FUEL AND REFUELING – INFORMATION MESSAGES - HYBRID ELECTRIC
VEHICLE (HEV)

Action

Message

An early reminder of a low fuel condition.

Fuel Level Low

The fuel fill inlet may not be properly closed.

Check Fuel Fill Inlet

The information message appears while the fuel system is
depressurizing with the fuel filler door closed. Wait for the fuel
system to depressurize and for the fuel filler door to unlatch.

Please wait for fuel door

to open

The information message appears when the fuel system has
depressurized and opened the fuel filler door. Fully open the
fuel filler door to refuel and fully close the fuel filler door when
refueling is complete.

Fuel Door Open

Your vehicle is equipped with a sealed fuel system that
requires the fuel filler door to be fully closed after refueling.
This warning message appears when the fuel filler door is ajar.
Please fully close the fuel filler door to avoid a "Check Engine"
Light.

Fuel door ajar Close fully

to avoid ""Check

Engine"" light

If you see this message and a "Check Engine" lamp illumin-
ates, please fully close the fuel filler door. The "Check Engine"
Light should clear within five seconds. If the "Check Engine"
light persists, please see your dealer.

The information message appears when the fuel system fails
to depressurize, or the fuel filler door fails to open. You could
have to use the fuel filler door manual override lever when
opening the fuel door.

Refuel Error See Manual

180

Fuel and Refueling

WHAT IS THE CATALYTIC
CONVERTER

The catalytic converter is part of your
vehicle's emissions system and filters
harmful pollutants from the exhaust gas.

CATALYTIC CONVERTER
PRECAUTIONS

WARNING:

Do not park, idle or

drive your vehicle on dry grass or other
dry ground cover. The emission system
heats up the engine compartment and
exhaust system, creating the risk of fire.

WARNING:

The normal operating

temperature of the exhaust system is
very high. Never work around or attempt
to repair any part of the exhaust system
until it has cooled. Use special care when
working around the catalytic converter.
The catalytic converter heats up to a very
high temperature after only a short
period of engine operation and stays hot
after the engine is switched off.

To avoid damaging the catalytic converter:

Do not crank the engine for more than
10 seconds at a time.

Do not run the engine with a spark plug
lead disconnected.

Do not push-start or tow-start your
vehicle. Use booster cables. See

Jump

Starting Precautions

 (page 280).

Use the correct fuel. See

Fuel and

Refueling

 (page 171).

Do not switch the ignition off when your
vehicle is moving.

Avoid running out of fuel.

Have the items listed in scheduled
maintenance information performed
according to the specified schedule.

Note:

Do not make any unauthorized

changes to your vehicle or engine. By law,
vehicle owners and anyone who
manufactures, repairs, or services a fleet of
vehicles are not permitted to intentionally
remove an emission control device or
prevent it from working.

CATALYTIC CONVERTER –
TROUBLESHOOTING

CATALYTIC CONVERTER –
WARNING LAMPS

Your vehicle has an on-board diagnostics
system that monitors the emission control
system. If any of the following warning
lamps illuminate, this may indicate that
the on-board diagnostics system has
detected an emission control system
malfunction.

Continuing to drive your vehicle may cause
reduced power or the engine to stop.
Failure to respond to a warning lamp may
cause damage that your vehicle Warranty
may not cover.  Have your vehicle checked
as soon as possible.

181

Catalytic Converter

WHAT IS THE HIGH VOLTAGE
BATTERY

The high voltage battery is a highly
sophisticated lithium ion battery system,
used to store electrified energy to power
the vehicle.

HIGH VOLTAGE BATTERY
PRECAUTIONS

WARNING:

This battery pack

should only be serviced by an authorized
electric vehicle technician. Improper
handling can result in personal injury or
death.

WARNING:

Apply the parking

brake, shift into park (P), switch the
ignition off and remove the key before
you open the hood or have any service
or repair work completed. If you do not
switch the ignition off, the engine could
restart at any time. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

Do not touch the

electronic ignition system parts after you
have switched the ignition on or when
the engine is running. The system
operates at high voltage. Failure to
adhere to this warning could result in
serious personal injury or death.

Your vehicle consists of various
high-voltage components and wiring.  All
of the high-voltage power flows through
specific wiring assemblies labeled as such
or covered with a solid orange convolute,
or orange striped tape, or both.  Do not
come in contact with these components.

Note:

Keep your hands and clothing clear

of the radiator cooling fan.

182

High Voltage Battery

AUTOMATIC TRANSMISSION
PRECAUTIONS

WARNING:

When your vehicle is

stationary, keep the brake pedal fully
pressed when shifting gears. Failure to
follow this instruction could result in
personal injury, death or property
damage.

WARNING:

Do not apply the brake

pedal and accelerator pedal
simultaneously. Applying both pedals
simultaneously for more than a few
seconds will limit power, which may
result in difficulty maintaining speed in
traffic and could lead to serious injury.

WARNING:

Apply the parking

brake, shift into park (P), switch the
vehicle off and remove the key or remote
control before you leave your vehicle.
Failure to follow this instruction could
result in personal injury or death.

Note:

You may not be able to shift out of

park (P) unless the intelligent access key is
inside your vehicle.

AUTOMATIC TRANSMISSION
POSITIONS

PARK (P)

WARNING:

Move the transmission

selector lever to park (P) only when your
vehicle is stationary.

This position locks the driveline and
prevents the wheels from turning.

The electric parking brake could apply if:

You shift to park (P) on a slope.

You shift to park (P) without the brake
pedal fully pressed.

Note:

A tone sounds if you attempt to exit

your vehicle without the transmission in park
(P).

Note:

You can start your vehicle in this

position.

Note:

You may not be able to shift out of

park (P) if the vehicle battery has no charge.
See

Crash and Breakdown Information

(page 278).

Note:

You may not be able to shift out of

park (P) if your vehicle blows a fuse. See

Fuses

 (page 290).

Note:

You may not be able to shift out of

park (P) unless the key or remote control is
inside your vehicle.

Note:

Your vehicle could shift into park (P)

if you attempt to exit your vehicle without
the transmission in park (P). See

How Does

Automatic Return to Park (P) Work

 (page

186).

Note:

A tone could sound when you select

park (P).

REVERSE (R)

WARNING:

Move the transmission

selector lever to reverse (R) only when
your vehicle is stationary and the engine
is at idle speed.

This position allows your vehicle to move
backward. Come to a complete stop
before shifting into and out of reverse (R).

183

Automatic Transmission

NEUTRAL (N)

WARNING:

In neutral (N) your

vehicle is free to roll.

This position allows your vehicle to roll
free. Hold the brake pedal down when in
this position.

Note:

You can start your vehicle in this

position.

DRIVE (D)

This position, drive (D), is the normal
driving position, and allows your vehicle to
move forward.

LOW (L)

This mode is for driving on steep slopes.
The transmission will hold low gear for
maximum torque driving uphill and
maximum engine braking driving downhill.
You can enter this mode at any vehicle
speed.

Note:

Prolonged use of this mode could

lower fuel economy. With your vehicle in
drive (D), press the L button to enter this
mode.

SHIFTING YOUR VEHICLE INTO
GEAR

E224178

Your vehicle has an electronic transmission
selector. The transmission selector is on
the center console. The gears are selected
by rotating the transmission selector to

PRNDL

.

Park (P)

Reverse (R)

Neutral (N)

Drive (D)

Low (L)

Putting your vehicle in gear:

1.

Fully press down the brake pedal.

2. Rotate the transmission selector to the

position you want and release.

3. The transmission position you select

illuminates.

4. Release the brake pedal and your

transmission remains in the selected
gear.

AUTOMATIC TRANSMISSION
POSITION INDICATORS

The instrument cluster displays the current
position.

184

Automatic Transmission

E341619

Note:

The position could illuminate on the

transmission selector.

TEMPORARY NEUTRAL MODE

WHAT IS TEMPORARY NEUTRAL
MODE

This mode keeps your vehicle in neutral
(N) when you switch your vehicle off. Use
this mode if you exit your vehicle or switch
your vehicle off at an automatic car wash.

Note:

Do not tow your vehicle in this mode.

Note:

Automatic return to park (P) is

delayed when your vehicle is in this mode.
See

What Is Automatic Return to Park

(P)

 (page 185).

TEMPORARY NEUTRAL MODE
LIMITATIONS

Your vehicle could shift to park (P) after
30 minutes, or when the vehicle battery
charge level is low. Prolonged use of this
mode can cause the vehicle battery to run
out of charge.

Do not tow your vehicle in this mode.
Failure to follow these instructions could
result in vehicle damage not covered by
the vehicle warranty.

ENTERING TEMPORARY
NEUTRAL MODE

1.

Power your vehicle on.

2. Bring your vehicle to a complete stop.

3. Press and hold the brake pedal.

4. Shift into neutral (N).

Note:

An instructional message appears.

5. Press the low (L) button.

Note:

A confirmation message appears

when your vehicle enters the mode.

6. Release the brake pedal.

Note:

Your vehicle is free to roll.

7.

Switch your vehicle off.

Note:

Do not tow your vehicle in this mode.

Note:

The neutral (N) indicator on the

transmission selector may flash in this
mode.

EXITING TEMPORARY NEUTRAL
MODE

1.

Press the brake pedal.

2. Shift into park (P), or power your

vehicle on and shift into drive (D) or
reverse (R).

AUTOMATIC RETURN TO
PARK (P)

WHAT IS AUTOMATIC RETURN TO
PARK (P)

Your vehicle shifts into park (P) if you
attempt to exit your vehicle without the
transmission in park (P).

185

Automatic Transmission

HOW DOES AUTOMATIC RETURN
TO PARK (P) WORK

Your vehicle shifts into park (P) when your
vehicle is stationary and any of the
following occur:

You switch the vehicle off.

You open the driver door with your
seatbelt unlatched.

You unlatch the driver seatbelt when
the driver door is open.

Note:

Do not use automatic return to park

(P) when your vehicle is moving, except in
an emergency. See

Stopping the Engine

When Your Vehicle is Moving

 (page 161).

AUTOMATIC RETURN TO PARK
(P) LIMITATIONS

Automatic return to park may not work if
the door ajar switch is malfunctioning.

See an authorized dealer if any of the
following occur:

Door ajar indicator does not illuminate
with the driver door open.

Door ajar indicator illuminates with the
driver door closed.

Transmission not in park message
appears with the driver door closed,
after you shift out of park (P).

GRADE ASSIST - HYBRID
ELECTRIC VEHICLE (HEV)

WHAT IS GRADE ASSIST

Provides additional grade braking with a
combination of engine motoring and
high-voltage battery charging to help
maintain vehicle speed when descending
a grade.

MANUAL PARK RELEASE -
GASOLINE

 (IF EQUIPPED)

WHAT IS MANUAL PARK RELEASE

Manual park release is used to move your
transmission from the park (P) position in
the event of an electrical malfunction or
emergency.

MANUAL PARK RELEASE
PRECAUTIONS

WARNING:

When doing this

procedure, you need to take the
transmission out of park (P) which
means your vehicle can roll freely. To
avoid unwanted vehicle movement,
always fully apply the parking brake prior
to doing this procedure. Use wheel
chocks if appropriate.

WARNING:

If the parking brake is

fully released, but the brake warning
lamp remains illuminated, the brakes
may not be working properly. Have your
vehicle checked as soon as possible.

WARNING:

Do not drive your

vehicle until you verify that the
stoplamps are working.

USING MANUAL PARK RELEASE

Activating the Manual Park
Release Cable

1.

Apply the parking brake.  See

Electric

Parking Brake

 (page 194).

Note:

If the vehicle battery is dead, for

example, no electrical power available, you
could need an external power source to
apply the parking brake.

186

Automatic Transmission

2. Remove the access cover with a tool

or key by prying the panel in the upper
corner.

E356795

3. Locate the manual park release tether

in the center console.

4. Switch the ignition on but do not start

your vehicle.

Note:

Do not activate the override lever

until you are in the driver seat.

Note:

Do not activate the manual park

release with the engine started.

5. Once in the driver seat, fully apply the

brake pedal and hold. Do not release.
Pull the tether straight rearward until
engaged. If done correctly, a message
appears in the instrument cluster.

Note:

There is an audible click when you

pull the tether back in the locked position.

6. With your foot still fully applied on the

brake pedal, disengage the parking
brake.  See

Electric Parking Brake

(page 194).

Note:

Your vehicle is now out of the park

(P) position and is free to roll.

7.

Your vehicle remains in neutral (N) for
emergency towing purposes.

8. Once it is safe to do so and there is no

risk that your vehicle will roll,
disconnect the negative battery cable
from the battery.

Returning Your Vehicle to Normal
Mode

E356796

1.

Once it is safe to do so, reconnect the
negative battery cable to the battery.

2. Apply the parking brake.  See

Electric

Parking Brake

 (page 194).

Note:

If the vehicle battery is dead, for

example, no electrical power available, you
could need an external power source to
apply the parking brake.

3. Once in the driver seat, fully apply the

brake pedal and hold, do not release.
Press the white, manual park release
button, and the manual park release
lever returns to its rested position.
Confirm that your vehicle is in the park
(P) position and that the instrument
cluster indicates park (P).

Note:

If the instrument cluster is not

displaying the park (P) position or the
instrument cluster displays an error
message, apply the parking brake before
exiting your vehicle. Contact an authorized
dealer for service.

187

Automatic Transmission

4. Reinstall the access cover.

AUTOMATIC TRANSMISSION
AUDIBLE WARNINGS

Transmission Not In Park (P)
Audible Warning

Sounds if you open the driver door before
shifting into park (P).

AUTOMATIC TRANSMISSION
– TROUBLESHOOTING

AUTOMATIC TRANSMISSION –
INFORMATION MESSAGES

Description

Message

Displays to confirm

that your vehicle

has entered 30min

neutral mode.

30min Neutral

mode enabled. Not

a tow mode

Displays to confirm

that your vehicle

has entered 30min

neutral mode. Press

brake to unlock

shifter.

30min Neutral

mode enabled. Not

a tow mode. Press

brake to unlock

shifter

Displays when you

shift into neutral

(N).

To stay in Neutral

when exiting

vehicle select L

button

Displays when you

shift into neutral

(N).

To stay in Neutral

when exiting

vehicle select M

button

The electric parking

brake is not fully

applied.

Park Brake Not

Applied

Description

Message

A reminder to shift

into park. In addi-

tion, this message

is typically after
reconnecting or

recharging the

battery until you

cycle the ignition to

the on mode.

Transmission Not in

Park

Displays when

there is a system

fault and the park
brake needs to be

depressed before

exiting the vehicle.

See your authorized

dealer.

SHIFT SYS FAULT

Apply Park Brake

Before Exiting the

Vehicle

The system has

detected a fault

that requires

service.  Have your

vehicle checked as

soon as possible.

Transmission

Malfunction Service

Now

188

Automatic Transmission

HOW DOES ALL-WHEEL DRIVE
WORK - EXCLUDING: FX4 OFF
ROAD

Your all-wheel drive vehicle is not intended
for off-road use. The AWD feature gives
your vehicle some limited off-road
capabilities in which driving surfaces are
relatively level, obstruction-free and
otherwise similar to normal on-road driving
conditions. Operating your vehicle in
conditions other than those, could subject
the vehicle to excess stress which might
result in damage which is not covered
under your warranty.

HOW DOES ALL-WHEEL DRIVE
WORK - FX4 OFF ROAD

All-wheel drive uses all four wheels to
power the vehicle. This increases traction,
enabling you to drive over terrain and road
conditions that a conventional two-wheel
drive vehicle cannot. The AWD system
turns on when needed and does not require
input from you.

ALL-WHEEL DRIVE
PRECAUTIONS

WARNING:

Do not become

overconfident in the ability of all-wheel
drive vehicles. Although an all-wheel
drive vehicle may accelerate better than
a two-wheel drive vehicle in low traction
situations, it won't stop any faster than
two-wheel drive vehicles. Always drive
at a safe speed.

ALL-WHEEL DRIVE
LIMITATIONS

Using different size tires other than the
provided spare could cause system
damage or disable the all-wheel drive
system.

189

All-Wheel Drive

 (If Equipped)

ALL-WHEEL DRIVE – TROUBLESHOOTING

ALL-WHEEL DRIVE – INFORMATION MESSAGES

Action

Message

The all-wheel drive system temporarily turns off to protect

itself from overheating.

AWD Temporarily

Disabled

The all-wheel drive system will resume normal function and

clear this message after driving a short distance with the road

tire re-installed or after the system cools.

AWD Restored

The all-wheel drive system temporarily turns off to protect

itself from overheating or if you are using the temporary spare

tire.

AWD OFF

The all-wheel drive system is not operating properly. If the

warning stays on or continues to come on, contact an

authorized dealer.

AWD Malfunction

Service Required

190

All-Wheel Drive

 (If Equipped)

BRAKE PRECAUTIONS

WARNING:

Driving your vehicle

with the warning lamp on is dangerous.
A significant decrease in braking
performance may occur. It may take you
longer to stop your vehicle. Have your
vehicle checked as soon as possible.
Driving extended distances with the
parking brake engaged can cause brake
failure and the risk of personal injury.

Wet brakes result in reduced braking
efficiency.  Gently press the brake pedal a
few times when driving from a car wash or
standing water to dry the brakes.

ANTI-LOCK BRAKING SYSTEM

ANTI-LOCK BRAKING SYSTEM
LIMITATIONS

The anti-lock braking system does not
eliminate the risk of crash when:

You drive too closely to the vehicle in
front of you.

Your vehicle is hydroplaning.

You take corners too fast.

The road surface is poor.

Note:

 If the system activates, the brake

pedal could pulse and travel further.
Maintain pressure on the brake pedal.

ANTI-LOCK BRAKING SYSTEM
INDICATORS

This system helps you maintain steering
control during emergency stops by keeping
the brakes from locking.

If it illuminates when you are
driving, this indicates a
malfunction.  Your vehicle

continues to have normal braking without
the anti-lock brake system function.  Have
your vehicle checked as soon as possible.

It also momentarily illuminates when you
switch the ignition on to confirm the lamp
is functional. If it does not illuminate when
you switch the ignition on, or begins to
flash at any time, have the system checked
by an authorized dealer.

E270480

It illuminates when you engage
the parking brake and the
ignition is on.

If it illuminates when your vehicle
is moving, make sure the parking
brake is disengaged.  If the

parking brake is disengaged, this indicates
low brake fluid level or a brake system
fault.  Have your vehicle checked as soon
as possible.

It also momentarily illuminates when you
switch the ignition on to confirm the lamp
is functional. If it does not illuminate when
you switch the ignition on, or begins to
flash at any time, have the system checked
by an authorized dealer.

BRAKE OVER ACCELERATOR

In the event the accelerator pedal
becomes stuck or entrapped, apply steady
and firm pressure to the brake pedal to
slow the vehicle and reduce engine power.
If you experience this condition, apply the
brakes and bring your vehicle to a safe
stop. Move the transmission to park (P),
switch the engine off and apply the parking
brake. Inspect the accelerator pedal for
any interference. If none are found and the
condition persists, have your vehicle towed
to the nearest authorized dealer.

191

Brakes

LOCATING THE BRAKE FLUID
RESERVOIR

See

Under Hood Overview

 (page 301).

CHECKING THE BRAKE FLUID

WARNING:

Do not use any fluid

other than the recommended brake fluid
as this will reduce brake efficiency. Use
of incorrect fluid could result in the loss
of vehicle control, serious personal injury
or death.

WARNING:

Only use brake fluid

from a sealed container. Contamination
with dirt, water, petroleum products or
other materials may result in brake
system damage or failure. Failure to
adhere to this warning could result in the
loss of vehicle control, serious personal
injury or death.

WARNING:

Do not allow the fluid

to touch your skin or eyes. If this
happens, rinse the affected areas
immediately with plenty of water and
contact your physician.

WARNING:

The brake system

could be affected if the brake fluid level
is below the

MIN

 mark or above the

MAX

mark on the brake fluid reservoir.

E170684

1.

Park your vehicle on a level surface.

2. Look at the brake fluid reservoir to see

where the brake fluid level is relative
to the

MIN

 and the

MAX

 marks on the

reservoir.

Note:

To avoid fluid contamination, the

reservoir cap must remain in place and fully
tight, unless you are adding fluid.

Only use fluid that meets our
specifications. See

Capacities and

Specifications

 (page 355).

BRAKE FLUID SPECIFICATION

See

Brake Fluid Specification

 (page 367).

192

Brakes

BRAKES –
TROUBLESHOOTING

BRAKES – WARNING LAMPS

If the ABS indicator illuminates
when you are driving, this
indicates a malfunction. Your

vehicle continues to have normal braking
without the anti-lock braking system
function. See an authorized dealer.

It also momentarily illuminates when you
switch the ignition on to confirm the lamp
is functional. If it does not illuminate when
you switch the ignition on, or begins to
flash at any time, have the system checked
by an authorized dealer.

E270480

The brake indicator momentarily
illuminates when you switch the
ignition on to confirm the lamp

is functional.  It may also illuminate when
you apply the parking brake and the
ignition is on.  If it illuminates when your
vehicle is moving, make sure the parking
brake is disengaged.  If the parking brake
is disengaged, this indicates low brake fluid
level or a brake system fault.  See an
authorized dealer.

BRAKES – FREQUENTLY ASKED
QUESTIONS

Is brake dust on the wheels normal?

Brake dust could accumulate on the
wheels, even under normal driving
conditions. Some dust is inevitable as
the brakes wear and does not
contribute to brake noise. See

Cleaning Wheels

 (page 320).

Will wet driving conditions effect my
braking abilities?

Wet brakes result in reduced braking
efficiency. Gently press the brake
pedal a few times when driving from
a car wash or standing water to dry the
brakes.

Is brake noise considered normal?

Occasional brake noise is normal. If a
metal-to-metal, continuous grinding
or continuous squeal sound is present,
the brake linings may be worn-out and
an authorized dealer should check
them. If the vehicle has continuous
vibration or shudder in the steering
wheel while braking, an authorized
dealer should check your vehicle.

When should you replace the brake
fluid?

Brake fluid absorbs water over time
which degrades the effectiveness of
the brake fluid. Change the brake fluid
at the specified intervals to prevent
degraded braking performance. See

Normal Scheduled Maintenance

(page 439).

193

Brakes

WHAT IS THE ELECTRIC
PARKING BRAKE

The electric parking brake is used to hold
your vehicle on slopes and flat roads.

APPLYING THE ELECTRIC
PARKING BRAKE

WARNING:

Always fully apply the

parking brake and make sure you shift
into park (P). Failure to follow this
instruction could result in personal injury
or death.

WARNING:

If you drive extended

distances with the parking brake applied,
you could cause damage to the brake
system.

WARNING:

The electric parking

brake does not operate if the vehicle
battery has run out of charge.

E267156

The electronic parking brake
switch is on the center console.

1.

Pull the switch up.

The red warning lamp flashes during
operation and illuminates when the parking
brake is applied.

Note:

You can apply the electric parking

brake when the power is off.

Note:

The electric parking brake could

apply when you shift into park (P). See

Park

(P)

 (page 183).

APPLYING THE ELECTRIC
PARKING BRAKE IN AN
EMERGENCY

You can use the electric parking brake to
slow or stop your vehicle in an emergency.

1.

Pull the switch up and hold it.

The electric parking brake continues to
slow your vehicle down unless you release
the switch.

The red warning lamp illuminates, a tone
sounds and the stoplamps turn on when
you use the electric parking brake in an
emergency.

Note:

Do not apply the electric parking

brake when your vehicle is moving, except
in an emergency.

MANUALLY RELEASING THE
ELECTRIC PARKING BRAKE

1.

Switch the ignition on.

2. Press and hold the brake pedal.

3. Push the switch down.

The red warning lamp turns off.

Pulling Away on a Hill When Towing a
Trailer

1.

Press and hold the brake pedal.

2. Pull the switch upward and hold it.

3. Shift into gear.

4. Press the accelerator pedal until engine

has developed sufficient torque to
prevent your vehicle from rolling down
the hill.

5. Release the switch and pull away in a

normal manner.

194

Electric Parking Brake

AUTOMATICALLY RELEASING
THE ELECTRIC PARKING
BRAKE

1.

Close the driver door.

2. Shift into gear.

3. Press the accelerator pedal and pull

away in a normal manner.

ELECTRIC PARKING BRAKE
AUDIBLE WARNING

Sounds when the parking brake is on and
your vehicle is moving. If the warning tone
continues after you have released the
parking brake, this indicates a malfunction.
Have your vehicle checked as soon as
possible.

RELEASING THE ELECTRIC
PARKING BRAKE IF THE
VEHICLE BATTERY HAS RUN
OUT OF CHARGE

See

Jump Starting Precautions

 (page

280).

ELECTRIC PARKING BRAKE –
TROUBLESHOOTING

ELECTRIC PARKING BRAKE –
WARNING LAMPS

Brake System

E270480

It illuminates red when you apply
the parking brake and your
vehicle is on.  If the lamp flashes
when the parking brake has been
released, this indicates the
parking brake system requires

service.   Have your vehicle checked as
soon as possible.

Note:

Lamps may vary depending on region.

Electric Parking Brake

E146190

When the lamp illuminates
yellow, it indicates a malfunction
in the electric parking brake.

Have your vehicle checked as soon as
possible.

195

Electric Parking Brake















Content      ..     9      10      11      12     ..
