AIR CONDITIONING SYSTEM
CAPACITY AND
SPECIFICATION

WARNING:

The air conditioning

refrigerant system contains refrigerant
under high pressure. Only qualified
personnel should service the air
conditioning refrigerant system. Opening

the air conditioning refrigerant system
can cause personal injury.

Use refrigerant and oil that meets the
defined specifications.

If you do not use refrigerant and oil that
meets the defined specifications, it could
result in:
•

Component damage that your vehicle
warranty does not cover.

•

Reduced vehicle performance.

Capacities

Refrigerant Oil

Refrigerant

Variant

6.1 fl oz (180 ml)

37 oz (1.05 kg)

All.

Materials

Specification

Name

WSS-M17B21-A

R-1234yf Refrigerant(U.S.)
R-1234yf Refrigerant / Frigorigène R-1234yf(Canada)
YN-33-A(U.S.)
HS7Z-19B519-BA(Canada)

WSS-M2C300-A2

Motorcraft® R-1234yf Refrigerant PAG Oil(U.S.)
Motorcraft® R-1234yf Refrigerant PAG Oil / Huile
PAG pour frigorigène R-1234yf Motorcraft®(Canada)
YN-35(U.S. & Canada)

WASHER FLUID SPECIFICATION

Capacities

Quantity

Variant

Fill as required.

All.

456

Capacities and Specifications

Materials

Specification

Name

WSS-M14P19-A

Motorcraft® Premium Windshield Wash Concen-
trate with Bitterant(U.S.)
Motorcraft® Premium Quality Windshield Washer
Fluid / Liquide lave-glace de haute qualité Motor-
craft®(Canada)
ZC-32-B2(U.S.)
CXC-37-F/M(Canada)

BRAKE FLUID SPECIFICATION

Use fluid that meets the defined
specification and viscosity grade.

If you do not use fluid that meets the
defined specification and viscosity grade,
it could result in:
•

Component damage that your vehicle
warranty does not cover.

•

Reduced brake performance.

Note:

We recommend you use Dot 4 Low

Viscosity (LV) High Performance Brake Fluid
meeting WSS-M6C65-A2 specifications or
ISO 4925 Class 6 standards. If you use any
fluid other than the recommended fluid, it
could cause reduced brake performance
and not meet our performance standards.
Keep brake fluid clean and dry.
Contamination with dirt, water, petroleum
products or other materials could result in
brake system damage and possible failure.

Capacities

Quantity

Variant

Fill as required.

All.

Materials

Specification

Name

WSS-M6C65-A2

Motorcraft® DOT 4 LV High Performance Motor
Vehicle Brake Fluid(U.S.)
Motorcraft® DOT 4 LV High Performance Motor
Vehicle Brake Fluid / Liquide de frein automobile
haute performance DOT 4 LV Motorcraft®(Canada)
PM-20(U.S. & Canada)

457

Capacities and Specifications

TRANSFER CASE FLUID
CAPACITY AND
SPECIFICATION

Use fluid that meets the defined
specification and viscosity grade.

If you do not use fluid that meets the
defined specification and viscosity grade,
it could result in:
•

Component damage that your vehicle
warranty does not cover.

•

Reduced vehicle performance.

Capacities

Quantity

Variant

1.4–1.6 qt (1.3–1.5 L)

All.

Materials

Specification

Name

WSS-M2C938-AMERCON® LV,

Motorcraft® MERCON® LV Automatic Transmission
Fluid(U.S.)
Motorcraft® MERCON® LV Automatic Transmission
Fluid / Huile pour boîte automatique MERCON® LV
Motorcraft®(Canada)
XT-10-QLVC(U.S.)
CXT-10-LV6(Canada)

FRONT AXLE FLUID CAPACITY
AND SPECIFICATION

Use fluid that meets the defined
specification and viscosity grade.

If you do not use fluid that meets the
defined specification and viscosity grade,
it could result in:
•

Component damage that your vehicle
warranty does not cover.

•

Reduced vehicle performance.

Capacities

Quantity

Variant

1.8 qt (1.7 L)

Four-wheel drive.

458

Capacities and Specifications

Materials

Specification

Name

WSS-M2C942-A

Motorcraft® SAE 75W-85 Premium Synthetic
Hypoid Gear Lubricant(U.S.)
Motorcraft® SAE 75W-85 Premium Synthetic
Hypoid Gear Lubricant / Huile synthétique de haute
qualité pour engrenages hypoïdes SAE 75W-85
Motorcraft®(Canada)
XY-75W85-QL(U.S. & Canada)

REAR AXLE FLUID CAPACITY
AND SPECIFICATION

Use fluid that meets the defined
specification and viscosity grade.

If you do not use fluid that meets the
defined specification and viscosity grade,
it could result in:
•

Component damage that your vehicle
warranty does not cover.

•

Reduced vehicle performance.

Rear Axle - 8.8

Capacities

Quantity

Variant

2.5 qt (2.4 L)

All.

Materials

Specification

Name

WSS-M2C942-A

459

Capacities and Specifications

Rear Axle - 9.75 without Limited-Slip

Capacities

Quantity

Variant

2.5 qt (2.4 L)

All.

Materials

Specification

Name

WSS-M2C942-A

Rear Axle - 9.75 with Limited-Slip

Capacities

Quantity

Variant

2.4 qt (2.3 L)

All.

For complete refill of limited slip axles, add 4 fl oz. (118 ml) of Additive Friction Modifier

XL-3 or equivalent, meeting specification EST-M2C118-A. Include this friction modifier in
the total lube volume of 2.4 qt (2.3 L).

460

Capacities and Specifications

Materials

Specification

Name

EST-M2C118-A

Motorcraft® Additive Friction Modifier(U.S.)
Motorcraft® Additive Friction Modifier / Additif
modificateur de friction Motorcraft®(Canada)
XL-3(U.S.)
CXL-3(Canada)

WSS-M2C942-A

461

Capacities and Specifications

VEHICLE IDENTIFICATION
NUMBER

LOCATING THE VEHICLE
IDENTIFICATION NUMBER

The vehicle identification number is on the
left-hand side of the instrument panel.

E311767

Note:

In the illustration, XXXX is

representative of your vehicle identification
number.

VEHICLE IDENTIFICATION
NUMBER OVERVIEW

The vehicle identification number contains
the following information:

E142477

World manufacturer identifier.

Brake system, gross vehicle
weight rating, restraint devices
and their locations.

Make, vehicle line, series, body
type.

Engine or motor type.

Check digit.

Model year.

Assembly plant.

Production sequence number.

462

Vehicle Identification

WHAT IS A CONNECTED
VEHICLE

A connected vehicle has technology that
allows your vehicle to connect to a mobile
network and for you to access a range of
features. When used in conjunction with
the FordPass app, it could allow you to
monitor and control your vehicle further,
for example checking the tire pressures,
the fuel level and the vehicle location. For
additional information, refer to the local
Ford website.

CONNECTED VEHICLE
REQUIREMENTS

Connected service and related feature
functionality requires a compatible vehicle
network.

Some remote features require additional
service activation. Log in to your Ford
account for details. Some restrictions, third
party terms and message or data rates
may apply.

CONNECTED VEHICLE
LIMITATIONS

Evolving technology, cellular networks, or
regulations could affect functionality and
availability, or continued provision of some
features. These changes could even stop
some features from functioning.

CONNECTING THE VEHICLE TO
A MOBILE NETWORK

WHAT IS THE MODEM

The modem allows access to a
range of features built into your
vehicle.

ENABLING AND DISABLING THE
MODEM - VEHICLES WITH: 12.3
INCH SCREEN

Press

Settings

2. Press

Connectivity

3. Press

Connected Vehicle Features

4. Switch vehicle connectivity on or off.

ENABLING AND DISABLING THE
MODEM - VEHICLES WITH: 15 INCH
SCREEN

Tap the vehicle drawer on the top left of
the screen.

Press

Connectivity

2. Press

Connected Vehicle Features

3. Switch vehicle connectivity on or off.

CONNECTING FORDPASS TO THE
MODEM

Make sure that the modem is enabled
using the vehicle settings menu.

2. Open the FordPass app on your device

and log in.

3. Add your vehicle or select your vehicle

if already added.

4. Select the option to activate your

vehicle.

5. Make sure that the name on the screen

matches the name shown in your
FordPass account.

6. Confirm that FordPass account is

connected to the modem.

463

Connected Vehicle

CONNECTING THE VEHICLE TO
A WI-FI NETWORK - VEHICLES
WITH: 12.3 INCH SCREEN

E280315

Select the settings option on the
feature bar.

Press

Connectivity

2. Press

Manage Wi-Fi Networks

3. Switch

Wi-Fi

on.

4. Press

View Available Networks

5. Select an available Wi-Fi network.

Note:

Enter the network password to

connect to a secure network.

CONNECTING THE VEHICLE TO
A WI-FI NETWORK - VEHICLES
WITH: 15 INCH SCREEN

Access the application drawer on the
touchscreen.

Press

Connectivity

2. Press

Manage Wi-Fi Networks

3. Switch

Wi-Fi

on.

4. Press

View Available Networks

5. Select an available Wi-Fi network.

Note:

Enter the network password to

connect to a secure network.

CONNECTED VEHICLE – TROUBLESHOOTING

CONNECTED VEHICLE – FREQUENTLY ASKED QUESTIONS - VEHICLES
WITH: MODEM

Possible Cause and Resolution

Symptom

I cannot confirm the
connection of my FordPass
account to the modem.

–

Modem is not enabled.
•

Switch vehicle connectivity on.

–

Weak network signal.
•

Move your vehicle closer to a place where the
network signal is not obstructed.

464

Connected Vehicle

CONNECTED VEHICLE –
FREQUENTLY ASKED QUESTIONS
- VEHICLES WITH: SYNC 4

Why can I not confirm the
connection of my FordPass
account to the modem?

•

The modem is not enabled. Switch
vehicle connectivity on.

•

The network signal is weak. Move your
vehicle closer to a place where the
network signal is not obstructed.

Why can I not connect to a Wi-Fi
network?

•

You entered the wrong network
password. Enter the correct password.

•

The network signal is weak. Move your
vehicle closer to the Wi-Fi router or to
a place where the network signal is not
obstructed.

•

There are multiple access points in
range with the same network name.
Choose a unique name for your
network. Do not use the default name
unless it contains a unique identifier,
for example as part of the MAC
address.

Why does the Wi-Fi connection
disconnect after successful
connection?

•

The network signal is weak. Move your
vehicle closer to the Wi-Fi router or to
a place where the network signal is not
obstructed.

What can I do if I am close to a Wi-
Fi router but the network signal
strength is weak?

•

If your vehicle has a heated windshield,
position your vehicle so that the
windshield is not facing the Wi-Fi
router.

•

If your vehicle has metallic tinting on
the windows but not on the windshield,
position your vehicle so that the
windshield is facing the Wi-Fi router or
open the windows that are facing the
router.

•

If your vehicle has metallic tinting on
the windows and the windshield, open
the windows that are facing the router.

•

If your vehicle is in a garage and you
have the garage door closed, open the
garage door as it could block the signal.

Why can I not see a network I

expect to see in the list of available
networks?

•

The network is hidden. Make the
network visible and try again, or
manually add a network in the Wi-Fi
settings menu.

•

Some network security types are not
supported, for example WEP.

Why do software downloads take
too long?

•

The network signal is weak. Move your
vehicle closer to the Wi-Fi router or to
a place where the network signal is not
obstructed.

•

Wi-Fi network is in high demand or has
a slow Internet connection. Use a more
reliable Wi-Fi network.

465

Connected Vehicle

Why does the software not update
when the system seems to connect
to a Wi-Fi network and the signal
strength is excellent?

•

No software update is available at this
time.

•

Select automatic updates option in the
settings menu to enable automatic
software update or contact an
authorized dealer.

•

There could be a connection problem.
Test the network using another device.

466

Connected Vehicle

CREATING A VEHICLE WI-FI
HOTSPOT - VEHICLES WITH:
12.3 INCH SCREEN

You can create a Wi-Fi hotspot in your
vehicle and allow devices to connect to it
for access to the Internet.

E280315

Select the settings option on the
feature bar.

Press

Vehicle Hotspot

Note:

The vehicle hotspot default setting

is on.

2. Press

Settings

3. Press

Edit

4. Press

Hotspot visibility

Note:

The hotspot visibility default setting

is on.

Finding the Wi-Fi Hotspot Name
and Password

E280315

Select the settings option on the
feature bar.

Press

Vehicle Hotspot

2. Press

Settings

Note:

The network name is the hotspot

name.

3. Press

View Password

Connecting a Device to the Wi-Fi
Hotspot

On your device, switch Wi-Fi on and
select the hotspot from the list of
available Wi-Fi networks.

2. When prompted, enter the password.

Purchasing a Data Plan

Connect a device to the hotspot.

Note:

The vehicle network carrier’s portal

opens on your device.

2. If the portal does not open on your

device, open a website and it redirects
to the vehicle network carrier’s portal.

Note:

Secure websites do not redirect.

3. Follow the instructions on the carrier

portal to purchase a plan.

Note:

If you have an active plan, the system

does not redirect to the vehicle network
carrier’s portal when you connect a device.
Visit the vehicle network carrier’s website
to purchase more data.

Note:

If data usage information is available

in the vehicle hotspot menu, it is
approximate.

Note:

If you carry out a master reset, the

system does not remove your vehicle from
your vehicle network carrier’s account. To
remove your vehicle from the account,
contact your vehicle network carrier.

Note:

The vehicle network carrier provides

Vehicle Hotspot services, subject to your
vehicle network carrier agreement, coverage
and availability.

CREATING A VEHICLE WI-FI
HOTSPOT - VEHICLES WITH:
15 INCH SCREEN

You can create a Wi-Fi hotspot in your
vehicle and allow devices to connect to it
for access to the Internet.

Tap the vehicle drawer on the top left of
the screen.

Press

Vehicle Hotspot

Note:

The vehicle hotspot default setting

is on.

2. Press Settings under the Vehicle

Hotspot menu.

3. Press

Edit

4. Switch the Wi-Fi Visibility option on or

off.

467

Vehicle Wi-Fi Hotspot

Note:

The Wi-Fi visibility default setting is

on.

Finding the Wi-Fi Hotspot Name
and Password

Tap the vehicle drawer on the top left of
the screen.

Press

Vehicle Hotspot

2. Press Settings under the Vehicle

Hotspot menu.

Note:

The network name is the hotspot

name.

3. Switch the Show Password option on

or off.

Connecting a Device to the Wi-Fi
Hotspot

On your device, switch Wi-Fi on and
select the hotspot from the list of
available Wi-Fi networks.

2. When prompted, enter the password.

Purchasing a Data Plan

Connect a device to the hotspot.

Note:

The vehicle network carrier’s portal

opens on your device.

2. If the portal does not open on your

device, open a website and it redirects
to the vehicle network carrier’s portal.

Note:

Secure websites do not redirect.

3. Follow the instructions on the carrier

portal to purchase a plan.

Note:

If you have an active plan, the system

does not redirect to the vehicle network
carrier’s portal when you connect a device.
Visit the vehicle network carrier’s website
to purchase more data.

Note:

If data usage information is available

in the vehicle hotspot menu, it is
approximate.

Note:

If you carry out a master reset, the

system does not remove your vehicle from
your vehicle network carrier’s account. To
remove your vehicle from the account,
contact your vehicle network carrier.

Note:

The vehicle network carrier provides

Vehicle Hotspot services, subject to your
vehicle network carrier agreement, coverage
and availability.

CHANGING THE VEHICLE WI-
FI HOTSPOT NAME OR
PASSWORD - VEHICLES WITH:
12.3 INCH SCREEN

E280315

Select the settings option on the
feature bar.

Press

Vehicle Hotspot

2. Press

Settings

3. Press

Edit

4. Press

Change Network Name

5. Enter your required network name.

6. Press

Done

Press

Change Password

8. Enter your required password.

9. Press

Done

Changing the Wi-Fi Hotspot
Frequency

Note:

The vehicle hotspot frequency band

is selectable depending upon your device
capabilities. You will not be able to connect
your device to the vehicle hotspot if it does
not support the selected frequency band.

E280315

Select the settings option on the
feature bar.

Press

Vehicle Hotspot

2. Press

Settings

3. Press

Edit

468

Vehicle Wi-Fi Hotspot

4. Select a frequency.

CHANGING THE VEHICLE WI-
FI HOTSPOT NAME OR
PASSWORD - VEHICLES WITH:
15 INCH SCREEN

Tap the vehicle drawer on the top left of
the screen.

Press

Vehicle Hotspot

2. Press Settings under the Vehicle

Hotspot menu.

3. Press

Edit

4. Press

Change Network Name

5. Enter your required network name.

6. Press enter to save the network name.

Press

Change Password

8. Enter your required password.

9. Press enter to save the password.

Changing the Wi-Fi Hotspot
Frequency

Note:

The vehicle hotspot frequency band

is selectable depending upon your device
capabilities. You will not be able to connect
your device to the vehicle hotspot if it does
not support the selected frequency band.

Tap the vehicle drawer on the top left of
the screen.

Press

Vehicle Hotspot

2. Press Settings under the Vehicle

Hotspot menu.

3. Press

Edit

4. Select a frequency.

469

Vehicle Wi-Fi Hotspot

AUDIO SYSTEM
PRECAUTIONS

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

Listening to loud audio for long periods of
time could damage your hearing.

IDENTIFYING THE AUDIO UNIT

E308144

Depending on your vehicle options, the
controls may look different from what you
see here.

SWITCHING THE AUDIO UNIT
ON AND OFF

Press the button on the volume
control.

SELECTING THE AUDIO
SOURCE

Audio Unit

E308143

Press to open the media source
menu.

You can press this multiple times to
change the audio source or scroll through
the media sources.

Touchscreen

Press

Sources

on the touchscreen to open

the media source menu.

PLAYING OR PAUSING THE
AUDIO SOURCE

Audio Unit

Press the button to pause
playback. Press again to resume
playback.

Touchscreen

Press the button to pause
playback. Press again to resume
playback.

Note:

Not all sources can be paused.

470

Audio System - Vehicles With: 12.3 Inch Screen

ADJUSTING THE VOLUME

E248939

Turn to adjust the volume.

Some vehicles may be able to adjust the
volume using buttons on the steering
wheel.

SWITCHING SHUFFLE MODE
ON AND OFF

Press the button on the
touchscreen to switch shuffle
mode on or off.

Note:

Not all sources have shuffle mode.

SWITCHING REPEAT MODE ON
AND OFF

Press the button on the
touchscreen to switch repeat
mode on or off.

Note:

Not all sources have repeat mode.

SETTING A MEMORY PRESET

Select a station or channel.

2. Press and hold a memory preset button

on the touchscreen.

Note:

The audio mutes briefly while the

system saves the preset and returns once it
is stored.

Note:

You can save presets from multiple

sources to the memory preset bar.

MUTING THE AUDIO

Press to mute the signal. Press
again to restore the signal.

ADJUSTING THE SOUND
SETTINGS

Balance and Fade

(If Equipped)

Press

Settings

on the touchscreen.

2. Press

Sound Settings

3. Press

Balance / Fade

4. Press the arrows to adjust the settings.

Tone Settings

Press

Settings

on the touchscreen.

2. Press

Sound Settings

3. Press

Tone Settings

4. Press the arrows or slider bar to adjust

the settings.

Speed Compensated Volume

Press

Settings

on the touchscreen.

2. Press

Sound Settings

3. Press

Speed Compensated Volume

4. Press a setting.

471

Audio System - Vehicles With: 12.3 Inch Screen

Content .. 26 27 28 29 ..
