Ford Edge (2024 year). Manual in english

HEADLAMPS –
TROUBLESHOOTING

HEADLAMPS – FREQUENTLY
ASKED QUESTIONS

Why is there condensation in the
headlamps?

•

Headlamps have vents to
accommodate normal changes in air
pressure. Condensation can be a
natural by-product of this design.
When moist air enters the lamp
assembly through the vents, there is a
possibility that condensation can occur
when the temperature is cold. When
normal condensation occurs, a fine
mist can form on the interior of the
lens. The fine mist eventually clears
and exits through the vents during
normal operation.

How much condensation is
acceptable?

•

The presence of a fine mist, for
example no streaks, drip marks or large
droplets. A fine mist covers less than
50% of the lens.

How long does it take for the
acceptable condensation to clear?

•

Clearing time can take as long as 48
hours under dry weather conditions.

How much condensation is
unacceptable?

•

A water puddle inside the lamp.
Streaks, drip marks or large droplets
present on the interior of the lens.

What should I do if unacceptable
condensation is present?

•

Have your vehicle checked as soon as
possible.

Why do my headlamps turn off
when I have them switched on
when I switch my vehicle off?

•

The battery saver turns the headlamps
off after a short period of time after you
switch your vehicle off.

AUTOLAMPS

WHAT ARE AUTOLAMPS

WARNING:

The system does not

relieve you of your responsibility to drive
with due care and attention. You may
need to override the system if it does not
turn the headlamps on in low visibility
conditions, for example daytime fog.

Autolamps turn the headlamps on in low
light situations or when the windshield
wipers operate.

AUTOLAMP SETTINGS

Using the instrument cluster controls
on the steering wheel, select

Settings

2. Select

Vehicle

3. Select

Lighting

4. Select

Autolamp Delay

5. Select a setting and press the

button.

Exterior Lighting

EXTERIOR LAMPS

USING THE TURN SIGNAL LAMPS

E162681

E67018

Push the lever up or down to
switch the turn signal lamps on.

Set the lever to the middle position to
switch the turn signal lamps off.

Note:

Tap the lever up or down to make the

turn signal lamps flash three times.

Turn Signal Lamp Indicator

E67018

It flashes when you switch the
turn signal lamps on.

Note:

An increase in the rate of flashing

warns of a failed turn signal lamp.

SWITCHING THE DAYTIME
RUNNING LAMPS ON AND OFF -
VEHICLES WITH: CONFIGURABLE
DAYTIME RUNNING LAMPS

WARNING:

The daytime running

lamps system does not activate the rear
lamps and may not provide adequate
lighting during low visibility driving
conditions. Make sure you switch the
headlamps on, as appropriate, during all
low visibility conditions. Failure to do so
may result in a crash.

Using the instrument cluster controls
on the steering wheel, select

Settings

2. Select

Vehicle

3. Select

Lighting

4. Switch

Daytime Running Lights

on or

off.

The daytime running lamps turn on when
all of the following occur:
•

You switch the system on.

•

You switch your vehicle on.

•

The transmission is not in park (P) for
vehicles with automatic transmissions
or you release the parking brake for
vehicles with manual transmissions.

•

The lighting control is in the autolamps
position.

•

The headlamps are off.

Note:

Other lighting control positions do

not turn on the daytime running lamps.

Exterior Lighting

SWITCHING THE DAYTIME
RUNNING LAMPS ON AND OFF -
VEHICLES WITH: DAYTIME
RUNNING LAMPS (DRL)

WARNING:

The daytime running

Daytime running lamps are always on
unless you switch on the headlamps or
your vehicle is in park (P).

USING THE FRONT FOG LAMPS

(If

Equipped)

To switch the lamps on or off:

Set the lighting control to the parking
lamps, headlamps or autolamps
position.

Note:

When the lighting control is in the

autolamps position, you cannot switch the
fog lamps on unless the low beam
headlamps are on.

Press the button on the

lighting control to switch the front fog
lamps on or off.

Note:

Only switch the front fog lamps on

during reduced visibility.

Note:

The brightness of the daytime running

lamps may decrease when the front fog
lamps are switched on.

Note:

The front fog lamps lights switch off

automatically when high beams are
activated.

Front Fog Lamps Indicator

It illuminates when you switch
the front fog lamps on.

AUTOMATIC HIGH BEAM
CONTROL

HOW DOES AUTOMATIC HIGH
BEAM CONTROL WORK

Automatic high beam control turns the
high beams on if it is dark enough and no
other traffic is present. If it detects an
approaching vehicle’s headlamps or tail
lamps, or street lighting ahead, the system
turns the high beams off.

A camera sensor, centrally mounted
behind the windshield of your vehicle,
continuously monitors conditions to turn
the high beams on and off.

Exterior Lighting

E327596

Without automatic high beam
control.

With automatic high beam
control.

AUTOMATIC HIGH BEAM
CONTROL PRECAUTIONS

WARNING:

The system does not

relieve you of your responsibility to drive
with due care and attention. You may
need to override the system if it does not
turn the high beams on or off.

WARNING:

The system may not

switch the high beams off if the lights of
oncoming vehicles are hidden by
obstacles, for example guard rails.

WARNING:

You may need to

override the system when approaching
other road users.

WARNING:

In situations with poor

visibility, such as fog, heavy rain or other
inclement weather, you may need to
override or completely switch off the
system.

AUTOMATIC HIGH BEAM
CONTROL REQUIREMENTS

The system turns the high beams on if all
of the following occur:
•

You switch the system on.

•

You set the lighting control to the
autolamps position.

•

The ambient light level is low enough
that you require high beams.

•

There is no traffic in front of your
vehicle.

•

The vehicle speed is greater than
approximately 32 mph (52 km/h).

AUTOMATIC HIGH BEAM
CONTROL LIMITATIONS

The system turns the high beams off if any
of the following occur:
•

You switch the system off.

•

You set the lighting control to any
position except autolamps.

•

The ambient light level is high enough
that you do not require high beams.

•

The system detects an approaching
vehicle's headlamps or a leading
vehicle's tail lamps.

100

Exterior Lighting

•

The system detects severe rain, snow
or fog.

•

The system detects street lighting.

•

The camera has reduced visibility.

•

The vehicle speed falls below
approximately 27 mph (44 km/h).

Note:

The deactivation speed may be lower

on curves.

SWITCHING AUTOMATIC HIGH
BEAM CONTROL ON AND OFF

Using the instrument cluster controls
on the steering wheel, select

Settings

2. Select

Vehicle

3. Select

Lighting

4. Switch

Auto High Beam

on or off.

AUTOMATIC HIGH BEAM
CONTROL INDICATORS

E146105

Illuminates to confirm when the
system is ready to assist.

OVERRIDING AUTOMATIC HIGH
BEAM CONTROL

E162679

Push the lever away from you to switch
the high beam on.

Push the lever away from you again to
switch the high beam off.

Push the lever away from you for a third
time to switch automatic high beam
control back on.

AUTOMATIC HIGH BEAM CONTROL – TROUBLESHOOTING

AUTOMATIC HIGH BEAM CONTROL – INFORMATION MESSAGES

Details

Message

The camera has reduced visibility. Clean the windshield. If
the message continues to appear, have your vehicle checked
as soon as possible.

Front Camera Low Visib-
ility Clean Screen

The camera has malfunctioned. Wait a short period of time
for the camera to cool down. If the message continues to
appear, have your vehicle checked as soon as possible.

Front Camera Tempor-
arily Not Available

The camera has malfunctioned. Have your vehicle checked
as soon as possible.

Front Camera Malfunc-
tion Service Required

101

Exterior Lighting

ADAPTIVE FRONT LIGHTING

HOW DOES ADAPTIVE FRONT
LIGHTING WORK

Adaptive front lighting adapts when you
are steering around a curve or if the camera
detects lane markings indicating a curve.

E161714

Without adaptive front lighting.

With adaptive front lighting.

SWITCHING ADAPTIVE FRONT
LIGHTING ON AND OFF

Using the instrument cluster controls
on the steering wheel, select

Settings

2. Select

Vehicle

3. Select

Lighting

4. Switch

Adaptive Headlamps

on or off.

Set the lighting control to the autolamps
position to use the adaptive front lighting.

EXTERIOR LIGHTING VIDEOS

Automatic headlamps with wiper-activated
headlamp feature Video Link

Intelligent Three Blink Turn Signal Video
Link

Configurable Daytime Running Lamps

Auto High Beams

102

Exterior Lighting

SWITCHING ALL OF THE
INTERIOR LAMPS ON AND OFF

The lamps turn on under the following
conditions:

•

You open any door.

•

You press a button on the remote
control.

•

You press the all lamps on button on
the overhead console.

E259649

Press to switch all interior lamps
on or off.

SWITCHING THE FRONT
INTERIOR LAMPS ON AND OFF

E262162

The front interior lamp switches are on the
overhead console.

Note:

The position of each button on the

overhead console depends on your vehicle.

Individual Map Lamps

E262193

Press to switch the left-hand
individual dome lamp on and off.

Press to switch the right-hand
individual dome lamp on and off.

SWITCHING THE REAR
INTERIOR LAMPS ON AND OFF

E281231

The rear interior lamps may be above the
rear seat or above the rear windows.

E259649

Press to switch the lamps on or
off.

Note:

If you switch the rear lamps on

through the overhead console, you cannot
switch them off with the rear lamp switch.

INTERIOR LAMP FUNCTION

WHAT IS THE INTERIOR LAMP
FUNCTION

The interior lamp function switches the
courtesy and door lamps on or off.

SWITCHING THE INTERIOR LAMP
FUNCTION ON AND OFF

Press to switch the interior lamp
function on and off.

Note:

The indicator lamp illuminates amber

when the door function is off.

103

Interior Lighting

ADJUSTING THE INSTRUMENT
PANEL LIGHTING
BRIGHTNESS

The instrument lighting dimmer buttons
are on the lighting control.

E291299

E296433

Repeatedly press one of the
buttons to adjust the brightness.

AMBIENT LIGHTING

(IF EQUIPPED)

SWITCHING AMBIENT LIGHTING
ON AND OFF

From the settings menu, press General.
See

Center Display

(page 371).

2. Press Ambient Light.

3. Press a color.

ADJUSTING AMBIENT LIGHTING

Drag the selected color up or down.

INTERIOR LIGHTING –
TROUBLESHOOTING

INTERIOR LIGHTING –
FREQUENTLY ASKED QUESTIONS

Why do my courtesy lamps or
interior lamps turn off when I have
them switched on when I switch
my vehicle off?

•

The battery saver turns the courtesy
lamps and interior lamps off after a
short period of time after you switch
your vehicle off.

104

Interior Lighting

OPENING AND CLOSING THE
WINDOWS

WARNING:

Do not leave children

or pets unattended in your vehicle and
do not let children play with the power
windows. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

When closing the

power windows, verify that they are free
of obstructions and make sure children
and pets are not in the proximity of the
window openings. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

If an obstruction is

detected, release the switch and reverse
the window immediately. Failure to
follow this instruction could result in
personal injury or death.

WARNING:

Do not leave a key or

remote control unattended in the vehicle.
Children or pets could operate the power
windows and could become trapped in
a closing window. Failure to follow this
instruction could result in personal injury
or death.

Press the window control switch
to open the window. Lift the
window control switch to close

the window.

Note:

The power windows operate with the

ignition on, and for several minutes after you
switch the ignition off or until you open a
front door.

To reduce wind noise or pulsing noise when
one window is open, slightly open the
opposite window.

One-Touch Open

(If Equipped)

Fully press the window control switch and
release it. Press again or lift it to stop the
window.

One-Touch Close

(If Equipped)

Fully lift the window control switch and
release it. Press again or lift it to stop the
window.

Resetting One-Touch Close

Carry out all steps within 30 seconds of
starting the sequence.

Close the window.

2. Press and hold the window control

switch until the window is fully open.
Keep the window control switch
pressed for a few seconds.

3. Lift and hold the window control switch

until the window is fully closed. Keep
the window control switch held for a
few seconds.

4. Press and hold the window control

switch until the window is fully open.
Keep the window control switch
pressed for a few seconds.

5. Lift and hold the window control switch

until the window is fully closed. Keep
the window control switch held for a
few seconds.

Note:

Repeat the procedure if the window

does not close when you use one-touch.

Accessory Delay

The window switches remain operational
for several minutes when you switch the
ignition off or until you open either front
door.

105

Windows

GLOBAL OPENING

WHAT IS GLOBAL OPENING

You can use the remote control to open
the windows with the ignition off.

USING GLOBAL OPENING

Global Open Windows

Press and release the unlock button on
the remote control.

2. Press and hold the unlock button on

the remote control.

3. Release the button when the windows

start to open.

Press the lock or the unlock button on the
remote control to stop global opening.

Note:

You can use global opening for a

short period of time when you unlock your
vehicle using the remote control.

SWITCHING GLOBAL OPENING ON
AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Windows

4. Switch

Remote Open

on or off.

WINDOW BOUNCE-BACK

WHAT IS WINDOW BOUNCE-BACK

The window stops and reverses if it detects
an obstruction when closing.

OVERRIDING WINDOW BOUNCE-
BACK

WARNING:

If you override

bounce-back, the window does not
reverse if it detects an obstacle. Take
care when closing the windows to avoid
personal injury or damage to your
vehicle.

Close the window until it reaches the
point of resistance and let it reverse.

2. Lift and hold the window control switch

within two seconds to override
bounce-back and close the window.
Bounce-back is now disabled and you
can close the window manually.

Note:

The window goes past the point of

resistance and you can fully close it.

Note:

If the window does not close, have

your vehicle checked as soon as possible.

LOCKING THE REAR WINDOW
CONTROLS

WARNING:

When children and pets

are in the rear seat, use the power
window lockout button to prevent
accidental operation of the power
windows.

Press the window control switch
to lock or unlock the rear window
controls. It illuminates when you

lock the rear window controls.

106

Windows

INTERIOR MIRROR
PRECAUTIONS

WARNING:

Do not adjust the

mirrors when your vehicle is moving. This
could result in the loss of control of your
vehicle, serious personal injury or death.

Note:

Do not clean the mirror housing or

glass with harsh abrasives, fuel or other
petroleum-based cleaning products.

MANUALLY DIMMING THE
INTERIOR MIRROR

Pull the tab below the mirror toward you
to reduce glare at night.

AUTO-DIMMING INTERIOR
MIRROR

(IF EQUIPPED)

WHAT IS THE AUTO-DIMMING
INTERIOR MIRROR

The mirror dims to reduce the effect of
bright light from behind. It returns to
normal when the bright light from behind
is no longer present or if you shift into
reverse (R).

AUTO-DIMMING INTERIOR
MIRROR LIMITATIONS

Do not block the sensors on the front and
back of the mirror.

Note:

A rear center passenger or raised rear

center head restraint could prevent light
from reaching the sensor.

107

Interior Mirror

ADJUSTING THE EXTERIOR
MIRRORS

WARNING:

Do not adjust the

mirrors when your vehicle is moving. This
could result in the loss of control of your
vehicle, serious personal injury or death.

E144073

Left-hand mirror.

Adjustment control.

Right-hand mirror.

To adjust your mirrors, switch your vehicle
on, with the ignition in accessory mode or
the engine running and then:
1.

Select the mirror you want to adjust.
The control light turns on.

2. Use the adjustment control to adjust

the position of the mirror.

3. Press the mirror control again. The

control light turns off.

FOLDING THE EXTERIOR
MIRRORS

Push the mirror toward the door window
glass.

Make sure that you fully engage the mirror
in its support when returning it to its
original position.

AUTO-DIMMING EXTERIOR
MIRROR

WHAT IS THE AUTO-DIMMING
EXTERIOR MIRROR

The driver exterior mirror dims when the
interior auto-dimming mirror turns on.

108

Exterior Mirrors

OPENING AND CLOSING THE
SUNSHADE

WARNING:

Do not leave a key or

remote control unattended in the vehicle.
Children or pets could operate the
sunshade and get caught in a closing
sunshade. Failure to follow this
instruction could result in personal injury.

WARNING:

Do not leave children

or pets unattended in your vehicle and
do not let children play with the
sunshade. Failure to follow this
instruction could result in personal injury.

The controls are on the overhead console.

Opening the Sunshade

E312249

Press and release the switch to
activate the one-touch open
feature. To stop movement,

press the switch a second time. The
sunshade also opens when you open the
moonroof.

Closing the Sunshade

WARNING:

When closing the

sunshade, verify that it is free of
obstructions and make sure children and
pets are not in the proximity of the
sunshade. Failure to follow this
instruction could result in personal injury.

WARNING:

If an obstruction is

detected, press the switch a second time
and reverse the sunshade immediately.
Failure to follow this instruction could
result in personal injury.

E312250

Press and release the switch to
activate the one-touch close
feature. To stop movement,

press the switch a second time.

OPENING AND CLOSING THE
MOONROOF

WARNING:

Do not leave children

or pets unattended in your vehicle and
do not let children play with the
moonroof. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

Do not leave a key or

remote control unattended in the vehicle.
Children or pets could operate the
moonroof and could become trapped in
a closing moonroof. Failure to follow this
instruction could result in personal injury
or death.

The moonroof controls are on the
overhead console and have a one-touch
open feature. To stop its movement during
one-touch operation, press the switch a
second time.

Opening the Moonroof

E340663

Press and release the switch to
activate the one-touch open
feature. To stop movement,

press the switch a second time.

Note:

The moonroof stops short of the fully

opened position to reduce wind noise or
rumbling that may happen with the
moonroof fully open.

Press and release the switch again to fully
open the moonroof.

109

Moonroof

(If Equipped)

Closing the Moonroof

WARNING:

When closing the

moonroof, verify that it is free of
obstructions and make sure children and
pets are not in the proximity of the
moonroof. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

If an obstruction is

detected, release the switch and reverse
the moonroof immediately. Failure to
follow this instruction could result in
personal injury or death.

E340636

Press and hold the switch to
close from either the open or
vent positions. To stop

movement, release the switch.

Note:

The moonroof stops 8 in (200 mm)

from the closed position. To close the
moonroof, press and hold the moonroof
close control until the moonroof is in the
fully closed position.

VENTING THE MOONROOF

WARNING:

Do not leave children

unattended in your vehicle and do not
let them play with the moonroof. Failure
to follow this instruction could result in
personal injury.

The moonroof controls are on the
overhead console.

E340635

With the moonroof in the closed
position, press and release the
switch to vent the moonroof. To

close the moonroof from the vent position,
press and release the close switch.

MOONROOF BOUNCE-BACK

WHAT IS MOONROOF BOUNCE-
BACK

The moonroof stops and reverses some
distance if it detects an obstacle when
closing.

OVERRIDING MOONROOF
BOUNCE-BACK

Press and hold the close switch within two
seconds after the moonroof comes to a
stop.

110

Moonroof

(If Equipped)

FUEL GAUGE LIMITATIONS

The fuel gauge may not provide an
accurate reading when your vehicle is on
an incline.

LOCATING THE FUEL FILLER
DOOR

The arrow adjacent to the fuel pump
symbol indicates on which side of your
vehicle the fuel filler door is located.

WHAT IS THE LOW FUEL
REMINDER

A low fuel level reminder displays and
sounds when the distance to empty
reaches 75 mi (120 km) to empty for
MyKey, and at 50 mi (80 km), 25 mi
(40 km), 12 mi (20 km) and 0 mi (0 km)
for all vehicle keys.

Note:

The low fuel reminder can appear at

different fuel gauge positions depending on
fuel economy conditions. This variation is
normal.

WHAT IS DISTANCE TO EMPTY

Indicates the approximate distance your
vehicle can travel on the fuel remaining in
the tank. Changes in driving pattern can
cause the value to not only decrease but
also increase or stay constant for periods
of time.

ENGINE COOLANT
TEMPERATURE GAUGE

Indicates the engine coolant temperature.

TURBO BOOST GAUGE

Indicates the amount of manifold air
pressure in the engine.

Note:

This is a configurable gauge.

WHAT ARE THE INSTRUMENT
CLUSTER WARNING LAMPS

Warning lamps alert you to a vehicle
condition that could become serious.
Some lamps illuminate when you start
your vehicle to make sure they work. If any
lamps remain on after starting your vehicle,
refer to the respective system warning
lamp for further information.

INSTRUMENT CLUSTER
WARNING LAMPS

Anti-Lock Brake System

E67020

If it illuminates when you are
driving, this indicates the system
requires service. Your vehicle

continues to have normal braking without
the anti-lock brake system function. Have
your vehicle checked as soon as possible.

Battery

E67021

It illuminates when you switch
the ignition on.

If it illuminates when the engine

is running, this indicates your vehicle
requires service. Have your vehicle
checked as soon as possible.

Brake System

E270480

E67024

It illuminates when you apply the
parking brake and the ignition is
on. If it illuminates when your
vehicle is moving, make sure the
parking brake is released. If the
parking brake is released, this

indicates low brake fluid level or the brake
system requires service. Have your vehicle
checked as soon as possible.

112

Instrument Cluster

Note:

Lamps may vary depending on region.

Door Ajar

It illuminates when ignition is on
and remains on if any door is
open.

Electric Park Brake

E146190

It illuminates or flashes when the
electric parking brake requires
service.

Engine Coolant Temperature

E103308

If it illuminates, safely stop your
vehicle and switch the vehicle
off.

Fasten Seatbelt

E71880

It illuminates and a tone sounds
until you fasten the seatbelts.

Hood Ajar

E159324

It illuminates when ignition is on
and remains on if the hood is
open.

Liftgate Ajar

E162453

It illuminates when ignition is on
and remains on if the liftgate is
open.

Low Fuel Level

It illuminates when the fuel level
is low.

Low Tire Pressure Warning

E139232

It illuminates when your tire
pressure is low. If illuminated,
check your tire pressure as soon

as possible. If it begins to flash at anytime,
have the system checked as soon as
possible.

Low Washer Fluid Level

E132353

It illuminates when the washer
fluid is low.

Malfunction Indicator Lamp

E67028

It illuminates when the ignition
is on and the engine is off, this is
normal operation. If it illuminates

when the engine is on this indicates that
the emission control system requires
service. If it flashes, have your vehicle
checked immediately. See

Emission Law

(page 478). See

Starting and Stopping

the Engine – Warning Lamps

(page 160).

Oil Pressure

E67022

It illuminates when the engine
oil pressure is low.

Powertrain Fault

It illuminates when the
powertrain requires service. Have
the system checked as soon as

possible.

WHAT ARE THE INSTRUMENT
CLUSTER INDICATORS

Indicators notify you of various features
that are active on your vehicle.

113

Instrument Cluster

INSTRUMENT CLUSTER
INDICATORS

Adaptive Cruise Control

E144524

See

Adaptive Cruise Control

(page 213).

Automatic Headlamp High Beam

E146105

Auto-Start-Stop

E121377

Blind Spot Monitor

E151262

See

Blind Spot Information

System

(page 230).

Cruise Control

E71340

See

Cruise Control

(page 211).

Front Airbag

E67017

Front Fog Lamps

High Beam

E67019

Hill Start Assist

Lane Keeping Aid

E144813

Side Marker Lamps

E71341

See

Exterior Lamps

(page 99).

Stability and Traction Control

E138639

E130458

Turn Signal Lamps

E67018

See

Exterior Lamps

(page 99).

114

Instrument Cluster

USING THE INSTRUMENT
CLUSTER DISPLAY CONTROLS

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

The controls are on the steering wheel.

E144638

Button

Press to make a selection.

Toggle Buttons

Press the toggle button up and down to
scroll through the menu items.

Press the right arrow button to enter a
sub-menu.

Press the left arrow button to exit a menu.

Status Indicator

E204495

Menu items with a check box
indicates a feature's status. A
check in the box indicates the

feature is on, and unchecked indicates the
feature is off.

INSTRUMENT CLUSTER
DISPLAY MAIN MENU

Depending on your vehicle options, some
menu items may appear different or not
at all.

Note:

For your safety, some features are

speed-dependent and could be unavailable
when your vehicle is above a certain speed.

Menu Item

Trip 1 & 2

Fuel Economy

Driver Assist

Settings

115

Instrument Cluster Display

RESETTING THE TRIP COMPUTER

You can reset values using the steering

wheel controls to navigate the instrument
cluster display.

Action

Menu Item

Press the

button.

Fuel Economy

Press and hold the

button until the

system reset confirmation appears.

Fuel Economy

Press and hold the

button until the

system reset confirmation appears.

Fuel History

Press and hold the

button until the

system reset confirmation appears.

Average Speed

117

Instrument Cluster Display

RESETTING THE INDIVIDUAL TRIP
VALUES

You can reset the trip values using the
steering wheel controls to navigate the
instrument cluster display.

Action

Menu Item

Press the

button.

Trip 1 & 2

Press and hold the

button until the

system reset confirmation appears.

Trip 1

Press and hold the

button until the

system reset confirmation appears.

Trip 2

CUSTOMIZING THE
INSTRUMENT CLUSTER
DISPLAY

You can change the gauge layout in the
cluster using the steering wheel controls
to navigate the instrument cluster display.

Action

Menu Item

Press the

button.

Settings

Press the

button.

Display Setup

Press the

button. Choose a gauge

display.

Gauge Display

PERSONALIZED SETTINGS

CHANGING THE INSTRUMENT
CLUSTER DISPLAY LANGUAGE

You can change the language using the
steering wheel controls to navigate the
instrument cluster display.

118

Instrument Cluster Display

Action

Menu Item

Press the

button.

Settings

Press the

button.

Display Setup

Press the

button. Select a language.

Language

Note:

Available languages vary by region.

CHANGING THE MEASUREMENT
UNIT

You can change the measurement unit
using the steering wheel controls to
navigate the instrument cluster display.

Action

Menu Item

Press the

button.

Settings

Press the

button.

Display Setup

Press the

button. Select a measure-

ment unit.

Units

119

Instrument Cluster Display

WHAT IS REMOTE START

The system allows you to remotely start
your vehicle and to adjust the interior
temperature according to the settings that
you chose.

REMOTE START
PRECAUTIONS

WARNING:

Do not start the engine

in a closed garage or in other enclosed
areas. Exhaust fumes are toxic. Always
open the garage door before you start
the engine. Failure to follow this
instruction could result in personal injury
or death.

REMOTE START LIMITATIONS

Remote start does not work under the
following conditions:

•

The alarm horn is sounding.

•

The hood is open.

•

The transmission is not in park (P).

•

The ignition is on.

•

The battery voltage is below the
minimum operating voltage.

•

Remote start is not enabled.

Note:

Do not use remote start if the fuel

level is low.

ENABLING REMOTE START

Using the information display controls
on the steering wheel, select

Settings

2. Select

Settings

3. Select

Vehicle

4. Select

Remote Start

5. Switch

System

on.

Note:

To use remote start, make sure that

the modem is enabled. See

Enabling and

Disabling the Modem

(page 360).

REMOTELY STARTING AND
STOPPING THE VEHICLE

Remotely Starting the Vehicle

E138623

Press the button on the remote
control.

E138625

Within three seconds, press the
button on the remote control.

Within three seconds, press the

button again.

Note:

You can also use FordPass to start

the vehicle.

Note:

The vehicle doors lock when you

successfully remote start your vehicle.

Note:

The turn signal lamps flash twice.

Note:

The parking lamps turn on when the

vehicle is running.

Note:

The horn sounds if the system fails

to start.

Note:

All other vehicle systems remain off

when you have remotely started the vehicle.

Note:

The vehicle remains secured when

you have remotely started the vehicle. A
valid key must be inside your vehicle to
switch the ignition on and drive your vehicle.

Remotely Stopping the Vehicle

E138625

Press the button on the remote
control.

EXTENDING THE REMOTE
START DURATION

To extend the remote start duration during
remote start, do the following:

123

Remote Start

(If Equipped)

E138623

Press the button on the remote
control.

E138625

Within three seconds, press the
button on the remote control.

Within three seconds, press the

button again.

If the duration is set to 15 minutes, the
duration extends by another 15 minutes.
This provides a total of 30 minutes.

Note:

Remote start can only be extended

once.

Note:

A maximum of two remote starts, or

one remote start with an extension, are
allowed. To reset the restart procedure
switch the vehicle to on, then to off.

REMOTE START REMOTE
CONTROL INDICATORS

Remote Control Feedback

An LED on the remote control provides
status feedback of remote start or stop
commands.

Status

LED

Remote start

successful.

Solid green.

Remote stop

successful.

Solid red.

Request failed or

status not received.

Blinking red.

Status incomplete.

Blinking green.

REMOTE START SETTINGS

Switching Climate Control Auto
Mode On and Off

Using the instrument cluster display
controls on the steering wheel, select

Settings

2. Select

Vehicle

3. Select

Remote Start

4. Select

Climate Control

5. Select

Auto

Last settings

Note:

If you switch the auto mode on, the

system attempts to heat or cool the interior
to 72°F (22°C). When you switch the vehicle
on, the climate control system returns to
the last used settings.

Note:

If you switch the last settings on, the

system remembers the last used settings.

Heated Seat Settings

Using the instrument cluster display
controls on the steering wheel, select

Settings

2. Select

Vehicle

3. Select

Remote Start

4. Select

Seats

5. Select

Auto

Off

Note:

If you switch the heated seat settings

on, the heated seats turn on during cold
weather.

Note:

You cannot adjust the heated seat

settings when you remotely start your
vehicle.

Heated Steering Wheel Settings

Using the instrument cluster display
controls on the steering wheel, select

Settings

2. Select

Vehicle

3. Select

Remote Start

124

Remote Start

(If Equipped)

4. Select

Seats and Wheel

5. Select

Auto

Off

Note:

If you switch the heated steering

wheel settings on, the heated steering wheel
turns on during cold weather.

Note:

You cannot adjust the heated

steering wheel settings when you remotely
start your vehicle.

Remote Start Duration

Using the instrument cluster display
controls on the steering wheel, select

Settings

2. Select

Vehicle

3. Select

Remote Start

4. Select

Duration

5. Press the duration you prefer.

125

Remote Start

(If Equipped)

SWITCHING CLIMATE
CONTROL ON AND OFF

Use the touchscreen to change
the climate inside of your vehicle.

SWITCHING RECIRCULATED
AIR ON AND OFF

Press the touchscreen to
recirculate air currently in the
passenger compartment.

Note:

Recirculated air may turn off, or

prevent you from switching on, in all air flow
modes except MAX A/C to reduce the risk
of fogging. Recirculation may also turn on
and off in various air distribution control
combinations during hot weather to improve
cooling efficiency

Note:

Recirculated air could turn off or be

prevented from turning on in all air flow
modes except maximum cooling to reduce
the risk of the windows fogging up.

Note:

Recirculated air could turn on and off

when you direct air to the instrument panel
or footwell air vents during hot weather to
improve cooling efficiency.

SWITCHING AIR
CONDITIONING ON AND OFF

Press the touchscreen.

Note:

Under certain conditions, the air

conditioning compressor could continue to
operate after you switch air conditioning off.

SWITCHING MAXIMUM
DEFROST ON AND OFF

Press the button.

Note:

When you switch maximum defrost

on, the heated windshield, heated rear
window and air conditioning turn on. The
blower motor is set to the highest speed.

Note:

When you switch maximum defrost

off, the heated windshield and heated rear
window remain on.

SWITCHING MAXIMUM
COOLING ON AND OFF

Press the touchscreen.

Note:

When you switch maximum cooling

off, air conditioning remains on.

SWITCHING THE HEATED
REAR WINDOW ON AND OFF

Press the touchscreen to clear
the rear window of thin ice and
fog. The heated rear window

turns off after a short period of time.

Note:

Do not use harsh chemicals, razor

blades or other sharp objects to clean or
remove decals from the inside of the heated
rear window as this could cause damage to
the heated rear window grid lines not
covered by the vehicle Warranty.

126

Climate Control

SETTING THE BLOWER MOTOR
SPEED

E266187

E266186

Press the touchscreen up or
down on the control to select the
blower motor speed.

SWITCHING THE HEATED
MIRRORS ON AND OFF

Heated Mirrors

E266189

Press the touchscreen.

SETTING THE TEMPERATURE

Press the touchscreen temperature
controls on either side of the climate
control to set the temperature for that side.

E328451

Slide the control to set the
temperature.

Note:

This control also sets the right-hand

side temperature when you switch off dual
zone mode.

DIRECTING THE FLOW OF AIR

Directing Air to the Windshield Air
Vents

Press the touchscreen.

Directing Air to the Instrument
Panel Air Vents

E244097

Press the touchscreen.

Directing Air to the Footwell Air
Vents

E244098

Press the touchscreen.

AUTO MODE

SWITCHING AUTO MODE ON AND
OFF

Press the touchscreen to switch
auto mode on. Repeatedly press
the button to adjust auto mode.

Note:

When you switch auto mode on,

lights on the blower motor control do not
illuminate to indicate the blower motor
speed.

Adjust the blower motor control or air
distribution control to switch auto mode
off.

SWITCHING DUAL MODE ON AND
OFF

E265280

Press the button.

127

Climate Control

Ford Edge (2024 year). Manual in english - page 4
