REMOVING THE KEY BLADE

E322866

Push the release button on your passive
key and pull the key blade out.

SOUNDING THE PANIC ALARM

E138624

Press the button to sound the
panic alarm. Press the button
again, or switch the ignition on

to turn it off.

Note:

The panic alarm only operates when

the ignition is off.

LOCATING YOUR VEHICLE

E138623

Press the lock button twice
within three seconds. The turn
signal lamps flash.

Note:

We recommend you use this method

to locate your vehicle.

CHANGING THE REMOTE
CONTROL BATTERY - POLICE
RESPONDER

WARNING:

Keep batteries away

from children to prevent ingestion.
Failure to follow this instruction could
result in personal injury or death. If
ingested, immediately seek medical
attention.

WARNING:

If the battery

compartment does not securely close,
stop using the remote control and
replace it as soon as possible. In the
meantime, keep the remote control away
from children. Failure to follow this
instruction could result in personal injury
or death.

The remote control uses one coin-type
three-volt lithium battery CR2032 or
equivalent.

E107998

Make sure you dispose of old
batteries in an environmentally
friendly way. Seek advice from

local authorities about recycling old
batteries.

Keys and Remote Controls

E203601

Twist a thin coin in the slot of the
remote control near the key ring to
remove the battery cover.

Note:

Do not remove the rubber cover and

circuit board from the front housing of the
remote control.

Note:

Do not wipe off any grease on the

battery terminals or on the back surface of
the circuit board.

2. Remove the old battery.

3. Insert the new battery. Refer to the

symbols inside the remote control for
the correct orientation of the battery.
Press the battery down to make sure
you have it fully seated in the housing.

4. Reinstall the battery housing cover

onto the remote control.

Note:

Replacing the battery does not erase

the programmed key from your vehicle. The
remote control operates normally.

CHANGING THE REMOTE
CONTROL BATTERY -
VEHICLES WITH: PUSH
BUTTON START

WARNING:

Keep batteries away

from children to prevent ingestion.
Failure to follow this instruction could
result in personal injury or death. If
ingested, immediately seek medical
attention.

WARNING:

If the battery

The remote control uses one coin-type
3-volt lithium battery CR2450 or
equivalent.

E322866

Keys and Remote Controls

Push the release button and pull the
key blade out.

E303824

2. Twist a thin coin under the tab hidden

behind the key blade head to remove
the battery cover.

E218402

3. Insert a screwdriver, and carefully

remove the battery.

4. Install a new battery with the

facing

upward.

5. Reinstall the battery housing cover

onto the transmitter and install the key
blade.

E107998

Dispose of old batteries in an
environmentally friendly way.
Seek advice from your local

authority about recycling old batteries.

Note:

Do not wipe off any grease on the

battery terminals or on the back surface of
the circuit board.

Note:

Replacing the battery does not erase

the programmed key from your vehicle. The
remote control should operate normally.

Keys and Remote Controls

CHANGING THE REMOTE
CONTROL BATTERY -
VEHICLES WITH: FLIP KEY

WARNING:

Keep batteries away

from children to prevent ingestion.
Failure to follow this instruction could
result in personal injury or death. If
ingested, immediately seek medical
attention.

WARNING:

If the battery

Battery Replacement Procedure

The remote control uses one coin-type
3-volt lithium battery CR2032 or
equivalent.

Press the button to release the key blade
before beginning the procedure.

E191533

Insert a screwdriver, in the position
shown and gently push the clip.

2. Press the clip down to release the

battery cover.

E151799

3. Carefully remove the cover.

E151800

4. Insert a screwdriver as shown to

release the battery.

E151801

Note:

Do not touch the battery contacts or

the printed circuit board with the
screwdriver.

5. Remove the battery.

Keys and Remote Controls

6. Install a new battery with the

facing

up.

Replace the battery cover.

E107998

Dispose of old batteries in an
environmentally friendly way.
Seek advice from your local

authority about recycling old batteries.

Note:

Do not wipe off any grease on the

battery terminals or on the back surface of
the circuit board.

Note:

Replacing the battery does not erase

the programmed key from your vehicle. The
remote control should operate normally.

REPLACING A LOST KEY OR
REMOTE CONTROL

You can purchase replacement keys or
remote controls from an authorized dealer.
Authorized dealers can program remote
controls for your vehicle.

E151795

Note:

Your vehicle keys came with a

security label that provides important key
cut information. Keep the label in a safe
place for future reference.

PROGRAMMING THE REMOTE
CONTROL - VEHICLES WITH:
PUSH BUTTON START

General Information

You must have two previously
programmed remote controls inside your
vehicle and the new unprogrammed
remote controls readily accessible. Contact
an authorized dealer to have the spare
remote control programmed if two
previously programmed remotes are not
available. Make sure that your vehicle is
off before beginning this procedure. Make
sure that you close all the doors before
beginning and that they remain closed
throughout the procedure. Perform all
steps within 30 seconds of starting the
sequence. Stop and wait for at least one
minute before starting again if you perform
any steps out of sequence.

Read and understand the entire procedure
before you begin.

Note:

You can program a maximum of four

remote controls to your vehicle.

Note:

If your programmed remote controls

are lost or stolen and you do not have an
extra coded remote, you need to have your
vehicle towed to an authorized dealer. Store
an extra programmed remote away from
your vehicle in a safe place to help prevent
any inconvenience. Contact an authorized
dealer to purchase additional spare or
replacement remotes.

Steps for Programming Your Spare
Remote Control

Note:

Your vehicle is equipped with one of

the following center consoles.

Keys and Remote Controls

Programming Backup Location

E312216

E269950

Place the first programmed remote in
the backup slot inside the cup holder
or center console with your foot off the
brake pedal, press and release the push
button ignition switch.

2. Wait five seconds and then press and

release the push button ignition switch
again.

3. Remove the remote control.

4. Within 10 seconds, place a second

programmed remote control in the
backup slot. Press and release the
push button ignition switch.

5. Wait five seconds and then press and

release the push button ignition switch
again. Keep the ignition on for at least
three seconds, but no more than 10
seconds.

6. Remove the remote control.

Place the unprogrammed remote
control in the backup slot and press
and release the push button ignition
switch.

Programming is now complete. With your
foot on the brake pedal, press the push
button ignition switch to verify the remote
control functions operate and your vehicle
starts with the new remote control.

If programming was not successful, wait
10 seconds and repeat Steps 1 through 7.
If you are still unsuccessful, take your
vehicle to an authorized dealer.

PROGRAMMING THE REMOTE
CONTROL - VEHICLES WITH:
FLIP KEY

General Information

You can program your own remote control
to your vehicle. This procedure programs
both the engine immobilizer keycode and
the remote entry portion of the remote
control to your vehicle.

Only use remote controls with an
integrated mechanical key.

You must have two previously
programmed coded remote controls and
the new un–programmed remote readily
accessible. Contact an authorized dealer
to have the spare remote control
programmed if the two previously
programmed coded remote controls are
not available.

Read and understand the entire procedure
before you begin.

Steps for Programming Your Spare
Remote Control

Insert the first previously programmed
coded key into the ignition.

Keys and Remote Controls

2. Switch the ignition from off to on. Keep

the ignition on for at least three
seconds, but no more than 10 seconds.

3. Switch the ignition off and remove the

first coded key from the ignition.

4. After three seconds but within 10

seconds of switching the ignition off,
insert the second previously coded key
into the ignition.

5. Switch the ignition from off to on. Keep

the ignition on for at least three
seconds, but no more than 10 seconds.

6. Switch the ignition off and remove the

second previously programmed coded
key from the ignition.

After three seconds but within 10
seconds of switching the ignition off
and removing the previously
programmed coded key, insert the new
un–programmed key into the ignition.

8. Switch the ignition from off to on. Keep

the ignition on for at least six seconds
until you hear the door locks cycle.

9. Remove the newly programmed coded

key from the ignition.

The key starts the engine if programming
is successful. You can operate the keyless
remote entry system with the new remote
control with integrated key.

If programming was not successful, wait
20 seconds and repeat Steps 1 through 8.
If you are still unsuccessful, take your
vehicle to an authorized dealer.

Note:

You can program a maximum of six

coded remote controls to your vehicle.

KEYS AND REMOTE CONTROLS – TROUBLESHOOTING

KEYS AND REMOTE CONTROLS – INFORMATION MESSAGES

Action

Message

Replace remote control battery.

Key Battery Low Replace
Soon

Keys and Remote Controls

WHAT IS MYKEY

MyKey allows you to program keys with
restricted driving modes to promote good
driving habits.

MYKEY SETTINGS

NON-CONFIGURABLE MYKEY
SETTINGS

Seatbelt Reminder or Belt-
Minder™

MyKey mutes the audio system until the
front seat passengers buckle the front seat
belts.

Note:

If your vehicle includes an AM/FM

radio or a very basic audio system, then the
radio may not mute.

Satellite Radio

(If Equipped)

Some Satellite radio channels have
restricted access to adult radio content.

Early Low Fuel

The low fuel level warning lamp turns on
earlier.

Driving and Parking Aids

You cannot configure settings for parking
aids, blind spot information system, and
cross traffic alert. These systems turn on
when the vehicle turns on, and you cannot
switch them off with a MyKey.

You cannot configure settings for
pre-collision assist and lane keeping. These
systems turn on when the vehicle turns on,
but you can switch them off with a MyKey.

A new destination in the navigation system
can only be set using voice commands
when using a MyKey, and with your vehicle
moving.

Note:

MyKey drivers may be able to switch

the lane departure warning feature off, but
this feature turns back on automatically
with every new key cycle.

CONFIGURABLE MYKEY
SETTINGS

You can configure the following settings
after creating a MyKey. See

Creating a

MyKey

(page 98).

Speed Limit

WARNING:

Do not set MyKey

maximum speed limit to a limit that will
prevent the driver from maintaining a
safe speed considering posted speed
limits and prevailing road conditions. The
driver is always responsible to drive in
accordance with local laws and
prevailing conditions. Failure to do so
could result in accident or injury.

You can set a speed limit for your vehicle.
Warning messages appear in the
information display and a tone sounds if
your vehicle reaches the set speed. You
cannot override the set speed when using
a MyKey.

Speed Minder

You can set a speed reminder for your
vehicle. Warning messages appear in the
information display and a tone sounds if
your vehicle exceeds the set speed.

Audio System Volume Limit

The audio system maximum volume
reduces. A message appears in the
information display if you attempt to
exceed the volume limit. Automatic
volume control turns off.

MyKey™

(If Equipped)

Emergency Assistance

If you set emergency assistance to always
on, you cannot switch it off with a MyKey.

Do Not Disturb

If you set do not disturb to always on, you
cannot switch it off with a MyKey.

Note:

If a phone is connected using Apple

CarPlay or Android Auto while driving with
a MyKey, the driver can receive phone calls
and text messages even if the do not disturb
restriction is on, and if the vehicle comes
with satellite radio, there is no restriction on
the adult content.

Traction and Stability Control

If you set traction control or stability
control to always on, you cannot switch it
off with a MyKey.

CREATING A MYKEY -
VEHICLES WITH: PUSH
BUTTON START

Vehicles with a center console shifter:

E312216

Remove the mat from the center
console cup holder.

2. Remove the key blade from the

transmitter.

3. Place the remote control in the backup

slot with the buttons facing toward the
front of the vehicle.

4. Switch the ignition on using an admin

key.

5. Press

Settings

on the touchscreen.

6. Press

Vehicle Settings

Press

MyKey

8. Press

Create MyKey

9. Press

Yes

Note:

After you confirm the creation of a

MyKey, we recommend that you label this
key.

Vehicles with a column shifter.

E269950

Raise the front center seat storage lid.

2. Place the remote control in the backup

slot with the buttons facing toward the
front of the vehicle.

3. Switch the ignition on using an admin

key.

4. Press

Settings

on the touchscreen.

5. Press

Vehicle Settings

6. Press

MyKey

Press

Create MyKey

8. Press

Yes

Note:

After you confirm the creation of a

MyKey, we recommend that you label this
key.

MyKey™

(If Equipped)

CREATING A MYKEY -
VEHICLES WITH: FLIP KEY

Switch the ignition on using an admin
key.

2. Press

Settings

on the touchscreen.

3. Press

Vehicle Settings

4. Press

MyKey

5. Press

Create MyKey

6. Press

Yes

Note:

After you confirm the creation of a

MyKey, we recommend that you label this
key.

PROGRAMMING A MYKEY

You can program any remote control to
become a restricted MyKey, but you must
leave one unmodified as an admin key.

Switch the ignition on using an admin
key.

2. Press

Settings

on the touchscreen.

3. Press

Vehicle Settings

4. Press

MyKey

5. Select a setting and press the

button.

6. Configure the setting

CLEARING ALL MYKEYS

When you clear all MyKeys, you remove all
restrictions and return all MyKeys to their
original admin key status.

Switch the ignition on using an admin
key.

2. Press

Settings

on the touchscreen.

3. Press

Vehicle Settings

4. Press

MyKey

5. Press

Clear All MyKeys

6. Press

Yes

CHECKING MYKEY SYSTEM
STATUS

You can find information about the
distance traveled using a MyKey, and the
number of admin keys and MyKeys created
for your vehicle.

Switch the ignition on.

2. Press

Settings

on the touchscreen.

3. Press

Vehicle Settings

4. Press

MyKey

5. Press

MyKey Information

USING MYKEY WITH REMOTE
START SYSTEMS

(IF EQUIPPED)

MyKey is not compatible with unapproved,
aftermarket remote start systems. If you
choose to install a remote start system,
see an authorized dealer for an approved
remote start system.

MyKey™

(If Equipped)

MYKEY – TROUBLESHOOTING

MYKEY – INFORMATION MESSAGES - VEHICLES WITH: PUSH BUTTON
START

Description

Message

Displays when trying to create a MyKey and the admin key is
not placed in the backup position. See

Creating a MyKey

(page 97).

Place Key in Backup
Location

Displays when trying to create a MyKey with a key already
designated as a MyKey.

Key is Already a MyKey

Displays to confirm that the key is restricted after you switch
the ignition off.

This Key restricted at
Next Key Cycle. Label
Key as MyKey

MyKey™

(If Equipped)

MYKEY – FREQUENTLY ASKED
QUESTIONS - VEHICLES WITH:
PUSH BUTTON START

What is an admin key?

An admin key is a key that you have
not created as a MyKey. See

Creating

a MyKey

(page 97).

Why am I not able to create a MyKey?

You have not placed the admin key in
the backup position. See

Creating a

MyKey

(page 97). The key used to

switch the ignition on is not an admin
key. The key used to switch the ignition
on is the only admin key. There has to
be at least one admin key. You did not
switch the ignition off after creating
the last MyKey.

Why am I not able to program a MyKey?

The admin key is not inside your
vehicle. The key used to switch the
ignition on is not an admin key. You
have not created any MyKeys. See

Creating a MyKey

(page 97).

Why am I not able to clear the MyKeys?

The admin key is not inside your
vehicle. The key used to switch the
ignition on is not an admin key. You
have not created any MyKeys. See

Creating a MyKey

(page 97).

Why is the MyKey distance not
accumulating?

The key used to start the engine is an
admin key. An admin key and a MyKey
are inside your vehicle. You have not
created any MyKeys. See

Creating a

MyKey

(page 97). You have cleared

the MyKeys. See

Clearing All

MyKeys

(page 98).

Why am I not able to start the engine
with a MyKey?

An admin key and a MyKey are inside
your vehicle. The system recognizes
only the admin key when both are
present.

MYKEY – FREQUENTLY ASKED
QUESTIONS - VEHICLES WITH:
FLIP KEY

What is an admin key?

An admin key is a key that you have
not created as a MyKey. See

Creating

a MyKey

(page 98).

Why am I not able to create a MyKey?

The key used to switch the ignition on
is not an admin key. The key used to
switch the ignition on is the only admin
key. There has to be at least one admin
key.

Why am I not able to program a MyKey?

The key used to switch the ignition on
is not an admin key. You have not
created any MyKeys. See

Creating a

MyKey

(page 98).

Why am I not able to clear the MyKeys?

The key used to switch the ignition on
is not an admin key. You have not
created any MyKeys. See

Creating a

MyKey

(page 98).

Why is the MyKey distance not
accumulating?

The key used to start the engine is an
admin key. You have not created any
MyKeys. See

Creating a MyKey

(page 98). You have cleared the
MyKeys. See

Clearing All MyKeys

(page 98).

101

MyKey™

(If Equipped)

OPERATING THE DOORS
FROM OUTSIDE YOUR
VEHICLE

UNLOCKING AND LOCKING THE
DOORS USING THE REMOTE
CONTROL

(If Equipped)

You can only use the remote control when
your vehicle is stationary.

Unlocking the Doors

E267112

Press the button to unlock all
doors.

Locking the Doors

E267111

Press the button to lock all
doors. One short flash of the
turn signal lamps confirms that

your vehicle has locked.

Note:

For more information on operating

the doors from outside your vehicle

UNLOCKING AND LOCKING THE
DOORS USING THE KEY BLADE

If there is a power door lock fault you can
use the key blade to lock and unlock the
doors.

E333745

Lock.

Unlock.

OPERATING THE DOORS
FROM INSIDE YOUR VEHICLE

INDIVIDUALLY UNLOCKING AND
LOCKING THE DOORS USING THE
LOCKING BUTTON

The power door lock control is on the driver
and front passenger door panels.

E138628

Unlock.

Lock.

102

Doors and Locks

OPENING THE DOORS FROM
INSIDE YOUR VEHICLE - CREW
CAB

Pull the interior door handle twice to
unlock and open a rear door. The first pull
unlocks the door and the second pull
opens the door.

AUTOUNLOCK

(IF EQUIPPED)

WHAT IS AUTOUNLOCK

Autounlock is an unlocking feature that
unlocks the vehicle doors when your
vehicle comes to a stop.

AUTOUNLOCK REQUIREMENTS

Autounlock unlocks all the doors when all
of the following occur:
•

The ignition is on, all the doors are
closed and your vehicle is moving at a
speed greater than 12 mph (20 km/h).

•

Your vehicle comes to a stop.

•

You open the driver door within 10
minutes of switching the ignition off or
to the accessory position.

SWITCHING AUTOUNLOCK ON
AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Switch

Autounlock

on or off.

AUTOLOCK

(IF EQUIPPED)

WHAT IS AUTOLOCK

Autolock is a locking feature that locks
your vehicle doors when you start driving.

AUTOLOCK REQUIREMENTS

Autolock locks all the doors when all of the
following occur:
•

All doors are closed.

•

The ignition is on.

•

Your vehicle reaches a speed greater
than 12 mph (20 km/h).

MISLOCK

(IF EQUIPPED)

WHAT IS MISLOCK

Mislock is a locking feature that warns you
if your vehicle has not locked.

MISLOCK LIMITATIONS

When you press the lock button once, the
turn signals do not flash if:
•

Any door or the tailgate is open.

•

The hood is open.

If you switch mislock off, the horn does not
sound if you press the lock button on the
remote control when a door is open.

SWITCHING MISLOCK ON AND
OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Switch

Mislock Chirp

on or off.

DOORS AND LOCKS AUDIBLE
WARNINGS

Door Ajar Audible Warning

Sounds when a door is not fully closed and
your vehicle is moving.

103

Doors and Locks

DOORS AND LOCKS –
TROUBLESHOOTING

DOORS AND LOCKS – WARNING
LAMPS

Door Ajar Warning Lamp

E249859

It illuminates when you switch
the ignition on and remains on if
any door or the hood is open.

DOORS AND LOCKS – INFORMATION MESSAGES

Action

Message

Displays if a door is open. Fully close the door.

Driver Door Ajar

Passenger Door Ajar

Rear Left Door Ajar

Rear Right Door Ajar

104

Doors and Locks

Ford F-150 (2022 year). Manual in english - page 5
