a button. Press the button
to cycle through all of the HD stations on
that specific frequency.

391

Audio System

SATELLITE RADIO

WHAT IS SATELLITE RADIO

Your factory-installed SiriusXM radio
system includes a limited subscription
term, which begins on the date of sale or
lease of your vehicle. See an authorized
dealer for availability.

For additional information about extended
subscription terms, visit

www.SiriusXM.com

in the United States,

www.SiriusXM.ca

Canada, or call SiriusXM at
1-888-539-7474.

Note:

SiriusXM reserves the unrestricted

right to change, rearrange, add or delete
programming including canceling, moving
or adding particular channels, and its prices,
at any time, with or without notice to you.
Neither SiriusXM and its affiliates nor Ford
Motor Company and its affiliates will be
liable to you or any third party for any such
modification, suspension or termination.

SATELLITE RADIO LIMITATIONS

For optimal reception performance, keep
the antenna clear of snow and ice build-up
and keep luggage and other material as
far away from the antenna as possible.
Placing luggage over the antenna may
reduce performance. Factory-installed and
aftermarket vehicle structures including,
but not limited to, roof racks and soft top
roofs in a partially open position could
reduce reception performance.

Hills, mountains, tall buildings, bridges,
tunnels, freeway overpasses, parking
garages, dense tree foliage and
thunderstorms can interfere with your
reception.

When you pass a ground-based
broadcast-repeating tower, a stronger
signal may overtake a weaker one and
could result in the audio system muting.
Your display could show an error message
to indicate the interference.

LOCATING THE SATELLITE RADIO
IDENTIFICATION NUMBER

Select SiriusXM as the audio source.

2. Tune to channel 0.

SELECTING A CHANNEL

Manually Selecting a Channel

E328569

E328570

Press the button to find the
previous or next available radio
channel.

Linear Tuner

The linear tuner is displayed when
manually selecting a channel. You can
swipe left or right on the linear tuner
carousel to navigate through the channel
list. Tap on a channel title to listen to it.

Using Direct Tune

Press the channel up or down button
to open the linear tuner screen.

2. Press

Direct Tune

to open the number

pad.

3. Enter the channel you prefer.

Using Browse

Press

Browse

2. Select a channel.

392

Audio System

SATELLITE RADIO SETTINGS

Subscription

Your subscription status is displayed. You
can subscribe or manage your subscription
directly from the touchscreen.

SiriusXM Favorites

While you are listening to SiriusXM, you can
save favorites by:

•

Tapping the currently tuned channel
or show logo on the SiriusXM audio
screen.

•

Tuning to a channel or show you want
to save as a favorite. Navigate to the
SiriusXM Favorites screen and press
the Add Current button. The currently
tuned channel or show is saved as a
favorite.

•

Saving a radio preset. This saves the
currently tuned SiriusXM channel or
show as a favorite

Note:

Requires a trial or active subscription

to use.

Listening History

Listening history is a list of recently listened
to SiriusXM content. You can view, manage
and reset the listening history using the
controls on the touchscreen.

Note:

Requires a trial or active subscription

to use.

Help and Support

You can contact SiriusXM Customer Care
directly from the operating system and
view information required to manage your
SiriusXM account.

393

Audio System

AUDIO SYSTEM – TROUBLESHOOTING

AUDIO SYSTEM – INFORMATION MESSAGES

Satellite Radio Troubleshooting

Recommended Action

Potential Effects

Error Message

Internet connectivity is

turned off. See

Connected

Vehicle

(page 383).

Internet streaming and On

Demand shows are unavail-

able and some SiriusXM

features are disabled.

Connectivity Disabled

SYNC attempts to connect.

See

Satellite Radio Limit-

ations

(page 392). Switch to

a satellite connection for the
current channel if the option

is available.

Audio system may mute.

Switch to Satellite button

may be displayed on the

SiriusXM audio screen if the
channel is also available via

satellite.

No Internet

Antenna may be obstructed
or satellite reception is weak
in your location. See

Satel-

lite Radio Limitations

(page 392). Switch to an

internet connection for the

current channel if the option

is available.

Audio system may mute.

Switch to Internet button

may be displayed on the

SiriusXM audio screen if the
channel is also available via

streaming.

No Satellite Signal

Allow some time for the

audio to load or tune to a

different channel.

Audio system may mute

while the audio attempts to

load.

Slow Network Connection

A temporary update may be
in progress. Allow some time
before retrying to tune to the

channel. If the issue

continues, the channel may

no longer be available.

Audio system may mute.

Radio may tune to a

different channel.

Channel Unavailable

A temporary update may be
in progress. Allow some time

before retrying to play the

episode. If the issue

continues, the episode may

no longer be available.

Audio system may mute.

Radio may tune to a

different channel.

Episode Unavailable

394

Audio System

Recommended Action

Potential Effects

Error Message

Allow some time and retry

the action.

Audio system may mute.

Radio may tune to a

different channel.

Something went wrong

Your subscription has

expired or you have not yet

subscribed for access to the

listed content. Navigate to

Subscription under the

Satellite Radio Settings

menu. If you have an active

subscription which includes
the listed channel or content

and you see this error, you

may need to refresh your

radio. To refresh your Siri-

usXM radio, visit www.siri-

usxm.com/refresh in the US,

or www.siriusxm.ca/refresh

in Canada.

You may need to provide

your SiriusXM Radio identific-

ation number. See

Locating the Satellite

Radio Identification

Number

(page 392).

Cannot listen to selected

content. Content may

appear grayed out and some

features may be disabled.

Subscribe to Listen

395

Audio System

Recommended Action

Potential Effects

Error Message

Your subscription does not

include access to the listed

content. You may need to

upgrade your subscription.

Navigate to Subscription

under the Satellite Radio

Settings menu. If you have

an active subscription which

includes the listed channel

or content and you see this

error, you may need to

refresh your radio. To refresh

your SiriusXM radio, visit

www.siriusxm.com/refresh

in the US, or www.siri-

usxm.ca/refresh in Canada.

You may need to provide

your SiriusXM Radio identific-

ation number. See

Locating the Satellite

Radio Identification

Number

(page 392).

Cannot listen to selected

content. Content may

appear grayed out and some

features may be disabled.

Upgrade to Listen

Content is not available in

your location or SiriusXM is

unable to determine your

location. Tuning to a

different channel may

resolve the issue.

Audio may mute. Not avail-

able in your location or

Unable to determine your

location may be displayed.

Location Restricted Content

The Block Explicit Content

filter is turned on. Navigate

to Listener Settings under

the Satellite Radio Settings

menu to access the Block

Explicit Content filter.

Navigate to Listener

Settings. See

Satellite

Radio Settings

(page 393).

Audio may mute. Radio may

tune to a different channel.

Channel Blocked

If issue persists, you may

need to visit an authorized

dealer for service.

Audio may mute. Access to

SiriusXM features may be

unavailable.

Antenna Problem or Hard-

ware Problem

396

Audio System

Recommended Action

Potential Effects

Error Message

Allow SiriusXM some time

to complete updating.

Audio may mute.

SiriusXM Updating...

No action necessary. If

loading time is longer than

usual, See

Satellite Radio

Settings

(page 393).

Audio may mute. Content

may be temporarily unavail-

able while loading.

No action necessary. Allow

SiriusXM some time to finish

Audio may mute. Content

and controls may be

temporarily unavailable.

SiriusXM Loading...

397

Audio System

CENTER DISPLAY
PRECAUTIONS

WARNING:

Driving while distracted

CENTER DISPLAY
LIMITATIONS

Speed-restricted Features

For your safety, features that are not
critical while driving are not available when
the vehicle is moving at or above 5 mph
(8 km/h).

STATUS BAR

The bar is on top of the display and
indicates the status of your vehicle's
features.

Audio System

E353221

Audio system muted.

Connected Device

Cell phone microphone muted.

E353213

Phone call in progress.

E353208

Media player connected using

Bluetooth®

Cell phone network signal
strength.

Cell phone roaming.

E335295

Text message received.

E353216

Unread email message.

Automatic crash notification
system off.

E335293

Cell phone battery status.

Vehicle Data

E353219

Wi-Fi available.

Wi-Fi connected.

Vehicle data sharing on.

E335292

Vehicle data sharing off.

Vehicle location sharing on.

Vehicle data and vehicle location
sharing on.

398

Center Display Overview

Vehicle Software Update

See

Software Update Indicators

(page

428).

Wireless Accessory Charger

E353214

Wireless accessory charger
active.

HOME SCREEN

Features, such as navigation, audio and
phone, are located in the main portion of
the display. The icons located on the side
of the display allow you to access other
vehicle features and settings.

E280315

Press to adjust system settings.

E335299

Press to view features.

Note:

The icon may be different depending

on your vehicle.

E353220

Press to search for and use
compatible apps on your iOS or
Android device.

FAVORITE

E381409

Press the button on the
instrument panel to turn a
feature on or off.

Assigning a Feature

If there is no feature assigned:

E381409

Press the button on the

instrument panel.

2. Follow the prompts on the

touchscreen.

To change the assigned feature:

Press

Features

on the touchscreen.

2. Press

Edit Favorite

Note:

If you assign an exhaust mode to the

favorite button, pressing the button
activates the exhaust mode, and pressing
it again restores the previous exhaust mode.

INFORMATION ON DEMAND
SCREEN

The information on demand screen
displays cards on the side of the display
and allows you to see information from
different features.

You can swipe up or down to view a
different card.

Note:

On some screens, you can swipe a

card toward the center of the screen to
move the content into the main screen.

CENTER DISPLAY SETTINGS

Adjusting the Display Brightness

Press

Settings

on the touchscreen.

2. Press

Center Display

3. Press

Brightness

4. Drag the slider left or right.

Valet Mode

Valet mode allows you to lock the system.
No information is accessible until the
system is unlocked with the correct PIN.

When you select valet mode, a pop up
appears informing you that a four digit PIN
must be entered to enable and disable
valet mode. You can use any PIN you
choose, but you must use the same PIN to
disable valet mode. The system asks you
to input the code.

399

Center Display Overview

TRACK APPS

TRACK APPS PRECAUTIONS

WARNING:

Track Apps™

is for

track use only. Remember that even
advanced technology cannot defy the
laws of physics. It is always possible to
lose control of a vehicle due to
inappropriate driver input for the
conditions. Aggressive driving on any
road condition can cause you to lose

control of your vehicle increasing the risk
of personal injury or property damage.

Note:

Track apps are for track use only. Do

not use them under any other driving
conditions.

Note:

The pre-collision assist system turns

off when using Track apps or when you
switch off your stability control system.

TRACK APPS OVERVIEW

From the My Mustang menu, press

Track

Apps

E385062

Acceleration timer.

Brake performance.

Lap timer.

Launch settings.

402

My Mustang

Performance shift indicator.

Drift brake.

Line lock.

Launch control.

Rev match.

ACCELERATION TIMER

Displays your vehicle's rate of acceleration
for a given speed or distance range.

Note:

Test events vary depending on the

measurement unit conventions selected.

Using Acceleration Timer

From the Track Apps menu, press

Acceleration Timer

2. Select a drive type.

3. Select a start type.

4. Press

Start

Note:

The start button is not available until

a drive type and start type are selected.

5. Press the OK button on the steering

wheel to start the timer.

When finished, press OK for more options.

Results

To view your timer results:

From the acceleration timer menu,
press

Results

To clear results without clearing all-time
best:

Press

Clear

2. Press

Yes

To clear all results.

Press

Clear All

2. Press

Yes

BRAKE PERFORMANCE

Displays your vehicle's rate of deceleration
for a given speed range.

Note:

Test events vary depending on the

measurement unit conventions selected.

Using Brake Performance

From the Track Apps menu, press

Brake Performance

2. Select a speed range.

3. Press

Start

4. Press the OK button on the steering

wheel.

When finished, press OK for more options.

Results

To view your results:

From the brake performance menu,
press

Results

To clear results without clearing all-time
best:

Press

Clear

2. Press

Yes

To clear all results.

Press

Clear All

2. Press

Yes

MANUAL LAP TIMER

Gives you the ability to record lap times at
three separate tracks.

403

My Mustang

Note:

Test events vary depending on the

measurement unit conventions selected.

Using Lap Timer

From the Track Apps menu, press

Lap

Timer

2. Select a track.

Note:

You can edit the track names.

3. Press

Start

4. Press the OK button on the steering

wheel.

Note:

You can interrupt a session at any

time by holding the OK button on the
steering wheel.

When finished, press OK for more options.

Results

To view your results:

From the lap timer menu, press

Results

To clear results without clearing all-time
best:

Press

Clear

2. Press

Yes

To clear all results.

Press

Clear All

2. Press

Yes

PERFORMANCE SHIFT
INDICATOR - MANUAL
TRANSMISSION

The performance shift indicator allows you
to set the point at which you want to be
alerted to shift gears, through audible and
visual alerts. You can choose different
graphic themes that represent the engine's
rotation.

From the Track Apps menu, press

Performance Shift Indicator

to reach

the menu.

E385733

2. From the menu, you can:

•

Set the light mode between off, tach,
track and drag.

•

Set a shift point within the allowable
RPM range in increments of 100.

•

Enable or disable the shift tone, based
on the set shift point.

Note:

To enable or disable the feature, you

must choose a light mode.

LINE LOCK

Line lock maintains brake force at the front
wheels, allowing the rear wheels to spin
with minimal vehicle movement. It is
intended to condition the rear tires to
maximize traction prior to track use.

Note:

Line lock is a feature intended for use

at tracks only and should not be used on
public roadways.

Note:

Use of this feature could result in

significantly increased rear tire wear.

There are three line lock stages:
•

Initiated.

•

Engaged.

•

Off.

404

My Mustang

Initiating Line Lock

The initiation stage verifies that the vehicle
is ready for line lock function, and confirms
driver intent.

From the track apps menu, press

Line

Lock

The following conditions must be met to
initialize line lock:
•

The vehicle is on a level surface.

•

The engine is running.

•

The vehicle is traveling less than
25 mph (40 km/h).

•

Selectable drive mode is not in wet
mode (if equipped).

•

There are no electronic stability control
faults.

•

A spare tire is not installed.

•

The parking brake is not applied.

•

Auto hold is turned off.

•

Adaptive cruise control is not active.

•

Both doors are closed.

If you want to cancel line lock once it is
initialized, press the OK button on the
steering wheel. Once initiated, line lock is
prepared for activation and remains
initiated up to 25 mph (40 km/h). If vehicle
speed exceeds 25 mph (40 km/h), line lock
automatically cancels.

Engaging Line Lock

Follow the prompts in the instrument
cluster display to engage line lock after it
is initialized. To engage, firmly apply the
brakes. Then press the OK button. Once
engaged, release the brake pedal. The
front brakes remain applied and the rear
brakes release. At this point, the
engagement timer is initiated and shown
on the instrument cluster display.

The following conditions must be met to
engage line lock:
•

The vehicle is on a level surface.

•

The engine is running.

•

The vehicle is stopped.

•

The parking brake is not applied.

•

Both doors are closed.

•

The transmission is in a forward gear.

•

There are no electronic stability control
faults.

•

The steering wheel is in the straight
ahead position.

•

A spare tire is not installed.

•

Auto hold is turned off.

•

Adaptive cruise control is not active.

Releasing Line Lock

While line lock is engaged, you can exit
(release) the feature using the OK button.
When you press the OK button, line lock
releases immediately and normal vehicle
function resumes. When line lock engages,
a countdown timer shows the remaining
time before line lock is released
automatically. If you exceed the time limit,
or another vehicle condition requires line
lock to release, the system safely
disengages and normal vehicle function
resumes.

Note:

If you apply the brake pedal or

parking brake while line lock is engaged, line
lock automatically cancels and normal
brake function resumes.

405

My Mustang

Ford Mustang (2024 year). Manual in english - page 12
