Ford Escape (2022 year). Manual in english

Selecting Which Information the

System Displays

Start the engine and switch the system on.

Note:

Press the head up display button if

you do not see the head up display menu in
the instrument cluster display.

Note:

For your safety, some features are

speed-dependent. The system limits their
use to when your vehicle is not moving.

Use the instrument cluster display controls
on the steering wheel to select which
information the system displays.

Action

Menu Item

Press the

button.

Content

Press the

button.

Distance Indication

Eco Advice

Incoming Calls

Lane Keeping System

Navigation

Speed Assistance

Speed Sign Recognition

HEAD UP DISPLAY

INDICATORS

E265900

Note:

The head up display indicator could

illuminate to supplement an information
message.

132

Head Up Display

(If Equipped)

HEAD UP DISPLAY – TROUBLESHOOTING

HEAD UP DISPLAY – INFORMATION MESSAGES

Action

Message

The system is malfunctioning or something

is obstructing the display. Make sure that

the head up display is free from obstruction.

If the message continues to appear, have

your vehicle checked as soon as possible.

Head Up Display System Fault See Manual

Press the button on the steering wheel or

center console. The head up display menu

appears in the instrument cluster display.

Make sure the blue frame is fully visible. Do

not manually move the screen. This can

cause damage not covered by your vehicle's

warranty.

Head Up Display To Position Use the

Information Display

133

Head Up Display

(If Equipped)

WHAT IS REMOTE START

The system allows you to remotely start
your vehicle and to adjust the interior
temperature according to the settings that
you chose.

REMOTE START

PRECAUTIONS

WARNING:

Do not start the engine

in a closed garage or in other enclosed
areas. Exhaust fumes are toxic. Always
open the garage door before you start
the engine. Failure to follow this
instruction could result in personal injury
or death.

REMOTE START LIMITATIONS

Remote start does not work under the
following conditions:

•

The alarm horn is sounding.

•

The hood is open.

•

The transmission is not in park (P).

•

The ignition is on.

•

The battery voltage is below the
minimum operating voltage.

•

Remote start is not enabled.

Note:

Do not use remote start if the fuel

level is low.

Note:

You can use remote start with

FordPass. See

Connecting the Vehicle to

a Wi-Fi Network

(page 405).

ENABLING REMOTE START

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Switch

Remote Start

on or off.

Note:

To remote start with FordPass, make

sure that the modem is enabled. See

Connected Vehicle Requirements

(page

405).

REMOTELY STARTING AND

STOPPING THE VEHICLE

Remotely Starting the Vehicle

E138623

Press the button on the remote
control.

E138625

Within three seconds, press the
button twice on the remote
control.

Note:

You can also use the FordPass App

to start the vehicle.

Note:

The turn signals flash twice.

Note:

The parking lamps turn on when the

vehicle is running.

Note:

The horn sounds if the system fails

to start.

Note:

All other vehicle systems remain off

when you have remotely started the vehicle.

Note:

The vehicle remains secured when

you have remotely started the vehicle. A
valid key must be inside your vehicle to
switch the ignition on and drive your vehicle.

Remotely Stopping the Vehicle

E138625

Within three seconds, press the
button twice on the remote
control.

EXTENDING THE REMOTE

START DURATION

To extend the remote start duration during
remote start, do the following:

134

Remote Start

(If Equipped)

E138623

Press the button on the remote
control.

E138625

Within three seconds, press the
button on the remote control.

Within three seconds, press the

button again.

If the duration is set to 15 minutes, the
duration extends by another 15 minutes.
This provides a total of 30 minutes.

Note:

Remote start can only be extended

once.

Note:

A maximum of two remote starts, or

one remote start with an extension, are
allowed. To reset the restart procedure
switch the vehicle to on, then to off.

REMOTE START REMOTE

CONTROL INDICATORS

Remote Control Feedback

An LED on the remote control provides
status feedback of remote start or stop
commands.

Status

LED

Remote start

successful.

Solid green.

Remote stop

successful.

Solid red.

Request failed or

status not received.

Blinking red.

Status incomplete.

Blinking green.

REMOTE START SETTINGS

SWITCHING CLIMATE CONTROL

AUTO MODE ON AND OFF

Press

Settings

on the touchscreen.

2. Press

Remote Start Setup

3. Press

Climate Control

4. Select

Vehicle

5. Switch

Auto

on or off.

Note:

If you switch the auto mode on, the

system attempts to heat or cool the interior
to 72°F (22°C).

Note:

When you switch the ignition on, the

climate control system returns to the last
used settings.

SWITCHING CLIMATE CONTROL

LAST SETTINGS ON AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Switch

Last settings

on or off.

Note:

If you switch the last settings on, the

system remembers the last used settings.

SWITCHING THE HEATED SEAT

SETTINGS ON AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Press

Seats

5. Switch

Auto

on or off.

Note:

If you switch the heated seat settings

on, the heated seats turn on during cold
weather.

SWITCHING THE HEATED

STEERING WHEEL SETTINGS ON

AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Press

Seats and Steering Wheel

135

Remote Start

(If Equipped)

5. Switch

Auto

on or off.

Note:

If you switch the heated steering

wheel settings on, the heated steering wheel
turns on during cold weather.

SETTING THE REMOTE START

DURATION

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Press

Duration

Note:

Wait a few seconds before remotely

starting the vehicle after the vehicle stops
running.

136

Remote Start

(If Equipped)

MANUAL CLIMATE CONTROL

E290056

Note:

Depending on your vehicle option

package, the controls may look different
from what you see here.

Directing the Airflow

Press and release the button to
direct airflow to the windshield
air vents and de-mister.

E244097

Press and release the button to
direct airflow to the instrument
panel air vents.

Press and release the button to
direct airflow to the footwell air
vents.

You can direct air through any combination
of these air vents.

Setting the Blower Motor Speed

265389

265

389

265389

Turn the control to adjust the volume of
air circulated in the vehicle.

Setting the Temperature

106

244

106

Turn the control to set the temperature.

Switching the Air Conditioning On

and Off

Press and release the button to
switch the air conditioning on or
off.

137

Climate Control

Use air conditioning with recirculated air
to improve cooling performance and
efficiency.

Note:

In certain conditions, for example,

maximum defrost, the air conditioning
compressor may continue to operate even
though you switch off the air conditioning.

Switching the Climate Control On

and Off

Press and release the button.

Switching Maximum Air

Conditioning On and Off

Turn the temperature control
counterclockwise to the lowest
setting for maximum cooling.

The left-hand and right-hand settings set
to LO, recirculated air flows through the
instrument panel air vents, air conditioning
turns on and the blower motor adjusts to
the highest speed.

Switching Maximum Defrost On

and Off

Turn the temperature control
clockwise to the highest setting
for maximum defrosting.

The left-hand and right-hand settings set
to HI, air flows through the windshield air
vents, and the blower motor adjusts to the
highest speed. You can also use this setting
to defog and clear the windshield of a thin
covering of ice. The heated rear window
also turns on when you select maximum
defrost.

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Switching Recirculated Air On and

Off

Press and release the button to
switch between outside air and
recirculated air.

The air currently in the passenger
compartment recirculates. This may
reduce the time needed to cool the interior,
when used with A/C, and reduce unwanted
odors from entering your vehicle.

Note:

Recirculated air may turn off, or

prevent you from switching on, in all air flow
modes except MAX A/C to reduce the risk
of fogging. Recirculation may also turn on
and off in various air distribution control
combinations during hot weather to improve
cooling efficiency.

AUTOMATIC CLIMATE

CONTROL - VEHICLES WITH:

DUAL AUTOMATIC

TEMPERATURE CONTROL

(DATC)

E290005

Note:

Depending on your vehicle option

package, the controls may look different
from what you see here.

Note:

For Hybrid vehicles, the air

conditioning compressor may run and
airflow may be felt when the climate control
is off to provide cooling to the battery.

138

Climate Control

Directing the Airflow

Press and release the button to
direct airflow to the windshield
air vents and de-mister.

E244097

Press and release the button to
direct airflow to the instrument
panel air vents.

Press and release the button to
direct airflow to the footwell air
vents.

You can direct air through any combination
of these air vents.

Setting the Blower Motor Speed

Press and release + or - to adjust
the volume of air circulated in
the vehicle.

Setting the Temperature

E2441

115

Turn the control on the left-hand side of
the climate control to set the left-hand
temperature.

Note:

This control also sets the right-hand

side temperature when you switch off dual
zone mode.

Turn the control on the right-hand side of
the climate control to set the right-hand
temperature.

Switching Auto Mode On and Off

Press and release the button to
switch on automatic operation.
Repeatedly press the button to

adjust auto mode.

The system adjusts the blower motor
speed, air distribution, air conditioning
operation, and outside or recirculated air
to reach and maintain the temperature you
have set.

Adjust the blower motor control to turn
auto mode off.

139

Climate Control

Auto Mode Indicator Status

Description

Auto Mode Indicator

Status

One indicator illumin-
ated.

•

The blower motor speed is reduced.

•

Use this setting to minimize the amount of noise from
the blower motor.

•

This setting increases the time taken to cool the
interior.

Two indicators illumin-
ated.

•

The blower motor speed is moderate.

Three indicators illumin-
ated.

•

The blower motor speed is increased.

•

This setting increases the amount of noise from the
blower motor.

•

Use this setting to reduce the time taken to cool the
interior.

Switching the Air Conditioning On

and Off

Press and release the button to
switch the air conditioning on or
off.

Use air conditioning with recirculated air
to improve cooling performance and
efficiency.

Note:

In certain conditions, for example,

maximum defrost, the air conditioning
compressor may continue to operate even
though you switch off the air conditioning.

Switching the Climate Control On

and Off

Press and release the button.

Note:

The button may be on the

temperature control.

Switching Dual Zone Mode On and

Off

E265280

Press and release the button to
switch on temperature control
for the right-hand side of the

vehicle.

Note:

The button may be on the

temperature control.

Switching Maximum Air

Conditioning On and Off

Press and release the button for
maximum cooling.

The system sets the left-hand and
right-hand settings to LO, recirculated air
flows through the instrument panel air
vents, air conditioning turns on and the
blower motor adjusts to the highest speed.

140

Climate Control

Switching Maximum Defrost On

and Off

Press and release the button to
switch on maximum defrost.

The system sets the left-hand and
right-hand settings to HI, air flows through
the windshield air vents, and the blower
motor adjusts to the highest speed. You
can also use this setting to defog and clear
the windshield of a thin covering of ice. The
heated rear window also turns on when
you select maximum defrost.

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Switching Recirculated Air On and

Off

Press and release the button to
switch between outside air and
recirculated air.

The air currently in the passenger
compartment recirculates. This may
reduce the time needed to cool the interior,
when used with A/C, and reduce unwanted
odors from entering your vehicle.

Note:

Recirculated air may turn off, or

AUTOMATIC CLIMATE

CONTROL - VEHICLES WITH:

ELECTRONIC AUTOMATIC

TEMPERATURE CONTROL

(EATC)

E289733

Note:

Depending on your vehicle option

package, the controls may look different
from what you see here.

Note:

For Hybrid vehicles, the air

conditioning compressor may run and
airflow may be felt when the climate control
is off to provide cooling to the battery.

Directing the Airflow

Press and release the button to
direct airflow to the windshield
air vents and de-mister.

E244097

Press and release the button to
direct airflow to the instrument
panel air vents.

Press and release the button to
direct airflow to the footwell air
vents.

You can direct air through any combination
of these air vents.

141

Climate Control

Setting the Blower Motor Speed

265389

265

389

265389

Turn the control to adjust the volume of
air circulated in the vehicle.

Setting the Temperature

E2441

115

Turn the control to set the temperature.

Switching Auto Mode On and Off

Press and release the button to
switch on automatic operation.
Repeatedly press the button to

adjust auto mode.

The system adjusts the blower motor
speed, air distribution, air conditioning
operation, and outside or recirculated air
to reach and maintain the temperature you
have set.

Adjust the blower motor control to turn
auto mode off.

Note:

The system starts at the previous

setting when you switch on AUTO mode.

142

Climate Control

Auto Mode Indicator Status

Description

Auto Mode Indicator

Status

One indicator illumin-
ated.

•

The blower motor speed is reduced.

•

Use this setting to minimize the amount of noise from
the blower motor.

•

This setting increases the time taken to cool the
interior.

Two indicators illumin-
ated.

•

The blower motor speed is moderate.

Three indicators illumin-
ated.

•

The blower motor speed is increased.

•

This setting increases the amount of noise from the
blower motor.

•

Use this setting to reduce the time taken to cool the
interior.

Switching the Air Conditioning On

and Off

Press and release the button to
switch the air conditioning on or
off.

Use air conditioning with recirculated air
to improve cooling performance and
efficiency.

Note:

In certain conditions, for example,

maximum defrost, the air conditioning
compressor may continue to operate even
though you switch off the air conditioning.

Switching the Climate Control On

and Off

Press and release the button.

Note:

The button may be on the

temperature control.

Switching Maximum Air

Conditioning On and Off

Press and release the button for
maximum cooling.

Recirculated air flows through the
instrument panel air vents, air conditioning
turns on and the blower motor adjusts to
the highest speed.

Switching Maximum Defrost On

and Off

Press and release the button for
maximum defrosting.

Air flows through the windshield air vents,
and the blower motor adjusts to the
highest speed.

You can also use this setting to defog and
clear the windshield of a thin covering of
ice.

143

Climate Control

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Note:

The heated rear window also turns

on when you select maximum defrost.

Switching Recirculated Air On and

Off

Press and release the button to
switch between outside air and
recirculated air.

The air currently in the passenger
compartment recirculates. This may
reduce the time needed to cool the interior,
when used with A/C, and reduce unwanted
odors from entering your vehicle.

Note:

Recirculated air may turn off, or

HINTS ON CONTROLLING THE

INTERIOR CLIMATE -

VEHICLES WITH: AUTOMATIC

TEMPERATURE CONTROL

General Hints

Note:

Prolonged use of recirculated air may

cause the windows to fog up.

Note:

You may feel a small amount of air

from the footwell air vents regardless of the
air distribution setting.

Note:

To reduce humidity build-up inside

your vehicle, do not drive with the system
switched off or with recirculated air always
switched on.

Note:

Do not place objects under the front

seats as this may interfere with the airflow
to the rear seats.

Note:

Remove any snow, ice or leaves from

the air intake area at the base of the
windshield.

Note:

To improve the time to reach a

comfortable temperature in hot weather,
drive with the windows open until you feel
cold air through the air vents.

Automatic Climate Control
Note:

Adjusting the settings when your

vehicle interior is extremely hot or cold is
not necessary. Automatic mode is best
recommended to maintain set temperature.

Note:

The system adjusts to heat or cool

the interior to the temperature you select
as quickly as possible.

Note:

For the system to function efficiently,

the instrument panel and side air vents
should be fully open.

Note:

If you select

AUTO

during cold

outside temperatures, the system directs
air flow to the windshield and side window
air vents. In addition, the blower motor may
run at a slower speed until the engine warms
up.

Note:

If you select

AUTO

during hot

temperatures and the inside of the vehicle
is hot, the system uses recirculated air to
maximize interior cooling. Blower motor
speed may also reduce until the air cools.

Quickly Heating the Interior

Press and release

AUTO

2. Adjust the temperature function to the

setting you prefer.

Recommended Settings for

Heating

Press and release

AUTO

2. Adjust the temperature function to the

setting you prefer. Use 72°F (22°C) as
a starting point, then adjust the setting
as necessary.

144

Climate Control

Quickly Cooling the Interior

Press and release

MAX A/C

Recommended Settings for

Cooling

Press and release

AUTO

2. Adjust the temperature function to the

setting you prefer. Use 72°F (22°C) as
a starting point, then adjust the setting
as necessary.

Defogging the Side Windows in

Cold Weather

Press and release defrost or maximum
defrost.

2. Adjust the temperature control to the

setting you prefer. Use 72°F (22°C) as
a starting point, then adjust the setting
as necessary.

HINTS ON CONTROLLING THE

INTERIOR CLIMATE -

VEHICLES WITH: MANUAL

TEMPERATURE CONTROL

General Hints

Note:

Prolonged use of recirculated air may

cause the windows to fog up.

Note:

You may feel a small amount of air

from the footwell air vents regardless of the
air distribution setting.

Note:

To reduce humidity build-up inside

your vehicle, do not drive with the system
switched off or with recirculated air always
switched on.

Note:

Do not place objects under the front

seats as this may interfere with the airflow
to the rear seats.

Note:

Remove any snow, ice or leaves from

the air intake area at the base of the
windshield.

Note:

To improve the time to reach a

comfortable temperature in hot weather,
drive with the windows open until you feel
cold air through the air vents.

Quickly Heating the Interior

Adjust the blower motor speed to the
highest speed setting.

2. Adjust the temperature control to the

highest setting.

3. Direct air to the footwell air vents.

Recommended Settings for

Heating

Adjust the blower motor speed to the
center setting.

2. Adjust the temperature control to the

midway point of the hot settings.

3. Direct air to the footwell air vents.

Quickly Cooling the Interior

Switch

MAX A/C

on.

2. Drive with the windows open for a short

period of time.

Recommended Settings for

Cooling

Adjust the blower motor speed to the
center setting.

2. Adjust the temperature control to the

midway point of the cold settings.

3. Direct air to the instrument panel air

vents.

Vehicle Stationary for Extended

Periods During Extreme High

Ambient Temperatures

Apply the parking brake.

2. Place your vehicle in park (P) or neutral

(N).

3. Switch

MAX A/C

on.

145

Climate Control

4. Adjust the blower motor speed to the

lowest speed setting.

Defogging the Side Windows in

Cold Weather

Direct air to the instrument panel and
windshield air vents.

2. Press and release

A/C

3. Adjust the temperature control to the

setting you prefer.

4. Adjust the blower motor speed to the

highest setting.

5. Direct air toward the side windows.

6. Close the instrument panel air vents.

HEATED WINDSHIELD

(IF

EQUIPPED)

Windshield Wiper De-Icer

When you switch the heated rear
window on, the windshield wiper
de-icer turns on.

HEATED REAR WINDOW

Press the button to clear the rear
window of thin ice and fog. The
heated rear window turns off

after a short period of time.

Note:

Make sure the engine is on before

operating the heated windows.

Note:

Do not use harsh chemicals, razor

blades or other sharp objects to clean or
remove decals from the inside of the heated
rear window. The vehicle warranty may not
cover damage to the heated rear window
grid lines.

HEATED EXTERIOR MIRRORS

(IF EQUIPPED)

When you switch the heated rear window
on, the heated exterior mirrors turn on.

Note:

Do not remove ice from the mirrors

with a scraper or adjust the mirror glass
when it is frozen in place.

Note:

Do not clean the mirror housing or

glass with harsh abrasives, fuel or other
petroleum-based cleaning products. The
vehicle warranty may not cover damage
caused to the mirror housing or glass.

146

Climate Control

WHAT IS THE CABIN AIR

FILTER

The cabin air filter improves the quality of
air in your vehicle by trapping dust, pollen
and other particles.

REPLACING THE CABIN AIR

FILTER

Replace the filter at regular intervals. See

Scheduled Maintenance

(page 482).

The cabin air filter is behind the glove
compartment.

To remove the lower glove compartment
and access the filter:

Open the glove compartment.

E31

1296

2. Press the tab on each side.

3. Fully lower the glove compartment.

4. Pull the glove compartment toward

you.

147

Interior Air Quality

Ford Escape (2022 year). Manual in english - page 8
