WHAT IS THE POWER OUTLET

The power outlet can power devices that
use a household plug.

POWER OUTLET
PRECAUTIONS

WARNING:

Do not keep electrical

devices plugged in the power point
whenever the device is not in use. Do not
use any extension cord with the 110 volt
AC power point, since it will defeat the
safety protection design. Doing so may
cause the power point to overload due
to powering multiple devices that can
reach beyond the 400 watt load limit
and could result in fire or serious injury.

WARNING:

Do not keep electrical

devices plugged in the power point
whenever the device is not in use. Power
points power up during remote start.

POWER OUTLET LIMITATIONS

Devices may exceed the power rating
shown the device label when plugged in.
Unplug the device and switch the ignition
on and off to reset the system.

You should not use the power outlet for
these types of electric devices:
•

Cathode ray tube type televisions.

•

Motor loads, for example vacuum
cleaners, electric saws and other
electric power tools, or
compressor-driven refrigerators.

•

Measuring devices which process
precise data, for example medical
equipment or measuring equipment.

•

Other appliances requiring an
extremely stable power supply, for
example microcomputer-controlled
electric blankets or touch sensor
lamps.

LOCATING THE POWER
OUTLET

The power outlet could be on the
instrument panel, the rear of the center
console or in the pickup bed.

POWER OUTLET INDICATORS

The power outlet indicator illuminates to
let you know the status of the system.

Description

Indicator Status

When the indicator

light is on, the

outlet is providing

power.

When the indicator

light is off, there is

no power to the

outlet.

Off

When the indicator
light is flashing, the

outlet is in a fault

mode.

Flashing

Fault mode

The power outlet temporarily turns off
power if the device exceeds the watt limit.

Unplug your device.

2. Switch your vehicle off to let the

system cool and reset the fault mode.

149

Power Outlet - Vehicles With: 110V Power Outlet

WHAT IS THE POWER OUTLET

The power outlet can power devices using
a 12 V outlet adapter.

POWER OUTLET
PRECAUTIONS

When you switch the vehicle on, you can
use the socket to power 12 V appliances
with a maximum current rating of 15 A. Do
not use the power point over the vehicle
capacity of 12 V DC 180 W or a fuse could
blow. Do not plug in any device that
supplies power to the vehicle through the
power points. This could result in damage
to vehicle systems. Do not hang any
accessory from the accessory plug. Always
keep the power point caps closed when
not in use. Do not insert objects other than
an accessory plug into the power point.

To prevent the battery from running out of
charge:
•

Do not use the power point longer than
necessary when the vehicle is off.

•

Do not leave devices plugged in
overnight or when you park your vehicle
for extended periods.

LOCATING THE POWER
OUTLET

Power outlets may be in the following
locations:
•

On the lower instrument panel.

•

Inside the center console.

•

On the front of the center console.

•

On the rear of the center console.

•

On the passenger side floor panel.

•

3rd row on the quarter trim panels.

Auxiliary Power Access

The set of wires located in the auxiliary
power access makes aftermarket
customization easier with a prewired 12V
circuit. The circuit is individually fused for
12V connection of electrical accessories.

E357738

151

Power Outlet - Vehicles With: 12V Power Outlet

WHAT IS THE WIRELESS
ACCESSORY CHARGER

The wireless accessory charger allows you
to charge one compatible Qi wireless
charging device on the charging area.

WIRELESS ACCESSORY
CHARGER PRECAUTIONS

WARNING:

Wireless charging

devices can affect the operation of
implanted medical devices, including
cardiac pacemakers. If you have any
implanted medical devices, we
recommend that you consult with your
physician.

Tests on this equipment show that it
complies with part 18 of the FCC Rules.
•

This equipment generates, uses and
can radiate radio frequency energy and
may cause harmful interference to
radio communications. There is no
guarantee that the interference will not
occur in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, please consult the dealer.

•

This product is not end-user
serviceable.

WARNING:

Changes or

modifications not expressively approved
by the party responsible for compliance
could void the user's authority to operate
the equipment. The term "IC:" before the
radio certification number only signifies
that Industry Canada technical
specifications were met.

This device complies with Industry Canada
licence-exempt RSS standard(s).
Operation is subject to:
•

This device may not cause interference.

•

This device must accept any
interference, including interference that
may cause undesired operation of the
device.

Keep the charging area clean and remove
foreign objects prior to charging a device.

Do not place items with a magnetic strip
or radio-frequency identification chip, for
example passports, parking tickets,
transportation passes or credit cards, near
the charging area when charging a device.
Damage may occur to the magnetic strip
or radio-frequency identification chip.

Do not place metal objects, for example
remote controls, coins and candy
wrappers, on or near the charging area
when charging a device. Metal objects may
heat up and degrade the charging
performance, in addition to causing
interruptions in charging.

Note:

During charging, the device and the

charger could heat up, this is normal. If the
battery gets hotter than usual, the device
may stop charging.

LOCATING THE WIRELESS
ACCESSORY CHARGER

E297549

The charging area is on the
center console or in the media
bin below the instrument panel.

CHARGING A WIRELESS
DEVICE

Place the device on the center of the
charging surface with the charging side
down. The charging stops after your device
reaches a full charge.

152

Wireless Accessory Charger

(If Equipped)

You can use the charger when the vehicle
is in accessory mode, when the vehicle is
running, or when SYNC is on.

Displays on the status bar when
wireless charging is in progress.

Note:

The charging performance may be

affected if your device is in a case. It may be
necessary to remove the case to wirelessly
charge your device.

Note:

Software and firmware updates may

affect device compatibility, including the
use of unofficial software or firmware. You
should verify charging functionality with your
specific devices in-vehicle.

WIRELESS ACCESSORY CHARGER – TROUBLESHOOTING

WIRELESS ACCESSORY CHARGER – INFORMATION MESSAGES

Description

Behavior

Message

This message appears when

wireless charging begins.

Message on screen display

or pop-up window.

Wireless Charger Active

The system stops charging

your device if the system

detects the phone is

misaligned, or a foreign

metal object is on the char-

ging surface.

Pop-up window.

Phone misaligned or object

between phone and charger
detected. Correct the condi-

tion to resume charging.

153

Wireless Accessory Charger

(If Equipped)

CUP HOLDERS

CUP HOLDER PRECAUTIONS

WARNING:

Use caution when

stowing items or hot drinks in the cup
holders. Items could become loose or
spill during hard braking, acceleration or
crashes. Failure to follow this instruction
could result in personal injury.

UNDER SEAT STORAGE

LOCATING THE UNDER SEAT
STORAGE COMPARTMENT

E355885

Lift the front of the rear seat cushion.

GLASSES HOLDER

LOCATING THE GLASSES HOLDER

(If Equipped)

E324912

The glasses holder is in the overhead
console. Press near the rear edge of the
door to open.

PICKUP BED STORAGE

(IF

EQUIPPED)

LOCATING THE PICKUP BED
STORAGE

E354607

OPENING THE PICKUP BED
STORAGE

To open the pickup bed storage, turn the
latch.

154

Storage

(If Equipped)

STARTING AND STOPPING
THE ENGINE – PRECAUTIONS

WARNING:

Extended idling at high

engine speeds can produce very high
temperatures in the engine and exhaust
system, creating the risk of fire or other
damage.

WARNING:

Do not park, idle or

drive your vehicle on dry grass or other
dry ground cover. The emission system
heats up the engine compartment and
exhaust system, creating the risk of fire.

WARNING:

Do not start the engine

in a closed garage or in other enclosed
areas. Exhaust fumes are toxic. Always
open the garage door before you start
the engine. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

Do not use starting

fluid, for example ether, in the air intake
system. Such fluid could cause
immediate explosive damage to the
engine and possible personal injury.

WARNING:

Exhaust leaks may

result in entry of harmful and potentially
lethal fumes into the passenger
compartment. If you smell exhaust
fumes inside your vehicle, have your
vehicle inspected immediately. Do not
drive if you smell exhaust fumes.

The powertrain control system meets all
Canadian interference-causing equipment
standard requirements regulating the
impulse electrical field or radio noise.

If you stop your vehicle and leave the
engine idling for long periods, we
recommend that you do one of the
following:
•

Open the windows at least 1 in
(2.5 cm).

•

Set your climate control to outside air.

IGNITION SWITCH

(IF EQUIPPED)

E252522

///

Switching the Ignition Off

Turn the key to position

Switching the Ignition to
Accessory Mode

Turn the key to position

. Electrical

accessories, for example the radio, operate
without the engine running.

Switching the Ignition On

Turn the key to position

. All electrical

circuits and accessories are operational
and the warning lamps and indicators
illuminate.

156

Starting and Stopping the Engine

Starting the Engine

Turn the key to position

III

. Release the

key when the engine starts.

PUSH BUTTON IGNITION
SWITCH

(IF EQUIPPED)

E321258

Switching the Ignition Off

When the ignition is on or in accessory
mode, press the push button ignition
switch once without your foot on the brake
pedal.

Switching the Ignition to
Accessory Mode

When the ignition is off, press the push
button ignition switch once without your
foot on the brake pedal.

All electrical circuits and accessories are
operational and the warning lamps and
indicators illuminate.

Note:

Your vehicle has a battery saver

feature that shuts your vehicle off when it
detects a certain amount of battery drain,
or after approximately 30 minutes of
inactivity in accessory mode.

Starting the Engine

With the transmission in park (P), press
the brake pedal and press the push button
ignition switch. An indicator light on the
button illuminates when the ignition is on
and when the engine starts.

Note:

The system may not function if the

passive key is close to metal objects or
electronic devices, for example keys or a cell
phone.

Note:

A valid key must be inside your

vehicle to switch the ignition on and start
the engine.

STARTING THE ENGINE

STARTING A GASOLINE ENGINE -
VEHICLES WITHOUT: PUSH
BUTTON START

Before starting your vehicle, check the
following:
•

Make sure that the headlamps and
electrical accessories are off.

•

Make sure that the parking brake is on.

•

Make sure that the transmission is in
park (P).

Fully press the brake pedal.

Note:

Do not touch the accelerator pedal.

E322354

2. Turn the key to position

III

Note:

The engine may continue cranking

for up to 15 seconds or until it starts.

Note:

The engine takes longer to start at

lower temperatures. It may crank for several
seconds when very cold.

157

Starting and Stopping the Engine

STARTING A GASOLINE ENGINE -
VEHICLES WITH: PUSH BUTTON
START

Before starting your vehicle, check the
following:
•

Make sure that the headlamps and
electrical accessories are off.

•

Make sure that the parking brake is on.

•

Make sure that the transmission is in
park (P).

Fully press the brake pedal.

Note:

Do not touch the accelerator pedal.

E321258

2. Press the push button ignition switch.

Note:

The engine may continue cranking

for up to 15 seconds or until it starts.

Note:

The engine takes longer to start at

lower temperatures. It may crank for several
seconds when very cold.

STARTING A HYBRID ELECTRIC
VEHICLE SYSTEM - VEHICLES
WITHOUT: PUSH BUTTON START

Before starting your vehicle, check the
following:
•

Make sure that the headlamps and
electrical accessories are off.

•

Make sure that the parking brake is on.

•

Make sure that the transmission is in
park (P).

Fully press the brake pedal.

Note:

Do not touch the accelerator pedal.

E322354

2. Turn the key to position

III

Note:

The green ready indicator illuminates

letting you know that your vehicle is ready
for driving. Since your vehicle is equipped
with a silent key start, the engine may not
start when your vehicle starts.

When the engine starts for the first time
on your drive, the idle speed increases, this
helps to warm up the engine. If the engine
idle speed does not slow down, have your
vehicle checked by an authorized dealer.

STARTING A HYBRID ELECTRIC
VEHICLE SYSTEM - VEHICLES
WITH: PUSH BUTTON START

Before starting your vehicle, check the
following:
•

Make sure the headlamps and
electrical accessories are off.

•

Make sure the parking brake is on.

•

Make sure the transmission is in park
(P).

Note:

Do not touch the accelerator pedal.

Fully press the brake pedal.

E321258

2. Press the push button ignition switch.

Note:

The green ready indicator illuminates

letting you know that your vehicle is ready
for driving. Since your vehicle is equipped
with a silent key start, the engine may not
start when your vehicle starts.

158

Starting and Stopping the Engine

The system does not function if:
•

The passive key frequencies are
jammed.

•

The key battery has no charge.

RESTARTING THE ENGINE AFTER
STOPPING IT

The system allows you to start the engine
within 10 seconds of switching it off, even
if it does not detect a valid passive key.

Within 10 seconds of switching the engine
off, fully press the brake pedal and press
the push button ignition switch. After 10
seconds, you can no longer start the engine
if the system does not detect a valid
passive key.

When you start the engine, it remains
running until you press the push button
ignition switch, even if your vehicle does
not detect a valid passive key. If you open
and close a door when the engine is
running, the system searches for a valid
passive key.

ENGINE BLOCK HEATER

(IF

EQUIPPED)

ENGINE BLOCK HEATER
PRECAUTIONS

WARNING:

Failure to follow engine

block heater instructions could result in
property damage or serious personal
injury.

WARNING:

Do not use your heater

with ungrounded electrical systems or
two-pronged adapters. There is a risk of
electrical shock.

WARNING:

Do not fully close the

hood, or allow it to drop under its own
weight when using the engine block
heater. This could damage the power
cable and may cause an electrical short
resulting in fire, injury and property
damage.

We recommend that you do the following
for a safe and correct operation:
•

Use a 16-gauge outdoor extension cord
that is product certified by
Underwriter’s Laboratory (UL) or
Canadian Standards Association
(CSA). This extension cord must be
suitable for use outdoors, in cold
temperatures, and be clearly marked
Suitable for Use with Outdoor
Appliances. Do not use an indoor
extension cord outdoors. This could
result in an electric shock or become a
fire hazard.

•

Use as short an extension cord as
possible.

•

Do not use multiple extension cords.

•

Make sure that when in operation, the
extension cord plug and engine block
heater cord plug connections are free
and clear of water. This could cause an
electric shock or fire.

•

If the engine block heater cord is under
the hood, do not remove the wiring
from its original location. Do not close
the hood on the extension wiring.

•

Park your vehicle in a clean area, clear
of combustible materials.

•

Firmly connect the engine block heater
cord and the extension cord.

159

Starting and Stopping the Engine

•

Check the extension cord for heat
anywhere when the system has been
operating for approximately 30
minutes.

•

Unplug and properly stow the system
before starting and driving your vehicle.
The protective cover seals the
terminals of the engine block heater
cord plug when not in use.

•

Check the engine block heater system
for proper operation before winter.

HOW DOES THE ENGINE BLOCK
HEATER WORK

The engine block heater warms the engine
coolant. This allows the climate control
system to quickly respond. The equipment
includes a heater element installed in the
engine block and a wire harness. You can
connect the system to a grounded
220-240 volt AC electrical source.

Note:

The engine block heater is most

effective when outdoor temperatures are
below 0°F (-18°C).

USING THE ENGINE BLOCK
HEATER

Make sure the receptacle terminals are
clean and dry prior to use. Clean them with
a dry cloth if necessary.

The heater uses 0.4 to 1.0 kilowatt-hours
of energy per hour of use. The system does
not have a thermostat. It achieves
maximum temperature after
approximately three hours of operation.
Using the engine block heater longer than
three hours does not improve system
performance and unnecessarily uses
electricity.

STOPPING THE ENGINE

STOPPING THE ENGINE WHEN
YOUR VEHICLE IS STATIONARY -
VEHICLES WITHOUT: PUSH
BUTTON START

Shift into park (P).

2. Apply the parking brake.

3. Wait until the engine reaches idle

speed.

E322405

4. Turn the key to position

STOPPING THE ENGINE WHEN
YOUR VEHICLE IS STATIONARY -
VEHICLES WITH: PUSH BUTTON
START

Shift into park (P).

2. Apply the parking brake.

3. Wait until the engine reaches idle

speed.

E321258

4. Press the push button ignition switch.

160

Starting and Stopping the Engine

STOPPING THE ENGINE WHEN
YOUR VEHICLE IS MOVING -
VEHICLES WITHOUT: PUSH
BUTTON START

WARNING:

Switching off the

engine when your vehicle is still moving
results in a significant decrease in
braking assistance. Higher effort is
required to apply the brakes and to stop
your vehicle. A significant decrease in
steering assistance could also occur. The
steering does not lock, but higher effort
could be required to steer your vehicle.
When you switch the ignition off, some
electrical circuits, for example airbags,
also turn off. If you unintentionally switch
the ignition off, shift into neutral (N) and
restart the engine.

E322405

Turn the key to position

2. Shift into neutral and use the brakes to

bring your vehicle to a safe stop.

3. Shift into park (P).

4. Apply the parking brake.

STOPPING THE ENGINE WHEN
YOUR VEHICLE IS MOVING -
VEHICLES WITH: PUSH BUTTON
START

WARNING:

Switching off the

engine when your vehicle is still moving
results in a significant decrease in
braking assistance. Higher effort is
required to apply the brakes and to stop
your vehicle. A significant decrease in

steering assistance could also occur. The
steering does not lock, but higher effort
could be required to steer your vehicle.
When you switch the ignition off, some
electrical circuits, for example airbags,
also turn off. If you unintentionally switch
the ignition off, shift into neutral (N) and
restart the engine.

E321258

Press and hold the push button ignition
switch until the engine stops, or press
it three times within two seconds.

2. Shift into neutral and use the brakes to

bring your vehicle to a safe stop.

3. Shift into park (P).

4. Apply the parking brake.

AUTOMATIC ENGINE STOP

(IF

EQUIPPED)

WHAT IS AUTOMATIC ENGINE
STOP

Automatic engine stop is a feature that
switches the engine off if it has been idling
for an extended period to help you save
fuel.

161

Starting and Stopping the Engine

HOW DOES AUTOMATIC ENGINE
STOP WORK

Automatic engine stop turns the engine
off. The ignition also turns off in order to
save battery power. Before the engine
shuts down, a message appears in the
information display showing a timer
counting down. If you do not intervene
within 30 seconds, the engine shuts down.
Another message appears in the
information display to inform you that the
engine has shut down in order to save fuel.
Start your vehicle as you normally do.

SWITCHING AUTOMATIC ENGINE
STOP ON AND OFF

Using the information display controls
on the steering wheel, select

Settings

2. Select

Vehicle Settings

3. Switch

30min Max Idle

on or off.

Note:

You cannot permanently switch off

the automatic shutdown. If you switch it
off, it turns on each time you switch the
ignition on.

OVERRIDING AUTOMATIC ENGINE
STOP

You can stop the engine shutdown, or reset
the timer, at any point before the
30-second countdown has expired by
doing any of the following:
•

Pressing the brake pedal or accelerator
pedal.

•

Pressing the

RESET

button

during the countdown.

Note:

You cannot permanently switch off

the automatic engine shutdown feature.
When you switch it off temporarily, it turns
on at the next ignition cycle.

STARTING AND STOPPING
THE ENGINE –
TROUBLESHOOTING

STARTING AND STOPPING THE
ENGINE – WARNING LAMPS

Malfunction Indicator Lamp

If it illuminates when the engine
is running, the on-board
diagnostics system is detecting

a malfunction of the vehicle emission
control system.

If it flashes, engine misfire could be
occurring. Increased exhaust gas
temperatures could damage the catalytic
converter or other vehicle components.
Avoid heavy acceleration and deceleration,
and have your vehicle checked as soon as
possible.

Powertrain Warning Lamp

If it illuminates when the engine
is running, this indicates a
powertrain or four-wheel drive

fault. If it flashes when you are driving,
immediately reduce the vehicle speed.
Avoid heavy acceleration and deceleration,
and have your vehicle checked as soon as
possible.

If both lamps illuminate when the engine
is running, stop your vehicle as soon as it
is safe to do so. Continuing to drive your
vehicle could cause reduced power or the
engine to stop. Switch the ignition off and
attempt to restart the engine. Have your
vehicle checked as soon as possible.

162

Starting and Stopping the Engine

STARTING AND STOPPING THE ENGINE – INFORMATION MESSAGES

Action

Message

Displays if you exceed the starting time limit. You cannot
attempt to start the engine for 15 minutes. If you cannot start
the engine after 15 minutes passes, have your vehicle imme-
diately checked.

Cranking Time Exceeded

Displays if you are unable to start your vehicle with a correctly
coded key. The system has detected a fault that requires
service. Have your vehicle checked as soon as possible.

Starting System Fault

Displays if the system does not detect a valid passive key.

No Key Detected

163

Starting and Stopping the Engine

Ford Maverick (2022 year). Manual in english - page 9
