ENGINE SPECIFICATIONS - 6.2L

6.2L V8 Engine

Engine

378

Cubic inches

Minimum 87 octane

Required fuel

1-5-4-8-6-3-7-2

Firing order

Coil on plug

Ignition system

0.041-0.047 in (1.04-1.20 mm)

Spark plug gap

9.8:1

Compression ratio

Drivebelt Routing

E163761

ENGINE SPECIFICATIONS - 6.8L

6.8L V10 Engine

Engine

413

Cubic inches

Minimum 87 octane

Required fuel

1-6-5-10-2-7-3-8-4-9

Firing order

Coil on plug

Ignition system

0.039 - 0.043 in (1.00 - 1.10 mm)

Spark plug gap

9.2:1

Compression ratio

411

Drivebelt Routing

6.8L Engines with A/C

E163762

6.8L Engines without A/C

E163763

ENGINE SPECIFICATIONS - 6.7L DIESEL

Drivebelt Routing

6.7L Diesel

Engine

406

Cubic inches

Low Sulfur Diesel up to B20

Required fuel

1-3-7-2-6-5-4-8

Firing order

16.2:1

Compression ratio

Single Alternator

E224819

Dual Alternator

E224820

412

MOTORCRAFT PARTS - 6.2L

Motorcraft Part number

Component

FA-1883

Air filter element

FL-820-S

Oil filter

BXT-65-650

Battery (XL)

BXT-65-750

Battery (all except XL)

SP-526

Spark plugs-platinum

WW-2242

Windshield wiper blade

FT-187

Transmission fluid filter

FP-79

Cabin air filter

For scheduled maintenance, we recommend Motorcraft® replacement parts available
at your Ford dealer or at fordparts.com. These parts meet or exceed Ford Motor Company’s
specifications and are engineered for your vehicle. Use of other parts may impact vehicle
performance, emissions and durability. Your warranty may be void for any damage related
to use of other parts.

If a Motorcraft® oil filter is not available, use an oil filter that meets industry performance
specification SAE/USCAR-36.

For spark plug replacement, contact an authorized dealer. Replace the spark plugs at the
appropriate intervals.  See Scheduled Maintenance (page 567).

413

MOTORCRAFT PARTS - 6.8L

Motorcraft Part number

Component

FA-1883

Air filter element.

FL-820-S

Oil filter.

BXT-65-650

Battery (XL).

BXT-65-750

Battery (all except XL).

SP-509

Spark plugs-platinum.

WW-2242

Windshield wiper blade.

FP-79

Cabin air filter.

For scheduled maintenance, we recommend Motorcraft® replacement parts available
at your Ford dealer or at fordparts.com. These parts meet or exceed Ford Motor Company’s
specifications and are engineered for your vehicle. Use of other parts may impact vehicle
performance, emissions and durability. Your warranty may be void for any damage related
to use of other parts.

If a Motorcraft® oil filter is not available, use an oil filter that meets industry performance
specification SAE/USCAR-36/USC-D.

For spark plug replacement, contact an authorized dealer. Replace the spark plugs at the
appropriate intervals.  See Normal Scheduled Maintenance (page 570).
