Ford Mustang (2024 year). Manual in english

E372630

A vehicle image illuminates if there is a
vehicle detected in front of you.

Note:

When adaptive cruise control is

active, the speedometer may vary slightly
from the set speed displayed in the
instrument cluster display.

Manually Changing the Set Speed

E246884

Press the SET+ button to
increase the set speed in small
increments. Press and hold the

SET+ button to increase set speed in large
increments. Release the button when the
indicated set speed reaches the preferred
speed.

E246885

Press the SET- button to
decrease the set speed in small
increments. Press and hold the

SET- button to decrease the set speed in
large increments. Release the button when
the indicated set speed reaches the
preferred speed.

You can also press the accelerator or brake
pedal until you reach the speed you prefer.
Press the SET+ or SET- button to select
the current speed as the set speed.

The system may apply the brakes to slow
the vehicle to the new set speed. The set
speed continuously displays in the
instrument cluster display when the
system is active.

SETTING THE ADAPTIVE
CRUISE CONTROL SPEED -
AUTOMATIC TRANSMISSION

Drive to the speed you prefer.

E246884

E246885

Press the SET+ or SET- buttons
to set the current speed.

Take your foot off the accelerator pedal.

The indicator, current gap setting and set
speed appear in the instrument cluster
display.

A vehicle image illuminates if there is a
vehicle detected in front of you.

E372630

Note:

When adaptive cruise control is

active, the speedometer may vary slightly
from the set speed displayed in the
instrument cluster display.

Setting the Adaptive Cruise Speed
from a Complete Stop

E246884

E246885

Press the SET+ or SET- buttons
while keeping the brake pedal
fully pressed.

214

Adaptive Cruise Control

(If Equipped)

The set speed adjusts to 20 km/h when in
metric units or 15 mph when in imperial
units.

The indicator, current gap setting and set
speed appear in the instrument cluster
display.

Note:

The system activates from a

complete stop only when it detects a lead
vehicle in close proximity.

Manually Changing the Set Speed

E246884

Press the SET+ button to
increase the set speed in small
increments. Press and hold the

SET+ button to increase set speed in large
increments. Release the button when the
indicated set speed reaches the preferred
speed.

E246885

Press the SET- button to
decrease the set speed in small
increments. Press and hold the

SET- button to decrease the set speed in
large increments. Release the button when
the indicated set speed reaches the
preferred speed.

You can also press the accelerator or brake
pedal until you reach the speed you prefer.
Press the SET+ or SET- button to select
the current speed as the set speed.

The system may apply the brakes to slow
the vehicle to the new set speed. The set
speed continuously displays in the
instrument cluster display when the
system is active.

SETTING THE ADAPTIVE
CRUISE CONTROL GAP

Press the button to cycle
through the four gap settings.

E372631

The selected gap appears in the
instrument cluster display as shown by the
bars in the image.

Note:

The gap setting is time dependent

and therefore, the distance adjusts with your
vehicle speed.

Note:

It is your responsibility to select a gap

appropriate to the driving conditions.

Adaptive Cruise Control Gap Settings

Dynamic

Behavior

Gap Distance

Graphic

Display,

Bars Indic-

ated

Between

Vehicles

Sport.

Closest.

Normal.

Close.

Normal.

Medium.

Comfort.

Far.

Each time you switch the system on, it
selects the last chosen gap setting.

Following a Vehicle

When a vehicle ahead of you enters the
same lane or a slower vehicle is ahead in
the same lane, the vehicle speed adjusts
to maintain the gap setting.

215

Adaptive Cruise Control

(If Equipped)

Note:

When you are following a vehicle and

you switch on a turn signal lamp, adaptive
cruise control may provide a small,
temporary acceleration to help you pass.

Your vehicle maintains a consistent gap
from the vehicle ahead until:
•

The vehicle in front of you accelerates
to a speed above the set speed.

•

The vehicle in front of you moves out
of the lane you are in.

•

You set a new gap distance.

The system applies the brakes to slow
down your vehicle to maintain a safe gap
distance from the vehicle in front of you.
The system only applies limited braking.
You can override the system by applying
the brakes.

Note:

The brakes may emit noise when

applied by the system.

If the system determines that its maximum
braking level is not sufficient, an audible
warning sounds, a message appears in the
instrument cluster display and an indicator
flashes when the system continues to
brake. Take immediate action.

CANCELING THE SET SPEED

E308130

Press the button or tap the brake
pedal.

The set speed does not erase.

RESUMING THE SET SPEED -
MANUAL TRANSMISSION

E308130

Press the button.

Your vehicle speed returns to the
previously set speed and gap setting. The
set speed displays continuously in the
information display when the system is
active.

Note:

Only use resume if you are aware of

the set speed and intend to return to it.

RESUMING THE SET SPEED -
AUTOMATIC TRANSMISSION

E308130

Press the button.

Your vehicle speed returns to the
previously set speed and gap setting. The
set speed displays continuously in the
instrument cluster display when the
system is active.

Note:

Only use resume if you are aware of

the set speed and intend to return to it.

Resuming the Set Speed from a
Complete Stop

(If Equipped)

If your vehicle follows a vehicle to a
complete stop and remains stationary for
less than a few seconds, your vehicle
accelerates from a stationary position to
follow the vehicle ahead.

If your vehicle follows a vehicle to a
complete stop and remains stationary for
more than a few seconds, an indicator and
message displays.

216

Adaptive Cruise Control

(If Equipped)

E375927

Action

Message

Cruise control does not resume automatic-

ally when this display is active.

Stopped

If the lead vehicle begins to move, you are

prompted to press the resume button.

Press button to resume

Press and release the button or use the

accelerator pedal to resume following the

lead vehicle.

Displays when on a limited access highway
after following a vehicle to a complete stop.

In this situation, the vehicle resumes

following the lead vehicle without a button
press or pressing the accelerator pedal. The

system can remain in auto-resume state

for approximately 30 seconds, after which

it no longer automatically resumes.

Auto-Resume

OVERRIDING THE SET SPEED

WARNING:

If you override the

system by pressing the accelerator
pedal, it does not automatically apply
the brakes to maintain a gap from any
vehicle ahead.

When you press the accelerator pedal, you
override the set speed and gap distance.

Use the accelerator pedal to intentionally
exceed the set speed limit.

When you override the system, the
indicator remains blue, the set speed is
dimmed and the lead vehicle icon does not
appear in the instrument cluster display.

217

Adaptive Cruise Control

(If Equipped)

The system resumes operation when you
release the accelerator pedal. The vehicle
speed decreases to the set speed, or a
lower speed if following a slower vehicle.

ADAPTIVE CRUISE CONTROL
INDICATORS

E144529

Illuminates when you switch
adaptive cruise control on. The
color of the indicator changes to

indicate the system status.

White indicates the system is on but
inactive.

Blue indicates that you set the speed and
the system is active.

SWITCHING FROM ADAPTIVE
CRUISE CONTROL TO CRUISE
CONTROL

WARNING:

Normal cruise control

will not brake when your vehicle is
approaching slower vehicles. Always be
aware of which mode you have selected
and apply the brakes when necessary.

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Press

Cruise Control

4. Press

Normal Cruise Control

E332905

The cruise control indicator
replaces the adaptive cruise
control indicator if you select

normal cruise control. The gap setting
does not display, and the system does not
respond to lead vehicles. Automatic
braking remains active to maintain set
speed. The system remembers the last
setting when you start your vehicle.

LANE CENTERING

(IF EQUIPPED)

HOW DOES LANE CENTERING
WORK

Adaptive cruise control with lane centering
uses the vehicle's front radar sensor and
front windshield camera sensor, together
with the steering sensor to operate.

Using these sensors, the system applies
continuous steering assistance towards
driving in the middle of the lane you choose
on highway roads.

Note:

The gap setting for adaptive cruise

control with lane centering, operates in the
same way as normal adaptive cruise control.

LANE CENTERING PRECAUTIONS

WARNING:

Do not use the system

if any changes or modifications to the
steering wheel have been made. Any
changes or modifications to the steering
wheel could affect the functionality or
performance of the system. Failure to
follow this instruction could result in the
loss of control of your vehicle, personal
injury or death.

Adaptive cruise control precautions apply
to lane centering unless stated otherwise
or contradicted by a lane centering
precaution. See

Adaptive Cruise Control

Precautions

(page 210).

LANE CENTERING
REQUIREMENTS

You must keep your hands on the steering
wheel at all times.

218

Adaptive Cruise Control

(If Equipped)

Lane centering only activates when all of
the following occur:
•

Adaptive cruise control with lane
centering is enabled in the touchscreen.
See

Switching Lane Centering On

and Off

(page 219).

•

You have adaptive cruise control with
stop and go enabled and set.

•

The steering sensor detects your hands
on the steering wheel.

•

The system detects both lane markings
when driving on a straight road.

•

Your vehicle is initially centered in the
lane between two visible line markings.

Note:

If the system does not detect valid

lane line markings, the system remains in
standby until valid line markings are
available.

Note:

If the system does not detect your

hands on the steering wheel, apply a slight
force to the steering wheel.

LANE CENTERING LIMITATIONS

Adaptive cruise control limitations apply
to lane centering unless stated otherwise
or contradicted by a lane centering
limitation. See

Adaptive Cruise Control

Limitations

(page 211).

Lane centering may not correctly operate
in any of the following conditions:
•

The lane width is too narrow or wide.

•

The curve in the road is too tight.

•

The system does not detect the
minimum required lane markings or
when lanes merge or split.

•

When the required steering effort to
maintain lane center exceeds the lane
centering system limit.

•

When driving in areas that are under
construction or when road work is in
progress.

•

If the front windshield camera and/or
the front radar are blocked.

•

When using a spare tire.

•

Inclement weather conditions
including, but not limited to, high wind,
heavy rain, and fog.

•

Driving into direct sunlight.

•

When modification to the steering
system has been made, including
alterations to the steering wheel.

•

When towing a trailer.

See

Lane Centering Precautions

(page

218).

Note:

The system steering assistance is

limited and may not have sufficient effort
for all driving situations and/or conditions,
such as driving through tight curves or
driving through curves at high speeds.

Note:

In exceptional conditions, the system

may deviate from the lane center.

SWITCHING LANE CENTERING ON
AND OFF

Keep your hands on the steering wheel at
all times.

The controls are on the steering wheel.

E308131

Press the button.

The indicator appears in the instrument
cluster display. When the system is on, the
color of the indicator changes to indicate
the system status.

You can override the system at any time
by steering your vehicle.

Note:

The correct requirements must be

met before you can switch the system on.
See

Lane Centering Requirements

(page

218).

219

Adaptive Cruise Control

(If Equipped)

Enabling and Disabling Lane
Centering

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Press

Cruise Control

4. Press

Lane Centering Assist

LANE CENTERING ALERTS

You must keep your hands on the steering
wheel at all times.

When the system is active and detects no
steering activity for a period of time, the
system alerts you to put your hands on the
steering wheel. If you do not react
appropriately to the warnings the adaptive
cruise control with lane centering system
cancels and slows your vehicle down to
idle speeds while maintaining steering
control. See

Lane Centering Automatic

Cancellation

(page 220).

The system also alerts you if your vehicle
crosses lane line markings without
detected steering activity.

Note:

The system could detect a light grip

or light touch on the steering wheel as
hands-off driving.

LANE CENTERING AUTOMATIC
CANCELLATION

When an external condition cancels the
system, and your hands are on the steering
wheel, a tone sounds and a message
appears in the instrument cluster display.

When an external condition cancels the
system, and your hands are not on the
steering wheel, the system immediately
alerts you to take control of the vehicle. If
this alert is ignored, the system slows the
vehicle while maintaining steering
assistance when lane markings are
available. When no lane markings are
available, the vehicle comes to a stop.

E308130

If your vehicle starts to slow
down after system cancellation,
you must take full control of the

vehicle. To re-enable adaptive cruise
control with lane centering after
cancellation, press and release the resume
button.

Automatic cancellation can also occur if:
•

The lane becomes too wide or narrow.

•

The system cannot detect valid lane
markings.

•

Lane markings cross over one another.

•

The curve of the road is too sharp.

Note:

If your vehicle slows down due to your

inactivity twice within a key cycle, the
system disables. To reset the system, when
the vehicle is stationary, return the gear
selector to park (P) and turn the vehicle off.
Then, restart the vehicle with your foot on
the brake pedal.

LANE CENTERING MANUAL
CANCELLATION

When you perform the following actions,
adaptive cruise control with lane centering
will cancel:

•

The brake pedal is pressed.

•

Adaptive cruise control button on the
steering wheel is switched off.

The lane centering system is momentarily
suppressed when either of the following
actions are performed:

•

Turn signal indicator is latched or
tapped.

•

You steer the vehicle out of lane.

LANE CENTERING INDICATORS

E308131

Illuminates when you switch
lane centering on. The color of
the indicator changes to indicate

the system status.

220

Adaptive Cruise Control

(If Equipped)

Gray status indicates the system is on but
in standby mode.

Blue status indicates the system is enabled
and applying steering assistance to keep
the vehicle in the center of the lane.

Amber status with an audible tone, that
then changes to gray status, indicates a
system automatic cancellation.

PREDICTIVE SPEED ASSIST

HOW DOES PREDICTIVE SPEED

ASSIST WORK

Predictive Speed Assist works with
adaptive cruise control and adjusts the
vehicle speed to the road geometry and to
the speed limit detected by the speed sign
recognition system. As the system
identifies curves and highway exits, the
vehicle speed temporarily decreases ahead
of and during the changing road geometry.
When passing new speed signs, the set
speed updates. See

Predictive Speed

Assist Precautions

(page 221).

There are limitations that affect the
accuracy of the speed sign recognition
system and its ability to determine the
current speed limit. Predictive speed assist
and its ability to determine the current
speed limit shares these limitations. See

Speed Sign Recognition

(page 257).

Note:

The adaptive cruise control gap

setting operates normally when the feature
is enabled.

PREDICTIVE SPEED ASSIST
PRECAUTIONS

WARNING:

You are responsible for

controlling your vehicle at all times. The
system is designed to be an aid and does
not relieve you of your responsibility to
drive with due care and attention. Failure
to follow this instruction could result in
the loss of control of your vehicle,
personal injury or death.

WARNING:

Pay close attention to

changing road conditions. You may need
to override the system by pressing the
brake or accelerator pedal if the adjusted
speed becomes higher or lower than
necessary.

WARNING:

The system only

provides limited braking. Your vehicle
may not always decelerate quickly
enough to avoid a crash without driver
intervention. Apply the brakes when
necessary.

WARNING:

The system does not

activate the turn signal.

Adaptive cruise control precautions apply
to predictive speed assist unless stated
otherwise or contradicted by a predictive
speed assist precaution. See

Adaptive

Cruise Control Precautions

(page 210).

The system only applies limited braking.
You can override the system with the
accelerator pedal or cancel the system by
applying the brakes.

The system may adapt to various factors
such as time of day, lane width. This could
influence speed adjustments and
accelerations.

221

Adaptive Cruise Control

(If Equipped)

The system may adapt to various drive
modes. See

Drive Mode Control

(page

226). This could influence speed
adjustments and accelerations.

Note:

The system does not activate the

turn signal automatically.

PREDICTIVE SPEED ASSIST
LIMITATIONS

WARNING:

The system may not

always adjust vehicle speed in certain
road or weather conditions such as
crossing traffic, yield or stop signs, right
of way, traffic lights, speed bumps, rain,
snow, fog. You must always apply the
brake or accelerator pedal when
necessary.

The road geometry and speed limit
information provided by the navigation
map data could be inaccurate or out of
date.

The system may not detect and read
speed limit signs with conditional
information, for example, when a sign is
flashing, during specific time ranges, or
when children are present.

Note:

The system does not set the vehicle

speed to speed limits shown with a
supplementary traffic sign.

Under certain conditions, the system may
not adjust the vehicle speed until after your
vehicle passes the speed limit.

Detection of road geometry operates only
where related information is available.
Road geometry information may not be
available in some areas.

SWITCHING PREDICTIVE SPEED
ASSIST MODE ON AND OFF

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Press

Cruise Control

4. Press

Adaptive Cruise Control

5. Switch

Predictive Speed Assist

on or

off.

ADJUSTING THE SET SPEED
TOLERANCE

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Press

Cruise Control

4. Press

Adaptive Cruise Control

5. Switch

Predictive Speed Assist

on.

6. Press

Tolerance

Adjust the slider to set the tolerance.

Note:

You can set tolerance for vehicle

speed adjustment based on speed sign
recognition only.

PREDICTIVE SPEED ASSIST
ALERTS

If the speed sign recognition system
detects a speed limit below the minimum
adaptive cruise control set speed, a tone
sounds and the system returns to standby
mode.

PREDICTIVE SPEED ASSIST
INDICATORS

A blue marker around the speed sign and
a blue arrow next to the set speed
indicates that the system is active.

Speed Sign Indicator

When the system detects a new speed
sign, a gray indicator appears above the
set speed while the system adjusts the
vehicle speed to the speed limit. When the
speed limit is reached, the set speed
updates and the gray indicator disappears.

222

Adaptive Cruise Control

(If Equipped)

Road Geometry Indicator

When the system detects a curve or
highway exit, the vehicle starts to
decelerate, and the indicator appears and
changes color.

Road Geometry Indicator Symbols

E379737

Left curve.

E379738

Right curve.

PREDICTIVE SPEED ASSIST – TROUBLESHOOTING

PREDICTIVE SPEED ASSIST – INFORMATION MESSAGES

Details

Message

Navigation system based speed limit information is not

available. If the message continues to appear, have your

vehicle checked as soon as possible.

Adaptive Cruise Control

Speed Sign Recognition

Not Available

The system is going to cancel and you must take control.

Driver Resume Control

ADAPTIVE CRUISE CONTROL
– TROUBLESHOOTING

ADAPTIVE CRUISE CONTROL –
INFORMATION MESSAGES -
VEHICLES WITH: LANE
CENTERING

Note:

Depending on your vehicle options

and instrument cluster type, some
messages can appear different or not at all.

223

Adaptive Cruise Control

(If Equipped)

Action

Message

You must return your hands to the steering wheel and provide

steering input to cancel the message.

Keep Hands on Steering

Wheel

Lane centering is currently not available, due to conditions

that prevent the system from becoming active. To reset the

system, when the vehicle is stationary, return the gear selector

to park (P) and turn the vehicle off. Then, restart the vehicle

with your foot on the brake pedal.

Lane Centering Assist

Not Available

Adaptive cruise control with lane centering is about to cancel.

You must immediately take full control of the vehicle.

Resume Control

Adaptive cruise control with lane centering is in standby mode.

When safe to do so, you can resume adaptive cruise control

with lane centering by applying pressure on the accelerator
pedal. Alternatively, you can also re-enable adaptive cruise

control with lane centering by pressing the resume button on

the steering wheel.

Press Accelerator Pedal

to Resume

ADAPTIVE CRUISE CONTROL –

INFORMATION MESSAGES -
VEHICLES WITH: STOP AND GO

Note:

Depending on your vehicle options

and instrument cluster type, not all
messages display or are available.

Note:

The system could abbreviate or

shorten certain messages depending upon
which cluster type you have.

Action

Message

A malfunction is preventing the adaptive cruise from engaging.

Adaptive Cruise

Malfunction

Front Sensor Not Aligned

Contact an authorized dealer to have the radar checked for

proper coverage and operation.

Conditions exist preventing the system from being available.

Adaptive Cruise Not

Available

You have a blocked radar because of poor radar visibility due
to inclement weather or ice, mud, or water in front of the radar.

You can typically clean the sensor to resolve this.

Adaptive Cruise Not

Available Sensor

Blocked See Manual

224

Adaptive Cruise Control

(If Equipped)

Action

Message

Due to the nature of radar technology, it is possible to get a

blockage warning with no actual block. This happens, for

example, when driving in sparse rural or desert environments.
A false blocked condition either self clears, or clears after you

restart your vehicle.

You have selected normal cruise control. The system does

not brake or react to traffic.

Normal Cruise Active

Adaptive Braking Off

Displays when the adaptive cruise control is going to cancel

and you must take control.

Adaptive Cruise - Driver

Resume Control

Displays when the vehicle speed is too slow to activate the

adaptive cruise control and there is no lead vehicle in range.

Adaptive Cruise Speed

Too Low to Activate

225

Adaptive Cruise Control

(If Equipped)

WHAT IS DRIVE MODE
CONTROL

This feature connects multiple vehicle
systems through a single interface,
providing you with enhanced vehicle
control and driving dynamics for different
driving scenarios, terrains, weather, or
various road conditions.

HOW DOES DRIVE MODE
CONTROL WORK

Drive mode control adjusts your vehicle
configuration for each mode you select.

Changing the drive mode adjusts the
steering effort and feel of the steering
system.

The stability and traction control assist
your vehicle control in adverse conditions
or high-performance driving.

Throttle control enhances the powertrain
response, transmission controls become
optimized with shift schedules.

Note:

The system has diagnostic checks

that continuously monitor the system for
proper operation. If a mode is unavailable
due to a system fault, the drive mode
system defaults to normal. When the
system defaults to normal, the driveline
settings remain the same as prior to the
system fault.

SELECTING A DRIVE MODE

E374605

Press the mode buttons on the steering
wheel to scroll through the available
modes.

Note:

Button icons vary depending on your

vehicles options.

Note:

If you disconnect or remove the

battery, the steering system defaults to
normal.

Selecting a Steering Mode

E347142

To change the steering mode,
press the button on the steering
wheel. See

Custom Drive

Mode

(page 408). The first press of the

steering wheel displays a pop-up message
in the instrument cluster display for the
selected mode and subsequent presses
changes the selected mode.

Modes:
•

Normal – Developed to complement
vehicle response during daily driving.

•

Sport – Slightly less assist and
damping for improved steering feel
during spirited driving.

•

Comfort – Slightly more assist for
driver preference and daily driving ease.

The steering selections available are
dependent on the current drive mode.

226

Drive Mode Control

After selecting the desired setting, you may
feel a soft feedback bump in the steering
wheel when the changeover occurs.

Note:

Steering options from custom mode

may appear different from what is displayed
on the instrument cluster display.

Selecting a Suspension Mode

(If

Equipped)

E347107

The different available
suspension settings can be set
for different drive modes in the

custom drive mode menu. See

Custom

Drive Mode

(page 408).

Modes:
•

Normal – Default factory setting.

•

Sport – Slightly stiffer suspension with
emphasis on handling and control.

•

Track – Maximum emphasis on
handling and control.

•

Drag – Maximizes shock performance
for drag strip environments.

Selecting an Exhaust Mode

(If

Equipped)

E375920

The different available exhaust
settings can be set for different
drive modes. See

Modes:
•

Normal – Default setting provides a
balance of comfort and feedback.

•

Sport – Slightly louder than normal for
spirited driving.

•

Track – Loudest setting for track use
only. Maximum exhaust noise under all
driving conditions.

•

Quiet – Quietest setting for maximum
comfort under all driving conditions.

DRIVE MODES

CUSTOM

E375917

Allows you to create your own
drive mode experience. Choose
a drive mode to use as a starting

point and then mix and match settings to
tailor the experience to your preferences.
Custom drive mode must be active in order
to see real time updates. See

Custom

Drive Mode

(page 408).

Note:

Some settings or combinations of

settings may not be available.

DRAG STRIP

E375862

For high-performance drag strip
driving. This mode adjusts the
transmissions shift schedule for

aggressive shifting and higher engine
speeds, optimizing performance at
maximum throttle. Accelerator pedal
responsiveness increases, and steering is
set to its sport setting for enhanced driver
connectivity and feedback. Adaptive
dampers are optimized for straight line
maximum acceleration and active exhaust
is set to its loudest setting for a more
powerful tone. Use this mode for driving
on closed circuit drag strips where optimal
straight line performance is needed.

Note:

This mode is for track use only and

is not intended for public roads.

NORMAL

E375858

For everyday driving. This mode
is the perfect balance of
excitement, comfort, and

convenience. This is the default mode after
each ignition cycle and all systems altered
by drive mode control are adjusted to their
base settings.

227

Drive Mode Control

SLIPPERY

E295414

For less than ideal road
conditions such as snow or ice
covered roads. Use this mode for

crossing terrain where loose or slippery
materials cover a firm surface. Slippery
mode lowers throttle response and
optimizes shifting for slippery surfaces.

Note:

Using slippery mode on dry, hard

surfaces could produce some vibration,
driveline bind up, and excessive tire wear.

SPORT

E246593

For sporty driving with improved
performance handling and
response. This mode increases

accelerator pedal responsiveness, holds
the transmission in lower gears longer, and
changes steering feel to have more torque
buildup enhancing driver connectivity and
feedback. Chassis controls are switched
to their sport settings. The adjustable
suspension is modified to provide firmer
and more responsive dynamics.
Additionally, exhaust sound is changed to
its sport setting for a louder and more
aggressive tone. Use this mode for a fun
and engaging driving experience.

TRACK

E375861

For high-performance track
driving. This mode increases
throttle response and adjusts the

transmissions shift schedule to both hold
lower gears longer for faster acceleration
and downshift more aggressively under
braking. Traction and Stability Control
intervention is reduced and tuned
specifically for track usage. If equipped,
the adaptive dampers are optimized for
transient handling maneuvers and active
exhaust is opened to take on a more

powerful tone. Additionally, steering is
switched to its Sport setting for enhanced
connectivity and driver feedback. Use this
mode for on-road courses, auto-cross style
events, and on-road closed circuit track
driving.

Note:

This mode is for track use only and

is not intended for public roads. Automatic
Emergency Braking and Brake Over
Accelerator systems are disabled.

228

Drive Mode Control

WHAT IS THE INTELLIGENT
SPEED LIMITER

The system allows you to limit the vehicle
speed to the maximum speed limit
detected by the traffic sign recognition
system.

HOW DOES THE INTELLIGENT
SPEED LIMITER WORK

Intelligent speed limiter uses data from the
traffic sign recognition system to set a
maximum speed. For example, if the traffic
sign recognition system detects a 50 mph
(80 km/h) speed limit, the vehicle speed
is limited to 50 mph (80 km/h).

INTELLIGENT SPEED LIMITER
PRECAUTIONS

WARNING:

When you are going

downhill, your vehicle speed may
increase above the set speed. The
system will not apply the brakes but a
warning displays. Failure to follow this
warning could result in serious personal
injury or death.

WARNING:

You are responsible for

Note:

The system does not limit your

vehicle's speed to speed limits shown with
a supplementary traffic sign.

SWITCHING THE INTELLIGENT
SPEED LIMITER ON AND OFF

E396410

Press to switch the system on.

The system activates with the
detected speed limit or, if no

speed limit is detected the current speed
of your vehicle is set. Press again to switch
the system off.

SETTING THE SPEED LIMIT

E246884

E246885

Press the toggle button upward
or downward with the system in
standby mode to set the speed
limiter to the current vehicle
speed. The set speed is stored
and displayed in the instrument

cluster.

Note:

The set speed limiter adjusts when

the system detects a different maximum
speed limit.

Note:

If the system cannot detect a

maximum speed limit, the system returns
to standby mode.

CHANGING THE SET SPEED
LIMIT

E246884

E246885

You can adjust the set speed in
small or large increments. Press
the toggle button upward or
downward once to adjust the set
speed in small increments. Press
and hold the toggle button

upward or downward to adjust the set
speed in large increments.

229

Intelligent Speed Limiter

ADJUSTING THE SPEED LIMIT
TOLERANCE

You can set a permanent speed tolerance
that is in addition to the detected speed
limit.

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Press

Speed Limiter

4. Press

Intelligent Speed Limiter

5. Press

Tolerance

6. Select a setting.

CANCELING THE SET SPEED
LIMIT

E308130

Press to cancel the limiter and
place it in standby mode. The
symbol in instrument cluster

display appears grey.

RESUMING THE SET SPEED
LIMIT

E308130

Press to resume the limiter. The
system sets the speed limit to
the detected maximum speed

limit when it resumes. The symbol in the
instrument cluster display appears green.

INTENTIONALLY EXCEEDING
THE SET SPEED LIMIT

Firmly press the accelerator pedal to
temporarily turn the system off. The
system reactivates once your vehicle speed
drops below the set speed.

INTELLIGENT SPEED LIMITER
INDICATORS

E280228

It illuminates in the instrument
cluster when the system is in
standby or active.

INTELLIGENT SPEED LIMITER
AUDIBLE WARNINGS

A warning appears in the instrument
cluster and a tone sounds if any of the
following occur:
•

Your vehicle's speed exceeds the
current set speed.

•

The system detects a maximum speed
limit that is lower than your vehicle's
current speed.

•

You intentionally exceed the set speed.

If the traffic sign recognition system
detects a speed limit outside the
operational speed range, 12–112 mph
(20–180 km/h), a single warning tone
sounds and the system switches to
standby mode.

SWITCHING FROM
INTELLIGENT SPEED LIMITER
TO SPEED LIMITER

You can change between intelligent speed
limiter and normal speed limiter using the
center display. Intelligent speed limiter
allows you to limit the vehicle speed to the
maximum speed limit detected by the
speed sign recognition system. Normal
speed limiter allows you to manually limit
the vehicle speed using controls on the
steering wheel.

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Press

Speed Limiter

230

Intelligent Speed Limiter

4. Switch

Intelligent Speed Limiter

off.

Note:

If you switch intelligent speed limiter

off, the system defaults to manual speed
limiter. You can manually set the speed
limiter using the controls on the steering
wheel.

INTELLIGENT SPEED LIMITER
– TROUBLESHOOTING

INTELLIGENT SPEED LIMITER –
FREQUENTLY ASKED QUESTIONS

Why does a warning appear in the
instrument cluster display?
•

The vehicle speed exceeds the current
set speed.

•

The system detects a maximum speed
limit that is lower than the current
vehicle speed.

•

You intentionally exceed the set speed.

231

Intelligent Speed Limiter

WHAT IS THE LANE KEEPING
SYSTEM

The lane keeping system alerts you by
providing temporary steering assistance
or steering wheel vibration when it detects
an unintended lane departure.

HOW DOES THE LANE
KEEPING SYSTEM WORK

The lane keeping system uses a forward
looking camera mounted on the windshield
to monitor vehicle movement within the
lane of travel.

When the camera detects a drift out of the
lane of travel, the lane keeping system
alerts the driver by vibrating the steering
wheel, or aids the driver by providing a
small steering input to move the vehicle
back into the lane of travel.

The driver can select one of three modes:

•

Alert

•

Aid

•

Alert + Aid

LANE KEEPING SYSTEM
PRECAUTIONS

WARNING:

You are responsible for

WARNING:

The system will not

operate if the sensor cannot track the
road lane markings.

WARNING:

The sensor may

incorrectly track lane markings as other
structures or objects. This can result in
a false or missed warning.

WARNING:

In cold and severe

weather conditions the system may not
function. Rain, snow and spray can all
limit sensor performance.

WARNING:

The system may not

operate properly if the sensor is blocked.
Keep the windshield free from
obstruction.

WARNING:

If damage occurs in the

immediate area surrounding the sensor,
have your vehicle checked as soon as
possible.

WARNING:

The system may not

correctly operate if your vehicle is fitted
with a suspension kit not approved by
us.

WARNING:

Large contrasts in

outside lighting can limit sensor
performance.

LANE KEEPING SYSTEM
LIMITATIONS

The lane keeping system only operates
when the vehicle speed is greater than
40 mph (64 km/h).

The system works when the camera can
detect at least one lane marking or the
edge of the road.

The lane keeping system may not correctly
operate in any of the following conditions:
•

The lane keeping system does not
detect at least one lane marking.

•

You switch the turn signal on.

232

Lane Keeping System

•

You apply direct steering, accelerate
fast or brake hard.

•

The vehicle speed is less than 40 mph
(64 km/h).

•

The anti-lock brake, stability control or
traction control system activates.

•

The lane is too narrow.

•

Something is obscuring the camera or
it is unable to detect the lane markings
due to environment, traffic or vehicle
conditions.

The lane keeping system may not correct
lane positioning in any of the following
conditions:
•

High winds.

•

Uneven road surfaces.

•

Heavy or uneven loads.

•

Incorrect tire pressure.

SWITCHING THE LANE
KEEPING SYSTEM ON AND
OFF

E308131

To activate the lane keeping
system, press the button on the
steering wheel.

To deactivate the lane keeping system,
press the button again.

Note:

When switching the system on or off

a message appears in the instrument cluster
display to show the status.

Note:

The system stores the on or off

setting until manually changed.

SWITCHING THE LANE
KEEPING SYSTEM MODE

The lane keeping system has different
settings that you can view or adjust using
the touchscreen.

The system stores the last known selection
for each setting.

To change the lane keeping system mode,
use the touchscreen:

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Press

Lane-Keeping System

4. Press

Lane-Keeping Mode

5. Select a mode.

Note:

The system remembers the last

setting when you start your vehicle.

LANE KEEPING SYSTEM
SETTINGS

To change the steering wheel vibration,
use the touchscreen:

Press Features on the touchscreen.

2. Press

Driver Assistance

3. Press

Lane-Keeping System

4. Press

Lane-Keeping Intensity

5. Select an intensity setting.

ALERT MODE

WHAT IS ALERT MODE

Alert mode vibrates the steering wheel
when it detects an unintended lane
departure.

233

Lane Keeping System

HOW DOES ALERT MODE WORK

E165515

When in alert mode, the lane keeping
system alerts you by vibrating the steering
wheel. The intensity of the vibration is set
through the lane keeping system menu.

AID MODE

WHAT IS AID MODE

Aid mode provides temporary steering
assistance toward the center of the lane.

HOW DOES AID MODE WORK

E165516

The lane keeping system aids you when
an unintentional lane departure occurs.
The system provides a small steering input
to move the vehicle towards the center of
the lane.

ALERT AND AID MODE

WHAT IS ALERT AND AID MODE

Alert and aid mode uses multiple features
to keep you in your lane. The system first
provides a small steering input to bring
your vehicle back towards the center of
the lane. If your vehicle moves too far from
the center of the lane the system alerts
you with vibration in the steering wheel.

HOW DOES ALERT AND AID MODE
WORK

E165517

Alert.

Aid.

The lane keeping system detects a lane
departure and provides aid when the
vehicles enters

and applies the

additional alert warning if

is entered.

234

Lane Keeping System

LANE KEEPING SYSTEM
INDICATORS

E335297

If you switch the lane keeping system on,
a graphic with lane markings appears in
the information display.

When you switch the system off, the lane
marking graphics do not display.

Note:

The overhead vehicle graphic may

still display if adaptive cruise control is
enabled.

While the lane keeping system is on, the
color of the lane markings change to
indicate the system status.

Red

Yellow

Green

Gray

Indicates that the

system is providing

or has just provided
a lane keeping alert

warning.

Indicates that the

system is providing

or has just provided

a lane keeping aid

intervention.

Indicates that the

system is available

or ready to provide a

warning or interven-

tion on the indicated

side.

Indicates that the

system is tempor-

arily unavailable to

provide a warning or

intervention on the

indicated side.

BLIND SPOT ASSIST

WHAT IS BLIND SPOT ASSIST

Blind spot assist is an extension of the lane
keeping system.

It may help you identify adjacent vehicles
during a lane change.

Blind spot assist provides a blind spot
warning and steering assistance to help
you become aware of and steer away from
vehicles in your blind spot during lane
changes.

HOW DOES BLIND SPOT ASSIST
WORK

E308131

Activate and deactivate the
system using the lane keeping
system button on the steering

wheel.

During lane changes, the design of the
blind spot assist feature detects vehicles
in, or approaching, your blind spot and
provides a warning, plus steering
assistance to direct your vehicle back into
your lane.

When active, this system functions with or
without the use of direction indicators and
hazard flashers.

You must keep your hands on the steering
wheel at all times.

235

Lane Keeping System

BLIND SPOT ASSIST LIMITATIONS

All system limitations present in the basic
lane keeping system also apply to blind
spot assist.

Blind spot assist does not function under
the following conditions:

•

No lane markings are detected.

•

One or both rear radar sensors become
blocked or faulty.

•

Attaching bike or cargo racks could
cause false alerts due to obstruction
of the sensor.

Blind spot assist may have difficulty
detecting hazards under the following
conditions:

•

If a vehicle is approaching in an
adjacent lane at a speed higher than
your vehicle.

•

Bad weather obstructing the sensors.

BLIND SPOT ASSIST INDICATORS

E310089

Diagram 1:

Vehicle A uses its left turn

signal preparing to change from the right
lane to the middle lane. Vehicle B is already
in the middle lane and just entered Vehicle
A's blind spot causing the blind spot
information system alert indicator to flash
on the exterior mirror.

Diagram 2:

The driver of Vehicle A begins

to steer into the center lane not aware of
Vehicle B.

Diagram 3:

Blind spot assist counter

steers to help alert the driver of Vehicle A
to direct their vehicle back into the right
lane to help avoid a possible collision with
Vehicle B.

The lane keeping aid warning lamp or
yellow lane marking in your instrument
cluster display indicate blind spot assist
activation. In addition, the blind spot
information system alert indicator flashes
on the exterior mirror on the same side as
the detection. See

Blind Spot

Information System

(page 239).

236

Lane Keeping System

Blind Spot Assist Information Messages

Action

Message

Displays if you attach a trailer to your vehicle with the blind
spot information system switched off or you have not
configured the trailer.

Blind Spot Assist Not
Available Trailer
Attached

Displays if your blind spot information system sensors are
blocked.

Blind Spot Assist Not
Available Side Sensor
Blocked

The system has detected a fault that requires service. Have
your vehicle checked as soon as possible.

Blind Spot Assist System
fault

Lost communication with the trailer module. Blind spot assist
is suppressed until the failure is fixed.

Trailer Brake Module
Fault

Lost communication with the trailer module. Blind spot assist
is suppressed until the failure is fixed.

Trailer Lighting Module
Fault See Manual

Front camera fault. Blind spot assist is disabled until the
failure is fixed.

Front Camera Fault
Service Required

LANE KEEPING SYSTEM – TROUBLESHOOTING

LANE KEEPING SYSTEM – INFORMATION MESSAGES

Action

Message

The system has malfunctioned. Have your

vehicle checked as soon as possible.

Lane Keeping Sys. Malfunction Service

Required

The system has detected a condition that

has caused the system to be temporarily

unavailable.

Front Camera Temporarily Not Available

The system has detected a condition that

requires you to clean the windshield in order

for it to operate properly.

Front Camera Low Visibility Clean Screen

The system has malfunctioned. Have your

vehicle checked as soon as possible.

Front Camera Malfunction Service Required

The system requests that you keep your

hands on the steering wheel.

Keep Hands on Steering Wheel

237

Lane Keeping System

LANE KEEPING SYSTEM –
FREQUENTLY ASKED QUESTIONS

Why is the feature not available
(lane markings are gray) when I
can see the lane markings on the
road?

•

Your vehicle speed is less than 40 mph
(65 km/h).

•

The sun is shining directly into the
camera lens.

•

A quick intentional lane change has
occurred.

•

You are driving your vehicle too close
to the lane markings for an extended
interval of time.

•

Driving at high speeds in curves.

•

The last alert warning or aid
intervention occurred a short time ago.

•

Ambiguous lane markings, for example,
in construction zones.

•

Rapid transition from light to dark, or
from dark to light.

•

Sudden offset in lane markings.

•

ABS or AdvanceTrac™ is active.

•

There is a camera blockage due to dirt,
grime, fog, frost or water on the
windshield.

•

You are driving too close to the vehicle
in front of you.

•

Transitioning between no lane
markings to lane markings, or vice
versa.

•

There is standing water on the road.

•

Faint lane markings, for example,
partial yellow lane markings on
concrete roads.

•

Lane width is too narrow or too wide.

•

You have not calibrated the camera
after a windshield replacement.

•

Driving on roads with tight curves or
uneven surfaces.

Why does the vehicle not come
back toward the middle of the
lane, as expected, in the Aid, or Aid
+ Alert mode?

•

High cross winds are present.

•

There is a large road crown.

•

Rough roads, grooves or shoulder
drop-offs.

•

Heavy, uneven loading of the vehicle
or improper tire inflation pressure.

•

You changed the tires or modified the
suspension.

238

Lane Keeping System

WHAT IS BLIND SPOT
INFORMATION SYSTEM

Blind spot information system detects
vehicles that may have entered the blind
spot zone.

HOW DOES BLIND SPOT
INFORMATION SYSTEM WORK

Blind spot information system uses
sensors on both sides of your vehicle,
detecting rearward from the exterior
mirrors to approximately 13 ft (4 m)
beyond the rear bumper. The detection
area extends to approximately 59 ft (18 m)
beyond the rear bumper when the vehicle
speed is greater than 30 mph (48 km/h)
to alert you of faster approaching vehicles.

E255695

BLIND SPOT INFORMATION
SYSTEM PRECAUTIONS

WARNING:

Do not use the blind

spot information system as a
replacement for using the interior and
exterior mirrors or looking over your
shoulder before changing lanes. The
blind spot information system is not a
replacement for careful driving.

WARNING:

The system may not

operate properly during severe weather
conditions, for example snow, ice, heavy
rain and spray. Always drive with due
care and attention. Failure to take care
may result in a crash.

Note:

Blind spot information system does

not prevent contact with other vehicles. It
does not detect parked vehicles,
pedestrians, animals or other infrastructure.

BLIND SPOT INFORMATION
SYSTEM LIMITATIONS

Blind spot information system does not
operate in park (P) or reverse (R).

The system may not alert you if a vehicle
quickly passes through the detection zone
while overtaking.

Note:

For vehicles without the trailer

coverage feature, we recommend that you
switch the blind spot information system
off when you attach a trailer.

BLIND SPOT INFORMATION
SYSTEM REQUIREMENTS

Blind spot information system turns on
when all the following occur:
•

You start your vehicle.

•

You shift into drive (D).

•

The vehicle speed is greater than
6 mph (10 km/h).

SWITCHING BLIND SPOT
INFORMATION SYSTEM ON
AND OFF

To switch blind spot information system
on or off, use the touchscreen:

239

Blind Spot Information System

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Press

Blind Spot Information System

4. Switch the feature on or off.

When you switch blind spot information
system off, a warning lamp illuminates.
When you switch the system on or off, the
alert indicators flash twice.

Note:

The system remembers the last

setting when you start your vehicle.

LOCATING THE BLIND SPOT
INFORMATION SYSTEM
SENSORS

E388049

The sensors are behind the rear bumper
on both sides of your vehicle.

Note:

Keep the sensors free from snow, ice

and large accumulations of dirt.

Note:

Blocked sensors may affect system

accuracy.

Note:

Do not cover the sensors with bumper

stickers, repair compound or other objects.

Note:

Bike and cargo racks could cause

false alerts due to obstruction of the sensor.
We recommend switching the feature off
when using a bike or cargo rack.

Note:

The system may not correctly operate

when towing a trailer. For vehicles with a
trailer tow module and tow bar approved
by us, the system turns off when you attach
a trailer. For vehicles with an aftermarket
trailer tow module or tow bar, we
recommend that you switch the system off
when you attach a trailer.

If the sensors become blocked, a message
may appear in the instrument cluster
display. See

Blind Spot Information

System – Information Messages

(page

241). The alert indicators remain
illuminated, but the system does not alert
you.

BLIND SPOT INFORMATION
SYSTEM INDICATORS

E309137

E249861

When blind spot information
system detects a vehicle, an
alert indicator illuminates in the

exterior mirror on the side from which the
vehicle is approaching. If you turn the turn
signal on for that side of your vehicle, the
alert indicator flashes.

240

Blind Spot Information System

WHAT IS EXIT WARNING

Exit warning uses radar sensors to alert
you to traffic objects approaching your
open door.

HOW DOES EXIT WARNING
WORK

Exit warning detects traffic objects such
as vehicles, cyclists, scooters and
motorcycles that approach your vehicle
from the rear and cross into the exit
warning zone. The exit warning zones are
along the left and right sides of your vehicle
and extend slightly past a fully open door.

E371193

Note:

The system cannot detect animals,

slow moving pedestrians or any type of
stationary object.

EXIT WARNING PRECAUTIONS

WARNING:

The system is not a

crash warning or avoidance system.

WARNING:

Always pay attention

to the traffic situation and the area
around the vehicle.

WARNING:

In cold and severe

weather conditions the system may not
function. Rain, snow and spray can all
limit sensor performance.

WARNING:

If damage occurs in the

immediate area surrounding the sensor,
have your vehicle checked as soon as
possible.

WARNING:

You are responsible for

WARNING:

The system may not

detect objects with surfaces that absorb
reflection. Always drive with due care
and attention. Failure to take care may
result in a crash.

Note:

The exit warning system becomes

active once you have started your vehicle
and the vehicle is not moving.

EXIT WARNING LIMITATIONS

The exit warning system is operational in
any gear position once you start your
vehicle and anytime the vehicle is not
moving. The exit warning system remains
on for about 3 minutes after turning your
vehicle off. The system turns off
immediately when locking the doors. Exit
warning informs you when it turns off.

Note:

Do not use exit warning as a

replacement for paying attention when
exiting your vehicle.

Note:

The system does not automatically

close the doors to prevent contact with
other vehicles.

242

Exit Warning

Note:

The system may not inform and/or

alert you if a traffic object is approaching
too quickly or if the parking position prevents
detection.

Exit Warning Alert

Note:

Exit warning is designed to provide a

visual and audible alert during an exit when
an occupant opens any door and a traffic
object is approaching on the same side.

Exit Warning Prevention

(If Equipped)

Depending on your vehicle's features, exit
warning is also designed to prevent the
door latch from opening when a traffic
object is approaching on the same side. In
this situation, the inner door handle is
disabled, and the door remains closed. A
visual and audible warning is also present
during a prevention. After the traffic object
has passed and no additional traffic
objects are approaching, the inner door
handle is automatically enabled and the
occupant can open the door to exit the
vehicle.

Note:

Occupants can override the

prevention function and open the door while
the traffic object is still approaching and the
incident is still imminent by requesting the
door to open twice quickly (within 5
seconds).

Exit Warning and Power Child Lock

(If Equipped)

Power child lock remains active and must
be manually deactivated if you attempt to
switch it off at the same time exit warning
detects an approaching traffic object.

A visual and audible warning occur in this
situation.

E371195

Note:

The driver can override the exit

warning with power child lock function by
pressing the power child lock deactivation
button twice quickly (within 5 seconds).

Note:

When the exit warning and power

child lock function is activated, doors can
still be opened from outside.

EXIT WARNING INDICATORS

E309137

When exit warning detects an approaching
traffic object on one side, the
corresponding alert indicator in the exterior
mirror is illuminated. If exit warning alert
or the optional exit warning prevention are
active, the same alert indicator flashes.
See

Blind Spot Information System

Indicators

(page 240).

243

Exit Warning

In addition to the mirror indicator there is
also visual indicator in the information
display noting what side a traffic object
has been detected on.

SWITCHING EXIT WARNING
ON AND OFF

You can switch off the exit warning system
using the touchscreen.

Exit warning turns off approximately 3
minutes after you switch your vehicle off.
It turns off immediately after you lock the
doors. When exit warning turns off, a
message appears in the instrument cluster
display.

Note:

The system remembers the last

setting when you start your vehicle.

LOCATING THE EXIT WARNING
SENSORS

E388049

The sensors for the exit warning are
mounted behind the rear bumper on both
sides of your vehicle.

Note:

Keep the sensors free from snow, ice

and large accumulations of dirt.

Note:

Do not cover the sensors with bumper

stickers, repair compound or other objects.

Note:

Blocked sensors may affect system

accuracy.

Note:

The system may not correctly operate

when towing a trailer or bike rack.

EXIT WARNING - TROUBLESHOOTING

EXIT WARNING - INFORMATION MESSAGES

Reason

Message

Left/Right exit warning alert or exit warning

prevention is active.

Left/Right Side Check surroundings before

exiting

Displays if the exit warning system turns

off/shuts down.

Exit Warning turning off. Exit safely

Displays if the exit warning system detects

any system error.

Exit Warning System Fault

244

Exit Warning

Ford Mustang (2024 year). Manual in english - page 7
