Ford Ranger (2022 year). Manual in english

Description

Voice Command

Go to the next page.

Go to the previous page.

Add the name of the feature to the command.

Entertainment

Audio Source

Description

Voice Command

Use the radio.

Radio

Use the CD player.

CD Player

Use a

Bluetooth®

device.

Bluetooth Stereo

Use a USB or media player.

USB

Radio

Description

Voice Command

Listen to AM radio.

Tune to a specific AM frequency.

AM ___

Listen to SiriusXM radio.

Sirius Channel ___

Listen to FM radio.

Tune to a specific FM frequency.

FM ___

Add the radio frequency to two decimal places to the command.

You can say the Sirius channel name or number such as "Sirius Channel 16" or "Sirius

The Pulse".

375

SYNC™ 3

(If Equipped)

USB and Media Player

Description

Voice Command

Play your music by category.

Play Album ___

Play Artist ___

Play Genre ___

Play Playlist ___

Play Song ___

Play Audiobook ___

Play Podcast ___

Browse music on a USB device.

Browse All Albums

Browse All Artists

Browse All Audiobooks

Browse All Genres

Browse All Playlists

Browse All Podcasts

Browse All Songs

Browse your music by category on a USB device.

Browse Album ___

Browse Artist ___

Browse Audiobook ___

Browse Genre ___

Browse Playlist ___

Browse Podcast ___

Add an album name, artist name, audiobook name, genre name, playlist name, podcast

name or track name to the command. Say the name exactly as it appears on your device.

Climate

(If Equipped)

You can control the temperature of the
vehicle using voice commands.

___ is a dynamic listing, meaning that for
climate voice commands it can be the
desired degrees for the temperature
setting.

376

SYNC™ 3

(If Equipped)

To adjust the temperature, say:

Description

Voice command

Adjust the temperature between 60–85°F

(15.5–29.5°C).

Set Temperature ___

Phone

Description

Voice Command

Pair a cell phone or

Bluetooth®

-enabled device.

Pair Phone

Redial the last number that you dialed.

Redial

Dial a number.

Dial ___

Call a specific contact from your phonebook.

Call ___

Call a specific contact from your phonebook at a

specific location.

Call ___ ___

Listen to a text message.

Listen to Message

Listen to a specific text message from a list of text
messages.

Listen to Message ___

Reply to the last text message.

Reply to Message

Add the number you want to dial to the command.

Add a contact name from your phonebook to the command. Say the first and last name

of your contact exactly as it appears on your device.

Add a contact name and location from your phonebook to the command. Say the first

and last name of your contact exactly as it appears on your device.

377

SYNC™ 3

(If Equipped)

Navigation

(If Equipped)

Setting a Destination

Description

Voice Command

Enter a destination address. When prompted,
provide the house number, the street and city.

Find an Address

Search for a point of interest by name or by category.

Find a Place

Search for a nearby point of interest by category.

Find the Next ___

Search for a point of interest category.

Find a POI Category

Set your saved home address as your destination.

Drive Home

Set your saved place of work as your destination.

Drive to Work

Display and select from a list of previous destina-
tions.

Show Previous Destinations

Display and select from a list of favorite destinations.

Show Favorites

Add a point of interest category or the name of a major brand or chain to the command.

Route Guidance

Description

Voice Command

Cancel the current route.

Cancel Route

Select an alternate route.

Detour

Repeat the last guidance prompt.

Repeat Instruction

Display an overview of the route.

Show Route

Display a list of traffic events on your route.

Show Traffic

Display the map on the touchscreen.

Show Map

Display a two-dimensional map with north toward
the top of the touchscreen.

North Up

Display a two-dimensional map with the direction
you are traveling toward the top of the touchscreen.

Heading Up

Display a three-dimensional map with the direction
you are traveling toward the front.

Show 3D

378

SYNC™ 3

(If Equipped)

Apps

General

Description

Voice Command

Start an app. The system prompts you for the app
name.

Mobile Applications

Get a list of apps running on your device.

List Applications

Search and connect to apps running on your device.

Find Applications

Active App

Description

Voice Command

Get a list of voice commands for a specific app.

___ Help

Close an app.

Exit ___

Add an app name to the command.

SiriusXM Traffic and Travel Link

(If Equipped)

Description

Voice

command

Displays a list of traffic incidents.

Show
Traffic

Displays the current weather map.

Show
Weather
Map

Displays a list of fuel prices.

Show Fuel
Prices

Displays the 5 day weather forecast.

Show 5
Day Fore-
cast

379

SYNC™ 3

(If Equipped)

Voice Settings

Description

Voice Command

Go to the voice settings menu.

Voice Settings

Switch long voice prompts on.

Interaction Mode Novice

Switch short voice prompts on.

Interaction Mode Advanced

Switch call confirmation on. The system prompts
you to confirm before making a call.

Phone Confirmation On

Switch call confirmation off. The system does not
prompt you to confirm before making a call.

Phone Confirmation Off

Switch the display of voice commands on.

Voice Command Lists On

Switch the display of voice commands off.

Voice Command Lists Off

Automatic Blower Motor Speed
Reduction

If necessary, the system decreases the
blower motor speed when you are using
voice commands to reduce the amount of
background noise in your vehicle. It returns
to normal when you are done.

Switching Automatic Blower Motor
Speed Reduction Off

Simultaneously press the

A/C

and

recirculated air buttons.

ENTERTAINMENT

Select the entertainment option
on the feature bar.

E293491

Audio source. Select to choose
a different audio source.

Presets. Swipe left to view more
presets.

You can access these options using the
touchscreen or voice commands.

380

SYNC™ 3

(If Equipped)

Using the Radio

Setting a Radio Station Using the
Touchscreen

Directly Tuning a Radio Station

Select

Sources

Select

Frequency

Enter the frequency of the radio station
and select

Enter

Note:

You must enter the frequency to two

decimal places.

Selecting a Radio Station From a List

Select

Sources

Select

DAB

Select

Station

Select a radio station from the list.

Switching Traffic Announcements On

Select

Traffic (TA)

Note:

If you switch traffic announcements

on, traffic announcements broadcast by
radio stations interrupt the current audio
source to help you plan your route.

Storing a Radio Station

You can use the different sets of presets
to allow different drivers to store their
favorite radio stations.

Set a radio station.

Select

Presets

Note:

Only do this if you wish to select a

different set of presets.

Press and hold one of the preset buttons.

Note:

The radio briefly mutes to indicate

the radio station has been stored.

Streaming Music From a

Bluetooth®

Device.

Check the compatibility of your device on
the regional Ford website.

Pair your device. See

Phone

(page 385).

Select

Sources

Select

Bluetooth®

Searching for Tracks on

Bluetooth®

Device.

Select

Browse

Select a track.

Note:

Select the cover art to view

information about the current track.

Repeating Tracks on

Bluetooth®

Device.

Select the repeat icon to repeat
tracks.

Note:

You can repeat one track or all tracks

on an audio format

Bluetooth®

Device.

You can repeat one track, all tracks or all
tracks in one folder on a

Bluetooth®

Device.

Note:

A small number one appears next to

the repeat icon to indicate that a track is set
to repeat. A small folder icon appears next
to it to indicate that a folder is set to repeat

Playing Tracks on

Bluetooth®

Device

in a Random Order.

Select to play tracks in a random
order.

Playing Music From a USB or Media
Player

Connect your device to a USB port.

Select

Sources

381

SYNC™ 3

(If Equipped)

Select USB.

Note:

The system indexes your music

before you can play it.

Searching for Tracks on a USB or Media
Player

Select

Browse

Select a track.

Note:

Select the cover art to view

information about the current track.

Note:

You can also browse by album, artist,

audiobook, genre, playlist, podcast or track
name.

Repeating Tracks on a USB or Media
Player

Select the repeat icon to repeat
tracks.

Note:

You can repeat one track or all tracks

on an audio format USB or media player.
You can repeat one track, all tracks or all
tracks in one folder on a USB or media
player.

Note:

A small number one appears next to

the repeat icon to indicate that a track is set
to repeat. A small folder icon appears next
to it to indicate that a folder is set to repeat

Supported Devices

The system supports most USB and media
players, including iOS and Android devices.

Supported File Formats

The system supports the following file
formats:
•

MP3, MP4, WMA, WAV, AAC, AIFF, APE,
DSD, and FLAC audio file formats.

•

MP3, WMA, WAV, M4A, M4B, AAC, and
FLAC file extensions.

•

FAT, exFAT, and NTFS file systems.

Audio File Metadata

The system organizes files on your USB or
media player by metadata tags. Metadata
tags contain information about the file. If
the metadata tags for the files on your USB
or media player contain no information,
the system classifies them as unknown.
The system can index up to 50000 tracks
on a USB device or media player, and up
to 10 devices.

CLIMATE

Touch the climate button on the
touchscreen to access the climate control
features.

Note:

You can switch temperature units

between Fahrenheit and Celsius. See

Settings

(page 393).

Accessing the Climate Control
Menu

E265038

Touch the button to access
additional controls for the front
climate system.

Directing the Airflow

Touch the button to direct
airflow to the windshield air
vents and de-mister.

E244097

Touch the button to direct
airflow to the instrument panel
air vents.

Touch the button to direct
airflow to the footwell air vents.

You can direct air through any combination
of these air vents.

382

SYNC™ 3

(If Equipped)

Setting the Blower Motor Speed

Touch up or down to increase or
decrease the volume of air that
circulates in your vehicle.

Setting the Temperature

Touch up or down on the left-hand
temperature control to set the left-hand
temperature.

Note:

This control also adjusts the

right-hand side temperature when you
switch off dual zone mode.

Touch up or down on the right-hand
temperature control to set the right-hand
temperature.

Switching Auto Mode On and Off

Touch the button to switch on
automatic operation, then set
the temperature.

The system adjusts the blower motor
speed, air distribution, air conditioning
operation, and outside or recirculated air
to reach and maintain the temperature you
have set.

Switching the Air Conditioning On
and Off

A pop-up appears on the screen
to display the air conditioning
options.

MAX A/C:

Touch the button to activate

and maximize cooling. The driver and
passenger temperatures are set to LO,
recirculated air flows through the
instrument panel vents, air conditioning
automatically turns on and the fan
automatically adjusts to the highest speed.

A/C:

Touch to switch the air conditioning

on or off. Use A/C with recirculated air to
improve cooling performance and
efficiency.

Note:

In certain conditions, such as

maximum defrost, the air conditioning
compressor may continue to operate even
though you switch off the air conditioning.

Switching the Climate Control On
and Off

Touch the button.

Switching the Climate Controlled
Seats On and Off

E265282

Touch the button to cycle
through the various climate
controlled seat settings.

Switching Dual Zone Mode On and
Off

E265280

Touch the button to switch on
temperature control for the
right-hand side of the vehicle.

Switching the Heated Exterior
Mirrors On and Off

E266189

Touch the button.

Switching the Heated Windshield
On and Off

Touch the button to clear the
windshield of thin ice and fog.
The heated windshield turns off

after a short period of time.

Switching the Heated Rear
Window On and Off

E184884

Touch the button to clear the
rear window of thin ice and fog.

383

SYNC™ 3

(If Equipped)

Switching the Heated Seats On
and Off

Touch the button to cycle
through the various heat
settings.

Switching the Heated Steering
Wheel On and Off

Touch the button.

Switching Maximum Air
Conditioning On and Off

Touch the button for maximum
cooling.

Recirculated air flows through the
instrument panel air vents, air conditioning
turns on and the blower motor adjusts to
the highest speed.

Switching Maximum Defrost On
and Off

Touch the button for maximum
defrosting.

Air flows through the windshield air vents,
and the blower motor adjusts to the
highest speed.

You can also use this setting to defog and
clear the windshield of a thin covering of
ice.

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Note:

The heated rear window also turns

on when you select maximum defrost.

Note:

Depending on your region, air

conditioning turns on.

Switching Recirculated Air On and
Off

Touch the button to switch
between outside air and
recirculated air.

The air currently in the passenger
compartment recirculates. This may
reduce the time needed to cool the interior,
when used with

A/C

, and reduce unwanted

odors from entering your vehicle.

Note:

Recirculated air may turn off, or

prevent you from switching on, in all air flow
modes except

MAX A/C

to reduce the risk

of fogging. Recirculation may also turn on
and off in various air distribution control
combinations during hot weather to improve
cooling efficiency.

Switching the Ventilated Seats On
and Off

E268558

Touch the button to cycle
through the various ventilated
seat settings.

Accessing Rear Climate Controls

E270447

Touch the button to access
additional controls for the rear
climate system.

Rear Climate Control Lock
Indicator

E265289

Touch the button.

When on, you can only operate
the rear passenger settings

through the front controls.

Switching Rear Auto Mode On and
Off

Touch the button to switch on
rear automatic operation, then
set the temperature.

384

SYNC™ 3

(If Equipped)

Switching the Rear Climate
Controlled Seats On and Off

E265282

Touch the button to cycle
through the various climate
controlled seat settings.

Switching the Rear Heated Seats
On and Off

Touch the button to cycle
through the various heat
settings.

Switching the Rear Ventilated
Seats On and Off

E268558

Touch the button to cycle
through the various ventilated
seat settings.

PHONE

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

Check the compatibility of your device on
the regional website.

Pairing Your Cell Phone for the
First Time

Go to the settings menu on your device and
switch

Bluetooth®

on.

Select the phone option on the
feature bar.

Select

Add Phone

Note:

A prompt alerts you to search for your

vehicle on your cell phone.

2. Select your vehicle on your cell phone.

Note:

A number appears on your cell phone

and on the touchscreen.

3. Confirm that the number on your cell

phone matches the number on the
touchscreen.

Note:

The touchscreen indicates that you

have successfully paired your cell phone.

4. Download the phonebook from your

cell phone when you are prompted.

Note:

If you pair more than one cell phone,

use the phone settings to specify the
primary phone. You can change this setting
at any time.

Using Your Cell Phone

(If Equipped)

Recent Call List

Display and select an entry from a list of
previous calls.

Contacts

Display a smart search form to look up your
contacts. Use the List button to
alphabetically sort your contacts.

Change Phone

Display the list of paired or connected
devices that you can select.

Phone Settings

Change ring tones, alerts or pair another
phone.

Do Not Disturb

Reject incoming calls and switch ring tones
and alerts off.

385

SYNC™ 3

(If Equipped)

Phone Keypad

Directly dial a number.

Mute

Mute the microphone when in a call.

Phone Voice Assistant

Say a command to use the Google or Siri
voice assistant available on your
connected phone to access supported
features.

Text Messaging

Setting Text Message Notification

iOS

Go to the settings menu on your cell
phone.

2. Select

Bluetooth®

3. Select the information icon to the right

of your vehicle.

4. Switch text message notification on.

Android

Go to the settings menu on your cell
phone.

2. Select

Bluetooth®

3. Select the profiles option.

4. Select the phone profile.

5. Switch text message notification on.

Using Text Messaging

Description

Menu Item

Hear the text message.

Hear It

View the text message.

View

Call the sender.

Call

Reply to the text message with a standard text message.

Apple CarPlay

(If Equipped)

Connect your device to a USB port.

2. Follow the instructions on the

touchscreen.

Note:

Certain features of the system are

not available when you are using Apple
CarPlay.

Switching Apple CarPlay Off

Select the settings option on the
feature bar.

Select

Apple CarPlay Preferences

2. Switch

Apple CarPlay

off.

Android Auto

(If Equipped)

Connect your device to a USB port.

2. Follow the instructions on the

touchscreen.

Note:

You might need to enable Android

Auto from the settings menu.

Note:

Certain features of the system are

not available when you are using Android
Auto.

386

SYNC™ 3

(If Equipped)

Switching Android Auto Off

Select the settings option on the
feature bar.

Select

Android Auto

2. Switch

Android Auto

off.

NAVIGATION

(IF EQUIPPED)

Note:

For more information, refer to our

website.

Select the navigation option on
the feature bar.

E297557

Map view menu.

Zoom out.

Zoom in.

Route guidance menu.

Destination entry menu.

Setting a Destination

Destination Entry Menu

Description

Item

Enter a destination address.

Display and select from a list of previous destinations.

Previous Destinations

Set your saved home address as your destination

Home

Set your saved place of work as your destination.

Work

Display and select from a list of favorite destinations.

Favorites

387

SYNC™ 3

(If Equipped)

Setting a Destination Using the Text
Entry Screen

E297558

Text entry field.

Automatic suggestions based on
the text you enter.

Information icon.

Search.

Keyboard settings.

Note:

Select one of the suggestions to

copy the detail to the text entry field.

You can search by entering all or part of
the destination, such as the Address, POI
Category or Name, Intersection, City,
Latitude/Longitude, etc. Tips: If you do
not specify a location, the system will
use the current vehicle location. You can
specify a location by address, city, state
or zip code. For additional search support,
please visit: support.ford.com.

Note:

Press the button in the top right-hand

corner of the main map to display estimated
time of arrival, remaining travel time or
distance to destination.

Setting a Destination Using the Map
Screen

E297559

Re-center the map.

Selected location.

3D map rotation. Swipe left or
right.

Start route guidance.

Destination name.

Select the location on the map.

Select

Start

to begin route guidance.

Changing the Format of the Map

Display the map in one of the following
formats:
•

A two-dimensional map with the
direction you are traveling toward the
top of the screen.

•

A two-dimensional map with north
toward the top of the screen.

•

A three-dimensional map with the
direction you are traveling toward the
front.

Zoom

Display more or less detail on the map.

388

SYNC™ 3

(If Equipped)

Note:

You can use pinch gestures to zoom

in and out. Place two fingers on the screen
and move them apart to zoom in. Place two
fingers on the screen and bring them
together to zoom out.

Route Guidance

E297560

Turn indicator. Select to hear the
last voice prompt.

Point of interest.

Estimated time of arrival,
distance to destination or time
to destination.

Current road.

Mute guidance prompts.

Cancel route guidance.

Note:

To change guidance prompt volume,

turn the volume control when a guidance
prompt plays.

Route Guidance Menu

Description

Menu Item

Adjust your map preferences for when route guidance is active.

Screen View

View a full screen map when route guidance is active.

Full Map

View highway exit information for your current route.

Highway Exit Info

View the turn list for your current route. Select a road to avoid
it.

Turn List

You can find the SiriusXM Traffic and Travel Link information
by pressing this button. This information requires an active
subscription to SiriusXM Traffic and Travel Link. When a route
is not active, a list of nearby traffic incidents displays. When a
route is active, you can choose to display a list of traffic nearby
or on the route.

Traffic List

389

SYNC™ 3

(If Equipped)

Description

Menu Item

Adjust navigation settings. See

Settings

(page 393).

Navigation Settings

View information about your current location.

Where Am I?

Cancel route guidance.

Cancel Route

View the entire current route on the map.

View Route

View an alternative route compared to your current one.

Detour

Change the order or remove waypoints.

Edit Waypoints

The system determines the order of waypoints for you.

Optimize Order

Go to the next screen and start the new route.

Adjusting the Guidance Prompt
Volume

Turn the volume control when a guidance
prompt plays to adjust the volume.

Note:

If you have inadvertently adjusted

the volume to zero, press the turn indicator
button to play the last voice prompt and
then adjust the volume to the desired level.

Muting Guidance Prompts

Select the mute option on the
screen to mute guidance
prompts.

Note:

The system mutes the next and all

future guidance prompts.

Adding Waypoints

You can add a waypoint to a navigation
route as a destination along your route.
You can add up to five waypoints.

Select the search option on the map.

2. Set a destination.

3. Select

Add Waypoint

4. Select

Canceling Route Guidance

Select the route guidance menu
option on the active guidance
screen.

Select

Cancel Route

E294817

Note:

The route guidance menu option is

always in the bottom right-hand corner of
the main map.

cityseeker

(If Equipped)

Note:

cityseeker point of interest (POI)

information is limited to approximately 1,110
cities (1,049 in the United States, 36 in
Canada and 15 in Mexico).

390

SYNC™ 3

(If Equipped)

Ford Ranger (2022 year). Manual in english - page 24
