Fuel System - General Information - Fuel
System—1.8L Duratorq-TDCi (Lynx)
Diesel/2.0L Duratorq-TDCi (DW) Diesel
S-MAX/Galaxy 2006.5 (02/2006-)
Diagnosis and Testing
Special Tool(s)
General Equipment
Inspection and Verification
1. 1. Verify the customer concern.
2. 2. Visually inspect for obvious signs of mechanical or electrical damage.
Visual Inspection Chart
3. 3. If an obvious cause for an observed or reported concern is found, correct the cause
(if possible) before proceeding to the next step.
4. 4. If the cause is not visually evident, verify the symptom and refer to the Symptom
Chart.
Symptom Chart
Hand Pressure Pump with Adapter Kit
310-110
Worldwide Diagnostic System (WDS)
Mechanical
Electrical
Fuel level
Fuel leak(s)
Fuel line(s)
Fuel filler cap
Fuel filter
Fuel tank
Fuel tank ventilation hose
Fuel tank filler hose
Wiring harness
Electrical connector(s)
Fuel level sensor
Symptom
Possible Sources
Action
Engine cranks
but does not
start
Fuel charging and
controls.
*
Vehicles with 1.8L Duratorq-TDCi (Kent) diesel
engine.
REFER to:
Fuel Charging and Controls
(303-04D
Fuel Charging and Controls - 1.8L Duratorq-TDCi
(74kW/100PS) - Lynx/1.8L Duratorq-TDCi
(92kW/125PS) - Lynx, Diagnosis and Testing).
Vehicles with 2.0L Duratorq-TDCi (DW) diesel
engine.
REFER to:
Fuel Charging and Controls
(303-04E
Fuel Charging and Controls - 2.0L Duratorq-TDCi
(85kW/115PS) - DW/2.0L Duratorq-TDCi
(100kW/136PS) - DW/2.0L Duratorq-TDCi
(103kW/140PS) - DW, Emission Requirements:
Stage IV, Diagnosis and Testing).
*
Air ingress into the
fuel lines.
*
Vehicles with 1.8L Duratorq-TDCi (Kent) diesel
engine. GO to Pinpoint Test
A.
Vehicles with 2.0L
Duratorq-TDCi (DW) diesel engine. GO to Pinpoint
*
