can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

The controls are on the steering wheel.

E309379

Back button.

OK button.

Menu button.

Back Button

Press to go back or to exit a menu.

Button

Press to make a selection.

Menu Button

Press to display the submenus.

Scroll Buttons

Press the up or down buttons to scroll
through the menu items.

Status Indicator

E204495

Menu items with a check box
indicates a feature's status. A
check in the box indicates the

feature is on, and unchecked indicates the
feature is off.

INSTRUMENT CLUSTER
DISPLAY MAIN MENU -
VEHICLES WITH: 8 INCH
SCREEN

Depending on your vehicle options, some
menu items can appear different or not at
all.

Note:

For your safety, some features are

speed-dependent and could be unavailable
when your vehicle is above a certain speed.

Main Menu

MyView

Trip/Fuel

Vehicle Info

Towing

Navigation

Phone

Audio

Settings

137

Instrument Cluster Display

INSTRUMENT CLUSTER
DISPLAY MAIN MENU -
VEHICLES WITH: 12.3 INCH
SCREEN

Depending on your vehicle options, some
menu items can appear different or not at
all.

Note:

For your safety, some features are

speed-dependent and could be unavailable
when your vehicle is above a certain speed.

Main Menu

MyView

Trip/Fuel

Vehicle Information

Towing

Navigation

Phone

Audio

Settings

TRIP COMPUTER - VEHICLES
WITH: 8 INCH SCREEN/12.3
INCH SCREEN

ACCESSING THE TRIP COMPUTER

Select

Trip/Fuel

2. Select

This Trip

Trip 1

Trip 2

RESETTING THE TRIP COMPUTER

Select

Trip/Fuel

2. Select

Trip 1

Trip 2

3. Press and hold the

button for a few

seconds.

Note:

This Trip resets every time you start

your vehicle.

CUSTOMIZING THE
INSTRUMENT CLUSTER
DISPLAY

Adding Screens Using MyView

Using the information display controls
on the steering wheel, select

MyView

2. Select

Configure MyView

3. Select a screen.

4. Press the

button.

Note:

The number of screens you can add

is limited. If the selected screen does not
appear you must deselect screens from the
MyView menu.

Configuring Gauges

Select

Settings

2. Select

Configure Gauges

3. Select to swap or change left-hand

side and right-hand side gauges.

138

Instrument Cluster Display

CHANGING THE LANGUAGE

Press

Settings

on the touchscreen.

2. Press

General

3. Press

Language

4. Select a language.

CHANGING THE
MEASUREMENT UNIT

Press

Settings

on the touchscreen.

2. Press

General

3. Press

Measure Units

4. Select a measurement unit.

CHANGING THE
TEMPERATURE UNIT

Press

Settings

on the touchscreen.

2. Press

General

3. Press

Temperature Units

4. Select a temperature unit.

CHANGING THE TIRE
PRESSURE UNIT

Press

Settings

on the touchscreen.

2. Press

General

3. Press

Tire Pressure Units

4. Select a pressure unit.

139

Personalized Settings - Vehicles With: 12.3 Inch Screen

CHANGING THE LANGUAGE

To change the language use the center
display:

Press

SETTINGS

2. Press

General

3. Press

Language

4. Select a language.

CHANGING THE
MEASUREMENT UNIT

To change the measurement unit use the
center display:

Press

SETTINGS

2. Press

General

3. Press

Measurement Units

4. Select a measurement unit.

CHANGING THE
TEMPERATURE UNIT

To change the temperature unit use the
center display:

Press

SETTINGS

2. Press

General

3. Press

Temperature Units

4. Select a temperature unit.

CHANGING THE TIRE
PRESSURE UNIT

To change the tire pressure unit use the
center display:

Press

SETTINGS

2. Press

General

3. Press

Tire Pressure Units

4. Select a pressure unit.

140

Personalized Settings - Vehicles With: 15 Inch Screen

WHAT IS REMOTE START

The system allows you to remotely start
your vehicle and to adjust the interior
temperature according to the settings that
you chose.

REMOTE START
PRECAUTIONS

WARNING:

Do not start the engine

in a closed garage or in other enclosed
areas. Exhaust fumes are toxic. Always
open the garage door before you start
the engine. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

Do not keep electrical

devices plugged in the power point
whenever the device is not in use. Power
points power up during remote start.

WARNING:

Do not keep electrical

devices plugged into the power outlet
whenever the device is not in use. The
outlet provides power when the vehicle
is on. Failure to follow this instruction
could result in personal injury.

REMOTE START LIMITATIONS

Remote start does not work under the
following conditions:

•

The alarm horn is sounding.

•

The hood is open.

•

The transmission is not in park (P).

•

The ignition is on.

•

The battery voltage is below the
minimum operating voltage.

•

Remote start is not enabled.

Note:

Do not use remote start if the fuel

level is low.

Note:

You can use remote start with

FordPass. See

Connecting the Vehicle to

a Wi-Fi Network

(page 464).

ENABLING REMOTE START

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Switch

Remote Start

on or off.

Note:

To remote start with FordPass, make

sure that the modem is enabled. See

Connecting FordPass to the Modem

(page 463).

REMOTELY STARTING AND
STOPPING THE VEHICLE

Remotely Starting the Vehicle

E138623

Press the button on the remote
control.

E138625

Within three seconds, press the
button on the remote control.

Within three seconds, press the

button again.

Note:

You can also use FordPass to start

the vehicle.

Note:

The turn signal lamps flash twice.

Note:

The parking lamps turn on when the

vehicle is running.

Note:

The horn sounds if the system fails

to start.

Note:

All other vehicle systems remain off

when you have remotely started the vehicle.

141

Remote Start

(If Equipped)

Note:

The vehicle remains secured when

you have remotely started the vehicle. A
valid key must be inside your vehicle to
switch the ignition on and drive your vehicle.

Remotely Stopping the Vehicle

E138625

Within three seconds, press the
button on the remote control.

Within three seconds, press the

button again.

EXTENDING THE REMOTE
START DURATION

To extend the remote start duration during
remote start, do the following:

E138623

Press the button on the remote
control.

E138625

Within three seconds, press the
button on the remote control.

Within three seconds, press the

button again.

If the duration is set to 15 minutes, the
duration extends by another 15 minutes.
This provides a total of 30 minutes.

Note:

Remote start can only be extended

once.

Note:

A maximum of two remote starts, or

one remote start with an extension, are
allowed. To reset the restart procedure
switch the vehicle to on, then to off.

REMOTE START REMOTE
CONTROL INDICATORS

Remote Control Feedback

An LED on the remote control provides
status feedback of remote start or stop
commands.

Status

LED

Remote start

successful.

Solid green.

Remote stop

successful.

Solid red.

Request failed or

status not received.

Blinking red.

Status incomplete.

Blinking green.

REMOTE START SETTINGS

SWITCHING CLIMATE CONTROL
AUTO MODE ON AND OFF

Press

Settings

on the touchscreen.

2. Press

Remote Start Setup

3. Press

Climate Control

4. Select

Vehicle

5. Switch

Auto

on or off.

Note:

If you switch the auto mode on, the

system attempts to heat or cool the interior
to 72°F (22°C).

Note:

When you switch the ignition on, the

climate control system returns to the last
used settings.

SWITCHING CLIMATE CONTROL
LAST SETTINGS ON AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Switch

Last settings

on or off.

Note:

If you switch the last settings on, the

system remembers the last used settings.

142

Remote Start

(If Equipped)

SWITCHING THE HEATED SEAT
SETTINGS ON AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Press

Seats

5. Switch

Auto

on or off.

Note:

If you switch the heated seat settings

on, the heated seats turn on during cold
weather.

SWITCHING THE HEATED
STEERING WHEEL SETTINGS ON
AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Press

Seats and Steering Wheel

5. Switch

Auto

on or off.

Note:

If you switch the heated steering

wheel settings on, the heated steering wheel
turns on during cold weather.

SETTING THE REMOTE START
DURATION

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Press

Duration

Note:

Wait a few seconds before remotely

starting the vehicle after the vehicle stops
running.

143

Remote Start

(If Equipped)

IDENTIFYING THE CLIMATE
CONTROL UNIT

E339318

Depending on your vehicle options, the
controls could look different than what you
see here.

SWITCHING CLIMATE
CONTROL ON AND OFF

Press the button.

SWITCHING RECIRCULATED
AIR ON AND OFF

Press the button to recirculate
air currently in the passenger
compartment.

Note:

Recirculated air may turn off

automatically, or prevent you from switching
on in all air flow modes except MAX A/C to
reduce the risk of fogging. Recirculation may
also turn on and off automatically in various
air distribution control combinations to
improve heating or cooling efficiency.

SWITCHING AIR
CONDITIONING ON AND OFF

Press the button.

Note:

Under certain conditions, the air

conditioning compressor could continue to
operate after you switch air conditioning off.

Note:

To keep the system and its

components fully functional, switch air
conditioning on and let your vehicle idle at
least once per month for a minimum of two
minutes.

SWITCHING DEFROST ON AND
OFF

E265283

Press the button to activate the
selection screen.

Press the button on the
touchscreen to switch the
windshield air vents on.

E244097

Make sure that the instrument
panel air vents are switched off.

Make sure that the footwell air
vents are switched off.

SWITCHING MAXIMUM
DEFROST ON AND OFF

Press the button.

Air flows through the windshield air vents,
and the blower motor adjusts to the
highest speed.

You can also use this setting to defog and
clear the windshield of a thin covering of
ice.

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Note:

The heated rear window also turns

on when you select maximum defrost.

144

Climate Control

Note:

When maximum defrost is on, the air

conditioning compressor may continue to
operate even though you switch off the air
conditioning.

SWITCHING MAXIMUM
COOLING ON AND OFF

Press the button.

Note:

When you switch maximum cooling

off, air conditioning remains on.

SWITCHING THE HEATED
REAR WINDOW ON AND OFF

Press the button to clear the rear
window of thin ice and fog. The
heated rear window turns off

after a short period of time.

Note:

This button also activates the heated

mirrors.

Note:

Do not use harsh chemicals, razor

blades or other sharp objects to clean or
remove decals from the inside of the heated
rear window as this could cause damage to
the heated rear window grid lines not
covered by the vehicle Warranty.

SETTING THE BLOWER MOTOR
SPEED

E266187

E266186

Press up or down on the control
to select the blower motor
speed.

Note:

For Hybrid Electric Vehicle (HEV) and

Plug-In Hybrid Electric Vehicle (PHEV)
vehicles, the blower motor may run, and you
may feel airflow when the climate control
is off to provide cooling to the battery.

SETTING THE TEMPERATURE

E244115

Turn the control on the left-hand side of
the climate control to set the left-hand
temperature.

Note:

This control also sets the right-hand

side temperature when you switch off dual
zone mode.

Turn the control on the right-hand side of
the climate control to set the right-hand
temperature.

DIRECTING THE FLOW OF AIR

Directing Air to the Windshield Air
Vents

E265283

Press the button to activate the
selection screen.

Press the button on the
touchscreen.

145

Climate Control

Directing Air to the Instrument
Panel Air Vents

E265283

Press the button to activate the
selection screen.

E244097

Press the button on the
touchscreen.

Directing Air to the Footwell Air
Vents

E265283

Press the button to activate the
selection screen.

Press the button on the
touchscreen.

AUTO MODE

SWITCHING AUTO MODE ON AND
OFF

Press the button to switch auto
mode on. Repeatedly press the
button to adjust auto mode.

Note:

When you switch auto mode on,

lights on the blower motor control do not
illuminate to indicate the blower motor
speed.

Adjust the blower motor control or air
distribution control to switch auto mode
off.

AUTO MODE INDICATORS

The indicators are on the Auto Mode
button.

Description

Auto Mode Indicator

Status

The blower motor speed is reduced. Use this setting to
minimize the amount of noise from the blower motor. This
setting increases the time taken to cool the interior.

One indicator illumin-
ated.

The blower motor speed is moderate.

Two indicators illumin-
ated.

The blower motor speed is increased. Use this setting to
reduce the time taken to cool the interior. This setting
increases the amount of noise from the blower motor.

Three indicators illumin-
ated.

146

Climate Control

SWITCHING DUAL MODE ON AND
OFF

E265280

Press the button.

CLIMATE CONTROL HINTS

General Hints

•

Prolonged use of recirculated air may
cause the windows to fog up.

•

You may feel a small amount of air
from the footwell air vents regardless
of the air distribution setting.

•

To reduce humidity build-up inside your
vehicle, do not drive with the system
switched off or with recirculated air
always switched on.

•

Do not place objects under the front
seats as this may interfere with the
airflow to the rear seats.

•

Remove any snow, ice or leaves from
the air intake area at the base of the
windshield.

•

To improve the time to reach a
comfortable temperature in hot
weather, drive with the windows open
until you feel cold air through the air
vents.

Automatic Climate Control

•

Adjusting the settings when your
vehicle interior is extremely hot or cold
is not necessary. Automatic mode is
best recommended to maintain set
temperature.

•

The system adjusts to heat or cool the
interior to the temperature you select
as quickly as possible.

•

For the system to function efficiently,
the instrument panel and side air vents
should be fully open.

•

If you press

AUTO

during cold outside

temperatures, the system directs air
flow to the windshield and side window
air vents.In addition, the blower motor
may run at a slower speed until the
engine warms up.

•

If you press

AUTO

during hot

temperatures and the inside of the
vehicle is hot, the system uses
recirculated air to maximize interior
cooling. Blower motor speed may also
reduce until the air cools.

Quickly Heating the Interior

Press

AUTO

2. Adjust the temperature function to the

setting you prefer.

Recommended Settings for
Heating

Press

AUTO

2. Adjust the temperature function to the

setting you prefer. Use 72°F (22°C) as
a starting point, then adjust the setting
as necessary.

Quickly Cooling the Interior

Press

MAX A/C

2. Drive with the windows open for a short

period of time.

Recommended Settings for
Cooling

Press

AUTO

2. Adjust the temperature function to the

setting you prefer. Use 72°F (22°C) as
a starting point, then adjust the setting
as necessary.

Defogging the Side Windows in
Cold Weather

Press and release defrost or maximum
defrost.

147

Climate Control

2. Adjust the temperature control to the

setting you prefer. Use 72°F (22°C) as
a starting point, then adjust the setting
as necessary.

148

Climate Control

IDENTIFYING THE REAR
PASSENGER CLIMATE
CONTROL UNIT - VEHICLES
WITH: MANUAL
TEMPERATURE CONTROL

E289989

Note:

Depending on your vehicle option

package, the controls may look different
from what you see here.

IDENTIFYING THE REAR
PASSENGER CLIMATE
CONTROL UNIT - VEHICLES
WITH: AUTOMATIC
TEMPERATURE CONTROL

E293083

Note:

Depending on your vehicle option

package, the controls could look different
from what you see here.

SWITCHING THE REAR
PASSENGER CLIMATE
CONTROLS ON AND OFF

Press and release the button.

SETTING THE BLOWER MOTOR
SPEED

E265389

Turn the control to adjust the volume of
air circulated in the rear passenger
compartment.

149

Rear Passenger Climate Control

SETTING THE TEMPERATURE

E265862

Turn the control to set the temperature in
the rear passenger compartment.

DIRECTING THE FLOW OF AIR

Directing Air to the Overhead Air
Vents

E244097

Press and release the button to
direct airflow to the overhead air
vents.

Directing Air to the Rear Footwell
Air Vents

Press and release the button to
direct airflow to rear footwell air
vents.

REAR AUTO MODE

SWITCHING REAR AUTO MODE
ON AND OFF - VEHICLES WITH:
AUTOMATIC TEMPERATURE
CONTROL

Press and release the button to
switch on rear automatic
operation, then set the

temperature.

REAR PASSENGER CLIMATE
CONTROL INDICATORS

When illuminated, you can only
operate the rear passenger
settings through the front

controls.

150

Rear Passenger Climate Control

WHAT IS THE CABIN AIR
FILTER

The cabin air filter improves the quality of
air in your vehicle by trapping dust, pollen
and other particles.

REPLACING THE CABIN AIR
FILTER

Replace the filter at regular intervals. See

Scheduled Maintenance

(page 525).

The cabin air filter is behind the glove
compartment.

To remove the lower glove compartment
and access the filter:

Open the glove compartment.

E311296

2. Press the tab on each side.

3. Fully lower the glove compartment.

4. Pull the glove compartment toward

you.

151

Interior Air Quality

Content .. 6 7 8 9 ..
