VEHICLE IDENTIFICATION
NUMBER

The vehicle identification number is
located on the left-hand side of the
instrument panel.

E142476

Please note that in the graphic, XXXX is
representative of your vehicle identification
number.

The Vehicle Identification Number contains
the following information:

E142477

World manufacturer identifier

Brake system, Gross Vehicle
Weight Rating, Restraint Devices
and their locations

Make, vehicle line, series, body
type

Engine type

Check digit

Model year

Assembly plant

Production sequence number

CAPACITIES AND
SPECIFICATIONS - 2.3L
ECOBOOST™

Use oil and fluid that meets the defined
specification and viscosity grade.

If you do not use oil and fluid that meets
the defined specification and viscosity
grade, it could result in:
•

Component damage not covered by
the vehicle warranty.

•

Longer engine cranking periods.

•

Increased emission levels.

•

Reduced engine performance.

346

Capacities and Specifications

•

Reduced fuel economy.

•

Reduced brake performance.

Air Conditioning System

WARNING:

The air conditioning

refrigerant system contains refrigerant
under high pressure. Only qualified
personnel should service the air
conditioning refrigerant system. Opening
the air conditioning refrigerant system
can cause personal injury.

Capacities

Refrigerant Oil

Refrigerant

Variant

3.38 fl oz (100 ml)

19 oz (0.539 kg)

All.

Materials

Specification

Name

WSS-M17B21-A

R-1234yf Refrigerant(U.S.)
R-1234yf Refrigerant / Frigorigène R-1234yf(Canada)
YN-33-A(U.S.)
HS7Z-19B519-BA(Canada)

WSS-M2C300-A2

Motorcraft® R-1234yf Refrigerant PAG Oil(U.S.)
Motorcraft® R-1234yf Refrigerant PAG Oil / Huile
PAG pour frigorigène R-1234yf Motorcraft®(Canada)
YN-35(U.S. & Canada)

Manual Transmission

Capacities

Quantity

Variant

2.7 qt (2.6 L)

All.

347

Capacities and Specifications

Materials

Specification

Name

WSS-M2C200-D2

Motorcraft® Dual Clutch Transmission Fluid(U.S.)
Motorcraft® Dual Clutch Transmission Fluid / Huile
pour boîtes embrayage double Motor-
craft®(Canada)
XT-11-QDC(U.S. & Canada)

Engine Coolant

Capacities

Quantity

Variant

9.5 qt (8.96 L)

All.

Materials

Specification

Name

WSS-M97B57-A2

Motorcraft® Yellow Prediluted Antifreeze/
Coolant(U.S.)
Motorcraft® Yellow Prediluted Antifreeze/Coolant
/ Antigel/liquide de refroidissement prédilué jaune
Motorcraft®(Canada)
VC-13DL-G(U.S.)
CVC-13DL-G(Canada)

Engine Oil 2.3L EcoBoost Base

E142732

An oil that displays this symbol conforms
to current engine, emission system and
fuel economy performance standards of
ILSAC.

We recommend Motorcraft® motor oil for
your vehicle. If Motorcraft® oil is not
available, use motor oils of the
recommended viscosity grade that display
the API Certification Mark for gasoline
engines.

Do not use supplemental engine oil
additives because they are unnecessary
and could lead to engine damage not
covered by your vehicle warranty.

348

Capacities and Specifications

Capacities

Including the Oil Filter

Variant

6.0 qt (5.67 L)

All.

Materials

Specification

Name

WSS-M2C961-A1

Motorcraft® SAE 5W-30 Synthetic Blend Motor
Oil(U.S.)
Motorcraft® SAE 5W-30 Super Premium Motor Oil
/ Huile moteur de très haute qualité SAE 5W-30
Motorcraft®(Canada)
XO-5W30-Q1SP(U.S.)
CXO-5W30-LSP6(Canada)

Motor oil for track use:

Materials

Specification

Name

WSS-M2C931-C

Motorcraft® SAE 5W-50 Full Synthetic Motor
Oil(U.S.)
Motorcraft® SAE 5W-50 Full Synthetic Motor Oil /
Huile moteur synthétique SAE 5W-50 Motor-
craft®(Canada)
XO-5W50-QGT(U.S. & Canada)

Note:

Oil must meet specification

WSS-M2C931-C or use SAE 5W-50 oil that
meets API SN requirements.

Alternative Engine Oil for
Extremely Cold Climates

To improve engine cold start performance,
we recommend that you use the following
alternative engine oil in extremely cold
climates, where the ambient temperature
reaches -22.0°F (-30°C) or below.

Materials

Specification

Name

WSS-M2C963-A1

Engine Oil - SAE 0W-30 - Synthetic Blend

349

Capacities and Specifications

E240523

Engine Oil 2.3L EcoBoost High
Output

E300448

An oil that displays this symbol conforms
to current engine, emission system and
fuel economy performance standards of
ILSAC.

We recommend Motorcraft® motor oil for
your vehicle. If Motorcraft® oil is not
available, use motor oils of the
recommended viscosity grade that meets
API SN requirements.

Do not use supplemental engine oil
additives because they are unnecessary
and could lead to engine damage not
covered by your vehicle warranty.

Capacities

Including the Oil Filter

Variant

6.0 qt (5.67 L)

All.

350

Capacities and Specifications

Materials

Specification

Name

WSS-M2C931-C

Motorcraft® SAE 5W-50 Full Synthetic Motor
Oil(U.S.)
Motorcraft® SAE 5W-50 Full Synthetic Motor Oil /
Huile moteur synthétique SAE 5W-50 Motor-
craft®(Canada)
XO-5W50-QGT(U.S. & Canada)

Note:

Oil must meet specification

WSS-M2C931-C or use SAE 5W-50 oil that
meets API SN requirements.

Alternative Engine Oil for
Extremely Cold Climates

To improve engine cold start performance,
we recommend that you use the following
alternative engine oil in extremely cold
climates, where the ambient temperature
reaches -22.0°F (-30°C) or below.

Materials

Specification

Name

WSS-M2C937-A

Engine Oil - SAE 0W-40

E300343

351

Capacities and Specifications

Fuel Tank

Capacities

Quantity

Variant

15.5 gal (58.5 L)

All.

Grease

Materials

Specification

Name

ESB-M1C93-B

Motorcraft® Multi-Purpose Grease Spray(U.S.)
Motorcraft® Multi-Purpose Grease Spray / Graisse
tout usage en aérosol Motorcraft®(Canada)
XL-5-A(U.S. & Canada)

Hydraulic Brake System

Note:

We recommend you use DOT 4 LV

(Low Viscosity) High Performance Brake
Fluid meeting WSS-M6C65-A2
specifications or ISO 4925 Class 6
standards. If you use any fluid other than
the recommended fluid, it could cause
reduced brake performance and not meet
our performance standards. Keep brake fluid
clean and dry. Contamination with dirt,
water, petroleum products or other
materials could result in brake system
damage and possible failure.

Materials

Specification

Name

WSS-M6C65-A2

Motorcraft® DOT 4 LV High Performance Motor
Vehicle Brake Fluid(U.S.)
Motorcraft® DOT 4 LV High Performance Motor
Vehicle Brake Fluid / Liquide de frein automobile
haute performance DOT 4 LV Motorcraft®(Canada)
PM-20(U.S. & Canada)

Locks

352

Capacities and Specifications

Materials

Specification

Name

Motorcraft® Penetrating and Lock Lubricant(U.S.)
Motorcraft® Penetrating Fluid / Liquide dégrippant
Motorcraft®(Canada)
XL-1(U.S.)
CXC-51-A(Canada)

Rear Axle

Capacities

Quantity

Variant

1.6 qt (1.5 L)

All.

For complete refill of our limited slip axles, add 3.28 fl oz (97 ml) of Additive Friction

Modifier XL-3 or equivalent meeting specification EST-M2C118-A. Include this friction
modifier in the total fluid capacity. Our rear axles contain a synthetic lubricant that does
not require changing unless you submerge the axle in water.

Materials

Specification

Name

WSS-M2C942-A

Motorcraft® SAE 75W-85 Premium Synthetic
Hypoid Gear Lubricant(U.S.)
Motorcraft® SAE 75W-85 Premium Synthetic
Hypoid Gear Lubricant / Huile synthétique de haute
qualité pour engrenages hypoïdes SAE 75W-85
Motorcraft®(Canada)
XY-75W85-QL(U.S. & Canada)

EST-M2C118-A

Motorcraft® Additive Friction Modifier(U.S.)
Motorcraft® Additive Friction Modifier / Additif
modificateur de friction Motorcraft®(Canada)
XL-3(U.S.)
CXL-3(Canada)

353

Capacities and Specifications

Washer Reservoir

Capacities

Quantity

Variant

Fill as required.

All.

Materials

Specification

Name

WSS-M14P19-A

Motorcraft® Premium Windshield Wash Concen-
trate with Bitterant(U.S.)
Motorcraft® Premium Quality Windshield Washer
Fluid / Liquide lave-glace de haute qualité Motor-
craft®(Canada)
ZC-32-B2(U.S.)
CXC-37-F/M(Canada)

CAPACITIES AND
SPECIFICATIONS - 5.0L, MACH
1

Use oil and fluid that meets the defined
specification and viscosity grade.

If you do not use oil and fluid that meets
the defined specification and viscosity
grade, it could result in:
•

Component damage that your vehicle
warranty does not cover.

•

Longer engine cranking periods.

•

Increased emission levels.

•

Reduced engine performance.

•

Reduced fuel economy.

•

Reduced brake performance.

Air Conditioning System

WARNING:

The air conditioning

Capacities

Refrigerant Oil

Refrigerant

Variant

3.38 fl oz (100 ml)

19 oz (0.539 kg)

All.

354

Capacities and Specifications

Materials

Specification

Name

WSS-M17B21-A

R-1234yf Refrigerant(U.S.)
R-1234yf Refrigerant / Frigorigène R-1234yf(Canada)
YN-33-A(U.S.)
HS7Z-19B519-BA(Canada)

WSS-M2C300-A2

Motorcraft® R-1234yf Refrigerant PAG Oil(U.S.)
Motorcraft® R-1234yf Refrigerant PAG Oil / Huile
PAG pour frigorigène R-1234yf Motorcraft®(Canada)
YN-35(U.S. & Canada)

Manual Transmission

Capacities

Quantity

Variant

3.3 qt (3.1 L)

All.

Materials

Specification

Name

WSS-M2C938-AMERCON® LV,

Motorcraft® MERCON® LV Automatic Transmission
Fluid(U.S.)
Motorcraft® MERCON® LV Automatic Transmission
Fluid / Huile pour boîte automatique MERCON® LV
Motorcraft®(Canada)
XT-10-QLVC(U.S.)
CXT-10-LV6(Canada)

Engine Coolant

Capacities

Quantity

Variant

15.2 qt (14.4 L)

All.

355

Capacities and Specifications

Materials

Specification

Name

WSS-M97B57-A2

Engine Oil

E142732

An oil that displays this symbol conforms
to current engine, emission system and
fuel economy performance standards of
ILSAC.

Do not use supplemental engine oil
additives because they are unnecessary
and could lead to engine damage that your
vehicle warranty does not cover.

Capacities

Including the Oil Filter

Variant

10.0 qt (9.5 L)

All.

Materials

Specification

Name

WSS-M2C961-A1

356

Capacities and Specifications

Alternative Engine Oil for
Extremely Cold Climates

To improve engine cold start performance,

we recommend that you use the following
alternative engine oil in extremely cold
climates, where the ambient temperature
reaches -22.0°F (-30°C) or below.

Materials

Specification

Name

WSS-M2C963-A1

Engine Oil - SAE 0W-30 - Synthetic Blend

E240523

Fuel Tank

Capacities

Quantity

Variant

16.0 gal (60.55 L)

All.

Grease

Materials

Specification

Name

ESB-M1C93-B

Motorcraft® Multi-Purpose Grease Spray(U.S.)
Motorcraft® Multi-Purpose Grease Spray / Graisse
tout usage en aérosol Motorcraft®(Canada)
XL-5-A(U.S. & Canada)

357

Capacities and Specifications

Hydraulic Brake System

Note:

We recommend you use DOT 4 LV

Materials

Specification

Name

WSS-M6C65-A2

Locks

Materials

Specification

Name

Motorcraft® Penetrating and Lock Lubricant(U.S.)
Motorcraft® Penetrating Fluid / Liquide dégrippant
Motorcraft®(Canada)
XL-1(U.S.)
CXC-51-A(Canada)

Rear Axle

Capacities

Quantity

Variant

2.0 qt (1.9 L)

All.

For complete refill of our limited slip axles, add 3.28 fl oz (97 ml) of Additive Friction

358

Capacities and Specifications

Materials

Specification

Name

WSS-M2C942-A

EST-M2C118-A

Motorcraft® Additive Friction Modifier(U.S.)
Motorcraft® Additive Friction Modifier / Additif
modificateur de friction Motorcraft®(Canada)
XL-3(U.S.)
CXL-3(Canada)

Washer Reservoir

Capacities

Quantity

Variant

Fill as required.

All.

Materials

Specification

Name

WSS-M14P19-A

CAPACITIES AND
SPECIFICATIONS - 5.0L

Use oil and fluid that meets the defined
specification and viscosity grade.

If you do not use oil and fluid that meets
the defined specification and viscosity
grade, it could result in:
•

Component damage not covered by
the vehicle warranty.

•

Longer engine cranking periods.

•

Increased emission levels.

359

Capacities and Specifications

•

Reduced engine performance.

•

Reduced fuel economy.

•

Reduced brake performance.

Air Conditioning System

WARNING:

The air conditioning

Capacities

Refrigerant Oil

Refrigerant

Variant

3.38 fl oz (100 ml)

19 oz (0.539 kg)

All.

Materials

Specification

Name

WSS-M17B21-A

R-1234yf Refrigerant(U.S.)
R-1234yf Refrigerant / Frigorigène R-1234yf(Canada)
YN-33-A(U.S.)
HS7Z-19B519-BA(Canada)

WSS-M2C300-A2

Motorcraft® R-1234yf Refrigerant PAG Oil(U.S.)
Motorcraft® R-1234yf Refrigerant PAG Oil / Huile
PAG pour frigorigène R-1234yf Motorcraft®(Canada)
YN-35(U.S. & Canada)

Manual Transmission - MT82

Capacities

Quantity

Variant

2.7 qt (2.6 L)

All.

360

Capacities and Specifications

Materials

Specification

Name

WSS-M2C200-D2

Motorcraft® Dual Clutch Transmission Fluid(U.S.)
Motorcraft® Dual Clutch Transmission Fluid / Huile
pour boîtes embrayage double Motor-
craft®(Canada)
XT-11-QDC(U.S. & Canada)

Manual Transmission - 3160

Capacities

Quantity

Variant

3.3 qt (3.1 L)

Mach 1.

Materials

Specification

Name

WSS-M2C938-AMERCON® LV,

Engine Coolant

Capacities

Quantity

Variant

15.2 qt (14.4 L)

With Track Pack.

13.6 qt (12.88 L)

Without Track Pack.

361

Capacities and Specifications

Ford Mustang (2022 year). Manual in english - page 22
