USING THE INSTRUMENT
CLUSTER DISPLAY CONTROLS

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

The controls are on the steering wheel.

E250032

Return button.

OK button.

Menu button.

Return Button

Press to go back or exit a menu.

Button

Press to make a selection.

Toggle Buttons

Press the toggle up or down button to
scroll through menu items.

Status Indicator

E204495

Menu items with a check box
indicate a feature's status. A
check in the box indicates the

feature is on, and unchecked indicates the
feature is off.

INSTRUMENT CLUSTER
DISPLAY MAIN MENU -
VEHICLES WITH: 4.2 INCH
SCREEN

Menu Item

Trip 1

MyView

Driver Assist.

Audio

Phone

Settings

116

Instrument Cluster Display

INSTRUMENT CLUSTER
DISPLAY MAIN MENU -
VEHICLES WITH: 6.5 INCH
SCREEN

Menu Item

Select Screens

Audio

Phone

Settings

Display Setup

CUSTOMIZING THE
INSTRUMENT CLUSTER
DISPLAY - VEHICLES WITH: 4.2
INCH SCREEN

Using the information display controls
on the steering wheel, select

MyView

2. Press the menu button.

3. Select a screen.

4. Press the

button.

CUSTOMIZING THE
INSTRUMENT CLUSTER
DISPLAY - VEHICLES WITH: 6.5
INCH SCREEN

Adding Screens Using Select
Screens

You can select various screens to show on
the instrument cluster display.

Select

Select Screens

2. Use the controls on the steering wheel

to highlight a screen to add.

3. Press the

button.

Note:

The amount of screens you can add

is limited. If the selected screen does not
appear, you must deselect items from the
menu.

Select Screens

Calm screen

Fuel economy

Trip 1

Trip 2

This trip

EV Coach

Tire pressure

Intelligent AWD

Off-Road

Trailer light check

Seatbelts

Auto StartStop

Now playing

Note:

Some options may appear slightly

different or not at all if items are optional.

Configuring Gauges

You can select which values your
speedometer shows in the instrument
cluster display.

Select

Display Setup

2. Select a speed unit to display.

117

Instrument Cluster Display

PERSONALIZED SETTINGS

CHANGING THE INSTRUMENT
CLUSTER DISPLAY LANGUAGE -
VEHICLES WITH: 4.2 INCH
SCREEN

You can change the language using the
instrument cluster display.

Select

Settings

and press the menu

button.

2. Select

Display

3. Select

Language

4. Select a language.

CHANGING THE INSTRUMENT
CLUSTER DISPLAY LANGUAGE -
VEHICLES WITH: 6.5 INCH
SCREEN

You can change the language using the
instrument cluster display.

Select

Display Setup

2. Select

Language

3. Select a language.

Note:

Available languages vary by region.

CHANGING THE MEASURE UNIT -
VEHICLES WITH: 4.2 INCH
SCREEN

You can change the measurement unit
using the instrument cluster display.

Select

Settings

and press the menu

button.

2. Select

Display

3. Select

Measurement Unit

4. Select a measurement unit.

CHANGING THE MEASURE UNIT -
VEHICLES WITH: 6.5 INCH
SCREEN

You can change the measurement unit
using the instrument cluster display.

Select

Display Setup

2. Select

Measurement Units

3. Select a measurement unit.

CHANGING THE TEMPERATURE
UNIT - VEHICLES WITH: 4.2 INCH
SCREEN

You can change the temperature unit using
the instrument cluster display.

Select

Settings

and press the menu

button.

2. Select

Display

3. Select

Temperature Unit

4. Select a temperature unit.

CHANGING THE TEMPERATURE
UNIT - VEHICLES WITH: 6.5 INCH
SCREEN

You can change the temperature unit using
the instrument cluster display.

Select

Display Setup

2. Select

Temperature units

3. Select a temperature unit.

CHANGING THE TIRE PRESSURE
UNIT - VEHICLES WITH: 4.2 INCH
SCREEN

You can change the tire pressure unit using
the instrument cluster display.

Select

Settings

and press the menu

button.

2. Select

Display

3. Select

Tire Pressure

118

Instrument Cluster Display

4. Select a tire pressure unit.

CHANGING THE TIRE PRESSURE
UNIT - VEHICLES WITH: 6.5 INCH
SCREEN

You can change the tire pressure unit using
the instrument cluster display.

Select

Display Setup

2. Select

Tire pressure

3. Select a pressure unit.

FUEL ECONOMY DISPLAY -
GASOLINE

An instant fuel economy gauge is provided
along with average fuel economy. Average
fuel economy is continuously averaged
since the last reset.

Note:

Press and hold the

button on the

controls on the steering wheel to reset your
average fuel economy.

FUEL ECONOMY DISPLAY -
HYBRID ELECTRIC VEHICLE
(HEV)

An instant fuel economy gauge is provided
along with average fuel economy. Average
fuel economy is continuously averaged
since the last reset.

When the gasoline engine is off the instant
fuel economy gauges is replaced with an
electric driving message.

Note:

Press and hold the

button on the

controls on the steering wheel to reset your
average fuel economy.

EV COACH - HYBRID ELECTRIC
VEHICLE (HEV)

EV coach can help you get the most out of
your vehicle's electric driving capabilities.

Note:

EV coach is a selectable screen. See

Customizing the Instrument Cluster
Display

(page 117).

When you are accelerating or maintaining
speed you see a blue or white solid bar
indicating vehicle power. You may also see
a blue rectangular box which shows the
power level at which the engine turns on.

•

When the power level is within the box,
the color of the bar is blue. This means
you are in electric operation and the
engine is off.

•

When the power level is outside of the
box, the color of the bar is white. This
means you are in hybrid operation with
a combination of the electric motor
and the engine providing vehicle power.

When you are decelerating with either your
foot off the accelerator pedal or on the
brake pedal, a green or white solid bar
displays indicating the power being used
to slow down your vehicle. You may also
see a green rectangular box which shows
the amount of power that can be
recaptured by the regenerative braking
system and returned to the high voltage
battery.

•

When the power level is within the box,
the color of the bar will be all green.
This means that the regenerative
braking system is being used to
efficiently slow your vehicle down and
return the maximum percentage of
energy to the high voltage battery.

•

When the power level is outside of the
box, then the bar is white. This means
both the regenerative braking system
and conventional braking system are
being used.

119

Instrument Cluster Display

WHAT IS BRAKE COACH -
HYBRID ELECTRIC VEHICLE
(HEV)

The brake coach appears after your vehicle
has come to a stop. It coaches you to brake
in a manner that maximizes the amount
of energy returned through the
regenerative braking system.

The percent displayed is an indication of
the regenerative braking efficiency with
100% representing the maximum amount
of energy recovered. You can switch brake
coach on or off in the settings menu. See

Instrument Cluster Display Main Menu

(page 117).

WHAT IS THE TRIP SUMMARY
- HYBRID ELECTRIC VEHICLE
(HEV)

The trip summary displays upon shutting
off your vehicle. The values are cumulative
since you last started your vehicle.

The information shown is the same as the
This Trip screen. See

Trip Data

(page 121).

120

Instrument Cluster Display

ACCESSING THE TRIP
COMPUTER - VEHICLES WITH:
4.2 INCH SCREEN

Use the instrument cluster display
controls to navigate the home screen.

2. Select the trip screen.

3. Press the menu button on the steering

wheel.

4. Select

Trip 1

Trip 2

ACCESSING THE TRIP
COMPUTER - VEHICLES WITH:
6.5 INCH SCREEN

Using Select Screens

Use the instrument cluster display
controls to navigate the home menu.

2. Select

Select Screens

3. Use the control on the steering wheel

to navigate the menu. See

Customizing the Instrument Cluster
Display

(page 117).

Using the Home Screen

Once the screens have been added, use
the instrument cluster display controls on
the steering wheel to view each trip screen.

RESETTING THE TRIP
COMPUTER

Use the instrument cluster display
controls to navigate the home screen.

2. Select the trip screen you want to reset.

3. Press and hold the

button until the

system reset confirmation appears.

RESETTING THE INDIVIDUAL
TRIP VALUES - VEHICLES
WITH: 4.2 INCH SCREEN

Use the instrument cluster display
controls to navigate the home screen.

2. Select the trip screen.

3. Press the menu button on the steering

wheel.

4. Select

Reset Individual Values

5. Select a trip value to reset.

6. Press and hold the

button until the

system reset confirmation appears.

CONFIGURING THE TRIP
COMPUTER - VEHICLES WITH:
4.2 INCH SCREEN

Use the instrument cluster display
controls to navigate the home screen.

2. Select the trip screen.

3. Press the menu button on the steering

wheel.

4. Select

Configure View

5. Select values to display.

TRIP DATA

Trip 1 and 2

Provides trip timer, trip average fuel
economy and total trip distance traveled.
For hybrid vehicles, the trip also shows the
distance traveled on electric power only.

Note:

Trip 1 and 2 are selectable screens.

See

Accessing the Trip Computer

(page

121).

121

Trip Computer

WHAT IS REMOTE START

The system allows you to remotely start
your vehicle and to adjust the interior
temperature according to the settings that
you chose.

REMOTE START
PRECAUTIONS

WARNING:

Do not start the engine

in a closed garage or in other enclosed
areas. Exhaust fumes are toxic. Always
open the garage door before you start
the engine. Failure to follow this
instruction could result in personal injury
or death.

REMOTE START LIMITATIONS

Remote start does not work under the
following conditions:

•

The alarm horn is sounding.

•

The hood is open.

•

The transmission is not in park (P).

•

The ignition is on.

•

The battery voltage is below the
minimum operating voltage.

Note:

Do not use remote start if your fuel

level is low.

Note:

You can use remote start with

FordPass. See

Connecting the Vehicle to

a Wi-Fi Network

(page 369).

ENABLING REMOTE START

Using the information display controls
on the steering wheel, select

Settings

2. Select

Vehicle Settings

3. Select

Remote Start

4. Switch

System

on.

Note:

To use remote start, make sure that

the modem is enabled. See

Enabling and

Disabling the Modem

(page 369).

REMOTELY STARTING AND
STOPPING THE VEHICLE

Remotely Starting the Vehicle

E138623

Press the button on the remote
control.

E138625

Within three seconds, press the
button twice on the remote
control.

Note:

You can also use the FordPass App

to start the vehicle.

Note:

The turn signals flash twice.

Note:

The parking lamps turn on when the

vehicle is running.

Note:

The horn sounds if the system fails

to start.

Note:

All other vehicle systems remain off

when you have remotely started the vehicle.

Note:

The vehicle remains secured when

you have remotely started the vehicle. A
valid key must be inside your vehicle to
switch the ignition on and drive your vehicle.

Remotely Stopping the Vehicle

E138625

Within three seconds, press the
button twice on the remote
control.

EXTENDING THE REMOTE
START DURATION

To extend the remote start duration during
remote start, do the following:

123

Remote Start

(If Equipped)

E138623

Press the button on the remote
control.

E138625

Within three seconds, press the
button on the remote control.

Within three seconds, press the

button again.

If the duration is set to 15 minutes, the
duration extends by another 15 minutes.
This provides a total of 30 minutes.

Note:

Remote start can only be extended

once.

Note:

A maximum of two remote starts, or

one remote start with an extension, are
allowed. To reset the restart procedure
switch the vehicle to on, then to off.

REMOTE START REMOTE
CONTROL INDICATORS

Remote Control Feedback

An LED on the remote control provides
status feedback of remote start or stop
commands.

Status

LED

Remote start

successful.

Solid green.

Remote stop

successful.

Solid red.

Request failed or

status not received.

Blinking red.

Status incomplete.

Blinking green.

REMOTE START SETTINGS -
VEHICLES WITH: SYNC 3

SWITCHING CLIMATE CONTROL
AUTO MODE ON AND OFF

Using the information display controls
on the steering wheel, select

Settings

2. Select

Vehicle Settings

3. Select

Remote Start

4. Select

Climate Control

5. Switch

Auto

on.

Note:

If you switch the auto mode on, the

system attempts to heat or cool the interior
to 72°F (22°C).

Note:

When you remotely start the engine,

you cannot adjust the climate control
settings until you start your vehicle.

Note:

When you switch the ignition on, the

climate control system returns to the last
used settings.

Note:

The heated windshield, heated rear

window, heated mirrors, heated seats and
heated steering wheel could turn on in cold
weather. Ventilated seats could turn on in
hot weather.

SWITCHING CLIMATE CONTROL
LAST SETTINGS ON AND OFF

Using the information display controls
on the steering wheel, select

Settings

2. Select

Vehicle Settings

3. Select

Remote Start

4. Select

Climate Control

5. Switch

Last Settings

on.

Note:

If you switch the last settings on, the

system remembers the last used settings.

124

Remote Start

(If Equipped)

SWITCHING THE HEATED SEAT
SETTINGS ON AND OFF

Using the information display controls
on the steering wheel, select

Settings

2. Select

Vehicle Settings

3. Select

Remote Start

4. Select

Seats

5. Select

Auto

Off

Note:

If you switch the heated seat settings

on, the heated seats turn on during cold
weather.

Note:

You cannot adjust the heated seat

settings when you have remotely started
the engine.

SWITCHING THE HEATED
STEERING WHEEL SETTINGS ON
AND OFF

Using the information display controls
on the steering wheel, select

Settings

2. Select

Vehicle Settings

3. Select

Remote Start

4. Select

Seats and Wheel

5. Select

Auto

Off

Note:

If you switch the heated steering

wheel settings on, the heated steering wheel
turn on during cold weather.

Note:

You cannot adjust the heated

steering wheel settings when you have
remotely started the engine.

SETTING THE REMOTE START
DURATION

You can set a duration for the engine to
run.

Using the information display controls
on the steering wheel, select

Settings

2. Select

Vehicle Settings

3. Select

Remote Start

4. Select

Duration

125

Remote Start

(If Equipped)

IDENTIFYING THE CLIMATE
CONTROL UNIT

E352781

Depending on your vehicle options, the
controls could look different than what you
see here.

SWITCHING CLIMATE
CONTROL ON AND OFF

Press the button.

SWITCHING RECIRCULATED
AIR ON AND OFF

Press the button to recirculate
air currently in the passenger
compartment.

Note:

Recirculated air may turn off

automatically, or prevent you from switching
on in all air flow modes except MAX A/C to
reduce the risk of fogging. Recirculation may
also turn on and off automatically in various
air distribution control combinations to
improve heating or cooling efficiency.

SWITCHING AIR
CONDITIONING ON AND OFF

Press the button.

Note:

Under certain conditions, the air

conditioning compressor could continue to
operate after you switch air conditioning off.

SWITCHING MAXIMUM
DEFROST ON AND OFF

Press the button.

Air flows through the windshield air vents,
and the blower motor adjusts to the
highest speed.

You can also use this setting to defog and
clear the windshield of a thin covering of
ice.

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Note:

The heated wiper park also turns on

when you select maximum defrost.

SWITCHING MAXIMUM
COOLING ON AND OFF

Press the button.

Note:

When you switch maximum cooling

off, air conditioning remains on.

SWITCHING THE HEATED
WIPER PARK ON AND OFF

(IF

EQUIPPED)

E266189

When you switch the heated
mirrors on, the heated wiper park
also turns on.

SWITCHING THE HEATED
MIRRORS ON AND OFF

(IF

EQUIPPED)

E266189

Press the button.

126

Climate Control - Vehicles With: Dual Automatic Temperature

Control (DATC)

SETTING THE BLOWER MOTOR
SPEED

Note:

Lights on the control illuminate to

indicate the blower motor speed.

Note:

When you switch the blower motor

off, air conditioning turns off and the
windows could fog up.

SETTING THE TEMPERATURE

E244115

Turn the control on the left-hand side of
the climate control to set the left-hand
temperature.

Note:

This control also sets the right-hand

side temperature when you switch off dual
zone mode.

Turn the control on the right-hand side of
the climate control to set the right-hand
temperature.

DIRECTING THE FLOW OF AIR

Directing Air to the Windshield Air
Vents

Press the button.

Directing Air to the Instrument
Panel Air Vents

E244097

Press the button.

Directing Air to the Footwell Air
Vents

Press the button.

AUTO MODE

SWITCHING AUTO MODE ON AND
OFF

Press the button to switch auto
mode on. Repeatedly press the
button to adjust auto mode.

Note:

When you switch auto mode on,

lights on the blower motor control do not
illuminate to indicate the blower motor
speed.

Adjust the blower motor control or air
distribution control to switch auto mode
off.

AUTO MODE INDICATORS

The indicators are on the Auto Mode
button.

127

Climate Control - Vehicles With: Dual Automatic Temperature

Control (DATC)

SWITCHING DUAL MODE ON AND
OFF

E265280

Press the button.

CLIMATE CONTROL –
TROUBLESHOOTING

CLIMATE CONTROL –
FREQUENTLY ASKED QUESTIONS

Why is the volume of air to the rear
passenger compartment limited ?

Objects may obstruct the air direction
to the rear passenger compartment.
Make sure objects have not been
placed under the front seats.

Why is the volume of air from the air
vents reduced?

The air intake area at the base of the
windshield could be obstructed. Make
sure the air intake area is free from any
snow, ice or leaves.

What are the recommended settings
for heating the interior?

Auto mode on and instrument panel
and side air vents fully open.

How can I quickly heat the interior?

Select the highest blower motor
speed, highest temperature and direct
the air to the footwell air vents.

What are the recommended settings
for cooling the interior?

Auto mode on.

How can I quickly cool the interior?

Switch maximum cooling on, switch
recirculated air on and drive with the
windows open until you feel cold air
through the air vents.

How can I reduce the humidity build-up
inside my vehicle?

Do not drive with the system off or
with recirculated air on.

How can I defog the side windows?

Switch maximum defrost on.

How can I defog or clear the windshield
of thin ice?

Switch maximum defrost on.

Why do I feel air from the footwell air
vents regardless of the air
distribution?

This is normal operation. You may feel
a small amount of air from the
footwell air vents regardless of the air
distribution.

What happens if I switch auto mode on
when the outside temperature and
in-vehicle temperature is high?

The system temporarily selects
recirculated air to maximize cooling.

What happens if I switch auto mode on
when the outside temperature is low
and the engine is cold?

Air is directed to the windshield and
the outer instrument panel air vents.

129

Climate Control - Vehicles With: Dual Automatic Temperature

Control (DATC)

IDENTIFYING THE CLIMATE
CONTROL UNIT

E352780

Depending on your vehicle options, the
controls could look different than what you
see here.

SWITCHING CLIMATE
CONTROL ON AND OFF

Press the button.

SWITCHING RECIRCULATED
AIR ON AND OFF

Press the button to recirculate
air currently in the passenger
compartment.

Note:

Recirculated air may turn off

SWITCHING AIR
CONDITIONING ON AND OFF

Press the button.

Note:

Under certain conditions, the air

conditioning compressor could continue to
operate after you switch air conditioning off.

SWITCHING MAXIMUM
DEFROST ON AND OFF

Press the button.

Air flows through the windshield air vents,
and the blower motor adjusts to the
highest speed.

You can also use this setting to defog and
clear the windshield of a thin covering of
ice.

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Note:

The heated wiper park also turns on

when you select maximum defrost.

SWITCHING MAXIMUM
COOLING ON AND OFF

Press the button.

Note:

When you switch maximum cooling

off, air conditioning remains on.

SWITCHING THE HEATED
WIPER PARK ON AND OFF

(IF

EQUIPPED)

E266189

When you switch the heated
mirrors on, the heated wiper park
also turns on.

SWITCHING THE HEATED
MIRRORS ON AND OFF

(IF

EQUIPPED)

E266189

Press the button.

130

Climate Control - Vehicles With: Electronic Automatic Temperature

Control (EATC)

SETTING THE BLOWER MOTOR
SPEED

E317606

Turn the control.

Note:

Lights on the control illuminate to

indicate the blower motor speed.

Note:

When you switch the blower motor

off, air conditioning turns off and the
windows could fog up.

SETTING THE TEMPERATURE

E244115

Turn the control on the left-hand side of
the climate control to set the left-hand
temperature.

Turn the control on the right-hand side of
the climate control to set the right-hand
temperature.

DIRECTING THE FLOW OF AIR

Directing Air to the Windshield Air
Vents

Press the button.

Directing Air to the Instrument
Panel Air Vents

E244097

Press the button.

Directing Air to the Footwell Air
Vents

Press the button.

AUTO MODE

SWITCHING AUTO MODE ON AND
OFF

Press the button to switch auto
mode on. Repeatedly press the
button to adjust auto mode.

Note:

When you switch auto mode on,

lights on the blower motor control do not
illuminate to indicate the blower motor
speed.

Adjust the blower motor control or air
distribution control to switch auto mode
off.

131

Climate Control - Vehicles With: Electronic Automatic Temperature

Control (EATC)

Ford Maverick (2022 year). Manual in english - page 7
