Note:

Some options could appear slightly

different or not at all if the items are
optional.

Note:

Some MyKey menu options only

appear if MyKey is enabled and at least one
MyKey is programmed.

Select Screens

Menu options covered in Personalized Settings. See

Personalized Settings

(page

106).

Audio

Menu options covered in the SYNC chapter. See

General Information

(page 363).

Navigation

Menu options covered in the SYNC chapter. See

General Information

(page 363).

Phone

Menu options covered in the SYNC chapter. See

General Information

(page 363).

Settings

Percent Oil Life Indication XXX%
Hold Ok to Reset

Oil Life

Hold Ok to Reset

Tire Monitor

Note:

Additional vehicle settings are

available through your touchscreen. See

Settings

(page 391).

105

Information Displays

Display Setup

Speedometer km/h

Speedometer MPH

Note:

Additional display settings are

available through your touchscreen. See

Settings

(page 391).

PERSONALIZED SETTINGS

Select one of these options to display on
your main screen.

Note:

Some options could appear slightly

different or not at all if the items are
optional.

Select Screens

Calm Screen

Fuel Economy

Trip 1

Trip 2

Tire Pressure

Intelligent 4WD

Off Road

Trailer Light Check

Seatbelts

Auto StartStop

Now Playing

After making your selection:

Select a setting and press the

button. This offers more information
on the feature.

2. Select fuel economy, trip 1 or trip 2 to

reset. Press and hold the

button

for a few seconds.

Fuel Economy

An Instant Fuel Economy gauge is provided
along with average fuel economy. Average
fuel economy is continuously averaged
since the last reset.

106

Information Displays

Note:

When viewing this screen you can

reset your average fuel economy. Hold

to reset fuel history and average fuel
economy.

Trip 1 and 2

Provides trip timer, trip average fuel
economy and total trip distance traveled.
For hybrid vehicles, the trip also shows the
distance traveled on electric power only.

INFORMATION MESSAGES

Depending on your vehicle options and
instrument cluster type, not all messages
display or are available.

Note:

The system abbreviates or shortens

certain messages.

E222314

Press the

button to acknowledge and

remove some messages from the
information display. The system removes
other messages after a short time.

You need to confirm certain messages
before you can access the menus.

Adaptive Cruise Control

Details

Message

A radar malfunction is preventing the adaptive cruise from engaging.

Adaptive Cruise

Malfunction

Front Sensor Not

Aligned

Conditions exist such that the adaptive cruise cannot properly

function.

Adaptive Cruise

Not Available

Bad weather, ice, mud or water is causing poor radar visibility and

is blocking the radar sensor. You can typically clean the sensor to

resolve.

Adaptive Cruise

Not Available

Sensor Blocked

See Manual

Displays when automatic braking disables.

Normal Cruise

Active Adaptive

Braking Off

Displays when the adaptive cruise system reinstates control to the

driver.

Adaptive Cruise -

Driver Resume

Control

Displays when the vehicle speed is too slow to activate the adaptive

cruise.

Adaptive Cruise

Speed Too Low to

Activate

107

Information Displays

AdvanceTrac™ and Traction Control

Details

Message

The system detects a condition that requires service. Have the

system checked soon as possible.

Service Advan-

ceTrac

The status of the AdvanceTrac system after you switched it off.

AdvanceTrac Off

The status of the AdvanceTrac system after you switched it on.

AdvanceTrac On

The status of the traction control system after you switched it off.

Traction Control

Off

The status of the traction control system after you switched it on.

Traction Control

Alarm

Details

Message

Alarm triggered due to unauthorized entry. See

Anti-Theft Alarm

(page 75).

Vehicle Alarm To

Stop Alarm, Start

Vehicle.

Auto-Start-Stop

Details

Message

You need to restart the engine and press

the brake pedal to start.

Auto StartStop Press Brake to Start Engine

You need to restart the engine and press

the brake pedal harder to start.

Auto StartStop Press Brake Harder to

Activate

You need to restart the engine and press

any pedal to start.

Auto StartStop Press a Pedal to Start

Engine

Select neutral (N) for the system to restart

the engine.

Auto StartStop Select Neutral To Start

Engine

108

Information Displays

Details

Message

Select park (P) for the system to restart

the engine.

Auto StartStop Shift to P, then Restart

Engine

The system is not functioning. You need to

restart the engine.

Auto StartStop Manual Restart Required

Conditions are not met for the auto-start-

stop system to properly function.

Auto StartStop Not Available

Battery and Charging System

Details

Message

The charging system needs servicing. If the

warning stays on or continues to come on, have

the system checked as soon as possible.

Check Charging System

The charging system needs servicing. If the

warning stays on or continues to come on, have

the system checked as soon as possible.

Charging System Service Soon

The charging system needs servicing. Have the

system checked as soon as possible.

Charging System Service Now

The battery management system determines

that the 12V battery is at a low state of charge.
Start the engine to charge the battery or charge

the battery using an aftermarket battery

charger. This message clears once you restart

your vehicle and the battery state of charge

recovers.

Battery State of Charge Low

The battery management system determines

that the battery is at a low state of charge.

Switch the ignition off as soon as possible to

protect the battery. This message clears once

you restart your vehicle and the battery state

of charge recovers. Turning off unnecessary

electrical loads allows for a faster battery

state-of-charge recovery.

Turn Power Off To Save Battery

109

Information Displays

Blind Spot Information and Cross Traffic Alert System

Details

Message

A system error has occurred. Have the system checked as soon as

possible.

Blind Spot System

Fault

The system sensors are blocked. See

Blind Spot Information

System

(page 220).

Blind Spot Not

Available Sensor

Blocked See

Manual

The system detects a vehicle and automatically applied the brakes.

Cross Traffic Alert

Applying Brakes

The blind spot information system and cross traffic alert system

sensors are blocked. See

Cross Traffic Alert

(page 222).

Cross Traffic Not
Available Sensor

Blocked See

Manual

A system error has occurred. Have the system checked as soon as

possible.

Cross Traffic

System Fault

The system automatically turns off and displays this message when
you connect a trailer to the vehicle that does not have a trailer blind

spot system or when you switch the trailer blind spot system off
through the information display. See

Cross Traffic Alert

(page

222).

Cross Traffic Alert

Deactivated Trailer

Attached

The system automatically turns off and displays this message when
you connect a trailer to the vehicle that does not have a trailer blind

spot system or when you switch the trailer blind spot system off

through the information display. See

Blind Spot Information

System

(page 220).

Blind Spot Alert

Deactivated Trailer

Attached

Doors and Locks

Details

Message

The driver door is not completely closed.

Driver Door Ajar

The passenger door is not completely closed.

Passenger Door

Ajar

The rear left door is not completely closed.

Rear Left Door Ajar

The rear right door is not completely closed.

Rear Right Door

Ajar

110

Information Displays

Details

Message

The liftgate or liftgate glass is not completely closed.

Liftgate or liftglass

ajar

The hood is not completely closed.

Hood Ajar

The factory keypad code appears in the information display after
the system resets the keypad. See

Passive Anti-Theft System

(page 75).

Factory Keypad

Code {X X X X X}

Driver Alert

Details

Message

Stop and rest as soon as it is safe to do so.

Driver Alert

Warning Rest Now

Take a rest soon.

Driver Alert

Warning Rest

Suggested

Four-Wheel Drive

Details

Message

The four-wheel drive system temporarily turns off to protect itself

from overheating.

4WD Temporarily

Disabled

The four-wheel drive system is locking up the torque transfer clutch

to help reduce clutch temperature.

4WD Temporarily

Locked

The four-wheel drive system temporarily turns off to protect itself

from overheating or if you are using the temporary spare tire.

4WD Off

The four-wheel drive system will resume normal function and clear

this message after driving a short distance with the road tire re-

installed or after the system cools.

4WD Restored

The four-wheel drive system is not properly operating. If the warning
stays on or continues to come on, have the system checked as soon

as possible.

4WD Fault Service

Required

Displays when the power transfer unit fluid requires service.

Change 4WD

Power Transfer

Unit Lube

111

Information Displays

Details

Message

Displays when you have the power transfer unit fluid changed and

reset to new.

4WD Power

Transfer Unit Lube

Set to New

The selected drive mode does not allow you to turn on the rear

differential lock feature.

Rear Differential

Lock Not Available

in Current Drive

Mode

The selected drive mode requires your vehicle to be in four-wheel

drive.

4WD Lock

Required in Current

Drive Mode

Fuel

Details

Message

An early reminder of a low fuel condition.

Fuel Level Low

The fuel fill inlet may not be properly closed.

Check Fuel Fill

Inlet

Wait for up to 15 seconds while the fuel system depressurizes.

Fuel Door Opening

The fuel system has finished depressurizing and you can begin to
refuel.

Fuel Door Open

A reminder to close the fuel door. Failure to follow this instruction
can cause the check engine light to illuminate.

Close Fuel Door to

Avoid ""Check
Engine"" Light

There is an error in attempting to refill your vehicle.

Refuel Error See

Manual

Hill Start Assist

Details

Message

Hill start assist is not available. Have the system checked as soon

as possible. See

Hill Start Assist

(page 184).

Hill Start Assist

Not Available

112

Information Displays

Keys and Intelligent Access

Details

Message

A reminder to press the brake when starting your vehicle.

To START Press

Brake

The system does not detect the key. See

Keyless Starting

(page

155).

No Key Detected

Appears when you need to press the Start Stop button to shut off

the engine when the system does not detect an Intelligent Access

key inside your vehicle.

Restart Now or

Key is Needed

Your vehicle is in the accessory ignition state.

Full Accessory

Power Active

There is a problem with your vehicle’s starting system. Have the

system checked as soon as possible.

Starting System

Fault

During spare key programming, an intelligent access key is

programmed to the system.

Key Program

Successful

During spare key programming, the maximum number of keys have

been programmed.

Max Number of

Keys Learned

Displayed during spare key programming, when an intelligent access

key has failed to be programmed.

Key Program

Failure

Displayed during spare key programming when not enough keys

have been programmed.

Not Enough Keys

Learned

Displays when the key battery is low. Change the battery as soon

as possible.

Key Battery Low

Replace Soon

Displays when the vehicle is switched off.

Vehicle Switched

Off

113

Information Displays

Lane Keeping System

Details

Message

The system has malfunctioned. Have the system checked as soon

as possible.

Lane Keeping Sys.

Malfunction

Service Required

The system has detected a condition that has caused the system

to be temporarily unavailable.

Front Camera

Temporarily Not

Available

The system has detected a condition that requires the windshield

to be cleaned to properly operate.

Front Camera Low

Visibility Clean

Screen

The system has malfunctioned. Have the system checked as soon

as possible.

Front Camera

Malfunction

Service Required

The system requests the driver to keep their hands on the steering

wheel.

Keep Hands on

Steering Wheel

Maintenance

Details

Message

Stop your vehicle as soon as safely possible, turn off the engine.

Check the oil level. If the warning stays on or continues to come on

with your engine running, Have the system checked as soon as

possible.

Low Engine Oil

Pressure

The engine oil life remaining is 10% or less.

Change Engine Oil

Soon

The oil life left reaches 0%.

Oil Change

Required

The brake fluid level is low and the brake system should be imme-

diately inspected. See

Brake Fluid Check

(page 292).

Brake Fluid Level

Low

The brake system needs servicing. Stop the vehicle in a safe place.

Have the system checked as soon as possible.

Check Brake

System

The engine coolant temperature is excessively high.

Engine Coolant

Over Temperature

The washer fluid is low and needs to be refilled.

Washer Fluid Level

Low

114

Information Displays

Details

Message

Indicates that your vehicle is still in Transport mode. This may not

allow some features to properly operate. Have the system checked

as soon as possible.

Transport Mode

Contact Dealer

Indicates that your vehicle is still in Factory mode. This may not

allow some features to properly operate. Have your vehicle checked

as soon as possible.

Factory Mode

Contact Dealer

Informs the driver that the powertrain needs service due to a

powertrain malfunction.

See Manual

The engine has reduced power to help reduce high engine temper-

ature.

Power Reduced to

Lower Engine

Temp

The brake system has reduced stopping power.

Brake Applied

Power Reduced

MyKey

Details

Message

You cannot program a MyKey.

MyKey not Created

MyKey is active.

MyKey Active Drive

Safely

When switching on your vehicle and MyKey is in use, displays that

the MyKey speed limit is on.

Speed Limited to

XX MPH/km/h

MyKey is in use and the MyKey speed limit is on and the vehicle

speed is approaching 81 mph (130 km/h).

Near Vehicle Top

Speed

You have reached the speed limit set for your MyKey.

Vehicle at Top

Speed of MyKey

Setting

You have an active MyKey with a programmed set speed limit.

Check Speed Drive

Safely

Belt-Minder turns on with a MyKey in use.

Buckle Up to

Unmute Audio

With a MyKey in use, AdvanceTrac turns on.

AdvanceTrac On -

MyKey Setting

115

Information Displays

Details

Message

With a MyKey in use, traction control turns on.

Traction Control

On - MyKey

Setting

With a MyKey in use, park aid is always on.

MyKey Park Aid

Cannot be Deactiv-

ated

With a MyKey in use, lane keeping alert turns on.

Lane Keeping Alert

On MyKey Setting

Park Aid

Details

Message

The system has detected a fault that requires service. Have the

system checked as soon as possible.

Check Rear Park

Aid

The radar is blocked due to bad weather, ice, mud or water in front

of radar. You can typically clean the sensor to resolve. See

Rear

Parking Aid

(page 193).

Rear Park Aid Not

Available Sensor

Blocked See

Manual

The radar is blocked due to bad weather, ice, mud or water in front

of radar. You can typically clean the sensor to resolve. See

Prin-

ciple of Operation

(page 192).

Park Aid Not Avail-

able Sensor

Blocked See

Manual

Displays the park aid status.

Rear Park Aid On

Off

Park Brake

Details

Message

The parking brake is set, the engine is running and you drive your

vehicle more than 3 mph (5 km/h). If the warning stays on after the

parking brake is released, Have the system checked as soon as

possible.

Park Brake

Engaged

The electric parking brake is set and a manual release is attempted

without the brake pedal being pressed.

To Release: Press
Brake and Switch

The electric parking brake is set and an automatic release is

attempted but cannot be performed. Perform a manual release.

Park Brake Use

Switch to Release

116

Information Displays

Details

Message

The electric parking brake is set and your vehicle speed exceeds

3 mph (5 km/h). Release park brake before continued driving.

Release Park

Brake

The electric parking brake is not fully applied.

Park Brake Not

Applied

The electric parking brake is not fully released.

Park Brake Not

Released

The electric parking brake system has been put into a special mode

that is used to allow service of the rear brakes. Have the system

checked as soon as possible.

Park Brake Main-

tenance Mode

The electric park brake system has detected a condition that

requires service. Some functionality may still be available. Have the

system checked as soon as possible.

Park Brake Limited

Function Service

Required

The electric parking brake system has detected a condition that

requires service. Have the system checked as soon as possible.

Park Brake

Malfunction

Service Now

Numerous park brake applies have overheated the system. Wait 2

minutes before attempting to apply again.

Park Brake System

Overheated

Power Steering

Details

Message

The power steering system has detected a condition that requires

service. Have the system checked as soon as possible.

Steering Fault

Service Now

The power steering system is not working. Stop your vehicle in a

safe place. Have the system checked as soon as possible.

Steering Loss Stop

Safely

The power steering system has detected a condition within the

power steering system or passive entry or passive start system

requires service. Have the system checked as soon as possible.

Steering Assist

Fault Service

Required

The steering lock system has detected a condition that requires

service. Have the system checked as soon as possible.

Steering Lock

Malfunction

Service Now

117

Information Displays

Pre-Collision Assist

Details

Message

You have a blocked sensor due to bad weather, ice, mud or water
in front of the radar sensor. You can typically clean the sensor to
resolve.

Pre-Collision

Assist Not Avail-

able Sensor

Blocked

A fault with the system has occurred. Have the system checked as
soon as possible.

Pre-Collision

Assist Not Avail-

able

Remote Start

Details

Message

Displays as a reminder to apply the brake and push the gear shift

button to drive the vehicle after a remote start.

To Drive: Press

Brake and Gear

Shift Button

Seats

Details

Message

Objects are by the passenger seat. After the objects are moved

away from the seat, if the warning stays on or continues to come

on have the system checked as soon as possible.

Occupant Sensor

BLOCKED Remove

Objects Near

Passenger Seat

Displays as a reminder that memory seats are not available when

driving.

Memory Recall Not

Permitted While

Driving

Displays to show where your memory setting has been saved.

Memory {0} Saved

118

Information Displays

Starting System

Details

Message

Displays when starting the vehicle as a reminder to apply the brake.

To START Press

Brake

Displays when the starter has exceeded its cranking time in

attempting to start the vehicle.

Cranking Time

Exceeded

Displays when the starter is attempting to start the vehicle.

Engine Start

Pending Please

Wait

Displays when the pending start has been cancelled.

Pending Start

Cancelled

Tire Pressure Monitoring System

Details

Message

One or more tires on your vehicle have low tire pressure. See

Tire

Pressure Monitoring System

(page 324).

Tire Pressure Low

The tire pressure monitoring system is malfunctioning. If the warning
stays on or continues to come on, have the system checked as soon

as possible. See

Tire Pressure Monitoring System

(page 324).

Tire Pressure

Monitor Fault

A tire pressure sensor is malfunctioning, or your spare tire is in use.

For more information on how the system operates under these

conditions, See

Tire Pressure Monitoring System

(page 324). If

the warning stays on or continues to come on, have the system

checked as soon as possible.

Tire Pressure

Sensor Fault

119

Information Displays

Trailer

Details

Message

A correct trailer connection is sensed during

a given ignition cycle.

Trailer Connected

A trailer connection becomes either inten-

tionally or unintentionally disconnected and

has been sensed during a given ignition

cycle.

Trailer Disconnected

The trailer sway control has detected trailer

sway.

Trailer Sway Reduce Speed

There are certain faults in your vehicle

wiring and trailer wiring/brake system. See

Towing a Trailer

(page 245).

Trailer Wiring Fault

There is a fault with your trailer turn lamp.

Check your lamp.

Trailer Left Turn Lamps Fault Check Lamps

There is a fault with your trailer turn lamp.

Check your lamp.

Trailer Right Turn Lamps Fault Check

Lamps

There is a fault with your trailer battery.

See

Towing a Trailer

(page 245).

Trailer Battery Not Charging See Manual

There is a fault with your vehicle trailer

lighting module. See

Towing a Trailer

(page 245).

Trailer Lighting Module Fault See Manual

Transmission

Details

Message

Displays when you switch the engine off and the transmission is

not in park (P). Shift into park (P).

Shift to Park

Transmission is too cold. Wait for it to warm up before you drive.

Transmission

Warming Up

Please Wait

Displays when the brake pedal needs to be depressed.

Press Brake Pedal

The transmission is overheating and needs to cool. Stop in a safe

place as soon as it’s possible.

Transmission Over

Temperature Stop

Safely

120

Information Displays

Ford Bronco Sport (2022 year). Manual in english - page 7
