Ford Maverick (2022 year). Manual in english

SWITCHING REAR VIEW CAMERA
DELAY ON AND OFF

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Press

Rear View Camera

4. Switch

Rear View Camera Delay

on or

off.

When shifting the transmission out of
reverse (R) and into any gear other than
park (P), the camera image remains in the
display until:

•

Your vehicle speed reaches
approximately 5 mph (8 km/h).

•

You shift your vehicle into park (P).

212

Rear View Camera

WHAT IS CRUISE CONTROL

Cruise control lets you maintain a set
speed without keeping your foot on the
accelerator pedal.

Requirements

Use cruise control when the vehicle speed
is greater than 20 mph (30 km/h).

SWITCHING CRUISE CONTROL
ON AND OFF

WARNING:

Do not use cruise

control on winding roads, in heavy traffic
or when the road surface is slippery. This
could result in loss of vehicle control,
serious injury or death.

The cruise controls are on the steering
wheel.

Switching Cruise Control On

E71340

Press the button to put the
system in standby mode.

Switching Cruise Control Off

E71340

Press the button when in
standby mode or switch the
ignition off.

Note:

When you switch cruise control off

the set speed clears.

SETTING THE CRUISE
CONTROL SPEED

WARNING:

When you are going

downhill, your vehicle speed could
increase above the set speed. The
system does not apply the brakes.

Drive to the speed you prefer.

Press the toggle button upward
or downward to set the current
speed.

Take your foot off the accelerator pedal.

Note:

The indicator changes color in the

information display.

Changing the Set Speed

Press and release the toggle
button upward to increase the
set speed in small increments.

Press and hold the toggle button upward
to accelerate. Release the button when
you have reached your preferred speed.

Press and release the toggle
button downward to decrease
the set speed in small

increments.

Press and hold the toggle button
downward to decelerate. Release the
button when you have reached your
preferred speed.

Note:

If you accelerate by pressing the

accelerator pedal, the set speed does not
change. When you release the accelerator
pedal, your vehicle returns to the speed that
you previously set.

213

Cruise Control

(If Equipped)

CANCELING THE SET SPEED

E280804

Press the button, or tap the
brake pedal to cancel the set
speed.

Note:

The system remembers the set

speed.

Note:

The system cancels if the vehicle

speed drops below 10 mph (16 km/h) under
the set speed when driving uphill.

RESUMING THE SET SPEED

Press the button.

CRUISE CONTROL
INDICATORS

E71340

Illuminates when you switch the
system on.

214

Cruise Control

(If Equipped)

HOW DOES ADAPTIVE CRUISE
CONTROL WITH STOP AND GO
WORK

Adaptive cruise control with stop and go
uses radar and camera sensors to maintain
a set gap between your vehicle and the
vehicle in front of you while following it to
a complete stop. Stop and go can also be
set to follow a vehicle directly in front of
you and adjust the set speed, while you are
at a complete stop.

ADAPTIVE CRUISE CONTROL
PRECAUTIONS

WARNING:

You are responsible for

controlling your vehicle at all times. The
system is designed to be an aid and does
not relieve you of your responsibility to
drive with due care and attention. Failure
to follow this instruction could result in
the loss of control of your vehicle,
personal injury or death.

WARNING:

Do not use adaptive

cruise control on winding roads, in heavy
traffic or when the road surface is
slippery. This could result in loss of
vehicle control, serious injury or death.

WARNING:

Pay close attention to

changing road conditions such as
entering or leaving a highway, on roads
with intersections or roundabouts, roads
without visible lanes of travel, roads that
are winding, slippery, unpaved, or steep
slopes.

WARNING:

The system is not a

crash warning or avoidance system.

WARNING:

Do not use the system

when towing a trailer that has
aftermarket electronic trailer brake
controls. Failure to follow this instruction
could result in the loss of control of your
vehicle, personal injury or death.

WARNING:

Do not use tire sizes

other than those recommended because
this can affect the normal operation of
the system. Failure to do so may result
in a loss of vehicle control, which could
result in serious injury.

WARNING:

Do not use the system

with a snow plow blade installed.

WARNING:

Do not use the system

in poor visibility, for example fog, heavy
rain, spray or snow.

When Following a Vehicle

WARNING:

When following a

vehicle that is braking, your vehicle does
not always decelerate quickly enough to
avoid a crash without driver intervention.
Apply the brakes when necessary. Failure
to follow this instruction could result in
personal injury or death.

Hilly Condition Usage

You should select a lower gear when the
system is active in situations such as
prolonged downhill driving on steep slopes,
for example in mountainous areas.

215

Adaptive Cruise Control

(If Equipped)

ADAPTIVE CRUISE CONTROL
LIMITATIONS

Sensor Limitations

WARNING:

On rare occasions,

detection issues can occur due to the
road infrastructures, for example bridges,
tunnels and safety barriers. In these
cases, the system may brake late or
unexpectedly. At all times, you are
responsible for controlling your vehicle,
supervising the system and intervening,
if required.

WARNING:

If the system

malfunctions, have your vehicle checked
as soon as possible.

WARNING:

Large contrasts in

outside lighting can limit sensor
performance.

WARNING:

The system only warns

of vehicles detected by the radar sensor.
In some cases there may be no warning
or a delayed warning. Apply the brakes
when necessary. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

The system may not

detect stationary or slow moving
vehicles below 6 mph (10 km/h).

WARNING:

The system does not

detect pedestrians or objects in the road.

WARNING:

The system does not

detect oncoming vehicles in the same
lane.

WARNING:

The system may not

operate properly if the sensor is blocked.
Keep the windshield free from
obstruction.

WARNING:

The sensor may

incorrectly track lane markings as other
structures or objects. This can result in
a false or missed warning.

E307893

The camera is mounted on the windshield
behind the interior mirror.

E307892

The radar sensor is in the lower grille.

Note:

You cannot see the sensor. It is

behind a fascia panel.

Note:

Keep the front of your vehicle free of

dirt, metal badges or objects. Vehicle front
protectors, aftermarket lights, additional
paint or plastic coatings could also degrade
sensor performance.

216

Adaptive Cruise Control

(If Equipped)

A message displays if something obstructs
the camera or the sensor. When something
blocks the sensor, the system cannot
detect a vehicle ahead and does not
function. See

Adaptive Cruise Control

– Information Messages

(page 223).

The radar sensor has a limited field of view.
It may not detect vehicles at all or detect
a vehicle later than expected in some
situations. The lead vehicle image does
not illuminate if the system does not
detect a vehicle in front of you.

Detection issues can occur:

E71621

When driving on a different line
than the vehicle in front.

With vehicles that edge into your
lane. The system can only detect
these vehicles once they move
fully into your lane.

There may be issues with the
detection of vehicles in front
when driving into and coming out
of a bend or curve in the road.

In these cases, the system may brake late
or unexpectedly.

If something hits the front end of your
vehicle or damage occurs, the
radar-sensing zone may change. This could
cause missed or false vehicle detection.

217

Adaptive Cruise Control

(If Equipped)

Optimal system performance requires a
clear view of the road by the
windshield-mounted camera.

Optimal performance may not occur if:

•

The camera is blocked.

•

There is poor visibility or lighting
conditions.

•

There are bad weather conditions.

SWITCHING ADAPTIVE
CRUISE CONTROL ON AND OFF

The cruise controls are on the steering
wheel. See

What Is Cruise Control

(page 213).

Switching Adaptive Cruise Control
On

E144529

Press the button to set the
system in standby mode.

The indicator, current gap setting and set
speed appear in the information display.

Switching Adaptive Cruise Control
Off

E144529

Press the button when the
system is in standby mode, or
switch the ignition off.

Note:

You erase the set speed when you

switch the system off.

ADAPTIVE CRUISE CONTROL
AUTOMATIC CANCELLATION

The system may cancel if:
•

The tires lose traction.

•

You apply the parking brake.

The system may cancel and set the parking
brake if:
•

You unbuckle the seatbelt and open
the driver door after you stop your
vehicle.

•

Your vehicle is at a stop continuously
for more than three minutes.

The system may deactivate or prevent
activating when requested if:
•

The vehicle has a blocked sensor.

•

The brake temperature is too high.

•

There is a failure in the system or a
related system.

SETTING THE ADAPTIVE
CRUISE CONTROL SPEED

Drive to the speed you prefer.

Press the toggle button upward
or downward to set the current
speed.

Take your foot off the accelerator pedal.

The indicator, current gap setting and set
speed appear in the instrument cluster
display.

E356418

A vehicle image illuminates if there is a
vehicle detected in front of you.

218

Adaptive Cruise Control

(If Equipped)

Note:

When the system is active, the

speedometer may vary slightly from the set
speed displayed in the instrument cluster
display.

Setting the Adaptive Cruise Speed
from a Complete Stop

Press the toggle button upward
or downward while keeping the
brake pedal fully pressed.

The set speed adjusts to 20 mph
(30 km/h).

The indicator, current gap setting and set
speed appear in the instrument cluster
display.

Note:

To activate adaptive cruise control

from a complete stop, stop your vehicle
behind another vehicle.

Note:

Your vehicle must be stopped behind

another vehicle to activate adaptive cruise
control from a complete stop.

Manually Changing the Set Speed

Press and release the toggle
button upward to increase the
set speed in small increments.

Press and hold the toggle button upward
to increase the set speed in large
increments. Release the button once the
set speed is equal to the speed you prefer.

Press and release the toggle
button downward to decrease
the set speed in small

increments.

Press and hold the toggle button
downward to decrease the set speed in
large increments. Release the button once
the set speed is equal to the speed you
prefer.

You can also press the accelerator or brake
pedal until you reach the speed you prefer.
Press the toggle button upward or
downward to select the current speed as
the set speed.

The system may apply the brakes to slow
the vehicle to the new set speed. The set
speed continuously displays in the
information display when the system is
active.

SETTING THE ADAPTIVE
CRUISE CONTROL GAP

Press the button to cycle
through the four gap settings.

E356418

The selected gap appears in the
instrument cluster display as shown by the
bars in the image.

Note:

The gap setting is time dependent

and therefore, the distance adjusts with your
vehicle speed.

Note:

It is your responsibility to select a gap

appropriate to the driving conditions.

219

Adaptive Cruise Control

(If Equipped)

Adaptive Cruise Control Gap Settings

Dynamic

Behavior

Gap Distance

Graphic

Display,

Bars Indic-

ated

Between

Vehicles

Sport.

Closest.

Normal.

Close.

Normal.

Medium.

Comfort.

Far.

Each time you switch the system on, it
selects the last chosen gap setting.

Following a Vehicle

When a vehicle ahead of you enters the
same lane or a slower vehicle is ahead in
the same lane, the vehicle speed adjusts
to maintain the gap setting.

Note:

When you are following a vehicle and

you switch on the turn signal, adaptive
cruise control may provide a small,
temporary acceleration to help you pass.

Your vehicle maintains a consistent gap
from the vehicle ahead until:
•

The vehicle in front of you accelerates
to a speed above the set speed.

•

The vehicle in front of you moves out
of the lane you are in.

•

You set a new gap distance.

The system applies the brakes to slow
down your vehicle to maintain a safe gap
distance from the vehicle in front of you.
The system only applies limited braking.
You can override the system by applying
the brakes.

Note:

The brakes may emit noise when

applied by the system.

If the system determines that its maximum
braking level is not sufficient, an audible
warning sounds, a message appears in the
instrument cluster display and an indicator
flashes when the system continues to
brake. Immediately apply the brakes
manually.

CANCELING THE SET SPEED

E280804

Press the button or tap the brake
pedal.

The set speed does not erase.

RESUMING THE SET SPEED

Press the button.

Your vehicle speed returns to the
previously set speed and gap setting. The
set speed displays continuously in the
information display when the system is
active.

Note:

Only use resume if you are aware of

the set speed and intend to return to it.

Resuming the Set Speed from a
Complete Stop

If your vehicle follows a vehicle to a
complete stop and remains stationary for
less than three seconds, your vehicle
accelerates from a stationary position to
follow the vehicle ahead.

If your vehicle follows a vehicle
to a complete stop and remains
stationary for more than three

seconds, press and release the button or
press the accelerator pedal to follow the
vehicle ahead.

220

Adaptive Cruise Control

(If Equipped)

OVERRIDING THE SET SPEED

WARNING:

If you override the

system by pressing the accelerator
pedal, it does not automatically apply
the brakes to maintain a gap from any
vehicle ahead.

When you press the accelerator pedal, you
override the set speed and gap distance.

Use the accelerator pedal to intentionally
exceed the set speed limit.

When you override the system, the green
indicator illuminates and the vehicle icon
does not appear in the instrument cluster
display.

The system resumes operation when you
release the accelerator pedal. The vehicle
speed decreases to the set speed, or a
lower speed if following a slower vehicle.

ADAPTIVE CRUISE CONTROL
INDICATORS

E144529

Illuminates when you switch
adaptive cruise control on. The
color of the indicator changes to

indicate the system status.

White indicates the system is on but
inactive.

Green indicates that you set the speed and
the system is active.

SWITCHING FROM ADAPTIVE
CRUISE CONTROL TO CRUISE
CONTROL

WARNING:

Normal cruise control

will not brake when your vehicle is
approaching slower vehicles. Always be
aware of which mode you have selected
and apply the brakes when necessary.

Use the instrument cluster display to select
the following:

Select

Settings

2. Select

Driver Assistance

3. Select

Cruise Control

4. Select

Normal

E71340

The cruise control indicator
replaces the adaptive cruise
control indicator if you select

normal cruise control. The gap setting
does not display, and the system does not
respond to lead vehicles. Automatic
braking remains active to maintain set
speed. The system remembers the last
setting when you start your vehicle.

LANE CENTERING

HOW DOES LANE CENTERING
WORK

Adaptive cruise control with lane centering
uses radar and camera sensors to help
keep your vehicle in the lane by applying
continuous assistance steering torque
input toward the lane center on highways.

Note:

The adaptive cruise control gap

setting operates normally.

221

Adaptive Cruise Control

(If Equipped)

LANE CENTERING PRECAUTIONS

WARNING:

Do not use the system

when towing a trailer. Failure to follow
this instruction could result in the loss of
control of your vehicle, personal injury or
death.

WARNING:

Do not use the system

if any changes or modifications to the
steering wheel have been made. Any
changes or modifications to the steering
wheel could affect the functionality or
performance of the system. Failure to
follow this instruction could result in the
loss of control of your vehicle, personal
injury or death.

Adaptive cruise control precautions apply
to lane centering unless stated otherwise
or contradicted by a lane centering
precaution. See

Adaptive Cruise Control

Precautions

(page 215).

LANE CENTERING
REQUIREMENTS

You must keep your hands on the steering
wheel at all times.

The system only activates when all of the
following occur:
•

You have adaptive cruise control with
stop and go on.

•

Lane centering assist is enabled in your
information and entertainment screen.
See

Switching Lane Centering On

and Off

(page 222).

•

You have your hands on the steering
wheel.

•

The system detects both lane
markings.

Note:

If it does not detect valid lane

markings, the system stays inactive until
valid markings are available.

LANE CENTERING LIMITATIONS

Adaptive cruise control limitations apply
to lane centering unless stated otherwise
or contradicted by a lane centering
limitation. See

Adaptive Cruise Control

Limitations

(page 216).

Lane Centering may not correctly operate
in any of the following conditions:
•

Your vehicle is not centered in the lane.

•

The lane is too narrow or wide.

•

The system does not detect at least
one lane marking or when lanes merge
or split.

•

Limited steering torque input is applied.

•

Areas under construction or new
infrastructure.

•

When modifications to the steering
system have been made.

•

When using a spare tire.

•

In high wind conditions.

Note:

The driving assistance torque is

limited and may not be sufficient for all
driving situations such as driving through
tight curves or driving through curves at high
speeds.

Note:

In exceptional conditions, the system

may deviate from the center line.

SWITCHING LANE CENTERING ON
AND OFF

You must keep your hands on the steering
wheel at all times.

The controls are on the steering wheel.

E262175

Press the button.

The indicator appears in the information
display. When the system is on, the color
of the indicator changes to indicate the
system status.

222

Adaptive Cruise Control

(If Equipped)

You can override the system at any time
by steering your vehicle.

Note:

The correct requirements must be

met before you can switch the system on.
See

Lane Centering Requirements

(page

222).

LANE CENTERING ALERTS

You must keep your hands on the steering
wheel at all times.

When the system is active and detects no
steering activity for a period of time, the
system alerts you to put your hands on the
steering wheel. If you do not react to the
warnings the system cancels and slows
your vehicle down to idle speeds while
maintaining steering control.

The system also alerts you if your vehicle
crosses lane markings without detected
steering activity.

Note:

The system may detect a light grip

or touch on the steering wheel as hands-off
driving.

LANE CENTERING AUTOMATIC
CANCELLATION

When an external condition cancels the
system, for example, no lane markings
available, a tone sounds and a message
appears in the instrument cluster display.

If your vehicle starts to slow
down, you must provide steering
input to the wheel and press and

release the button to regain full system
performance.

Automatic cancellation can also occur if:
•

The lane becomes too wide or too
narrow.

•

The system cannot detect valid lane
markings.

•

Lane markings cross over one another.

Note:

The system disables until the next

key cycle if your vehicle slows down due to
driver inactivity twice within a key cycle.

LANE CENTERING INDICATORS

E297977

Illuminates when you switch
lane centering on. The color of
the indicator changes to indicate

the system status.

Gray indicates the system is on but
inactive.

Green indicates the system is active and
applying steering torque assistance input
to keep your vehicle in the center of the
lane.

Amber with an audible tone and then gray
indicates a system automatic cancellation.

ADAPTIVE CRUISE CONTROL
– TROUBLESHOOTING

ADAPTIVE CRUISE CONTROL –
INFORMATION MESSAGES -
VEHICLES WITH: ADAPTIVE
CRUISE CONTROL WITH LANE
CENTERING

Note:

Depending on your vehicle options

and instrument cluster type, not all
messages display or are available.

Note:

The system could abbreviate or

shorten certain messages depending upon
which cluster type you have.

223

Adaptive Cruise Control

(If Equipped)

Action

Message

Make sure you return your hands to the steering wheel and

provide steering input.

Keep Hands on Steering

Wheel

Lane centering assist conditions exist preventing the system

from being available.

Lane Centering Assist

Not Available

Adaptive cruise control must be on before lane centering can

be switched on.

For Lane Centering

Assist to work Turn On

Adaptive Cruise

224

Adaptive Cruise Control

(If Equipped)

ADAPTIVE CRUISE CONTROL –
INFORMATION MESSAGES -
VEHICLES WITH: STOP AND GO

Note:

Depending on your vehicle options

and instrument cluster type, not all
messages display or are available.

Note:

The system could abbreviate or

shorten certain messages depending upon
which cluster type you have.

Action

Message

A malfunction is preventing the adaptive cruise from engaging.

Adaptive Cruise

Malfunction

Front Sensor Not Aligned

Contact an authorized dealer to have the radar checked for

proper coverage and operation.

Conditions exist preventing the system from being available.

Adaptive Cruise Not

Available

You have a blocked radar because of poor radar visibility due
to inclement weather or ice, mud, or water in front of the radar.

You can typically clean the sensor to resolve this.

Adaptive Cruise Not

Available Sensor

Blocked See Manual

Due to the nature of radar technology, it is possible to get a

blockage warning with no actual block. This happens, for

example, when driving in sparse rural or desert environments.
A false blocked condition either self clears, or clears after you

restart your vehicle.

You have selected normal cruise control. The system does

not brake or react to traffic.

Normal Cruise Active

Adaptive Braking Off

Displays when the adaptive cruise control is going to cancel

and you must take control.

Adaptive Cruise - Driver

Resume Control

Displays when the vehicle speed is too slow to activate the

adaptive cruise control and there is no lead vehicle in range.

Adaptive Cruise Speed

Too Low to Activate

225

Adaptive Cruise Control

(If Equipped)

WHAT IS DRIVE MODE
CONTROL

Your vehicle has various drive modes that
you can select for different driving
conditions. Depending on the drive mode
that you select, the system adjusts various
vehicle settings.

HOW DOES DRIVE MODE
CONTROL WORK

Selectable drive modes change various
electronic and mechanical settings within
your vehicle to tailor its performance and
driving characteristics to on-road or
off-road driving conditions. Steering feel
and effort, traction control, stability
control, chassis control, powertrain
response, transmission shift points and
four-wheel driveline settings alter to a
pre-determined setting depending upon
the drive mode that you select.

Note:

Your vehicle has diagnostic checks

that continuously monitor all systems for
proper operation. If a drive mode is
unavailable due to a system fault, your
vehicle defaults to normal mode.

SELECTING A DRIVE MODE

E355263

To select drive modes, use the console
mounted control.

Note:

Drive mode changes may not be

available when the ignition is off.

Note:

Button icon shown may vary from

your vehicle.

Note:

Selected drive mode displays in the

instrument cluster display.

DRIVE MODES

ECO

(If Equipped)

E295413

For efficient driving. This mode
helps deliver maximum fuel
efficiency and helps to increase

driving range.

MUD/RUTS

(If Equipped)

E296606

For off-road driving. This mode
enhances vehicle performance
to traverse muddy, rutted or

uneven terrains. Lower gears hold longer
in mud/ruts mode to maintain momentum
in soft conditions. Mud/ruts mode
optimizes braking for off-road conditions,
allowing quick path corrections and
minimized stopping distance when on
deformable surfaces.

Note:

This mode may help get your vehicle

unstuck from deep snow or sand.

Note:

Using mud/ruts mode on dry, hard

surfaces could produce some vibration,
driveline bind up, and potential excessive
tire and vehicle wear.

226

Drive Mode Control

NORMAL

E225310

For everyday driving. This mode
is a perfect balance of
excitement, comfort and

convenience. This is the default mode after
each ignition cycle.

SAND

(If Equipped)

E332185

For off-road driving. Sand mode
is for off-road driving on soft, dry
sand or deep conditions. Lower

gears hold longer in sand mode to maintain
momentum in soft conditions. Sand mode
optimizes braking for off-road conditions,
allowing quick path corrections and
minimized stopping distance when on
deformable surfaces.

Note:

Using sand mode on dry, hard

surfaces could produce some vibration,
driveline bind up, potential excessive tire
wear and vehicle wear.

Note:

Do not use on firm, slippery surfaces,

such as paved roads covered with snow or
ice or driving on packed snow. For slippery,
firm surfaces use slippery mode.

SLIPPERY

E295414

For less than ideal road
conditions such as snow or ice
covered roads. You can use this

mode for crossing terrain where loose, wet
or slippery materials covers a firm surface.
Slippery mode lowers throttle response
and optimizes shifting for slippery surfaces.

SPORT

(If Equipped)

E246593

For sporty driving with improved
performance handling and
response. This mode increases

throttle response and provides a sportier
steering feel. The powertrain system
provides improved gear holding, helping
your vehicle accelerate faster.

TOW/HAUL

E246592

For improved transmission
operation when towing a trailer
or a heavy load. This mode

moves upshifts to higher engine speeds to
reduce the frequency of transmission
shifting. This mode also provides engine
braking in all forward gears, which slows
your vehicle and assists you in controlling
your vehicle when descending a slope. The
amount of downshift braking provided
varies based on the amount you press the
brake pedal.

The system tunes the steering and
suspension to enhance driving comfort
when towing or carrying heavy loads.

DRIVE MODE CONTROL –
TROUBLESHOOTING

DRIVE MODE CONTROL –
WARNING LAMPS

E130458

Some drive modes reduce
traction and stability control
performance and the indicator

illuminates in the instrument cluster.

227

Drive Mode Control

Ford Maverick (2022 year). Manual in english - page 13
